Toastmaster TOV200CAN User manual

USE AND CARE GUIDE
MODEL TOV200CAN
TOV200CAN
Toaster Oven
Broiler
Questions
Call toll free 1-800-233-9054
Monday–Friday, 8:00 a.m.-5:30 p.m. CST
www.toastmaster.com
?
•Non-Stick Interior For Easy Clean-Up
•30-Minute Timer With Stay-On Feature
•Fully Adjustable Thermostat Up To 450°F
•Removable Crumb Tray
•Power Indicator Light
TOV200CAN_IB_Cover_18-11-04 11/18/04 11:23 PM Page 1

1.
IMPORTANT SAFEGUARDS
When using electrical appliances, basic safety precautions should
always be followed including the following:
◆Read all instructions.
◆Do not touch hot surfaces. Use handles or knobs.
◆To protect against electrical shock do not immerse cord, plugs, or
appliance in water or other liquid.
◆Close supervision is necessary when any appliance is used by or
near children.
◆Unplug from outlet when not in use and before cleaning. Allow to
cool before putting on or taking off parts.
◆Do not operate any appliance with a damaged cord or plug or
after the appliance malfunctions or has been damaged in any
manner. Contact Consumer Service for examination, repair or
adjustment.
◆The use of accessory attachments not recommended by the
appliance manufacturer may cause injuries.
◆Do not use outdoors.
◆Do not let cord hang over edge of table or counter, or touch hot
surfaces.
◆Do not place on or near a hot gas or electric burner, or in a
heated oven.
◆Extreme caution must be used when moving an appliance
containing hot oil or other hot liquids.
◆To disconnect turn Timer Control to “OFF”, then remove plug
from wall outlet.
◆Do not use appliance for other than intended use.
◆Use extreme caution when removing tray or disposing of
hot grease.
◆Do not clean with metal scouring pads. Pieces can break off
the pad and touch electrical parts, creating a risk of electric shock.
TOV200CAN_IB_18-11-04 11/18/04 11:24 PM Page 1

2. Toaster Oven-Broiler Use and Care Guide
◆Oversize foods or metal utensils must not be inserted in a
toaster-oven as they may create a fire or risk of electric shock.
◆A fire may occur if the toaster-oven is covered or touching
flammable material, including curtains, draperies, walls, and the
like, when in operation. Do not store any item on top of the
appliance when in operation.
◆Extreme caution should be exercised when using containers
constructed of other than metal or glass.
◆Do not store any materials, other than manufacturers
recommended accessories, in this oven when not in use.
◆Do not place any of the following materials in the oven: paper,
cardboard, plastic, and the like.
◆Do not cover Crumb Tray or any part of the oven with metal foil.
This will cause overheating of the oven.
◆Use extreme caution when removing tray or disposing of hot
grease.
◆To Turn unit OFF, turn Timer Control to “OFF” position.
SAVE THESE INSTRUCTIONS
For Household Use Only
ADDITIONAL IMPORTANT
SAFEGUARDS
CAUTION: HOT SURFACES: This appliance generates heat and
escaping steam during use. Proper precautions must be taken to
prevent the risk of burns, fires, or other injury to persons or damage
to property.
◆A person who has not read and understood all operating and
safety instructions is not qualified to operate this appliance. All
users of this appliance must read and understand this Use and
Care Guide before operating or cleaning this appliance.
◆If this appliance falls or accidentally becomes immersed in water,
unplug it from the wall outlet immediately. Do not reach into the
water!
TOV200CAN_IB_18-11-04 11/18/04 11:24 PM Page 2

3.
◆When using this appliance, provide adequate air space above and
on all sides for air circulation. Do not operate this appliance while
it is touching or near curtains, wall coverings, clothing, dishtowels
or other flammable materials.
◆To reduce the risk of fire, do not leave this appliance unattended
during use.
◆If this appliance begins to malfunction during use, immediately
unplug the cord. Do not use or attempt to repair a malfunctioning
appliance!
◆The cord to this appliance should only be plugged into a
120V AC 60 Hz electrical wall outlet.
◆Do not use this appliance in an unstable position.
Polarized Plug
This appliance has a polarized plug (one blade is wider than the
other). To reduce the risk of electrical shock, this plug is intended to
fit into a polarized outlet only one way. If the plug does not fit fully in
the outlet, reverse the plug. If it still does not fit, contact a qualified
electrician. Do not attempt to modify the plug in any way.
Short Cord Instructions
A short power-supply cord is provided to reduce the risk resulting
from becoming entangled in or tripping over a longer cord.
Do not use an extension cord with this product.
Electric Power
If the electrical circuit is overloaded with other appliances, your
appliance may not operate properly. It should be operated on a
separate electrical circuit from other appliances.
TOV200CAN_IB_18-11-04 11/18/04 11:24 PM Page 3

