FormNo.3405-894RevA
SuperRecycler®LawnMower
ModelNo.20381—SerialNo.316000001andUp
ModelNo.20384—SerialNo.316000001andUp
Operator'sManual
Introduction
Thisrotary-blade,walk-behindlawnmowerisintendedto
beusedbyresidentialhomeowners.Itisdesignedprimarily
forcuttinggrassonwell-maintainedlawnsonresidential
properties.Itisnotdesignedforcuttingbrushorfor
agriculturaluses.
Readthisinformationcarefullytolearnhowtooperateand
maintainyourproductproperlyandtoavoidinjuryand
productdamage.Youareresponsibleforoperatingthe
productproperlyandsafely.
YoumaycontactTorodirectlyatwww .Toro.comforproduct
andaccessoryinformation,helpndingadealer,ortoregister
yourproduct.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourproductready.Figure1identiesthelocationofthe
modelandserialnumbersontheproduct.
1
g026368
Figure1
1.Modelandserialnumberplate
Writetheproductmodelandserialnumbersinthespace
below:
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
Figure2
1.Safetyalertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
WARNING
CALIFORNIA
Proposition65Warning
Thisproductcontainsachemicalorchemicals
knowntotheStateofCaliforniatocausecancer,
birthdefects,orotherreproductiveharm.
Theengineexhaustfromthisproduct
containschemicalsknowntotheStateof
Californiatocausecancer,birthdefects,
orotherreproductiveharm.
ItisaviolationofCaliforniaPublicResourceCode
Section4442or4443touseoroperatetheengineonany
forest-covered,brush-covered,orgrass-coveredlandunless
theengineisequippedwithasparkarrester,asdenedin
Section4442,maintainedineffectiveworkingorderorthe
engineisconstructed,equipped,andmaintainedforthe
preventionofre.
ThissparkignitionsystemcomplieswithCanadianICES-002.
Theenclosed
Engine Owner's Man ual
issuppliedfor
informationregardingtheUSEnvironmentalProtection
Agency(EPA)andtheCaliforniaEmissionControl
Regulationofemissionsystems,maintenance,and
warranty.Replacementsmaybeorderedthroughthe
enginemanufacturer.
NetTorque:Thegrossornettorqueofthisenginewas
laboratoryratedbytheenginemanufacturerinaccordance
withtheSocietyofAutomotiveEngineers(SAE)J1940.
Asconguredtomeetsafety,emission,andoperating
requirements,theactualenginetorqueonthisclassofmower
willbesignicantlylower.Gotowww.Toro.comtoview
specicationsonyourmowermodel.
©2016—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3405-894*A

Contents
Introduction..................................................................1
Safety...........................................................................2
GeneralSafety.........................................................2
SafetyandInstructionalDecals.................................3
Setup............................................................................6
1AssemblingandUnfoldingtheHandle.....................6
2InstallingtheRecoil-StarterRopeintheRope
Guide.................................................................7
3FillingtheEnginewithOil......................................7
4ChargingtheBattery..............................................7
5AssemblingtheGrassBag......................................8
ProductOverview..........................................................9
Operation.....................................................................9
BeforeOperation.......................................................9
BeforeOperationSafety...........................................9
FillingtheFuelTank...............................................10
CheckingtheEngine-OilLevel.................................10
AdjustingtheHandleHeight....................................10
AdjustingtheCuttingHeight....................................11
DuringOperation.....................................................11
GeneralSafety........................................................11
SlopeSafety...........................................................12
StartingtheEngine.................................................12
UsingtheSelf-PropelDrive.....................................12
StoppingtheEngine...............................................12
RecyclingtheClippings...........................................13
BaggingtheClippings.............................................13
Side-DischargingtheClippings.................................15
OperatingTips......................................................16
AfterOperation........................................................16
AfterOperatingSafety............................................16
CleaningtheMachine..............................................16
FoldingtheHandle.................................................17
Maintenance.................................................................19
RecommendedMaintenanceSchedule(s)......................19
MaintenanceSafety.................................................19
PreparingforMaintenance.......................................19
ReplacingtheAirCleaner........................................20
ChangingtheEngineOil.........................................20
ChargingtheBattery...............................................21
ReplacingtheFuse..................................................21
LubricatingtheWheelGears....................................22
ReplacingtheBlade................................................22
AdjustingtheSelf-PropelDrive................................23
Storage........................................................................23
PreparingtheMachineforStorage............................23
RemovingtheMachinefromStorage.........................24
Safety
ThismachinehasbeendesignedinaccordancewithANSI
B71.1-2012.
GeneralSafety
Thisproductiscapableofamputatinghandsandfeetand
ofthrowingobjects.Alwaysfollowallsafetyinstructionsto
avoidseriouspersonalinjury.
Usingthisproductforpurposesotherthanitsintendeduse
couldprovedangeroustoyouandbystanders.
•ReadandunderstandthecontentsofthisOperator’s
Manualbeforeyoustarttheengine.Ensurethateveryone
usingthisproductknowshowtouseitandunderstands
thewarnings.
•Donotputyourhandsorfeetnearmovingcomponents
ofthemachine.
•Donotoperatethemachinewithoutallguardsandother
safetyprotectivedevicesinplaceandworkingonthe
machine.
•Keepclearofanydischargeopening.Keepbystandersa
safedistancefromthemachine.
•Keepchildrenoutoftheoperatingarea.Neverallow
childrentooperatethemachine.
•Stopthemachine,shutofftheengine,andremove
theelectric-startbuttonbeforeservicing,fueling,or
uncloggingthemachine.
Improperlyusingormaintainingthismachinecanresult
ininjury.Toreducethepotentialforinjury,complywith
thesesafetyinstructionsandalwayspayattentiontothe
safety-alertsymbol,whichmeansCaution,Warning,or
Danger—personalsafetyinstruction.Failuretocomplywith
theseinstructionsmayresultinpersonalinjuryordeath.
Youcanndadditionalitemsofsafetyinformationintheir
respectivesectionsthroughoutthismanual.
2

