Topcom BABY VIEWER 2500 User manual

BABY VIEWER 2500
USER GUIDE / HANDLEIDING / MANUEL D’UTILISATEUR /
BEDIENUNGSANLEITUNG / MANUAL DE USUARIO / BRUKSANVISNING /
BRUGERVEJLEDNING / ANVÄNDARHANDBOK / KÄYTTÖOHJE /
MANUALE D’USOMANUAL DO UTILIZADOR / UŽIVATELSKÁ PÍRUKA /
  / HASZNÁLATI ÚTMUTATÓ / INSTRUKCJA OBSUGI /
UŽÍVATEL’SKÝ MANUÁL
V.1.1
UK The features described in this manual are published with reservation to
modifications.
NL De in deze handleiding beschreven mogelijkheden worden gepubliceerd onder
voorbehoud van wijzigingen.
FLes possibilités décrites dans ce manuel sont publiées sous réserve de
modifications.
DDie in dieser Bedienungsanleitung umschriebenen Möglichkeiten, werden
vorbehaltlich Änderungen publiziert.
ES Las características descritas en este manual pueden ser objeto de futuras
modificaciones.
SFunktionerna i denna bruksanvisning publiceras med reservation för ändringar.
DK Vi forbeholder os retten til ændringer af de specifikationer, der er beskrevet i denne
brugsanvisning.
NFunksjoner beskrevet i denne manualen kan endres uten nærmere informasjon.
SF Tässä ohjekirjassa julkaissut tiedot voivat muuttua ilman ennakkoilmoitusta.
IT Le caratteristiche descritte nel presente manuale vengono pubblicate con riserva di
modifica.
PT As características descritas neste manual são publicadas sob reserva de
modificação.
CZ Možnost úpravy funkcí popsaných v této píruce vyhrazena.
GR       ,  
  .
HU A jelen használati útmutatóban leírt adatokra a gyártó fenntartja a változtatás jogát.
PL Waciwoci opisane w niniejszej instrukcji obsugi s publikowane z zatrzeeniem
prawa wprowadzenia zmian.
SK Vlastnosti popísané v tejto príruke sú publikované s vyhradeným právom na
zmenu.

1
2
3
5
4
6
7
8
10
11
9
12
13
14
15
16
17
18
19
20
21
22
23
24
25
26
27
28
29
30

3
Topcom Baby Viewer 2500
ENGLISH
1 Introduction
Thanks for purchasing the Baby Viewer 2500. Now you can see and hear your baby during
sleeping or you can monitor your older children in their playroom.
2 Safety Instructions
WARNING:
Adult assembly required. Keep small parts away from children when
assembling.
This product is not a toy. Do not allow children to play with it.
• Always read the user guide instructions carefully before using the device
• Keep this User's Manual for future reference.
• Do not place the camera in the crib or within the arm’s reach of the baby.
• Never use extension cords with the enclosed AC adapters.
• Secure the cords away from babies reach.
• Test the monitor before use. Get confident with the functionallity.
• Do not use the monitor near water.
• Do not install the monitor on heat sources.
• Only use the charger plug supplied. Do not use other chargers, as this may damage the
battery cells.
• Only insert rechargeable batteries of the same type. Never use ordinary,
non-rechargeable batteries. Insert rechargeable batteries so they connect to the right
poles (indicated in the battery compartment of the handset).
• Do not touch the charger and plug contacts with sharp or metal objects.
3 Description
See folded cover page
3.1 Parent Unit
1. Display
2. VOX indicator LED (Voice Operated
Transmission)
3. Melody indicator LED
4. Volume indicator LED’s
5. Speaker
6. Link indicator LED
7. Power indicator LED
8. VOX button
9. Melody select button
10. Melody start/stop button
11. Antenna
12. Belt clip
13. Battery cover
14. DC power adapter Jack
15. On/Off/Volume switch
16. LCD brightness Low button
17. LCD brightness High button

4Topcom Baby Viewer 2500
Topcom Baby Viewer 2500
3.2 Baby unit
4 Getting started
4.1 Baby unit battery Installation
The camera uses either 4 AAA - Size batteries (alkaline batteries recommended) or the
household AC current. The Baby unit has no charging function.
1. Loosen the screw in a counter clockwise direction using a small screw driver. Remove
the battery cover.
2. Install 4 ‘AAA’ alkaline or rechargeable batteries following the polarity as shown. Close
the battery compartiment.
3. Slide the Power switch (26) to the ON position. The LED (24) on top of the camera
should light up green.
Slide the Power switch (26) to the OFF position to turn off the baby unit.
When the light is RED, the batteries are low and needs to be replaced.
Do not mix old batteries with new ones.
Keep batteries away from small children.
Do not short-circuit & dispose of in fire.
Remove the batteries if this device is not going to be used for a long period.
18. Night Light
19. Night Light button
20. Microphone
21. Support
22. Lens
23. Infrared LED’s
24. Power indicator LED
25. Antenna
26. On/Off switch
27. DC power adapter Jack
28. Battery cover
29. Speaker
30. Babybed fastener
2
1
3
1
2
3

