Toastmaster 357S User manual

USE AND CARE GUIDE
MODELS 357S/357SCAN
357S/357SCAN
4-Slice
Toaster-Oven-Broiler
with Removable Liner
Questions
Call toll free 1-800-947-3744
Monday–Friday, 8:00 a.m.-5:30 p.m. CST
www.toastmaster.com
?
•Dishwasher safe removable stainless steel liner
•Large capacity handles 4 slices of toast, 5 lb. chicken,
8" pie pan
•2-hour timer
•Cool wall exterior
•Auto shut-off when cooking time is reached
•Electronic toast control
•Includes wire rack, bake/broil pan and broil insert
•Adjustable thermostat
357S/357SCAN Cover TL 14/5/02 13:33 Page 1

1.
READ AND SAVE
THESE INSTRUCTIONS
WARNING: A risk of fire and electrical shock exists in all electrical
appliances and may cause personal injury or death. Please follow all
safety instructions.
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed to reduce the risk of fire, electrical shock and
injury to persons, including the following:
◆Read all instructions before using appliance.
◆Close supervision is necessary when any appliance is used near
children.
◆This appliance is not for use by children.
◆Do not touch hot surfaces. Use handles or knobs and oven mitts.
◆Do not operate any damaged appliance. Do not operate with a
damaged cord or plug, or after the appliance malfunctions or has
been dropped or damaged in any manner. Contact Consummer
Service for examination, repair, electrical or mechanical
adjustment.
◆Before using this appliance, move it four to six inches from the
wall or any object on the countertop. Do not store any item on top
of the appliance. Do not use on surfaces where heat may cause a
problem.
◆A fire may occur if this appliance touches or is covered by
flammable material, including curtains, draperies, walls, etc., when
in operation.
◆Do not store any materials, other than manufacturer’s
recommended accessories, in this oven when not in use.
◆Do not cover crumb tray or any part of the oven with metal foil.
This will cause overheating of the oven.
◆Extreme caution should be exercised when using containers
constructed of materials other than metal.
◆Do not place any flammable material such as paper, cardboard,
plastic, etc. in the oven.
◆When broiling, the bake/broil tray and broil insert rack must be used.
357S/357SCAN TOB TL 14/5/02 13:32 Page 1

2. 4-Slice Toaster-Oven-Broiler with Removable Liner Use and Care Guide
◆Do not use outdoors or while standing in a damp area.
◆Do not clean with metal scouring pads. Pieces of the pad may
break off and touch electrical parts.
◆Unplug from outlet when not in use and before cleaning. Allow to
cool before attaching or removing parts and before cleaning the
appliance.
◆CAUTION: Never leave toaster-oven-broiler unattended when
broiling or toasting.
◆Do not let cord hang over edge of table or counter, or touch hot
surfaces.
◆The toaster-oven-broiler is off when the temperature knob and the
timer are in the off position.
◆Extreme caution must be used when moving an appliance
containing hot oil or other hot liquids.
◆Use extreme caution when removing broiling tray or disposing of
hot grease.
◆Do not place on or near a hot gas or electric burner or in a heated
oven.
◆Use attachments only if recommended by Toastmaster Inc.
◆Only use appliance as indicated in these instructions.
SAVE THESE INSTRUCTIONS
CAUTION: A short power supply cord is provided to reduce the risk
of personal injury resulting from becoming entangled in or tripping
over a longer cord. Extension cords are available from local hardware
stores and may be used if care is exercised in their use. If an
extension cord is required, special care and caution is necessary. Also
the cord must be: (1) marked with an electrical rating of 125 V and at
least 13A, 1625 W, and (2) the cord must be arranged so that it will
not drape over the countertop or tabletop where it can be pulled on
by children or tripped over accidentally.
POLARIZED PLUG: This appliance has a polarized plug, (one blade
is wider than the other). As a safety feature to reduce the risk of
electrical shock, this plug is intended to fit in a polarized outlet only
one way. If the plug does not fit fully in the outlet, reverse the plug. If
it still does not fit, contact a qualified electrician. Do not attempt to
defeat this safety feature.
357S/357SCAN TOB TL 14/5/02 13:32 Page 2

