Topcon FC-6400 User manual

FC-6400
Ultra-Rugged Tablet
WEEE Recycling Passport

FC-6400
Ultra-Rugged Tablet
WEEE Recycling Passport
© 2023 Topcon Corporation
Part Number 1069122-01 (JS 31301)
Revision A

P/N: 1069122-01 (JS 31301) ii
FC-6400 Ultra-Rugged Tablet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
WEEE Recycling Passport . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-1
Product Identification and Selective Treatment Information. . . . . . . . . . . . . . . . . . . . . . . . . . 1-3
Primary Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-4
Case Back Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-5
Internal Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Cell Modem . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-7
Rear Camera Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-8
ER Bluetooth Module Disassembly (if equipped) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-9
Main PCBA Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-10
Remove Flextails from Frame . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-11
Final Disassembly . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1-12
Table of Contents

1-1 P/N: 1069122-01 (JS 31301)
FC-6400 Ultra-Rugged Tablet
WEEE Recycling Passport
TITLE:
FC-6400 WEEE Passport
REVISION DATE:
PART NUMBER:
31301
REVISION:
00
1132 West 1700 North
Logan, Utah 84321
435-753-1881
COLOR CODE:
N/A
Juniper Systems Internal
Use Only
PACKAGE NUMBER
WHERE USED: XXXXX
RoHS COMPLIANCY REQUIRED
The use of heavy metals and heavy metal compounds of lead (Pb),
cadmium (Cd), mercury (Hg), hexavalent chromium (Cr VI) and
flame retardant systems based on polybrominated biphenyls
(PBB), and polybrominated diphenyl ethers (PBDE), including
penta bromodiphenyl ethers, deca bromodiphenly ethers (DBDE)
and octa bromodipehenyl ethers is not allowed in the materials or
processing of this part. Trace levels of heavy metals may be
present as impurities, within threshold limits.
(<0.1% for Pb, Hg, Cr VI, PBB & PBDE and <0.01% for Cd)

1-2
P/N: 1069122-01 (JS 31301)
WEEE Recycling Passport FC-6400 ULTRA-RUGGED TABLET
REUSE AND TREATMENT INFORMATION
Material
Waste Disposal (WD) Weight (lb.) Weight [g] Weight [%] Important Information
Subtotal
Recovery Operations (RO)
Rubber/Elastomer 0.014 6.350288 0.97%
Sealant Compound
Wood
Subtotal 0.014 6.350288 0.97%
Recycling (RC)
Aluminum Alloy cast
Aluminum Alloy wrought
Battery 0.64 290.29888 44.46%
Cable
Cable with plug 0.001 0.453592 0.07%
Carton
Copper 0.03 13.60776 2.08%
Copper Alloy
Gas
Glass optical 0.291 131.995272 20.21%
Iron
Liquid
Magnesium Alloy 0.126 57.152592 8.75%
Magnetic material 0.014 6.350288 0.97%
Metal nonferrous 0.03 13.60776 2.08%
Paper
Plastic 0.0756 34.2915552 5.25%
Plug
Printed circuit board (PCB) 0.131 59.420552 9.10%
Sintered material
Steel 0.016 7.257472 1.11%
Steel stainless 0.071 32.205032 4.93%
Textile material
Subtotal 1.4256 646.6407552 99.03%
Re-Use (RU)
Subtotal
0.00%
Total Weight 1.4396 652.9910432 100.00%

1-3 P/N: 1069122-01 (JS 31301)
WEEE Recycling Passport FC-6400 ULTRA-RUGGED TABLET
Product Identification and Selective Treatment
Information
FC-6400 Geo and GEO Cell
USA and International Units Serial Label
Topcon Battery Door Label
Topcon Case Back Label
Topcon Product Label

1-4
P/N: 1069122-01 (JS 31301)
WEEE Recycling Passport FC-6400 ULTRA-RUGGED TABLET
Primary Disassembly
1. Remove I/O Dust Cover.
2. Remove Case Back Label.
3. Remove battery door label.
4. Unhook and remove hand strap.
5. Remove stylus from garage and cut tether
to remove.
6. Remove product label.
7. Remove bumper screws (eight places) with
PH#0 and remove bumpers.
8. Remove hand strap brackets (Four places).

