ToolPRO 610597 User manual

PLU: 610597
12V
1/2” RATCHET WRENCH SKIN

2
Customer Helpline 1300 858 645
Contents
Safety Information............................................................................................................................3
In The Box..........................................................................................................................................8
Accessories..............................................................................................................8
Operating Instructions.....................................................................................................................9
Maintenance.............................................................................................................16
Technical Data.................................................................................................................................17
Warranty..........................................................................................................18

3
Customer Helpline 1300 858 645
12V 1/2” RATCHET WRENCH SKIN
Safety Information
Warning Symbols
To reduce the risk of injury, Please read the instruction manual
Warning
Wear ear protection Wear eye protection
Wear dust mask Indoor use only
Do not expose to rain or water Do not burn
Waste electrical products must not be disposed of with household waste. Please
recycle where facilities exist. Check with your local authorities or retailer for
recycling advice.
Li-ion battery. This product has been marked with a symbol relating to
‘separate collection’ for all battery packs and battery pack. It will then be
recycled or dismantled in order to reduce the impact on the environment.
Battery packs can be hazardous for the environment and for human health
since they contain hazardous substances.
Fuse
Positive terminal
Negative terminal
Read the operator’s manual
Double insulation
RCM marking
Important - Please read these instructions fully before starting assembly

4
Customer Helpline 1300 858 645
Safety Information
Important - Please read these instructions fully before starting assembly
General Power Tool Safety Warnings
WARNING: Read all safety warnings and all instructions. Failure to follow the
warnings and instructions may result in electric shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
The term “power tool” in the warnings refers to your mains-operated (corded) power tool
or battery-operated (cordless) power tool.
1) Work area safety
a) Keep work area clean and well lit. Cluttered or dark areas invite accidents.
b) Do not operate power tools in explosive atmospheres, such as in the presence of flammable
liquids, gases or dust. Power tools create sparks which may ignite the dust or fumes.
c) Keep children and bystanders away while operating a power tool. Distractions can cause
you to lose control.
2) Electrical safety
a) Power tool plugs must match the outlet. Never modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power tools. Unmodified plugs and matching
outlets will reduce risk of electric shock.
b) Avoid body contact with earthed or grounded surfaces, such as pipes, radiators, ranges
and refrigerators. There is an increased risk of electric shock if your body is earthed or
grounded.
c) Do not expose power tools to rain or wet conditions. Water entering a power tool will
increase the risk of electric shock.
d) Do not abuse the cord. Never use the cord for carrying, pulling or unplugging the power tool.
Keep cord away from heat, oil, sharp edges or moving parts. Damaged or entangled cords
increase the risk of electric shock.
e) When operating a power tool outdoors, use an extension cord suitable for outdoor use. Use
of a cord suitable for outdoor use reduces the risk of electric shock.
f) If operating a power tool in a damp location is unavoidable, use a residual current device
(RCD) protected supply. Use of an RCD reduces the risk of electric shock.
3) Personal safety
a) Stay alert, watch what you are doing and use common sense when operating a power
tool. Do not use a power tool while you are tired or under the influence of drugs, alcohol or
medication. A moment of inattention while operating power tools may result in serious
personal injury.
b) Use personal protective equipment. Always wear eye protection. Protective equipment
such as dust mask, non-skid safety shoes, hard hat, or hearing protection used for
appropriate conditions will reduce personal injuries.
c) Prevent unintentional starting. Ensure the switch is in the off-position before connecting to
power source and/or battery pack, picking up or carrying the tool. Carrying power tools
with your finger on the switch or energising power tools that have the switch on invites
accidents.

