SXT Raptor 1200 User manual

SXT Raptor 1200 / Gekko 1200
OWNER’S MANUAL
HANDBUCH
MANUAL

I N T R O D U C T I O N 1
UNDERSTANDING THIS
M A N U A L 2
GENERAL SAFETY GUIDELINES 3
& RESTRICTIONS
• BEFORE EACH RIDE 4
• AFTER EACH RIDE 5
• ASSEMBLY INSTRUCTIONS 5
• FRONT PANEL E-SCOOTER 7
• HANDLE BAR 7
• STORAGE BOX 7
REARVIEW MIRRORS 8
BATTERY 9
• BATTERY RECYCLING 12
OWNER’S MANUAL
EN
READ THIS MANUAL BEFORE OPERATING YOUR
E-SCOOTER STRONGLY SUGGESTS THE OPERATOR OF THIS
PRODUCT BE 16 YEARS OF AGE OR OLDER
(if scooters max. speed is limited to 25 km/h we
recommend minimum age of 15 years)
GENERAL USAGE NOTES 13
• MAINTENANCE 14
• BRAKES MAINTENANCE 15
• FLAT TIRE REPAIR 15
OPERATING INSTRUCTIONS 18
• KEY AND THROTTLE OPERATION 18
• TORQUE/GEAR SWITCH 20
TECHNICAL INSTRUCTIONS 22
TROUBLESHOOTING 23
WIRING DIAGRAM 24

Dear Customer,
Wow! You are excited! You have just received your brand new E-Scooter! We are excited
too, because as designers and developers of our vehicles, we want to make you happy, and
we believe that your new e-scooter will give you lots of fun.
I know that you want to get this bike on the road immediately, but please STOP!
Why? Well, rst of all, you need to charge your batteries fully before using it. So, while your
electric scooter is charging, take the time to read this manual. We have worked hard to make
it as readable and fun as possible! This manual will help prevent injury and teach you how to
care for your new electric scooter.
• It is the Owner’s responsibility to carefully read all of the contents of this manual and to
comply with all laws pertaining to the operation of electrical scooters in your local jurisdic-
tion. If you have any questions please consult with the Laws web page or consult your local
department of motor vehicles for clarication.
• These electric scooters are classied as motor vehicles, to drive them on the roads, various
states have different laws.
• We have worked hard to provide you a quality product, well designed, and without
defects. That is our responsibility. You too have a part to play…with proper care and mainte-
nance and attention to motorbike safety rules, our e-scooter will give you years of enjoyment.
• Please read the instructions carefully before using. Do not ride this scooter until you have
read and thoroughly understand the Owner’s manual. It contains information critical to your
safety. If you have questions about the operation of this electric scooter, consult your autho-
rized dealer. It is extremely important that you follow the safety guidelines contained in this
manual in order to ensure your maximum safety. If you loan your scooter to anyone make
sure they also know how to operate it safely.
• When using, the load should not be greater than the maximum capacity, and please pay
attention to increase the braking distance during rainy or snowy days.
• This E-Scooter is not afraid of the rain and snow, but it can‘t be submerged in water. It will
cause short circuit and damage to the electric apparatus, when water submerges the rear
wheel electronic hub.
• The exposed metal contact on the battery box is positive and electronegative electrode,
can‘t be touched at the same time with wet hands, also it can’t be kept in touch with anything
metal at the same time, otherwise it will cause short circuit and accidents!
• Please don‘t dismantle and repair the spare parts by yourself, please go to the local
distributor or the servicing station to repair if necessary.
INTRODUCTION
I N T R O D U C T I O N S SXT-SCOOTERS
1

