Tokheim WWC T1 Operating manual

WWC T1
Calculator
Set Up & Maintenance
Manual
Document Ref 905675-001
Rev - 2
01/2006

Document Ref 905675-001 Rev 2
WWC T1 Set Up & Maintenance Manual
Issue A
Great care has been taken in the preparation of this manual however Tokheim
shall not be liable for any misunderstanding, errors and/or loss or defect
arising from the use of this manual.
Tokheim shall not be liable for damage to the product, nor for personal or
third party injury, caused by incorrect use of the product or by attempts to
maintain or to repair the product by parties other than those fully trained by
Tokheim or by its accredited third party representatives.
Please contact your nearest service department, at the relevant address
printed on the back cover of this manual, should any aspect of this manual
be unclear.
© Copyright by Tokheim. All intellectual rights arising from, accruing
to,and residing in this manual belong to Tokheim. No part of this
document may be reproduced in any form without the express written
permission of Tokheim.
Tokheim reserves the right to apply changes to this document and the
equipment without further notice.

Document Ref 905675-001 Rev 2 1
WWC T1 Set Up & Maintenance Manual Revision Record
REVISION RECORD
Date Revision Page Issue Reason
01/07/2004 1 All A Original Issue
19/01/2006 2 3 to 6 B Main Contents revised
19/01/2006 2 2-16,2-17 B Updated Functionalities
19/01/2006 2 2-21 to 2-23 B New info added (Input Type, Master PIN Code, Gallon
Type, Cent Overshoot Hide, 4 position product indicator,
Heavy Lei); repagination
19/01/2006 2 3-1 B Section 3 Contents revised
19/01/2006 2 3-6,3-7 B Headings changed
19/01/2006 2 5-1 B Section 5 Contents revised
19/01/2006 2 5-4 to 5-16 B New info added (Cent Overshoot Hide, 4 position
product indicator, Heavy Lei); repagination
19/01/2006 2 6-1 B Section 6 Contents revised
19/01/2006 2 6-8,6-9 B New info added (Heavy Lei)
19/01/2006 2 6-15 to 6-42 B New info added (Cent Overshoot Hide, 4 position
product indicator); repagination
19/01/2006 2 7-1 B Section 7 Contents revised
19/01/2006 2 7-3 B New information added (Vapour Mes menu)
19/01/2006 2 7-7,7-8 A New pages inserted, new information added (Tokheim
protocol
19/01/2006 2 11-4 B New info added (max time no flow)
19/01/2006 2 12-2,12-3 B New options added to POM

2Document Ref 905675-001 Rev 2
Revision Record WWC T1 Set Up & Maintenance Manual
This page is intentionally blank
IssueA

