TomTom LTO 200D User manual

TomTom

Before you start1.
2
Before you start
Switching on
Follow the instructions at the start of this manual to dock your TomTom in
your car stereo. Your TomTom can also be used without docking it in your car
stereo. A mount is available as an accessory so that you can use your
TomTom in other cars.
The first time you switch on your TomTom, it may take up to 20 seconds to
start. To switch off your TomTom, press and hold the On/Off button for 2
seconds.
Setting up
To set up your navigation device, you need to answer a few questions by
tapping the screen.
Important: Take care to select the correct language, since the language you
choose will be used for all menus and written instructions.
Troubleshooting
Always make sure that you are using the latest version of the TomTom
application on your TomTom. You can update the application using TomTom
HOME.
If you have problems turning on your TomTom, try resetting your TomTom.
To reset your TomTom, usea straightened paper clip, orsomethingsimilar, to
push the reset button. The reset button is on the bottom of your TomTom.
Then turn your TomTom on.
Take care of your TomTom
Never leave your TomTom or accessories on view when you leave the car or
they may become an easy target for thieves.
You can set a password for your TomTom which must be entered every time
you start your TomTom.

3
It is important to take care of your TomTom.
• Your TomTom is not designed for use in extreme temperatures and any
such exposure may cause permanent damage.
• Do not open the casing of your TomTom under any circumstances. Doing
so may be dangerous and will invalidate the warranty.
• Wipe or dry the screen of your TomTom using a soft cloth. Do not use any
liquid cleaners.
Light sensor
Your TomTom uses a light sensor to detect the background light level and can
automatically adjusts the brightness of the screen and switch to night view.
To use the light sensor to make these changes, tap Brightness preferences in
the Preferences menu. You can then select these options:
•Turn brightness down when dark
•Switch to night view when dark
Link night view to headlights
If you select Link night view to headlights in the settings on your car stereo,
your TomTom will switch to night view when you switch on the headlights in
your car. See the manual for your carstereofor information about the settings.

Driving View2.
4
Driving View When your TomTom starts, you are shown the Driving View along with
detailed information about your current location.
Tap the centre of the screen at any time to open the Main Menu.
Note: The Driving View is shown in black and white until your TomTom
locates your current position.
ATap + and - to zoom in and out.
BQuick menu - switch this on in the Preferences menu.
CYour current position.
DThe name of the next major road or road sign information, if applicable.
ETraffic bar - traffic information is available either through the stereo using
RDS-TMC or from TomTom Traffic. TomTom Traffic requiresa Bluetooth®-
enabledmobilephone.Formoreinformationabouthowtosubscribetoand
receive TomTom Traffic, go to tomtom.com/services.
To set up traffic information, tap TomTom Traffic in the Main Menu.
FNavigation instruction for the road ahead.
Tap this area to repeat the last spoken instruction and to change the
volume.
GThe name of the street you are on.
HInformation about your journey such as journey time, remaining distance
and arrival time.
To change the information shown, tap Status bar preferences in the
Preferences menu.
IGPS signal strength.

Making your first journey3.
5
Making your first journey Planninga routewith your TomTom is easy.To planyourfirst route, followthe
steps below.
Important: You should always plan your journey before you start driving. It is
dangerous to plan a route while driving.
1. Tap the screen to bring up the Main Menu.
Note: The buttons on your TomTom are shown in full colour unless a button
is currently unavailable. For example, the button named Find alternative... in
the Main Menu is not available until you have planned a route.
2. Tap Navigate to...
3. Tap Address.
When you enter an address, you can choose from the following options:
•City centre - tap this button to set your destination as the centre of a city
or town.
•Street and house number -tapthisbuttonto set anexact address asyour
destination.
•Postcode - tap this button to enter a postcode as your destination.
Note: You can enter a postcode for any country. In the UK and the
Netherlands, postcodes are detailed enough to identify a house on their own.
In other countries you can enter a postcode to identify a town or area. You will
then have to enter a street and house number.