• Please take time to record the following information:
Recording Your Serial Number
VIN: __________________________________________________________
Model: ________________________________________________________
Color: ________________________________________________________
Date of Purchasing : _____________________________________________
Distributor: _____________________________________________________
This Manual contain many WARNING notes concerning the consequences of failure to
maintain or inspect your E-SCOOTER.
WARNING means that failure to follow the instructions following it may result in injury to
the rider or others during use, which may include loosing control and falling. Because any
fall can result in serious injury or even death, we do not repeat the warning of possible injury
or death whenever the risk of falling is mentioned.
CAUTION on the other hand means that failure to follow the instructions may result in
damage to the E-SCOOTER or component during installation or use. (i.e. risk or property
product damage only).
Thank you for the purchasing the electrical powered scooter, The product complies with the
European Motor Vehicle Safety Regulation Act 2002/24/EC).
UNDERSTANDING THIS MANUAL
I N T R O D U C T I O N S SXT-SCOOTERS
2

3
1. Don‘t weave through trafc or make any moves that may surprise people with whom you
are sharing the road.
2. Never carry anything which obstructs your vision or your complete control of the
E-SCOOTER or which could become entangled in the moving parts of the E-SCOOTER.
3. Never hitch a ride by holding on to another vehicle.
NEITHER WE NOR THE RETAIL SELLER OF THE E-SCOOTER IS RESPONSIBLE FOR THE
CONSEQUENCES OF FAILURE TO COMPLY WITH FEDERAL AND PROVINCIAL
ORDINANCES RELATING TO THE USE OF THE E-SCOOTER.
WARNING
ALWAYS USE A HELMET WHILE RIDING THE E-SCOOTER. EU safety regulations require that
you use a helmet like those used by human powered bike riders while riding the E-SCOOTER.
This E-SCOOTER should not be used under any circumstances without properly wearing a
helmet.
WARNING
IN ADDITION TO THE REQUIREMENTS ABOVE, THE E-SCOOTER IS NOT TO BE RIDDEN /
USED:
1. on any roadways where the speed limit is in excess of 45 km/h
2. on any sidewalks or pedestrian walkways.
3. on any bumpy, rough or unpaved surfaces.
4. in darkness without lights on
5. on sandy or gravel covered surfaces.
6. by any person weighing more than 150 kgs.
7. by any person with an inseam of less than 22“.
8. by any physically or mentally challenged person.
9.by any person with vision, balance, hearing or coordination impairments.
10. by any person using headphones or a cellular phone [ They mask trafc sounds and
emergency vehicle sirens, distract you from concentrating on what‘s going on around you,
and their wires can tangle in the moving parts of the E-SCOOTER , causing you to lose
control ].
11. to carry more than 4 kgs of cargo in the cargo compartment (in addition to the rider).
12. in excess of 45 kmph (with or without the motor activated).
13. by barefoot riders or those wearing sandals, open toed, high heeled, platform or slip
on footwear
GENERAL SAFETY GUIDELINES & RESTRICTIONS
GENERAL SAFETY GUIDELINES & RESTRICTIONS SXT-SCOOTERS

3
14. by any person who has ingested any alcohol or drug that could impair their ability to
operate the E-SCOOTER.
15. without 2 hands on the handle bar.
16. while not seated on the seat.
17. to jump ramps, curbs, or objects or attempt any stunts.
18. with excessive speed for the terrain, circumstances or maneuver with clothing or
extremities in close proximity to the drive chain or any moving parts.
19. beyond your ability or prior experience.
20. by stopping with only the front brake. Use both brakes simultaneously.
21. Do not try to accelerate and have the brake (s) on at the same time.
[This may cause damage to the motor or drive train or cause the motor or drive train to
overheat.]
BEFORE EACH RIDE:
CAUTION
1. Make sure you properly wear a helmet.
2. Wear protective clothing and gloves.
3. Wear eye protection that does not interfere with your
peripheral vision.
4. Check local and state laws before operating the E-SCOOTER in any area.
5. Make sure all tail/brake lights, turn signals and headlight are operational.
6. Make sure the horn is operational.
7. Make sure the brakes are properly adjusted and working correctly
(see further detailed instructions).
8. Make sure you understand how the brakes work and that your hands can reach and
squeeze the levers comfortably and hard enough to stop the E-SCOOTER safely.
9. Make sure all parts of the E-SCOOTER are properly and securely fastened and adjusted,
including but not limited to crank arms, wheels, all controls and cargo (Please refer to
Assembly Instructions).
10. Make sure the tires are not excessively worn, do not have tears or cuts, and are proper-
ly seated on the rim and inated to the proper pressure on the sidewall (DO NOT USE GAS
STATION PUMPS FOR INFLATION).
11. Make sure the wheels spin straight and that the rims are not bent or damaged (front
wheel must be undamaged for front brake to work properly).
12. Make sure the throttle is in the „OFF“ position before turning E-SCOOTER key on.
This will prevent the E-SCOOTER from moving forward without notice once the ignition key
is turned.
13. Make sure the “Air Switch” under the seat is in the ‘On” position before turning key on.
SXT-SCOOTERS
4

