Electric Hot Plates
TMHPE & TMHPF
TMHPE
Standard Features:
Model TMHPE
•Removable coil-type incoloy sheath tubular
elements.
•Independent infinite controls for precise
temperature control.
•Requires only 12” of counter space.
•Drip pan for easy cleaning.
•Adjustable 4" legs.
Model TMHPF
• Two each 9” solid round ceramic heating
element.
•Independent controls for precise tempera-
ture control.
•Solid top design for easy clean-up and
even heat distribution.
•Requires only 12” of counter space.
•Adjustable 4" legs.
Applications:
Toastmaster’s countertop electric hot plates
are the most economical and flexible
countertop hot plates in the food service
industry. They offer unsurpassed
performance, combining a proven control
system with Toastmaster quality and
durability.
General Information:
Stainless steel front including top rail, with
aluminized steel rear and sides. Units
include full drip tray for easy cleaning.
Both models are designed with (2) 9”
cooking plates.
Warranty:
Toastmaster hot plates are covered by
Toastmaster’s one year parts and labor
warranty.
TMHPF

Model No. Rated Wattage Nominal Amps - Single Phase
208V 240V 208V 240V
TMHPE 3150 4200 15.1 17.5
TMHPF 3900 5200 18.8 21.6
INTENDED FOR COMMERCIAL USE ONLY. NOT FOR HOUSEHOLD USE.
Toastmaster, in line with its policy to continually improve its product,
reserves the right to change materials or specifications without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements,
additions, or replacements for previously purchased equipment.
Electric Hot Plates
TMHPE & TMHPF
Toastmaster®10 Sunnen Dr, St. Louis MO 63143 • www.toastmastercorp.com
Toll Free: 1-800-264-7827 • Telephone: [phone] • Fax: [phone]
Typical Specifications:
Electric hot plates are constructed of aluminized steel with stainless top and front. Units are equipped with infinite con-
trols, 2 indicator lights, and are available with incoloy sheath tubular elements or sealed ceramic elements. Hot plates
have a junction box at the rear of the unit for electrical connection and operate on 208V or 240V. Units carry the approval
of Underwriters' Laboratories, NSF listed and CSA approved. Printed in the U.S.A.
Model Number TMHPE TMHPF
Dimensions 12-3/16” W x 12-3/16” W x
11-15/16” H x 11-15/16” H x
28-7/8” L 28-7/8” L
Cooking Surface Height (In.) 11-5/8 11-5/8
(cm) (29.5) (29.5)
Number of 2 2
Controls
Installed Weight (lbs.) 30 lbs. 35 lbs.
(kg) (13.6) (18.1)
Shipping Weight (lbs.) 35 lbs. 45 lbs.
(kg) (15.9) (20.4)
*4” (10cm) legs with 1-3/8” (3.5cm) adjustment
TM104/1060