SafetyandInstructionalDecals
Important:Safetyandinstructiondecalsarelocatednearareasofpotentialdanger.Replacedamageddecals.
Manufacturer'sMark
1.Indicatesthebladeisidentiedasapartfromtheoriginal
machinemanufacturer.
94-8072
104-7403
Electric-startmodelonly
104-7953
Electric-startmodelonly
1.Warning—readtheOperator'sManualforinformationonchargingthebattery;containslead;donotdiscard.
2.ReadtheOperator'sManual.
3

112-8867
1.Lock2.Unlock
115-2884
HandlePositionAdjustment
115-2896
Electric-startmodelonly
115-8411
1.Unlocked2.Locked
117-2718
4

133–1900
1.ReadtheOperator’sManualformoreinformationonstarting
theengine—1)Inserttheelectric-startbuttonintotheignition;
2)Engagetheblade-controlbar;3)Pushtheelectric-start
buttontostarttheengine.
2.ReadtheOperator’sManualformoreinformationonstopping
theengine—1)Releasetheblade-controlbar;2)Removethe
electric-startbuttonfromtheignition.
131-0894
TractionAdjustment
1.Attention;readtheOperator'sManual—1)Loosenthe
knobbyturningitcounterclockwise;2)Pullthecable(s)
awayfromtheenginetodecreasethetraction,orpush
thecable(s)towardtheenginetoincreasethetraction;3)
Tightentheknobbyturningitclockwise.
131–4514
1.Warning—readtheOperator'sManual.
2.Cutting/dismembermenthazardofhandorfoot,mower
blade—stayawayfrommovingparts;keepallguardsand
shieldsinplace.
3.Cutting/dismembermenthazardofhandorfoot,mower
blade—disconnectthespark-plugwireandreadthe
instructionsbeforeservicingorperformingmaintenance.
4.Thrownobjecthazard—keepbystandersasafedistance
fromthemachine;stoptheenginebeforeleavingthe
operatingposition;pickupanydebrisbeforemowing.
5.Cutting/dismembermenthazardofhandorfoot,mower
blade—donotoperateupanddownslopes;operatesideto
sideonslopes;lookbehindyouwhenbackingup.
5

Setup
Important:Removeanddiscardtheprotectiveplastic
sheetthatcoverstheengineandanyotherplasticor
wrappingonthemachine.
Important:Topreventaccidentalstarting,donotinsert
theelectric-startbuttonintotheelectricstarterswitch
untilyouarereadytostarttheengine.
1
AssemblingandUnfoldingthe
Handle
NoPartsRequired
Procedure
WARNING
Assemblingandunfoldingthehandleimproperly
candamagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenassemblingand
unfoldingthehandle.
•Ensurethatthecablesareroutedtotheoutside
ofthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Raisetherearofthemachinehousingtoits
highestcutting-heightsettingbymovingthe2rear
cutting-heightleversallthewayforward.Referto
AdjustingtheCuttingHeight(page11).
2.Attachthehandleendstothemachinehousingwith
2washersand2handlebolts(Figure3),butdonot
tightenthehandlebolts.
G017457
Figure3
1.Washer3.Handleend
2.Handlebolt
Important:Routethecablestothe
outside
ofthe
handle(Figure3).
3.Rotatethehandlerearward(Figure4).
G017458
Figure4
4.Lockthehandleatyourdesiredheight.Referto
AdjustingtheHandleHeight(page10).
5.Torquethehandleboltsto14to17N∙m(120to160
in-lb).
6