5
AFTER EACH RIDE:
WARNING
1. Make sure that the ignition key is turned OFF and that all keys are removed and
kept in a safe place.
2. Make sure to plug the battery on charge.
3. Make sure the throttle is rotated to the off position
4. Ensure that the kickstand is used so the E-SCOOTER will not fall over and get
damaged.
5. Ensure the E-SCOOTER is not kept outdoors or where moisture can damage it.
6. Do not charge or store the E-SCOOTER closer than 20 feet from any ame
(e.g. furnace, replace, water heater, space heater).
7. Do not allow children under 16 to play on or near the unattended E-SCOOTER
(if scooters max. speed is limited to 25 km/h we recommend minimum age of 15
years).
WARNING FAILURE TO FOLLOW THESE OPERATION INSTRUCTIONS CAN
RESULT IN SERIOUS INJURY OR DEATH OR COULD RESULT IN AN ELECTRICAL
SHORT AND OR FIRE.
WARNING DO NOT MAKE ANY ALTERATIONS OR MODIFICATIONS TO THE
MOTOR , OR ADD ANY PARTS NOT AUTHORIZED BY US. EXCEPT THOSE DIS-
CUSSED IN THIS MANUAL OR THOSE REQUIRED BY LAW. DO NOT REMOVE ANY
REFLECTORS, LIGHTS OR OTHER STANDARD EQUIPMENT. DOING THAT WILL
AVOID YOUR WARRANTY.
All authorized replacement parts are listed on the parts list enclosed or by calling
your local dealer.
ASSEMBLY INSTRUCTIONS
Your E-SCOOTER may come in three different ways:
a) 95% assembled -you only need to install the mirrors and the cargo box
b) 90% assembled -you need to install (a) plus front wheel
c) 85% assembled -you need to install (b) plus handle bar and some plastic elements.
All instructions for (a) and (b) are described below with supporting pictures.
GENERAL SAFETY GUIDELINES & RESTRICTIONS SXT-SCOOTERS

6
GENERAL SAFETY GUIDELINES & RESTRICTIONS SXT-SCOOTERS
a.1 FRONT WHEEL WITH DRUM BRAKE
The front end of the bike is attached to the
crate with a bolt which is the original axle.
Unscrew the nut carefully and remove the axle.
Locate the front wheel and insert the break
mechanism into it.
Insert the axle rst in the swing arm of the front
fork and then in the break drum and the wheel.
Make sure to apply the spacer before inserting
the axle in the other side of the fork. Tighten
the nuts rmly.
a.2 FRONT WHEEL WITH DISK BREAK
Before installing the front wheel gently take
apart disk break pads using a wide at
screwdriver, so the wheel disk can squeeze
between the pads. Push the speedometer black
cap against the wheel and position it in the way
that the axle bolt can go through it. Tighten
rmly the nut at the opposite side.
b) HANDLE BAR
Insert the top part of the handlebar into the
handlebar post as shown on the picture.
Locate the attachment bolt with the nut and the
spacer and insert the bolt in the hole from back
to front. Slide the spacer into the bolt with the
round side facing the handlebar post. Screw
the nut on top and tighten it. After attached,
the handlebar should look as on the picture on
the right.

