Toshiba FT-8901A User manual

Preparation Basics Answering system Additional Information
Preparation Basics Answering system Additional Information
FT-8901A.qx 7/2/1 11:35 AM Page 1

Preparation
2
GETTING STARTED: DO THIS FIRST!
FIRST, After unpacking your new cordless phone:
CHARGE THE HANDSET BATTERY!
• Set your new phone in an out-of-the-way place near a
power outlet but where it will not be disturbed.
• Plug the AC adaptor into the wall power outlet.
• Plug the AC adaptor cord into the power jack on the base
unit. The “POWER” LED should light. If not, see
“TROUBLESHOOTING,” page 31.
• Take the cover off the handset battery compartment; plug
the battery connector into the receptacle inside the battery
compartment and replace the cover. The connector only
goes in one way.
• Place the handset into the base unit’s charging cradle. The
“CHARGE” LED should light.
• The battery charging period has now started. From now
until the 12 hour period is complete, do not let anything
cause the handset to be removed from electrical contact
with the base unit’s charging pins or power to be removed
from the base unit.
Now, set the dial mode to Tone or Pulse for your type of
service according to the instructions on Page 14 and your
telephone is ready for normal use. Information on the use of
other features follows page 15.
FT-8901A.qx 7/2/1 11:35 AM Page 2

INTRODUCTION
3
Toshiba America Consumer Products Inc. takes pride in presenting the
cordless telephone and digital answering system. An all digital
answering device provides many new conveniences not available on
tape machines, such as repeat, skip and individual message delete.
• 900MHz analog transmission with
extended talk range
• 40 channel auto scanning
• All digital recording system
(approx. 15 min. recording time)
• Advanced compandor noise
reduction
• Advanced message management
design
• Voice guidance/time stamp
• Long standby battery life (14 days)
• One way page/handset locator
• Last number redial (32 digits)
• 10 speed-dial memories, 16 digits
each
• Mute on handset
• Any-key answer
• Reversible charging system
• Hearing aid compatible/HAC volume
• Desk/Wall mountable
(bracket included)
• Custom greeting message /
pre-recorded greeting message
• Memo recording
• Volume control (3 level)
• Digital security code (65,536 codes)
FEATURES
TALK
BATTLOW
Preparation
FT-8901A.qx 7/2/1 11:35 AM Page 3

TABLE OF CONTENTS
4
Preparation
INTRODUCTION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .3
IMPORTANT SAFETY INSTRUCTIONS . . . . . . . . . . . . . . . . . . . . . . . .6
LOCATION OF CONTROLS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .8
Base unit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .9
INSTALLATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Setting up the base unit (Desk top mounting) . . . . . . . . . . . . . . . . .10
AC adaptor information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Setting up the base unit (Wall mounting) . . . . . . . . . . . . . . . . . . . . .11
Charging the battery pack . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
Setting the dial mode . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
Basics
BASIC OPERATION . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Making a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Receiving a call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
Redial . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Out of range . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Call waiting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Handset earpiece volume setting . . . . . . . . . . . . . . . . . . . . . . . . . .16
Handset ringer volume setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .16
Base speaker volume setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Mute . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Tone/Entering a pause . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Interference or static . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Paging the handset . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
MEMORY DIALING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Storing numbers . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Inserting a pause in memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Dialing a stored number . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
FT-8901A.qx 7/2/1 11:35 AM Page 4

