Toro 38805 User manual

FormNo.3396-743RevA
PowerMaxHeavyDuty826OXESnowthrower
ModelNo.38805—SerialNo.316000001andUp
Operator'sManual
Introduction
Thismachineisintendedtobeusedbyresidential
homeownersorprofessional,hiredoperators.Itis
designedforremovingsnowfrompavedsurfaces,such
asdrivewaysandsidewalks,andothersurfacesfor
trafconresidentialorcommercialproperties.Itisnot
designedforremovingmaterialsotherthansnow.
Readthisinformationcarefullytolearnhowtooperateand
maintainyourmachineproperlyandtoavoidinjuryand
machinedamage.Youareresponsibleforoperatingthe
machineproperlyandsafely.
YoumaycontactTorodirectlyatwww.Toro.comformachine
andaccessoryinformation,helpndingadealer,ortoregister
yourmachine.
Wheneveryouneedservice,genuineToroparts,oradditional
information,contactanAuthorizedServiceDealerorToro
CustomerServiceandhavethemodelandserialnumbersof
yourmachineready.Figure1identiesthelocationofthe
modelandserialnumbersonthemachine.Writethenumbers
inthespaceprovided.
STOP
G016493
1
Figure1
1.Modelandserialnumberlocation
ModelNo.
SerialNo.
Thismanualidentiespotentialhazardsandhassafety
messagesidentiedbythesafetyalertsymbol(Figure2),
whichsignalsahazardthatmaycauseseriousinjuryordeath
ifyoudonotfollowtherecommendedprecautions.
Figure2
1.Safetyalertsymbol
Thismanualuses2wordstohighlightinformation.
Importantcallsattentiontospecialmechanicalinformation
andNoteemphasizesgeneralinformationworthyofspecial
attention.
©2015—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA
AllRightsReserved*3396-743*A

ThissparkignitionsystemcomplieswithCanadianICES-002.
Contents
Introduction..................................................................1
Safety...........................................................................3
SafetyandInstructionalDecals.................................3
Setup............................................................................5
1InstallingtheUpperHandle....................................6
2InstallingtheWheelClutchCableEnds....................6
3InstallingtheTractionControlLinkage....................7
4InstallingtheChuteControlRod.............................8
5ConnectingtheWiretotheHeadlight......................9
6FillingtheEnginewithOil......................................9
7CheckingtheTirePressure....................................10
8CheckingtheSkidsandScraper..............................11
9CheckingtheTractionDriveOperation...................11
ProductOverview.........................................................12
Operation....................................................................12
BeforeOperation......................................................12
Safety....................................................................12
FillingtheFuelTank...............................................12
DuringOperation.....................................................13
Safety....................................................................13
FreewheelingorUsingtheSelf-propelDrive...............13
StartingtheEngine.................................................14
StoppingtheEngine...............................................16
OperatingtheTractionDrive...................................16
UsingtheWheelClutchLevers.................................16
OperatingtheSpeedSelector...................................17
OperatingtheAuger/ImpellerDrive.........................17
OperatingtheQuickStick®.....................................18
UncloggingtheDischargeChute..............................18
OperatingTips......................................................19
AfterOperation........................................................19
Safety....................................................................19
PreventingFreeze-up..............................................19
Maintenance.................................................................20
RecommendedMaintenanceSchedule(s)......................20
MaintenanceSafety.................................................20
PreparingforMaintenance.......................................20
CheckingtheEngineOilLevel.................................21
CheckingandAdjustingtheSkids.............................21
CheckingandAdjustingtheTractionCable................22
CheckingandAdjustingtheAuger/Impeller
Cable................................................................22
CheckingtheAugerGearboxOilLevel......................23
ChangingtheEngineOil.........................................24
LubricatingtheHexShaft........................................24
ReplacingtheSparkPlug.........................................25
AdjustingtheDischargeChuteLatch........................25
ReplacingtheDriveBelts.........................................26
ReplacingtheHeadlightBulb...................................26
Storage........................................................................27
PreparingtheMachineforStorage............................27
RemovingtheMachinefromStorage.........................27
Troubleshooting...........................................................28
2

