TMW-9161 SERIES
WIRELESS MICROPHONE SYSTEM
TMW-9161
NF03123-1.0

SAFETY RELATED SYMBOLS
This symbol, wherever used, alerts you to the
presence of un-insulated and dangerous voltages
within the product enclosure. These are voltages
that may be sufficient to constitute the risk of
electric shock or death.
This symbol, wherever used, alerts you to important
operating and maintenance instructions.
Please read.
Protective Ground Terminal
AC mains (Alternating Current)
AC mains (Alternating Current)
Denotes the product is turned on.
Denotes the product is turned off.
WARNING
Describes precautions that should be observed to
prevent the possibility of death or injury to the user.
CAUTION
Describes precautions that should be observed to
prevent damage to the product.
WARNING
Power Supply
Ensure that the mains source voltage (AC outlet)
matches the voltage rating of the product. Failure to
do so could result in damage to the product and
possibly the user. Unplug the product before electrical
storms occur and when unused for long periods of time
to reduce the risk of electric shock or fire.
External Connection
Always use proper ready-made insulated mains
cabling (power cord). Failure to do so could result in
shock/death or fire. If in doubt, seek advice from a
registered electrician.
Do Not Remove Any Covers
Within the product are areas where high voltages may
present. To reduce the risk of electric shock do not
remove any covers unless the AC mains power cord is
removed. Covers should be removed by qualified service
personnel only.
No user serviceable parts inside.
Fuse
To prevent fire and damage to the product, use only
the recommended fuse type as indicated in this
manual. Do not short-circuit the fuse holder. Before
replacing the fuse, make sure that the product is OFF
and disconnected from the AC outlet.
Protective Ground
Before turning the unit ON, make sure that it is connected
to Ground. This is to prevent the risk of electric shock.
Never cut internal or external Ground wires. Likewise, never
remove Ground wiring from the Protective Ground Terminal.
Operating Conditions
Always install in accordance with the manufacturer's
instructions.
To avoid the risk of electric shock and damage, do not
subject this product to any liquid/rain or moisture.
Do not use this product when in close proximity to water.
Do not install this product near any direct heat source.
Do not block areas of ventilation. Failure to do so could
result in fire.
Keep product away from naked flames.
Disposing of this product should not be placed in
municipal waste but rather in a separate collection.
IMPORTANT SAFETY INSTRUCTIONS
Read these instructions
Follow all instructions
Keep these instructions. Do not discard.
Heed all warnings.
Only use attachments / accessories specified by the
manufacturer.
Power Cord and Plug
Do not tamper with the power cord or plug. These are
designed for your safety.
Do not remove Ground connections!
If the plug does not fit your AC outlet seek advice
from a qualified electrician.
Protect the power cord and plug from any physical
stress to avoid risk of electric shock.
Do not place heavy objects on the power cord. This
could cause electric shock or fire.
Cleaning
When required, either blow off dust from the product
or use a dry cloth.
Do not use any solvents such as Benzol or Alcohol.
For safety, keep product clean and free from dust.
Servicing
Refer all servicing to qualified service personnel only.
Do not perform any servicing other than those instruct
-ions contained within the User's Manual.
Carts and stands - The
component should be used
only with a cart or stand
that is recommended by
the manufacturer.
A component and cart
combination should be
moved with care. Quick
stops, excessive force,
and uneven surfaces may
cause the component and
cart combination to overturn.
TMW
SERIES
TMW
SERIES
NOTE
9

TABLE OF CONTENTS
1. INTRODUCTION.........................................................................................4
2. FEATURES.................................................................................................5
3. USEFUL DATA............................................................................................6
4. CONTROL ELEMENTS................................................................................6
5. OPERATION........... ...................................................................................9
6. CONNECTION DIAGRAM ...........................................................................11
7. TECHNICALSPECIFICATION.....................................................................12
8. GUARANTEE.............................................................................................14
9. NOTE........................................................................................................15
TMW
SERIES
TMW
SERIES

