Top CMS3 Series User manual

Thank you for choosing TOP VME .
CMS3 Series
Card Reader
User Guide

Contents
1. Product Introduction ............................................................................................... 1
1-1. Overview............................................................................................................................ 1
1-2. Features.............................................................................................................................. 1
2. Product Specifications............................................................................................. 2
2-1. General Specifications.................................................................................................. 2
2-2. Electronic Specifications.............................................................................................. 2
2-3. Machine Specifications ................................................................................................ 2
3. Product content......................................................................................................... 2
4. Product Dimension................................................................................................... 3
5. Installation Instructions .......................................................................................... 4
6. Application................................................................................................................... 5
7. Wiring ............................................................................................................................ 6
8. Function Description................................................................................................ 14
8-1. Setting and Display........................................................................................................ 14
8-2. Setting ................................................................................................................................ 14
8-2-1. GAME ........................................................................................................................ 14
8-2-2. Signal......................................................................................................................... 15
8-2-3. System....................................................................................................................... 15
8-3. Function Modes.............................................................................................................. 15
8-4. Operation Display .......................................................................................................... 16
9. Troubleshooting ........................................................................................................ 16

1
CMS3 Series
1. Product Introduction
1-1. Overview
The card management system can save labor costs, and reduce auditing
stress. All top-ups and cash settlements are completed at the cash
register to avoid unnecessary cash handling. This solves the problem of
miscalculation and difference between the cash and computer accounts of
other branches, and increase the time cost of checking and reconciling.
Easy to install and use, no need for network cable connection between
devices. Information is using and transferring by the memory of the CPU.
Without the computer management, each host can work independently.
After using the system management, the accounts are clearer, the handover
is simple, it is easy to check and manage at any time, and improve the work
efficiency of the playground.
All game cards can be transferred between players, and the venue does not
need to be recovered, but can be stored, refunded and deposited.
Applicable to all: game machine machines with the functions of opening
points, returning coins, and issuing lottery tickets.
1-2. Features
• Card Information High security
• Compatible with various game consoles
• Multiple devices can be connected in real time
• Available a variety of card management modes

2
Card Reader
2. Product Specifications
2-1. General Specifications
Communication
Interface RS232/PULSE
Card type Complies with ISO14443A, can support
Mifare1 S70 contactless smart card
Installation site Indoors
2-2. Electronic Specifications
Input power +12V DC
Power Consumption
Standby:1.5~1.6W
Working:2.3W
Max.:2.5W
Temperature Range (° C)
Ambient: 0~60
Storage:-10~80
Humidity:20~70%RH(no condensation)
2-3. Machine Specifications
Weight 154 ±10 g
Dimension 124 X 67 X 62.9 mm
Screen Size 18 Inch Screen
3. Product content
Main CMS 305(with RF) or 355(No RF) *1
Accessories
Manual
Wires (Check page…)
Screw set
CMS100H Adapter board(Optional)

3
CMS3 Series
4. Product Dimension
67 2.638
52 2.047
103 4.055 124 4.882
36.50 1.437
62.90 2.476
Unit : mm [inch]

4
Card Reader
5. Installation Instructions
(a)x4
(d)x4
(b)x4
(c)x4
42 1.654
52 2.047
58 2.283
93 3.661
114 4.488 103 4.055
C2[0.079]
5 0.197
-4Holes
Unit : mm [inch]
Recommended size
Installation:
1. Please follow the steps according to the recommended shape and size of
the door panel.
2. Align the mounting holes from the CMS3 (b) and the mounting holes on
the installing panel.
3. Insert the carriage screw (a) and push through the aligned mounting
openings (c) of the door panel.
4. Lock into place with the provided nuts (d).

5
CMS3 Series
6. Application

6
Card Reader
7. Wiring
Connector Interface Voltage Use Wire Pag.
J3 Power +12V
DC Power Cable WEL-R7U02 8
Power +12V
DC
Power
Extension CU-R961-1 9
CN1 RS232/
UART Data Transfer WEL-R7U06 (Purchase) 10
CN1 USB/UART Data Transfer 2WIR-CP2102N-00
(Purchase) 11
CMS100H PULSE/
HOPPER Data Transfer
2WIR-
CMS3000C-00
(Purchase)
12
CMS100H Power +12V
DC
CMS100H
Power cord
2WIR-CMS100G1-
0B
(Purchase)
13
CMS100H UART/
UART
CMS100H Data
transfer
2WIR-CMS100H1-
0A
(Purchase)
14
For Software update
WEL-R7U06
2WIR-CP2102N-00
WEL-R7U02
DIP Switch
Setting button