WWC T1 Set Up & Maintenance Manual Contents
Document Ref 905675-001 Rev 2 3
(CONT.)
Issue B
CONTENTS
1 INTRODUCTION......................................................................................................... 1-2
1.1 How to Use this Manual ..................................................................................... 1-2
1.2 Product Scope ..................................................................................................... 1-3
1.3 Authorised Technicians....................................................................................... 1-3
1.4 Contact Information ............................................................................................ 1-3
1.5 Health & Safety .................................................................................................. 1-3
1.5.1 Safety Checklist.................................................................................. 1-3
1.5.2 Duties of the Employees..................................................................... 1-4
1.5.3 Hazards ............................................................................................... 1-4
1.5.4 Warning Signs .................................................................................... 1-5
1.5.5 Personal Protective Equipment (PPE)................................................ 1-6
1.6 Nomenclature...................................................................................................... 1-7
2 PRODUCT INFORMATION....................................................................................... 2-2
2.1 System Description ............................................................................................. 2-2
2.1.1 Operating Principles ........................................................................... 2-2
2.2 Main Components of the WWC ......................................................................... 2-2
2.2.1 External Power Supply....................................................................... 2-3
2.2.2 Mainboard .......................................................................................... 2-3
2.2.3 I/O Board (version 3++) ..................................................................... 2-4
2.2.4 Transaction Displays .......................................................................... 2-4
2.2.5 User Access Devices (UAK/UAM).................................................... 2-4
2.3 Different Configurations..................................................................................... 2-4
2.3.1 Standard dispensers with up to four single products.......................... 2-5
2.3.2 Low-end dispensers : single product or twin configuration, super
high speed, single-sided (Fleet).......................................................... 2-5
2.3.3 Vapour Recovery Controller Board (VRC) ........................................ 2-6
2.3.4 Option Controller Board (OCB)......................................................... 2-6
2.3.5 Hydraulic Option Modules (HOM).................................................... 2-6
2.3.6 I/O Extension Board (IEB)................................................................. 2-6
2.4 Product Option Matrix (POM)............................................................................ 2-6
2.5 Functionality ....................................................................................................... 2-6
2.5.1 Functionalities per hose...................................................................... 2-7
2.5.2 Functionalities per side .................................................................... 2-10
2.5.3 Functionalities per dispenser............................................................ 2-16
2.5.4 Weights & Measures related Functionality ...................................... 2-21
3 LPG SET UP .................................................................................................................. 3-2
3.1 LPG Functionality............................................................................................... 3-2
3.1.1 LPG Pulse Menu ................................................................................ 3-2
3.1.2 LPG Nozzle Flag Menu...................................................................... 3-2
3.1.3 LPG Delay Timer Menu ..................................................................... 3-3
3.1.4 LPG Motor Off Timer Menu .............................................................. 3-3
3.2 LPG Hydraulic Functions ................................................................................... 3-4
3.2.1 Valves ................................................................................................. 3-4
3.2.2 Hydraulic Schematic .......................................................................... 3-5
3.3 Timing Diagrams ................................................................................................ 3-6
3.3.1 Timing with Nozzle Switch & Motor Off Delay ≠≠
≠≠
≠0 ......................... 3-6
3.3.2 Timing with Nozzle Switch & Motor Off Delay = 0 ......................... 3-6

Contents WWC T1 Set Up & Maintenance Manual
4Document Ref 905675-001 Rev 2
Issue B
(CONT.)
3 LPG SET UP /
3.3.3 Timing with Deadmans Button only & Motor Off Delay ≠≠
≠≠
≠0 ............ 3-7
3.3.4 Timing with Deadmans Button only & Motor Off Delay = 0 ............ 3-7
4 SERVICE KEYPAD...................................................................................................... 4-2
4.1 User Access Keypad (UAK) ............................................................................... 4-2
4.2 Infra Red (IR) Remote Control Keypad.............................................................. 4-4
4.3 Internal Configuration Keypad ........................................................................... 4-4
5 SET UP MODE.............................................................................................................. 5-2
5.1 General................................................................................................................ 5-2
5.2 Start Ups ............................................................................................................. 5-2
5.2.1 Cold Start............................................................................................ 5-2
5.2.2 Warm Start.......................................................................................... 5-3
5.2.3 Service Start ....................................................................................... 5-3
5.3 Initial Set Up Menu............................................................................................. 5-3
5.3.1 Set up Function Overview .................................................................. 5-4
5.3.2 Set Up Menu....................................................................................... 5-5
5.4 AFM Set Up Menu ........................................................................................... 5-10
5.4.1 No Address Conflict ......................................................................... 5-10
5.4.2 Address Conflict............................................................................... 5-14
5.4.3 AFM Addresses ................................................................................ 5-16
6 MAINTENANCE MODE............................................................................................. 6-2
6.1 General................................................................................................................ 6-2
6.2 Maintenance Function Overview........................................................................ 6-2
6.3 Access the Maintenance Functions..................................................................... 6-4
6.4 Exit Maintenance Mode...................................................................................... 6-5
6.5 Diagnostic Information (Error Log) ................................................................... 6-6
6.5.1 Kernel versions > 01.07 ..................................................................... 6-6
6.5.2 Kernel versions <= 01.07 ................................................................... 6-7
6.6 Leak Tests ........................................................................................................... 6-8
6.7 Country Code, Euro and Application Set Up...................................................... 6-8
6.8 LPG Functionality............................................................................................. 6-10
6.9 Thermal Protection Reset ..................................................................................6-11
6.9.1 Kernel versions > 01.07 ....................................................................6-11
6.9.2 Kernel versions <= 01.07 ..................................................................6-11
6.10 Leak Detection Functionality............................................................................ 6-12
6.10.1 Vapour Leak Detection (France only) .............................................. 6-12
6.10.2 Flow Protection Reset (AFM Leak Detection) ................................ 6-12
6.10.3 Esso Leak Detection......................................................................... 6-13
6.11 Fraud Detection Functionality .......................................................................... 6-13
6.12 Combined Hose Pre-selection and Display Timeout ........................................ 6-14
6.13 Electro-Mechanical Totaliser Mode (EMT) Functionality ............................... 6-14
6.14 Cent Overshoot Hide Functionality .................................................................. 6-15
6.15 Q500T1 Four Position Product Indicator ......................................................... 6-15
6.16 Stop/Off Switch ................................................................................................ 6-16
6.17 Fuel Leak Detection.......................................................................................... 6-16
6.17.1 Set Up PIN Code (Fuel Leak Detection only).................................. 6-17
6.18 Blend Ratio ....................................................................................................... 6-17
6.19 Local Preset Values........................................................................................... 6-18

