TOPMAQ FAAT1065 Assembly instructions

Rev091916
14CU.FT. DUMP CART
Instruction & Assembly
SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE

- 2 -
Table of Contents
General Warnings and Rules...............................................................................3
Hazard Signal Word Definition.............................................................................4
Controls and Features Identification....................................................................5
Component & Hardware.................................................................................. 6, 7
Assembly Instructions......................................................................8, 9 10, 11, 12
Operation Instructions........................................................................................ 13
Maintenance and Storage.................................................................................. 14
Specification...................................................................................................... 15
Parts Drawing & Parts List........................................................................... 16, 17

- 3 -
GENERAL WARNINGS
READ and UNDERSTAND this manual completely before using Utility Dump Cart.
Operator must read and understand all safety and warning information, operating instructions,
maintenance and storage instructions before operating this equipment. Failure to properly operate and
maintain the utility dump cart could result in serious injury to the operator or bystanders.
Operation Warnings
lDo not at any time carry passengers sit or stand on the cart.
lDo not allow children to play on, stand upon or climb in the cart.
lAlways inspect the cart before using to assure it is in good working condition.
lReplace or repair damaged or worn parts immediately.
lAlways check and tighten hardware and assembled parts before operation.
lDo not exceed equipment maximum load capacity of 700lb (317.5kg).
lAvoid large holes and ditches when transporting loads.
lBe careful when operating on steep grades (hill) the cart may tip over.
lAlways operate at reduce speed in rough terrain, along creeks, ditches and on hillsides.
lDo not operate close to creeks, ditches and public highways.
lTo avoid personal injury and/or equipment damage DO NOT EXCEED 10 MPH.
lAlways use caution when loading and unloading the cart.
lOnly tow with recommended vehicles (Lawn/Garden Tractors andATVs).
lAlways secure and lock dump cart to the vehicle hitch before operating.
.
Crush and Cut Hazards
lAlways keep hands and feet clear from moving parts while operating the equipment.
lAlways clear and keep work area clean when operating.
lAlways wear safety gear, eye protection, gloves and work boots when operating the dump cart.
.
WARNING
The warnings, cautions, and instructions outlined in this instruction manual cannot cover all
possible conditions or situations that may occur. It must be understood by the operator that
common sense and caution are factors which cannot be built into this product and must be supplied
by the operator.
PROP 65
WARNING
This product contains chemicals known to the state of California to cause cancer, birth defects, or
other reproductive harm.
Assembly Is Required
This product requires assembly before use. See “Assembly” section for instructions. Because of the
weight and/or size of the utility dump cart, it is recommended that another adult be present to assist with
the assembly. INSPECT ALL COMPONENTS closely upon receipt to make sure no components are
missing or damaged.
.

- 4 -
Hazard Signal Word Definitions
ABOUT YOUR UTILITY DUMP CART
This utility dump cart has a roughed steel construction and is designed to carry a wide range of materials.
The dump cart will easily haul up to 700lbs of tools, firewood, animal feed, trash, landscaping materials,
cement or anything else that needs to moved. Easy to use removable tailgate makes loading and
un-loading fast and convenient. Never exceed the rated load capacity of 700lbs when operating the
utility dump cart.
Technical specifications on the utility dump cart are provided in the “Specifications” section of this manual.
This is the safety alert symbol. It is used to alert
you to potential personal injury hazards. Obey all
safety messages that follow this symbol to avoid
possible injury or death.
DANGER indicates an imminently hazardous
situation which, if not avoided, will result in death
or serious injury.
DANGER
WARNING indicates a potentially hazardous
situation which, if not avoided, could result in
death or serious injury.
WARNING
CAUTION indicates a potentially hazardous
situation which, if not avoided, may result in minor
or moderate injury.
CAUTION
CAUTION used without the safety alert symbol
indicates a potentially hazardous situation which,
if not avoided, may result in property damage.
CAUTION

- 5 -
Read this owner’s manual before operating the equipment. Familiarize yourself with the location and
function of the controls and features. Save this manual for future reference.
1) Removable Tailgate – Push up to remove for loading and unloading.
2) Tires / Wheel – Do not exceed the recommended rate 25 PSI.
3) Hitch – Pin-type design use only with approve vehicles.
4) Utility Cart Box – Do not exceed rated load capacity 700lb (317.5kg).
5) Release Pedal– Release the cart bed.
Controls and Features
Identification
1
4
3 2
5

- 6 -
CAUTION
Read and follow all instructions for assembly and operation. Failure to properly assemble this
equipment could result in serious injury to the user or bystanders, or cause equipment damage.
UTILITY DUMP CART COMPONENT PARTS AND ASSEMBLY
Take all parts out of the shipping crate and inspect components to ensure there are no missing pieces
before starting to assemble the utility dump cart follow steps 1 through 10.
TOOLS REQUIRED
·Pliers
·Screw Driver
·10mm & 14mm Wrench
Component Parts

- 7 -
Note: you may have extra nuts & bolts when finished.
Component Parts

- 8 -
STEP 1:Attach Bottom Panels and Support Tubes
1. Put the left bottom panel and right bottom panel together.
2. Attach the support tubes to the panels using four sets of M8x40 screws and M8 nylon lock nuts.
Loosely tighten the nuts.
STEP 2: Attach Tongue Support
1. Attach the tongue support to the bottom panels using two sets M8x20 screws and M8 nylon lock
nuts. Loosely tighten the nuts.
Assembly Instruct
ion
s