TMW
SERIES
INTRODUCTION
The TMW-9161 is the delicately designed UHF, PLL synthesized system, with antenna built inside
the receiver for smart switching diversity control, the higher level RF signals maybe fed into the
system for greater reliability and coverage, therefore, the risks of breakdown and interference
are to be effectively reduced. You can manually adjust the channel of the transmitter to match
that of the receiver if you know about the operating frequency of it.
PLL UHF DIVERSITY RECEIVER
HANDHELD TRANSMITTER
BODY PACK TRANSMITTER
Generally, the TMW-9161 series consists of:
PLL UHF Diversity Receiver
Handheld Transmitter
Body Pack Transmitter
Thank you for choosing TOPP PRO.
Our Professional Audio Products are designed and tested by a highly qualified engineering team
with more than 20 years of experience. Great pride & care is placed in delivering products with
excellent performance, specifications and dependable reliability. Also great emphasis is placed in
creating and bringing to market products that can fill multiple applications and also offer customers
exceptional value.
Our creative and dedicated design & engineering team uses the latest tools in technology and the
latest concepts inacoustics design to create products for real-life applications. Every TOPP PRO
Audio product istested and must comply to very strict Standards.
TMW
SERIES
TMW-9161

TMW
SERIES
INTRODUCTION
For the TMW-9161 series, there are several types of clip microphones are included in this product
range, please make sure that the proper microphone has been selected for your typical sound
reinforcement system before installation.
Last but not the least, the operating frequency of this system may be varied from 798 MHz to 827 MHz, please
refer to your national EMC regulations to pick out the authorized frequency band (0 ~ F) for your end application.
HM-38, Condenser Microphone
Preset impedance: 600 ohm;
Freq. response: 80-12 kHz;
Sensitivity: -68 dB+/-3 dB at 1 kHz;
Directional: Uni-directional;
Weight: 52 g (0.12Ib)
HM-58, Condenser Microphone
Preset impedance: 700 ohm;
Freq. response: 200-8 kHz;
Sensitivity: -65 dB at 1 kHz;
Directional: Uni-directional;
Weight: 54 g (0.12Ib)
FEATURES
PLL UHF DIVERSITY RECEIVER
Pressing the flip switch to switch channel for desired Radio Frequency
LED indication RF
One receiving module
AF level display
one balanced output
one squelch control
one volume control
Soft touch painting for comfortable use
Channel frequency adjusted manually
TRANSMITTER
COMMON FEATURES
PLL synthesized design
Consistent operating frequencies to comply with the EMC regulations
16 channels frequency presets
Manufactured under ISO9000:2000, ISO/TS16949:2002 Quality Management System
TMW
SERIES

TMW
SERIES
CONTROL ELEMENTS
4.1 PLL UHF DIVERSITY RECEIVER
FRONT PANEL
1. Power Switch
It switches yourTMW-9161 ONand OFF.
2. RF ChannelIndicator
This indicator shows the selectedchannel whose rangegoes from 0to F.
3. RF LEDs
These LEDs light up when antennas receive signals.
Note: The receiver has two antennas. LED A lights up when antenna A receives more signals than antenna
B. LED B lights up when antenna B receives more signals than antenna A.
4. AF Level LED
When the receiver receives signal, the LED starts to light up. The higher the signal level is, the more LEDs
light up. When the signal level reaches peak, all LEDs light up. If there is no signal received, all LEDs light off.
5. Antennas
These antennas receive the signals from transmitter.
TMW
SERIES
XLR Type Unbalanced
Pin3 (-)
Pin2 (+)
Pin1 ( )
(Linked to Pin1 manually, )
XLR Type Balanced
Pin1 ( )
Pin2 (+)
Pin3 (-)
TRS Type Balanced
Tip
Ring
Sleeve
+
-
TRS Type Unbalanced
Tip
Ring
Sleeve
+
TS Type Unbalanced
Sleeve
Tip
+
Tip
Ring
Sleeve
Tip
Ring
Sleeve
Tip
Ring
Sleeve
1
2
3
1
2
3
1
2
3
TIP RING SLEEVE SLEEVE RING TIP
TIP RING SLEEVE
21
3
12
3
12
3
Tip
Ring
Sleeve
Tip
Ring
Sleeve
Tip
Sleeve
Tip
Sleeve
Tip
Sleeve
Cent er
Cent er
Centre
Screen
Screen
Screen
1
2
3
Tip
Ring
Sleeve
1
2
3
1
2
3
TIP SLEEVE
TIP SLEEVE
TIP RING SLEEVE
TIP RING SLEEVE
12
3
21
3
21
3
Tip
Ring
Sleeve
1
2
3
Tip
Sleeve
1
2
3
TIP RING SLEEVE
TIP SLEEVE
12
3
12
3
SLEEVE TIP
SLEEVE RINGTIP
(5) (5)
(1)(2)(3)(4)
(6)(7)
(5) (5)
(1)(2)(3)(4)
(6)(7)

