FormNo.3374-274RevA
36cmand41cmElectricLawnMowers
ModelNo.21180—SerialNo.312000001andUp
ModelNo.21190—SerialNo.312000001andUp
Operator'sManual
Introduction
Thisrotary-blade,walk-behindlawnmowerisintended
tobeusedbyresidentialhomeowners.Itisdesigned
primarilyforcuttinggrassonwell-maintainedlawns
onresidentialproperties.Itisnotdesignedforcutting
brushorforagriculturaluses.
Readthismanualcarefullytolearnhowtooperateand
maintainyourmowerproperly.Theinformationinthis
manualcanhelpyouandothersavoidinjuryandproduct
damage.AlthoughTorodesignsandproducessafeproducts,
youareresponsibleforoperatingtheproductproperlyand
safely.
Regulationsontheoperationofmowersvaryfromonearea
toanother.Consultwithlocalauthoritiesforregulationsand
restrictionsregardingpermittedmowingtimesinyourarea.
Contents
Introduction..................................................................1
SafeOperatingPractices...........................................1
SoundPressure(Model21180)..................................2
SoundPower(Model21180).....................................2
Vibration,Hand/arm(Model21180).........................3
SoundPressure(Model21190)..................................3
SoundPower(Model21190).....................................3
Vibration,Hand/arm(Model21190).........................3
.............................................................................3
WasteofElectrical/ElectronicEquipment
(WEEE).............................................................3
SafetyandInstructionalDecals.................................3
Setup............................................................................4
1UnfoldingtheHandle............................................4
2AssemblingtheGrassBag......................................4
ProductOverview..........................................................6
Specications.........................................................6
Operation.....................................................................6
SecuringtheExtensionCord.....................................6
PlanningYourMowingPattern..................................7
StartingtheMotor...................................................7
StoppingtheMotor.................................................7
AdjustingtheHeight-of-CutSetting...........................8
BaggingtheClippings..............................................8
MowingTips..........................................................9
Maintenance..................................................................9
Double-insulatedAppliances....................................9
CleaningtheMowerHousing....................................9
LubricatingtheMachine..........................................10
ServicingtheBlade.................................................10
ServicingtheOn/OffandBladeBrake
System..............................................................11
Storage........................................................................12
Troubleshooting...........................................................13
Safety
Readandunderstandthecontentsofthismanualbefore
startingthemotor.
Thisisthesafetyalertsymbol.Itisusedtoalertyou
topotentialpersonalinjuryhazards.Obeyallsafety
messagesthatfollowthissymboltoavoidpossibleinjury
ordeath.
Improperlyusingormaintainingthislawnmowercould
resultininjuryordeath.Toreducethispotential,
complywiththefollowingsafetyinstructions.
WARNING
Toreducetheriskofre,electricshock,and
personalinjurywhenusingthiselectriclawn
mower,alwaysfollowthesesafetyinstructions.
Thefollowingsafetyinformationhasbeenadaptedfrom
EuropeanStandardEN836/A3:2004andEN60335-77:2006.
SafeOperatingPractices
GeneralInformation
•Readtheinstructionscarefully.Befamiliarwiththe
controlsandtheproperuseoftheequipment.
•Neverallowchildrenorpeopleunfamiliarwiththese
instructionstousethelawnmower.Localregulationscan
restricttheageoftheoperator.
•Nevermowwhilepeople,especiallychildrenorpets,are
nearby.
•Theoperatororuserisresponsibleforaccidentsor
hazardsoccurringtootherpeopleortheirproperty.
©2012—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.T oro.com.OriginalInstructions(EN)
PrintedinChina
AllRightsReserved*3374-274*A