- 9 -
STEP 3:Attach the Wheel Axle Support
1. Put together the two wheel axle supports and attached them to the bottom panels using eight sets
of the M8x16 Screws and M8 nylon lock nuts. Loosely tighten the nuts.
STEP 4: Attach Release Pedal
1. Insert the release pedal into the hitch tongue and secure using M6x90 hex bolt and M6 nylon lock
nut. Put the two spacers (A) on each side of the of the release pedal.
2. Attach the latch spring hook on the bottom hole on the release pedal and hitch tongue.

- 10 -
STEP 5: Attach Wheel Axle
1. Center the hitch tongue assembly in the wheel axle support.
2. Insert the axle through the hole and slide it through both the axle support and the hitch tongue
assembly.
3. Tighten all hardware.
STEP 6: Attach the Wheels
1. Put an Ø20 flat washer on the axle; slide the wheel over the end, followed by the second Ø20 flat
washers and secure with Ø3 R pin.
2. Repeat the process for the other side of the axle.

- 11 -
STEP 7:Attach Side Panel
1. Attach the left and right side panel assemblies to the bottom panels using the four hinge pins.
STEP 8:Attach the Front Panel
1. Attach the front panel to the bottom panels and secure using the using the two hinge pins.
2. Lock the left and right side panel assemblies in place using the Handle.

- 12 -
STEP 9: Attach the Rear Panel
1. Slide the rear panel through the slots on the back side panels.
NOTE: The rear panel pins must go through the holes on the side panels to lock the panel in place.
STEP 10: Attach Side Rails and Front Rail
1. Remove the four Ø3 R pins in the side rails, insert the side rails into the holes on the side panels.
Then fix with the four Ø3 R pins.
2. Secure the front rail using the two Ø3 R pins.

- 13 -
WARNING
Before using the utility dump cart, review the instructions below and safety information. Failure to
follow these instructions may result in property damage or injury to the operator or bystanders.
USING YOUR UTILITY DUMP CART
1. DO NOT exceed rated capacity of 700lb (317.5kg).
2. ALWAYS secure and lock the utility cart to the vehicle hitch before operating.
3. ONLY use approved vehicles when towing the dump cart (Lawn/Garden Tractors and ATVs)
4. NEVER tow the utility dump cart with box raised.
5. DO NOT over fill the utility dump cart. Over flow loads can cause the cart and towing vehicle to lose
traction and skid out of control.
6. ONLY fill the dump cart to a comfortable dumping load. Extremely heavy loads will be difficult to
operate and dump.
7. ALWAYS use the dump cart for its intended purpose.
8. ALWAYS make sure that the tow vehicle and the combined weight of the operator MUST BE greater
than the load of the cart weight for proper control.
9. DO NOT use cart on public highways or roads.
10. NEVER exceed 10mph when towing the dump cart.
11. DO NOT make sharp turns that may cause the Lawn/Garden Tractor or ATV tires to rub against the
utility dump cart.
12. ALWAYS slow down before turning.
13. ALWAYS use caution when backing the utility cart. To avoid the cart from “jack-knifing” always back
up in a straight line.
Operation Instructions

- 14 -
WARNING
Improper maintenance and storage of the utility dump cart may void your warranty.
MAINTENANCE
·After each use clean material out of the cart box.
·Rinse/dry inside and outside of the dump cart after each use.
·Before operating make sure the tires have the RECOMMENDED TIRE PRESSURE 25 PSI.
·Regularly grease the axle and the wheel bearing area or when needed.
·Periodically check all fasteners for tightness.
·Annually clean and lightly lubricate parts.
·Use a glossy enamel spray paint to touch up scratched or worn painted metal surfaces.
·Never exceed load capacity rating of 700lbs it will damage the utility dump cart.
IMPORTANT:
If a part needs replacement, only use parts that meet the manufacturer’s specifications. Replacement
parts that do not meet specifications may result in a safety hazard or poor operation.
STORAGE
·Never allow material to remain in the utility dump cart for extended periods of time.
·Before storing make sure the cart is clean and dry for years of trouble free service.
·Store indoors or protected area during severe weather and winter months.
·When storing outside always keep the tongue a little higher than the back of the cart to allow the
moister to easily run out the back and will not accumulate in the box.
Maintenance
and
Storage

- 15 -
Load Capacity................................................................................700lb (317.5kg)
Box and Frame Material ................................................................................ Steel
Inside Box Dimensions...................................45.5” x 28” x 17” /116x71.5x43.7cm
Overall Dimensions ........................................66.13” x 33” x 36.25”/168x83x92cm
Axle Dimensions........................................................... 0.78” x 32.25”/ Ø20x82cm
Wheel Size.......................................................................................................16”
Wheel Type ...........................................................................................Pneumatic
Hitch Type ............................................................................................... Pin Style
Tire Pressure (PSI)............................................................................................ 25
Unit Weight..................................................................................... 114.5lb/52.4kg
Specifications