WWC T1 Set Up & Maintenance Manual Contents
Document Ref 905675-001 Rev 2 5
Issue B
(CONT.)
6 MAINTENANCE MODE /
6.20 Node Address .................................................................................................... 6-18
6.21 Test Delivery..................................................................................................... 6-19
6.22 Emergency Manual Pumping Device (EMPD)................................................. 6-21
6.23 Product Relation ............................................................................................... 6-21
6.23.1 Product Name by Character Input .................................................... 6-22
6.23.2 Product Name from Pick List ........................................................... 6-23
6.24 Vapour Recovery............................................................................................... 6-24
6.24.1 Kernel versions <= 0.???.................................................................. 6-24
6.25 Vapour Delay .................................................................................................... 6-25
6.26 Pump Motor Delay (Submerged/Remote pumps only)..................................... 6-25
6.27 Optional Preset Valve........................................................................................ 6-26
6.28 Valve Reponse Value ........................................................................................ 6-26
6.29 AFM Menu ....................................................................................................... 6-27
6.29.1 AFM change menu ........................................................................... 6-27
6.29.2 AFM Read-only menu ...................................................................... 6-27
6.30 Product Position................................................................................................ 6-29
6.31 Option Selection ............................................................................................... 6-30
6.31.1 IEB (I/O Extension Board) Options ................................................. 6-30
6.31.2 OCB (Option Controller Board) Options ......................................... 6-31
6.32 Nozzle Sensor Definition.................................................................................. 6-37
6.32.1 Kernel version >= 03.08................................................................... 6-37
6.32.2 Kernel version >= 03.03................................................................... 6-37
6.32.3 Kernel version >= 02.12................................................................... 6-40
6.32.4 Kernel version < 02.12 ..................................................................... 6-42
7 APPLICATION MODE................................................................................................ 7-2
7.1 All Applications .................................................................................................. 7-2
7.2 EPS...................................................................................................................... 7-3
7.3 IFSF..................................................................................................................... 7-4
7.4 ZSR ..................................................................................................................... 7-5
7.5 Dunclare.............................................................................................................. 7-6
7.6 Tokheim .............................................................................................................. 7-7
8 PIN CODES ................................................................................................................... 8-2
8.1 First PIN code ..................................................................................................... 8-2
8.2 Change PIN code ................................................................................................ 8-3
9 TOTALS ......................................................................................................................... 9-2
9.1 Reading the Totals (Amount, Volume & Number of Deliveries) ....................... 9-2
10 UNIT PRICES ............................................................................................................. 10-2
10.1 Set/Change Unit Prices ..................................................................................... 10-2
11 INSPECTION FUNCTIONS ......................................................................................11-2
11.1 Inspection Function Overview ...........................................................................11-2
11.2 General...............................................................................................................11-3
11.3 Delivery Mode ...................................................................................................11-3
11.4 Traffic Lights .....................................................................................................11-3
11.5 Idle Display Control...........................................................................................11-3
11.6 Satellite Control .................................................................................................11-3

