LD WSECO16 User manual

1
4
8
12
15
IR
A F
0
dB V
+6
+3
-3
-5
AB
IR
ASC SYSTEM
1
LD WSECO16
UHF DIVERSITY WIRELESS SYSTEM
U
H
F
B
o
d
y
p
ac
k
Tr
ans
m
itte
r
U
H
F
B
o
d
y
p
ac
k
Tr
ans
m
it
t
e
r
USER´S MANUAL
BEDIENUNGSANLEITUNG
MANUEL D´UTILISATION
MANUAL DE USUARIO
INSTRUKCJA OBSŁUGI
MANUALE D‘USO

2
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
Thank you for choosing LD-Systems!
We have designed this product to give you reliable operation over many years. Therefore LD-Systems underwrites
high quality products with its name and many years of experience as a producer.
Please, take a few moments to read these instructions carefully, as we want you to enjoy your new LD-Systems
products quickly and to the fullest.
Further information about LD-Systems check our website WWW.LD-SYSTEMS.COM

1
4
8
12
15
IR
A F
0
dB V
+6
+3
-3
-5
AB
IR
ASC SYSTEM
U
H
F
B
o
d
y
p
ac
k
Tr
ans
m
itte
r
U
H
F
B
o
d
y
p
ac
k
Tr
ans
m
it
t
e
r
3
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
LD WSECO16
UHF DIVERSITY WIRELESS SYSTEM

4
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
PREVENTIVE MEASURES:
1. Please read the attached safety instructions as well as the following instructions carefully.
2. Please keep all the instructions.
3. Please use the device only as intended.
4. Please respect the valid waste management rules. Please deliver the packaging divided into plastic and
paper/ cardboard to the recycling management.
5. Please refer all servicing to qualified personel only if the device is damaged, exposed to liquid/rain or if it does
not operate normally.
6. Please, do not expose to any kind of heat such as ovens, radiators, or any other devices (incl. amplifiers).
Please check for enough distance between amplifiers and walls, racks, etc. to prevent overheating.
7. After connection please check the wiring to prevent any kind of accident or damage.
Please never use any kind of damaged cable and wiring.
8. Only use authorized and stable stands, brackets, shelfs, tables etc.. for installations. Please check for
adequate stability against collapse.
9. Appearance of interferences when using wireless systems.
The simultaneous use of wireless microphones and of mobile phones (if both devices are not very distant from
each other) can lead to the appearance of interferences in the microphone signal which can be heard in the
PA system.
CAUTION:
To reduce the risk of electric shock, do not remove cover (or back). No user serviceable parts inside. Refer
servicing to qualified personnel.
The lightning flash with arrowhead symbol within an equilateral triangle is intended to alert the
user to the presence of uninsulated “dangerous voltage” within the product´s enclosure that may be
of sufficient magnitude to constitute a risk to persons.
The exclamation mark within an equilateral triangle is intended to alert the user to the presence of
important operating and maintenance (servicing) instructions in the literature accompanying the
appliance.
CAUTION! HIGH VOLUME!
You will operate this transmission system for professional use. Therefore the commercial use of this equipment
is liable to the rules and regulations of the Accident Prevention & Insurance Association of your industry sector.
Adam Hall as a manufacturer is bound to inform you formally about the existence of eventual sanitary risks.
This system is able to induce an acoustic pressure of 80 db. 85 db is by law the maximum audio pressure
level which your ear can be exposed to during a work day. It was set according to the technical expertise of the
occupational medicine as a basis for the noise rating level. Higher sound levels or longer exposition times could
damage your ear. The time of exposition by higher sound pressure levels should be shortened in order to prevent
from ear damages. Here are a few reliable warning signals which show that you have exposed yourself for a too
long period to excessive sound pressure levels:
- You hear bell- or whistling sounds!
- You have the impression that you can’t hear high tones anymore!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN

5
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
1
4
8
12
15
IR
A F
0
dBV
+6
+3
-3
-5
AB
IR
ASC SYSTEM
tter
All sets contain the following system components:
Receiver
Batteries
Audio cable 6.3 mm mono jack to 6.3 mm mono jack
AC Adapter
Dynamic handheld microphone
Headset
Belt Pack
Additionally, depending on the set, the following accessories are included:
LDWSECO16BPH - ECO Set with belt pack and
headset
LDWSECO16HHD - ECO Set with dynamic hand-ECO Set with dynamic hand-
held microphone
SYSTEM COMPONENTS:

THE RECEIVER FEATURES THE PILOT TONE FUNCTION
The pilot tone protects against interference due to RF signals from other units. The transmitter adds an inaudible
signal, known as the pilot tone, to the transmitted signal. The receiver detects and evaluates the pilot tone, and is
thus able to identify the signal of the matching transmitter and mute all others.
6
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
1ON/OFF SWITCH
Press and hold for 1 second to turn on or off.
25 SEGMENT AUDIO LEVEL METER
3CHANNEL A ANTENNA INDICATOR LED
4CHANNEL B ANTENNA INDICATOR LED
5CHANNEL NUMBER DISPLAY
6CHANNEL DOWN BUTTON
7CHANNEL UP BUTTON
8IR WINDOW
9CHANNEL SYNCHRONIZING BUTTON
Hold Transmitter in front of the Receiver with both infrared
ports in eye contact. Press this button to complete the
synchronizing.
10 AUDIO OUTPUT LEVEL CONTROL BUTTON
Turn right to increase volume, turn left to decrease
volume.
11 ANTENNAS
1DC POWER ADAPTER SOCKET
26.3 MM UNBALANCED JACK OUTPUT
3XLR BALANCED OUTPUT
LD WSECO16 RECEIVER:
V O LU M E
1
4
8
12
15
UHF PLL ANTENNA DIVER SITY W IR ELESS REC EIVER
IR
0
dB V
+6
+3
-3
-5
ASC
AB
IR
ASC
SYSTEM
1 2 3 4 567 8 910 11
11
123
FRONT PANEL:
BACK PANEL:

7
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
1MICROPHONE HEAD GRILLE
2POWER / BATTERY STATUS INDICATOR
Red LED lights up when the battery is low, Green
LED lights up when the power is on and the battery
status is okay.
3POWER SWITCH
4BATTERY COVER
5IR WINDOW
HANDHELD TRANSMITTER:
3
1
2
4
5
CHANGING BATTERIES
The operating time of the batteries (alkaline) is approx.
10-12 hours. Change the batteries as soon as the red
LED blinks.

8
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
1ANTENNA
2BATTERY STATUS INDICATOR
Red LED lights up when the battery is low, Green LED
lights up when the power is on and the battery status
is okay.
3MINI-XLR INPUT
4GAIN ADJUSTMENT AND MUTE SWITCH
Three gain settings are available.
Mic: microphone
0 dB: Guitar with passive pickups
- 10 dB: Guitar with active pickups
5ON/OFF/MUTE SWITCH
Mid position for mute.
6IR WINDOW
BELT PACK TRANSMITTER:
tter
WEARING THE BELT PACK TRANSMITTER
Fasten the transmitter to a belt 1or guitar strap 2
. The most secure way to fasten the transmitter is to
press it down all the way so that the belt or strap is
completely enclosed by the clip, as in variant 1
CHANGING BATTERIES
Generally, 2 alkaline batteries will last 10-12 hours. If
the LED of the battery status indicator is on, the batter-
ies should be replaced immediately.
1
2
6
12
3 4 5

