Tommy Docks Roll-In Dock Kit User manual

Roll-In Dock Kit
Assembly Instructions
Tommy Docks
4003 Dixie Ave, Wausau, WI 54401
Phone : [phone]
Toll Free : 866-675-1880
Fax : [phone]
www.tommydocks.com

Roll-In Dock Kit
Components
Wheels
Qty 2
59 ½” Long
Support Braces
Qty 2
72” Long Axle
Qty 1
Upright
Qty 2
Axle Brackets
with ½” Bolts
Qty 2
Plastic Hubcaps
Qty 2
Caps
Qty 2
Locking Collars
with ½” Bolts
Qty 2
Angle
Brackets
Qty 2
Corner
Bracket
Qty 2

Hardware
Tools
½” x 1 ½” Hexhead
Bolts and Nuts
Qty 2
¼” x 1 ½”
Lagbolts
Qty 4
For bolting angle
brackets to a wood
frame dock
¼” x 1”
Hexhead Bolts
Qty 4
For bolting angle
brackets to a metal
frame dock
Hammer ⁄”Wrenches
Qty 2
¾”Wrenches
Qty 2
Tape Measure
1Flip deck over. Align Corner Brackets to corners of Deck (1a) and secure each Corner Bracket using
two (2) Lagbolts.
4x
1a
1b
Corner
Bracket

2Slide Blocks or Wood underneath Deck.
Blocks or Wood
3Slide each Upright into each Corner Bracket (3a). Measure so the Upright is XX” from Corner Bracket (3b).
3a
3b
Upright
Corner
Bracket
Upright

5
4Tighten each Bolt located on each Corner Bracket using a wrench..
Lower each Axle Bracket and each Locking Collar onto each Upright (5a). Let each Locking Collar
slide downward. Tighten bolt on each Axle Bracket using a wrench (5b).
Corner
Bracket
4a
4b
Axle Bracket
Axle Bracket
Locking Collar

7
6Remove each Bolt from each Locking Collar (6a). Align each end of each Support Brace with each
Locking Collar and secure using the bolt removed earlier (6b).
Lift each Support Bracket upward so it is flush with the bottom of each Axle Bracket (7a). Tighten
bolt using wrench (7b).
6a
6b
Support Brace
Locking
Collar
7a
7b

9
8Hold Support Brace parallel to Deck Frame and align end of Support Brace with Angle Bracket.
Secure each Angle Bracket to each Support Brace using one (1) Bolt and one (1) Nut (8a). Tighten
using two (2) wrenches as shown (8b).
Secure each Angle Bracket to Deck Frame using two (2) Lagbolts (9a). If you are installing onto an
Metal Deck Frame, secure each Angle Bracket to Metal Deck Frame using two (2) Hexhead Bolts,
Two (2) Nuts and Two (2) Washers per Angle Bracket (9b).
4x 4x 4x 4x
Wood Deck Frame
Wood
Deck Frame
Metal Deck Frame
9a
9b
or
Metal
Deck Frame
6a
Angle Bracket
2x 2x
6b

11
10 Insert Axle through both Axle Brackets (10a). Tighten Bolt using wrench (10b).
Slide each Wheel onto axle (11a) and secure by placing a hubcap onto end of axle and pounding with
a hammer (11b).
10b
10a
Support Brace
11a
11b
Wheel
Hubcap

12 Flip assembly over (12a). Insert Cap onto top of each Upright (12b).
Cap
12a
12b
Upright