3
7
GENERAL SAFETY GUIDELINES & RESTRICTIONS SXT-SCOOTERS
FRONT PANEL E-SCOOTER
Locate the front panel and connect the head light
wire plug to the correspondent plug at the front
of the scooter as shown on the picture. Insert the
plastic ns of the front panel at the corresponding
channels of the base (see the picture) and slide
it upwards until the holes of the back black cover
match the screw holes of the cover. Insert the
screws into the holes of the black back cover and
screw them onto the front cover.
E-SCOOTER
Locate the front panel and connect the head light
wire plug to the correspondent plug at the front
of the bike as shown on the picture. Locate the
front hole in the middle of the panel and use the
included short bolt to attach it to the body. Locate
all attachment points of the cover, insert the screws
into the holes of the black cover and screw them
onto the front cover.
STORAGE BOX
Locate the storage box and the hardware neces-
sary to mount it on the back of the Scooter. Mount
the scooter rack using the bolts and the nuts in the
package. Install the box on the top of the rack
using the metal bracket and bolts.

8
REARVIEW MIRRORS SXT-SCOOTERS
REARVIEW MIRRORS
REARVIEW MIRRORS
Locate the mirrors included with your E-
SCOOTER .Connect the three wires of the
mirrors to the same color wires coming out of
the mirror holes. Use a hexagonal („Allen“ or
„Hex“ wrench) to attach the mirrors as shown
in the pictures. Make sure you use the included
spacer under the mirror base if necessary. Then
screw the bolt onto the threaded ends as shown
on picture below.
When you are sitting on the scooter you can
adjust the mirrors by pushing the mirror surface
up, down, left and right.
Different Operating for assembly the Mirrors
for different scooter.
The mirror needs to be tightened fully for
assembly to be safe. Repeat the process for the
other mirrors. Once mirrors are installed, they
should look like the picture below. Make sure
to adjust the mirrors before use. so that you
can see behind you as you ride.

9
3
9
BATTERY SXT-SCOOTERS
BATTERY
BATTERY
BEFORE OPERATING YOUR NEW SCOOTER FOR THE FIRST TIME, CHARGE
THE BATTERY FOR 8-12 HOURS, BUT UNDER NO CIRCUMSTANCES IN EXCESS
OF 18 HOURS. Be sure to charge the E-SCOOTER after each use. Keeping
the battery properly charged will help extend the battery life. Do not use the
E-SCOOTER while the power indicator on the instrument panel shows low energy.
If the E-SCOOTER is over-used the battery‘s life will be reduced. The E-SCOOTER
uses a 60V (volt) battery pack. To charge the battery, connect the 3-pin plug into
the charging receptacle located directly below the front seat. The battery must be
charged while installed in the E-SCOOTER. If you notice anything unusual about
the battery such as a cracked or leaking battery case, a battery that gets hot
while being used or charged, a battery case that appears „puffy“ or „bloated“
etc, or there are any other problems with the battery, please contact your local
dealer. The battery is sealed and is NOT user serviceable. Do not attempt to
repair, remove, adjust or in any way alter any internal or electrical components,
controls or wiring without rst speaking with a customer service representative.
The main battery weights approximately thirty ve (35) kgs. There are total ve
(5) cells (12V20Ah/cell) connecting with wires. There is no need to remove it from
the E-SCOOTER unless you are replacing it. Use caution on removal. Proceed
to pull the battery out utilizing the handle. Disconnect the battery cable. The
E-SCOOTER is equipped with a 60V battery charger that will interrupt the char-
ging process once the battery has received a sufcient charge. Hereby strongly
suggests that the charger not be used in excess of 18 hours to prevent any unne-
cessary wear on the battery or charger itself. Charging for periods greater than
18hours may reduce the overall life expectancy and efciency of these items.

