Tomura PS-9304S User manual

DVR User Manual
PS-9304S
PS-9308S
For H.264 4/8/16-channel digital video recorder
All rights reserved

Digital Video Recorder User Manual
2
CAUTION
Please read this user manual carefully to ensure that you can use the device correctly and safely
We do not warrant all the content is correct. The contents of this manual are subject to change without notice
This device should be operated only from the type of power source indicated on the marking label. The voltage
of the power must be verified before using. Kindly remove the cables from the power source if the device is not to
be used for a long period of time.
Do not install this device near any heat sources such as radiators, heat registers, stoves or other device that
produce heat
Do not install this device near water. Clean only with a dry cloth
Do not block any ventilation openings and ensure well ventilation around the machine
Do not power off the DVR when the device is function. The correct procedure to shut down DVR is to stop
recording firstly, and then use “shut down”button from the menu, and finally switching off the main power.
This equipment is for indoor use only. Do not expose the machine in rain or moist environment. In case any solid
or liquid get inside the machine’s case, please cut off the power supply immediately, and get it checked by a
qualified technician.
Refer all servicing to qualified service personnel. No any parts repaired by yourself without technical aid or
approval.
This manual is suitable for 4/8/16-channel digital video recorders. All examples and pictures used in the manual
are from 8-channel DVR.

Digital Video Recorder User Manual
3
Table of Contents
1Introduction...................................................................................................................................................................7
1.1 DVR Introduction.............................................................................................................................................................................................7
1.2 Main Features.................................................................................................................................................................................................7
2Hardware Installation ..................................................................................................................................................10
2.1 Install Hard Drive ..........................................................................................................................................................................................10
2.1.1 Install Hard Drive.................................................................................................................................................................................10
2.2 Front Panel Instructions ................................................................................................................................................................................11
2.3 Rear Panel Instructions.................................................................................................................................................................................13
2.3.1 Rear Panel Interface............................................................................................................................................................................13
2.4 Remote Controller.........................................................................................................................................................................................15
2.5 Control with Mouse.......................................................................................................................................................................................16
2.5.1 Connect Mouse...................................................................................................................................................................................16
2.5.2 Use Mouse..........................................................................................................................................................................................17
3Basic Function Instruction..........................................................................................................................................18
3.1 Power On/Off................................................................................................................................................................................................18
3.1.1 Power on ............................................................................................................................................................................................18
3.1.2 Power off ............................................................................................................................................................................................18
3.2 Login............................................................................................................................................................................................................19
3.3 Live preview..................................................................................................................................................................................................19
3.3.1 Live playback......................................................................................................................................................................................20
4Main menu setup guide...............................................................................................................................................21
4.1 Basic configuration........................................................................................................................................................................................22
4.1.1 System ...............................................................................................................................................................................................22

Digital Video Recorder User Manual
4
4.1.2 Time & date.........................................................................................................................................................................................24
4.1.3 DST....................................................................................................................................................................................................24
4.2 Live configuration..........................................................................................................................................................................................25
4.2.1 Live.....................................................................................................................................................................................................25
4.2.2 Main monitor.......................................................................................................................................................................................26
4.2.3 Spot....................................................................................................................................................................................................27
4.2.4 Mask...................................................................................................................................................................................................28
4.3 Record configuration.....................................................................................................................................................................................29
4.3.1 Enable................................................................................................................................................................................................29
4.3.2 Record stream ....................................................................................................................................................................................29
4.3.3 Time ...................................................................................................................................................................................................30
4.3.4 Stamp.................................................................................................................................................................................................31
4.3.5 Recycle record....................................................................................................................................................................................32
4.3.6 Snap...................................................................................................................................................................................................32
4.4 Schedule configuration..................................................................................................................................................................................32
4.4.1 Schedule.............................................................................................................................................................................................33
4.4.2 Motion.................................................................................................................................................................................................34
4.4.3 Sensor................................................................................................................................................................................................34
4.5 Alarm configuration.......................................................................................................................................................................................35
4.5.1 Sensor................................................................................................................................................................................................35
4.5.2 Motion.................................................................................................................................................................................................38
4.5.3 Video loss...........................................................................................................................................................................................40
4.5.4 Other alarm.........................................................................................................................................................................................40
4.5.5 Alarm out ............................................................................................................................................................................................41
4.6 Network configuration....................................................................................................................................................................................42
4.6.1 Network ..............................................................................................................................................................................................42