TMW
SERIES
CONTROL ELEMENTS
6. Channel Selector
Press this flipswitch slightly to switch channel for desired frequency.
7. Volume Control
"AF LEVEL" isa potentiometer for master volume control.
3. AF Output(Unbalanced)
This is a professional unbalanced output jack.
1. DC Input
This DC jack is usedto input 12-18 V 500 mADC current.
2. Squelch Control
This squelch control is used to adjust the squelch level. The adjustable squelch range is 95.0 dB~65.0 dB.
4.2 HANDHELD TRANSMITTER
1. Massive FrontGrill
Extremely rugged spring steel mesh grill to protect the capsule underneath in tough stage or live performance.
2. Power Switch
Set the power switch at the position "ON", then the microphone is turned on and the BATT LED lights up.
4. XLR Audio Output (Balanced)
This is a professional balanced XLR output connector.
REAR PANEL
(1)(2)(3)(4)
TMW
SERIES
TMW-9161
(4) (5)
(2)
(3)
(6) (1)
(7)
TMW-9161

TMW
SERIES
CONTROL ELEMENTS
3. Power LED
When the unit is turned on, this LED lights up.
4. Band Selector
With an adjusting bar, the band selector can be used to switch to an expected frequency. Before switching
frequencies, turn off the microphone first and then turn on it.
4.3 BODY PACK TRANSMITTER
5. Adjusting Bar
This adjusting bar is placedin the microphone. It is usedto adjust squelch control and bandselector for
switching frequencies.
6. Antenna
The antenna isintegrated into the transmitter body fortransmitting signals.
7. Battery Compartment
This unit may be powered fromone pair dry or rechargeable batteries,size AA1.5 V.
1. Power Switch
Set the power switch in the position "ON", then the microphone is turned on and the BATT LED flashes once.
Set the power switch in the position" OFF", then the microphone is turned off and the BATT LED lights off slowly.
2. MINI 4PConnector
This connector isused to connect the unit with the clip microphones, forexample, HM-38 or HM-58condenser
microphones.
Pin1
Pin2
Pin 1 GND
Pin 2 Phantom power supply for condenser microphone
Pin 3 For guitar, bass and keyboards
Pin 4 For dynamic or condenser microphone
Pin4
Pin3
3. Battery Compartment
This unit may be powered from one pair dry or rechargeable batteries, size AA 1.5 V.
4. Belt Clip
It is the detachable belt clip for easycarry during the live applications.
TMW
SERIES
TMW-9161
(3)
(6) (7)
(8) (9)
(5) (4)
(2) (1) (10)