4. Toaster Oven-Broiler Use and Care Guide
11.
12.
10.
9. 8. 7. 6. 5.
3.
2.
1.
1. Control Panel
2. Power Indicator Light
3. Temperature/Function
Control
4. Cord
5. Timer Control (with
30-minute Timer, “OFF”
and “Stay On” feature)
6. Lower Heating Elements
7. Removable Crumb Tray
(P/N 22367)
8. Glass Door
9. Handle
10. Shelf Position 3 and 4
11. Shelf Position 1 and 2
12. Upper Heating Elements
Figure 1
CAUTION: To prevent Plasticizers from migrating from the finish of
the countertop or tabletop or other furniture, place NON-PLASTIC
coasters or placemats between the appliance and the finish of the
countertop or tabletop.
Failure to do so may cause the finish to darken, permanent blemishes
may occur or stains can appear.
Getting to Know Your Toastmaster
Toaster Oven-Broiler
Your product may vary slightly from illustration.
4.
TOV200CAN_IB_18-11-04 11/18/04 11:24 PM Page 4

5.
Broil Insert
(P/N 22368)
Bake Pan
(P/N 22369)
Broil Pan
Assembly
1 Wire Rack
(P/N 22370)
Shelf Positions
1 and 3
Shelf Positions
2 and 4
Figure 2
Figure 3
Temperature/Function
Control
Power Indicator Light
Timer Control with “OFF” and
“Stay-ON” feature
TOV200CAN_IB_18-11-04 11/18/04 11:24 PM Page 5

6. Toaster Oven-Broiler Use and Care Guide
Operating Instructions
BEFORE FIRST USE
1. Carefully unpack your Toaster Oven-Broiler and remove all
packaging materials.
2. Place your Toaster Oven-Broiler on a level surface such as a
countertop or table. Be sure the sides, back, and top of the
Toaster Oven-Broiler are at least four inches away from any walls,
cabinets, or objects on the countertop or table.
3. Remove all stickers from the Toaster Oven-Broiler except the
rating label.
4. Remove Broil Insert, Bake Pan, Wire Rack and Crumb Tray and
wash in warm, soapy water. Rinse and dry thoroughly before
placing in the Toaster Oven-Broiler.
5. Remove any dust that may have accumulated during packaging.
Simply wipe the Toaster Oven-Broiler exterior with a clean,
damp cloth.
6. Do not use abrasive cleansers.
7. Make sure the Crumb Tray is firmly in place in the bottom of the
Toaster-Oven-Broiler.
8. Plug into 120 V AC 60 Hz outlet. Close the Glass Door.
9. To eliminate any protective substance or oil that may have been
used for packing and shipping, turn the Temperature/Function
Control to Toast and set the Timer Control for 15 minutes. The
Power Light will come on. A small amount of smoke and odor
may be detected. This is normal.
10. To avoid scratching, marring, or discoloration, do not store
anything on top of the Toaster Oven-Broiler during operation.
CAUTION: Appliance surfaces are hot during and after use.
CAUTION: Always wear protective, insulated oven mitts on hands
when touching hot Toaster Oven-Broiler or hot dishes and food or
when inserting or removing Wire Rack, baking dish and food.
TOV200CAN_IB_18-11-04 11/18/04 11:24 PM Page 6

7.
Cooking Containers
◆The Bake Pan included with the Toaster Oven-Broiler is suitable for
items such as cookies, rolls, biscuits, nachos and pork chops.
◆A variety of standard baking dishes, such as an 8" round or square
cake pan, a 6-cup muffin pan may be used for other foods.
◆Choose bakeware made of metal, or glass/ceramic without lids.
◆Dark or dull pans absorb heat faster; foods will bake more rapidly
and crust will brown more easily than in shiny bake pans.
◆Check package directions and/or with the ovenware manufacturer
to determine if the container is suitable for use in a Toaster Oven-
Broiler.
◆Do not use oven roasting bags in this Toaster Oven-Broiler, as they
may come in contact with the Heating Elements.
CAUTION: Allow at least 1" air space between the top of the container
and the Upper Heating Elements. Never use glass lids on glass or metal
bakeware. If a lid is necessary, cover tightly with heavy-duty aluminum foil.
Instructions For Toast
1. Make sure the Crumb Tray is firmly in place in the bottom of the
Toaster Oven-Broiler.
2. Plug into 120V AC 60 Hz outlet.
3. Open the Glass Door and center bread on the Wire Rack.
Place Wire Rack in Shelf Position #3. Close the Glass Door.
4. Turn the Temperature /Function Control to Toast.
TOV200CAN_IB_18-11-04 11/18/04 11:24 PM Page 7