Preparation
•Whilemowing,alwayswearsubstantialfootwearandlong
trousers.Donotoperatetheequipmentwhenbarefoot
orwearingopensandals.
•Thoroughlyinspecttheareawheretheequipmentisto
beused,andremoveallobjectswhichcanbethrownby
themachine.
•Beforeusing,alwaysvisuallyinspecttoseethattheblade,
bladebolts,andcutterassemblyarenotwornordamaged.
Replaceawornordamagedbladeandboltsasasetto
preservebalance.
•Tororecommendsthatthemowershouldbesupplied
witharesidualcurrentdevice(RCD)havingatripping
currentofnotmorethan30mA.
•Useonly1.00mm2sizeextensioncordnomorethan30
mlongsuitableforoutdooruse(ifapplicable).
•Regularlyinspectthepowercordsforsignsofdamageor
aging.Replaceimmediatelyifdefective.
•Donotusethemowerifanypowercordisdamagedor
worn.
•Donotconnectadamagedextensioncordtothemains
supplyortouchadamagedcordbeforeitisdisconnected
fromthemainssupply.Adamagedcordcanleadto
contactwithliveparts.
Handling
•Mowonlyindaylightoringoodarticiallight.
•Avoidoperatingtheequipmentinwetgrass,where
feasible.
•Alwaysbesureofyourfootingonslopes.
•Walk;neverrun.
•Forwheeledrotarymowers,mowacrossthefaceof
slopes,neverupanddown.
•Exerciseextremecautionwhenchangingdirectionon
slopes.
•Donotmowexcessivelysteepslopes.
•Useextremecautionwhenreversingorpullingthelawn
mowertowardyou.
•Switchoffthemowerwhentransportingitfromone
cuttingareatoanother.Stopthebladewheneveryou
movethemoweroffthelawn.
•Neveroperatethelawnmowerwithdefectiveguardsor
withoutmountedsafetydevices(forexample,deectors
and/orgrasscatchers)inplace.
•Switchonthemotorcarefullyaccordingtoinstructions
andwithfeetwellawayfromtheblade.
•Donottiltthelawnmowerwhenswitchingonthemotor,
exceptifthelawnmowerhastobetiltedforstarting.In
thiscase,donottiltitmorethanabsolutelynecessaryand
liftonlythepartwhichisawayfromtheoperator.Always
ensurethatbothhandsareintheoperatingposition
beforereturningtheappliancetotheground.
•Donotputhandsorfeetnearorunderrotatingparts.
Keepclearofthedischargeopeningatalltimes.
•Neverpickuporcarryalawnmowerwhilethemotoris
running.
•Pulltheplugfromthesocket:
–wheneveryouleavethelawnmower;
–beforeclearingablockageorremovingmaterialfrom
thechute;
–beforechecking,cleaning,orworkingonthelawn
mower;
–afterstrikingaforeignobject.Inspectthelawn
mowerfordamageandmakerepairsbeforerestarting
andoperatingthelawnmower;
–ifthelawnmowerstartstovibrateabnormally(check
immediately).
•Iftheextensioncordbecomesdamagedduringuse,stop
themower,removeplugfromthemainssupply,and
replacethedamagedextensioncord.
•Donottouchthebladesbeforethemachineis
disconnectedfromthemainssupplyandthebladeshave
cometoacompletestop.
•Keeptheextensioncordawayfromtheblades.The
bladescancausedamagetotheextensioncordandlead
tocontactwithliveparts.
MaintenanceandStorage
•Keepallnuts,bolts,andscrewstighttobesurethe
equipmentisinsafeworkingcondition.
•Checkthegrasscatcherfrequentlyforwearor
deterioration.
•Replacewornordamagedpartsforsafety.
•Ensurethatonlytheproperreplacementcuttingblade
isused.
•PurchaseonlygenuineTororeplacementpartsand
accessories.
SoundPressure(Model21180)
Thisunithasasoundpressurelevelattheoperator’searof78
dBA,whichincludesanUncertaintyValue(K)of2dBA.
Soundpressurelevelwasdeterminedaccordingtothe
proceduresoutlinedinEN836.
SoundPower(Model21180)
Thisunithasaguaranteedsoundpowerlevelof88dBA,
whichincludesanUncertaintyValue(K)of2dBA.
Soundpowerlevelwasdeterminedaccordingtothe
proceduresoutlinedinISO11094.
2