6.Adjustthecuttingheight.RefertoAdjustingthe
CuttingHeight(page11).
2
InstallingtheRecoil-Starter
RopeintheRopeGuide
NoPartsRequired
Procedure
Important:Tostarttheenginesafelyandeasily
wheneveryouusethemachine,installtherecoil-starter
ropeintheropeguide.
Holdtheblade-controlbartotheupperhandleandpullthe
recoil-starterropethroughtheropeguideonthehandle
(Figure5).
Figure5
1.Recoil-starterrope2.Ropeguide
3
FillingtheEnginewithOil
NoPartsRequired
Procedure
Important:Yourmachinedoesnotcomewithoilin
theengine.Beforestartingtheengine,lltheengine
withoil.
1.Movethemachinetoalevelsurface.
2.Removethedipstick(Figure6)andpourabout3/4of
thecrankcasecapacityofoilintotheoil-lltube.
Note:Max.ll:0.59L(20oz),type:SAE30orSAE
10W-30detergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.
G017459
Figure6
1.Theoillevelisatits
maximum.
3.Theoillevelistoo
low—addoiltothe
crankcase.
2.Theoillevelistoo
high—removeoilfrom
thecrankcase.
3.Wipeoffthedipstickendwithacleancloth.
4.Insertthedipstickintotheoil-lltube,butdonot
screwitin.
5.Removethedipstickandreadtheoillevelonthe
dipstick(Figure6).
•Iftheoillevelistoolow,addasmallamountof
oilslowlytotheoil-lltube,andthenrepeatsteps
3through5untiltheoillevelonthedipstickis
correct.
•Iftheoillevelistoohigh,draintheexcessoiluntil
theoillevelonthedipstickiscorrect.Todrainthe
excessoil,refertoChangingtheEngineOil(page
20).
Important:Iftheoillevelinthecrankcaseis
toolowortoohighandyouruntheengine,
youmaydamagetheengine.
6.Installthedipsticksecurely.
Important:
Change the engine oil after the r st 5
operating hour s
;changeityearlythereafter.Refer
toChangingtheEngineOil(page20).
7

4
ChargingtheBattery
NoPartsRequired
Procedure
Electric-startmodelonly
RefertoChargingtheBattery(page21).
5
AssemblingtheGrassBag
NoPartsRequired
Procedure
1.SlipthegrassbagovertheframeasshowninFigure7.
g027257
1
23
Figure7
1.Handle3.Grassbag
2.Frame
Note:Donotslipthebagoverthehandle(Figure7).
2.Hookthebottomchannelofthebagontothebottom
oftheframe(Figure8).
g027258
Figure8
3.Hookthetopandsidechannelsofthebagontothetop
andsidesoftheframe,respectively(Figure8).
8

