Toro 22290 User manual

FormNo.3423-303RevA
21inHeavy-DutyRecycler®/Rear
BaggerLawnMower
ModelNo.22290—SerialNo.404320000andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)*3423-303*A

ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineon
anyforest-covered,brush-covered,orgrass-covered
landunlesstheengineisequippedwithaspark
arrester,asdenedinSection4442,maintainedin
effectiveworkingorderortheengineisconstructed,
equipped,andmaintainedforthepreventionofre.
Theenclosedengineowner'smanualissupplied
forinformationregardingtheUSEnvironmental
ProtectionAgency(EPA)andtheCaliforniaEmission
ControlRegulationofemissionsystems,maintenance,
andwarranty.Replacementsmaybeorderedthrough
theenginemanufacturer.
GrossorNetTorque:Thegrossornettorque
ofthisenginewaslaboratoryratedbytheengine
manufacturerinaccordancewiththeSocietyof
AutomotiveEngineers(SAE)J1940orJ2723.As
conguredtomeetsafety,emission,andoperating
requirements,theactualenginetorqueonthisclass
ofmowerwillbesignicantlylower.Pleasereferto
theenginemanufacturer’sinformationincludedwith
themachine.
WARNING
CALIFORNIA
Proposition65Warning
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Useofthisproductmaycauseexposure
tochemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
Introduction
Thisrotary-blade,walk-behindlawnmowerisintended
tobeusedprofessional,hiredoperators.Itisdesigned
primarilyforcuttinggrassonwell-maintainedlawns
onresidentialorcommercialproperties.Usingthis
productforpurposesotherthanitsintendedusecould
provedangeroustoyouandbystanders.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
Visitwww.T oro.comformoreinformation,including
safetytips,trainingmaterials,accessoryinformation,
helpndingadealer,ortoregisteryourproduct.
Wheneveryouneedservice,genuineToroparts,or
additionalinformation,contactanAuthorizedService
DealerorT oroCustomerServiceandhavethemodel
andserialnumbersofyourproductready.Figure1
identiesthelocationofthemodelandserialnumbers
ontheproduct.Writethenumbersinthespace
provided.
Important:Withyourmobiledevice,youcan
scantheQRcodeontheserialnumberdecal(if
equipped)toaccesswarranty,parts,andother
productinformation
g226623
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhas
safetymessagesidentiedbythesafety-alertsymbol
(Figure2),whichsignalsahazardthatmaycause
seriousinjuryordeathifyoudonotfollowthe
recommendedprecautions.
g000502
Figure2
Safety-alertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanical
informationandNoteemphasizesgeneralinformation
worthyofspecialattention.
©2018—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedinMexico
AllRightsReserved

Contents
Safety.......................................................................3
GeneralSafety...................................................3
SafetyandInstructionalDecals..........................4
Setup........................................................................6
1RemovingtheCableGuard..............................6
2InstallingtheHandle........................................6
3InstallingtheCableGuard................................7
4InstallingtheRecoil-StarterRopeinthe
RopeGuide.....................................................8
5FillingtheCrankcasewithOil...........................8
6AssemblingtheGrassBag...............................9
7AdjustingtheSelf-PropelDrive......................10
ProductOverview....................................................11
BeforeOperation..................................................11
BeforeOperationSafety....................................11
FillingtheFuelTank..........................................12
CheckingtheEngine-OilLevel..........................13
AdjustingtheHandleHeight.............................13
AdjustingtheCuttingHeight.............................14
DuringOperation.................................................14
DuringOperationSafety...................................14
StartingtheEngine...........................................15
ShuttingOfftheEngine.....................................15
OperatingtheSelf-PropelDrive........................15
RecyclingtheClippings....................................16
BaggingtheClippings.......................................17
OperatingTips.................................................19
AfterOperation....................................................19
AfterOperationSafety......................................19
CleaningundertheMachine.............................20
Maintenance...........................................................21
MaintenanceSafety..........................................21
ServicingtheAirFilter.......................................21
ChangingtheEngineOil...................................21
ServicingtheSparkPlug...................................22
AdjustingtheSelf-PropelDrive.........................22
MaintainingtheBlade.......................................23
CleaningundertheBeltCover..........................25
CleaningtheWheels.........................................26
Storage...................................................................26
StorageSafety..................................................26
PreparingtheFuelSystem...............................26
PreparingtheEngine........................................26
GeneralInformation..........................................26
RemovingtheMachinefromStorage................27
Troubleshooting......................................................28
Safety
Thismachinehasbeendesignedinaccordancewith
ANSIB71.4-2017.
GeneralSafety
Thisproductiscapableofamputatinghandsand
feetandofthrowingobjects.Alwaysfollowallsafety
instructionstoavoidseriouspersonalinjury.
•Read,understand,andfollowtheinstructions
andwarningsinthisOperator’sManualandon
themachineandattachmentsbeforestartingthe
engine.
•Donotputyourhandsorfeetnearmovingpartsof
orunderthemachine.Keepclearofanydischarge
opening.
•Donotoperatethemachinewithoutallguards
andothersafetyprotectivedevicesinplaceand
functioningproperlyonthemachine.
•Keepbystandersandchildrenoutoftheoperating
area.Donotallowchildrentooperatethemachine.
Allowonlypeoplewhoareresponsible,trained,
familiarwiththeinstructions,andphysically
capabletooperatethemachine.
•Stopthemachine,shutofftheengine,andwaitfor
allmovingpartstostopbeforeservicing,fueling,
oruncloggingthemachine.
Improperlyusingormaintainingthismachinecan
resultininjury.Toreducethepotentialforinjury,
complywiththesesafetyinstructionsandalways
payattentiontothesafety-alertsymbol,which
meansCaution,Warning,orDanger—personalsafety
instruction.Failuretocomplywiththeseinstructions
mayresultinpersonalinjuryordeath.
3

