TOKYO INTERPHONE WFA-200 User manual

WIRE HARNESS CHECKER
Continuity checker for wire harness, cables, etc.
Special features
● Test capacity
● Connection data
● Continuity test
● Instantaneous open
cirucit test
● Diode circuit test
● Step test
● OK / NG count
● External output
● Outer shape
● Power source
: 64 to 384 points (64-point unit).
: Data by sampling or create data by PC.
: Checks Open, Mix and Short circuits.
:
Checks incomplete connections (a wire seems to be cut
or a terminal seems to be pulled out at any moment).
: Checks polarity, open and short of diode.
: Checks 10 different connection deta sequentially.
:
Indicates OK / NG count (NG count - only for manual start)
: Outputs the OK / NG state with a contact point signal.
: Compact size - much smaller than PC keyboard space.
: AC 85V to 264V. Usable at any countries.
SEARCHPOWER
TOKYO INTERPHONE Wireharness Checker
WFA-200
SEARCH OLB STOP SKIP
CANCEL START NEXT SET
WIRE HARNESS CHECKER
WFA-200
WFA-200

For more reliable testing
More versatile use with your PC
Available models and the capacities
1. Selectable the test mode : Auto start or Manual start
2. Available checking the circuit for an instantaneous open reaction.
AUTO start
When connected the test object to this machine, the continuity test will start automatically.
If the test is passed, an OK tremolo sound will be heard and counts up the OK (= passed
test object). Its data will be output external with a contact point signal.
The purpose of this function is to eliminate the insecure connections like a wire being cut
or terminal being pull out. If added some outer pressures, such as a vibraion, bending or
t wisting, or jerking to the test object, the insecure connection part may happen or occur the
instantaneous open reaction. If the checker would find this phenomenon, sounds the alarm
and indicates the part in question.
MANUAL start
Starts the test when pressed a start button after connecting the test object. If the test is
passed, an OK tremolo sound will be heard and counts up the OK.
I
n case of a failure test object (wire harness), an alarm sound to be heard and counts up
a NG. Possible to start by the external signal. Both OK / NG data will be output external
with a contact point signal.
Model Capacity (point) Model Capacity (point)
WFA-200-1 128 P
64 P
192 P
320 P
256 P
384 P
WFA-200-2
WFA-200-3
WFA-200-4
WFA-200-5
WFA-200-6
The point capacity can be increased up to 384P after purchase except WFA-200-6.
You can create a connection data securely and effectively !
Edit functions on the PC :
(1)
Edit and Print out of connection tables, terminal name lists, file names and test names.
Copy, shift, delete of a connection data.
Auto creation of a sequenced terminal name list.
Check the connection table and the terminal name list.
Auto input of an independent terminal.
Auto creation of 1 : 1 connection table.
In order to connect your PC to this machine, you need an optional program (software).
PC operate circumstance : Windows 2000 / XP
(3) Others :
(2) Test definition ( Set up of a STEP test).

AC IN
AC OUTOK/NG OUT
RS-232C
EXT.OU
T
FUSE
VOLTIMEDISPLANUSBSTART
Specifications
Rear panel
Front panel
Stand foot
1) Q'ty of test point
2) Test sensitivity
3) Starting test mode
4) External output
5) Diode circuit
6) OK sound
7) OK / NG count
8) Step test
9) Capacity between wires
10) Display
11) Saving q'ty of connection data
12) PC interface
13)
Connector for the test object
14) Power source
15) Dimensions and weight
: 64 ~ 384 points
: More than 200 ohms for Open, Less than 60K ohms for Short,
and 100 μsec at 128 points for instantaneous Open
: Auto / Manual start
: OK / NG signal output -- on contact point signal (
0.5 / 1 / 5 / 10
sec) - Open collector
: Two-way electricity test
: Select from four kinds of sounds
: Indicates up to 9999 counts for both OK and NG.
( Indication
of NG counts are only for the Manual start.)
: Possible to setup 10 steps.
: 0.2 μF
:16 digits, 2 lines LCD display
: 20 data
: USB : 64-pin flat cable with connector:
: AC 85V ~ 264V
: 290(W) x 130 (H) x 250 (D) mm, 6 Kgs.
SEARCHPOWER
TOKYO INTERPHONE Wireharness Checker
WFA-200
SEARCH OLB STOP SKIP
CANCEL START NEXT SET
WIRE HARNESS CHECKER
WFA - 200
SEARCHPOWER
TOKYO INTERPHONE
Wireharness Checker
WFA-200
SEARCH OLB STOP SKIP
CANCEL START NEXT SET
WIRE HARNESS CHECKER
WFA - 200
Using stand foot
SEARCHPOWER
TOKYO INTERPHONE
Wireharness Checker WFA-200
SEARCH OLB STOP SKIP
CANCEL START NEXT SET
WIRE HARNESS CHECKER
WFA-200

Optional accessories
1) Jig connection cable FC64-1.2K
2) Printer WKE-07
3) Tape cutter WTC-100E
4) "OK" marker OM-01
64 wires flat cable with connector at one side.
Cable length : 1.2 meters cable
(Possible to arrange an optional length on request)
Function : Print out of connection data, test
results, etc.
Features : High speed printing, light weight
Interface : RS-232C Serial interface
Accessories : connection cable, AC adaptor
Size & weight : 106(W) x 106(H) x 180(D) mm
0.5 Kgs.
When the test object (wire harness) is passed
the test, a fixed length of tape will come out and
paste a "OK" mark to the object.
(The tape length : 1 ~ 12 cm adjustable)
With a buzzer for tape cutting error.
Tape role : Cellophane tape (
1 or 3" inner dia.)
Size & weight : 91(W) x 128(H) x 178(D) mm
1.3 Kgs.
When the test object (wire harness) is passed
the test, a "OK" mark will be put automatically.
Available to change the mark.
Possible to combine the fitting position and the
mark position optionally.
Size : 74(W) x 50(H) x 28(D) mm
Nov. 7, 2006
Test name : A-150-0042
#1001 OK
50
28
74
64C
39-6, Udagawa-cho, Shibuya-ku, Tokyo 150-0042, Japan Tel : [phone] Fax : [phone]