Safety
ThismachinemeetsorexceedstheB71.3specications
oftheAmericanNationalStandardsInstituteineffect
atthetimeofproduction.
•Shutthemachineoffbeforeunclogging,servicing,or
fueling.
•Readandunderstandthecontentsofthemanualbefore
youstarttheengine.Makesureeveryoneusingthis
productknowshowtousetheproductandunderstands
thewarnings.
•Donotputhandsorfeetnearmovingcomponentson
themachine.
•Donotoperatemachinewithoutallguardsandother
safetyprotectivedevicesinplaceandworkingonthe
machine.
•Keepclearofanydischargeopening.Keepbystandersa
safedistancefromthemachine.
•Keepchildrenoutoftheoperatingareaandunderthe
watchfulcareofaresponsibleadultotherthanthe
operator.Neverallowchildrentooperatethemachine.
SafetyandInstructionalDecals
Important:Safetyandinstructiondecalsarelocatednearareasofpotentialdanger.Replacedamageddecals.
106-4525
Reorderpartno.112-6633
1.Fast3.Slow
2.Forwardspeeds4.Reversespeeds
107-3040
1.Cuttingdismemberment,impellerandcutting
dismemberment,augerhazards—keepbystandersasafe
distancefromthesnowthrower.
112-6625
Reorderpartno.112-6629
1.Cutting/dismembermenthazard,impeller—donotplace
yourhandinthechute;stoptheenginebeforeleavingthe
operator'sposition,usethetooltoclearthechute.
3

112-6627
1.Leftturncontrol3.Warning—readthe
Operator'sManual.
5.Cutting/dismemberment
hazard,impeller—keep
awayfrommovingparts;
removetheignitionkeyand
readtheinstructionsbefore
servicingorperforming
maintenance.
7.Auger/impeller
drive—squeezetheleverto
engage;releasethelever
todisengage.
2.Tractiondrive—squeeze
thelevertoengage;release
thelevertodisengage.
4.Cutting/dismemberment
hazard,impeller—do
notplaceyourhand
inthechute;stopthe
enginebeforeleavingthe
operator'sposition,usethe
tooltoclearthechute.
6.Thrownobject
hazard—keepbystanders
asafedistancefromthe
snowthrower.
8.Rightturncontrol
131–6487
1.Engine—stop3.Fast
2.Slow
x 3
12
34
5
120-9805
120-9805
1.Insertthekey.
2.Primetheengine3times.
3.Engagethechoke.
4.Pullthestartercord.
5.Oncetheengineisrunning,disengagethechoke.
4

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
Handlebolts4
Curvedwashers4
1Locknuts4
Installtheupperhandle.
2Nopartsrequired–Installthewheelclutchcableends
3Nopartsrequired–Installthetractioncontrollinkage.
Carriagebolts2
4Locknuts2Installthechutecontrolrod.
5Cabletie1Connectthewiretotheheadlight.
6Nopartsrequired–Filltheenginewithoil.
7Nopartsrequired–Checkthetirepressure.
8Nopartsrequired–Checktheskidsandscraper.
9Nopartsrequired–Checktheoperationofthetractiondrive.
5

1
InstallingtheUpperHandle
Partsneededforthisprocedure:
4Handlebolts
4Curvedwashers
4Locknuts
Procedure
Note:Donotremovetherubberbandonthecablesuntil
youhaveinstalledtheupperhandle.
1.Liftandrotatetheupperhandleandpositionitover
thelowerhandle(Figure3).
Important:Routethecablesattachedtothe
QuickStickinsidetheupperhandlelegsand
ensurethatthecablesandthewireforthe
headlightarenotpinchedbetweenthehandle
sections.
Figure3
1.Cables
2.Securetheupperhandlewith4handlebolts,4curved
washers,and4locknutsfromtheloosepartsbag
(Figure4).
Figure4
2
InstallingtheWheelClutch
CableEnds
NoPartsRequired
Procedure
1.Unwrapthecableendsfromthelowerhandle(Figure
5).
Figure5
2.Routeeithertheleftorrightcableendoverthelower
handleandinsertthecableendintotheholeinthe
correspondingwheelclutchlever(Figure6).
6

