Tommy Docks TD-10072 User manual

Winch Leveling
Assembly Instructions
Model # TD-10072
Tommy Docks
4003 Dixie Ave, Wausau, WI 54401
Phone : [phone]
Toll Free : 866-675-1880
Fax : [phone]
www.tommydocks.com
Thank you for choosing our Tommy Dock Interlocking system. The following instructions assume you
have chosen your Tommy Dock layout and examined the bill of materials. The bill of materials describes
all necessary hardware, post (refer to post length formula), and optional accessories to assemble and
install your Tommy Dock system. Ask your dealer for answers to any questions you may have.
Caution: Use only cordless power tools when near or on water.

Winch Leveling Components Tools
Winch Lock
Leveler
½ ” B o x
End Wrench
1
2 3
Winch Leveling Setup. Attach Strap to Winch Assembly following the instructions provided by the
Winch manufacturer. Attach the 1/2” x 3” Bolt and 1/2” Nylon Insert Hex Nut to the Upper Winch
Tube. Attach the Strap Hook to the Leveling Hook.
Leveling Operation. Place Winch Leveling
Assembly onto the Pipe Leg.
Unwind the Winch Strap and place the
Leveling Hook under the Dock Bracket.
Leveling
Hook
Dock
Bracket
Winch Lock
Leveler
Pipe
Leg

4
6
5
Wind the Winch until the Winch Stap becomes
taut (4a). Loosen the single 1/2” Dock
Bracket Adjusting Bolt adjacent to the
Leveling Hook (4b).
Tighten the 1/2” Dock Adjusting Bolt.
Remove the Winch Leveling Assembly and
repeat the procedure on the next Pipe Leg.
Note: Depending upon the amount of ad-
justment that is required to level the Dock
Section, it may be necessary to repeat the
previous leveling steps several times.
Lift or lower the Dock to achieve a level
position.
1/2” Dock Bracket
Adjusting Bolt
Dock
Water Line
Bracket
4a
4b
1/2” Dock Bracket
Adjusting Bolt