5
Customer Helpline 1300 858 645
12V 1/2” RATCHET WRENCH SKIN
Safety Information
Important - Please read these instructions fully before starting assembly
General Power Tool Safety Warnings
d) Remove any adjusting key or wrench before turning the power tool on. A wrench or a key
left attached to a rotating part of the power tool may result in personal injury.
e) Do not overreach. Keep proper footing and balance at all times. This enables better control
of the power tool in unexpected situations.
f) Dress properly. Do not wear loose clothing or jewellery. Keep your hair, clothing and gloves
away from moving parts. Loose clothes, jewellery or long hair can be caught in moving
parts.
g) If devices are provided for the connection of dust extraction and collection facilities, ensure
these are connected and properly used. Use of dust collection can reduce dust-related
hazards.
4) Power tool use and care
a) Do not force the power tool. Use the correct power tool for your application. The correct
power tool will do the job better and safer at the rate for which it was designed.
b) Do not use the power tool if the switch does not turn it on and off. Any power tool that
cannot be controlled with the switch is dangerous and must be repaired.
c) Disconnect the plug from the power source and/or the battery pack from the power tool
before making any adjustments, changing accessories, or storing power tools. Such
preventive safety measures reduce the risk of starting the power tool accidentally.
d) Store idle power tools out of the reach of children and do not allow persons unfamiliar with
the power tool or these instructions to operate the power tool. Power tools are dangerous
in the hands of untrained users.
e) Maintain power tools. Check for misalignment or binding of moving parts, breakage of parts
and any other condition that may affect the power tool’s operation. If damaged, have the
power tool repaired before use. Many accidents are caused by poorly maintained power
tools.
f) Keep cutting tools sharp and clean. Properly maintained cutting tools with sharp cutting
edges are less likely to bind and are easier to control.
g) Use the power tool, accessories and tool bits etc. in accordance with these instructions,
taking into account the working conditions and the work to be performed. Use of the power
tool for operations different from those intended could result in a hazardous situation.
5) Battery tool use and care
a) Recharge only with the charger specified by the manufacturer. A charger that is suitable
for one type of battery pack may create a risk of fire when used with another battery
pack.
b) Use power tools only with specifically designated battery packs. Use of any other battery
packs may create a risk of injury and fire.
c) When battery pack is not in use, keep it away from other metal objects, like paper clips,
coins, keys, nails, screws or other small metal objects, that can make a connection from one
terminal to another. Shorting the battery terminals together may cause burns or a fire.

6
Customer Helpline 1300 858 645
Important - Please read these instructions fully before starting assembly
General Power Tool Safety Warnings
Safety Information
d) Under abusive conditions, liquid may be ejected from the battery; avoid contact. If contact
accidentally occurs, flush with water. If liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause irritation or burns.
6) Service
Have your power tool serviced by a qualified repair person using only identical replacement
parts. This will ensure that the safety of the power tool is maintained.
Safety points for your battery operated ratchet wrench
1. Hold power tool by insulated gripping surface, when performing an operation where
the fastener may contact hidden wiring. Fasteners contacting a “live“ wire may make
exposed metal parts of the power tool “live“and could give the operator an electric shock.
1. Before charging, read the instructions.
2. For charge Li-ion battery pack only.
3. Do not charge a leaking battery.
4. Do not use chargers for works other than those for which they are designed.
5. Before charging, ensure your charger is matching the local AC supply.
6. The charging device must be protected from moisture.
7. Do not use the charging device in the open.
8. Do not short out the contacts of battery or charger.
9. Respect the polarity “+/-“ when charging.
10. Do not open the unit and keep out of the reach of children.
11. Ensure that the connection between the battery charger and battery is correctly
positioned and is not obstructed by foreign bodies.
12. Keep battery charger’s slots free of foreign objects and protect against dirt and humidity.
Store in a dry and frost-free place.
13. When charging batteries, ensure that the battery charger is in a well-ventilated area
and away from inflammable materials. Batteries can get hot during charging. Do not
overcharge any batteries. Ensure that batteries and chargers are not left unsupervised
during charging.
14. Do not recharge non-rechargeable batteries, as they can overheat and break.
15. Longer life and better performance can be obtained if the battery pack is charged when
the air temperature is between 18°C and 24°C. Do not charge the battery pack in air
temperatures below 4.5°C, or above 40.5°C. This is important as it can prevent serious
damage to the battery pack.
16. Charge only battery pack of the same model provided by manufacturer and of models
recommended by manufacturer.
Additional safety instructions for your Battery Charger