CAUTION
DO NOT DROP THE BATTERY.
CAUTION
TO AVOID DAMAGE TO THE BATTERY WHEN
CHARGING, USE ONLY THE CHARGER PROVIDED WITH DEALER.
1. WARNING
DO NOT CHARGE OR STORE THE SCOOTER CLOSER THAN 20 FEET
FROM ANY FLAME (E.G. FURNACE, FIREPLACE, WATER HEATER,
SPACE HEATER)
2. Be sure to only use 110-230V AC with the E-SCOOTER charger. Also
make sure the plug is inserted into a three prong grounded AC outlet.
3. PLUG the POWER INPUT CORD into the E-SCOOTER charging recep-
tacle located below the front of the seat. See picture above.
4. Plug the 60V battery charger into a 110-230V AC power source.
5. The CHARGER INDICATOR LIGHT will illuminate conrming that pow-
er is connected to the charger. If the light does not come on check all
connections. If it still does not come on after checking all connections,
fuses and that your AC plug is working, unplug the charger and call
your local dealer.
6. WARNING
DO NOT KEEP THE SCOOTER CONNECTED TO THE CHARGER FOR
LONGER THAN 18 HOURS UNDER ANY CIRCUMSTANCES! DOING
SO COULD CAUSE THE BATTERY OR CHARGER TO OVERHEAT AND
CAUSE A FIRE.
7. When the light on the 60V charger is “red”, the E-SCOOTER battery
is being properly charged. When the E-SCOOTER battery is fully
charged, the light will turn “green”. If this does not occur after 16 hours
of charging, unplug the charger and call your local dealer. Normal
recharge time for the main battery is 6-8 hours (assuming it is not 100%
discharged).
10
BATTERY SXT-SCOOTERS

8. WARNING
NEVER LEAVE THE BATTERY CHARGER CONNECTED TO THE 220V
POWER SOURCE OR THE E-SCOOTER WHEN NOT CHARGING THE
BATTERY IN AMERICAN AREA.
KEEPING THE CHARGER PLUGGED INTO THE 110V/220V POWER
SOURCE AND NOT THE BATTERY COULD CAUSE THE CHARGER TO
OVERHEAT AND OR CAUSE A FIRE.
9. When storing your E-SCOOTER for lengthy periods of time, the
battery should be charged at least once a month to avoid full depletion.
WARNING
FAILURE TO KEEP THE E-SCOOTER BATTERY CHARGED WILL
CAUSE TOTAL BATTERY FAILURE. DO NOT ALLOW BATTERY TO
BECOME FULLY DISCHARGED!!! ALWAYS RECHARGE THE BATTERY
BEFORE THE POWER INDICATOR ON THE INSTRUMENT PANEL
SHOWS NO POWER. ALLOWING THE BATTERY TO FULLY DISCHARGE
WILL REDUCE BATTERY LIFE AND MAY RUIN THE BATTERY OR COULD
CAUSE THE BATTERY OR CHARGER TO OVERHEAT AND CAUSE A
FIRE THE NEXT TIME THE E-SCOOTER IS CHARGED.
WARNING
BATTERY POSTS, TERMINALS, POWER CORDS AND BRAKE CABLES
MAY CONTAIN LEAD AND LEAD COMPOUNDS, AND OTHER
CHEMICALS. WASH HANDS AFTER HANDLING.
9
3
11
BATTERY SXT-SCOOTERS

BATTERY RECYCLING
When maintained and used properly, (by following charging and
storage guidelines), the Lead Gel Battery Pack used in this product has
a normal lifespan of two to three years. When the battery pack no
longer holds a charge or is unable to be charged properly, it should
be removed from the E-SCOOTER and delivered to a recycling facility.
Federal Laws prohibit disposal of lead-acid batteries in everyday trash.
Please contact your local solid waste or recycling authority for recycling
information in your area.
12
BATTERY SXT-SCOOTERS