Vibration,Hand/arm(Model
21180)
Measuredvibrationlevelforrighthand=1.0m/s2
Measuredvibrationlevelforlefthand=1.0m/s2
UncertaintyValue(K)=0.5m/s2
Measuredvaluesweredeterminedaccordingtotheprocedures
outlinedinEN836.
SoundPressure(Model21190)
Thisunithasasoundpressurelevelattheoperator’searof83
dBA,whichincludesanUncertaintyValue(K)of2dBA.
Soundpressurelevelwasdeterminedaccordingtothe
proceduresoutlinedinEN836.
SoundPower(Model21190)
Thisunithasaguaranteedsoundpowerlevelof93dBA,
whichincludesanUncertaintyValue(K)of2dBA.
Soundpowerlevelwasdeterminedaccordingtothe
proceduresoutlinedinISO11094.
Vibration,Hand/arm(Model
21190)
Measuredvibrationlevelforrighthand=1.0m/s2
Measuredvibrationlevelforlefthand=1.0m/s2
UncertaintyValue(K)=0.5m/s2
Measuredvaluesweredeterminedaccordingtotheprocedures
outlinedinEN836.
WasteofElectrical/ElectronicEquipment(WEEE)
•EUdirective2002/96/ECclassiesthisproductasanelectricalorelectronictool.
•DoNotdisposeofthistoolasunsortedmunicipalwaste.
•Disposeofthistoolatacollectionorrecyclingcenteraccordingtolocalandnationallaw.
•Theconsumerhasanimportantroleinreducingthedisposalofwastebyreturningwasteelectronic/electrical
toolsforrecycling.
•Recyclingavoidsthedispersionofhazardousmaterialsintothemunicipalwastestream.
•Thecrossed-outbinsymbolremindstheusernottodisposeofthisproductasunsortedmunicipalwaste.
SafetyandInstructional
Decals
Important:Safetyandinstructiondecalsarelocated
nearareasofpotentialdanger.Replacedamagedor
lostdecals.
111-4782
1.Heightofcut
111–5173
1.Warning—readthe
Operator’sManual.
4.Electricalshock
hazard—donotoperate
themachineintherain.
2.Cutting/dismemberment
hazardofhandorfoot,
mowerblade—waitfor
movingpartstostop.
5.Electricalshock
hazard—donotrunover
themachine’selectrical
cable.
3.Thrownobject
hazard—keepbystanders
asafedistancefromthe
machine.
6.Cutting/dismemberment
hazardofhandorfoot,
mowerblade—unplug
themachinebefore
performingmaintenance.
3

Setup
Note:Donotconnectthemowertoapowersourceuntil
themowerisfullyassembled.
1
UnfoldingtheHandle
NoPartsRequired
Procedure
1.Carefullyunfoldthehandle,keepingthecablesclearof
thepivotpointssothattheydonotgetpinched.
CAUTION
Thehandlespasseachotherlikeascissors
whilefoldingandunfoldingthemandcan
pinchyourngers.
Keepyourngersclearofthepivotpointsand
crossinghandlesasyoufoldorunfoldthe
handles.
g015048
Figure1
Model21180
g015106
Figure2
Model21190
2.Tightentheknobsonthehandletosecurethehandle
inplace.
2
AssemblingtheGrassBag
NoPartsRequired
Procedure
1.Slidethewirebagframeintothegrassbag,ensuring
thatthehandleisabovethefabric(Figure3).
4

1
2
3
g015049
Figure3
1.Grassbag3.Handle
2.Wireframe
2.Startingatthehandle,connectthe6plasticclipsonthe
grassbagtothewireframe(Figure4).
1
g015107
Figure4
1.Starthereandworkdownward.
3.Installtheplasticcoverontothebagframeasshown
inFigure5.
1
g015108
Figure5
1.Plasticcover
5

ProductOverview
2
6
4
3
1
8
7
9
5
g015050
Figure6
1.Handleknob(2)6.Cordlock
2.Extensioncord(not
supplied)
7.Grassbag
3.Button8.Reardoor
4.Controlbar9.Height-of-cutlever
5.Handle
Specications
Model2118021190
Weight20.4kg27.4kg
Length136cm138cm
Width45cm48cm
Height104cm106cm
Widthofcut36cm41cm
Height-of-cut
range(7positions)
13to60mm13to65mm
Voltsand
Frequency
230V/50Hz230V/50Hz
Power1.4kW1.5kW
Operation
SecuringtheExtensionCord
Useonlyanextensioncordrecommendedforoutdoor,
cold-weatheruse.
WARNING
Contactingwaterwhileoperatingthemowercould
causeanelectricshock,whichcancauseaninjury
ordeath.
•Don'thandletheplugorthemowerwithwet
handsorwhilestandinginwater.
•Useonlyanextensioncordrecommendedfor
outdoor,cold-weatheruse.
1.Formaloopintheextensioncordandsecureitinthe
cordlock(Figure7).
g015051
Figure7
2.Connecttheextensioncordtothemowerplug.
Note:Donotunplugtheextensioncordbypulling
onthecord;tounplugthecord,grasptheplug,not
thecord.
WARNING
Theelectricalcordcouldbedamaged,causinga
shockorre.
Thoroughlyinspecttheelectricalcordbeforeusing
themower.Ifthecordisdamaged,donotoperate
themower.HaveanAuthorizedToroServiceDealer
replaceorrepairadamagedcordimmediately.
6