6
•Crossing or intersection - tap this button to set your destination as the
point where two streets meet.
•Spoken address - tap this button to set your destination by announcing
the address to your TomTom.
In this example, we will enter an exact address.
4. Tap Street and house number.
Note: When planning a trip for the first time your TomTom asks you to choose
a country. Your choice is saved and used for all routes you plan.
You can change this setting at any time by tapping the country flag.
Note: Spoken address input is not supported for all maps or for all languages.
5. Start to type the name of the town where you want to go.
As you type, the names of the towns that match what you have typed are
shown. When your destination appears in the list, tap the name of the town
to set the destination.
Tip: Instead of typing the name, tap this button to say the address by
speaking to your TomTom.
6. Start to type the name of the street and select it when it is shown.
As with the name of the town, the names of the streetsthat match what you
have typed are shown. When your destination appears in the list, tap the
name of the street to set the destination.
7. Now enter the house number of your destination and then tap Done.

7
8. Your TomTom asks if you need to arrive at a particular time. For this
exercise, tap NO.
The route is calculated by your TomTom.
9. When the route has been calculated, tap Done.
Your TomTom will immediately begin to guide you to your destination, using
both spoken instructions and on-screen directions.
Arrival times
When you plan a route, your TomTom asks you if you need to arrive at a
particular time.
Tap YES to enter a preferred arrival time.
Your TomTom calculates your arrival time and shows you whether you will
arrive on time.
You can also use this information to work out when you need to leave. If your
TomTom shows that you will arrive 30 minutes early, you can wait and leave
in 30 minutes time, rather than arrive early.
Yourarrivaltime isconstantly recalculatedduringyour journey.Thestatus bar
shows whether you will arrive on time or if you are going to be late, as shown
below:
You will arrive 55 minutes before the arrival time you entered.
If the estimated arrival time is more than five minutes before
the time you entered, it is shown in green.
You will arrive 3 minutes before the arrival time you entered.
If the estimated arrival time is less than 5 minutes before the
time you entered, it is shown in yellow.
You will arrive 19 minutes late.
If the estimated arrival time is later than the time you entered,
it is shown in red.

8
What are the other navigation options?
When you tap Navigate to..., you can set your destination in many ways, not
just by entering the address. The other options are listed below:
Status bar
preferences
Tap Status bar preferences in the Preferences menu, to enable or disable
arrival time notifications.
Select the required options on the first menu screen and then tap Done.
To enable arrival time notifications, select Show leeway to arrival time.
Home
Tap this button to navigate to your Home location.
You will probably use this button more than any other.
Favourite
Tap this button to select a Favourite as your destination.
Address
Tap this button to enter an address as your destination.
Recent
destination
Tap this button to select your destination from a list of places you have
recently used as destinations.
Point of
Interest
Tap this button to navigate to a Point of Interest (POI).
Point on map
Tap this button to select a point on the map as your destination using the
map browser.
Latitude
Longitude
Tap this button to enter a destination using latitude and longitude values.
TomTom
Buddy
Tap this button to navigate to the last known position of a TomTom Buddy.
Don’t forget that the Buddy may move before you reach him.
2
3
1
2

9
Planning a route in advance
You can also use your TomTom to plan journeys in advance by selecting both
your starting point and your destination. You could, for example, do the
following:
• Find out how long a journey is going to take before you start.
• Check the route of a journey you are planning.
• Check a route for someone who is coming to visit you, so that you can
explain the route to them.
To plan a route in advance, follow these steps:
1. Tap the screen to bring up the main menu.
2. Tap the arrow button to move to the next menu screen and tap Prepare
route.
3. Select the starting point for your journey in the same way that you would
select your destination.
4. Set the destination for your journey.
5. Choose the type of route that should be planned.
•Fastest route - the route which takes the least time.
•Shortest route -theshortestdistancebetweenthelocationsyouset.This
may not be the quickest route, especially if the shortest route is through
a town or city.
•Avoid motorways - a route which avoids motorways.
•Walking route - a route designed for making the journey on foot.
•Bicycle route - a route designed for making the journey on a bicycle.
•Limited speed - a route for a vehicle which can only be driven at a limited
speed. You have to specify the maximum speed.
6. Your TomTom plans the route between the two locations you selected.
More information about a route
You can access these options for the route you last planned by tapping View
route in the Main Menu or the Details button on the route summary screen.
You can then select from the following options:
Last docked
Tap this button to select the last recorded position where your TomTom
navigation device was docked, as your destination.
Prepare route
Browse as
text
Tap this button for a list of all the turn instructions on the route.
This is very useful if you need to explain a route to someone else.

