1Introduction
Congratulations with your purchase of the Topcom BPM Arm 1480. This fully
automatic, wrist mounted blood pressure monitor is both easy to use and ideally
suited for daily measurements. The large display includes systolic, diastolic
and pulse, all clearly shown at the completion of each reading.
In addition, you can store up to 48 measurements ine the memory, ideal for
users who want to monitor and track their blood pressure on a regular basis.
The BPM Arm 1480 is compact and portable, making it ideal for home use and
travel.
2 Safety instructions
1. This product is for household use only. It is not intended as a substitute for
consultation with your doctor.
2. For users diagnosed with common arrhythmia (atrial or ventricular
premature beats or atrial fibrillation), diabetes, poor circulation of blood,
kidney problems, or for users suffered from stroke, or for unconscious
users, the device might not be suitable for use. Consult your doctor in case
of any doubt.
3. The unit should not be operated by children so to avoid hazardous
situations.
4. The unit contains high-precision assemblies. Therefore, avoid extreme
temperatures, humidity, and direct sunlight. Avoid dropping or strongly
shocking the main unit, and protect it from dust.
5. Leaky batteries can damage the unit. Remove the batteries when the unit
is not used for a long time.
6. Do not press the START key when the cuff is not placed around the arm.
7. Do not disassemble the main unit or cuff.
8. If the unit is stored in a cold place, allow it to acclimate at room
temperature before use.
9. Clean the blood pressure monitor body and the cuff carefully with a slightly
damp, soft cloth. Do not press. Do not bend the pre-formed cuff inside out.
Do not wash the cuff or use chemical cleaner on it. Never use thinner,
alcohol or petrol (gasoline) as cleaner.
10. To ensure accurate measurements, it is recommended that calibration be
completed every two years.
Please read this manual carefully before use. For specific
information on your own blood pressure, contact your
physician. Put the user guide away in a safe place for future
reference.

4
TOPCOM BPM ARM 1480
3Helpfull tips
Here are a few helpful tips to help you obtain more accurate readings:
• Do not measure your blood pressure immediately after consuming a large
meal. To obtain more accurate readings, please wait one hour before
measuring.
• Do not smoke or drink alcohol before measuring your blood pressure.
• You should not be physically tired or exhausted while taking a
measurement.
• It is important that you relax during measurement. Try to take 15-minutes
rest before a reading.
• Do not take measurements if you are under stress or under tension.
• Take your blood pressure at normal body temperature. If you are feeling
cold or hot, wait a while before taking a measurement.
• If the monitor is stored at very low temperature (near freezing), have it
placed at a warm location for at least one hour before using it.
• Wait about 5 minutes before taking the next pressure measurement.
4 Disposal of the device
At the end of the product lifecycle, you should not throw this
product into the normal household garbage but bring the
product to a collection point for the recycling of electrical and
electronic equipments. The symbol on the product, user guide
and/or box indicate this.
Some of the product materials can be re-used if you bring them to a recycling
point. By re-using some parts or raw materials from used products you make
an important contribution to the protection of the environment. Please contact
your local authorities in case you need more information on the collection points
in your area.

5
TOPCOM BPM ARM 1480
ENGLISH
5 Blood pressure
5.1 What is Blood Pressure?
Blood pressure is the pressure exerted on the artery tube while blood flows
through the arteries. The pressure measured when the heart contracts and
sends blood out of the heart is systolic (highest). The pressure measured when
the heart dilates with blood flowing back into the heart is called diastolic (lowest)
blood pressure.
5.2 Why Measure Your Blood Pressure?
Among the various health problems afflicting modern people, problems
associated with high blood pressure are by far the most common. High blood
pressure's dangerously strong correlation with cardiovascular diseases
and high morbidity has made measuring blood pressures a necessity of
identifying those at risk.
5.3Blood Pressure Standard
The World Health Organization (WHO) and National High Blood Pressure
Education Program has developed a Blood pressure standard, according to
which areas of low and high-risk blood pressure are identified. This standard
however, is a general guideline as individual's blood pressure varies among
different people and different groups...etc.
It is important that you consult with your physician regularly. Your physician will
tell you your normal blood pressure range as well as the point at which you will
be considered at risk.
Systolic >= 160
Diastolic >= 100
Stage 2 Hypertension
Systolic 140 - 159
Diastolic
90 - 94
Stage 1 Hypertension
Systolic < 120
Diastolic < 80
Normal
Systolic (mmHg) ->
140
90
100
160
Diastolic (mmHg)
!
120
Prehypertension
Systolic 120 - 139
Diastolic 80 - 89
80

6
TOPCOM BPM ARM 1480
5.4 Blood Pressure Fluctuation
Blood pressure fluctuates all the time!
You should not be worried if you encountered two or three measurements at
high levels. Blood pressure changes over the month and even throughout the
day depending on circumstances (state of mind, temperature, ...)
Ex. Fluctuation within the day for a Male, 35 years old.
6 Battery installation
• Open the battery compartiment by pulling the cover away on the bottom of
the unit.
• Insert 4 AAA non - rechargeable batteries. Follow the polarity as indicated
in the battery compartiment.
18u 24u12u6u
50
1
00
1
50
2
00
m
mHg
Systolic
Diastolic
When the Battery Low Indicator is displayed, the
batteries needs to be replaced.
Do not shortcircuit & dispose of in fire. Remove the
battery if this device is not going to be used for a long
period.