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decaloemmarkt
Manufacturer'sMark
1.Thismarkindicatesthatthebladeisidentiedasapart
fromtheoriginalmachinemanufacturer.
decal94-8072
94-8072
decal116-7583
116-7583
1.Warning—readtheOperator’sManual.Donotoperatethis
machineunlessyouaretrained.
4.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts;keepallguardsinplace.
2.Thrownobjecthazard—keepbystandersasafedistance
awayfromthemachine.
5.Warning—wearhearingprotection.
3.Thrownobjecthazard—donotoperatethemachinewithout
therear-dischargeplugorbaginplace.
6.Cutting/dismembermenthazardofhandorfoot,mower
blade—donotoperateupanddownslopes;operateside
tosideonslopes;shutofftheenginebeforeleavingthe
operatingposition—pickupobjectsthatthebladescould
throw;andlookbehindyouwhenbackingup.
4

decal125-8404
125-8404
1.Pushtheprimeronce.2.Pulltherecoil-starthandle.
decal130-6722
130-6722
1.Attention—readtheOperator'sManual.
decal130-9670
130-9670
1.Severinghazardofhandorfoot;mowerblade—keepaway
frommovingparts.
decal133-8062
133-8062
5

Setup
Important:Removeanddiscardtheprotectiveplasticsheetthatcoverstheengineandanyother
plasticorwrappingonthemachine.
1
RemovingtheCableGuard
NoPartsRequired
Procedure
g234471
Figure3
6

2
InstallingtheHandle
NoPartsRequired
Procedure
g234475
Figure4
7

3
InstallingtheCableGuard
NoPartsRequired
Procedure
g234486
Figure5
4
InstallingtheRecoil-Starter
RopeintheRopeGuide
NoPartsRequired
Procedure
g230180
Figure6
8

5
FillingtheCrankcasewithOil
NoPartsRequired
Procedure
Important:Iftheoillevelinthecrankcaseistoolowortoohighandyouruntheengine,youmay
damagetheengine.
g235721
Figure7
9

6
AssemblingtheGrassBag
NoPartsRequired
Procedure
g238450
Figure8
7
AdjustingtheSelf-Propel
Drive
NoPartsRequired
Procedure
Important:Youmustadjusttheself-propel-drive
cablebeforeyouoperatethemachinefortherst
time.RefertoAdjustingtheSelf-PropelDrive
(page22).
10