ProductOverview
G027603
1
2
3
4
5
6
7
89
10
11
12
13
14
Figure9
1.Cutting-heightlever(4)8.Blade-controlbar
2.Sparkplug9.Upperhandle
3.Oilll/Dipstick(notshown)10.Electric-start
button(electric-startmodel
only)
4.Fueltankcap11.Grassbag
5.Dischargedeector12.Battery(electric-start
modelonly)
6.Recoilstarthandle13.Washoutport
7.Adjustmentknobforthe
self-propeldrive
14.Airlter
Figure10
1.Grassbag3.Batterycharger
(electric-startmodelonly)
2.Side-dischargechute4.Rear-dischargeplug
(installed)
Operation
BeforeOperation
BeforeOperationSafety
GeneralSafety
•Becomefamiliarwiththesafeoperationoftheequipment,
operatorcontrols,andsafetysigns.
•Checkthatallguardsandsafetydevices,suchasdeectors
and/orgrasscatcher,areinplaceandworkingproperly.
•Alwaysinspectthemachinetoensurethattheblades,
bladebolts,andcuttingassemblyarenotwornor
damaged.
•Inspecttheareawhereyouwillusethemachineand
removeallobjectsthatthemachinecouldthrow.
•Adjustingthecuttingheightmaybringyouintocontact
withthemovingblade,causingseriousinjury.
–Shutofftheengine,removetheelectric-startbutton,
andwaitforallmovingpartstostop.
–Donotputyourngersunderthehousingwhen
adjustingthecuttingheight.
FuelSafety
DANGER
Fuelisextremelyammableandhighlyexplosive.
Areorexplosionfromfuelcanburnyouand
othersandcandamageproperty.
•Topreventastaticchargefromignitingthefuel,
placethecontainerand/ormachinedirectlyon
thegroundbeforelling,notinavehicleoron
anobject.
•Fillthefueltankoutdoors,inanopenarea,when
theengineiscold.Wipeupanyfuelthatspills.
•Donothandlefuelwhensmokingoraroundan
openameorsparks.
•Storefuelinanapprovedcontainerandkeepit
outofthereachofchildren.
WARNING
Fuelisharmfulorfatalifswallowed.Long-term
exposuretovaporscancauseseriousinjuryand
illness.
•Avoidprolongedbreathingofvapors.
•Keepyourhandsandfaceawayfromthenozzle
andthefuel-tankopening.
•Keepfuelawayfromyoureyesandskin.
9

FillingtheFuelTank
•Forbestresults,useonlyclean,fresh,unleadedgasoline
withanoctaneratingof87orhigher((R+M)/2rating
method).
•Oxygenatedfuelwithupto10%ethanolor15%MTBE
byvolumeisacceptable.
•Donotuseethanolblendsofgasoline,suchasE15
orE85,withmorethan10%ethanolbyvolume.
Performanceproblemsand/orenginedamagemayresult,
whichmaynotbecoveredunderwarranty.
•Donotusegasolinecontainingmethanol.
•Donotstorefueleitherinthefueltankorinfuel
containersoverthewinterunlessfuelstabilizerhasbeen
addedtothefuel.
•Donotaddoiltogasoline.
Important:Toreducestartingproblems,addfuel
stabilizertothefuelallseason,mixingitwithgasoline
lessthan30daysold.
Fillthefueltankwithfreshunleadedregulargasolinefroma
majorname-brandservicestation(Figure11).
G027604
1 cm (1/2 inch)
Figure11
CheckingtheEngine-OilLevel
ServiceInterval:Beforeeachuseordaily
Max.ll:0.59L(20oz),type:SAE30orSAE10W-30
detergentoilwithanAPIserviceclassicationofSF,SG,SH,
SJ,SL,orhigher.
1.Movethemachinetoalevelsurface.
2.Removethedipstick(Figure12).
G017459
Figure12
1.Theoillevelisatits
maximum.
3.Theoillevelistoo
low—addoiltothe
crankcase.
2.Theoillevelistoo
high—removeoilfrom
thecrankcase.
3.Wipeoffthedipstickendwithacleancloth.
4.Insertthedipstickintotheoil-lltube,butdonot
screwitin.
5.Removethedipstickandreadtheoillevel;referto
Figure12.
•Iftheoillevelistoolow,addasmallamountof
oilslowlytotheoil-lltube,andthenrepeatsteps
3through5untiltheoillevelonthedipstickis
correct.
•Iftheoillevelistoohigh,draintheexcessoiluntil
theoillevelonthedipstickiscorrect.Todrainthe
excessoil,refertoChangingtheEngineOil(page
20).
Important:Iftheoillevelinthecrankcaseis
toolowortoohighandyouruntheengine,
youmaydamagetheengine.
6.Installthedipsticksecurely.
AdjustingtheHandleHeight
Youmayraiseorlowerthehandletoapositioncomfortable
foryou.
Rotatethehandlelock,movethehandleto1of3positions,
andlockthehandleintoposition(Figure13).
10