7
Customer Helpline 1300 858 645
12V 1/2” RATCHET WRENCH SKIN
Safety Information
Important - Please read these instructions fully before starting assembly
a) Do not dismantle, open or shred cells or battery pack.
b) Do not short-circuit a battery pack. Do not store battery packs haphazardly in a box or drawer where
they may short-circuit each other or be short-circuited by conductive materials. When battery pack
is not in use, keep it away from other metal objects, like paper clips, coins, keys, nails, screws
or other small metal objects, that can make a connection from one terminal to another. Shorting
the battery terminals together may cause burns or a fire.
c) Do not expose battery pack to heat or fire. Avoid storage in direct sunlight.
d) Do not subject battery pack to mechanical shock.
e) In the event of battery leaking, do not allow the liquid to come into contact with the skin or eyes. If
contact has been made, wash the affected area with copious amounts of water and seek medical
advice.
f) Seek medical advice immediately if a cell or battery pack has been swallowed.
g) Keep battery pack clean and dry.
h) Wipe the battery pack terminals with a clean dry cloth if they become dirty.
i) Battery pack needs to be charged before use. Always refer to this instruction and use the correct
charging procedure.
j) Do not maintain battery pack on charge when not in use.
k) After extended periods of storage, it may be necessary to charge and discharge the battery pack
several times to obtain maximum performance.
l) Battery pack gives its best performance when it is operated at normal room temperature (20 °C ± 5 °C).
m) When disposing of battery packs, keep battery packs of different electrochemical systems separate
from each other.
n) Recharge only with the charger specified by manufacturer. Do not use any charger other than that
specifically provided for use with the equipment. A charger that is suitable for one type of battery
pack may create a risk of fire when used with another battery pack.
o) Do not use any battery pack which is not designed for use with the equipment.
p) Keep battery pack out of the reach of children.
q) Retain the original product literature for future reference.
r) Remove the battery from the equipment when not in use.
s) Dispose of properly.
Safety Warnings for battery pack

8
Customer Helpline 1300 858 645
In The Box
1
Accessories
3/8’ Adaptor
5
6
1
2
3
Sight light
On/off switch
Battery pack release button
Battery capacity indication
Direction selector
Battery pack
Locking switch
Ratchet head
3
5
1
4
7
4
7
8
8
2
6
Parts

9
Customer Helpline 1300 858 645
12V 1/2” RATCHET WRENCH SKIN
Intended Use
This tool is intended for the fastening and loosening of bolts, nuts and various threaded
fasteners.
This tool is not intended for use as a drill, Please check manually to ensure safety after
fastening, and we recommend tightening to manufactures specifications.
NOTE: Before using the tool, read the instruction book carefully.
1. CHARGING PROCEDURE
BEFORE PUTTING INTO OPERATION
CHARGING THE BATTERY PACK (SEE FIG A)
NOTE:
a) The battery in your new tool is not charged when it leaves the plant. Therefore it must be full
charged before using the first time.
b) Do not use any charger other than that specifically provided for use with the
equipment.
c) If the battery pack is very hot you must remove your battery pack from the charger and
allow time for the battery to cool down before recharging.
d) Please charge the battery to reach full or no less than half charge before storage. If the
tool will not be used for long periods of time, charge the battery every 3-6 months.
CHARGING PROCEDURE
1) Plug the charger into an appropriate outlet.
2) Place the battery pack into the charger.
3) When charging is completed,unplug the charger and remove the battery pack.
WARNING: When battery charge runs out after continuous use or exposure to
direct sunlight or heat, allow time for the battery to cool down before re-charging
to achieve the full charge.
Operating Instructions
LED INDICATOR
SITUATION
Green Red
Blinking light No light Stand by
No light Solid light Charging
Solid light No light Charging is complete
Blinking light Blinking light
Battery pack is too hot
or cold (charging will
begin automatically when
battery reaches correct
charging tem perature)
No light Blinking light Damaged or faulty
battery pack
A