ProductOverview
g024344
Figure9
1.Handle7.Sparkplug
2.Self-propel-drivebar8.Cutting-heightlever(4)
3.Blade-controlbar9.Oilll/dipstick
4.Reardeector10.Grassbag
5.Fuel-tankcap11.Recoil-starthandle
6.Aircleaner
Operation
Note:Determinetheleftandrightsidesofthe
machinefromthenormaloperatingposition.
BeforeOperation
BeforeOperationSafety
GeneralSafety
•Alwaysshutoffthemachine,waitforallmoving
partstostop,andallowthemachinetocoolbefore
adjusting,servicing,cleaning,orstoringit.
•Becomefamiliarwiththesafeoperationofthe
equipment,operatorcontrols,andsafetysigns.
•Checkthatallguardsandsafetydevices,suchas
deectorsand/orgrasscatcher,areinplaceand
functioningproperly.
•Alwaysinspectthemachinetoensurethatthe
bladesandbladeboltsarenotwornordamaged.
•Inspecttheareawhereyouwillusethemachine,
andremoveallobjectsthatcouldinterferewith
theoperationofthemachineorthatthemachine
couldthrow.
•Contactwiththemovingbladewillcauseserious
injury.Donotputyourngersunderthehousing
whenadjustingthecuttingheight.
FuelSafety
•Fuelisextremelyammableandhighlyexplosive.
Areorexplosionfromfuelcanburnyouand
othersandcandamageproperty.
–Topreventastaticchargefromignitingthefuel,
placethecontainerand/ormachinedirectlyon
thegroundbeforelling,notinavehicleoron
anobject.
–Fillthefueltankoutdoors,inanopenarea,
whentheengineiscold.Wipeupanyfuelthat
spills.
–Donothandlefuelwhensmokingoraroundan
openameorsparks.
–Donotremovethefuelcaporaddfueltothe
tankwhiletheengineisrunningorhot.
–Ifyouspillfuel,donotattempttostartthe
engine.Avoidcreatingasourceofignitionuntil
thefuelvaporshavedissipated.
–Storefuelinanapprovedcontainerandkeep
itoutofthereachofchildren.
•Fuelisharmfulorfatalifswallowed.Long-term
exposuretovaporscancauseseriousinjuryand
illness.
11

–Avoidprolongedbreathingofvapors.
–Keepyourhandsandfaceawayfromthe
nozzleandthefuel-tankopening.
–Keepfuelawayfromyoureyesandskin.
FillingtheFuelTank
DANGER
Gasolineisextremelyammableand
explosive.Areorexplosionfromgasoline
canburnyouandothers.
•Topreventastaticchargefromigniting
thegasoline,placethecontainerand/or
machinedirectlyonthegroundbefore
lling,notinavehicleoronanobject.
•Fillthetankoutdoorswhentheengineis
cold.Wipeupspills.
•Donothandlegasolinewhensmokingor
aroundanopenameorsparks.
•Storegasolineinanapprovedfuel
container,outofthereachofchildren.
•Forbestresults,useonlyclean,fresh(lessthan
30daysold),unleadedgasolinewithanoctane
ratingof87orhigher((R+M)/2ratingmethod).
•Oxygenatedfuelwithupto10%ethanolor15%
MTBEbyvolumeisacceptable.
•Ethanol:Gasolinewithupto10%ethanol
(gasohol)or15%MTBE(methyltertiarybutyl
ether)byvolumeisacceptable.Ethanoland
MTBEarenotthesame.Gasolinewith15%
ethanol(E15)byvolumeisnotapprovedforuse.
Neverusegasolinethatcontainsmorethan
10%ethanolbyvolume,suchasE15(contains
15%ethanol),E20(contains20%ethanol),orE85
(containsupto85%ethanol).Usingunapproved
gasolinemaycauseperformanceproblemsand/or
enginedamagewhichmaynotbecoveredunder
warranty.
•Donotusegasolinecontainingmethanol.
•Donotstorefueleitherinthefueltankorinfuel
containersoverthewinterunlessyouuseafuel
stabilizer.
•Donotaddoiltogasoline.
Important:Toreducestartingproblems,addfuel
stabilizer/conditionertofreshfuelasdirectedby
thefuel-stabilizermanufacturer.
Note:Thecapacityofthefueltankis1.8L(0.47
USgallon).
g230458
Figure10
12

CheckingtheEngine-OilLevel
ServiceInterval:Beforeeachuseordaily
Important:Iftheoillevelinthecrankcaseistoolowortoohighandyouruntheengine,youmay
damagetheengine.
g235721
Figure11
AdjustingtheHandleHeight
Youcanraiseorlowerthehandlein1of3positionsthatismorecomfortableforyou(Figure12).
g272748
Figure12
1.Removebothhandleboltsandcorrespondingnuts.
2.Movethehandletothedesiredheightposition.
3.Securethehandlewiththepreviouslyremovedboltsandcorrespondingnuts.
13