5
TABLE OF CONTENTS
Answering system
USING THE MENU MODE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .20
Recording the greeting message . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Changing the greeting message . . . . . . . . . . . . . . . . . . . . . . . . . . .21
Setting the clock . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .22
Setting the security code (PIN) . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Setting the base ringer volume . . . . . . . . . . . . . . . . . . . . . . . . . . . .23
Setting the number of rings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
Setting the recording time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .24
USING THE ANSWERING MACHINE . . . . . . . . . . . . . . . . . . . . . . . . .25
Turning the answering machine ON & OFF . . . . . . . . . . . . . . . . . . .25
Checking and switching greeting message . . . . . . . . . . . . . . . . . . .25
Checking clock setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Playing recorded messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .26
Deleting recorded messages . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Screening incomming calls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .27
Leaving a memo message . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .28
Recording a phone conversation (2 WAY REC) . . . . . . . . . . . . . . . .28
Calling in from a remote location . . . . . . . . . . . . . . . . . . . . . . . . . . .29
Table of commands . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .30
Additional information
TROUBLESHOOTING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .31
WARRANTY/SERVICE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .34
REMOTE OPERATION CARDS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .37
FT-8901A.qx 7/2/1 11:35 AM Page 5

6
Preparation
IMPORTANT SAFETY INSTRUCTIONS
When using your telephone equipment,
basic safety precautions should always
be followed to reduce the risk of fire,
electric shock and injury.
1Read and understand all instructions.
2Follow all warnings and instructions
marked on the product.
3Unplug this product from the wall
outlet before cleaning. Do not use
liquid cleaners or aerosol cleaners.
Use a dry cloth for cleaning.
4Do not use this product near water
sources, such as bath tubs, wash
bowls, kitchen sinks, laundry tubs, wet
basements, or swimming pools.
5Do not place this product on an
unstable cart, stand, or table. The
telephone may fall, causing serious
damage to the telephone.
6Slots and openings in the cabinet and
the back or bottom are provided for
ventilation. To protect it from
overheating, these openings must not
be blocked or covered. The openings
should never be blocked by placing
the product on a bed, sofa, rug, or
other similar surface. This product
should never be placed near or over a
radiator or heat register. This product
should not be placed in a built-in
installation unless proper ventilation is
provided.
7Do not allow anything to rest on the
power cord. Do not locate this product
where the cord can be stepped on or
tripped over.
8Do not overload wall outlets and
extension cords as this can result in
the risk of fire or electric shock.
9Never push objects of any kind into
this product through cabinet slots as
they may touch dangerous voltage
points or short out parts that could
result in a risk of fire or electric shock.
Never spill liquid of any kind on the
product.
10 Do not disassemble this product.
Opening or removing covers puts you
at risk of electrical shock, and incorrect
reassembly can cause shocks, sparks
or other damage during subsequent
use.
11 Take this product to a qualified service
technician under any of the following
conditions:
A. When the power supply cord is
damaged or frayed.
B. If liquid has been spilled into the
product.
C. If the product has been exposed to
rain or water.
D. If the product does not operate
normally according to the operating
instructions. Adjust only those
controls covered by this manual.
Improper adjustment of other
controls may result in serious
damage to the unit or your home.
E. If the product has been dropped or
the cabinet has been damaged.
F. If the product exhibits a distinct
change in performance.
12 Do not use the telephone in the
vicinity of a gas leak.
FT-8901A.qx 7/2/1 11:35 AM Page 6