8. Toaster Oven-Broiler Use and Care Guide
Instructions For Toast (Cont.)
5. Turn the Timer Control to the toast symbol. The Power Light will
come on.
NOTE: To set the Timer Control for less than 10 minutes, turn to 10
and then turn back to the appropriate amount of time.
NOTE: Do not set the Timer Control to the Stay On position when
using the Toast function.
CAUTION: As soon as the Timer Control is engaged, the Toaster
Oven-Broiler will turn ON. Both the top and the bottom Heating
Elements may cycle On and Off to maintain temperature for the
entire cooking time.
CAUTION: As soon as the Timer Control is engaged both Heating
Elements will become hot immediately. Use care not to place
anything on top of the Toaster Oven-Broiler. Do not touch the
Toaster Oven-Broiler or any part of the Toaster Oven-Broiler
without wearing oven mitts.
6. With the Timer Control set, the Toaster Oven-Broiler will shut off
automatically when the Toast cycle is complete. If toasting is
completed before the Timer Control shuts the Toaster Oven-Broiler
OFF, you may shut the Toaster Oven-Broiler OFF manually by
turning the Timer Control to the OFF position. The Power Light
will go off.
7. Do not set Timer Control past time indicated on Toast Graphics.
When time set has passed, a signal will sound, and the Timer
Control will finish in the OFF position. The Power Light will go off.
NOTE: Watch toast until desired color is achieved.
8. Open the Glass Door. Wear protective oven mitts to remove toast from
Toaster Oven-Broiler. Be careful when removing toast from the back
of Rack Positions 1 and 2. The inside of the Toaster Oven-Broiler is
very hot. Close Glass Door.
9. Unplug unit and allow to cool before cleaning.
DO NOT LEAVE TOASTER OVEN-BROILER UNATTENDED
DURING TOASTING.
See User Maintenance Instructions. Unplug when not in use.
TOV200CAN_IB_18-11-04 11/18/04 11:24 PM Page 8

9.
Hints For Toast
◆Remove all protective wrappings from food before placing in
Toaster Oven-Broiler. Follow toaster food directions.
◆Frozen and heavy bread require a longer time setting (e.g. bagels
and English muffins).
NOTE: Use extra caution when using this Toaster Oven-Broiler for
toasting pastry items with runny-type frosting or open fillings.
◆When toasting more than one slice of bread, use slices of similar
size, thickness and freshness.
◆One slice of bread requires a lighter setting than several slices of bread.
◆Stale bread, thin bread or sweet bread products, such as tea cakes
and fruit loaf, brown much more quickly than ordinary bread, so
they should be toasted for less time.
◆Different breads require different toasting times. Turn Timer
Control to the OFF position and open the Glass Door to check toast
color. Close Glass Door and reset Timer Control if more toasting
time is needed.
◆For best results, clean Crumb Tray frequently.
Instructions For Baking
1. Make sure the Crumb Tray is firmly in place in the bottom of the
Toaster Oven-Broiler.
2. Plug into 120V AC 60 Hz outlet. Close the Glass Door.
3. Preheat the Toaster Oven-Broiler for 5 minutes for baking. After
5 minutes, a signal will sound and the Toaster Oven-Broiler will
automatically shut OFF.
4. Remove all protective wrappings from food before placing in
Toaster Oven-Broiler.
5. Open the Glass Door. Place the Wire Rack in Shelf Position
#3 or #4, depending on the height of the pan and food or recipe
directions. Use the Baking Tray or an appropriate baking container.
If you would like your food browned top and bottom, place food
directly on Rack and close Glass Door. Bake according to package
or recipe time.
6. Set the Temperature/Function Control to the desired temperature.
7. Turn the Timer Control to the desired time or to the Stay On
position. The Power Light will come on.
TOV200CAN_IB_18-11-04 11/18/04 11:24 PM Page 9
