OWNER’S MANUAL
AIR CONDITIONER (SPLIT TYPE)
For general public use
Indoor unit
RAS-077, 107, 137, 167SKV-E7
Outdoor unit
RAS-077, 107, 137SAV-E6
RAS-167SAV-E5
1110255125
ENGLISHENGLISH

4
5
"
!
1
2
7
8
#
3
9
6
1Press : Move the louver in
the desired vertical direction.
2Press : Swing the air
automatically and press again to
stop.
3For horizontal direction, adjust
manually.
Note:
●Do not move the louver manually by others.
●The louver may automation positioning by some operation mode.
AUTOMATIC OPERATION
5
To automatically select cooling, heating, or fan only operation
1. Press : Select A.
2. Press : Set the desired temperature.
3. Press : Select AUTO, LOW , LOW+ , MED ,
MED+ , or HIGH .
COOLING / HEATING / FAN ONLY
OPERATION
6
1. Press : Select Cool , Heat , or Fan only .
2. Press : Set the desired temperature.
Cooling: Min. 17°C, Heating: Max. 30°C, Fan Only:
No temperature indication
3. Press : Select AUTO, LOW , LOW+ , MED ,
MED+ , or HIGH .
DRY OPERATION
7
For dehumidification, a moderate cooling performance is controlled
automatically.
1. Press : Select Dry .
2. Press : Set the desired temperature.
Hi-POWER OPERATION
8
To automatically control room temperature and airflow for faster cooling or
heating operation (except in DRY and FAN ONLY mode)
Press : Start and stop the operation.
1TIMER (Yellow)
2OPERATION (Green)
3RESET button
1Infrared signal emitter
2Start/Stop button
3Mode select button (MODE)
4Temperature button (TEMP)
5Fan speed button (FAN)
6Swing louver button (SWING)
7Set louver button (FIX)
8Off timer button (OFF)
9High power button (Hi-POWER)
!Economy button (ECO)
"Clear button (CLEAR)
#Check button (CHECK)
PRECAUTIONS FOR SAFETY
REMOTE CONTROL
4
INDOOR UNIT DISPLAY
1
PREPARATION BEFORE USE
2
AIRFLOW DIRECTION
3
Preparing Filters
1. Open the air inlet grille and remove the air filters.
2. Attach the filters. (see detail in the accessory sheet).
Loading Batteries (when use wireless operation.)
1. Remove the slide cover.
2. Insert 2 new batteries (AAA type) following the (+)
and (–) positions.
Remote Control Reset
1. Remove the batteries.
2. Press .
3. Insert the batteries.
DANGER
●Do not install, repair, open or remove the cover. It may
expose you to dangerous voltages. Ask the dealer or the
specialist to do this.
●Turning off the power supply will not prevent potential
electric shock.
●The appliance shall be installed in accordance with
national wiring regulation.
●Means for disconnection from the supply having a
contact separation of at least 3 mm in all poles must be
incorporated in the fixed wiring.
WARNING
●Do not expose your body directly to cool air for a long
time.
●Do not insert your finger or any article into the air inlet/
outlet.
●When an abnormality (burning smell, etc.) occurs, stop
the air conditioner and disconnect the power supply or
turn off the breaker.
●This appliance is not intended for use by persons
(including children) with reduced physical, sensory or
mental capabilities, or lack of experience and knowledge,
unless they have been given supervision or instruction
concerning use of the appliance by a person responsible
for their safety.
●Children should be supervised to ensure that they do not
play with the appliance.
●Do not use any refrigerant different from the one specified
for complement or replacement. Otherwise, abnormally
high pressure may be generated in the refrigeration
cycle, which may result in a failure or explosion of the
product or an injury to your body.
CAUTION
●Do not wash the unit with water. It may cause an electric
shock.
●Do not use this air conditioner for other purposes such as
preserving food, breeding animal, etc.
●Do not step or put anything on the indoor/outdoor unit. It
may cause an injury or damage the unit.
●Do not touch aluminium fin because it may cause an
injury.
●Before cleaning the unit, turn off the main switch or the
circuit breaker.
●When the unit won’t be used for a long time, turn off the
main switch or the circuit breaker.
●It is recommended that maintenance be performed by
a specialist when the unit has been operated for a long
time.
●The manufacturer shall not assume any liability for the
damage caused by not observing the description of this
manual.

