Toshiba Personal Computer
QOSMIO E10
Maintenance Manual
TOSHIBA CORPORATION
File Number 960-492

ii QOSMIO E10 Maintenance Manual (960-492)
Copyright
© 2004 by Toshiba Corporation. All rights reserved. Under the copyright laws, this manual cannot be
reproduced in any form without the prior written permission of Toshiba. No patent liability is assumed with
respect to the use of the information contained herein.
Toshiba QOSMIO E10 Maintenance Manual
First edition July 2004
Disclaimer
The information presented in this manual has been reviewed and validated for accuracy. The included set of
instructions and descriptions are accurate for the QOSMIO E10 at the time of this manual's production.
However, succeeding computers and manuals are subject to change without notice. Therefore, Toshiba assumes
no liability for damages incurred directly or indirectly from errors, omissions, or discrepancies between any
succeeding product and this manual.
Trademarks
IBM is a registered trademark and IBM PC is a trademark of International Business Machines Corporation.
Intel, Intel SpeedStep, Centrino, Celeron and Pentium are trademarks or registered trademarks of Intel
Corporation or its subsidiaries in the United States and other countries/regions.
Windows and Microsoft are registered trademarks of Microsoft Corporation.
Bluetooth is a trademark owned by its proprietor and used by TOSHIBA under license.
Memory Stick is a registered trademark and i.LINK is a trademark of Sony Corporation.
Other trademarks and registered trademarks not listed above may be used in this manual.

QOSMIO E10 Maintenance Manual (960-492) iii
Preface
This maintenance manual describes how to perform hardware service maintenance for the
Toshiba Personal Computer QOSMIO E10.
NOTE: Each model of QOSMIO E10 has a different configuration. For each model’s
configuration, refer to the parts list dedicated to it.
The procedures described in this manual are intended to help service technicians isolate
faulty Field Replaceable Units (FRUs) and replace them in the field.
SAFETY PRECAUTIONS
Four types of messages are used in this manual to bring important information to your
attention. Each of these messages will be italicized and identified as shown below.
DANGER: “Danger” indicates the existence of a hazard that could result in death or
serious bodily injury, if the safety instruction is not observed.
WARNING: “Warning” indicates the existence of a hazard that could result in bodily
injury, if the safety instruction is not observed.
CAUTION: “Caution” indicates the existence of a hazard that could result in property
damage, if the safety instruction is not observed.
NOTE: “Note” contains general information that relates to your safe maintenance
service.
Improper repair of the computer may result in safety hazards. Toshiba requires service
technicians and authorized dealers or service providers to ensure the following safety
precautions are adhered to strictly.
 Be sure to fasten screws securely with the right screwdriver. Be sure to use the PH
Point size “0” and “1” screwdrivers complying with the ISO/DIS 8764-1:1996. If a
screw is not fully fastened, it could come loose, creating a danger of a short circuit,
which could cause overheating, smoke or fire.
 If you replace the battery pack or RTC battery, be sure to use only the same model
battery or an equivalent battery recommended by Toshiba. Installation of the wrong
battery can cause the battery to explode.

iv QOSMIO E10 Maintenance Manual (960-492)
The manual is divided into the following parts:
Chapter 1 Hardware Overview describes the QOSMIO E10 system unit and each
FRU.
Chapter 2 Troubleshooting Procedures explains how to diagnose and resolve
FRU problems.
Chapter 3 Test and Diagnostics describes how to perform test and diagnostic
operations for maintenance service.
Chapter 4 Replacement Procedures describes the removal and replacement of the
FRUs.
Appendices The appendices describe the following:
❑ Handling the LCD module
❑ Board layout
❑ Pin assignment
❑ Display codes
❑ Key layout
❑ Wiring diagrams
❑ BIOS Rewrite procedures
❑ EC/KBC Rewrite procedures
❑ Reliability