9
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
TIPS FOR IMPROVING PERFORMANCE:
•Aim the transmitter directly at the receiver ("line-of-sight" contact between the devices).
•Do not position the receiver near metal objects/surfaces or digital devices (CD players, computers, etc.).
•Position the receiver so that it is not directly in front of a wall and is at least 1 m above the oor.
•Cell phones, bi-directional radio devices, etc. can interfere with the radio link between transmitter and receiver
and should not be operated in the vicinity of the transmitter.
TROUBLESHOOTING
PROBLEM DISPLAY SOLUTION
No sound or volume too low
Transmitter: on/off indicator
is off
Make certain that the unit is con-
nected correctly.
"Power" indicator is off
Make certain that the power
pack is connected to the receiver
correctly.
Receiver: RF indicator is on
Increase the volume. Increase the
gain setting on the transmitter.
Check the connections from the
receiver to the amplifier or mixer.
RF indicator is off
Transmitter: indicator is on
Do not position the receiver near
metal objects. Check whether
the transmission path between
transmitter and receiver is unob-
structed ("line-of-sight" contact).
Position the transmitter closer to
the receiver. Make certain that the
transmitter and the receiver are
using the same frequency.
Transmitter: Battery status
light is on Replace the batteries.
Distortion or unwanted noise Receiver: RF indicator ON
Remove potential sources of
interference such as CD players,
computers, digital sources, etc.
Increasing distortion Transmitter: Battery status
light is on Replace the batteries
Substantial difference in levels in comparison with wired operation with
the same source or when other guitars or microphones are used
Adjust the gain setting on the
transmitter and the volume on the
receiver accordingly.

10
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
SPECIFICATIONS:
SYSTEM
Range under typical ambient conditions: 50 m
Note: the actual useable range depends on absorp-
tion and reflection of the RF signal as well as
interference.
Frequency range: (+/-3 dB) 60 Hz - 16 kHz
THD: (+/-30 kHz, 1 kHz audio signal): <1%
1 kHz Audiosignal): <1%
Dynamics: 90 dB (A-weighted)
Temperature range: -10°C / +50°C
Note: Range is dependent on battery type.
RECEIVER
Max. audio output level(ref. +/- 30 kHz, 1 kHz):
XLR connector (600 Ω ): -12 dBV
6.3-mm jack connector (3000 Ω ): -18 dBV
Output impedance: XLR connector: 200 ohms
6.3-mm jack connector: 1 kohms
XLR connector: balanced
Pin 1: ground
Pin 2: (+)
Pin 3: (-)
Sensitivity (in reference to middle audio frequency):
<-92 dB
Image rejection: 90 dB
Dimensions (W x H x D): 235 x 118 x 44 mm
Weight: 400 g
Power supply: 12 - 18 V, 400 mA, external power
adapter
BELT PACK TRANSMITTER
Max. audio input level: 0 dBV / +20 dBV
Gain range: 30 dB
Input impedance: 470 kohms
Dimensions (W x H x D): 85 x 65 x 23 mm
Weight: 80 g, without batteries
Power supply: 2 type "AA" (mignon cell) alkaline bat-
teries or corresponding rechargeable batteries
Battery life: 10-12 hours (alkaline batteries)
RF transmission power: 10 mW
HANDHELD MICROPHONE TRANSMITTER
Max. audio input level: 0 dBV
Dimensions: 250 mm (L), 53 mm (diameter)
Weight: 270 g
Power supply: 2 type "AA" (mignon cell) alkaline bat-
teries or corresponding rechargeable batteries
Battery life: 10-12 hours (alkaline batteries)
RF transmission power: 10 mW

11
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
Nr.
1 863,100 X
2 863,900
3 864,500
4 864,900
5 863,200
6 863,300
7 863,400
8 863,500
9 863,600
10 863,700 X
11 863,800
12 864,000
13 864,100 X
14 864,200
15 864,300
16 864,400
LDWSECO16 / LDWS1616 / Roadman / Roadboy
Frequency list for intermodulation free use of up to three wireless microphones simultaneously.
Frequency MHz Simultaneous
FREQUENCY LIST:

12
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
OPTIONAL ACCESSORIES:
LDWS100GC - guitar cable 6.3
mm mono jack to mini XLR
LDWS100MH1 - headset,
black
LDWSECO16BP - belt pack
transmitter
LDWS100ML - lavaliere
microphone
LDWSECO16MD - handheld
dynamic microphone