3.
ELECTRIC POWER: If the electric circuit is overloaded with other
appliances, your appliance may not operate properly. It should be
operated on a separate electrical circuit from other appliances.
This product is for household use only.
Remove all packaging materials including the piece of paper that has
been placed between the top of the oven door and oven for protection
during shipping. Also remove the piece of cardboard that has also been
placed between the bottom of the oven door and the oven.
Your product may vary slightly from illustration.
Power Light
Mode
Knob
TEMPERATURE
Knob
TIMER
Figure 1 Wire Rack
Upper Shelf
Positions 1 and 2
Lower Shelf
Positions 3 and 4
Broil Insert Rack
(P/N 21497)
Bake/Broil Pan
(P/N 21498)
Figure 2
357S/357SCAN TOB TL 14/5/02 13:32 Page 3

4. 4-Slice Toaster-Oven-Broiler with Removable Liner Use and Care Guide
Figure 3
Wire Rack
(Shelf Positions 1 and 3)
(P/N 21499)
Wire Rack Inverted
(Shelf Positions 2 and 4)
Removable Liner
(P/N 21500)
Wire
Handle
Figure 4
Figure 5
Dark
Toast
Broil
Oven
OFF OFF
Stay on
120
TIMER
80
60
40
20
Light
I
357S/357SCAN TOB TL 14/5/02 13:32 Page 4

5.
Getting To Know
Your Toaster-Oven-Broiler
Your new Toastmaster toaster-oven-broiler has the versatility to bake,
broil, defrost, toast, top brown and keep foods warm. The adjustable
thermostat allows you to prepare recipes according to package or
recipe directions. The Power Light will be on any time the unit is
operating. Both upper and lower heating elements will be on when
toasting, baking, defrosting, top browning and keeping foods warm. Only
the upper elements will be on when broiling.
CAUTION: APPLIANCE SURFACES ARE HOT DURING AND
AFTER USE.
CAUTION: ALWAYS WEAR PROTECTIVE, INSULATED OVEN
MITTS ON HANDS WHEN TOUCHING HOT OVEN OR HOT
DISHES AND FOOD OR WHEN INSERTING OR REMOVING
RACK, PAN OR BAKING DISH.
Ovenware manufacturers do not recommend using see-through glass
baking containers or lids in this oven. Glass-ceramic baking containers
may be used. Do not use oven roasting bags in this oven, as they may
come in contact with the heating elements.
Bake/Broil Pan, Toast Rack
And Broil Insert
For best results use pan to bake, defrost, top brown, keep warm and
to minimize clean-up due to spills.
For toasting, place bread directly on rack.
When broiling, both the bake/broil pan and the broil insert rack
must be used.
Timer
The TIMER control dial also acts as the oven’s ON and OFF switch.
Turn the timer clockwise to select the appropriate cooking time up to
2 hours. When timer is complete, a signal will sound and the unit will
turn off automatically. If cooking for less than 10 minutes, using the
timer is not recommended.
357S/357SCAN TOB TL 14/5/02 13:32 Page 5

6. 4-Slice Toaster-Oven-Broiler with Removable Liner Use and Care Guide
If you do not wish to use the timer feature, turn the dial to STAY ON
to turn the oven on and watch food for doneness. Turn dial to OFF
position when cooking is complete.
Wire Rack
The wire rack must be used for all cooking functions. It may be inserted
in either the upper or lower rack position as shown in Figure 1.
The wire rack may also be inverted for two additional positions
(see Figure 3). Each section of instructions suggest a rack specific
position. However, the rack may be adjusted to accommodate the
different thickness of foods.
Instructions For Toast
1. Remove bake/broil pan and rack.
2. Plug into 120 V ~ 60 Hz outlet.
3.
Center food on rack. Place in shelf position 2 or 3 of oven and close
the door.
4. Turn TOAST control to the desired shade.
5. Press the TOAST button. The power light will come on.
Condensation may build up on door glass, but will evaporate
during toasting.
6. The unit shuts off automatically when the cycle is complete. The
power light will go off. Note: Watch toast until desired color is
achieved and shut off unit manually by opening the oven door.
This will shut the unit off without damaging the oven. To restart,
push TOAST button again.
Hints For Toast
◆Follow toaster food directions.
◆Frozen and heavy bread require a darker setting
(e.g. bagels and English muffins.)
◆One slice requires a lighter setting than several slices.
357S/357SCAN TOB TL 14/5/02 13:32 Page 6