21
ECO OPERATION
9
To automatically control room to save energy (except in DRY and FAN ONLY
mode)
Press : Start and stop the operation.
Note: Cooling operation; the set temperature will increase automatically 1
degree/hour for 2 hours (maximum 2 degrees increase). For heating
operation the set temperature will decrease.
TEMPORARY OPERATION
10
In case of the misplaced or discharged remote control
●Pressing the RESET button, the unit can start
or stop without using the remote control.
●Operation mode is set on AUTOMATIC
operation, preset temperature is 24°C and fan
operation is automatic speed.
Set the timer when the air conditioner is operating.
Setting the OFF timer
1Press for enter OFF timer setting.
2Press for select desired OFF timer. (0.5 - 12 hrs)
3Press for set OFF timer.
4Press again for cancel OFF timer.
TIMER OPERATION
11
AUTO RESTART OPERATION
12
To automatically restart the air conditioner after the power failure (Power of
the unit must be on.)
Setting
1. Press and hold the RESET button on the indoor unit for 3 seconds to
set the operation. (3 beep sound and OPERATION lamp blink 5 time/
sec for 5 seconds)
2. Press and hold the RESET button on the indoor unit for 3 seconds to
cancel the operation. (3 beep sound but OPERATION lamp does not
blink)
• In case of ON timer or OFF timer are set, AUTO RESTART
OPERATION does not activate.
SELF CLEANING OPERATION
(COOL AND DRY OPERATION ONLY)
14
OPERATION AND PERFORMANCE
15
1. Three-minute protection feature: To prevent the unit from being
activated for 3 minutes when suddenly restarted or switched to ON.
2. Preheating operation: Warm up the unit for 5 minutes before the
heating operation starts.
3. Warm air control: When the room temperature reaches the set
temperature, the fan speed is automatically reduced and the outdoor
unit will stop.
4. Automatic defrosting: Fans will stop during defrost operation.
5. Heating capacity: Heat is absorbed from outdoors and released into
the room. When the outdoor temperature is too low, use another
recommended heating apparatus in combination with the air
conditioner.
6. Consideration for accumulated snow: Select the position for outdoor
unit where it will not be subjected to snow drifts, accumulation of
leaves or other seasonal debris.
7. Some minor cracking sound may occur when unit operating. This is
normal because the cracking sound may be caused by expansion/
contraction of plastic.
Note: Item 2 to 6 for Heating model
Air conditioner operating conditions
Temp.
Operation
Outdoor Temperature Room Temperature
Heating –15°C ~ 24°C Less than 28°C
Cooling –10°C ~ 46°C 21°C ~ 32°C
Dry –10°C ~ 46°C 17°C ~ 32°C
The unit does not operate. Cooling or Heating is abnormally low.
●The power main switch is
turned off.
●The circuit breaker is
activated to cut off the power
supply.
●Stoppage of electric current
●ON timer is set.
●The filters are blocked with dust.
●The temperature has been set
improperly.
●The windows or doors are opened.
●The air inlet or outlet of the outdoor
unit is blocked.
●The fan speed is too low.
●The operation mode is FAN or DRY.
TROUBLESHOOTING (CHECK POINT)
16
REMOTE CONTROL A-B SELECTION
17
To separate using of remote control for each indoor unit in case of 2 air
conditioner are installed nearly.
Remote Control B Setup.
1. Press RESET button on the indoor unit to turn the air conditioner ON.
2. Point the remote control at the indoor unit.
3. Push and hold button on the Remote Control by the tip of the
pencil. “00” will be shown on the display. (Picture 1)
4. Press during pushing . “B” will show on the display
and “00” will disappear and the air conditioner will turn OFF. The
Remote Control B is memorized. (Picture 2)
Note: 1. Repeat above step to reset Remote Control to be A.
2. Remote Control A has not “A” display.
3. Default setting of Remote Control from factory is A.
Firstly, turn off the circuit breaker.
Indoor Unit and Remote Control
●Clean the indoor unit and the remote control with a wet cloth when
needed.
●No benzine, thinner, polishing powder or chemically-treated duster.
MAINTENANCE
13
To protect bad smell caused by the humidity in the indoor unit.
1. If the button is pressed once during “Cool” or “Dry” mode,
the fan will continue to run for other 30 minutes, then it will turn off
automatically. This will reduce the moisture in the indoor unit.
2. To stop the unit immediately, press the more 2 times
within 30 seconds.
ES
FR
IT
DE
PT
PL
CZ
CR
HU
NL
GR
FI
DK
RO
BG
EE
LV
SK
SI
LT
EN

Information according to EMC Directive 2004/108/EC
(Name of the manufacturer) TOSHIBA CARRIER (THAILAND) CO., LTD.
(Address, city, country) 144/9 MOO 5, BANGKADI INDUSTRIAL PARK, TIVANON ROAD,
TAMBOL BANGKADI, AMPHUR MUANG, PATHUMTHANI 12000, THAILAND.
(Name of the Importer/Distributor in EU) TOSHIBA CARRIER UK LTD.
(Address, city, country) Porsham Close, Belliver Industrial Estate, PLYMOUTH, Devon, PL6 7DB.
United Kingdom
1110255125