13
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
LIMITED WARRANTY
This Limited Warranty applies to the Adam Hall, LD Systems, Defender, Palmer and Eminence branded products.
The statutory warranty rights towards the seller are not affected by this guarantee. In fact, it justifies, additional
independent warranty claims towards Adam Hall.
Adam Hall warrants that the Adam Hall product you have purchased from Adam Hall or from an Adam Hall autho-
rized reseller is free from defects in materials or workmanship under normal use for a period of 2 or 5 years from
the date of purchase.
The Limited Warranty Period starts on the date of purchase. In order to receive warranty services you are required
to provide proof of the purchase date. Your dated sales or delivery receipt, showing the date of purchase, is your
proof of the purchase date. Should products of the brands named above be in need of repair within the limited war-
ranty period, you are entitled to warranty services according to the terms and conditions stated in this document.
This Limited Warranty extends only to the original purchaser of this Adam Hall branded product and is not trans-
ferable to anyone who obtains ownership of the Adam Hall branded product from the original purchaser. During
the Limited Warranty Period, Adam Hall will repair or replace the defective component parts or the product. All
component parts or hardware products removed under this Limited Warranty become the property of Adam Hall.
In the unlikely event that your Adam Hall product has a recurring failure, Adam Hall, at its discretion, may elect to
provide you with a replacement unit of Adam Hall´s choice that is at least equivalent to your Adam Hall branded
product in hardware performance.
Adam Hall does not warrant that the operation of this product will be uninterrupted or error-free. Adam Hall is not
responsible for damage that occurs as a result of your failure to follow the instructions included with the Adam
Hall branded product.
This Limited Warranty does not apply,
- to wear parts (e.g. accumulator)
- to any product from which the serial number has been removed or that has been damaged or rendered defec
tive as the result of an accident
- in case of, misuse, abuse, or other external causes
- by operation outside the usage parameters stated in the user´s documentation shipped with the
product
- by use of spare parts not manufactured or sold by Adam Hall
- by modification or service by anyone other than Adam Hall
These terms and conditions constitute the complete and exclusive warranty agreement between you and Adam
Hall regarding the Adam Hall branded product you have purchased.
MANUFACTURER´S DECLARATIONS:

14
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
MANUFACTURER´S DECLARATIONS:
LIMITATION OF LIABILITY
If your Adam Hall branded hardware product fails to work as warranted above, your sole and exclusive remedy
shall be repair or replacement. Adam Halls’ maximum liability under this limited warranty is expressly limited
to the lesser of the price you have paid for the product or the cost of repair or replacement of any hardware
components that malfunction in conditions of normal use.
Adam Hall is not liable for any damages caused by the product or the failure of the product, including any lost
profits or savings or special, incidental, or consequential damages. Adam Hall is not liable for any claim made by
a third party or made by you for a third party.
This limitation of liability applies whether damages are sought, or claims are made, under this Limited Warranty
or as a tort claim (including negligence and strict product liability), a contract claim, or any other claim. This limi-
tation of liability cannot be waived or amended by any person. This limitation of liability will be effective even if
you have advised Adam Hall of an authorized representative of Adam Hall of the possibility of any such damages.
This limitation of liability however, will not apply to claims for personal injury.
This Limited Warranty gives you specific legal rights. You may also have other rights that may vary from state to
state or from country to country. You are advised to consult applicable state or country laws for a full determina-
tion of your rights.
REQUESTING WARRANTY-SERVICE
To request warranty service for the product, contact Adam Hall or the Adam Hall authorized reseller from which
you purchased the product.
EC DECLARATION OF CONFORMITY
These devices meet the essential requirements and further relevant specifications of Directives 2004/108/EC
(EMC) and 2006/95/EC (LVD). For more information, see www.adamhall.com.
CORRECT DISPOSAL OF THIS PRODUCT (ELECTRICAL WASTE)
(Applicable in the European Union and other European countries with separate collection systems)
This marking shown on the product or its literature, indicates that it should not be disposed with other household
wastes at the end of its working life. To prevent possible harm to the environment or human health from uncon-
trolled waste disposal, please separate this from other types of wastes and recycle it responsibly to promote the
sustainable reuse of material resources.
Household users should contact either the retailer where they purchased this product, or their local government
office, for details on where and how they can recycle this item in an enviromentally friendly manner.
Business users should contact their supplier and check the terms and conditions of the purchase contract. This
product should not be mixed with other commercial wastes for disposal.