Figure13
1.Handlelock2.Handlepositions
AdjustingtheCuttingHeight
WARNING
Adjustingthecuttingheightmaybringyouinto
contactwiththemovingblade,causingserious
injury.
•Stoptheengineandwaitforallmovingparts
tostop.
•Donotputyourngersunderthehousingwhen
adjustingthecuttingheight.
CAUTION
Iftheenginehasbeenrunning,themuferwillbe
hotandcanseverelyburnyou.Keepawayfromthe
hotmufer.
Adjustthecuttingheightasdesired.Setall4wheelstothe
sameheight.
Note:Toraisethemachine,moveall4cuttingheightlevers
forward;tolowerthemachine,movethemallrearward
(Figure14).
G027605
A = 3 cm (1-1/4 inches)
B = 4 cm (1-3/4 inches)
C = 6 cm (2-1/4 inches)
D = 7 cm (2-3/4 inches)
E = 8 cm (3-1/4 inches)
F = 1 1 cm (4-1/4 inches)
G = 1 1 cm (4-1/4 inches)
Figure14
DuringOperation
GeneralSafety
•Wearappropriateclothing,includingeyeprotection;
slip-resistant,substantialfootwear;andhearing
protection.Tiebacklonghair,securelooseclothing,and
donotwearjewelry.
•Donotoperatethemachinewhileill,tired,orunderthe
inuenceofalcoholordrugs.
•Thebladeissharp;contactingthebladecanresultin
seriouspersonalinjury.Shutofftheengine,removethe
electric-startbutton,andwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
•Whenyoureleasetheblade-controlbar,theengineshould
shutoffandthebladeshouldstopwithin3seconds.If
not,stopusingyourmachineimmediatelyandcontactan
AuthorizedServiceDealer.
•Operatethemachineonlyingoodvisibilityand
appropriateweatherconditions.Donotoperatethe
machinewhenthereistheriskoflighting.
•Wetgrassorleavescancauseseriousinjuryifyouslipand
contacttheblade.Mowonlyindryconditions.
•Useextremecarewhenapproachingblindcorners,
shrubs,trees,orotherobjectsthatmayblockyourview .
•Watchforholes,ruts,bumps,rocks,orotherhidden
objects.Uneventerraincouldcauseaslip-and-fall
accident.
•Stopthemachineandinspectthebladesafterstrikingan
objectorifthereisanabnormalvibrationinthemachine.
Makeallnecessaryrepairsbeforeresumingoperation.
•Beforeleavingtheoperatingposition,shutofftheengine,
removetheelectric-startbutton,andwaitforallmoving
partstostop.
•Iftheenginehasbeenrunningthemuferwillbehotand
canseverelyburnyou.Keepawayfromthehotmufer.
•Checkthegrasscatchercomponentsandthedischarge
guardfrequentlyandreplacethemwiththemanufacturer’s
recommendedpartswhennecessary.
•UseaccessoriesandattachmentsapprovedbyTheToro
Companyonly.
11

SlopeSafety
•Mowacrossthefaceofslopes;neverupanddown.Use
extremecautionwhenchangingdirectiononslopes.
•Donotmowonexcessivelysteepslopes.Poorfooting
couldcauseaslip-and-fallaccident.
•Donotmowneardrop-offs,ditches,orembankments.
Youcouldloseyourfootingorbalance.
StartingtheEngine
1.Pulltheblade-controlbartothehandle(Figure15).
Figure15
2.Pushtheelectric-startbutton(electricstartmodelonly)
(Figure16)orpulltherecoil-starthandle(Figure17).
Note:Iftheelectric-startbuttonhasbeenremoved,
insertitintheelectricstarter;refertoFigure16
(electric-startmodelonly).
G020174
1
2
3
Figure16
Electric-startmodelonly
1.Electric-starter3.Electric-startbutton
(installed)
2.Electric-startbutton
Figure17
Note:Ifthemachinedoesnotstart,contactan
AuthorizedServiceDealer.
UsingtheSelf-PropelDrive
Tooperatetheself-propeldrive,simplywalkwithyourhands
ontheupperhandleandyourelbowsatyoursides,andthe
machinewillautomaticallykeeppacewithyou(Figure18).
Figure18
StoppingtheEngine
Releasetheblade-controlbar(Figure19).
Note:Removetheelectric-startbuttonwheneveryouleave
themachine(electric-startmodelonly).
Important:Whenyoureleasetheblade-controlbar,
thebladeshouldstopwithin3seconds.Ifitdoesnot
stopproperly,stopusingyourmachineimmediatelyand
contactanAuthorizedServiceDealer.
Figure19
12