PlanningYourMowingPattern
Followingthesuggestedmowingpatternwillreducetherisk
ofrunningoverthecordwiththemower,andthecordwill
notsustainunnecessarywear.Donotallowthepowercord
towraparoundtrees,shrubs,orotherobstacles.
Beginbymowingneartheelectricalpowersource.Mowback
andforth,graduallymowingawayfromthepowersource
(Figure8).
G019210
Figure8
StartingtheMotor
WARNING
Allowthemotortocometoacompletestopbefore
startingit.Failuretodothiscoulddamagethe
motor,makingthemowerunsafe.
1.Connecttheextensioncordtothemower(if
applicable).
2.Plugtheotherendofthecordintoahousehold
electricalpoweroutlet.
3.Pushthebuttonontherightsideofthehandleand
holditin(Figure9).
g015053
Figure9
4.Whileholdinginthebutton,pullthecontrolbar
towardthehandle(Figure10).
g015054
Figure10
5.Holdthecontrolbartothehandleandreleasethe
button(Figure11).
g015055
Figure11
StoppingtheMotor
1.Releasethecontrolbar(Figure12).
g015056
Figure12
2.Disconnectthemowerfromthepowersourceifyou
leavethemowerunattended.
7

AdjustingtheHeight-of-Cut
Setting
DANGER
Adjustingtheheight-of-cutsettingcouldbringyour
handsandfeetintocontactwithamovingblade
andresultinseriousinjury.
Stopthemotorandwaitforallmovingpartstostop
beforechangingtheheight-of-cutsetting.
1.Stopthemotorandwaitforallmovingpartstostop.
2.Pulltheheight-of-cutleveroutofthepositionslotit
isin,andmoveitforwardorrearwardtothedesired
slot(Figure13).
g015057
Figure13
BaggingtheClippings
Installthegrassbagtocollecttheclippings.
1.Liftthereardoorandremovethemulchplug
(Figure14).
1
G01921 1
2
Figure14
1.Reardoor2.Mulchplug
2.Whileholdingupthereardoor,installthegrassbag
ontothelugs(Figure15).
1
2
3
g0151 10
Figure15
1.Reardoor3.Grassbag
2.Lug
3.Releasethereardoor.
4.Mowwiththegrassbagattached.
5.Whenthebagisfull,stopthemotor,removethegrass
bagfromthemower,andemptythecontents.
8

