Breezesta AD-0113 User manual

REV01-4/19
SINGLE COASTAL GLIDER
AD-0113
1 AD-0113 Assembly
1-877-904-1234
www.Poly-Lumber-Furniture.com

A
B
C
D
F
E
a b c d
Suggested Tools:
Drill, Plastic Mallet
e
G
H
I
J
K
L
M
f
PARTS
PART DESCRIPTION PART NO. QTY
A FRONT LEG ASSEMBLY SA-00101 2
B UNDER ARM SUPPORT PRT-00146 2
C LEFT BACK LEG ASSEMBLY SA-00102 1
D RIGHT BACK LEG ASSEMBLY SA-00103 1
E LEFT ARM ASSEMBLY SA-00087 1
F RIGHT ARM ASSEMBLY SA-00088 1
G SEAT ASSEMBLY SA-00104 1
H STOP BAR PRT-00194 1
I BASE SIDE RAIL PRT-00192 2
J LEFT BASE FOOT ASSEMBLY SA-00099 2
K RIGHT BASE FOOT ASSEMBLY SA-00100 2
L BACK ASSEMBLY SA-00069 1
M SINGLE GLIDER SPREADER SS-11 2
HARDWARE
PART DESCRIPTION PART NO. QTY
a #8 X 2" TORX SCREW H-0000-S82 10
b #8 X 2-1/2" TORX SCREW H-0000-S825 4
c 5/16" X 1-1/2" CHAIR BOLT H-0000-CB51615 6
d 5/16" X 2-1/8" CHAIR BOLT H-0000-CB516218 14
e DOUBLE SCREW H-0000-DS 4
f T20 & T25 TORX BIT H-0000-CTD 1
AD-0113 Assembly 2
1-877-904-1234
www.Poly-Lumber-Furniture.com

e
x2
E
C
A
T20
b
x2
B
G
L
T25
d
x6
T20
T25
a
x2
c
x2
1.
Starting with Part C, attach Parts C & A to
Part E by inserting Hardware d into the pre-
drilled holes and rotating clockwise, stopping
when the assembly is tight
3.
Repeat Steps 1 & 2 with
Parts A, B, F, D
4.
Attach Part G to the previous
assemblies using Hardware d
5.
Slide Part L into place & attach
it with the hardware shown
Please read entire instructions
before beginning
2.
Place Part B into the pre-cut
slot and attach with Hardware b
3 AD-0113 Assembly
1-877-904-1234
www.Poly-Lumber-Furniture.com

T20
a
x4
I
x2
M
x2
T20
a
x4
H
T25
d
x8
J
x2
K
x2
T25
c
x4
6.
Attach Parts M between Parts I as shown
7.
Connect Part H to the previous
assembly using Hardware a
9.
Assemble the base to the upper as
shown, starting from the front & moving
to the back
8.
Attach Parts K & J as shown