Figure6
1.Wheelclutchlever
3.Removethenutandwasherfromthehandle,attach
thecableclamponthecabletothehandle,installthe
washerandthenut,andhandtightenthenut(Figure7).
Figure7
1.Cableclamp(2)
Important:Ensurethatthecurvedsideofthe
cableclampisagainstthehandleandthatthe
cableisroutedbelowtheclampbolt.Thecable
mustbeinastraightlinefromthecableclamp
tothepointwhereitattachestothewheelclutch
lever.
4.Pullthecablejacketdowngentlyuntilthewheelclutch
leverisdownandtheslackisoutofthecable,then
tightenthecableclampnutsecurely(Figure8).
Figure8
5.Squeezetheleverfully,thencheckthegapbetween
thebottomofthehandleandthewheelclutchlever
end(Figure9).
Figure9
Note:Thegapshouldbeapproximatelythethickness
ofapencil(1/4inchor6mm).Ifitisgreater,loosen
thecableclampnut,slidethecablejacketupslightly,
tightenthecableclampnut,andcheckthegapagain.
6.Repeatsteps2through5fortheothercable.
3
InstallingtheTractionControl
Linkage
NoPartsRequired
Procedure
1.Removethehairpincotterandwasherfromthelower
endofthespeedcontrolrodandinsertthelowerend
oftherodintothelowerlinkarmsothatthebentend
ofthespeedcontrolrodfacesrearward(Figure10).
Figure10
2.Securethelowerendofthespeedcontrolrodwiththe
washerandhairpincotterthatyoupreviouslyremoved.
3.Removethehairpincotterandtheouterwasherfrom
thetrunnionontheupperendofthespeedcontrol
rod(Figure11).
7

Figure11
1.Speedselectorlever3.Innerwasher
2.Trunnion4.Outerwasher
Note:Tomakeinstallationeasier,leavetheatwasher
onthetrunnion(Figure11).
4.ShiftthespeedselectorleverintoPositionR2.
5.Rotatethelowerlinkarmfullyupward
(counterclockwise)(Figure12).
Figure12
6.Liftuponthespeedcontrolrodandinsertthetrunnion
intotheholeinthespeedselectorlever(Figure11).
Note:Ifthetrunniondoesnottintothehole
whenyouliftuponthespeedcontrolrod,rotatethe
trunnionupwardordownwardonthespeedcontrol
roduntilitts.
7.Securethetrunnionandupperendofthespeedcontrol
rodwiththeouterwasherandahairpincotteryou
previouslyremoved.
Note:Foreasierinstallation,lookdownthroughthe
openinginthespeedselector(Figure13).
Figure13
1.Speedselector
4
InstallingtheChuteControl
Rod
Partsneededforthisprocedure:
2Carriagebolts
2Locknuts
Procedure
1.UnwraptheQuickStickandrotateitsothatitis
uprightandinthecenter.
2.Holdthebluetriggercapdownandpulltheleverfully
rearward.
Note:Thedischargechuteanddeectorshouldface
forward.Iftheydonot,holdthebluetriggercap
down(butdonotmovetheQuickStick)androtatethe
dischargechuteuntiltheydo.
3.Aligntheattenedbackendofthelongchutecontrol
rodwiththeattenedfrontendoftheshortrod
thatextendsfromthecontrolpanelsothattheynest
together(Figure14).
8

g018656
Figure14
1.Shortrod2.Longchutecontrolrod
4.Insertthefrontendoftherodintotheopeningin
thebackofthechutegearcoveruntilitslidesintothe
chutegear(Figure15).
Figure15
5.Aligntheholesinthenestedendsoftherodsand
insert2carriagebolts(intheloosepartsbag)through
theshortrodfromtheleftsideofthemachine(from
theoperatingposition).
6.Insertthecableclipthatsupportsthedeectorcable
ontotheforwardcarriagebolt,andsecurethecarriage
boltswithlocknutsfromtheloosepartsbag(Figure
16).
g018657
Figure16
1.Cableclip2.Deectorcable
7.HoldthebluetriggercapdownandrotatetheQuick
Stickinacircletoensurethatthechuteanddeector
operatesmoothly.
5
ConnectingtheWiretothe
Headlight
Partsneededforthisprocedure:
1Cabletie
Procedure
1.Insertthewireconnectoronthelooseendofthewire
straightintothebackoftheheadlightuntilitissecurely
inplace(Figure17).
12
3
G016761
Figure17
1.Plasticcliponwire
connector
3.Cabletie
2.U-bolt
Note:Ensurethattheplasticcliponthewire
connectorisonthebottom(Figure17).
2.Secureacabletie(fromtheloosepartsbag)aroundthe
wireandthehandleabout2.5cm(1inch)belowthe
U-bolt(Figure17).
9