GENERAL USAGE NOTES
Break-in Period: Your E-SCOOTER will last longer and work better when
it is broken in properly. Brake control cables and axle nuts may get loose
when a new E-SCOOTER is rst used and may require an adjustment.
W e suggest that the brakes and axle nuts be checked every 30 days
and adjusted if necessary.
Turning the throttle all the way up and riding the scooter all the time on
a full throttle will also reduce the range and the battery life. We suggest
you to start smoothly and turn the throttle 1/4 turn down when you
have built a momentum.
It is a good idea to keep a tool kit with you when you ride. You should
also carry a manual air pump (with gauge) to re-inate the tire if you
have a at or it becomes low during use.
If your E-SCOOTER sustains an impact:
WARNING
A CRASH OR OTHER IMPACT CAN PUT EXTRAORDINARY STRESS ON
COMPONENTS, CAUSING THEM TO FATIGUE PREMATURELY. COM-
PONENTS SUFFERING FROM STRESS FATIGUE CAN FAIL SUDDENLY
AND CATASTROPHICALLY, CAUSING LOSS OF CONTROL, SERIOUS
INJURY OR DEATH.
First, check yourself for injuries, and take care of them as best you can.
Seek medical help if necessary. Next, if your E-SCOOTER is damaged,
perform the checks described in this manual. If you are unable to x
any or all damage/problems, or if you nd any bent, scored, or discolo-
red parts, please call your local SCOOTER dealer.
WARNING IF YOU HAVE ANY DOUBT ABOUT THE CONDITION
OF THE SCOOTER OR ANY OF ITS PARTS, DONT USE IT. CALL YOUR
DEALER.
9
3
13
GENERAL USAGE NOTES SXT-SCOOTERS
GENERAL USAGE NOTES

MAINTENANCE
Technological breakthroughs have made components more complex
than ever before, and the pace of innovation is increasing. This on-going
revolution makes it impossible for this manual to provide all the informa-
tion required to properly repair and/or maintain your E-SCOOTER In
order to help minimize the chances of an accident and possible injury,
it is critical that you have all repair and maintenance work performed
regularly.
For more detailed maintenance instructions or for ordering replacement
parts please contact your E-SCOOTER dealer. Local bicycle retail stores,
which have service facilities in your area, can also assist you with
certain non-electrical repairs or adjustments that you are not qualied
to make or for which you do not have the specic or specialized tools
needed for repair.
The fact that these scooters have no combustion engine, no transmis-
sion, no belts, no chains, no clutch, no ignition plugs, no carburetor,
and uses no gasoline and no lubricants means it requires basically no
maintenance. The unique design of the direct drive system and the use
of regenerative brushless motor braking system conne all friction in
E-SCOOTER scooters only in the two bearings of the front axle and the
two bearings in the motor and make it much easier to maintain than
other electric scooters.
In generally all the regular mechanic maintenance is to:
• Adjust the brakes
• Check the nuts and bolts
• Check tire pressure
• Check the brake pads
14
GENERAL USAGE NOTES SXT-SCOOTERS

BRAKES MAINTENANCE
Rear break cables may get stretched. Tighten the nuts at the threaded
end of the cable to adjust them. If the breaking power decrease, check
the break pads. If necessary clean them with sand paper. If the break
pads are worn out, replace them. If the break cable is stretched to the
point that there is no more threads left at the end, unscrew the lever and
turned it away from the cable.
FLAT TIRE REPAIR
Your E-SCOOTER may come with tubeless tires or tires with tubes. For
tubeless tires we recommend to carry with you a tubeless tire repair
kit and use it if the magnitude of puncture permits. Then consult with a
professional tire repair service shop if this is sufcient.
WARNING Don’t ride or push your E-SCOOTER with at tire. This will
cause the tire beads to detach from the rim and possibly bent the rim.
If your E-SCOOTER comes with tube tires, follow the next instructions:
1. Depress the tire valve to let all the air out of the tube, which will assist
in removing the wheel from the Scooter.
9
3
15
GENERAL USAGE NOTES SXT-SCOOTERS
Rear Axle nuts -Check them
regularly