Digital Video Recorder User Manual
5
4.6.2 Sub stream .........................................................................................................................................................................................43
4.6.3 Email..................................................................................................................................................................................................45
4.6.4 Other settings......................................................................................................................................................................................46
4.7 User management configuration....................................................................................................................................................................48
4.8 P.T.Z configuration.........................................................................................................................................................................................50
4.9 Reset............................................................................................................................................................................................................54
5Record search & playback and backup......................................................................................................................55
5.1 Time search..................................................................................................................................................................................................55
5.2 Event search.................................................................................................................................................................................................56
5.3 File management..........................................................................................................................................................................................57
5.4 Image...........................................................................................................................................................................................................58
5.5 Backup.........................................................................................................................................................................................................58
6Manage DVR................................................................................................................................................................60
6.1 Check system information.............................................................................................................................................................................60
6.1.1 System information..............................................................................................................................................................................60
6.1.2 Event information................................................................................................................................................................................60
6.1.3 Log information ...................................................................................................................................................................................60
6.1.4 Network information.............................................................................................................................................................................60
6.1.5 Online information...............................................................................................................................................................................60
6.2 Disk management.........................................................................................................................................................................................60
6.3 Upgrade .......................................................................................................................................................................................................61
6.4 Logoff...........................................................................................................................................................................................................61
7Remote Surveillance ................................................................................................................................................... 62
7.1 Accessing DVR.............................................................................................................................................................................................62
7.1.1 On LAN...............................................................................................................................................................................................62
7.1.2 OnWAN..............................................................................................................................................................................................63

Digital Video Recorder User Manual
6
7.2 The remote live preview interface as below:...................................................................................................................................................64
7.3 Remote playback & backup...........................................................................................................................................................................67
7.3.1 Remote playback ................................................................................................................................................................................67
7.3.2 Remote backup...................................................................................................................................................................................72
7.4 Remote System Configuration.......................................................................................................................................................................74
8Mobile Surveillance.....................................................................................................................................................75
8.1 By Phones with Windows mobile...................................................................................................................................................................75
8.2 By Phones with Symbian...............................................................................................................................................................................78
8.3 The operation method for iPhone mobile clients................................................................................................. Error! Bookmark not defined.
8.4 The installation & operation methods for Android mobile clients Software Installation........................................... Error! Bookmark not defined.
8.5 Installation and Operation methods for blackberry mobile phone Client...........................................................................................................94
8.5.1 Installation instruction for Blackberry mobile phone client......................................................................................................................94
8.5.2 Operation method for Black berry mobile phone client..........................................................................................................................97
Appendix A FAQ………………………………………………………………………………………………………………….............104
Appendix B Calculate Recording Capacity………………………………………………………………..…………………………108
Appendix C Compatible Devices…………………………………………………………………………………………………........109
Appendix D 4-CH DVR Specifications…………………………………………………………………………………………………110
Appendix E 8-CH DVR Specifications…………………………………………………………………………………………………111
Appendix F 16-CH DVR Specifications………………………………………………………………………………………………..112

Digital Video Recorder User Manual
7
1 Introduction
1.1 DVR Introduction
This model of DVR (Digital Video Recorder) is designed for high performance CCTV solutions. It adopts state of the art
video processing chips and embedded Linux system. Meanwhile, it utilizes most advanced technologies, such as standard
H.264 with low bit rate, Dual stream, SATA interface, VGA output mouse supported, IE browser supported with full remote
control, mobile view(by phones), etc., ensuring powerful functions and high stability. Due to these distinctive characteristics,
it is widely used in banks, telecommunication, transportation, factories, warehouse, and other related applications.
1.2 Main Features
COMPRESSION FORMAT
Standard H.264 compression with low bit rate and better image quality
LIVE SURVEILLANCE
Support HD VGA output
Support channel security by hiding live display
Display the local record state and basic information
Support USB to make full control
RECORD MEDIA
Support one SATA HDD to record for a longer time without any limitation
BACKUP
Support USB 2.0 devices to backup

