TOMINI H10 User manual

1
USER MANUAL

2
Catalogue
1. Document overview
1.1 Regarding the manual
1.2 Related conventions
2. Product overview
2.1 Product picture
2.2 Product configuration table
2.3 The controller of the scooter
2.4 The appearance
3. OPENING AND FOLDING E-SCOOTER
4. Riding operation
5. Battery and Charger
6. Contact information and Warranty

3
1.1 Regarding the manual
For your cycling safety, please read this manual carefully before
using H10 electric scooter , make sure you can ride H10 electric
scooter correctly.
Knowing all the warnings and precautions listed in this manual will
help you to ride your H10 electric scooter better.
If you have any questions or can not obtain the information you need
from this manual, please contact the authorized agent or the after
sales department.
1.2 Related conventions
The following instructions are applicable to the basic (user manual),
please pay special attention to "warning", "note" and "prompt".
Note
Your actions may lead to
personal injury
Prompt
Information about what the user needs
to be aware of or the function prompt

4
2. Product overview
H10 electric scooter is a small, efficient and economy personal
vehicle , its fashion sense of science and technology modeling, the
light structure design, strong lithium battery power, will give you a
pleasant riding experience.
2.1 Product picture

5
2.2 Product configuration table
Parameter
Description
Material
Aluminum
Battery voltage
48V15AH 48V18AH
52V15AH 52V18AH 52V23AH
Max Range
45-50KM / 50-60KM
Max Speed
25KM-45KM-65KM
Net weight/Gross weight
29KG/33KG
Max loading
120KG
Climbing Angle
35%
Screen
LED
Tire size
10INCH
Brake Mode
Disc break & Electric break
Charger
AC110-240V/50-60Hz
Charging time
9-12hours
Max Motor Power
48V 1200W*2
52V 1300W*2
Light
LED

6
2.3 The controller of the scooter
THROTTLE SPEED CONTROL
Push button of speed control to accelerate e-scooter

7
2.4 The appearance
1. The button
There are two buttons on the meter, the power. and function
keys
1. Useful
2. Press and hold the power button to turn on the power.
The battery power and speed are displayed instantaneously
according to the running state of the electric vehicle, and the single
mileage and accumulated mileage are displayed according to the
selected function
After the instrument is turned on, if there is no signal input for a
long time (3 minutes), the meter will automatically turn off the power;
when the instrument appears CA 2:00 interface, it means to enter the
countdown state after 2 hours of shutdown.
Short press the function key to change the display content of
the instrument. There are TIME, TRIP, ODO, DST, VOL, CH 2:00
characters, etc. The time is displayed when TIME is displayed, the single
mileage is displayed when TRIP is displayed, and the accumulated

8
mileage is displayed when the ODO is displayed. When the DST is
displayed, the remaining mileage is displayed (the mileage that the
electric vehicle can run according to the current battery remaining
capacity and the running state of the electric vehicle in the first few
minutes, the battery needs to be matched), the battery voltage is
displayed when the VOL is displayed; the CH 2:00 is displayed. Indicates
that the 2 hour shutdown countdown state (some models are not
available), as time passes, the time display phase decreases.
Short pressing the function button will change the gear
position. 1 is slow speed, 2 is medium speed, 3 is fast.
When the meter is turned on, press and hold the power button
again. to turn off the power

9
3. OPENING AND FOLDING E-SCOOTER
NOTICE
B e f o r e d r i v i ng y ou mu s t en s u r e t ha t t he Mbutton is i n s e r t ed a ll t he w a y i n to
the central folding mechanism. Otherwise you risk injuring yourself and
damaging the folding system!

10
Opening the scooter
STEP1 -
STEP2 -

11
STEP3 -
Step4-

12
Folding the scooter
STEP1-
STEP2-

13
STEP3
STEP4

14
4.Riding operation
Ready to start
1. Find a flat field.
2. Open the product as previously described.
3. Adjust Ttube height.
Driving (start assist)
1. Press the POWER button.
2. In order to ensure the safety of users, this product is set to assist
start .First, one foot on the E-scooter dock, the other one kick the
ground, keep sliding and sliding, then the E-scooter slowly and gently
speed up at the sametime.
3. The E-scooter start moving forward, at the same time put the foot on
the ground to the E-scooter dock. The greater the Angle of pull
accelerator, the car run faster.
Stopping
Brake handle gently pull back, immediately to cut off the power supply
and speed down, then place one foot on the ground. Remember do not to
brake hard. Because that would abrasion the single side of tyre, lead to
jump, it is not comfortable.
Note: If it is raining, do not use this product, unless control the speed less
than 10 km/h, and shall not brake hard, avoid to slip.
Like most sports, cycling is also there is the risk of injury and damage. By
choosing to ride E-SCOOTER the responsibility and all inherent risk is on
you. It is crucial that you know, understand and act according to safety
rules.

15
5. Battery and charger
Each E-scooter is equipped with unique lithium battery and charger, do
not use other sort charger, other sort charger can't charge for the
battery.
Lithium battery (ternary lithium battery)
Battery can be charged at any time, ensure the battery power is full at any
time, that is harmless for the battery; please charge once less than one
month, if keep it too long to be charged, please contact the dealer to
starting batteries again.
Charging instructions
1. Connect the charger cable to E-SCOOTER charging socket.
2. Connect another charger cable to the normal power supply socket
(AC100-240V).
Feed the charger power, charger indicator light is red, said is charging,
the indicator light is green, said the battery is full (it is best state to keep
the green light is on for two hours ).

16
6.Contact information and Warranty
6.1 Contact information
If you have any questions or request during the cycling, please
feel free to contact us. we will try our best to offer you.
6.2 Warranty
(the Scooter needs to be
ridden in normal way) Below
situation is not in the scope
of warranty:
(1)
The shell of the battery is opened.
(2) The connect jack was broken by human reason.
(3)
The appearance of the bike is broken.
(4)
The failure or damage caused by an irresistible forces (such
as a fire, an earthquake, etc) or a natural disaster (such as a
lightning strike).
(5) Beyond the warranty period
Manufacturer : Zhejiang Taimi Technology Co., Ltd.
