Toastmaster TMDG2400T User manual

Application:
The Toastmaster Countertop Gas
Griddles are the most economical
and flexible Countertop Griddles in
the food service industry. They offer
unsurpassed performance,
combining a proven control system
with Toastmaster quality and
durability. Available in 3 different
widths - 24”, 36” and 48”.
Controls:
One front panel mounted control
knob per burner, to allow adjustable
flame height. One burner per 12” of
griddle.
Electrical:
None required.
Models shown may ship UPS
Countertop Gas Griddles
Thermostatic Gas Griddles:
TMDG2400T, TMDG2400TP, TMDG3600T, TMDG3600TP, TMDG4800T, TMDG4800TP
Manual Gas Griddles:
TMDG2400, TMDG2400P, TMDG3600, TMDG3600P, TMDG4800, TMDG4800P
Countertop Gas Griddles (Thermostatic & Manual) Models: TMDG24, 36, & 48
Heating:
U shaped burner is controlled by
independent control of flame. One
standing pilot services each burner.
A 3/4” rear connection is standard.
Area over burners is covered by
stainless steel radiant.
Each burner is rated for 20,000
BTU/hr for natural gas and 20,000
BTU/hr for propane gas. The
TMDG units have one U shaped
burner per 12” of charbroiler.
The TMDG24’s have a total of 2
burners, the TMDG36’s have a total
of 3 burners and the TMDG48’s
have a total of 4 burners.
Dual branding cast iron grates are
reversible, allowing for a 1/4” or 1/8”
brand.
Construction:
Stainless steel front including top
rail, with aluminized steel rear and
sides, with 4” high rear and side
splash guards and full width
stainless steel grease trough and
easy to access grease drawer. Gas
units have 3/4” polished rolled steel
plate.
The gas units have one U shaped
burner per 12” of griddle. The
TMDG24’s have a total of 2 burners,
TMDG36’s have a total of 3 burners,
and the TMDG48’s have a total of
4 burners.
Cleanability:
•Stainless steel front for
durability and easy cleanup.
•Easy access to grease drawer.
Warranty:
Warranted for one year covering
parts and labor. (USA only) Call
factory for warranty authorization.
Standard Features:
•Stainless steel front including top rail
•Aluminized steel rear and sides
•4” steel legs
•Natural gas or LP
•3/4” rear gas connection
and universal pressure
regulator supplied
•3/4” thick polished rolled steel
plate with 4” high rear and side
splash guards
•Adjustable flame per 12” cooking zone
TMDG2400
Foodservice Equipment
Job Item#
Toastmaster ®5600 13th Street, Menominee, MI 49858 • www.toastmastercorp.com
Toll Free: 1-800-338-9886 • Telephone: [phone] • Fax: [phone]

Countertop Gas Griddles (Thermostatic & Manual) Models: TMDG24, 36, & 48
Toastmaster ®5600 13th Street, Menominee, MI 49858 • www.toastmastercorp.com
Toll Free: 1-800-338-9886 • Telephone: [phone] • Fax: [phone]
INTENDED FOR COMMERCIAL USE ONLY NOT FOR HOUSEHOLD USE
Toastmaster, in line with its policy to continually improve its product,
reserves the right to change materials or specifications without notice. Such
revisions do not entitle the buyer to corresponding changes, improvements,
additions, or replacements for previously purchased equipment.
All units are shipped with NAT
configuration. A universal pressure
regulator is shipped loose with
the unit including LP orifice for
field conversion.
Models shown may ship UPS
Model Number TMDG2400 TMDG2400P TMDG3600 TMDG3600P TMDG4800 TMDG4800P
Gas Type Natural LP Natural LP Natural LP
Cook Zone
Size 24” 24” 36” 36” 48” 48”
BTU/hr 40,000 40,000 60,000 60,000 80,000 80,000
Weight 215 lbs. 215 lbs. 290 lbs. 290 lbs. 365 lbs. 365 lbs.
Dimensions 24” W x 24” W x 36” W x 36” W x 48” W x 48” W x
14” H x 14” H x 14” H x 14” H x 14” H x 14” H x
27-9/16” L 27-9/16” L 27-9/16” L 27-9/16” L 27-9/16” L 27-9/16” L
Thermostatic
Manual
Model Number TMDG2400T TMDG2400TP TMDG3600T TMDG3600TP TMDG4800T TMDG4800TP
Gas Type Natural LP Natural LP Natural LP
Cook Zone
Size 24” 24” 36” 36” 48” 48”
BTU/hr 40,000 40,000 60,000 60,000 80,000 80,000
Weight 215 lbs. 215 lbs. 290 lbs. 290 lbs. 365 lbs. 365 lbs.
Dimensions 24” W x 24” W x 36” W x 36” W x 48” W x 48” W x
14” H x 14” H x 14” H x 14” H x 14” H x 14” H x
27-9/16” L 27-9/16” L 27-9/16” L 27-9/16” L 27-9/16” L 27-9/16” L
Countertop Gas Griddles
Thermostatic: TMDG2400T, TMDG2400TP, TMDG3600T, TMDG3600TP, TMDG4800T, TMDG4800TP
Manual: TMDG2400, TMDG2400P, TMDG3600, TMDG3600P, TMDG4800, TMDG4800P
FRONT SIDE
TOP
279/16”
(690)
279/16” (690)
14”
(356)
21/4”
(57)
255/8” (650.87)
10”
(254)
4”
(102) 3”
(76)
24” (610), 36” (914), 48” (1219)