RecyclingtheClippings
Yourmachinecomesfromthefactoryreadytorecyclethe
grassandleafclippingsbackintothelawn.
Ifthegrassbagisonthemachine,removeit;referto
RemovingtheGrassBag(page14)beforerecyclingthe
clippings.Iftheside-dischargechuteisonthemachine,
removeitandlocktheside-dischargedoor;refertoRemoving
theSide-DischargeChute(page16)beforerecyclingthe
clippings.
Important:Ensurethattherear-dischargeplugis
lockedinplace.Tolocktheplug:Raisethedischarge
deector(Figure20),rmlypushthepluginuntilit
snapsintoplacebehindthetabs,androtatetheleveron
theplugtotheleft(Figure21).
G017463
Figure20
1.Dischargedeector2.Rear-dischargeplug
Figure21
1.Lever2.Tabs
Note:Tounlocktheplug,rotatetheleverontheplugtothe
right(Figure21).
BaggingtheClippings
Usethegrassbagwhenyouwanttocollectgrassandleaf
clippingsfromthelawn.
Note:Ensurethebagisseatedinthecorrectposition.
Iftheside-dischargechuteisonthemachine,removeit
andlocktheside-dischargedoor;refertoRemovingthe
Side-DischargeChute(page16)beforebaggingtheclippings.
InstallingtheGrassBag
1.Routethestarterropearoundthelower-ropeguide
(Figure22).
13

G017473
Figure22
1.Lower-ropeguide
Note:Thelower-ropeguidereleasesthestarterrope
whenyoupulltherecoil-starthandle.
2.Raiseandholdupthedischargedeector(Figure23).
G017464
Figure23
1.Dischargedeector2.Rear-dischargeplug
3.Pullouttherear-dischargeplug(Figure23).
4.Hangtheupperfrontedgeofthebagonthenotches
(Figure24).
G017474
Figure24
1.Dischargedeector2.Grassbag
Note:Ensurethatthegrassbagissecurelyinstalled
ontothemachine.
5.Lowerthedischargedeector.
RemovingtheGrassBag
1.Routethestarterropearoundthelower-ropeguide
(Figure25).
G017473
Figure25
1.Lower-ropeguide
Note:Thelower-ropeguidereleasesthestarterrope
whenyoupulltherecoil-starthandle.
2.Raiseandholdupthedischargedeector.
3.Removethegrassbag.
4.Installtherear-dischargeplug(Figure26).
G017463
Figure26
1.Dischargedeector2.Rear-dischargeplug
Important:Ensurethattherear-dischargeplugis
lockedinplace.Tolocktheplug,rmlypushthe
pluginuntilitsnapsintoplacebehindthetabs,
androtatetheleverontheplugtotheleft(Figure
27).
14

Figure27
1.Lever2.Tabs
Note:Tounlocktheplug,rotatetheleverontheplug
totheright(Figure27).
5.Lowerthedischargedeector.
Side-Dischargingthe
Clippings
Usetheside-dischargefeatureforcuttingverytallgrass.
Ifthebagisonthemachine,removeitandinsertthe
rear-dischargeplug;refertoRemovingtheGrassBag(page
14)beforeside-dischargingtheclippings.
Important:Ensurethattherear-dischargeplugis
lockedinplace.Tolocktheplug:Raisethedischarge
deector(Figure28),rmlypushthepluginuntilit
snapsintoplacebehindthetabs,androtatetheleveron
theplugtotheleft(Figure28).
G017463
Figure28
1.Dischargedeector2.Rear-dischargeplug
Note:Tounlocktheplug,rotatetheleverontheplugtothe
right(Figure27).
InstallingtheSide-DischargeChute
1.Unlocktheside-dischargedoor(Figure29).
Figure29
2.Liftopentheside-dischargedoor(Figure30).
Figure30
3.Installtheside-dischargechuteandclosethedooronto
thechute(Figure31).
Figure31
15