Digital Video Recorder User Manual
8
Support saving recorded files with AVI standard format to a remote computer through internet
RECORD & PLAYBACK
Record modes: Manual, Schedule, Motion detection and Sensor alarm recording
Support recycle after HDD full
Resolution, frame rate and picture quality are adjustable
128MB for every video file packaging
4 audio channels available
Two record search mode: time search and event search
Support 4/8/16 screen playback simultaneously
Support deleting and locking the recorded files one by one
Support remote playback in Network Client through LAN or internet
ALARM
1 channel alarm output and 4/8/16 channel alarm input available
Support schedule for motion detection and sensor alarm
Support pre-recording and post recording
Support linked channels recording once motion or alarm triggered on certain channel
Support linked PTZ preset ，auto cruise and track of the corresponding channel
PTZ CONTROL
Support various PTZ protocols
Support 128 PTZ presets and 8 auto cruise tracks
Support remote PTZ control through internet
SECURITY
Customize user right: log search, system setup, two way audio, file management, disk management, remote login,

Digital Video Recorder User Manual
9
live view, manual record, playback, PTZ control and remote live view
Support 1 administrator and 15 users.
Support event log recording and checking, events unlimited
NETWORK
Support TCP/IP, DHCP, PPPoE, DDNS protocol
Support IE browser to do remote view
Support setup client connection amount
Support dual stream. Network stream is adjustable independently to fit the network bandwidth and environment.
Support picture snap and color adjustment in remote live
Support remote time and event search, and channel playback with picture snap
Support remote PTZ control with preset and auto cruise
Support remote full menu setup, changing all the DVR parameters remotely
Support mobile surveillance by smart phones , Symbian, WinCE, Iphone , Gphone, or Blackberry, 3G network
available
Support CMS to manage multi devices on internet

Digital Video Recorder User Manual
10
2 Hardware Installation
Notice: Check the unit and the accessories after getting the DVR.
Please disconnect the power before being connected to other devices. Don't hot plug in/out
2.1 Install Hard Drive
2.1.1 Install Hard Drive
Notice: 1.This series support one SATA hard drive. Please use the hard drive the manufacturers recommend specially
for security and safe field. Please refer to “Appendix C Compatible Devices 2”.
2. Please calculate HDD capacity according to the recording setting. Please refer to “Appendix B Calculate
Recording Capacity”.
Step1: Unscrew and Open the top cover
Step2: Connect the power and data cables. Place the HDD onto the bottom case as below.
Fig 2.1 Connect HDD
Step3: Mount the HDD as below.

Digital Video Recorder User Manual
11
Note: For installation convenience, please connect the power and data cables first, and then wind the screws to fix
the HDD.
Fig 2.2 Screw HDD
2.2 Front Panel Instructions
Notice: The front panel descriptions are only for reference; please make the object as the standard.
Item
Type
Name
Description
1
Work state
indicator
Power
Power indicator, when connection , the light is blue
HDD
When HDD is writing and reading , the light is blue
Net
When access to network , the light is blue
Backup
When backup files and data, the light is blue
Play
When playing video, the light is blue
REC
When recording, the light is blue
2
MENU/+
1. Enter menu in live
2. Increase the value in setup
BACKUP/-
1. Decrease the value in setup
2. Enter backup mode in live

Digital Video Recorder User Manual
12
Item
Type
Name
Description
Compound
button
RECORD/FOCUS
1. Record manually
2. FOCUS function enables at PTZ mode.
REW/SPEED
1. Rewind key
2. SPEED function enables at PTZ mode
SEARCH/ZOOM
1. Enter search mode
2.ZOOM function enables at PTZ mode.
PLAY /IRIS
1. Enter play interface
2. IRIS function enables at PTZ mode
FF/ P.T.Z.
1. Fast forward
2. Enter PTZ mode in live
STOP/ESC
1. Quit play mode
2. Exit the current interface or status
3
Digital button
1-9
Input number 1-9 or choose camera
0/10+
Input number0, 10 and the above number together
with other digital keys
4
Input button
Direction button
Change direction to select items
Multi-screen
Change screen display mode like1/4/9/16 channel
Enter button
Confirm selection
5
IR receiver
IR
For remote controller
6
USB
USB port
To connect external USB devices like USB flash,
USB HDD for backup or update firmware; or connect
to USB mouse
7
POWER
POWER
Shot switch off