7
CMS3 Series
PIN NO COLOR PIN DEFINE
PIN1 RED +12V DC
PIN2 ORANGE GND
PIN3 YELLOW NC
NC
NC
NCPIN4 GREEN
PIN5 BLUE
PIN6 PURPLE
PIN NO COLOR PIN DEFINE
PIN1 YELLOW NC
PIN2 GREEN NC
PIN5 RED +12V DC
PIN7 BLUE NC
PIN8 PURPLE NC
PIN9 ORANGE GND
WEL-R7U02

8
Card Reader
CU-R961-1
PIN NO COLOR PIN DEFINE
PIN1 YELLOW NC
PIN2 GREEN NC
PIN5 RED +12V DC
PIN7 BLUE NC
PIN8 PURPLE NC
PIN9 ORANGE GND

9
CMS3 Series
WEL-R7U06
PIN NO PIN DEFINE
PIN2 TXD
PIN3 RXD
PIN5 GND
PIN NO COLOR PIN DEFINE
PIN1 BLUE GND
PIN6 WHITE VCC
PIN7 BLACK RXD
PIN8 PURPLE TXD

10
Card Reader
4
3
2
1
1
7
2
8
2WIR-CP2102N--00
PIN NO COLOR PIN DEFINE
PIN1 BLUE GND
PIN6 WHITE NC
PIN7 BLACK RXD
PIN8 PURPLE TXD
PIN NO PIN DEFINE
PIN1 GND
PIN2 USB DP
PIN3 USB DM
PIN4 USB +5V

11
CMS3 Series
2WIR-CMS3000C-00
1
2
3
4
6
5
7
8
9
10
11
12
PIN NO COLOR PIN DEFINE
PIN1 BLACK GND
PIN2 BROWN NOTE
PIN3 GREEN PAY+
PIN4 ORANGE TICKET_OUT
PIN5 YELLOW HOP_N
PIN6 RED +12V DC
PIN NO COLOR PIN DEFINE
PIN7 BLUE PAY-
PIN8 WHITE TICKET_IN
PIN9 PURPLE HOP_OUT
PIN10 GRAY METER_OUT
PIN11 PINK INHIBIT_IN
PIN12 WHITE/GREEN CREDIT_OUT

12
Card Reader
2WIR-CMS100G1-0B
PIN NO COLOR PIN DEFINE
PIN1 BLACK GND
PIN2 RED +12 DC

2WIR-CMS100H1-0A
PIN NO COLOR PIN DEFINE
PIN1 YELLOW GND
PIN7 BLACK TXD
PIN8 RED RXD
PIN NO COLOR PIN DEFINE
PIN1 YELLOW GND
PIN7 RED RXD
PIN8 BLACK TXD

14
Card Reader
8. Function Description
8-1. Setting and Display
1. 【○】Button: Open points, Set value confirmation, service request(long press)
2. 【▲】Button: Scroll up/add
3. 【▼】Button: Scroll down/less
4. 【●】Setting Button: Set the function mode of cms3
5. DIP Switch : Setting mode
8-2. Setting
Press the setting button for 1 seconds to enter the setting menu, then use
the buttons【▲】and 【▼】to select and the ，【○】button to confirm

15
CMS3 Series
8-2-1. GAME
1. Mode : Hopper or Pulse mode
2. Play : Opening points
3. Level : Signal level
8-2-2. Signal
Signal time width setting, units in ms
8-2-3. System
1. Card key : Card Key Setting
2. Version : Version Check
3. Channel : RFChannel、dBm Setting
8-3. Function Modes
Mode Function Dip Switch
1234
Mode 1 System: No Connection
Mode: RS232 (Without converter board) ON ON ON ON
Mode 2 System: Connected
Mode: RS232 (Without converter board) ON ON ON OFF
Mode 3
System: No Connection
Mode: Hopper or Pulse (With converter
board)
ON ON OFF OFF
Mode 4
System: Connected
Mode: Hopper or Pulse (With converter
board)
ON OFF OFF OFF
PC Setting
Mode PC Tool Tool Setting OFF OFF OFF OFF

16
Card Reader
8-4. Operation Display
Display Description
Credit Balance
Rate Score ratio
Ticket Ticket
Play Open Score
Ready Card Read
No card No card inserted
Unknow Unknown card
Invalid card Unknown card
9. Troubleshooting
Message Narrative Preventive action
Card limit Card used over 100K times Replace card
Version Err Firm. Version error Download the
correct firmware
Game no link Not connected to the
game Check the Game
Mode error Mode error Adjust Dip Switch
No link Host not connected Check wireless
communication
Write Error Card error Check card