RemovingtheSide-DischargeChute
Toremovetheside-dischargechute,reversethestepsabove.
Important:Locktheside-dischargedoorafteryouclose
it(Figure32).
Figure32
OperatingTips
GeneralMowingTips
•Cleartheareaofsticks,stones,wire,branches,andother
debristhatthebladecouldhit.
•Avoidstrikingsolidobjectswiththeblade.Never
deliberatelymowoveranyobject.
•Ifthemachinestrikesanobjectorstartstovibrate,
immediatelystoptheengine,disconnectthewirefromthe
sparkplug,removetheelectric-startbutton,andexamine
themachinefordamage.
•Forbestperformance,installanewbladebeforethe
cuttingseasonbegins.
•ReplacethebladewhennecessarywithaToro
replacementblade.
CuttingGrass
•Cutonlyaboutathirdofthegrassbladeatatime.Donot
cutbelowthe54mm(2-1/8inch)settingunlessthegrass
issparseoritislatefallwhengrassgrowthbeginstoslow
down.RefertoAdjustingtheCuttingHeight(page11).
•Whencuttinggrassover15cm(6inches)tall,mowatthe
highestcuttingheightsettingandwalkslower;thenmow
againatalowersettingforthebestlawnappearance.If
thegrassistoolong,themachinemayplugandcause
theenginetostall.
•Mowonlydrygrassorleaves.Wetgrassandleavestend
toclumpontheyardandcancausethemachinetoplug
ortheenginetostall.
•Beawareofapotentialrehazardinverydryconditions,
followalllocalrewarnings,andkeepthemachinefree
ofdrygrassandleafdebris.
•Alternatethemowingdirection.Thishelpsdispersethe
clippingsoverthelawnforevenfertilization.
•Ifthenishedlawnappearanceisunsatisfactory,try1
ormoreofthefollowing:
–Replacethebladeorhaveitsharpened.
–Walkataslowerpacewhilemowing.
–Raisethecuttingheightonyourmachine.
–Cutthegrassmorefrequently.
–Overlapcuttingswathsinsteadofcuttingafullswath
witheachpass.
–Setthecuttingheightonthefrontwheelsanotch
lowerthantherearwheels.Forexample,setthefront
wheelsat54mm(2-1/8inches)andtherearwheels
at64mm(2-1/2inches).
CuttingLeaves
•Aftercuttingthelawn,ensurethathalfofthelawnshows
throughthecutleafcover.Youmayneedtomakemore
thanasinglepassovertheleaves.
•Iftherearemorethan13cm(5inches)ofleavesonthe
lawn,setthefrontcuttingheight1or2notcheshigher
thantherearcuttingheight.
•Slowdownyourmowingspeedifthemachinedoesnot
cuttheleavesnelyenough.
AfterOperation
AfterOperatingSafety
GeneralSafety
•Cleangrassanddebrisfromthemachinetohelpprevent
res.Cleanupoilorfuelspills.
•Allowtheenginetocoolbeforestoringthemachinein
anyenclosure.
•Neverstorethemachineorfuelcontainerwherethereis
anopename,spark,orpilotlight,suchasonawater
heateroronotherappliances.
HaulingSafety
•Removetheelectric-startbuttonbeforeloadingtheunit
forhauling.
•Usecarewhenloadingorunloadingthemachineintoa
trailerortruck.
•Usefull-widthrampsforloadingthemachineintoa
trailerortruck.Donotexceeda15°anglebetweenthe
rampandthetrailerortruck.
•Tiethemachinedownsecurelyusingstraps,chains,cable,
orropes.Bothfrontandrearstrapsshouldbedirected
downandoutwardfromthemachine.
CleaningtheMachine
ServiceInterval:Beforeeachuseordaily
16

WARNING
Themachinemaydislodgematerialfromunderthe
machine.
•Weareyeprotection.
•Stayintheoperatingposition(behindthe
handle)whentheengineisrunning.
•Donotallowbystandersinthearea.
Forbestresults,cleanthemachinesoonafteryouhave
completedmowing.
1.Movethemachineontoaatpavedsurface.
2.Stoptheengineandwaitforallmovingpartstostop
beforeleavingtheoperatingposition.
3.Lowerthemachinetoitslowestcutting-heightsetting.
RefertoAdjustingtheCuttingHeight(page11).
4.Attachagardenhosethatisconnectedtoawater
supplytothewashoutportonthemachine(Figure33).
G017477
1
Figure33
1.Washoutport
5.Turnthewateron.
6.Starttheengineandrunituntiltherearenomore
clippingsthatcomeoutfromunderthemachine.
7.Stoptheengine.
8.Shutoffthewateranddisconnectthegardenhose
fromthemachine.
9.Starttheengineandrunitforafewminutestodrythe
undersideofthemachine.
FoldingtheHandle
WARNING
Foldingorunfoldingthehandleimproperlycan
damagethecables,causinganunsafeoperating
condition.
•Donotdamagethecableswhenfoldingor
unfoldingthehandle.
•Ifacableisdamaged,contactanAuthorized
ServiceDealer.
1.Removetheelectric-startbutton(Figure34).
Figure34
1.Electricstarter2.Electric-startbutton
2.Rotatethehandleforward(Figure35).
Important:Routethecablestotheoutsideofthe
handleknobsasyoufoldtheupperhandle.
17