AdjustingtheCuttingHeight
CAUTION
Iftheenginehasbeenrunning,themuferwillbehotandcanseverelyburnyou.
Keepawayfromthehotmufer.
Adjustthecuttingheightasdesired.Setallwheelstothesamecuttingheight(Figure13).
g234297
Figure13
DuringOperation
DuringOperationSafety
GeneralSafety
•Wearappropriateclothing,includingeye
protection;longpants;substantial,slip-resistant
footwear;andhearingprotection.Tiebacklong
hairanddonotwearlooseclothingorloose
jewelry.
•Useyourfullattentionwhileoperatingthe
machine.Donotengageinanyactivitythat
causesdistractions;otherwise,injuryorproperty
damagemayoccur.
•Donotoperatethemachinewhileill,tired,or
undertheinuenceofalcoholordrugs.
•Thebladeissharp;contactingthebladecanresult
inseriouspersonalinjury.Shutofftheengineand
waitforallmovingpartstostopbeforeleavingthe
operatingposition.
•Whenyoureleasetheblade-controlbar,the
engineshouldshutoffandthebladeshouldstop
within3seconds.Ifnot,stopusingyourmachine
immediatelyandcontactanAuthorizedService
Dealer.
•Keepbystandersoutoftheoperatingarea.Keep
smallchildrenoutoftheoperatingareaandunder
thewatchfulcareofaresponsibleadultwhois
notoperatingthemachine.Stopthemachineif
anyoneentersthearea.
14

•Alwayslookdownandbehindyoubeforemoving
themachineinreverse.
•Operatethemachineonlyingoodvisibilityand
appropriateweatherconditions.Donotoperate
themachinewhenthereistheriskoflightning.
•Wetgrassorleavescancauseseriousinjuryif
youslipandcontacttheblade.Avoidmowingin
wetconditions.
•Useextremecarewhenapproachingblind
corners,shrubs,trees,orotherobjectsthatmay
blockyourview.
•Donotdirectthedischargematerialtoward
anyone.Avoiddischargingmaterialagainstawall
orobstruction;materialmayricochettowardyou.
Stoptheblade(s)whencrossinggravelsurfaces.
•Watchforholes,ruts,bumps,rocks,orother
hiddenobjects.Uneventerraincouldcauseyou
toloseyourbalanceorfooting.
•Ifthemachinestrikesanobjectorstartsto
vibrate,immediatelyshutofftheengine,waitfor
allmovingpartstostop,anddisconnectthewire
fromthesparkplugbeforeexaminingthemachine
fordamage.Makeallnecessaryrepairsbefore
resumingoperation.
•Beforeleavingtheoperatingposition,shutoffthe
engineandwaitforallmovingpartstostop.
•Iftheenginehasbeenrunning,itwillbehotand
canseverelyburnyou.Keepawayfromthehot
engine.
•Operatetheengineonlyinwell-ventilatedareas.
Exhaustgasescontaincarbonmonoxide,which
islethalifinhaled.
•Checkthegrasscatchercomponentsandthe
dischargechutefrequentlyforanywearor
deteriorationandreplacethemwithgenuineT oro
partswhennecessary.
SlopeSafety
•Mowacrossthefaceofslopes;neverupand
down.Useextremecautionwhenchanging
directiononslopes.
•Donotmowonexcessivelysteepslopes.Poor
footingcouldcauseaslip-and-fallaccident.
•Mowwithcautionneardrop-offs,ditches,or
embankments.
StartingtheEngine
g234299
Figure14
ShuttingOfftheEngine
ServiceInterval:Beforeeachuseordaily
Toshutofftheengine,releasetheblade-controlbar.
Important:Whenyoureleasetheblade-control
bar,boththeengineandbladeshouldstopwithin
3seconds.Iftheydonotstopproperly,stop
usingyourmachineimmediatelyandcontactan
AuthorizedServiceDealer.
OperatingtheSelf-Propel
Drive
•Toengagetheself-propel-drive:Pullthe
self-propel-drivebartothehandleandholdit
(Figure15).
15