2. Remove the wheel from the E-SCOOTER using a wrench. Loosen the
nuts counterclockwise and make sure to remove the wheel retention
clips on the front wheel. Be sure to remember where all the spacers
and washers belong. For rear tire removal you will also need to slip
the chain off the rear sprocket to remove the wheel. The chain must be
properly reinstalled and retention when reinstalling the rear wheel.
3. Remove one bead of the tire from the rim by grasping it at a point
opposite the valve stem with both hands and, at the same time, lifting
and peeling one side of the tire off the rim. If the bead is on too tight for
you to unseat it with your hands use tire levers to lift the bead carefully
over the tire rim. Tire levers can be purchased at any local bike shop.
Push the valve stem through the wheel rim. Remove the inner tube.
4. Carefully check the outside and inside of the tire for the cause of the
puncture and remove any debris or damaging material from the inside
or outside of the tire.
WARNING IF THE TIRE IS CUT, YOU MUST REPLACE THE TIRE TO
PREVENT ANY SUDDEN AND CATASTROPHIC FAILURE CAUSING
LOSS OF CONTROL, SERIOUS INJURY OR DEATH. Replacement parts
are able to be purchased by calling your local scooter dealer
WARNING PATCHING A TUBE IS AN EMERGENCY REPAIR.
CARELESS PATCHING OR APPLYING SEVERAL PATCHES CAN
SERIOUSLY WEAKEN THE TUBE, RESULTING IN POSSIBLE TUBE
FAILURE, WHICH COULD CAUSE YOU TO LOOSE CONTROL AND
FALL. REPLACE A PATCHED TUBE AS SOON AS POSSIBLE.
5. Reinstall the tire and tube. Slip one tire bead over the rim. Insert the
tube valve through its hold in the rim. Feed the tube carefully into the
cavity of the tire. Inate the tube just enough to give it some shape.
Starting at the valve stem and working around both sides of the rim to
the side opposite the valve stem, use your thumbs to push and seat the
other bead of the tire inside the rim. Be careful not to pinch the tube
16
GENERAL USAGE NOTES SXT-SCOOTERS

between the tire bead and the wheel rim. If you have trouble getting the
last few inches of bead over the edge of the rim with thumb pressure,
use a tire lever and be careful not to pinch the tube.
CAUTION IF YOU USE A SCREWDRIVER OR ANY TOOL OTHER
THAN A TIRE LEVER, YOU ARE LIKELY TO PUNCTURE THE TUBE.
6. Check to make sure that the tire is evenly seated around both sides
of the rim and that the tube is inside the tire beads. Push the valve stem
into the tire to make sure that its base is seated within the tire’s beads.
Inate the tube slowly to the recommended pressure on the tire sidewall,
all the while checking to make sure that the tire beads stay seated in the
rim.
9
3
17
GENERAL USAGE NOTES SXT-SCOOTERS

KEY AND THROTTLE OPERATION
ON/OFF/LOCK Switch: (ignition)
1. E-SCOOTER is ON. Turn it ON only when you are ready to go.
Turn it OFF when you are not riding and remove key.
2. E-SCOOTER is OFF. Turn it OFF when not in use to preserve the
battery.
3. Push the key in on this position to lock the handlebar and turn it to
position.
4. Handlebar is locked. The key can be removed.
CAUTION
BEFORE OPERATING YOUR E-SCOOTER, MAKE SURE THAT THE
THROTTLE GRIP IS NOT ROTATED TO THE “ON” POSITION!!! MAKE
ALSO SURE THAT YOUR THROTTLE IS NOT “STICKY” AND ROTATES
FREELY BACK TO THE INITIAL POSITION SEE PICTURE FOR CORRECT
PLACEMENT OF LEVER BEFORE USAGE!!!
18
OPERATING INSTRUCTION SXT-SCOOTERS
OPERATING INSTRUCTIONS