6
FillingtheEnginewithOil
NoPartsRequired
Procedure
Yourmachinecomeswithoilintheenginecrankcase.
Note:Beforestartingtheengine,checktheoilleveland
addoilifnecessary.
UseautomotivedetergentoilwithanAPIserviceclassication
ofSF,SG,SH,SJ,SL,orhigher.Refertoyourengineowner's
manual.
UseFigure18belowtoselectthebestoilviscosityforthe
outdoortemperaturerangeexpected:
Figure18
EngineOilCapacities
ModelEngineOilCapacity
388050.53to0.59L(18to20oz)
1.Removethedipstickandslowlypouroilintotheoil
lltubetoraisetheoilleveltotheFullmarkonthe
dipstick.Donotoverll(Figure19).Referto(page).
Figure19
2.Installthedipsticksecurely.
Note:Donotspilloilaroundtheoillltube;oilcould
leakontotractionpartsandcausethetractiontoslip.
7
CheckingtheTirePressure
NoPartsRequired
Procedure
Thetiresareoverinatedatthefactoryforshipping.Reduce
thepressureequallyinbothtirestobetween116and137
kPa(17and20psi).
10

8
CheckingtheSkidsand
Scraper
NoPartsRequired
Procedure
Referto(page).
9
CheckingtheTractionDrive
Operation
NoPartsRequired
Procedure
CAUTION
Ifthetractiondriveisnotproperlyadjusted,the
machinemaymoveinthedirectionoppositeof
whatyouintended,causinginjuryand/orproperty
damage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary.
Note:Tocheckthetractiondriveoperation,theself-propel
featuremustbeengagedbyensuringthewheelsarepinned
intheaxle.RefertoFreewheelingorUsingtheSelf-propel
Drive(page13).
1.Starttheengine;refertoStartingtheEngine(page14).
2.MovethespeedselectortoPositionR1;referto
OperatingtheSpeedSelector(page17).
3.Squeezethelefthand(traction)levertothehand-grip
(Figure20).
Figure20
Themachineshouldmoverearward.Ifthemachine
doesnotmoveormovesforward,completethe
following:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(Figure11).
C.Turnthetrunniondownward(clockwise)onthe
speedcontrolrod(Figure11).
D.Connectthetrunniontothespeedselectorlever
(Figure11).
4.Releasethetractionlever.
5.MovethespeedselectortothePositionF1;referto
OperatingtheSpeedSelector.
6.Squeezethelefthand(traction)levertothehand-grip
(Figure20).
Themachineshouldmoveforward.Ifthemachine
doesnotmoveormovesrearward,completethe
following:
A.Releasethetractionleverandstoptheengine.
B.Disconnectthetrunnionfromthespeedselector
lever(Figure11).
C.Turnthetrunnionupward(counterclockwise)on
thespeedcontrolrod(Figure11).
D.Connectthetrunniontothespeedselectorlever
(Figure11).
7.Ifyoumadeanyadjustments,repeatthisprocedure
untilnoadjustmentsarerequired.
Important:Ifthemachinemoveswhenthetraction
leverisinthereleasedposition,checkthetractioncable
(refertoCheckingandAdjustingtheTractionCable
(page22))ortakethemachinetoanAuthorizedService
Dealerforservice.
11

ProductOverview
Figure21
1.Hand-grip(2)9.Dischargechute
2.Auger/impellerlever10.Scraper
3.Speed-selectorlever11.Auger
4.QuickStick™
discharge-chutecontrol
12.Skid(2)
5.Tractionlever13.Electric-starterbutton
6.Fueltankcap14.Electric-starterplug
7.Oillltube/dipstick15.Snow-cleanouttool
8.Chutedeector
STOP
1
2
3
4
5
6
7
G016500
Figure22
1.Primer5.Throttle
2.Ignitionswitch6.Oil-drainplug
3.Choke7.Recoilstarter
4.Fuel-shutoffvalve
Figure23
1.Snowcleanouttool(attachedtothehandle)
Operation
Note:Determinetheleftandrightsidesofthemachine
fromthenormaloperatingposition.
BeforeOperation
Safety
•Useextensioncordsandreceptaclesasspeciedby
themanufacturerforallmachineswithelectricstarting
motors.
•Donotoperatethemachinewithoutwearingadequate
wintergarments.Avoidloosettingclothingthatcanget
caughtinmovingparts.Wearslipresistantfootwearthat
willimprovefootingonslipperysurfaces.
•Alwayswearsafetyglassesoreyeshieldsduringoperation
orwhileperforminganadjustmentorrepairtoprotect
eyesfromforeignobjectsthatmaybethrownfromthe
machine.
•Thoroughlyinspecttheareawherethemachineistobe
usedandremovealldoormats,sleds,boards,wires,and
otherforeignobjects.
•Ifashield,safetydevice,ordecalisdamaged,illegible,or
lost,repairorreplaceitbeforebeginningoperation.Also,
tightenanyloosefasteners.
FillingtheFuelTank
DANGER
Gasolineisextremelyammableandexplosive.A
reorexplosionfromgasolinecanburnyouand
others.
•Topreventastaticchargefromignitingthe
gasoline,placethecontainerand/ormachine
onthegroundbeforelling,notinavehicleor
onanobject.
•Fillthetankoutdoorswhentheengineiscold.
Wipeupspills.
•Donothandlegasolinewhensmokingoraround
anopenameorsparks.
•Storegasolineinanapprovedfuelcontainer,out
ofthereachofchildren.
12