Contents WWC T1 Set Up & Maintenance Manual
6Document Ref 905675-001 Rev 2
Issue B
11 INSPECTION FUNCTIONS /
11.7 Release Management .........................................................................................11-4
11.8 Maximum Time for a Filling .............................................................................11-4
11.9 Time Between Two Fillings ...............................................................................11-4
11.10 Maximum Time of No Flow ..............................................................................11-4
11.11 Maximum Time a Filling can be Suspended .....................................................11-5
11.12 Timer for Display TImeout ................................................................................11-5
11.13 Delivery Fraud Timer.........................................................................................11-5
11.14 Software Versions ..............................................................................................11-5
11.15 Pulser Hide.........................................................................................................11-8
11.16 Preset Totalisers .................................................................................................11-8
12 APPENDIX .................................................................................................................. 12-2
12.1 Appendix A - Product Option Matrix ............................................................... 12-2
12.2 Appendix B - Country Codes............................................................................ 12-4
12.3 Appendix C - Error Codes ................................................................................ 12-6
12.3.1 Startup Error Situations.................................................................... 12-6
12.3.2 Displaying Error Messages .............................................................. 12-6
12.3.3 Diagnostic Database ......................................................................... 12-7
12.4 Appendix D - Jumper Positions ...................................................................... 12-10
12.4.1 Mainboard ...................................................................................... 12-10
12.4.2 VRC Board ......................................................................................12-11
12.4.3 User Access Module....................................................................... 12-12
12.4.4 OCB Board ..................................................................................... 12-13
12.4.5 I/O Extension Board (IEB)............................................................. 12-14
12.4.6 Hydraulic Option Module (HOM) ................................................. 12-14
12.4.7 Axial Flow Meter Measurement Solution (AFM) ......................... 12-14
12.5 Appendix E - General Purpose Inputs ............................................................ 12-15
12.6 Appendix F- IEB General Purpose Outputs.................................................... 12-16

WWC T1 Set Up & Maintenance Manual Introduction
Document Ref 905675-001 Rev 2 Page 1-1
CONTENTS
1 INTRODUCTION........................................................................................................ 1-2
1.1 How to Use this Manual ......................................................................................1-2
1.2 Product Scope ......................................................................................................1-3
1.3 AuthorisedTechnicians ........................................................................................1-3
1.4 Contact Information .............................................................................................1-3
1.5 Health & Safety ...................................................................................................1-3
1.5.1 Safety Checklist...................................................................................1-3
1.5.2 Duties of the Employees......................................................................1-4
1.5.3 Hazards................................................................................................1-4
1.5.4 WarningSigns ......................................................................................1-5
1.5.5 Personal Protective Equipment (PPE) ................................................1-6
1.6 Nomenclature.......................................................................................................1-7
Issue A

Page 1-2 Document Ref 905675-001 Rev 2
Introduction WWC T1 Set Up & Maintenance Manual
1 INTRODUCTION
1.1 How to Use this Manual
It is recommended that all relevant persons familiarise themselves with the contents of this
manual prior to carrying out any operations or procedures.
This manual is divided into sections which are described as follows: -
Section 1 - Introduction
Thissectioncontainsinformation on howtousethe manual, thescopeofequipment covered,
recommendationsonqualifiedtechniciansand contact information. It alsoincludesrelevant
health and safety information and certification relating to the product.
Section 2 - Product Information
This section contains the system description and operating principles of the WWC T1
Calculator. It also describes the main components, their configurations and functions
including the service keypads.
Section 3 - LPG Specification
All additional information relating to LPG options is contained in this section.
Section 4 - Service Keypad
This section describes the functions of the various keypads.
Section 5 - Set Up Modes
This section provides instructions for cold start, warm start and service start of the product.
Section 6 - Maintenance Mode
All aspects relating to the maintenance of the equipment are covered in this section.
Section 7 - Application Mode
This section contains information on the EPS, IFSF and ZSRApplication Modes.
Section 8 - PIN Code
This section contains information on how to change the PIN code.
Section 9 - Totals
Instructions on how to read totals is contained in this section.
Section 10 - Unit Prices
This section contains information on setting and changing the Unit Prices.
Section 11 - Inspection Functions
All information relating to the Inspection Function is contained in this section.
Section 12 Appendices
This section contains the appendices.
Issue A