5
Topcom Baby Viewer 2500
ENGLISH
4.2 Baby unit power supply
1. Connect the small plug of the AC adaptor to the Baby unit and the other end of the
adapter cable to the electric socket (230V/50Hz).
Only use the enclosed adapter (6V DC / 1,75A).
2. Slide the Power switch (26) to the ON position. The LED (24) on top of the camera
should light up green.
Slide the Power switch (26) to the OFF position to turn off the baby unit.
4.3 Parent unit battery Installation
1. Turn the belt clip facing upwards.
2. Press the battery cover and slide it downwards.
3. Install the rechargeable battery pack (3,7V Li-ion)
following the polarity as shown. Ensure that the
metal contacts touch the contact in the unit.
Close the battery door.
4. Turn the On/Off/Volume switch (15) counter
clockwise to turn the unit on and change to the
desired audio volume.
Turn the On/Off/Volume switch (15) clockwise to
turn the parent unit off.
4.4 Parent unit power supply
1. Connect the small plug of the AC adaptor to the parent unit and the other end of the
adapter cable to the electric socket (230V/50Hz)
2. Turn the On/Off/Volume switch (15) counter clockwise to turn the unit on and change to
the desired audio volume.
Turn the On/Off/Volume switch (15) clockwise to turn the parent unit off.
1
3
4

6Topcom Baby Viewer 2500
Topcom Baby Viewer 2500
Once the Baby unit and Parent Unit have been switched on, the display of the parent unit
must show the captured video from the Baby unit.
5 Using the Baby Viewer 2500
5.1 Fine tuning
• Place the camera in a convenient location, point the
lens of the camera to the observation area.
• Adjust the angle by rotation the baby unit.
Do not place the camera within the babies reach!
5.2 Fixing the camera
• Use the crib connector to fix the baby unit to the crib.
(See illustration)
5.3 Night Light
• Press the Night Light button (19). The night light (18)
will illuminate.
5.4 Night vision
The camera has 9 high-intensity LED’s for picking up clear
images in the dark. When the build in photo sensor
measures the ambient light level as low, the LED’s will
automatically activate.
5.5 Setting the Parent - Unit display brightness
• Press the Brighthess Low button (16) to make the display darker.
• Press the Brightness High button (17) to make the display brighter.
5.6 VOX function
• Press the VOX-button (8) on the side of the monitor. This will turn off the display, but the
VOX indicator (2) will turn on.
In VOX mode, the display will turn on when it is activated by the babies voice or other
sound around the baby unit. It will turn off again after 30 seconds.
• Press the VOX-button (8) again to turn off VOX - mode. The LCD will be on continously.
5.7 Melody function
You can remotely activate a melody broadcasted on the baby-unit.
• Press the Melody start/stop button (10) to active the melody.
• Press the Melody select button (9) to switch between 3 different melodies.
• Press the Melody start/stop button (10) to deactive the melody.

7
Topcom Baby Viewer 2500
ENGLISH
6 Disposal of the device (environment)
At the end of the product lifecycle, you should not throw this product into the
normal household garbage but bring the product to a collection point for the
recycling of electrical and electronic equipments. The symbol on the product, user
guide and/or box indicate this.
Some of the product materials can be re-used if you bring them to a recycling point. By re-
using some parts or raw materials from used products you make an important contribution to
the protection of the environment.
Please contact your local authorities in case you need more information on the collection
points in your area.
7 Cleaning
Clean the device with a slightly damp cloth or with an anti-static cloth. Never use cleaning
agents or abrasive solvents.
8 Specifications
Parent unit
Frequency
Maximum range
Modulation
Display
Display colors
Brightness control
Dimensions
Weight
Power
Operation temperature
2,4GHz
150M Line of Sight
GFSK,FHSS
2,36’’ TFT LCD
Full-color
5 steps
6,6(W)x14,5(H)x4,1(D) cm
120g
DC 6V, 800mA + Li-ion
battery (charging function)
0°C ~40°C
Baby unit
Frequency
Modulation
Image sensor
Lens
IR LED
VOX
Dimensions
Weight
Power
Operation temperature
2,4GHz
GFSK,FHSS
Color CMOS
f 6.0mm, F 2.0
9 pcs
Voice activation
8,9(W)x10,7(H)x8,2(D) cm
175g
DC 6V, 800mA or 4 x AAA
batteries (no charging function)
0°C ~40°C
This product is in compliance with the essential requirements and other
relevant provisions of the the R&TTE directive.
The Declaration of conformity can be found on:
http://www.topcom.net/cedeclarations.php