g024356
Figure15
1.Blade-controlbar(shown
engaged)
3.Upperhandle
2.Self-propel-drivebar
Note:Themaximumself-propel-drivespeedis
xed.T oreducethespeed,increasethespace
betweentheself-propel-drivebarandthehandle.
•Todisengagetheself-propeldrive:Releasethe
self-propel-drivebar.
Note:Themachinecomeswithfreewheeling
clutchesthatmakeiteasiertopullthemachine
rearward.Todisengagetheclutches,you
mayneedtopushthemachineforwardabout
2.5cm(1inch)ormoreafteryoureleasethe
self-propel-drivebar.
RecyclingtheClippings
Thismachinecomesfromthefactoryreadytorecyclegrassandleafclippingsbackintothelawn.T oprepare
themachinetorecycle:
•Ifthegrassbagisonthemachine,removeit(AofFigure16).
•Iftherear-dischargeplugisnotinstalled,gripitbythehandle,raisethereardeector,andinsertitintothe
rear-dischargechuteuntilthelatchlocksintoplace(BofFigure16).
g236734
Figure16
WARNING
Operatingthemachinetorecyclelawnclippingswithoutthepluginplaceallowsobjectstobe
throwntowardyouorbystanders.Also,contactwiththebladescouldoccur.Thrownobjects
orbladecontactcancauseseriousinjuryordeath.
Ensurethattherear-dischargeplugisinplacebeforeyourecycletheclippings.Neverengage
thebladeswithouteithertherear-dischargeplugorthegrassbaginstalledonthemachine.
16

BaggingtheClippings
Usethegrassbagwhenyouwanttocollectgrassandleafclippingsfromthelawn.
WARNING
Aworngrassbagcouldallowsmallstonesandothersimilardebristobethrowntowardyou
orbystanders,resultinginseriouspersonalinjuryordeath.
Checkthegrassbagfrequently.Ifitisdamaged,installanewTororeplacementbag.
WARNING
Thebladesaresharp;contactingthebladescanresultinseriouspersonalinjury.
Shutofftheengineandwaitforallmovingpartstostopbeforeleavingtheoperatingposition.
17

InstallingtheGrassBag
1.Shutofftheengineandwaitforallmovingpartstostop.
2.Raiseandholdupthereardeector(AofFigure17).
3.Removetherear-dischargeplugbypushinginthelatchwithyourthumbandpullingtheplugoutfrom
themachine(BandCofFigure17).
4.Installthebag-rodendsintothenotchesatthebaseofthehandle,androckthebagbackandforthto
ensurethatthebag-rodendsareseatedatthebottomofbothnotches(DofFigure17).
5.Lowerthereardeectoruntilitrestsonthegrassbag.
g236745
Figure17
RemovingtheGrassBag
DANGER
Themachinecanthrowgrassclippingsandotherobjectsthroughanopeninginthemachine
housing.Objectsthrownwithenoughforcecouldcauseseriouspersonalinjuryordeathto
youortobystanders.
•Neverremovethegrassbagandthenstarttheenginewithoutthedischargepluginstalled
onthemachine.
•Neveropenthereardeectoronthemachinewhentheengineisrunning.
1.Shutofftheengineandwaitforallmovingpartstostop.
2.Raisethereardeector.
3.Removethebagrodonthegrassbagfromthenotchesatthebaseofthehandle(AofFigure16).
4.Installthedischargeplug(BofFigure16).
5.Lowerthereardeector(CofFigure16).
18