WWC T1 Set Up & Maintenance Manual Introduction
Document Ref 905675-001 Rev 2 Page 1-3
1.2 Product Scope
This manual is designed to cover the Quantium T range of dispensers including LPG. As
functionality is equivalent to the Coca 1.1 functionality, reference is frequently made to the
existing Coca Manuals.
1.3 Authorised Technicians
Only qualified technicians familiar with the contents of this manual should carry out the
procedures contained herein.
WARNING : ANY ATTEMPTS TO CARRY OUT THE PROCEDURES OF THIS
MANUAL, BY UNQUALIFIED OR UNAUTHORISED PERSONS, MAY
RESULT IN SERIOUS INJURY OR LOSS OF LIFE.
Note : This manual is not intended to replace the services of a fully qualified
technician.
1.4 Contact Information
For information relating to the contents of this manual please contact: -
TechnicalAuthor
Tokheim UK Ltd.
Dundee, Scotland
For technical assistance please contact the appropriate service division listed on the back
cover of this manual.
1.5 Health & Safety
1.5.1 SAFETY CHECKLIST
•It is obligatory that this checklist be fully complied with during all work at the
petrol station, particularly construction or repair work.
•It is the duty of the contractor to ensure that all workers employed by him obey
each and all of the relevant laws, directives and other regulations.
Areas where special caution is required
•Theinsidesoftanks,tubes,dome shafts, filling shafts, change overshafts,vessels
and dispensers.
•All areas in which fuel vapour that is heavier than air can accumulate, e.g. fuel
separator, draining shafts, low located rooms, cellars, excavations, pipe trenches
etc.
•Theareasaroundtheoutletsof tank ventilation pipes, especially duringthefilling
phase.
•All areas near dispensers, tanker lorries and other vehicles while they are being
tanked up, and particularly when there is a lack of wind.
•A radius of 1.0 metres around petrol carrying pipes, as well as pipes that are not
vapour free.
•Silt traps.
Issue A

Page 1-4 Document Ref 905675-001 Rev 2
Introduction WWC T1 Set Up & Maintenance Manual
1.5.2 DUTIES OF THE EMPLOYEES
•To ensure optimal accident prevention in our company, in addition to general
rules applying to worker’s protection, it is necessary to take into account all the
national protection of workers legislation and to actively support all measures
which enhance safety standards.
•Itisanemployee’s duty to followallcompanydirectivesregarding the prevention
of accidents, unless such directives can be proved to be unfounded.
•Employees should not follow any instructions that go against safety standards.
•Employees are only permitted to use equipment for its original purpose, and this
is defined by the company alone.
•If an employee detects equipment that is deficient in terms of safety, he shall
eliminate this deficiency immediately. If such safety rectification is not part of
his defined area of activities, or if his knowledge is insufficient to carry out such
work he must immediately inform his superior about the detected safety
deficiency.
This equally applies to:
1) Work Materials which have not been correctly packed or correctly marked in
order to meet safety requirements.
2) Work Methods or work processes which have not been correctly coordinated
or controlled in order to meet safety requirements.
3) Where dangerous activities are carried out by several persons, the need
for a permanent faultless communication between them in order to avoid
dangerous events shall require the appointing of one person in order to carry out
overallsupervision.
1.5.3 HAZARDS
Prior to starting work, the dispenser must be isolated (i.e. entirely disconnected
from the mains supply) and the mains supply switch locked in the OFF position.
The submerged pump (if applicable) and control signals from the dispenser must
also be isolated. This is done to provide safety for the technician. As a further
precaution, switch off the mains supply in the service station shop and place a
clear notice on the switch to avoid it being turned on again inadvertently.
WARNING : THE CONNECTION AND DISCONNECTION OF
ELECTRICAL CONNECTIONS MAY ONLY BE CARRIED OUT BY
QUALIFIED PERSONNEL AUTHORISED FOR SUCH ACTIVITIES.
WORK IN DANGEROUS AREAS MUST BE MADE SAFE BY
OBSERVING ALL THE NATIONAL SAFETY REQUIREMENTS IN
FORCE.
It is not permitted to put a fuel dispenser into operation before an authorised
officialhasinspectedit and releasedit.Thisdependsupon the nationalregulations
in force.
Dismantled packaging and cladding must be stored in such a way as to avoid
damage to components or injuries to persons. Covers that can be opened, such
as the calculator housing, should be handled with care. Ensure that the retaining
catch is placed in the correct position to prevent the cover falling onto the head
of the service engineer or other persons in the area.
Issue A