•Forbestresults,useonlyclean,fresh,unleadedgasoline
withanoctaneratingof87orhigher((R+M)/2rating
method).
•Oxygenatedfuelwithupto10%ethanolor15%MTBE
byvolumeisacceptable.
•Donotuseethanolblendsofgasoline(suchasE15
orE85)withmorethan10%ethanolbyvolume.
Performanceproblemsand/orenginedamagemayresult
whichmaynotbecoveredunderwarranty.
•Donotusegasolinecontainingmethanol.
•Donotstorefueleitherinthefueltankorfuelcontainers
overthewinterunlessafuelstabilizerisused.
•Donotaddoiltogasoline.
Important:Toreducestartingproblems,addfuel
stabilizertothefuelallseason,mixingitwithgasoline
lessthan30daysold.
Do not add oil to the gasoline.
Figure24
1.3.8cm(1-1/2inch)
DuringOperation
Safety
•Rotatingaugerbladescaninjurengersorhands.
Staybehindthehandlesandawayfromthedischarge
openingwhileoperatingthemachine.Keepyourface,
hands,feet,andanyotherpartofyourbodyor
clothingawayfrommovingorrotatingparts.
•Neverdirectthedischargetowardpeopleorareaswhere
propertydamagecanoccur.
•Exercisecautiontoavoidslippingorfalling.Alwaysbe
sureofyourfooting,andkeeparmholdonthehandles.
Walk;neverrun.
•Exerciseextremecautionwhenoperatingonslopes.
•Neveroperatethemachinewithoutgoodvisibilityor
light.
•Lookbehindandusecarewhenbackingupwiththe
machine.
•Whennotactivelyclearingsnow,disengagepowertothe
rotorblades.
•Useextensioncordsandreceptaclesasspeciedby
themanufacturerforallmachineswithelectricstarting
motors.
•Donotattempttoclearsnowfromagravelorcrushed
rocksurface.Thisproductisintendedforuseonlyon
pavedsurfaces.
•Donotusethemachineonaroof.
•Neverattempttomakeanyadjustmentswhiletheengine
isrunning(exceptwhenspecicallyrecommendedby
manufacturer).
•Stayalertforhiddenhazardsortrafc.
•Afterstrikingaforeignobject,stoptheengine,remove
theignitionkey,thoroughlyinspectthemachineforany
damage,andrepairthedamagebeforerestartingand
operatingthemachine.
•Ifthemachineshouldstarttovibrateabnormally,stop
theengineandcheckimmediatelyforthecause.
•Donotruntheengineindoors,exceptwhenstarting
theengineandfortransportingthemachineinorout
ofthebuilding.Opentheoutsidedoors;exhaustfumes
aredangerous.
•Donotoverloadthemachinecapacitybyattemptingto
clearsnowattoofastarate.
•Nevertouchahotengineormufer.
•Thoroughlyinspecttheelectricalcordbeforeplugging
itintoapowersource.Ifthecordisdamaged,donot
useittostartthemachine.Replacethedamagedcord
immediately.Unplugthepowercordwheneveryouare
notstartingthemachine.
FreewheelingorUsingthe
Self-propelDrive
Youcanoperatethesnowthrowerwiththeself-propelfeature
engagedordisengaged(freewheeling).
Tofreewheel,inserttheaxlepinsthroughtheaxleholes,but
notthroughthewheelhubs(Figure25).
g019015
Figure25
13