TMW
SERIES
TMW
SERIES
CONTROL ELEMENTS
5.Antenna
It is the flexible antenna. To get effective transmission, never cover the antennawith hand, clothes, etc.
During the operation, and always position the transmitter nearby the receiver.
6. GT Level Switch
It is used to adjust the input signal level of electrical guitar. When an electrical guitar is being used it is
ineffective to adjust MT level switch.
9. Adjusting Bar
It is used to adjust BAND SELECTOR, MT SWITCH and GT SWITCH.
7. MT Level Switch
It is used to adjust the input signal level of microphone. When an microphone is being used it is ineffective
to adjust GT level switch.
8. Band Selector
With the adjusting bar, the bandselector can be usedto switch to an expected frequency before switching
the frequencies, turn offthe transmitter first andthen turn on it.
10. Power LED
When the unit isturned on, this LEDflashes once. When theunit is turnedoff this LED lights off slowly.
When the batteries areshort of power,this LED flashes. Whenthe batteries can notbe used, thisLED
lights up.
OPERATION
5.1 PLL UHF DIVERSITY RECEIVER
SQUELCH CONTROL
The job of a squelch circuit is to reduce audible noise. It eliminates noise during pauses in theaudio
signal by muting the receiver every time and the audio level drops below a def ined th resho ld. The s quelc h
control on the receiver sets this threshold. Use the squelch control with care! If the squelch threshold
is too high, the squelch will not only cut out noise but mute quiet audio signals as well because the
squelch responds to thedetected voltage and cannot distinguish betweenwanted signal and noise.
Besides that, a too high squelch threshold also decreases the usable range. The squelch range is
95.0 dB~65.0 dB. Use an adjusting bar to adjust the squelch selector for a right squelch threshold.
MANUALLY SELECTING FREQUENCY
Press this flip switch slightly to switch channel for desired frequency.
OUTPUT VOLUME CONTROL
There is one master volume control "AF LEVEL" on the front panel. It is used to control the output volume.
Turn theknob clockwise and the output volume increases. Turn the knob counterclockwise and the output
volume decreases.
(8) (9)
(3)
(6) (7) (5) (4)
(2) (1) (10)
Pin1
Pin2 Pin4
Pin3

TMW
SERIES
OPERATION
5.2 TRANSMITTER
FREQUENCY SELECT
In practice, to effectivelyavoid the interferencefrom any lightingequipment, computers, fax machin es, etc n ear
by, it is usually advised to switch to another frequency to get best performance. The frequency range of this
system is UHF, 798 MHz ~827 MHz, and it is divided into 16frequency bands according to the country's EMC
regulations; Each frequencyband can be manually adjusted withan adjusting bar. If you want toswitch a
frequency, you have to turn off the unit, adjust frequency and then turn it on again.
BATTERY REPLACING
Please be advised to use only one pair of AA 1.5 V batteries for power supply.
Caution: Danger of explosion if battery is incorrectly replaced. Replace the batteries only with the same or
equivalent type.
5.3 OPERATING FREQUENCY MATCHES BETWEEN THE RECEIVER AND THE TRANSMITTER
To make the operating frequency matched betweenthe transmitter andthe receiver, adjust the transmitter
and receiver manually forthe same frequency.
Note:
1. If several systemsare operated, do not use thesame frequency at the same time.
2. If several wirelesssystems are used to avoid interference, tenfrequencies can beselected simultaneously
at most. Theyare respectively CH 0, CH 1,CH 3, CH 4, CH 5,CH 6, CH 7, CH 8,CH 9,CH B.
3. The rest 6 frequenciesare available for customer's choice.
Please refer tothe following table to select frequencies.
CH 0~CH F FREQUENCY
1
2
0
3
4
5
6
7
8
9
A
B
C
D
E
F
798.125 MHz
798.325 MHz
798.925 MHz
799.325 MHz
800.725 MHz
802.725 MHz
805.725 MHz
807.925 MHz
811.525 MHz
815.725 MHz
820.825 MHz
822.725 MHz
823.225 MHz
824.625 MHz
825.425 MHz
826.625 MHz
TMW
SERIES
(1)(2)(3)(4)
TMW-9161
(4) (5)
(2)
(3)
(6) (1)
(7)
TMW-9161