Note:Toconvertfrombaggingtorecycling,removethe
grassbag,andinsertthemulchplugthatyouremovedinstep
1(Figure16).
1
G019212
Figure16
Model21180shown
1.Mulchplug
MowingTips
Followtheseinstructionswhencuttinggrassforthebest
cuttingresultsandlawnappearance.
•Maintainasharpbladethroughoutthemowingseason.
•Onlymowdrygrass.Wetgrasstendstoclumponthe
yardandmaycausethemowertopluguporthemotor
tostall.Theymayalsobeslipperytowalkonandcould
causeyoutoslipandfall.
•Whilecuttingsingleswaths,ensureanoverlapofabout
4cm.
•Whencuttingverytallgrass,youmaywanttorstmow
atthehighestheight-of-cutsettingandaslowerwalking
speed;thenmowagainatalowersettingforbestlawn
appearance.
•Ifthenishedcutlawnappearanceisunsatisfactory,try
oneormoreofthefollowing:
–Sharpentheblade.
–Walkataslowerpacewhilemowing.
–Raisetheheight-of-cutsettingonyourmower.
–Cutthegrassmorefrequently.
–Overlapcuttingswathsinsteadofcuttingafullswath
witheachpass.
Maintenance
Torohasdesignedthisproducttogiveyouyearsof
trouble-freeuse.Shoulditneedservice,bringtheproductto
anAuthorizedToroServiceDealer.
WARNING
Whenthemowerisconnectedtoahouseholdpower
source,themowerisoperational.Someonecould
accidentallystartthemowerandcauseaserious
injurytoyouorotherbystanders.
Alwaysdisconnectthemowerfromthepower
sourcewhenyouleavethemowerunattended.
Double-insulatedAppliances
Inadouble-insulatedappliance,2systemsofinsulation
areprovidedinsteadofgrounding.Nogroundingmeans
isprovidedonadouble-insulatedappliance,norshoulda
meansforgroundingbeaddedtotheappliance.Servicing
adouble-insulatedappliancerequiresextremecareand
knowledgeofthesystem,andshouldbedoneonlybythe
qualiedservicepersonnelatanAuthorizedToroService
Dealer.Replacementpartsforadouble-insulatedappliance
mustbeidenticaltothepartstheyreplace.Adouble-insulated
applianceismarkedwiththewords“DoubleInsulation”or
“DoubleInsulated.”Thesymbol(squarewithinasquare)
mayalsobemarkedontheappliance.
CleaningtheMowerHousing
Aftereachuse,cleanthemowerhousing.
Beforecleaning,stopthemotor,waitforallmovingpartsto
stop,anddisconnectthemowerfromthepowersource.
Important:Donotcleanthemowerwithwater.
Moisturecangettrappedinthemowerandmaycause
corrosionofinternalparts.
•Cleantheundersideofthemowerhousing.Removedirt
andgrassclippingswithahardwoodscraperorbrush
(Figure17).
9

g0151 16
Figure17
•Removethedebrisfromthehousingventsalongthetop
ofthemower.
•Brushallthedebrisoffthemowerhousing.
•Inspectthepowerplugreceptacleforsignsofmelting
orheating.Oldworn-outextensioncordplugsthatt
looselyintheplugreceptaclecancauseoverheatingfrom
poorcontact.Replaceanydamagedextensioncords
immediately(ifapplicable).
LubricatingtheMachine
Lubricatethewheels,linkages,andpivotpointsevery25
operatinghourswithengineoil(Figure18).
g0151 15
Figure18
ServicingtheBlade
Alwaysmowwithasharpblade.Asharpbladecutsthegrass
evenly,withouttearingorshreddingthegrass.
Whenyoureplacetheblade,useonlygenuineToro
replacementblades.
WARNING
Someonecouldaccidentallystartthemotor
andcauseaseriousinjurytotheoperatororto
bystanders.
Donotattempttoinspect,remove,orreplacethe
bladewithoutrstdisconnectingthemowerfrom
thepowersource.
1.Stopthemotorandwaitforallmovingpartstostop.
2.Disconnectthemowerfromtheelectricalpower
source.
3.Tipthemowerontoitsside.
4.Carefullyexaminethebladeforsharpnessandwear,
especiallywheretheatandcurvedpartsoftheblade
meet.Ifyounoticewear,replacetheblade.
Note:Forbestperformance,installanewblade
beforethemowingseasonbegins.Duringtheseason,
ledownsmallnicksonthebladetomaintainits
cuttingedge.
DANGER
Awornordamagedbladecouldbreakanda
pieceofbladecouldbethrownintheoperator's
orbystander'sdirection,causingseriouspersonal
injuryordeath.
Inspectthebladeperiodicallyforwearordamage,
andreplaceawornordamagedblade.
RemovingtheBlade
1.Grasptheendoftheblade(Figure19)witharagor
thicklypaddedglove.
1
2
g014059
Figure19
1.Bladebolt2.Blade
2.Removethebladeboltandtheblade.
Important:Ifthebladeadaptercomesoff,ensure
thatyouinstallitbeforeinstallingthebladeand
10

