Toastmaster TECHP1132 User manual

Foodservice Equipment
Job ________ Item# ________
1400 Toastmaster Drive, Elgin IL 60120-9272 USA - Tel: [phone] - Fax: [phone] - www.toastmastercorp.com
Form 907 Rev 0 (02/05)
Application
The Toastmaster Countertop
Electric Hot Plate is the most
economical and flexible Countertop
Hot Plate in the food service
industry. It offers unsurpassed
performance, combining a proven
control system with Toastmaster
quality and durability.
Standard Features
•Reinforced stainless steel front
sides and top.
•Aluminized steel at the rear and
bottom.
•Heating is accomplished with 9”
solid round hotplate with
element embedded in ceramic
and permanently bonded to the
plate.
•Adjustable 4” legs.
•Temperature is regulated by an
infinite heat switch with positive
“OFF” position.
Electrical
TECHP1132 is wired with
combination voltage of 208/230
volts, single phase. All wiring is to
be connected at the terminal block
located in rear of unit through
access panel.
Heating
Heating is accomplished with 9”
solid round hotplate with element
embedded in ceramic and
permanently bonded to the plate.
Controls
Temperatures are regulated by an
infinite heat switch. Dial knobs, with
an “OFF” position are mounted in
front with guard. An indicator light is
associated with each switch. Each
hotplates is provided with an
integral temperature limit control for
over temperature protection.
Countertop Electric Hot Plate
Models TECHP1132
COUNTERTOP ELECTRIC HOT PLATE - MODELS TECHP1132
TECHP1132
Warranty
Product warranty includes one year
parts and labor. (USA only)
Approximate Weights
TECHP1132 - 42 lbs. shipping.
Cleanability
!Stainless steel body.

INTENDED FOR COMMERCIAL USE ONLY. NOT FOR HOUSEHOLD USE.
Toastmaster, in line with its policy to continually improve its product, reserves the right to change materials or specifications without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements, additions, or replacements for previously purchased equipment.
1400 Toastmaster Drive, Elgin IL 60120-9272 USA - Tel: [phone] - Fax: [phone] - www.toastmastercorp.com
Countertop Electric Hot Plate
Models TECHP1132
Form 907 Rev 0 (02/05)
COUNTERTOP ELECTRIC HOT PLATE - MODELS TECHP1132