IMPORTANT SAFETY INSTRUCTIONS
7
Preparation
The RBRCTM Seal
The RBRCTM Seal on the (easily removable) nickel-cadmium battery
(contained in our product) indicates that Toshiba America Consumer
Products, Inc. (TACP) is voluntarily participating in an industry program
to collect and recycle these batteries at the end of their useful lives,
when taken out of service within the United States. The RBRCTM
program provides a convenient alternative to placing used nickel-
cadmium batteries into the trash or municipal waste, which is illegal in some areas.
TACP’s payments to RBRCTM make it easy for you to drop off the spent battery at
local retailers of replacement nickel-cadmium batteries, or at authorized TACP product
service centers. You may also contact your local recycling center for information on
where to return the spent battery. Please call 1-800-8-BATTER for information on Ni-
Cd battery recycling in your area. TACP’s involvement in this program is part of its
commitment to protecting our environment and conserving natural resources.
RBRCTM is a trademark of Rechargeable Battery Recycling Corporation.
CAUTION: TO REDUCE THE RISK OF FIRE OR INJURY TO PERSONS BY THE
BATTERY, READ AND FOLLOW THESE INSTRUCTIONS.
BATTERIES
1Use only the appropriate type and
size battery pack specified in the
instruction manual provided for this
product.
2Do not dispose of the battery pack in
a fire. The cell may explode. Check
with State and local codes for
possible special disposal instructions.
3Do not open or mutilate the battery
pack. Released electrolytes are
corrosive and may cause damage to
the eyes or skin. It may be toxic if
swallowed.
4Exercise care in handling the
batteries. Contact with conductive
materials such as rings, bracelets and
keys may cause the battery to short
out, resulting in overheating which
could burn.
5Charge the battery pack provided with
or identified for use with this product
only in accordance with the
instructions and limitations specified
in the instruction manual provided for
this product.
6Observe proper polarity orientation
between the battery pack and the
battery charger.
ATTENTION: THE PRODUCT THAT YOU HAVE PURCHASED CONTAINS A
RECHARGEABLE BATTERY. UNDER VARIOUS STATE AND LOCAL LAWS, IT MAY
BE ILLEGAL TO DISPOSE OF THIS BATTERY INTO THE MUNICIPAL WASTE
STREAM. PLEASE CHECK WITH YOUR LOCAL GOVERNMENT FOR DETAILS IN
YOUR AREA REGARDING RECYCLING OPTIONS OR PROPER DISPOSAL.
SAVE THESE INSTRUCTIONS
TO HELP PROTECT THE ENVIRONMENT, THIS PRODUCT MAY CONTAIN
RECYCLED OR RECONDITIONED PARTS AND MATERIALS.
FT-8901A.qx 7/2/1 11:35 AM Page 7

Preparation
8
HANDSET
LOCATION OF CONTROLS
SUPPLIED ACCESSORIES:
TONE
TALK
BATTLOW
TUV
8
WX
YZ
9
PQ
RS
7
OPER
0
#
JKL
GHI
5
6
4
ABC
DEF
MNO
2
3
1
TALK
MEM
VOL/RING
MUTE
CH
RDL/P
FLASH
button (page 15)
TALK
TONE MODE button
(page 14, 17)
TONE
(Memory) button
(page 18)
MEM
button (page 14, 16)
FLASH
TALK/BATT LOW LED
button (page 16)
VOL/RING
(Redial/Pause) button
(page 16, 17)
RDL/P
Antenna
Speed-Dial Index Card (back)
Write down numbers stored in
memory
Battery Compartment (page 12)
Charging Contacts (Channel) button (page 17)
CH
button (page 17)
MUTE
Modular Line Cord
Part # RC008231
Wall Mount Bracket
Part # RC009245
AC Adaptor
TAC-8930
Part # RC009255
PULSE MODE button (page 14)
#
FT-8901A.qx 7/2/1 11:35 AM Page 8

LOCATION OF CONTROLS
9
Preparation
BASE UNIT
Rechargeable Battery Pack
Toshiba TRB-8000
Part # RC004931
Quick Reference Guide
Part # RC012157
For purchase of accessories, please call 1-877-644-7373.
Speed Dial Index Card
Part # RC005157
1
3
5
7
9
2
4
6
8
0
SPEED DIAL INDEX
POWER
IN USE
CHARGE
PAGEREC
MEMO/2WAY
MENU
SET
SELECTSELECT
VOLUME
TIME
GREETING
MIC
REW
FF
button (page 26, 27)
DELETE
Speaker
button (page 25)
GREETING
button (page 26)
TIME
POWER LED
IN USE LED
CHARGE LED
buttons (page 26)
VOLUME
button (page 26)
PLAY/STOP
button (page 17)
PAGE
/button
(page 20 to 26)
SELECT
SKIP FF
button
(page 20 to 24)
SET
button (page 21, 28)
REC MEMO/2WAY
Microphone
button
(page 25), ANSWER
LED
ANSWER
/
button (page 20 to 26)
SELECT
REW REPEAT
button
(page 20 to 24)
MENU
Owner's manual
Part # RC012156
DC IN 9V jack (page 10)
TELEPHONE LINE modular jack (page 10)
Antenna
FT-8901A.qx 7/2/1 11:35 AM Page 9