bladebolt.Operatingthemowerwithouttheblade
adapterwilldamagethemower.
SharpeningtheBlade
Usealetosharpenthetopsideofthebladeandmaintain
theoriginalcuttingangle.
Note:Thebladewillremainbalancedifyouremovethe
sameamountofmaterialfrombothcuttingedges.
Important:Checkthebalanceofthebladebyputtingit
onabladebalancer.Youcanpurchaseaninexpensive
balanceratahardwarestore.Abalancedbladestaysina
horizontalposition;anunbalancedbladesettlestothe
heavyside.Ifthebladeisnotbalanced,lemoremetal
offthecuttingedgeontheheavyendoftheblade.
InstallingtheBlade
Installasharp,balancedbladeandthebladebolt.Thesail
partoftheblademustpointtowardthetopofthemower
housingtoensurecorrectinstallation.Tightenthebladebolt
to20N-m.
ServicingtheOn/OffandBlade
BrakeSystem
Themotorandbladearedesignedtostopwithin3seconds
afteryoureleasethecontrolbar.Ensurethatthecontrolbar
functionsproperlyeachtimebeforeyouoperatethemower.
Ifthebladedoesnotstopwithin3secondsorthereisa
grindingorscraping,metal-to-metalnoisewhenyourelease
thecontrolbar,contactanAuthorizedToroServiceDealer.
Thissamerecommendationappliesifyouobserveheavy
vibrationswhenusingthemower.
11

Storage
1.Cleanthemowerhousing.
2.Checktheconditionoftheblade.
3.FoldthehandleasshowninFigure20andFigure21,
dependingonyourmodel.
Important:Ensurethatyoudonotcrimpthe
controlcablesasyoufoldthehandle.
CAUTION
Thehandlespasseachotherlikeascissors
whilefoldingandunfoldingthemandcan
pinchyourngers.
Keepyourngersclearofthepivotpointsand
crossinghandlesasyoufoldorunfoldthe
handles.
g015060
Figure20
Model21180shown
g015052
Figure21
Model21190shown
4.Storethemowerinacool,clean,anddryplaceaway
fromchildren.
5.Coverthemowertokeepitcleanandprotected.
12

Troubleshooting
ProblemPossibleCauseCorrectiveAction
1.Theextensioncordisnotconnectedto
themower.
1.Connecttheextensioncordtothe
mowerandplugtheotherendofthe
extensioncordintoanormalhousehold
outlet.
2.Theextensioncordisdamaged.2.Checktheextensioncord,andrepair
orreplacethecordifitisdamaged.
Motorwillnotstart
3.Thefuseorcircuitbreakerisblown.3.Checktheoutletfuseorthecircuit
breaker.
1.Themowerdischargechuteisplugged.1.Cleanthemowerdischargechute.
2.Theundersideofthemowerhousing
needstobecleaned.
2.Cleantheundersideofthemower
housing.
Motorstartshardorlosespower
3.Thecuttingheightissettoolow.3.Setthemowercuttingheightinahigher
positionandstartthemotoragain.
1.Thebladeisnotbalanced.1.Balancetheblade.
2.Theblademountingboltisloose.2.Tightentheblademountingbolt.
3.Themowerdischargechuteisplugged.3.Cleanthemowerdischargechute.
4.Theundersideofthemowerhousing
needstobecleaned.
4.Cleantheundersideofthemower
deck.
Mowerormotorvibratesexcessively
5.Themotormountingboltsareloose.5.Tightenthemotormountingbolts.
1.Thebladeisdullandisnotbalanced.1.Sharpenandbalancetheblade.
2.Youaremowingthesamepattern
everytimeyoumow.
2.Changethemowingpattern.
Unevencuttingpattern
3.Theundersideofthemowerhousing
needstobecleaned.
3.Cleantheundersideofthemower
deck.
1.Theheight-of-cutsettingissettoolow.1.Raisetheheight-of-cutsetting.
2.Youaretryingtomowwetgrass.2.Allowthegrasstodrybeforemowing.
Dischargechuteplugs
3.Theundersideofthemowerhousing
needstobecleaned.
3.Cleantheundersideofthemower
deck.
13