Toself-propel,inserttheaxlepinsthroughtheholesinthe
wheelhubsandtheinneraxleholes(Figure26).
g019014
Figure26
StartingtheEngine
1.Checktheengineoillevel.RefertoCheckingthe
EngineOilLevel(page21).
2.Turnthefuelshutoffvalve1/4turncounterclockwise
toopenit(Figure27).
G016512
Figure27
3.Inserttheignitionkeyallthewayin(Figure28).
1
G016498
Figure28
1.Ignitionkey
4.Firmlypushintheprimerwithyourthumb3times,
holdingtheprimerinforasecondbeforereleasingit
eachtime(Figure29).
G016494
Figure29
14

5.MovethechoketotheCHOKEposition(Figure30).
G016501
Figure30
6.MovethethrottletotheFASTposition(Figure31).
STOP
G016504
Figure31
7.Startthemachinebypullingtherecoilstarteror
pressingtheelectric-starterbutton(Figure32).
g019055
Figure32
1.Electric-starterbutton3.Recoilstarter
2.Electricstarterplug-in
Note:Tousetheelectricstarter,connectapower
cordtotheelectricstarterplug-inrstandthentoa
poweroutlet.UseonlyaUL-listed,16-gaugeextension
cordrecommendedforoutdoorusethatisnotlonger
than15m(50feet).
WARNING
Theelectricalcordcanbecomedamaged,
causingashockorre.
Thoroughlyinspecttheelectricalcordbefore
usingthemachine.Ifthecordisdamaged,
donotoperatethemachine.Replaceorrepair
thedamagedcordimmediately.Contactan
AuthorizedServiceDealerforassistance.
Important:Topreventdamagingtheelectric
starter,runitinshortcycles(5secondson,
5secondsoff),nomorethan10times.Ifthe
enginestilldoesnotstart,takethemachinetoan
AuthorizedServiceDealerforservice.
8.Disconnectthepowercordfromthepoweroutletrst
andthenfromthemachine(electricstartonly).
9.Allowtheenginetowarmup;graduallymovethe
choketowardtheRUNposition.Waitfortheengineto
runsmoothlybeforeeachchokeadjustment.
CAUTION
Ifyouleavethemachinepluggedintoa
poweroutlet,someonecaninadvertentlystart
themachineandinjurepeopleordamage
property.
Unplugthepowercordwheneveryouarenot
startingthemachine.
15

StoppingtheEngine
1.MovethethrottletotheSLOWposition,andthento
theSTOPposition(Figure33)tokilltheengine.The
enginecanalsobestoppedbypullingtheignitionkey
outwardtothemiddleposition.
STOP
G016505
Figure33
2.Waitforallmovingpartstostopbeforeleavingthe
operatingposition.
3.Removetheignitionkeytopreventaccidentalstarting.
4.Closethefuelshutoffvalvebyrotatingitclockwise
(Figure34).
G016499
Figure34
5.Pulltherecoilstarter3or4times.Thishelpsprevent
therecoilstarterfromfreezingup.
OperatingtheTractionDrive
CAUTION
Ifthetractiondriveisnotproperlyadjusted,the
machinemaymoveinthedirectionoppositeof
whatyouintended,causinginjuryand/orproperty
damage.
Carefullycheckthetractiondriveandadjustit
properly,ifnecessary;referto9Checkingthe
TractionDriveOperation(page11)formore
information.
Important:Ifthemachinemoveswhenthetraction
leverisinthereleasedposition,checkthetractioncable
(refertoCheckingandAdjustingtheTractionCable
(page22))ortakethemachinetoanAuthorizedService
Dealerforservice.
Important:Tooperatethetractiondrive,youmust
operatethemachinewiththeself-propelfeature
engaged.RefertoFreewheelingorUsingtheSelf-propel
Drive(page13).
1.Toengagethetractiondrive,squeezetheleft(traction)
levertothehandgrip(Figure35).
Figure35
2.Tostopthetractiondrive,releasethetractionlever.
UsingtheWheelClutchLevers
Thewheelclutchleversallowyoutomomentarilydisengage
thedrivetooneorbothwheelswiththetractiondrivelever
stillengaged.Thisenablesyoutoturnandmaneuverthe
machineeasily.
Note:Holdingdownthetractionleveragainstthehandle
engagesthetractiondrivetobothwheels.
Toturnthemachinetotheright,liftupontherightwheel
clutchleverandsqueezeittowardthehandle(Figure36).
16