QOSMIO E10 Maintenance Manual (960-492) v
Conventions
This manual uses the following formats to describe, identify, and highlight terms and
operating procedures.
Acronyms
On the first appearance and whenever necessary for clarification acronyms are enclosed in
parentheses following their definition. For example:
Read Only Memory (ROM)
Keys
Keys are used in the text to describe many operations. The key top symbol as it appears on
the keyboard is printed in boldface type.
Key operation
Some operations require you to simultaneously use two or more keys. We identify such
operations by the key top symbols separated by a plus (+) sign. For example, Ctrl + Pause
(Break) means you must hold down Ctrl and at the same time press Pause (Break). If
three keys are used, hold down the first two and at the same time press the third.
User input
Text that you are instructed to type in is shown in the boldface type below:
DISKCOPY A: B:
The display
Text generated by the QOSMIO E10 that appear on its display is presented in the type face
below:
Format complete
System transferred

vi QOSMIO E10 Maintenance Manual (960-492)
Table of Contents
Chapter 1 Hardware Overview
1.1 Features ...................................................................................................................... 1-1
1.2 System Block Diagram .............................................................................................. 1-5
1.3 2.5-inch Hard Disk Drive........................................................................................... 1-9
1.4 Optical Drive............................................................................................................ 1-13
1.5 Keyboard.................................................................................................................. 1-18
1.6 TFT Color Display................................................................................................... 1-19
1.7 Power Supply ........................................................................................................... 1-21
1.8 Batteries ................................................................................................................... 1-23
1.9 AC Adapter .............................................................................................................. 1-26
Chapter 2 Troubleshooting Procedures
2.1 Troubleshooting ......................................................................................................... 2-1
2.2 Troubleshooting Flowchart........................................................................................ 2-2
2.3 Power Supply Troubleshooting.................................................................................. 2-6
2.4 System Board Troubleshooting................................................................................ 2-16
2.5 USB 3.5” FDD Troubleshooting.............................................................................. 2-36
2.6 2.5” HDD Troubleshooting...................................................................................... 2-39
2.7 Keyboard/Touch pad Troubleshooting .................................................................... 2-44
2.8 Display Troubleshooting.......................................................................................... 2-46
2.9 Optical Drive Troubleshooting ................................................................................ 2-49
2.10 Modem Troubleshooting.......................................................................................... 2-50
2.11 LAN Troubleshooting.............................................................................................. 2-51
2.12 Wireless LAN Troubleshooting............................................................................... 2-52
2.13 Sound Troubleshooting............................................................................................ 2-55
2.14 TV Tuner Troubleshooting ...................................................................................... 2-57

QOSMIO E10 Maintenance Manual (960-492) vii
Chapter 3 Tests and Diagnostics
3.1 The Diagnostic Test ................................................................................................... 3-1
3.2 Executing the Diagnostic Test ................................................................................... 3-4
3.3 Setting of the hardware configuration........................................................................ 3-8
3.4 Heatrun Test............................................................................................................. 3-11
3.5 Subtest Names.......................................................................................................... 3-12
3.6 System Test .............................................................................................................. 3-14
3.7 Memory Test............................................................................................................ 3-16
3.8 Keyboard Test.......................................................................................................... 3-17
3.9 Display Test ............................................................................................................. 3-18
3.10 Floppy Disk Test...................................................................................................... 3-21
3.11 Printer Test............................................................................................................... 3-23
3.12 Async Test ............................................................................................................... 3-25
3.13 Hard Disk Test ......................................................................................................... 3-26
3.14 Real Timer Test........................................................................................................ 3-29
3.15 NDP Test.................................................................................................................. 3-31
3.16 Expansion Test......................................................................................................... 3-32
3.17 CD-ROM/DVD-ROM Test ..................................................................................... 3-33
3.18 Error Code and Error Status Names......................................................................... 3-34
3.19 Hard Disk Test Detail Status.................................................................................... 3-37
3.20 Only one Test........................................................................................................... 3-39
3.21 Head Cleaning.......................................................................................................... 3-44
3.22 Log Utilities ............................................................................................................. 3-45
3.23 Running Test............................................................................................................ 3-47
3.24 Floppy Disk Drive Utilities...................................................................................... 3-48
3.25 System Configuration .............................................................................................. 3-53
3.26 Wireless LAN Test Program.................................................................................... 3-55
3.27 LAN/Modem/Bluetooth/IEEE1394 Test ................................................................. 3-58
3.28 Sound Test Program................................................................................................. 3-72
3.29 SETUP ..................................................................................................................... 3-78