Notes:
14

InternationalDistributorList
Distributor:Country:PhoneNumber:Distributor:Country:PhoneNumber:
AtlantisSuveSulamaSisstemleriLtTurkey902163448674JeanHeybroekb.v.Netherlands31306394611
BalamaPrimaEngineeringEquip.HongKong85221552163MaquiverS.A.Colombia5712364079
B-RayCorporationKorea82325512076MaruyamaMfg.Co.Inc.Japan81332522285
CascoSalesCompanyPuertoRico7877888383AgrolancKftHungary3627539640
CeresS.A.CostaRica5062391138Mountelda.s.CzechRepublic420255704220
CSSCTurfEquipment(pvt)Ltd.SriLanka94112746100MunditolS.A.Argentina541148219999
CyrilJohnston&Co.NorthernIreland442890813121OslingerTurfEquipmentSAEcuador59342396970
EquiverMexico525553995444OyHakoGroundandGardenAbFinland35898700733
FemcoS.A.Guatemala5024423277ParklandProductsLtd.NewZealand6433493760
G.Y .K.CompanyLtd.Japan81726325861Prochaska&CieAustria4312785100
GeomechanikiofAthensGreece30109350054RTCohen2004Ltd.Israel97298617979
GuandongGoldenStarChina862087651338RiversaSpain34952837500
HakoGroundandGardenSweden4635100000ScSvendCarlsenA/SDenmark4566109200
HakoGroundandGardenNorway4722907760SolvertS.A.S.France33130817700
HayterLimited(U.K.)UnitedKingdom441279723444SpyprosStavrinidesLimitedCyprus35722434131
HydroturfInt.CoDubaiUnitedArabEmirates97143479479SurgeSystemsIndiaLimitedIndia911292299901
HydroturfEgyptLLCEgypt2025194308T-MarktLogisticsLtd.Hungary3626525500
IbeaS.P .A.Italy390331853611ToroAustraliaAustralia61395807355
IrriamcPortugal351212388260T oroEuropeNVBelgium3214562960
IrrigationProductsInt'lPvtLtd.India862283960789
EuropeanPrivacyNotice
TheInformationT oroCollects
ToroWarrantyCompany(Toro)respectsyourprivacy.Inordertoprocessyourwarrantyclaimandcontactyouintheeventofaproductrecall,weaskyou
tosharecertainpersonalinformationwithus,eitherdirectlyorthroughyourlocalTorodealer.
TheT orowarrantysystemishostedonserverslocatedwithintheUnitedStateswhereprivacylawmaynotprovidethesameprotectionasapplies
inyourcountry.
BYSHARINGYOURPERSONALINFORMATIONWITHUS,YOUARECONSENTINGTOTHEPROCESSINGOFYOURPERSONALINFORMATION
ASDESCRIBEDINTHISPRIVACYNOTICE.
TheWayT oroUsesInformation
Toromayuseyourpersonalinformationtoprocesswarrantyclaimsandtocontactyouintheeventofaproductrecall.T oromayshareyourinformation
withToro'safliates,dealersorotherbusinesspartnersinconnectionwithanyoftheseactivities.Wewillnotusepersonalinformationprovidedfor
warrantypurposesformarketing,norshallwegiveorsellpersonalinformationprovidedforwarrantypurposestoanyothercompanyformarketing.We
reservetherighttodisclosepersonalinformationinordertocomplywithapplicablelawsandwithrequestsbytheappropriateauthorities,tooperateits
systemsproperlyorforourownprotectionorthatofotherusers.
RetentionofyourPersonalInformation
Wewillkeepyourpersonalinformationaslongasweneeditforthepurposesforwhichitwasoriginallycollectedorforotherlegitimatepurposes
(suchasregulatorycompliance),orasrequiredbyapplicablelaw.
Toro'sCommitmenttoSecurityofYourPersonalInformation
Wetakereasonableprecautionsinordertoprotectthesecurityofyourpersonalinformation.Wealsotakestepstomaintaintheaccuracyandcurrent
statusofpersonalinformation.
AccessandCorrectionofyourPersonalInformation
Ifyouwouldliketorevieworcorrectyourpersonalinformation,pleasecontactusbyemailat[email protected].
AustralianConsumerLaw
AustraliancustomerswillnddetailsrelatingtotheAustralianConsumerLaweitherinsidetheboxoratyourlocalToroDealer.
374-0269RevD