10
INSTALLATION
SETTING UP THE BASE UNIT (DESK TOP MOUNTING)
For setting up the base unit follow the instructions below.
•Plug the AC adaptor firmly into the base unit and the AC 120V outlet.
•USE ONLY WITH Supplied AC ADAPTOR (TAC-8930 power source
AC 120V 60Hz/DC9V).
•The AC adaptor must remain connected at all times.
(It is normal for the adaptor to feel warm during use.)
AC ADAPTOR INFORMATION
Use only the supplied AC adaptor, or
one matching its specifications exactly
with this product. Incorrect voltage may
damage the unit or cause it to function
improperly.
Preparation
Raise the
antenna to a
vertical position.
Fasten the AC adaptor
cord to prevent it from
being disconnected.
Telephone Line Cord
Single-Line
Telephone Jack
(RJ11C)
Power Outlet
(AC 120V, 60Hz)
AC Adaptor
FT-8901A.qx 7/2/1 11:35 AM Page 10

Preparation
SETTING UP THE BASE UNIT (WALL MOUNTING)
MOUNTING ON A STANDARD WALL PLATE:
Insert the bracket’s tabs into the
notches on the base.
•Route the cords through the guides.
•Place the base unit on the posts of the wall plate and push down until it is
firmly seated.
•USE ONLY WITH Supplied AC ADAPTOR (TAC-8930 power source AC
120V, 60 Hz/DC 9V).
NOTES:
• Do not use any outlet controlled by a wall switch.
• If you don’t have a standard wall plate, cut out the template on this page and
use it to position two screws (minimum length of 13/8inches) into the wall
with the heads protruding about 1/4inch.
INSTALLATION
11
Raise the antenna.
Flip the switch hook tab
over so the tab holds the
handset.
Telephone
Line Cord Single-Line
Telephone Jack
(RJ11C)
Power Outlet
(AC 120V, 60Hz)
AC Adaptor
Wall mount template
IMPORTANT:
Before mounting, select a wall area of sufficient
strength. If mounting on wallboard or in an area
of questionable strength, locate a stud for
maximum support of your telephone.
Avoid electrical cables, pipes, or other items
behind the mounting location that could cause a
hazard.
CUT CUT
•
•
FT-8901A.qx 7/2/1 11:36 AM Page 11

Preparation
CHARGING THE BATTERY PACK
It is important to charge the battery for 12 to 16 hours
continuously without any interruption before you use the handset
for the first time. 1Remove the battery cover on the
back of the handset by sliding it
down.
2Plug the battery pack cord into the
connector with the correct polarity
(black and red wires).
3Place the battery pack in the battery
compartment.
4Put the battery cover back by
sliding until it snaps into place.
Make sure not to get the wires of
the battery pack caught in the
cover.
5Place the handset on the base unit.
Be sure the CHARGE LED lights.
If the CHARGE LED does not light,
make sure the AC adaptor is
plugged in securely.
NOTES:
•Use only the supplied battery pack (TRB-8000 power source 600mAh, 3.6VDC)
•The battery pack is not charged properly if the charging contacts are dirty or
tarnished. Clean the contacts occasionally with a dry cloth.
12
INSTALLATION
Red Black
TALK
BATT LOW
CHARGE
LED
Charging contacts
TALK/BATT LOW
LED
POWER
LED
FT-8901A.qx 7/2/1 11:36 AM Page 12

Preparation
13
INSTALLATION
After the battery pack is fully charged;
Operation Approx. battery life
While in use (Talk mode) up to 7 hours
While not in use (Standby mode) up to 14 days
When the TALK/BATT LOW LED blinks, all handset buttons are
disabled and the battery needs to be charged. If this occurs during a
call, you hear short beeps. Finish the call as soon as possible and
place the handset on the base unit.
NOTES:
•If a call comes in when the battery is too low to operate properly, you will be
unable to answer the call or the call will be disconnected.
•The redial number is held in memory for up to one minute while you replace
the battery pack.
•If you must replace the battery pack during a telephone call, complete the
replacement of the battery pack within 30 seconds, and you can return to the
original call.
FT-8901A.qx 7/2/1 11:36 AM Page 13