7.
Instructions For Top Brown
1. Remove bake/broil pan and rack.
2. Plug into 120 V ~ 60 Hz outlet.
3. Adjust TOAST control to desired shade.
4. Center a baking container or food on rack, or use bake pan. Place
on
shelf position 2 or 3 of oven and close door.
5. Press TOAST button. The power light will come on.
6. The unit shuts off automatically when the cycle is complete. The
power light will go off. Watch food to avoid over-browning. To stop
cycle manually, open the oven door.
7. Unplug and allow to cool before cleaning.
Hints For Top Brown
◆For a darker color set the toast control to a darker shade and restart
the cycle by pressing the TOAST button; watch until desired color is
achieved and shut unit off manually by opening the oven door.
◆Top Brown may be used to top brown bagels, English muffins or
melt cheese on sandwiches or casseroles.
Instructions For Keep Warm
1. Remove bake/broil pan and rack.
2. Plug into 120 V ~ 60 Hz outlet.
3. Turn OVEN control to 200° and TIMER to desired time or to Stay
On. The power light will come on.
4. Center a baking container or food on the rack, or use bake pan;
place in shelf position 2 or 3 and close door.
5. When finished open the door and remove food. Turn the OVEN and
TIMER controls to the OFF position. The power light will go off.
6. Unplug and allow to cool completely before cleaning.
357S/357SCAN TOB TL 14/5/02 13:32 Page 7

8. 4-Slice Toaster-Oven-Broiler with Removable Liner Use and Care Guide
Hints For Keep Warm
◆Use for short periods of time after food is cooked.
◆To heat frozen or cold foods, see instructions for defrost.
Instructions For Bake
1. Remove bake/broil pan and rack.
2. Plug into 120 V ~ 60 Hz outlet.
3. Turn OVEN control to desired setting. Turn TIMER to desired
time or to Stay On. If utilizing timed baking, allow approximately
10 minutes for preheat. The power light will come on.
4. Center a baking container or food directly on rack or use bake
pan. Place in
shelf position 2 or 3 of oven and close door.
5. Bake according to package or recipe directions.
6. When finished turn OVEN and TIMER controls to the OFF
position. The power light will go off.
7. Unplug and allow to cool before cleaning.
Hints For Bake
◆To prevent heat loss, avoid opening door excessively.
◆Foil may be used to cover glass-ceramic baking container if ends
are tucked closely against edge of pan.
◆For best results, foods that contain a leavening agent should be
baked on shelf position #4.
Instructions For Defrost
1. Remove bake/broil pan and rack.
2. Plug into 120 V ~ 60 Hz outlet.
3. Turn OVEN control to 200° and TIMER to desired time or to Stay
On. The power light will come on.
357S/357SCAN TOB TL 14/5/02 13:32 Page 8

9.
Instructions For Defrost (cont.)
4. Place rack in shelf position 2 or 3 of oven.
5. Center a baking container or food on rack or use bake pan. Note:
Defrost will take approximately 1/3 of the time recommended on
the package for defrosting at room temperature.
6. When finished turn the OVEN and TIMER controls to the OFF
position. The power light will go off.
7. Unplug and allow to cool completely before cleaning.
Hints For Defrost
◆Do not use this method for meat, poultry or fish.
◆Do not cover food.
◆Brush frozen dough with vegetable oil to prevent drying out and
remove food to preheat oven before baking.
Instructions For Broil
1. Remove bake/broil pan and rack.
2. Place broil insert in bake pan and position food on broil insert.
3. Place rack in shelf position 1 or 2.
4. Plug into 120 V ~ 60 Hz outlet.
5. Turn OVEN control to broil and TIMER to desired time or to Stay On.
6. Broil according to package or recipe instructions.
7. When finished turn OVEN and TIMER controls to the OFF
position. The power light will go off.
8. Unplug and allow to cool completely before cleaning.
357S/357SCAN TOB TL 14/5/02 13:32 Page 9
