Topline Peristaltic Dosing Pump for PAC
Installation, Commissioning and O&M Manual

Page 2of 8
Introduction.
The Topline Peristaltic PolyAluminium Chloride (PAC) dosing pump offers low capacity precision
output pump for the dosing of PAC directly from the carboy in which it is delivered, without further
need for diluting or decanting.
PAC is applied to swimming pools, and all such filtered water systems, to improve filtration efficiency
by increasing the size of small particles of suspended solids in the water, binding them together to
produce larger masses. A typical pool sand filter can produce a filtrate of around 20 microns. Many
small particles, including cryptosporidium, can pass straight through the filter bed at this size.
Correctly optimised PAC systems can increase the efficiency of the pool filter down to some 5
microns. Solids are backwashed away, following the filter manufacturer’s instructions for correct
backwashing rates, and results in crystal clear swimming pool.
Lowering the amount of suspended solids in the pool with PAC dosing can often lead to a marginal
lowering of chemical consumption, as there is a lower demand for chlorine from these solids, a
lowering of combined chlorine and can act as a phosphate remover, reducing algae growth.
Swimming pool PAC chemicals are normally designed only for sand filters up to a maximum filter rate
of 35m3/m2/hr.
PAC is not normally suitable for use with Diatomatious Earth filters, Cartridge filters or Zeolite filters.
PAC should only be installed pre-filter, in a full flow section of pipe work, as far from the filter as
possible, but after any chemical sample draw-off point.
PAC can only coagulate solids in stable pH conditions. pH levels between 7.0 and 8.0 should be
maintained at all times. Topline do not recommend that pre-filter chlorination (or pH correction) be
applied with PAC installations as the pH will locally fluctuate during injection, leading to poor
efficiency of ‘floc’ production.
Specification.
Topline Peristaltic Dosing Pump
Model Topline Peristaltic Dosing Pump
Capacity 1.5 –150 ml/hr
Suction Lift Max 2 m
Back Pressure 1.5 bar max.
Hose Connections: 6 mm x 4mm ID OD Soft PVC
Initial Accuracy ±10%
Operating Temperature: 5 - 55°C
Running Time 100%
Protection Rating IP65
Dimensions (W x H x D): 95 x 175 x 130 mm
Weight: 1.25 kg (approx.)
Power AC 230 V ±10%, 50/60 Hz
Fuses 0.2 A MT (fitted)
Current consumption 5 VA max

Page 3of 8
Installation.
The pump should be mounted on a suitable wall, or mounting board, directly above the carboy/bund
for the PAC and can be mounted using the four screws and wall plugs supplied.
The pump is disassembled to fix to the wall, by removing the front face plate, then unscrewing the
pump body from the rear mount plate.
The pump cover is removed by carefully levering the notches on either side of the pump with a flat
screwdriver and pulling the cover clear. The body is removed from the support plate by loosening the
four retaining screws.
Cover
Body
Mount Plate

Page 4of 8
It is recommended that the dosing hose from the Topline peristaltic dosing pump to the injection
point is as short as possible, with a maximum recommended hose length of 15m and vertical
injection height of <10m.
Power for the Topline peristaltic dosing pump maybe taken from any 1 amp fused supply, however
since the pump should only dose into a full flow filter delivery pipe, whilst the circulation is operating,
a source interlocked with the pool pumps would be preferred.
Some versions of the Topline TEC range of swimming pool controllers can be used to provide a power
supply interlocked to shut down with the controller flow switch.
The dosing pump should be fitted with either a switched fused spur or suitably IP rated plug and
socket. Topline do not typically recommend the use of IP rated standard UK 230v 13amp plug
enclosures, this is to prevent accidental use of such sockets with power tools etc. which may cause
damage of a chemical controller output power supply.
The Topline peristaltic dosing pump is supplied with 15m of dosing hose, which should be run in a
protective/carrier conduit for the entire run. We would recommend 20mm or 25mm uPVC electrical
conduit for this purpose. We do recommend that joints or swept bends are not solvent welded for
hose replacement/inspection purposes. In common with all chemical dosing hoses we do not
recommend that joints are positioned above walkways or doorways to prevent overhead chemical
spillages in the event of a split hose.
The cap of the supplied drum of PAC should be removed and drilled out to allow the hose(s) to pass
through. The cap will be reused with subsequent carboys.
Electrical installation works may only be carried out by suitably qualified and experienced electrical
engineers.
Main Power Input
L 230v –Terminal 3
Neutral –Terminal 1
1
3