OperatingTips
GeneralTips
•Reviewthesafetyinstructionsandreadthis
manualcarefullybeforeoperatingthemachine.
•Cleartheareaofsticks,stones,wire,branches,
andotherdebristhatthebladecouldhitandthrow.
•Keepeveryone,especiallychildrenandpets,away
fromtheareaofoperation.
•Avoidstrikingtrees,walls,curbs,orothersolid
objects.Neverdeliberatelymowoveranyobject.
•Ifthemachinestrikesanobjectorstartstovibrate,
immediatelyshutofftheengine,disconnect
thewirefromthesparkplug,andexaminethe
machinefordamage.
•Maintainasharpbladethroughoutthecutting
season.Periodicallyledownnicksontheblade.
•Replacethebladewhennecessarywithanoriginal
Tororeplacementblade.
•Mowonlydrygrassorleaves.Wetgrassand
leavestendtoclumpontheyardandcancause
themachinetoplugortheenginetostall.
WARNING
Wetgrassorleavescancauseserious
injuryifyouslipandcontacttheblade.
Mowonlyindryconditions.
•Cleanunderthemachineaftereachmowing;refer
toCleaningundertheMachine(page20).
•Keeptheengineingoodrunningcondition.
•Cleantheairlterfrequently.Mulchingstirsup
moreclippingsanddustwhichclogstheairlter
andreducesengineperformance.
•Settheenginespeedtothefastestpositionforthe
bestcuttingresults.
WARNING
Operatingamachinewithitsengine
runningataspeedgreaterthanthefactory
settingcancausethemachinetothrowa
partofthebladeorenginetowardyouor
bystanders,resultinginseriouspersonal
injuryordeath.
–Donotchangetheenginespeedsetting.
–Ifyoususpecttheenginespeedisfaster
thannormal,contactanAuthorized
ServiceDealer.
CuttingGrass
•Grassgrowsatdifferentratesatdifferenttimes
oftheyear.Inthesummerheat,itisbesttocut
grassatthe64mm(2-1/2inch),76mm(3inch),
or89mm(3-1/2inch)cutting-heightsettings.Cut
onlyaboutathirdofthegrassbladeatatime.
Donotcutbelowthe64mm(2-1/2inch)setting
unlessthegrassissparseoritislatefallwhen
grassgrowthbeginstoslowdown.
•Whencuttinggrassover15cm(6inches)tall,rst
mowatthehighestcutting-heightsettingandwalk
slower;thenmowagainatalowersettingforthe
bestlawnappearance.Ifthegrassistoolongand
theleavesclumpontopofthelawn,themachine
mayplugandcausetheenginetostall.
•Alternatethemowingdirection.Thishelps
dispersetheclippingsoverthelawnforeven
fertilization.
Ifthenishedlawnappearanceisunsatisfactory,try1
ormoreofthefollowing:
•Sharpentheblade.
•Walkataslowerpacewhilemowing.
•Raisethecuttingheightonyourmachine.
•Cutthegrassmorefrequently.
•Overlapcuttingswathsinsteadofcuttingafull
swathwitheachpass.
CuttingLeaves
•Aftercuttingthelawn,ensurethathalfofthelawn
showsthroughthecutleafcover.Youmayneed
tomakemorethanasinglepassovertheleaves.
•Forlightleafcoverage,setallthewheelsatthe
samecutting-heightsetting.
•Slowdownyourmowingspeedifthemachine
doesnotcuttheleavesnelyenough.
AfterOperation
AfterOperationSafety
GeneralSafety
•Alwaysshutoffthemachine,waitforallmoving
partstostop,andallowthemachinetocoolbefore
adjusting,servicing,cleaning,orstoringit.
•Cleangrassanddebrisfromthemachinetohelp
preventres.Cleanupoilorfuelspills.
•Neverstorethemachineorfuelcontainerwhere
thereisanopename,spark,orpilotlight,such
asonawaterheateroronotherappliances.
HaulingSafety
•Removetheignitionkey(ifequipped)before
loadingthemachineforhauling.
•Usecarewhenloadingorunloadingthemachine.
19

•Securethemachinefromrolling.
•Closethefuelvalvebeforeloadingthemachine
forhauling.
CleaningundertheMachine
Toensurethebestperformance,keeptheunderside
ofthemachineclean.Beespeciallycarefultokeep
thekickersfreeofdebris(Figure18).
g024254
Figure18
1.Kickers
WashingMethod
ServiceInterval:Beforeeachuseordaily
WARNING
Themachinemaydislodgematerialfrom
underthemachine.
•Weareyeprotection.
•Stayintheoperatingposition(behindthe
handle)whiletheengineisrunning.
•Donotallowbystandersinthearea.
1.Movethemachinetoapavedlevelsurfacenear
agardenhose.
2.Starttheengine.
3.Holdtherunninggardenhoseathandlelevel
anddirectthewatertoowonthegroundjustin
frontoftheright,rearwheel(Figure19).
g002275
Figure19
1.Right,rearwheel
Note:Thebladewilldrawinwaterandwash
outtheclippings.Letthewaterrununtilyou
nolongerseeclippingsbeingwashedoutfrom
underthemachine.
4.Shutofftheengineandwaitforallmovingparts
tostop.
5.Turnoffthewater.
6.Startthemachineandletitrunforafewminutes
todryouttheundersideofthemachine.
ScrapingMethod
Ifwashingdoesnotremovealldebrisfromunderthe
machine,scrapeitclean.
1.Disconnectthewirefromthesparkplug.
2.Drainthefuelfromthefueltank.
WARNING
Tippingthemachinemaycausethefuel
toleakfromthecarburetororthefuel
tank.Fuelisextremelyammable,highly
explosive,and,undercertainconditions,
cancausepersonalinjuryorproperty
damage.
Avoidfuelspillsbyrunningtheengine
dryorbyremovingthefuelwithahand
pump;neversiphon.
3.Tipthemachineontoitsrightside(aircleaner
up).
4.Removethedirtandgrassclippingswitha
hardwoodscraper.Avoidburrsandsharp
edges.
5.Returnthemachinetotheoperatingposition.
6.Connectthewiretothesparkplug.
20