1-5 P/N: 1069122-01 (JS 31301)
WEEE Recycling Passport FC-6400 ULTRA-RUGGED TABLET
Case Back Disassembly
1. Remove hydrophobic patch.
2. Unlatch and remove battery door.
3. Remove rare earth magnet (Magnetic
material).
4. Remove battery pack (see separate WEEE
Recycling Passport for the battery pack).
5. Remove battery compartment label.
6. Remove battery door gasket.
7. Remove five screws from battery latch
faceplate.
8. Remove battery latch and spring.
9. Remove 15 screws from perimeter of back
side of the unit with PH#1 and remove case
back.
10. Unplug speaker and remove from case
back.
11. Remove stylus garage from case back.

1-6
P/N: 1069122-01 (JS 31301)
WEEE Recycling Passport FC-6400 ULTRA-RUGGED TABLET
12. Remove plastic and rubber rings.
13. Remove rubber stopper from end.
14. Remove three brass inserts.
15. Remove camera lens and flashlight pipe.

1-7 P/N: 1069122-01 (JS 31301)
WEEE Recycling Passport FC-6400 ULTRA-RUGGED TABLET
Internal Disassembly
Cell Modem
1. Remove four screws indicated from Main
antenna with PH#1.
2. Remove antenna.
3. Remove two screws as shown with PH#1
and remove diversity antenna.
4. If installed, remove internal battery by
detaching cable from battery and removing
battery.
.
5. Remove RF tape.
6. Remove screw from Diversity module with
PH#1.
7. Remove main and diversity antenna PCBAs
and unplug cables.
8. Remove cell module.
9. Remove RF tape from cell module.
10. Remove Kapton tape from module.
11. Remove cables from front of cell module.

1-8
P/N: 1069122-01 (JS 31301)
WEEE Recycling Passport FC-6400 ULTRA-RUGGED TABLET
Rear Camera Disassembly
1. Remove camera boot.
2. Peel rear camera from support and remove
camera.
3. Remove rear camera support with PH#1.
4. Remove antenna support.

1-9 P/N: 1069122-01 (JS 31301)
WEEE Recycling Passport FC-6400 ULTRA-RUGGED TABLET
ER Bluetooth Module
Disassembly (if equipped)
1. Remove these three screws with PH#1.
2. Unplug the flex connector from the main
board.
3. Remove flex from PCBA.
4. Remove the seven screws from around the
PCBA with T5.
5. Separate the PCBA from the bracket.

1-10
P/N: 1069122-01 (JS 31301)
WEEE Recycling Passport FC-6400 ULTRA-RUGGED TABLET
Main PCBA Disassembly
1. Remove Kapton tape from can.
2. Disconnect touch screen flex tail from
connector.
3. Remove five screws from main PCBA with
PH#1.
NOTE: if an ER Bluetooth module has been
removed, three of these screws will have been
removed in the process.
4. Remove ground pad from main PCBA.

1-11 P/N: 1069122-01 (JS 31301)
WEEE Recycling Passport FC-6400 ULTRA-RUGGED TABLET
Remove Flextails from Frame
1. Remove front camera.
2. Remove thermal interface material.
3. Disconnect all flextails from PCBA.
4. Remove main PCBA.
5. Remove two Philips screws from docking
module.
6. Remove docking module.
7. Remove two T5 screws from I/O module.
8. Remove I/O module faceplate and remove
I/O module from unit.
9. Remove main gasket.

1-12
P/N: 1069122-01 (JS 31301)
WEEE Recycling Passport FC-6400 ULTRA-RUGGED TABLET
Final Disassembly
1. Pull keypad cover away from unit.
2. Pull keypad flex away from unit.
3. Remove flex tail from case front.
4. Remove screws from perimeter of frame
with a T5 driver and remove frame.
5. Remove light pipe from mag frame.
6. Remove heat pipe from mag frame.
7. Remove six grounding pads.
8. Remove ground tape strips from mag frame.
9. Remove display flex.
10. Remove display from case front.
11. Remove pressed-in hardware from case
front.