WWC T1 Set Up & Maintenance Manual Introduction
Document Ref 905675-001 Rev 2 Page 1-5
At unattended service stations, every end-user should be able to read the User
Instructions. They should be visible on a notice board or integrated into the DIT
and should be sufficiently well lit so that they can be read at night.
At unattended service stations break away couplings must always be used to
reduce the danger caused by a motorist driving off with the nozzle still in the
tank.
1.5.4 WARNINGSIGNS
The following warning signs are fitted as standard, on the dispenser, however
they may vary according to individual country requirements or customer
specifications.
Do not use mobile
phones
SIGN
Naked flames and
smokingforbidden
Do not spill fuel on the
ground
Stop vehicle engine
At Diesel high speed
dispensers near the
nozzleboots
Visible from both
sides of dispenser
Visible from both
sides of dispenser
Visible from both
sides of dispenser
Visible from both
sides of dispenser
Trucks only
MEANING POSITION
Do not drive away with
nozzle in tank
Next to User
Instructions near the
nozzleboot
Visible from both
sides of dispenser
Issue A

Page 1-6 Document Ref 905675-001 Rev 2
Introduction WWC T1 Set Up & Maintenance Manual
1.5.5 PERSONAL PROTECTIVE EQUIPMENT (PPE)
PROTECTIVE CLOTHING
The following clothing should be worn at all times during installation and
maintenance procedures:-
•Protective helmet.
•Protective shoes (conductive).
•Protective gloves and/or protective hand cream.
•Anti static clothing.
•Eye protection.
SAFETY EQUIPMENT FOR WORKING IN HAZARDOUS AREAS
The following safety equipment is required for working in hazardous areas:-
•Only spark free tools are permitted for work on dispensers.
•Work on bearings is only permitted using the standard workshop tools authorised
for this kind of work.
•The use of all electrical tools is strictly prohibited.
•Only the use of explosion protected work lights is permitted.
•Theuseof telecommunications equipmentinhazardous areasisstrictlyprohibited.
SAFETY INSTRUCTIONS
The following safety instructions must be adhered to during installation and
maintenance procedures:-
•Inhalation of petrol vapour must be avoided. Suitable precautions must be taken
and where necessary respirators used.
•Avoid direct contact of fuel with the skin.
•Use suitable protective clothing, protective gloves and/or protective hand cream.
•Avoid fuel spills.
•No smoking, no naked flames are permitted.
•Long hair and ties can get caught in moving parts. Hair must be suitably covered.
Issue A

WWC T1 Set Up & Maintenance Manual Introduction
Document Ref 905675-001 Rev 2 Page 1-7
1.6 Nomenclature
The various abbreviations used in thie manual are described as follows:-
CoCa Today’s Common Calculator and base of the WWC
CSD-F Common Sales Display - Ferranti
CSD-L Common Sales Display - LCD
Dipnet Dispenser inter-peripheral network
ELU Energy Limiting Unit (i.e.Nozzle Bus Intrinsically Safe Barrier)
EMPD Emergency Manual Pumping Device
EMT Electro-MechanicalTotalizer
HCM Hydraulic Control Module
HOM Hydraulic Option Module
HSC Hall Sensor Controller
HVU HighVoltage Unit
IEB I/O Extension Board
IFSF International Forecourt Standard Forum
IOB I/O Board
IRM Infra Red Module
LON Local Operating Network
MB251 Mainboard 80251
MP1 Magnetic Pulser 1
NBB Nozzle Bus Board (integrated in Main Board v3 and later)
OCB Option Controller Board
ODU Optional Display Board
OPB Option Peripheral Board
OPU Optional Peripheral Unit
PCB Printed Circuit Board
POS Point of Sale
SCG Self Calibrating Gas
SPI Serial Peripheral Interface
UAK User Access Keypad
UAM User Access Module
UPD Unit Price Display
VFM Vapour Flow Module
VRC Vapour Recovery Controller
WWC World Wide Calculator
Issue A