TMW
SERIES
TMW
SERIES
CONNECTION DIAGRAM
Either the 1/4" TRS phonejack or XLR connector can be wired in balanced and unbalanced modes, which
will be determined by the actual application status, please wire your system as the following wiring examples:
XLR Type Unbalanced XLR Type Balanced
Pin3 (-)
Pin2 (+)
Pin1 ( )
(Linked to Pin1 manually, )
Pin1 ( )
Pin2 (+)
Pin3 (-)
For XLR connector
Tip
Ring
Sleeve
Tip
Ring
Sleeve
Tip
Ring
Sleeve
1
2
3
1
2
3
1
2
3
TIP RING SLEEVE SLEEVE RING TIP
TIP RING SLEEVE
21
3
12
3
12
3
Tip
Ring
Sleeve
Tip
Ring
Sleeve
Tip
Sleeve
Tip
Sleeve
Tip
Sleeve
Center
Center
Centre
Screen
Screen
Screen
1
2
3
Tip
Ring
Sleeve
1
2
3
1
2
3
TIP SLEEVE
TIP SLEEVE
TIP RING SLEEVE
TIP RING SLEEVE
12
3
21
3
21
3
Tip
Ring
Sleeve
1
2
3
Tip
Sleeve
1
2
3
TIP RING SLEEVE
TIP SLEEVE
12
3
12
3
SLEEVE TIP
SLEEVE RINGTIP
For these applications the unit provides 1/4" TRS and XLR connectors to easily interface with most professional
audio devices. Follow the configuration examples below for your particular connection.
Unbalanced
In-line Connection
Balanced
TS Type Unbalanced
Sleeve
Tip
+
TRS Type Balanced
Tip
Ring
Sleeve
+
-
TRS Type Unbalanced
Tip
Ring
Sleeve
+
For 1/4" Phone jack
(5) (5)
(1)(2)(3)(4)
(6)(7)
(5) (5)
(1)(2)(3)(4)
(6)(7)

TMW
SERIES
TMW
SERIES
MODEL
Channel
Receiver Type
Frequency Response
Frequency Stability
Modulation Mode
Oscillation Mode
Frequency Band
T.H.D
Weight
Balance Output
S/N Ratio
RF Sensitivity
Dimensions
Audio Output
Power Supply
SPECIFICATION PLL UHF DIVERSITY RECEIVER
Single-channel
Diversity
PLL UHF SYNTHESIZED
UHF 798~827 MHz
50 Hz~50 kHz ( 3 dB)
0.005%
FM (F3E)
1%
1.16 Kg (Approx.)
600 mV at 15 kHz deviation
90 dB
-100 dbm/30 dB SINAD
170(W) 210(L) 43(H)
Unbalanced 6.3 mm phone jack 300 mV 15 kHz deviation
DC 12 V~18 V/0.5 A
100 dB
Dynamic Range
PLL UHF SYNTHESIZED
BODY PACK TRANSMITTER
UHF 798~827 MHz
50 Hz~15 kHz ( 3 dB)
0.005%
0.8%
FM (F3E)
10 mW
100 dB
32.768 kHz
150 mA
35 kHz deviation
"AA" 1.5 V 2 pcs (battery life: more than 6 hours)
Condenser capsule
2. Condenser
3. Electric instrument
4. Dynamic
1. Ground
65(W) 111(L) 31(H)
Oscillation Mode
MODEL
SPECIFICATION
Frequency Band
Frequency Response
Frequency Stability
T.H.D
Modulation Mode
RF Output Power
Dynamic Range
Tone Frequency
Current Drain
Max. Deviation
Battery
Microphone Capsule
4 Bands Choice
Dimensions
Weight
0.105 Kg (Approx.)
TECHNICAL SPEACIFICAION

