TOA SPEAKER SYSTEM
POWERED MONITOR SPEAKER
SM-25M
GENERAL DESCRIPTION
The TOA SM-25M is a self-powered personal monitor system
designed around our popular SM-25A powered monitor
system. The SM-25M has a built-in 25-watt power amp, a 5-
inch woofer and a 2-inch tweeter. An automatic compression
circuit is provided to ensure maximum headroom and speaker
component protection.
The system features a mic level XLR input on the front panel, as
well as a rotary volume control, a tone control, and headphone
monitoring jack. Add to that a back panel with both a line level
1/4" input jack and a bridging jack for chaining additional
speakers, and the SM-25M becomes a portable PA monitor
system....just plug in a microphone and go. A unique bracket
allows the system to be mounted to mic stands, and even to
walls in permanent installations. The cast aluminum enclosure
is rugged enough to withstand even the roughest handling. The
SM-25M combines high performance, durability, and in-
novative design in portable package with a wide range of
applications.

FEATURES 1. Built-in 25 watts power amplifier
2. Automatic compression circuit
3. Mic level XLR input
4. Tonecontrol
5. Rotary volume control
6. Headphone monitoring jack
7. Unique bracket
SPECIFICATIONS
Enclosure:
Speakers:
Sound pressure level:
Frequency response:
Amplifier:
Power requirements:
Powerconsumption:
Ratedoutputpower:
Mic input sensitivity:
Mic input impedance:
Mic input terminal:
Sealed type Lineinputsensitivity:
-20dB (77.5mV) or +4dB (1.23V)
2 way speaker of 12cm (5") and switchable
5cm (2") diameter Line input impedance:
8k ohms, set at -20dB, 40k ohms
88dB(1W/1m)
at +4dB
90Hz~20kHz
Transformerisolatedbalance
Tonecontrol(highcut):
-15dB at 10kHz
AC mains Lineinputterminal: Locked 1/4" jack
30W Bridgeterminal: Locked 1/4" jack
25W Finish:
-55dB (1.38mV)
Frontpanel: Metal Punched Net
Open (For use with nominal 50-ohm
Body: Cast Aluminum (Black)
to 250-ohm) electronically balanced Weight: Approx. 6.3kg (13.9 Ibs.)
XLR Type, NC3F
Dimensions: 325 (W) x 170 (H) x 140 (D)mm
12.8" (W) x 6.7" (H) x 5.5" (D)
ARCHITECT’S AND
The speaker system shall be a “powered” personal monitor and cymbal stand shafts. The cast aluminum enclosure shall
ENGINEER’S
speaker system, with a built-in 25 watts power amplifier, and be rugged enough to withstand even the roughest handling.
oneeachofa2-inch(5cm)tweeterand5-inch(12cm)woofer. In addition to the various specifications stated above, the
SPECIFICATIONS
An automatic compression circuit shall provide maximum speakersystemshallmeetthefollowingoverallperformance
headroom while insuring the reliability of the speaker
and specifications criteria: sound pressure level of 88dB
components. The front panel shall provide for a mic level (1W/1m);frequencyresponseof90Hzto20kHz;ratedoutput
XLR input, rotary volume control, tone control, and head-
power of 25W; front grill of black metal punching net;
phone monitoring jack. On the back panel both a line level
dimensions of 6.7" (170mm) high, 128" (325mm) wide, 5.5"
1/4" input jack and a bridging jack for chaining additional
(140mm) deep; weight of 13.9 Ibs(6.3kg). The speaker
speakers shall be also provided. A unique bracket shall system shall be a TOA Model SM-25M.
allowthespeaker system to be mountedonwalls, mic stands
CHARACTERISTIC
DIAGRAMS
FREQUENCY RESPONSE (1W/1m)
Frequency (Hz)
DIRECTIONAL FREQUENCY RESPONSE POWER AMP COMPRESSOR
POLAR RESPONSE
Frequency (Hz)
(1W/1m)
HORIZONTAL
DISPERSION
VERTICAL
DISPERSION
500Hz
1 kHz
2kHz
4kHz
SCALE IS 10dB PER DIVISION. SCALE IS 10dB PER DIVISION.
HARMONIC DISTORTION (1W/1m)
Frequency (Hz)
Input Voltage (V)
500Hz
1kHz
2kHz
4kHz
Printed in Japan 833-64-510-20