10
Browse as
images
Tap this button to see each turn in the journey. Tap the right and left arrows
to move forwards and backwards through the journey.
Tap the screen to turn off the 3D display and view the map from above.
Browse map
of route
Tap this button to see an overview of the route using the map browser.
Show route
demo
Tap this button to watch a demo of the journey. You can interrupt the demo
at any time by tapping the screen.
Show route
summary
Tap this button to open the route summary screen.

Finding alternative routes4.
11
Finding alternative routes Onceyou haveplanned a route, youmay wantto change something about the
route, without changing your destination.
Why change the route?
Maybe for one of these reasons:
• You can see a roadblock or a line of traffic ahead.
• You want to travel via a particular location, to pick someone up, stop for
lunch or fill up with petrol.
• You want to avoid a difficult junction or a road you don’t like.
Find alterna-
tive...
Tap Find alternative... in the Main Menu to change the route that is
currently planned.
Then tap one of the options below.
Calculate
alternative
Tap this button to calculate an alternative to the route already planned.
Your TomTom will look for another route from your current location to your
destination.
If you decide you would prefer to use the original route after all, tap
Recalculate original.
Why would I need to do this?
Apart from the roads near your position and near your destination, the new
route will use totally different roads to reach your destination. This is an
easy way of calculating a totally different route.
Avoid
roadblock
Tap this button if you can see a roadblock or a line of traffic ahead. You then
have to choose how much of the route ahead you want to avoid.
Choose from the different options: 100m, 500m, 2000m, 5000m. Your
TomTom will recalculate your route avoiding the section of the route for the
distance you selected.
Don’t forget that once a new route is calculated, you may have to turn off
the road you are on very soon.
If the roadblock suddenly clears, tap Recalculate original to return to your
original route.

12
Travel via...
Tap this button to change your route so that it passes a particular location,
perhaps to pick someone up on the way.
You choose the location you want to pass in the same way as you choose a
destination. So you can select from all the same options: for example,
Address, Favourite, Point of Interest and Point on map.
Your TomTom will calculate a new route to your destination that passes the
location you chose. Unlike your final destination, your TomTom does not
inform you when you pass by this location.
Using this button, you can only travel via one location. If you want to pass
more than one, use an Itinerary.
Recalculate
original
Tap this button to return to the original route without deviations to avoid
roadblocks or travelling via particular locations.
Avoid part of
route
Tap this button to avoid a part of the route. Use this button if you see that
your route includes a road or junction you don’t like, or which is well-
known for traffic problems.
You then choose the road you want to avoid from a list of the roads on your
route.
Minimise
delays
Tap this button to recalculate your route so that it avoids traffic problems as
much as possible. Your TomTom will check if there are any traffic problems
on your route and work out the best route to avoid the problems.
Note: This button is only available if your device is receiving traffic
information from TomTom Traffic or RDS-TMC (the Traffic Message
Channel).

Menus5.
13
Menus
Main menu
Tap the screen at any time when TomTom displays the Driving View to open
the Main Menu.
•Navigate to...
Tap this button to start planning a route.
•Find alternative...
Tap this button if you want to avoid part of your route, travel via a specific
location or calculate an alternative route.
•Help me!
Help me! provides an easy way for you to find and contact emergency
service centres and other specialist services.
•Mobile phone
This button opens the mobile phone menu. You can, for example, make
calls, and write or read messages.
•Change preferences
This button opens the Preferences menu. You can change many things
about the way TomTom looks and behaves.

14
Hidden buttons and features
When you first start using your TomTom, not all the buttons will be shown in
the menu.
Many buttons and some more advanced features are hidden because you will
not need these features very often.
To show all buttons and features, tap Show ALL menu options in the
Preferences menu.
Tohidethese buttonsagain,tap Show fewer menu options inthe Preferences
menu.

Sounds and voices6.
15
Sounds and voices The sound on your TomTom is used for features such as:
• Spoken instructions
• Hands-free calls
• Warnings
How do I change the volume level?
You can change the volume in three ways:
• Tap the bottom left hand area of the Driving View. The last spoken
instruction is repeated and the volume level is shown.
Move the volume slider to adjust the volume.
• In the Main Menu, tap Change preferences, then tap Volume preferences.
Tap Test to check your changes.
• You can set your TomTom to change the volume automatically depending
on how noisy it is in the car.
Changing the volume automatically
Volume
preferences
Your TomTom can change the volume automatically.
1. In the Main Menu, tap Change preferences.
2. Tap Volume preferences.
3. Select Link volume to car speed.
4. Tap Done.