TMW
SERIES
TMW
SERIES
TECHNICAL SPEACIFICAION
Oscillation Mode
PLL UHF SYNTHESIZED
MODEL HANDHELD TRANSMITTER
SPECIFICATION
Frequency Band
UHF 798~827 MHz
Frequency Response
50 Hz~15 kHz( 3 dB)
Frequency Stability
0.005%
T.H.D 0.8%
Modulation Mode FM (F3E)
RF Output Power
10 mW
Dynamic Range 100 dB
Tone Frequency 32.768 kHz
Current Drain 150 mA
Max. Deviation 35 kHz deviation
Battery "AA" 1.5 V 2 pcs (battery life: more than 6 hours)
Microphone Capsule
Dynamic capsule
Dimensions
230 mm
Weight 0.16 kg (Approx.)
TMW-9161

Topp Pro guarantees the normal operation of the product against any defect of manufacture
and/or vice of material, by the term of (12) months, counted as of the date of purchase on the part
of the user, committing itself to repair or to change, to its election, without posi tion so me, any
piece or component that will fail in normal conditions of use within the mentioned period.
This guarantee is valid if the original buyer will have to present /display this certificate properly
sealed and signed by the selling house, accompanied by the corresponding invoice of purchase
where it consisted the model and serial number of the acquired equipment.
With the object of its correct operation, and of the validity of this one guarantee, this product
will have to be installed and to be used according to the instructions that are detailed in the
manual associate or the package of the product.
This unit will be able to appear for its repair, next to the invoice of purchase (or any other
comprobante where the date of purchase consists), to its authorized distributer Topp Pro or an
authorized technical center on watch by Topp Pro.
Exclusion of damages:
Some states do not allow to exclusion or the limitation to the fortuitous or consequent damages,
so the aforesaid limitation can not be applied to you.
This guarantee gives specific legal rights him, you can also have other right that varies of state
to state.
The guarantee does not cover:
-Damagescaused by the illegal use of the product, repair and/or nonauthorized modification
conducted by people by Topp Pro.
-Damages caused by the connection of the equipment to other equipment different from the
specified ones in the manual of use, or by bad connection to these last ones.
-Damages caused by electrical storms, blows and / or incorrect transport.
-Damages caused by excessesor falls of tension in the network or by connection to networks
with a tension different from the required one by the unit.
-Damages caused by the presence of sand, acid of batteries, water, or any strange element
inside the equipment.
-Deteriorations produced by the course of the time, use and/or normal wear of the unit.
-Alteraion or absence of the serial number of factory of the equipment.
The repairs could only be carried out the authorized technical service by Topp Pro, that will
inform about the term and other details into the repairs to take place according to this guarantee.
Topp pro, will repair this unit in counted a term nongreater to 30 days as of the date of entrance
of the unit to the Technical Service. In those cases in that due to the particularity of the spare
part, outside necessary their import, the repair time and the viability of the same one will be
subject to the effective norms for the import of parts, in which case one will inquire to the user
about the term and possibility into repair.
THE RESPONS IBIL ITY OF TOPP PRO BY ANY DEFECTIVE PRODUCT IS LIMITED THE REPAIR
OR THE REPLACEMENT OFHE HIMSELF, TO TOPP OPTION PRO. IF WE CHOSE TO REPLACE
THE PRODUCT, THE REPLACEMENT CAN BE A RECONDITIONATED UNIT. TOPP PRO W IL L
NOT BE RESPONSIBLE BY THE DAMAGES BASED ON THE LOST, INCONVENIENCE, LOSS
OF USE, BENEFITS, LOST SAVINGS, BY THE DAMAGE TO OTHER EQUIPMENT OR OTHER
ARTICLES IN THE USE SITE, OR BY ANY OTHER DAMAGE IF HE IS FORTUITOUS,
CONSEQUENT OR OF ANOTHER TYPE, ALTHOUGH TOPP PRO HAS BEEN NOTICED OF THE
POSSIBILITY OF SUCH DAMAGES.
GUARANTEE
TMW
SERIES
TMW
SERIES

TMW
SERIES
TMW
SERIES
NOTE
9

TMW-9161
