Tommy Docks 4’ Cedar Bench User manual

4’ Cedar Bench
Assembly Instructions
Tommy Docks
4003 Dixie Ave, Wausau, WI 54401
Phone : [phone]
Toll Free : 866-675-1880
Fax : [phone]
www.tommydocks.com

4’ Cedar Bench
Components
⁄ x 6” x 48”
Deck Board
Qty 4
⁄ x 6” x 16”
Deck Board
Qty 2
Mount Assembly
Qty 2
Seat Assembly
Qty 2
Backrest Assembly
Qty 2

Hardware
Tools
⁄” x 1 ¼”
Truss Head Screws
Qty 20
⁄” x 1 ¼”
Hex Head Lag Screws
Qty 8
⁄” Drill Bit
Qty 1
⁄”Wrench
Qty 1
Tape Measure Drill Pencil
1Lower the Seat Rear Board and the Seat Front Board onto Seat Assembly. The Seat Rear Board has
holes spaced 4” apart (1a) and the Seat Front Board has holes 2” apart (1b). Secure boards to Seat
Assembly using four (4) Truss Head Screws per board (1c).
8x
Seat Front Board
Seat
Rear Board
Seat Assembly
Seat Rear Board
4”
Seat Front Board
2”
1c
1a
1b

2Place Back Top Boards onto Backrest Assembly. The Back Top Boards have holes spaced 3” apart
(2a). Secure boards to Back Top Boards to Backrest Assembly using four (4) Truss Head Screws per
board (2b).
3Lower Armboards onto Backrest Assembly and secure each Arm Board using two (2) Truss Head Screws
per board.
8x
Backrest Assembly
Back Top Board
Back Top Board
Back Top Board
3”
2b
2a
4x
Arm Board
Backrest Assembly

4Place Back Assembly into Seat Assembly by inserting the Mount Assembly Dowel Shaft into the Seat
Assembly Leg.
Back Assembly
Seat Assembly
Mount Assembly
Dowel Shaft
Seat
Assembly Leg

6
5Clamp each Mount Assembly to deck (5a). Space both Mount Assemblies so they are XX” apart on
center and mark with pencil (5b).
Using the holes in the Mount Assemblies as a template, drill a 7/32” pilot holes into the dock at each
corresponding hole location (6a and 6b).
Mount
Assembly
Clamp
Deck Frame
Deck Surface
5a
5b
6a
6b

8
7Secure each Mount Assembly to the dock at each corresponding hole location using four (4) Lag
Bolts per Mount Assembly (7a and 7b).
Place Assembly into each Mount Assembly by inserting the Mount Assembly Dowel Shaft into the
Mount Assembly Leg.
7a
7b
8x
Mount Assembly
Dowel Shaft
Mount
Assembly Leg