Page 1-8 Document Ref 905675-001 Rev 2
Introduction WWC T1 Set Up & Maintenance Manual
Issue A
This page is intentionally blank

WWC T1 Set Up & Maintenance Manual Product Information
Document Ref 905675-001 Rev 2 Page 2-1
Issue A
CONTENTS
2 PRODUCT INFORMATION .................................................................................... 2-2
2.1 System Description ..............................................................................................2-2
2.1.1 Operating Principles.............................................................................2-2
2.2 Main Components of the WWC ..........................................................................2-2
2.2.1 External Power Supply ........................................................................2-3
2.2.2 Mainboard............................................................................................2-3
2.2.3 I/O Board (version 3++) ......................................................................2-4
2.2.4 Transaction Displays............................................................................2-4
2.2.5 User Access Devices (UAK/UAM)...................................................2-4
2.3 Different Configurations ......................................................................................2-4
2.3.1 Standard dispensers with up to four single products............................2-5
2.3.2 Low-end dispensers : single product or twin configuration, super high
speed, single-sided (Fleet)....................................................................2-5
2.3.3 Vapour Recovery Controller Board (VRC) .........................................2-6
2.3.4 Option Controller Board (OCB) ..........................................................2-6
2.3.5 Hydraulic Option Modules (HOM)......................................................2-6
2.3.6 I/O Extension Board (IEB)..................................................................2-6
2.4 Product Option Matrix (POM).............................................................................2-6
2.5 Functionality .........................................................................................................2-6
2.5.1 Functionalities per hose........................................................................2-7
2.5.2 Functionalities per side.......................................................................2-10
2.5.3 Functionalities per dispenser ..............................................................2-16
2.5.4 Weights & Measures related Functionality........................................2-21

Page 2-2 Document Ref 905675-001 Rev 2
Product Information WWC T1 Set Up & Maintenance Manual
2 PRODUCT INFORMATION
2.1 System Description
The WWC (World Wide Calculator) is a ‘measuring system’ built to conform to the
international recommendations specified in the document OIMLR117 Edition 1995.
The WWC is also a peripheral within the different Tokheim filling station systems. As
such, the WWC software and hardware can be configured without modifying the
characteristics of the measuring system.
The WWC is based on the CoCa (Today’s Common Calculator). The hardware has been
re-designed to keep up with technological advances and to allow more flexibility in the
extended scope but the main controlling parts are structured in the same way as the CoCa.
The software is similar to the CoCa software with adaptations to the new hardware and
updated functionality on the kernel side to ensure the re-use of all application parts, with
only minor changes. For further details, refer to the separate documentation, WWC System
FunctionalDescription.
2.1.1 OPERATING PRINCIPLES
The WWC T1 Calculator has been built around a central microprocessor which
controls several other microcontrollers for the input and output devices e.g.
counters, indicators, peripherals etc.
For each road side (right and left) of the metering pump/dispenser, the double
pulse signals from one or more pulsers, mounted at mechanical volume meters,
are checked and the information is counted and displayed on the corresponding
transaction indicator unit.
One calculator can simultaneously control two deliveries - one at each side of
the dispenser. The data is checked through several hardware and software
security systems.
Connectiontoa fillingstationcontrolsystem (self-servicearrangement)is possible
through data communication. The calculator can also function as a standalone
unit whereby information is transmitted to the WWC via a remote control unit.
Forfurtherinformation onhardwarecomponents,general descriptionofa delivery,
data security and technical characteristics, refer to the separate documentation,
WWC System Functional Description.
2.2 Main Components of the WWC
The WWC consists of a number of modules which can be combined depending on the type
of the calculator and the number of products and options used. The main components
are:-
•External Power Supply (refer to see section 2.2.1)
•Mainboard (refer to section 2.2.2)
•I/O Board (refer to section 2.2.3)
•Transactions Displays (refer to section 2.2.4)
•User Access Devices (refer to section 2.2.5)
Issue A