14
INSTALLATION
Preparation
SETTING THE DIAL MODE
Most phone systems use tone dialing. But, to use tone dialing, you must
have a tone service dialing system supplied by your telephone company.
Then you must set your telephone dial mode for the type of service you
have. If you are not sure which type of service you have, do the following
steps.
1With the phone in the Standby mode, press and hold until
you hear a confirmation tone.
2Press .
You hear a confirmation tone.
3Press and listen for a dial tone.
4Press any number other than 0.
If the dial tone sounds, you have tone service and your setting is
complete. If the dial tone continues, you have pulse service and
you must perform steps 5 and 6 below.
5With the phone in the Standby mode, press and hold until
you hear a confirmation tone.
6Press and hear a confirmation tone. Your setting is complete
for pulse service.
FLASH
TALK
TONE/
FLASH
FLASH
Before using the handset, make sure to read the following instructions.
TALK
(PULSE MODE)
(TONE MODE)
TONE/
FT-8901A.qx 7/2/1 11:36 AM Page 14

BASIC OPERATION
MAKING A CALL
CH
TALK
VOL/RING
FLASH
15
Basics
MUTE
Before using the handset, make sure to read the following instructions.
To hang up: Press , or return the handset to the base (Auto Standby).
TALK
Handset On The Base
1) Pick up the handset.
2) Press .
3) Listen for the dial tone.
4) Dial the number.
TALK
Handset Off The Base
1) Press .
2) Listen for the dial tone.
3) Dial the number.
TALK
Handset On The Base
Pick up the handset (Auto Talk).
Handset Off The Base
Press any button (Any-key answer).
To hang up: Press , or return the handset to the base (Auto Standby).
TALK
RECEIVING A CALL
(Redial/Pause)
RDL/P
(TONE MODE)
TONE/
FT-8901A.qx 7/2/1 11:36 AM Page 15

16
BASIC OPERATION
REDIAL
OUT OF RANGE
During a call, as you begin to move too far from the base unit, the
noise increases. Then, you should move closer to the base unit. If
you travel out-of-range, your call terminates.(See page 17
“Interference or static”)
CALL WAITING
To use this feature, you must subscribe to the Call Waiting Service.
1When you hear a call-waiting tone during your conversation on the
phone, simply press .
2To return to the first caller, press again.
NOTE:
Pressing without receiving a Call Waiting signal may disconnect the
current caller.
HANDSET EARPIECE VOLUME SETTING
To adjust the earpiece volume, press during a call.
HANDSET RINGER VOLUME SETTING
To adjust the ringer volume, press during standby mode.
NOTE:
When the handset is on the base, the handset ringer volume is disabled.
VOL/RING
VOL/RING
FLASH
FLASH
FLASH
Basics
Handset On The Base
1) Pick up the handset and press .
2) Listen for the dial tone.
3) Press .
RDL/P
TALK
Handset Off The Base
1) Press .
2) Listen for the dial tone.
3) Press .
RDL/P
TALK
FT-8901A.qx 7/2/1 11:36 AM Page 16

BASIC OPERATION
BASE SPEAKER VOLUME SETTING
To adjust the base unit speaker volume, press or .
MUTE
To mute a conversation, press during a conversation.
To resume normal conversation, press or .
TONE/ENTERING A PAUSE
INTERFERENCE OR STATIC
If you hear noise during a call, press to select another channel.
The TALK/BATT LOW LED blinks while changing a channel.
PAGING THE HANDSET
To locate the handset while it is off the
base, press . The handset
beeps for 60 seconds.
To stop paging, press or any
key at the handset, or return the
handset to the base unit.
NOTE:
You cannot page the handset during a call.
PAGE
PAGE
CH
MUTE
TALK
MUTE
VOLUME/–
VOLUME/+
PAGE
17
Basics
To
To temporarily switch to tone dial
(When the handset is set to pulse mode)
To enter a pause within the dialing
sequence
Do this
Press . The following numbers
will be sent as tone dialing (See page 14).
Press (See page 19).
RDL/P
TONE/
FT-8901A.qx 7/2/1 11:36 AM Page 17

18
MEMORY DIALING
You can store up to 10 telephone numbers in the memory.
NOTES:
•Always press a button within 20 seconds or the phone will return to standby.
•If you press a wrong button, an error tone sounds and the handset returns to
standby mode.
•If you receive an incoming call or a pager call from the base unit during the
operation, the operation will be cancelled.
STORING NUMBERS
You can store up to 16 digits including #, , and PAUSE as a
telephone number.
1Pick up the handset and press .
2Dial the telephone number you wish to store (up to 16 digits).
3Press .
MEM
MEM
MEM
RDL/P
Basics
TALK
(Redial/Pause)
(Memory)
FT-8901A.qx 7/2/1 11:36 AM Page 18

MEMORY DIALING
19
4Enter the memory address (0 to 9) at which you wish to store the
phone number stored in step 3.
You will hear a long beep when the number is successfully stored.
To store more telephone numbers, repeat steps 1 to 4.
5Return the handset to the base unit.
6Record the telephone numbers on the SPEED DIAL INDEX CARD,
and place it on the back of the handset.
Basics
EXAMPLE: To store 9012345 in memory address 3
Replacing a telephone number
Just store the new number following the same steps in “STORING
NUMBERS.”
The new number will replace the previously stored one.
INSERTING A PAUSE IN MEMORY
Use (redial/pause) to make an outgoing call through a PBX or
long distance. Each time you press , a pause of about two
seconds is inserted during the dialing sequence. If more than two
seconds are needed, press twice.
EXAMPLE: To store “0 PAUSE 1234567890”in memory address 4,
press:
4
MEM
0
9
8
7
6
5
4
3
2
1
RDL/P
0
MEM
RDL/P
RDL/P
RDL/P
3
MEM
5
4
3
2
1
0
9
MEM
DIALING A STORED NUMBER
1Pick up the handset and press .
2Press the .
3Press the memory location number (0-9).
The stored number will be dialed.
NOTE:
If you enter a memory address which does not have any stored number, error
beeps sound.
MEM
TALK
FT-8901A.qx 7/2/1 11:36 AM Page 19

20
USING THE MENU MODE
Menu mode allows you to set the following Answering System
functions.
NOTES:
•If you make no entries within 20 seconds, or 20 seconds pass after a voice
prompt/guidance or greeting, you will hear a long beep and the answering
machine returns to standby. Note that time-out for clock setting is 2 minutes.
•Receiving a call or pressing talk will cancel the setting. If you press
, the setting is canceled and returns to standby.
•You can scroll to the next menu option by pressing .
•You can use or to adjust the announcement volume level
during voice prompt/guidance.
VOLUME/–
VOLUME/+
MENU
PLAY/STOP
Answering system
SELECT SELECT
VOLUME/–
TIME
SKIP FF
SELECT
PLAY/STOP
DELETE
MENU
SET
REW REPEAT
GREETING
VOLUME/+
REC MEMO/2WAY
LED display
LED display
-- --
[ ] - [ ], [ ], [ ]
[ ] - [ ]
[ ], [ ], [ ]
[ ], [ ], [ ], [ ]
[ ], [ ], [ ]
[ ] - [ ]
Menu No. Function
Menu1 Greeting message
Menu2 Clock
Menu3 Security code (PIN)
Menu4 Ringer volume
Menu5 Ring time
Menu6 Recording time
Standby Return to standby
/
SELECT
/
FT-8901A.qx 7/2/1 11:36 AM Page 20