10
Customer Helpline 1300 858 645
Operating Instructions
1. Slide switch
2. Battery level indicator
Pull the switch lever to indicate the
remaining battery capacity. When
release the switch lever, the indicator
lamps will light up for a few seconds.
1
2
2. INSTALLING AND REMOVING THE BATTERY PACK
a) To remove the battery pack
Press the Battery Pack Release Button (3) firmly first and then pull the Battery Pack out
from your tool.
b) To install the battery pack
Push the fully charged Battery Pack onto the tool with sufficient force until it clicks into
position.
3. TOOL / BATTERY PROTECTION SYSTEM
The tool is equipped with a tool/battery protection system. This system automatically
cuts off the power to extend tool and battery life. The tool will automatically stop during
operation if the tool or battery is placed under one of the following conditions:
a) Overload protection
This protection works when the tool is operated in a manner that causes it to draw an
abnormally high current. In this situation, turn the tool off and stop the application that
caused the tool to become overloaded. Then turn the tool on to restart.
b) Overheat protection
When the tool is overheated, the tool stops automatically and the lamp starts blinking. In
this situation, let the tool and battery cool before turning the tool on again.
c) Overdischarge protection
This protection works when the remaining battery capacity gets low. In this situation,
remove the battery from the tool and charge the battery.
4. INDICATING THE REMAINING BATTERY CAPACITY

11
Customer Helpline 1300 858 645
12V 1/2” RATCHET WRENCH SKIN
Operating Instructions
1
1. Switch lever
1. Lock lever 2. Lock 3. Unlock
NOTE: Depending on the conditions of use and the ambient temperature, the indication
may differ slightly from the actual capacity.
To start the tool, simply pull the switch
lever. Tool speed is increased by
increasing pressure on the switch lever.
Release the switch lever to stop.
To prevent the switch lever from
accidentally pulled, the lock lever is
provided.
When the lock lever is in the lock
position (2) , the switch lever cannot be
actuated.
When the lock lever is in the unlock
position (3), the switch lever can be
actuated.
Indicator lamps
Three green lights on Full Charged
30% to 60%
10% to 30%
Two green lights on
One green lights on
Lighted
Remaining
capacity
5. SWITCH ACTION
CAUTION: Before installing the battery cartridge into the tool, always check to see that
the switch lever actuates properly and returns to the “OFF” position when released.
CAUTION: When not operating the tool, always slide the lock lever to the lock position.
1
3 2

12
Customer Helpline 1300 858 645
Operating Instructions
CAUTION: Do not look in the light or see the source of light directly.
CAUTION: Always check the direction of rotation before operation.
CAUTION: Use the reversing lever only after the tool comes to a complete stop.
Changing the direction of rotation before the tool stops may damage the tool.
6. LIGHTING UP THE FRONT LAMP
7. REVERSING LEVER ACTION
This tool has a reversing lever to
change the direction of rotation. Turn
the reversing lever to the A side for
clockwise rotation or to the B side for
counterclockwise rotation. Make sure
that the reversing lever is fully turned
with a click.
1. Reversing lever
1. Switch lever
Pull the switch lever to light up the lamp. The lamp keeps on lighting while the switch lever
is being pulled.
The light automatically goes out approximately 10 seconds after the switch lever is released.
12
2. Lamp
NOTICE: When the tool is overheated, the lamp blinks. Cool down the tool fully before
operating the tool again.
NOTICE: Use a dry cloth to wipe the dirt off the lens of the lamp. Be careful not to scratch
the lens of lamp, or it may lower the illumination.
1
A side B side

13
Customer Helpline 1300 858 645
12V 1/2” RATCHET WRENCH SKIN
Operating Instructions
CAUTION: Always be sure that the tool is switched off and the battery cartridge is
removed before carrying out any work on the tool.
CAUTION: Before operation, make sure that the socket is properly locked onto the
socket adaptor. Incomplete attachment of the socket may cause injury.
NOTICE: Always use the correct size socket for bolt/ nut. An incorrect size socket will
result in inconsistent fastening torque and/or damage to the bolt/nut.
7. INSTALLING OR REMOVING SOCKET
Assembly
To install the socket, push it onto the ratchet head until it locks into place. To remove the
socket, simply pull it off.