TheToroWarranty
ConditionsandProductsCovered
TheToroCompanyanditsafliate,ToroWarrantyCompany,pursuantto
anagreementbetweenthem,jointlypromisetotheoriginalpurchaser*
torepairtheToroProductslistedbelowifdefectiveinmaterialsor
workmanship.
Thefollowingtimeperiodsapplyfromthedateofpurchase:
ProductsWarrantyPeriod
WalkPowerMowers
•CastDeck5yearsResidentialUse2
45DaysCommercialUse
•Engine5yearsGTSPromise
Seeenginemanufacturer'swarranty1
•SteelDeck2yearsResidentialUse2
45DaysCommercialUse
•Engine2yearsGTSPromise
Seeenginemanufacturer'swarranty1
ElectricHandHeldProducts2yearlimitedwarranty
Snowthrowers
•SingleStage2yearsResidentialUse2
45DaysCommercialUse
•TwoStage2yearsResidentialUse2
45DaysCommercialUse
•Electric2yearsResidentialUse2
AllRide-OnUnitsBelow
•EngineSeeenginemanufacturer'swarranty1
1yearPartsonly
•Attachments1year
RearEngineRiders2yearsResidentialUse2
90DaysCommercialUse
Lawn&GardenTractors2yearsResidentialUse2
90DaysCommercialUse
TimeCutterZMowers3yearsResidentialUse2
30DaysCommercialUse
TITANMowers3yearsor240hours3
•FrameLifetime(originalowneronly)4
TITANMXMowers3yearsor400hours3
•FrameLifetime(originalowneronly)4
ZMasterMowers—2000Series5yearsor1200hours3
•FrameLifetime(originalowneronly)4
*OriginalPurchasermeansthepersonwhooriginallypurchasedtheT oroProduct.
1SomeenginesusedonToroProductsarewarrantedbytheenginemanufacturer.
2Residentialusemeansuseoftheproductonthesamelotasyourhome.Useatmorethanone
locationisconsideredcommercialuseandthecommercialusewarrantywouldapply.
3Whicheveroccursrst.
4LifetimeFrameWarranty-Ifthemainframe,consistingofthepartsweldedtogethertoformthe
tractorstructurethatothercomponentssuchastheenginearesecuredto,cracksorbreaksin
normaluse,itwillberepairedorreplaced,atT oro'soption,underwarrantyatnocostforparts
andlabor.Framefailureduetomisuseorabuseandfailureorrepairrequiredduetorustor
corrosionarenotcovered.
Thiswarrantyincludesthecostofpartsandlabor,butyoumustpay
transportationcosts.
Warrantymaybedeniedifthehourmeterisdisconnected,altered,or
showssignsofbeingtamperedwith.
OwnerResponsibilities
YoumustmaintainyourToroProductbyfollowingthemaintenance
proceduresdescribedintheOperator'sManual.Suchroutine
maintenance,whetherperformedbyadealerorbyyou,isatyourexpense.
InstructionsforObtainingWarrantyService
IfyouthinkthatyourT oroProductcontainsadefectinmaterialsor
workmanship,followthisprocedure:
1.Contactyoursellertoarrangeserviceoftheproduct.Ifforany
reasonitisimpossibleforyoutocontactyourseller,youmaycontact
anyToroAuthorizedDistributortoarrangeservice.
2.Bringtheproductandyourproofofpurchase(salesreceipt)tothe
ServiceDealer.IfforanyreasonyouaredissatisedwiththeService
Dealer’sanalysisorwiththeassistanceprovided,contactusat:
CustomerCareDepartment,RLCDivision
TheToroCompany
8111LyndaleAvenueSouth
Bloomington,MN55420-1196
Manager:TechnicalProductSupport:001–952–887–8248
SeeattachedDistributorList
ItemsandConditionsNotCovered
Thisexpresswarrantydoesnotcoverthefollowing:
•Costofregularmaintenanceserviceorwearparts,suchasblades,
rotorblades(paddles),scraperblades,belts,fuel,lubricants,oil
changes,sparkplugs,cable/linkageorbrakeadjustments
•Anyproductorpartwhichhasbeenalteredormisusedandrequires
replacementorrepairduetoaccidentsorlackofpropermaintenance
•Repairsnecessaryduetofailuretousefreshfuel(lessthanone
monthold),orfailuretoproperlypreparetheunitpriortoanyperiod
ofnon-useoveronemonth
•Engineandtransmission.Thesearecoveredbytheappropriate
manufacturer’sguaranteeswithseparatetermsandconditions
Allrepairscoveredbythesewarrantiesmustbeperformedbyan
AuthorizedToroServiceDealerusingToroapprovedreplacementparts.
GeneralConditions
Thepurchaseriscoveredbythenationallawsofeachcountry.Therights
towhichthepurchaserisentitledwiththesupportoftheselawsarenot
restrictedbythiswarranty.
374-0268RevC