viii QOSMIO E10 Maintenance Manual (960-492)
Chapter 4 Replacement Procedures
4.1 Overview....................................................................................................................4-1
4.2 Battery pack/PC card/Bridge Media .......................................................................... 4-8
4.3 HDD......................................................................................................................... 4-12
4.4 Memory module....................................................................................................... 4-15
4.5 Keyboard/Bluetooth................................................................................................. 4-17
4.6 AN board.................................................................................................................. 4-22
4.7 Switch membrane..................................................................................................... 4-24
4.8 Optical drive............................................................................................................. 4-26
4.9 Display assembly ..................................................................................................... 4-29
4.10 Touch pad................................................................................................................. 4-34
4.11 SJ board/Microphone ............................................................................................... 4-36
4.12 SD board/MDC ........................................................................................................ 4-39
4.13 TV board .................................................................................................................. 4-42
4.14 Fan............................................................................................................................ 4-44
4.15 System board............................................................................................................ 4-45
4.16 Wireless LAN board ................................................................................................ 4-47
4.17 TV tuner module ...................................................................................................... 4-49
4.18 Heat sink/CPU ......................................................................................................... 4-51
4.19 RTC battery.............................................................................................................. 4-54
4.20 PC card cover........................................................................................................... 4-55
4.21 Speaker..................................................................................................................... 4-56
4.22 LCD unit/FL inverter ............................................................................................... 4-57
4.23 Wireless antennas/LCD harness .............................................................................. 4-62
4.24 Hinge........................................................................................................................ 4-67
4.25 Fluorescent lamp...................................................................................................... 4-71

QOSMIO E10 Maintenance Manual (960-492) ix
Appendices
Appendix A Handling the LCD Module ........................................................................ A-1
Appendix B Board Layout ............................................................................................. B-1
Appendix C Pin Assignment .......................................................................................... C-1
Appendix D Display Codes ............................................................................................ D-1
Appendix E Key Layout..................................................................................................E-1
Appendix F Wiring Diagrams.........................................................................................F-1
Appendix G BIOS Rewite procedures............................................................................ G-1
Appendix H EC/KBC Rewrite procedures..................................................................... H-1
Appendix I Reliability.....................................................................................................I-1

x QOSMIO E10 Maintenance Manual (960-492)

Chapter 1
Hardware Overview

1 Hardware Overview
1 Hardware Overview
1-ii QOSMIO E10 Maintenance Manual (960-492)

1 Hardware Overview
Chapter 1 Contents
1.1 Features...................................................................................................................... 1-1
1.2 System Block Diagram .............................................................................................. 1-5
1.3 2.5-inch Hard Disk Drive........................................................................................... 1-9
1.4 Optical Drive............................................................................................................ 1-13
1.4.1 DVD-ROM & CD-R/RW Drive ........................................................ 1-13
1.4.2 DVD Super Multi Drive..................................................................... 1-16
1.5 Keyboard.................................................................................................................. 1-18
1.6 TFT Color Display................................................................................................... 1-19
1.6.1 LCD Module ...................................................................................... 1-19
1.6.2 FL Inverter Board............................................................................... 1-20
1.7 Power Supply........................................................................................................... 1-21
1.8 Batteries ................................................................................................................... 1-23
1.8.1 Main Battery....................................................................................... 1-23
1.8.2 Battery Charging Control ................................................................... 1-24
1.8.3 RTC battery ........................................................................................ 1-25
1.9 AC Adapter .............................................................................................................. 1-26
QOSMIO E10 Maintenance Manual (960-492) 1-iii

1 Hardware Overview
1-iv QOSMIO E10 Maintenance Manual (960-492)
Figures
Figure 1-1 Front of the computer and the system units configuration ............................ 1-4
Figure 1-2 System block diagram.................................................................................... 1-5
Figure 1-3 2.5-inch HDD................................................................................................. 1-9
Figure 1-4 DVD-ROM & CD-R/RW drive ................................................................... 1-13
Figure 1-5 DVD Super Muti drive................................................................................. 1-16
Figure 1-6 Keyboard...................................................................................................... 1-18
Figure 1-7 LCD module................................................................................................. 1-19
Tables
Table 1-1 2.5-inch HDD dimensions ............................................................................. 1-9
Table 1-2 2.5-inch HDD specifications........................................................................ 1-11
Table 1-3 DVD-ROM & CD-R/RW drive outline dimensions.................................... 1-13
Table 1-4 DVD-ROM & CD-R/RW drive specifications ............................................ 1-14
Table 1-5 DVD Super Multi drive outline dimensions ................................................ 1-16
Table 1-6 DVD Super Multi specifications.................................................................. 1-17
Table 1-7 LCD module specifications.......................................................................... 1-19
Table 1-8 FL inverter board specifications .................................................................. 1-20
Table 1-9 Power supply output rating .......................................................................... 1-22
Table 1-10 Battery specifications................................................................................... 1-23
Table 1-11 Time required for charges of main battery .................................................. 1-24
Table 1-12 Data preservation time ................................................................................. 1-24
Table 1-13 Time required for charges of RTC battery................................................... 1-25
Table 1-14 AC adapter specifications ............................................................................ 1-26