8Topcom Baby Viewer 2500
Topcom Baby Viewer 2500
9 Topcom warranty
9.1 Warranty period
The Topcom units have a 24-month warranty period. The warranty period starts on the day
the new unit is purchased. The warranty on batteries is limited to 6 months after purchase.
Consumables or defects causing a negligible effect on operation or value of the equipment
are not covered.
The warranty has to be proven by presentation of the original purchase receipt, on which the
date of purchase and the unit-model are indicated.
9.2 Warranty handling
A faulty unit needs to be returned to a Topcom service centre including a valid purchase note.
If the unit develops a fault during the warranty period, Topcom or its officially appointed
service centre will repair any defects caused by material or manufacturing faults free of
charge.
Topcom will at its discretion fulfil its warranty obligations by either repairing or exchanging
the faulty units or parts of the faulty units. In case of replacement, colour and model can be
different from the original purchased unit.
The initial purchase date shall determine the start of the warranty period. The warranty period
is not extended if the unit is exchanged or repaired by Topcom or its appointed service
centres.
9.3 Warranty exclusions
Damage or defects caused by incorrect treatment or operation and damage resulting from
use of non-original parts or accessories not recommended by Topcom are not covered by
the warranty.
Topcom cordless phones are designed to work with rechargeable batteries only. The
damage caused by the use of non-rechargeable batteries is not covered under warranty.
The warranty does not cover damage caused by outside factors, such as lightning, water and
fire, nor any damage caused during transportation.
No warranty can be claimed if the serial number on the units has been changed, removed or
rendered illegible.
Any warranty claims will be invalid if the unit has been repaired, altered or modified by the
buyer or by unqualified, non-officially appointed Topcom service centres.

9
Topcom Baby Viewer 2500
NEDERLANDS
1 Inleiding
Wij danken u voor uw aankoop van de Baby Viewer 2500. Hiermee kunt u uw baby zien en
horen tijdens zijn slaap of uw kinderen gadeslaan tijdens het spel in de speelkamer.
2 Veiligheidsvoorschriften
WAARSCHUWING:
Dit toestel moet door een volwassene worden geïnstalleerd. Houd bij de
installatie kinderen uit de buurt.
Dit product is geen speelgoed. Laat kinderen niet met het toestel spelen.
• Lees de gebruiksaanwijzing zorgvuldig door voor u het toestel gebruikt.
• Bewaar deze handleiding voor later gebruik.
• Plaats de camera niet in het kinderbedje of binnen het bereik van de baby.
• Gebruik nooit verlengsnoeren met de meegeleverde netadapters.
• Plaats alle kabels buiten het bereik van de baby.
• Test de monitor voor gebruik. Maak u vertrouwd met de werking ervan.
• Gebruik de monitor niet in de nabijheid van water.
• Plaats de monitor niet op warmtebronnen.
• Gebruik uitsluitend de meegeleverde adapter. Gebruik geen andere adapters, omdat dit
de batterijcellen kan beschadigen.
• Gebruik uitsluitend oplaadbare batterijen van hetzelfde type. Gebruik nooit gewone,
niet-oplaadbare batterijen. Let bij het plaatsen van de oplaadbare batterijen op de
polariteit (aangeduid in het batterijvak van de handset).
• Raak de laad- en stekkercontacten niet aan met scherpe en metalen voorwerpen.
3 Beschrijving
Zie flap van het voorblad.
3.1 Ontvanger
1. Display
2. LED VOX-indicator (Voice Operated
Transmission)
3. LED Melodie-indicator
4. LEDs Luidsprekervolume
5. Luidspreker
6. LED Verbindingsindicator
7. LED Stroomindicator
8. VOX-toets
9. Melodie kiezen-toets
10. Melodie starten/stoppen-toets
11. Antenne
12. Riemclip
13. Batterijdeksel
14. Aansluiting netadapter
15. Aan/Uit/Volume-toets
16. LCD lage helderheid-toets
17. LCD hoge helderheid-toets

10 Topcom Baby Viewer 2500
Topcom Baby Viewer 2500
3.2 Babymonitor
4 Beginnen
4.1 Batterijen in de babymonitor plaatsen
De camera werkt met 4 AAA batterijen (bij voorkeur alkalinebatterijen) of netspanning. De
babymonitor heeft geen oplaadfunctie!.
1. Draai met een kleine schroevendraaier de schroef van het batterijdeksel linksom.
Verwijder het batterijdeksel.
2. Plaats 4 AAA alkaline of oplaadbare batterijen en let daarbij op de polariteit. Sluit het
batterijvak.
3. Zet de Aan/Uit-schakelaar (26) op de AAN-positie. De LED (24) bovenaan de camera
licht groen op.
Zet de Aan/Uit-schakelaar (26) in de UIT-positie om de babymonitor af te zetten.
Wanneer het lichtje rood is, zijn de batterijen bijna leeg en moet u ze vervangen.
Plaats nooit nieuwe en oude batterijen samen in het toestel.
Houd de batterijen uit de buurt van kleine kinderen.
Sluit de batterijen niet kort en gooi ze nooit in het vuur.
Verwijder de batterijen wanneer u het toestel langere tijd niet gebruikt.
18. Nachtlamp
19. Nachtlamp-toets
20. Microfoon
21. Steun
22. Lens
23. Infrarood LEDs
24. LED Stroomindicator
25. Antenne
26. Aan/Uit-schakelaar
27. Aansluiting netadapter
28. Batterijdeksel
29. Luidspreker
30. Bevestigingsklem
2
1
3
1
2
3