Page 5of 8
Application & Commissioning.
Not all PAC products are the same. Variations in PAC concentrations are common across the many
different suppliers. The stated dose rates are noted for reference only. Please refer to your chemical
supplier for specific dose rates.
Using the Topline peristaltic dosing pump, in keeping with the requirements of the
Pool Water Treatment Advisory Group (PWTAG), PAC is dosed pre-filter 24 hours per day, all the time
the filtration plant is operating.
The typical operational setting is for a PAC product is around 0.1ml/m3/hr. This may need adjusting
to suit the prevailing conditions of the pool water. For example; a heavily polluted pool, such as a
children’s pool, may need a setting of 0.3ml/m3/hr, and an ‘Olympic’size a pool, with a low use and
large buffer of treated water, could possibly be lowered to 0.1ml/m3/hr.
The Topline peristaltic dosing pump has a maximum output pressure of 1.5 Bar. The output of the
dosing pump should be checked against the dose rate chart to ensure that either a higher or lower
back pressure is not overrunning or impairing pump output.
The pump cover is removed by carefully levering the notches on either side of the pump
with a flat screwdriver.
The settings on the table below should be used to set up the pump for the desired output, for
example a pool of 100m3/hr with an applied dose rate of 0.1ml/m3/hr would require a dose rate of
10ml/hr. And so the selector switch would be set to Position 1 and the dial set to dial would be set to
5.5. Similarly 60m3/hr would require a dose of 6m/hr and so selector switch Position 1 would be set
and the dial set to 3.5. To check that this setting is correct the suction hose should be put into a
calibration tube (or tube of a known capacity) and the pump run for 10 minutes. The amount drawn
from the tube is multiplied by 6 to give the capacity in ml/hr. The pump should be adjusted
accordingly, until the correct setting is achieved.
The design of the motor is provides a step-less increase from 0.5 to 194ml/hr through the
potentiometer scale. This will vary however, depending upon the back pressure at the injector, the
length of suction lift and the length of delivery hose (max 15m) and its elevation to the injection
point.

Page 6of 8
The pump output is set by choosing the higher or lower dosing range, with the selector switch, and
then carefully rotating the potentiometer from 1 –10 clockwise to increase the pump output from
1.5 to 150ml/hr
Dose Rates (at 0.1ml/m3/hr PAC)
Pump Setting
Switch Position 1
Switch Position 2
Output ml/hr
Pool Flow m3/hr
Output ml/hr
Pool Flow m3/hr
1
0.5
5
19.4
194
1.5
1.2
12
29.1
291
2
2.4
24
38.8
388
2.5
3.6
36
48.5
485
3
4.8
48
58.2
582
3.5
6
60
67.9
679
4
7.2
72
77.6
776
4.5
8.4
84
87.3
873
5
9.6
96
97
970
5.5
10.8
108
106.7
1067
6
12
120
116.4
1164
6.5
13.2
132
126.1
1261
7
14.4
144
135.8
1358
7.5
15.6
156
145.5
1455
8
16.8
168
155.2
1552
8.5
18
180
164.9
1649
9
19.2
192
174.6
1746
9.5
20.4
204
184.3
1843
10
21.6
216
194
1940
Selector
Switch
Potentiometer

Page 7of 8
Operation
There is no operational procedure to follow. The Topline Peristaltic Dosing Pump is set to run 24
hours per day, all the time the circulation is in operation. The general usage of PAC should be noted
over a period of days/weeks to identify when the pump is losing efficiency.
The PAC is dosed from the carboy in which it is delivered.
The carboy in use and any carboy in stock must be bunded. PAC is generally an acid, and therefore
must not be stored with hypochlorites.
Suitable lifting and handling precautions should be made for the carboy drum, which in addition to
the dead weight carries some inertia when carried, due to the movement of the liquid within.
Suitable COSHH and RAMS will need to be produced for any such tasks.
The Topline Peristaltic Dosing Pump will not drain the carboy completely. Wearing suitable personal
protective equipment (PPE), the residue maybe decanted into a clean container and carefully poured
into the new carboy (provided suitable volume is available).
Service Intervals
Over a period of time the Topline peristaltic dosing pump injection point may become fouled with a
residue of PAC, we recommend that the injection point is checked and cleaned every six months
minimum.
The capillary hose will lose its elasticity over time. We recommend that the peristaltic dosing pump
capillary hose be replaced every 12 months.
We recommend that the injection hose be replaced every two years.
Spares
Capillary Hose Kit –(Blue)
6mm OD x 4mm ID Hose Connection
Part Number T6098
Injector –½” BSP
6mm OD x 4mm ID Hose Connection
Part Number T6097
Non-Return Foot Valve-
6mm OD x 4mm ID Hose Connection
Part Number T6096