7
TOPCOM BPM ARM 1480
ENGLISH
7 Buttons
8Display
1. LCD display
2. MEMORY button
3. START / STOP button
4. Wrist cuff
5. Air Plug
6. Air Jack
1. Systolic pressure
2. Diastolic pressure
3. Pulse rate
4. Pulse symbol
5. Memory number
6. Error indication
7. Battery Low indicator
8. Blood pressure unit
1
2
3
4
5
6
1
2
3
4
6
7
8
5

8
TOPCOM BPM ARM 1480
9 Applying the cuff
1. Remove all watches, jewelry, etc.
prior to attaching the cuff. Clothing
sleeves should be rolled up.
2. Press your brachial artery by two
fingers approximately 2,5 cm above
the elbow on the inside of your left
arm to determine where your
strongest pulse is.
3. Slide the end of arm cuff furthest
from the tube through the metal ring
to a loop. The smooth cloth should
be on the inside of the cuff. The
Velcro will be on the outside of the
cuff.
4. Put the left arm through the cuff
loop. The bottom of the cuff should
be approx. 1,5 cm above the elbow.
The cuff should lie over the
brachialartery on the inside of the
arm.
5. Pull the cuff so that the top and
bottom edges are tightened around
your arm.
6. When the cuff is positioned properly,
press the Velcro firmly against the
pile side of the cuff. The metal ring
will not touch your skin.
7. Relax your entire body,especially
the area between your elbow and
fingers. Place your elbow on a table
so that the cuff is at the same level
as your heart. Avoid leaning back
while the measurementis being
taken.
FP

9
TOPCOM BPM ARM 1480
ENGLISH
10 Measurement
10.1 Important
1. This monitor automatically switches off 1 minute after the last key
operation.
2. To interrupt the measurement, simply press any key. The cuff will deflate
immediately after a key is pressed.
3. During the measurement, do not talk or move your arm or hand muscles.
10.2 Procedure
1. Press the START/STOP button to
start measurement. All segments
will appear on the display. The cuff
will inflate to the level that is right for
you.
2. When the right level is reached, the
cuff will deflate.
3. When the measurement is
completed, systolic, diastolic and
pulse will be shown simultaneously
on the LCD screen. The result will
be saved automatically in the
memory system. Up to 48 results
can be saved. If the memory is full,
the oldest data will be erased
automatically.
When a mistake was detected
during measurement the Error
mark appears on the display
ERROR

10
TOPCOM BPM ARM 1480
11 Memory
12 Technical specifications
*Specifications are subject to change without notice.
To recall stored blood pressure measurement
results from the memory:
• Press the MEMORY button. The last
memorized result will be displayed.
Press the MEMORY button again to recall the
previous result...
Power source
Measurement zone
Accuracy
Pressure sensor
Inflation
Deflation
Memory capacity
Auto-shut-off
Operation environment
Storage environment
Weight
Cuff Arm circumference
Limited patient
Classification
6V DC: 4 x AA - Non rechargeable batteries
Pressure: 0~300 mmHg
Pulse: 40~199 beats/minute
Pressure: ±3 mmHg
Pulse: within ±5% of reading
Semi-conductor
Automatic - Pump driven
Automatic Pressure release valve
48
1 minute after last key operation
10°C~40°C
30~85% RH max.
-20°C~60°C
10~95% RH max.
265g (with batteries)
23~33 cm
Over 18 years old
Classification of type BF
When the batteries are installed, the data in the memories
will not be lost even when the Blood Pressure Monitor is
switched off.

11
TOPCOM BPM ARM 1480
ENGLISH
13Topcom Warranty
13.1 Warranty period
The Topcom units have a 24-month warranty period. The warranty period starts
on the day the new unit is purchased. Consumables or defects causing a
negligible effect on operation or value of the equipment are not covered.
The warranty has to be proven by presentation of the original purchase receipt,
on which the date of purchase and the unit-model are indicated.
13.2 Warranty handling
A faulty unit needs to be returned to a Topcom service centre including a valid
purchase note.
If the unit develops a fault during the warranty period, Topcom or its officially
appointed service centre will repair any defects caused by material or
manufacturing faults free of charge.
Topcom will at its discretion fulfil its warranty obligations by either repairing or
exchanging the faulty units or parts of the faulty units. In case of replacement,
colour and model can be different from the original purchased unit.
The initial purchase date shall determine the start of the warranty period. The
warranty period is not extended if the unit is exchanged or repaired by Topcom
or its appointed service centres.
13.3Warranty exclusions
Damage or defects caused by incorrect treatment or operation and damage
resulting from use of non-original parts or accessories not recommended by
Topcom are not covered by the warranty.
The warranty does not cover damage caused by outside factors, such as
lightning, water and fire, nor any damage caused during transportation.
No warranty can be claimed if the serial number on the units has been changed,
removed or rendered illegible.

MB300041
visit our website
www.topcom.net