Figure36
Note:Thisdisengagesthedrivetotherightwheelwhile
theleftwheelcontinuesdriving,andthemachineturnsto
theright.
Note:Similarly,squeezingtheleftwheelclutchleverturns
themachinetotheleft.
Whenyoucompletetheturn,releasethewheelclutchlever,
andthedrivere-engagesbothwheels(Figure37).
Figure37
Momentarilysqueezingandreleasingtheleftorrightwheel
clutchleveralsoallowsforsteeringadjustmentstokeepthe
machinegoinginastraightline,especiallyindeepsnow .
Squeezingbothwheelclutchleverssimultaneouslydisengages
thedrivetobothwheels.Thisenablesyoutomanuallymove
themachinebackwardwithoutstoppingtoshiftitintoa
reversegear.Italsoallowsyoutomaneuverandtransportthe
machinemoreeasilywhentheengineisnotrunning.
OperatingtheSpeedSelector
Thespeedselectorhas6forwardand2reversegears.To
changespeeds,releasethetractionleverandshiftthespeed
selectorlevertothedesiredposition(Figure38).Thelever
locksinanotchateachspeedselection.
Figure38
OperatingtheAuger/Impeller
Drive
1.Toengagetheauger/impellerdrive,squeezetheright
hand(auger/impeller)levertothehandgrip(Figure
39).
Figure39
2.Tostoptheaugerandimpeller,releasetherighthand
lever.
Important:Whenyouengageboththe
auger/impellerleverandthetractionlever,the
tractionleverlockstheauger/impellerleverdown,
freeingyourrighthand.Toreleasebothlevers,
simplyreleasethelefthand(traction)lever.
3.Iftheaugerandimpellercontinuetorotatewhenyou
releasetheauger/impellerlever,donotoperatethe
machine.Checktheauger/impellercable;referto
(page))andadjustitifnecessary.Otherwise,takethe
machinetoanAuthorizedDealerforservice.
WARNING
Iftheaugerandimpellercontinuetorotate
whenyoureleasetheauger/impellerlever,you
couldseriouslyinjureyourselforothers.
Donotoperatethemachine.Takeittoan
AuthorizedServiceDealerforservice.
17

OperatingtheQuickStick®
HoldthebluetriggercapdowntousetheQuickStickto
movethedischargechuteandthechutedeector.Releasethe
triggercaptolockthedischargechuteandchutedeector
intoposition(Figure40).
Figure40
MovingtheDischargeChute
HoldthebluetriggercapdownandmovetheQuickStick
tothelefttomovethedischargechutetotheleft;movethe
QuickSticktotherighttomovethedischargechutetothe
right(Figure41).
Figure41
•Ifthechutedoesnotmove,refertoAdjustingthe
DischargeChuteLatch(page25).
•Ifthechutedoesnotturnasfartotheleftasitdoestothe
right,ensurethatthecableisroutedtotheinsideofthe
handles.Referto1InstallingtheUpperHandle(page6).
•Ifthechutedoesnotlockintoplacewhenyourelease
thetriggercap,refertoAdjustingtheDischargeChute
Latch(page25).
MovingtheChuteDeector
HoldthebluetriggercapdownandmovetheQuickStick
forwardtolowerthechutedeector;moveitrearwardtoraise
thechutedeector(Figure42).
Figure42
UncloggingtheDischarge
Chute
WARNING
Iftheauger/impellerisrunningbutthereisno
snowcomingoutofthedischargechute,the
dischargechutemaybeclogged.
Neveruseyourhandstoclearacloggeddischarge
chute.Thiscouldresultinpersonalinjury.
•Tounclogthedischargechute,stayintheoperating
positionandreleasethelefthand(traction)lever.While
runningtheauger/impeller,pushdownonthehandlesto
raisethefrontofthemachineafewcentimeters(inches)
offthepavement.Thenliftthehandlesquicklytobump
thefrontofthemachineonthepavement.Repeatif
necessaryuntilastreamofsnowcomesoutthedischarge
chute.
•Ifyoucannotunclogthedischargechutebybumping
thefrontofthemachine,stoptheengine,waitforall
movingpartstostop,andusethesnowcleanouttool;
neveruseyourhand.
Important:Uncloggingthedischargechuteby
bumpingthefrontofthemachineonthepavement
maycausetheskidstomove.Adjusttheskidsand
tightentheskidboltssecurely.
18