WWC T1 Set Up & Maintenance Manual Product Information
Document Ref 905675-001 Rev 2 Page 2-3
ARCHITECTURAL OVERVIEW
Fig. 1 Calculator Block Diagram
2.2.1 EXTERNAL POWER SUPPLY
The external power supply contains the following components:-
•Apower distribution unit High Voltage Unit (HVU) including transformer
•A rechargeable back-up battery
2.2.2 MAINBOARD
The mainboard (version 3++) includes the calculator module and the Hydraulic
Controller Module (HCM):-
•The calculator module is able to manage two deliveries independently (one on
eachroadside);controlthedeliveries;maintain the volume and amount counters;
control the transaction displays and hydraulic units; and communicate with the
self-service device.
•The HCM is responsible for supporting the hydraulic interface by checking the
volume pulser devices; counting and checking the two incoming line volume
pulses; controlling the motor and valves and updating the electro-mechanical
totalisers.
Themainboardprovidesalltheinterfacesrequiredto drivethe‘low-end’ hydraulics
without the need for an I/O board - single product and twin functionality (two
motors, two pulsers, four valves).
Issue A
COM
Calculator Module
HCM
HVU
Mains
UAM/
UAK
OCB
Battery
VRC
Low End H
y
draulic
(Single/Twin)
UAK
Displa
y
s
Valves, motors and sensors
Mainboard MB251
I/O Board
H1 H2 H3 H4
H
y
draulic Units
(pulsers, valves, motors)
Dipnet
IEB
Communication
Interfaces
Nozzle Bus
Interface
OPB
CSD-L
CSD-F
Dispenser I/O
O
p
tional Peri
p
herals:
UPD
Product Indication
Others
IRM
12
3
5
4
HOM
Hydraulic Option Modules
I/O extensions
Dispenser li
g
ht,
Electr totaliser
CSD-L
CSD-F
OPU
ODU

Page 2-4 Document Ref 905675-001 Rev 2
Product Information WWC T1 Set Up & Maintenance Manual
Since the release of Version 3 of the mainboard, the NBB board has been
eliminated and the serial nozzle bus is directly controlled by the mainboard.
Two optional modules can be directly connected to the mainboard (piggy-back):-
•The COM (Communications adapter) is used to interface the hardware to the
various self-service devices.
•The IEB (I/O Extension Board) is used to connect the peripherals often used in
Single/Twin configurations e.g. preset keypad, simple set up and configuration
keypad.
2.2.3 I/O BOARD (VERSION 3++)
The I/O Board is a level converter and control signal distributor for one to four
single product hydraulic units.
2.2.4 TRANSACTIONDISPLAYS
The transaction displays indicate the transactions on each side of the dispenser
showing the volume, amount and fuel price of the actual delivery. For each
side, it is possible to add a ‘slave’ display. Two different types of display are
available:-
•CSD-L : Liquid Crystal Display device
•CSD-F : Electromechanical Display device (Ferranti)
2.2.5 USERACCESS DEVICES(UAK/UAM)
User Access Devices are used to set the basic set up and configuration for the
calculator and optional devices via an integrated keypad module for service
engineers (UAK) or via an infra-red remote control unit (UAM/IRM). It is
possible to get a readout of totals, errors and service parameters. Either the
UAK (also used for VRC configuration and calibration) or the UAM/IRM can
be used but both devices cannot be used in parallel.
2.3 Different Configurations
With the main components, the following configurations are possible:-
•Standard dispensers with up to four single products (refer to section 2.3.1)
•Low end dispensers: single product or twin configuration, super high speed single-sided
(Fleet) (refer to section 2.3.2)
In addition to the above configurations, the following options can be added via the Dipnet:-
•Vapour Recovery Controller Board (refer to section 2.3.3)
•Option Controller Board (refer to section 2.3.4)
•Hydraulic Option Modules (refer to section 2.3.5)
•I/O Extension Board (refer to section 2.3.6)
Issue A