16
Selecting a voice
Voice
preferences
To change the voice being used by your TomTom, tap Voice preferences in
the Preferences menu, then tap Change voice. Select a voice from the list.
Your TomTom has two different kinds of voices:
• Computer voices
These are generated by your TomTom. They provide spoken
instructions while you are driving and can pronounce street names and
announce messages, traffic reports, weather reports, tips and tutorials.
•Humanvoices
These are recorded by an actor.
Note: Human voices only provide spoken instructions.

Using the car stereo7.
17
Using the car stereo The car stereo uses the TomTom navigation device to display information,
play videos, and show controls.
Through your TomTom navigation device, you can control the following:
•Theradio
• The Audio CD/CD-ROM/DVD player
•AniPod
• Music stored on a USB stick
For full details, see the owner’s manual included with the car stereo.
Switching to audio
To use your TomTom navigation device to control your car stereo, press and
immediately release the Screen button on the car stereo. You can switch back
to the navigation functions at any time by pressing the Screen button again.
To switch to other audio input sources, press the Source button on the car
stereo.
The volume of music and the radio is set by the volume control on the car
stereo. You can adjust the volume of spoken instructions and hands-free calls
separately by changing the volume on your TomTom navigation device.
Using the radio
Your TomTom navigation device shows the radio station that you are tuned to
and the frequency.
You can save the a station so that it is a preset. There are 6 presets per radio
band. To save a frequency, press and hold the number that you want to use
to save the frequency. When the colour of the button changes, the frequency
is saved.
Using an iPod® and USB storage devices
You can use your TomTom navigation device to play songs and videos saved
on an iPod® and songs stored on a USB storage device. The cable for
connecting an iPod to your car stereo is available as an accessory.

18
Note: Your TomTom must be docked in the car stereo to play back music or
videos stored on an iPod® or USB storage device
When you connect an iPod® or USB storage device and select one of these as
the audio input source, your car stereo starts to play the first song on the
iPod® or USB storage device.
To select your iPod® or USB storage device, press the Source button on your
car stereo until iPod or USB is shown on the display on your car stereo. To
select the song to play, tap Select. You can then choose the songs you want
to listen to.
•Playlist - tap this button to select a playlist.
Note: You can create playlists in a third-party application like iTunes®,
Musicmatch® or Winamp®. You must change the extension of playlist files on
USB storage devices from .M3U to .PLA.
•Song - tap this button to select from all the songs.
•Artist - tap this button to select a song by a particular singer or group.
•Genre - tap this button to select a particular type of music.
•Album - tap this button to select from a list of all the albums.
•Audiobooks - tap this button to select an Audiobook. Audiobooks can be
played from an iPod.
•Video - tap this button to play videos stored on your iPod. Videos stored on
a USB storage device cannot be played.
Important: You should not select songs or videos, or watch videos while
driving as this is dangerous.
To skip to the next or previous song, use the controls on the car stereo.
Note: Not all mp3 files contain information about the song, such as the artist
or genre. If the file contains no information, the file name is used as the song
title.
Back eye camera
The view from the back eye camera on your car can be shown on your
TomTom navigation device. The back eye camera must be connected
properly and your navigation device must be docked in the car stereo.
Toshowthe viewfromthe backeyecamera, pressand holdtheScreen button
on the car stereo until the back eye camera is shown. To switch back from the
back eye camera, press and immediately release the Screen button.

19
To switch automatically to the back eye camera when you are reversing the
car, set this in the Main unit settings.
For information about the Main unit settings, see the documentation for the
car stereo.

Browse Map8.
20
Browse Map To look at the map in the same way as you might look at a traditional paper
map, tap Browse map in the Main Menu.
You can move the map by touching the screen and moving your finger across
the screen.
AThe scale bar
BYour current position.
CGPS button
Tap this button to centre the map on your current position.
DOptions
EThe cursor
FThe Find button
Tap this button to find specific addresses.
GThe Cursor button
Tap this button to navigate to the cursor position, make a Favourite of the
cursor position, or find a Point of Interest near the cursor position.
HThe zoom bar
Zoom in and out by moving the slider.
Cursor button
You can use the cursor to find addresses and Points of Interest (POIs), for
example, restaurants, train stations and petrol stations.