Digital Video Recorder User Manual
13
2.3 Rear Panel Instructions
2.3.1 Rear Panel Interface
The rear Panel interface for 4-ch is shown as Fig 2.3:
Fig 2.3 Rear Panel for 4-ch
Item
Name
Description
1
Video out
Connect to monitor
2
Spot out
Connect to monitor as an AUX output channel by channel. Only
video display, no menu show
3
Audio out
Audio output, connect to the sound box
4
Video in
Video input channels from 1-4
5
DC12V
POWER INPUT
6
VGA port
VGA output, connect to monitor
7
LAN
Network port
8
USB port
Connect USB mouse or connect external USB devices
9
P/Z
Connect to speed dome
10
K/B
Connect to keyboard
11
ALARM OUT
1-ch relay output. Connect to external alarm
12
+ 5V and GND
+5 V and Grounding
13
ALARM IN
Connect to external sensor1-4
14
Audio in
4 CH Audio input
Tab 2.1 Definitions of Front Panel Buttons
The rear Panel interface for 8-ch is shown as Fig 2.4:

Digital Video Recorder User Manual
14
Fig 2.4 Rear Panel for 8-ch
Item
Name
Description
1
Video out
Connect to monitor
2
Spot out
Connect to monitor as an AUX output channel by channel. Only
video display, no menu show
3
Audio out
Audio output, connect to the sound box
4
Video in
Video input channels from 1-8
5
DC12V
POWER INPUT
6
VGA port
VGA output, connect to monitor
7
LAN
Network port
8
USB port
Connect USB mouse or connect external USB devices
9
P/Z
Connect to speed dome
10
K/B
Connect to keyboard
11
ALARM OUT
1-ch relay output. Connect to external alarm
12
+ 5V and GND
+5 V and Grounding
13
ALARM IN
Connect to external sensor1-4
14
Audio in
4 CH Audio input
Tab 2.2 Definitions of Front Panel Buttons

Digital Video Recorder User Manual
15
2.4 Remote Controller
It uses two AAA size batteries and works after loading batteries as following:
Step1: Open the battery cover of the Remote Controller
Step2: Place batteries. Please take care the poles (+ and -)
Step3: Replace the battery cover
Notice: Frequently defect checking as following
1. Check batteries poles
2. Check the remaining charge in the batteries
3. Check IR controller sensor is mask
If it still doesn't work, Please change a new remote controller to try, or contact your dealers
The interface of remote controller is shown in Fig2.6 Remote Controller.
Fig 2.6 Remote Controller
Item
Name
Function
1
Power Button
Soft switch off to stop firmwarerunning. Do it before power off.
2
INFOR Button
Get information about the DVR like firmware version, HDD information
3
REC Button
To record manually
4
Digital Button
Input digital or choose camera
5
Multi Screen Button
To choose multi screen display mode

Digital Video Recorder User Manual
16
Item
Name
Function
6
SEARCH Button
To enter search mode
7
MENU Button
To enter menu
8
ENTER Button
To confirm the choice or setup
9
Direction Button
Move cursor in setup or pan/title PTZ
10
+/- Button
To increase or decrease the value in setup
11
Playback Control Button
To control playback, Fast forward/rewind/stop/single frame play
12
AUDIO Button
To enable audio output in live mode
13
Auto Dwell Button
To enter auto dwell mode
14
BACKUP Button
To enter backup mode
15
PTZ Control Button
To control PTZ camera:
Move camera/ZOOM/FOCUS/IRIS/SPEED control
Operation processes with remote controller to control multi-DVR
The device ID of the DVR is 0. When use of remote controller to control single DVR, it‟s not necessarily to reset the device
ID, user can do operation directly; when control multiple DVR with remote controller, please refer to below steps:
Step1: Activate remote controller to control DVR: enable DVR: turn the IR sensor of the remote controller to the IR receiver
that on the front panel, press the number key 8 twice, then input device ID (Range from: 0-65535; the default device ID is
0.) with other digital number: 0-9, after that, press ENTER button to confirm.
Step2: User can check the device ID by enter into System configurationBasic configurationdevice ID. User also can
set other DVRs with the same device ID. For more convenient to operate, we don‟t recommend user to set the device ID
too long.
Step3: Cancel controller to control DVR: turn the IR sensor of the remote controller to the IR receiver that on the front panel,
press the number key 8 twice, then input the device ID that needs to be cancelled from controlling, press ENTER button to
confirm. After that, the DVR will not be controlled by remote controller.
2.5 Control with Mouse
2.5.1 Connect Mouse
It supports USB mouse through the ports on the rear panel, please refer to Fig 2.6 Remote Controller.
Notice: If mouse is not detected or doesn't work, check below steps:

Digital Video Recorder User Manual
17
1. Make sure the mouse plugs in the USB mouse port not the USB port 2. Change a mouse to try
2.5.2 Use Mouse
The structure of the main menu is shown in Fig 2.6 Remote Controller.
In live: Double-click left button on one camera to be full screen display. Double-click again to return to the previous screen
display.
Click right button to show the control bar at the bottom of the screen as Fig 2.6 Remote Controller. Here are all control and
setup. Click right mouse again to hide the control bar.
In setup: Click left button to enter. Click right button to cancel setup, or return to the previous.
If want to input the value, move cursor to the blank and click. An input window will appear as Fig2.7. It supports digitals,
letters and symbols input.
Fig 2.7 Digital Numbers and Letters Input Window
Users can change some value by the wheel, such as time. Move cursor onto the value, and roll the wheel when the value
blinks.
It supports mouse drag. I.e. Set motion detection area: click customized, hold left button and drag to set motion detection
area. Set schedule: hold left button and drag to set schedule time
In playback: Click left button to choose the options. Click right button to return to live mode.
In backup: Click left button to choose the options. Click right button to return to previous picture.
In PTZ control: Click left button to choose the buttons to control the PTZ. Click right button to return to live.
Notice: Mouse is the default tool in all the operation below unless Exceptional indication

Digital Video Recorder User Manual
18
3 Basic Function Instruction
3.1 Power On/Off
Before you power on the unit, please make sure all the connection is good.
3.1.1 Power on
Step1: connect with the source power; switch on the power button near the power port in the rear panel
Step2: the device will be loaded, and the power indicator will display blue
Step3: before start, a WIZZARD window will be pop-up and show some information about time zone，time setup，network
configuration, record configuration and disk management. User can setup here and refer to the concrete setup steps from
the corresponding chapters. If users don‟t want to setup Wizard, please click Exit button to exit.
After the device power on, if there is no menu or only has live image display, user can long press ESC button to switch.
Notice: this serial device can only display menu on VGA monitor or BNC monitor at one time, if there is live image
display without menu display, please check up whether other device has menu display firstly, or long press ESC key to
wait for login dialog box to appear. Long press ESC key can switch the output between BNC and VGA.
3.1.2 Power off
User can power off the device by using remote controller,keyboard and mouse.
By remote controller:
Step1: press Power button, the Shut down window will appear, click OK, the unit will power off after a while.
Step2: disconnect the power
By keyboard and mouse:
Step1: enter into Menu, then select “System Shut Down” icon, the Shut down window will appear
Step2: click OK, the unit will power off after a while.
Step3: disconnect the power

Digital Video Recorder User Manual
19
3.2 Login
User can login and logout the DVR system. User cannot do any other operations except changing the multi-screen display
once logout.
Fig 3-1 Login
Notice: the default user name and password is “admin” and 123456”
The concrete operation steps for change password, add or delete user please refer to 4.7 User management
configuration for more details.
3.3 Live preview
Fig 3-2 live preview interface
Symbol
Meaning
Green
Manual record
Yellow
Motion detection record
Red
Sensor Alarm record
Blue
Schedule record

Digital Video Recorder User Manual
20
3.3.1 Live playback
Click Play button to playback the record. Refer to Figure3-3. User can do concrete operation by click the buttons on
screen.
Fig 3-3 live playback