Maintenance
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Aftertherst5hours•Changetheengineoil.
Beforeeachuseordaily
•Checktheengineoillevel.
•Cleangrassclippingsanddirtfromunderthemachine.
•Ensurethattheenginestopswithin3secondsafterreleasingtheblade-controlbar.
Every25hours
•Chargethebattery.
•Lubricatetherearwheelgears.
•Replacethebladeorhaveitsharpened(morefrequentlyiftheedgedullsquickly).
Beforestorage•Chargethebattery.
•Emptythefueltankbeforerepairsasdirectedandbeforeannualstorage.
Yearly•Replacetheairlter;replaceitmorefrequentlyindustyoperatingconditions.
•Changetheengineoil.
MaintenanceSafety
•Disconnectthespark-plugwirefromthesparkplugand
removetheelectric-startbuttonbeforeperformingany
maintenanceprocedure.
•Wearglovesandeyeprotectionwhenservicingthe
machine.
•Thebladeissharp;contactingthebladecanresultin
seriouspersonalinjury.Weargloveswhenservicingthe
blade.
•Nevertamperwithsafetydevices.Checktheirproper
operationregularly.
•Tippingthemachinemaycausethefueltoleak.Fuelis
ammableandexplosive,andcancausepersonalinjury.
Runtheenginedrytoremovethefuelwithahandpump;
neversiphonthefuel.
PreparingforMaintenance
1.Stoptheengine,removetheelectric-startbutton,and
waitforallmovingpartstostop.
2.Disconnectthespark-plugwirefromthesparkplug
(Figure36)beforeperforminganymaintenance
procedure.
G017466
1
Figure36
1.Spark-plugwire
Important:Beforetippingthemachinetochange
theoilorreplacetheblade,allowthefueltankto
rundrythroughnormalusage.Ifyoumusttip
themachinepriortorunningoutoffuel,usea
handfuelpumptoremovethefuel.Alwaystipthe
machineontoitssidewiththeairlterup.
3.Afterperformingthemaintenanceprocedure(s),
connectthespark-plugwiretothesparkplug.
19

ReplacingtheAirCleaner
ServiceInterval:Yearly
1.Pressdownonthelatchtabsontopoftheair-cleaner
cover(Figure37).
Figure37
1.Latchtabs3.Foampre-lter
2.Paperairlter
2.Openthecover.
3.Removethepaperairlterandthefoampre-lter
(Figure37).
4.Inspectthefoampre-lter,andreplaceitifitis
damagedorexcessivelydirty.
5.Inspectthepaperairlter.
A.Ifthepaperairlterisdamagedoriswetwithoil
orfuel,replaceit.
B.Ifthepaperairlterisdirty,tapitonahard
surfaceseveraltimesorblowcompressedairless
than207kPa(30psi)throughthesideofthelter
thatfacestheengine.
Note:Donotbrushthedirtoffthelter;
brushingforcesdirtintothebers.
6.Removedirtfromtheaircleanerbodyandcoverusing
amoistrag(totrapthedirtandkeepitfromfallinginto
theengine).Donotwipedirtintotheairduct.
7.Insertthefoampre-lterandthepaperairlterinto
theaircleaner.
8.Installthecover.
ChangingtheEngineOil
ServiceInterval:Aftertherst5hours
Yearly
Runtheengineafewminutesbeforechangingtheoiltowarm
it.Warmoilowsbetterandcarriesmorecontaminants.
1.Performthepre-maintenanceprocedures;referto
PreparingforMaintenance(page19).
2.Removethedipstick.
3.Tipthemachineontoitsside,withthedipstickdown,
todraintheusedoiloutthroughtheoil-lltube(Figure
38).
G017475
Figure38
4.Afterdrainingtheusedoil,returnthemachinetothe
normaloperatingposition.
5.Removethedipstickandpourabout3/4ofthe
crankcasecapacityofoilintotheoil-lltube.
Note:Max.ll:0.59L(20oz),type:SAE30orSAE
10W-30detergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.
6.Wipeoffthedipstickendwithacleancloth.
7.Insertthedipstickintotheoil-lltube,butdonot
screwitin.
8.Removethedipstickandreadtheoillevelonthe
dipstick(Figure39).
20
Other manuals for Super Recycler 20381
3
This manual suits for next models
1
Table of contents
Other Toro Lawn Mower manuals

Toro
Toro Z580 DFI Z Master User manual

Toro
Toro 74926 Z Master G3 User manual

Toro
Toro Proline 30187 User manual

Toro
Toro 26634 User manual

Toro
Toro TimeCutter MX 4275T User manual

Toro
Toro 22293 User manual

Toro
Toro Recycler 20961 User manual

Toro
Toro 20007 User manual

Toro
Toro 74251 User manual

Toro
Toro Recycler 20353 User manual