15
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
WEEE-DECLARATION
Your LD-Systems product was developed and manufactured with high quality materials and components wich
can be recycled and/or reused. This symbol indicates that electrical and electronic equipment must be disposed
of separately from normal waste at the end of its operational lifetime.
Please dispose of this product by bringing it to your local collection point or recycling centre for such equipment.
This will help to protect the environment in which we all live.
BATTERIES AND ACCUMULATORS
The supplied batteries or rechargeable batteries can be recycled. Please dispose of them as special waste or return
them to your specialist dealer. In order to protect the environment, only dispose exhausted batteries.
Adam Hall GmbH, all rights reserved. The technical data and the functional product characteristics can be subject
to modifications. The photocopying, the translation, and all other forms of copying of fragments or of the integral-
ity of this user’s manual is prohibited.

16
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
Sie haben die richtige Wahl getroffen!
Diese LD-Systems Produkte werden Sie lange Jahre durch Zuverlässigkeit, Wirtschaftlichkeit und einfaches
Handling überzeugen. Dafür garantiert LD-Systems mit seinem Namen und seiner in vielen Jahren erworbenen
Kompetenz als Hersteller hochwertiger Geräte.
Nehmen Sie sich nun ein paar Minuten Zeit, diese Anleitung zu lesen. Wir möchten, dass Sie einfach
und schnell in den Genuss dieser Technik kommen.
Mehr Informationen zu LD-SYSTEMS finden Sie auf unserer Internetseite WWW.LD-SYSTEMS.COM

1
4
8
12
15
IR
A F
0
dB V
+6
+3
-3
-5
AB
IR
ASC SYSTEM
17
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
LD WSECO16
UHF DIVERSITY WIRELESS SYSTEM
U
H
F
B
o
d
y
p
ac
k
Tr
ans
m
itte
r
U
H
F
B
o
d
y
p
ac
k
Tr
ans
m
it
t
e
r

18
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
1. Bitte beachten Sie die Sicherheitshinweise und studieren Sie diese Anleitung sorgfältig.
2. Bewahren Sie alle Hinweise und Anleitungen sicher auf.
3. Verwenden Sie das Gerät nur in der vorgesehenen Art und Weise.
4. Beachten die in Ihrem Land geltenden Entsorgungsgesetze. Trennen Sie bei der Entsorgung bitte Plastik und
Papier bzw. Kartonagen von einander.
5. Sollte Ihr Gerät nicht mehr ordnungsgemäß funktionieren, Flüssigkeiten ausgesetzt werden oder auf sonstige Art
und Weise beschädigt sein, überlassen Sie bitte jegliche Reparaturen ausschließlich autorisiertem Fachpersonal.
6. Halten Sie das Gerät von Hitzequellen wie z.B. Ofen, Heizkörper, oder sonstige Quellen (auch Verstärker) fern.
Sorgen Sie dafür dass das Gerät immer so installiert ist, dass es ausreichend gekühlt wird und nicht überhitzt.
7. Überprüfen Sie alle Verbindungen nach dem Sie das Gerät angeschossen haben um Schäden oder Unfälle zu
vermeiden.
8. Verwenden Sie ausschließlich stabile und passende Stative bzw. Befestigungen wenn das Gerät fest installiert
wird. Stellen Sie sicher, dass das Gerät sicher installiert ist und nicht herunterfallen kann.
9. Auftretende Störungen beim Betrieb von Wireless Systemen.
Beim gleichzeitigen Betrieb von Funkmikrofonen und Funktelefonen (bei geringer Entfernung der Geräte zu
einander) können im Bereich der Funkmikrofone Störungen auftreten, welche im angeschlossenen
Audiosystem hörbar sind.
ACHTUNG:
Entfernen Sie niemals die Abdeckung, da sonst die Gefahr eines elektrischen Schocks besteht.
Im Inneren des Gerätes befinden sich keine Teile, die vom Bediener gewartet oder repariert werden können.
Lassen Sie Reparaturen ausschließlich von qualifiziertem Servicepersonal durchführen.
Dieses Symbol warnt vor nichtisolierten, gefährlichen Spannungen im Geräteinneren,
die einen gefährlichen Schlag verursachen können.
Dieses Symbol kennzeichnet wichtige Bedienungs- und Wartungshinweise.
Vorsicht! Hohe Lautstärke!
Diese Übertragungsanlage wird von Ihnen professionell eingesetzt. Daher unterliegt der Gebrauch bei gewerbli-
cher Nutzung den Regeln und Vorschriften der zuständigen Berufsgenossenschaft. Adam Hall als Hersteller ist
daher verpflichtet, Sie auf möglicherweise bestehende gesundheitliche Risiken ausdrücklich hinzuweisen.
Mit diesem System können Schalldrücke über 80 db erzeugt werden. 85db ist der Schalldruck, der laut Gesetz
als maximal zulässiger Wert über die Dauer eines Arbeitstages auf Ihr Gehör einwirken darf. Er wird nach den
Erkenntnissen der Arbeitsmedizin als Berurteilungspegel zu Grunde gelegt. Höhere Lautstärken oder längere
Einwirkzeit können Ihr Gehör schädigen. Bei höheren Lautstärken muss die Hörzeit verkürzt werden, um eine
Schädigung auszuschließen. Sichere Warnsignale dafür, dass Sie sich zu lange zu lauten Geräuschen ausgesetzt
haben, sind:
- Sie hören Klingel- oder Pfeifgeräusche in den Ohren!
- Sie haben den Eindruck, hohe Töne nicht mehr wahrzunehmen!
CAUTION
RISK OF ELECTRIC SHOCK
DO NOT OPEN
VORSICHTSMASSNAHMEN:

19
ITALIANO
POLSKI
ESPAÑOL
FRANCAIS
FRANCAIS FRANCAIS FRANCAIS FRANCAIS
DEUTSCH
ENGLISH
1
4
8
12
15
IR
A F
0
dBV
+6
+3
-3
-5
AB
IR
ASC SYSTEM
tter
SYSTEMKOMPONENTEN:
Alle Sets beinhalten folgende Systemteile:
Empfänger
Batterien
Audiokabel Klinke 6,3 mm mono auf Klinke 6,3 mm mono
Netzteil
Handmikrofon dynamisch
Headset
Belt Pack
Zusätzlich sind je nach Set folgende Zubehörteile enthalten:
LDWSECO16BPH - ECO Set mit Beltpack und
Headset
LDWSECO16HHD - ECO Set mit dynamischem
Handmikrofon

DER EMPFÄNGER VERFÜGT ÜBER EINEN PILOT-TON-SQUELCH FUNKTION
Die Pilot-Ton-Einrichtung schützt eine drahtlose Mikrofonanlage vor Einstreuungen unerwünschter Signale, bei-
spielsweise die von anderen Funkanlagen.
Der Sender fügt dem eigentlich zu übertragenden Signal ein zweites, unhörbares Signal, den Pilot-Ton, hinzu. Der
Empfänger identifiziert diesen als den übereinstimmenden Pilot-Ton und gibt das dazugehörige Signal frei. Alle
anderen Signale bleiben gemuted.
20
ENGLISHDEUTSCHFRANCAIS
FRANCAISFRANCAIS FRANCAISFRANCAIS ESPAÑOLPOLSKIITALIANO
1ON/OFF SCHALTER
2AUDIO PEGELANZEIGE 5 SEGMENTE
3ANTENNE A LED ANZEIGE
4ANTENNE B LED ANZEIGE
5ANZEIGE KANALNUMMER
6NÄCHSTER KANAL
7VORHERIGER KANAL
8IR (SYNC) FENSTER
9KANAL SYNC KNOPF
Drücken Sie hier um eine Infrarotverbindung zwischen
Sender und Empfänger herzustellen.
10 AUSGANGS-LAUTSTÄRKEREGELUNG
Nach links drehen, leiser, nach rechts lauter.
11 ANTENNEN
1AC NETZADAPTER ANSCHLUSS
26.3 MM UNSYMMETRISCHER KLINKENAUSGANG
3SYMMETRISCHER XLR AUSGANG
LD WSECO16 EMPFÄNGER:
V O LU M E
1
4
8
12
15
UHF PLL ANTENNA DIVER SITY W IR ELESS REC EIVER
IR
0
dB V
+6
+3
-3
-5
ASC
AB
IR
ASC
SYSTEM
1 2 3 4 567 8 910 11
11
123
VORDERSEITE:
RÜCKSEITE:
