Toshiba BL-60PHNMY User manual

TABLE BLENDER
USER MANUAL
BL-60PHNMY
CONTENT
IMPORTANT SAFETY INSTRUCTIONS.
PART NAME
TECHNICAL DATA OF THE PRODUCT
INSTRUCTIONS FOR USE
IMPORTANT NOTE: Please read the manual carefully before operating your
product. Retain it for future reference.
CLEANING AND MAINTENANCE
CIRCUIT PRINCIPLE DIAGRAM
ABNORMALITY ANALYSIS AND HANDLING
1
3
3
4
8
8
9
10
RECIPES

1
When using electrical appliances, basic safety precautions should
always be followed including the following:
There is a potential injury from misuse.Please handle it with care.
Always disconnect the appliance from the supply if it is left unattended
andbefore assembling,disassembling or cleaning.
This appliance shall not be used by children.Keep the appliance and its
cord out of children reach.
Appliances can be used by personswith reduced physical,sensory or
mental capabilities or lack of experience and knowledge if they have
been given supervision or instructionconcerning use of the appliance in
a safe wayand if they understand the hazards involved.
Children shall not play with the appliance.
Be careful when handing the sharp cutting blades,emptying the bowl and
during cleaning.
Be careful if hot liquid is poured into blender as it can be ejected out of
the appliance due to asudden steaming.
Switch off the appliance and disconnect from supply before changing
accessories or approachingparts that move in use.
This appliance is intended tobeusedin household and similar
applications such as:
– Staff kitchen areas in shops,officesand other working environments;
– Farm houses;
– By clients in hotels,motels and other residential type environments;
– Bed and breakfast typeenvironments.
This appliance conforms to EC Regulation 1935/2004 on materials and
articles intended to come into contact with food.
Do not exceed the maximum indication on the blender jar,the mill(specific
types only)beaker and the chopper bowl (specific types only).
1.
2.
3.
4.
5.
6.
7.
8.
9.
10.
11.
IMPORTANT SAFETY INSTRUCTIONS

2
The failure to follow any of the important safeguards and the important
instructions for safe use is a misuse of your table blender that can void
your warrantyandcreate the risk of serious injury.
Caution:
Ensure that the blender is switched off before removing
Caution:
12.
13.
14.
15.
16.
If food sticks to the wall of the blender jar,switch off the appliance and
unplugit.Then use a spatula to remove the food from the wall.
Never fill the blender jar with ingredients hotter than 80°C.
The appliance can onlybe switched on ifthe blender jar or the beaker is
assembled on the motor unit correctly.
Do not let the appliance run for morethan 2 minutes or 30 seconds at
a time. Let the appliance cool downtoroom temperature before you
continue processing.
If the supplycord is damaged,itmustbe replaced by the manufacturer,its
service agent or similarly qualified persons in order to avoid a hazard.
SAVE THESE INSTRUCTION.
THIS UNIT IS INTENDED FOR HOUSEHOLD USE ONLY.
IMPORTANT SAFETY INSTRUCTIONS

3
PART NAME
TECHNICAL DATA OF THE PRODUCT
Model No. Rated voltage Rated frequency Rated power Product name Effective capacity
TABLE BLENDER
(Eccentric blender jar) BL-60PHNMY 220-240V~ 50-60Hz 600W 1.5L
ACCESSORIES
10
No. Description
1
2
3
4
Measuring cup
Blender jar cover
Blender jar (1.5L)
Blender jar seal
Blade system
5
Speed control dial
6
7200ml jar
Jar seal
8
Grinder blade system
9
Spatula
10
7
8
9
1
2
3
4
5
6

4
INSTRUCTIONS FOR USE
Tableblender
9
12
11
10

5
INSTRUCTIONS FOR USE
Grinder
9
When the blender is switched on, use the spatula toenhancethe smoothness and
consistency of result.
When the blender is switched off, use the spatula to removethe sticky ingredients in
the jar.
Spatula

6
INSTRUCTIONS FOR USE
Hot liquids can erupt during blending. Do not blend hot liquids.
Warning:
Many recipes process best with a combination of speeds with occassional use of
pulse.
Momentary burst of high power.
Low speed to combine more delicate foods with a folding motion, and is good for
combining wet and dry ingredients.
High speed is ideal for breaking down ingredients to make ice based drinks and
other finely blended mixtures.
Run the blender only for the appropriate amount of time required.
Do not over blend ingredients.
Use the PULSE setting when food is too thick or coarse to circulate within the
blender jug.
Do not exceed the maximum mark.
If any moisture or liquid appears on top of the motorbase during blending, turn the
blender off and unplug at the wall. Remove the blender jug, and wipe motor base
MOTOR BASE SPEED CONTROL
BLENDING JUG
PULSE
CHOP (speed 1)
LIQUIFY (speed 2)
Before first use
Functions (Speed)
Before using your blender for the first time, remove any packaging material and
promotional labels.
Be careful when handling the blades as they are extremely sharp.
Wash the jug, lids, blade assembly and attachments in warm soapy water with a
soft cloth. Rinse and dry thoroughly. All parts (except motor base) may be
washed in the dishwasher, on the top shelf.

7
INSTRUCTIONS FOR USE
Overload protection system
immediately with adry cloth or paper towel.
The maximum amount of ice cubes that the blender can process is 8 cubes froma
standard ice tray.
Use the PULSE function for foods that only require short bursts of power,such as
choppingnuts and crushingice.
When blending drinks with ice cubes or frozen fruit, use PULSE in short bursts.
Thicker mixtures puree more efficiently if the jaris too full.
Do not use metal utensils, as they may damage the blades or blender jar.
Do not blend a heavy mixture for more than 10 seconds. For normal blending tasks,
do not blend longer than 1 minutes at a time. If you need to blend longer,turn offthe
blender and stir ingredients before starting again.
This rest will help protect the motor from wear and tear.
The blender will not knead dough, or mash potatoes.
When blending warm ingredients, do not put more than 2 blending bottles at atime
in.
Do not blend hot or boiling ingredients. Allow food to cooldown to a warmstate
before placing in the blender. This is to safeguard againstsuddenbursts of steam
that could cause the lid to dislodge.
If blending warm ingredients, place a tea towel over the lid and hold down firmly.
Machine running time cannot be more than 3 minutes. After theshutdown, it is
necessary to let it fullyheat, cooling to room temperature.
The MAX line is usually a good indicator to prevent overly heavy loading, however
some especially dense combinations of ingredients may still strain themotor. If the
motor seems to be straining or running slowly, only operatefor 10seconds at atime,
or reduce the amount of ingredients used. Adding more liquid can also help to loosen
dense mixtures.
Do not process hot foods or liquids in blender.
Do not store food or liquids in the blender jar.
Avoid bumping or dropping the blender.
Note:

8
In case of abnormalities such as abnormal noises, smell, smoke, etc., you should
immediately cut off power and stop use.
If the product cannot work, please check if the power supply is connected, if the switch is
put to the ON position and if fittings are installed in place.
If the product still cannot work after checks mentioned above, please consult the
designated repair centre for maintenance.
ABNORMALITY ANALYSIS AND HANDLING
Abnormality Handling
1.
2.
3.
Motor doesn’t start or
blade doesn’t rotate
Food is lumpy or
unevenly chopped
Food is chopped too
fine or is watery
Food sticks to
blade and jug
Blender stopped
suddenly while in use
• Check that the power plug is properly inserted into the power outlet.
• This can happen when too much food is being blended at one time.
Try a smaller amount, and work in batches if necessary.
• The ingredients may be too large. Try cutting into smaller pieces.
For best results, ingredients should be in pieces no larger than 2cm.
• Try blending for shorter period of time. Use PULSE for better control.
Food sticks
• The mixture may be too thick. Try adding more liquid, pulsing, and/or using
a slower speed for blending.
• We recommend blending in smaller batches, or cutting ingredients into
smaller batches.
This blending chart should be used as a guide only.
Note:
RECIPES
Ice or frozen
fruit
Grinder
Frozen no larger
than standard ice
tray
Coffee bean
Max 8 pieces
50g
Pulse;
Liquify (speed 2)
Speed 2
60 secs
30 secs
Chopper Onions 60g Speed 2 30 secs
Food Preparation Quantity Functions
(Speed) Time
Smoothie Milk, fruit, yoghurt,
ice cream Max 800ml Chop (speed 1);
Liquify (speed 2) 60 secs
Blended soups
Cool to room temp
800ml Chop (speed 1) 50-60 secs

Blades in jar are very sharp.Use caution when cleaning.
Warning:
9
CLEANING AND MAINTENANCE
Avoid allowing food residue to dry on. Follow these steps as soon as possible after
use:
• Rinse most of the residue off the jar, blades and lids.
• Hand wash in warm, soapy water using a mild liquid detergent and non-abrasive
sponge.
To clean the motor base, wipe with a soft, damp cloth then dry thoroughly. Wipe any
excess food particles from the power cord.
Do not use abrasive scouring pads or cleaners on either the motor base or any part
of the blender, as they may scratch the surface. Use only warm soapy water with a
soft cloth.
The jar, lids and blade assembly may be washed in the dishwasher on the top shelf
only.
Strong smelling foods such cumin and coriander, and some vegetables such as
Unplug the power cord from the power outlet after use for safety reasons.
Jar, blades and lids
Motor base
Cleaning agents
Dishwasher
Stubborn food stains and odours
Cleaning

The appliance must not be disposed of with regular household waste.
At the end of its service life, the appliance must be properly delivered
to a collection point for the recycling of electrical and electronic
equipment. By Collection and recycling of old appliances,
you are making an important contribution to the conservation of our
natural resources and provide for environmentally sound and healthy
disposal.
Environmental protection
CIRCUIT PRINCIPLE DIAGRAM
10
CLEANING AND MAINTENANCE
Maintaining
carrots may leave an odour or stain.
To remove, pour warm soapy water and fill to the MAX mark. Set aside to soak for 5
minutes. Then wash with a mild detergent and warm water, rinse well and dry
thoroughly. Store blending bottle and jar with lids off.
Store your blender upright with the blender jar assembled on the motor base, or
beside it. Do not place anything on top. To allow air to circulate, keep the lid off.