14
Customer Helpline 1300 858 645
Operating Instructions
Operation
CAUTION: Hold the tool firmly especially when the bolt/nut reaches the seating
position. The socket stops rotating and the motor reactiongenerate instant
backlash to rotate the tool.
NOTICE: Hold the tool pointed straight at the bolt/nut.
NOTICE: Do not cover vents, or it may cause overheating and damage to the tool.
Hold the tool firmly and place the
socket over the bolt/nut. Turn the
tool on and fasten. When the bolt/ nut
reaches the seating position, the tool
stops automatically.
1. Vent
1

15
Customer Helpline 1300 858 645
12V 1/2” RATCHET WRENCH SKIN
Operating Instructions
Operating
USING AS HAND TOOL
NOTICE: Excessive fastening torque may damage the bolt/nut, the socket or the tool.
You can use the tool as a hand ratchet wrench by turning the tool in the direction arrows as
illustrated. In particular when loosening a stiff bolt/nut, loosen it by hand first then turn the
tool on.

16
Customer Helpline 1300 858 645
Maintenance
Your tool requires no additional lubrication or maintenance.
There are no user serviceable parts in your power tool. Never use water or chemical
cleaners to clean your power tool. Wipe clean with a dry cloth. Always store your power tool
in a dry place. Keep the motor ventilation slots clean. Keep all working controls free of dust.
Occasionally you may see sparks through the ventilation slots. This is normal and will not
damage your power tool.

17
Customer Helpline 1300 858 645
12V 1/2” RATCHET WRENCH SKIN
Technical Data
Technical Data Table
Ratchet head 1/2” Square head
No load speed 0-170/RPM
Maximum Torque 80Nm
Charger protection class /II
Charger input 100-240V~50/60Hz, 35W
Charger output 12V 2000mA
Machine weight 1.35kg (without battery)
Optional battery 2.0/4.0Ah Li-ion battery packs
Charging time 1hr for 2.0Ah battery pack
2hr for 4.0Ah battery pack

18
Customer Helpline 1300 858 645
Customer Helpline 1300 858 645
This product is guaranteed against defects a period of (3 years) from date of purchase. This
warranty is provided by SRGS PTY LTD ABN 23 113 230 050 of 6 Coulthards Avenue, Strathpine QLD
4500. Ph 1300 880 764. Supercheap Auto will offer a repair, replacement product or store credit if
the product is assessed as being defective during the warranty period.
To claim under this warranty, take this product to the Front Service Desk of your nearest
Supercheap Auto store. For store locations, visit www.supercheapauto.com.au (AUS) or www.
supercheapauto.co.nz (NZ). You will need your receipt or proof of purchase. Additional information
may be requested of you to process your claim. Should you not be able to provide proof of purchase
with a receipt or a bank statement, identification showing your name, address and signature may
be required to process your claim.
This product may need to be sent to the manufacturer to assess the defect before determining any
claim. Faults or defects caused by product modification, misuse and abuse, normal wear and tear
or failure to follow user instructions are not covered under this warranty.
Your warranty is subject to the following conditions:
• Battery packs are guaranteed for a 12 month period only.
• The tool has not been misused, abused, neglected, altered, modified or repaired by anyone other
than an authorized service centre.
• Only genuine ToolPRO accessories and parts have been used on or with the product.
• The tool has been subjected to fair wear and tear.
• The tool has not been used for trade or professional purposes.
• The tool has not been used for rental purposes.
• The tool has not sustained damage through foreign objects, substances or accidents.
Our goods come with guarantees that cannot be excluded under the Australian Consumer Law.
You are entitled to a replacement or refund for a major failure and for compensation for any
other reasonably foreseeable loss or damage. You are also entitled to have the goods repaired or
replaced if the goods fail to be of acceptable quality and the failure does not amount to a major
failure.
Any expenses incurred relating to the return of this product to store will normally have to be paid
by you. For more information contact your nearest Supercheap Auto store.
The benefits to the consumer given by this warranty are in addition to other rights and remedies of
the Austrailan Consumer Law in relation to the goods and services to which this warranty relates.
WARRANTY

19
Customer Helpline 1300 858 645
12V 1/2” RATCHET WRENCH SKIN
Staple your purchase receipt here
Before returning this product for
warranty or any other reason, please call.
FREE CALL 1300 858 645
Email: [e-mail]

PLU: 610597
CODE: LCW699-9C
Manufactured and packaged for
SRGS PTY LTD
ABN 23 113 230 050
6 Coulthards Avenue, Strathpine,
Strathpine QLD 4500, Australia
MADE IN CHINA