OperatingTips
DANGER
Whenthemachineisinoperation,theimpellerand
augercanrotateandcutofforinjurehandsandfeet.
•Beforeadjusting,cleaning,inspecting,
troubleshooting,orrepairingthemachine,stop
theengineandwaitforallmovingpartstostop.
Disconnectthewirefromthesparkplugand
keepitawayfromtheplugtopreventsomeone
fromaccidentallystartingtheengine.
•Removeanobstructionfromthedischarge
chute;refertoUncloggingtheDischargeChute
(page18).Ifnecessary,usethesnowcleanout
tool,notyourhands,toremoveanobstruction
fromthedischargechute.
•Staybehindthehandlesandawayfromthe
dischargeopeningwhileoperatingthemachine.
•Keepface,hands,feet,andanyotherpartof
yourbodyorclothingawayfromconcealed,
moving,orrotatingparts.
WARNING
Theimpellercanthrowstones,toys,andother
foreignobjectsandcauseseriouspersonalinjuryto
theoperatorortobystanders.
•Keeptheareatobeclearedfreeofallobjects
thattheaugerscouldpickupandthrow.
•Keepallchildrenandpetsawayfromthearea
ofoperation.
•AlwayssetthethrottletotheFastpositionwhenthrowing
snow .
•Iftheengineslowsdownunderaloadorthewheelsslip,
shiftthemachineintoalowergear.
•Ifthefrontofthemachineridesup,shiftthemachine
intoalowergear.Ifthefrontcontinuestorideup,liftup
onthehandles.
AfterOperation
Safety
•Neverstorethemachinewithfuelinthefueltankinsidea
buildingwhereignitionsourcesarepresent,suchashot
waterheaters,spaceheaters,orclothesdryers.Allowthe
enginetocoolbeforestoringinanyenclosure.
•Whenstoringthemachineformorethan30days,referto
theStoragesectionforimportantdetails.
PreventingFreeze-up
•Insnowyandcoldconditions,somecontrolsandmoving
partsmayfreeze.Donotuseexcessiveforcewhen
tryingtooperatefrozencontrols.Ifyouhavedifculty
operatinganycontrolorpart,starttheengineandletit
runforafewminutes.
•Afterusingthemachine,lettheenginerunforafew
minutestopreventmovingpartsfromfreezing.Engage
theauger/impellertoclearanyremainingsnowfrom
insidethehousing.RotatetheQuickSticktopreventit
fromfreezing.Stoptheengine,waitforallmovingparts
tostop,andremovealliceandsnowfromthemachine.
•Withtheengineoff,pulltherecoilstarterhandleseveral
timesandpushtheelectric-starterbuttononcetoprevent
therecoilstarterandelectricstarterfromfreezingup.
19

Maintenance
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
RecommendedMaintenanceSchedule(s)
MaintenanceService
IntervalMaintenanceProcedure
Aftertherst2hours•Inspectthetractioncableandadjustitifnecessary.
•Inspecttheauger/impellercableandadjustitifnecessary.
Aftertherst5hours•Changetheengineoil.
Beforeeachuseordaily•Checktheengineoillevelandaddoilifnecessary.
Every25hours•Changetheengineoil.
Every100hours•Replacethesparkplug.
Yearly
•Checktheskidsandadjustthemifnecessary.
•Inspectthetractioncableandadjustorreplaceitifnecessary.
•Inspecttheauger/impellercableandadjustorreplaceitifnecessary.
•Checktheaugergearboxoilandaddoilifnecessary.
•Lubricatethehexshaft.
Yearlyorbeforestorage
•Checktheairpressureinthetiresandinatethemto17–20psi(116–137kPa).
•Runtheenginetodryoutthefueltankandthecarburetorattheendoftheseason.
•HaveanAuthorizedServiceDealerinspectandreplacethetractiondrivebeltand/or
theauger/impellerdrivebelt,ifnecessary.
Important:Youcanndmoreinformationaboutmaintainingandservicingyourmachineatwww.Toro.com.
MaintenanceSafety
Readthefollowingsafetyprecautionsbeforeperformingany
maintenanceonthemachine:
•Beforeperforminganymaintenance,service,or
adjustment,stoptheengineandremovethekey.Ifmajor
repairsareeverneeded,contactanAuthorizedService
Dealer.
•Checkallfastenersatfrequentintervalsforproper
tightnesstobesurethemachineisinsafeworking
condition.
•Maintainorreplacesafetyandinstructionlabels,as
necessary.
•Donotchangethegovernorsettingsontheengine.
•PurchaseonlygenuineTororeplacementpartsand
accessories.
PreparingforMaintenance
1.Movethemachinetoalevelsurface.
2.Stoptheengineandwaitforallmovingpartstostop.
3.Disconnectthesparkplugwire.RefertoReplacing
theSparkPlug.
20