1.1 Features 1 Hardware Overview
1 Features
1.1 Features
The QOSMIO E10 is high performance all-in-one PCs running a Pentium-M or Celeron-M
processor.
The features are listed below.
❑ Microprocessor
Microprocessor that is used will be different of the model.
Intel ®Mobile Pentium ®-M
Pentium-M 1.50GHz (Processor Number ; 715)
1.60GHz (Processor Number ; 725)
1.70GHz (Processor Number ; 735)
1.80GHz (Processor Number ; 745)
2.00GHz (Processor Number ; 755)
L1 cache : 64KB (32KB + 32KB)
L2 cache : 2MB
Intel ®Mobile Celeron ®-M
Celeron-M 1.40GHz (Processor Number ; 330)
1.50GHz (Processor Number ; 340)
L1 cache : 64KB (32KB + 32KB)
L2 cache : 1MB
❑ Memory
Two DDR333 SO-DIMM slots. Memory modules can be installed to provide a
maximum of 2GB. Memory modules are available in 256MB, 512MB and 1024MB
sizes.
❑ VRAM
nVIDIA NV34M is mounted.
❑ HDD
Single 60GB or 80GB internal drive. 2.5 inch x 9.5mm height.
QOSMIO E10 Maintenance Manual (960-492) 1-1

1 Hardware Overview 1.1 Features
❑ USB FDD
USB 3.5-inch FDD supports 720KB and 1.44MB.
❑ Display
LCD
Built-in 15.0-inch, XGA (1,024 x 768 dots), 262,144 colors, amorphous silicon
TFT color display.
CRT
Supported via a RGB connector.
TV-out
S-VIDEO out port supported.
D-VIDEO out port supported.
❑ Monitor-IN port
This port can be used also as line in port and enables connection of a stereo device for
audio input.
❑ TV-tuner
This enables to watch TV and record it.
According to the government regulation, it is not permitted to bring PAL/SECAM TV
tuner into Korea.
❑ Remote controller
A remote controller for watching TV is equipped.
❑ Keyboard
An-easy-to-use 85(US)/86(UK)-key keyboard provides a numeric keypad overlay for
fast numeric data entry or for cursor and page control. The keyboard also includes
two keys that have special functions in MicrosoftWindowsXP. It supports
software that uses a 101- or 102-key enhanced keyboard.
❑ Optical devices
A DVD Super Multi drive or DVD-ROM & CD-R/RW drive is equipped.
1-2 QOSMIO E10 Maintenance Manual (960-492)

1.1 Features 1 Hardware Overview
❑ Battery
The RTC battery is mounted inside the computer.
The main battery is a detachable lithium ion battery (3,600mAh:Li-Ion, 6cell).
❑ USB (Universal Serial Bus)
Four USB ports are provided. The ports comply with the USB2.0 standard, which
enables data transfer speeds 40 times faster than USB1.1 standard. USB1.1 is also
supported.
❑ PC card slot
PC card slots accept two Type II (5mm thick) cards. The slot is equipped with an
ejector. Supports ToPIC-100 (3.3V/CardBus).
❑ Bridge Media slot
One SD card/Memory stick (PRO)/xDPicture card slot. Data can be read and written
by inserting each media to the slot. Memory stick Duo/PRO Duo and memory stick
adapter is not supported.
❑ Sound system
Has an external monaural microphone connector, stereo headphone connector,
internal stereo speakers and internal microphone.
❑ Wireless LAN (Mini PCI slot)
The wireless LAN is equipped on the mini PCI slot.
❑ LAN/MODEM
Connectors for LAN and Modem are separately mounted.
❑ IEEE 1394 port
The computer has one IEEE 1394 port. It enables high-speed data transfer directly
from external devices such as digital video cameras.
❑ Bluetooth
Depending on the model, the computer is equipped with a dedicated Bluetooth
module. This enables a communication to devices that support Bluetooth
Version 1.1. It can be switched on or off with a switch on the computer.
QOSMIO E10 Maintenance Manual (960-492) 1-3

1 Hardware Overview 1.1 Features
Figure 1-1 shows the front of the computer and the system units configuration.
Figure 1-1 Front of the computer and the system units configuration
1-4 QOSMIO E10 Maintenance Manual (960-492)

1.2 System Block Diagram 1 Hardware Overview
1.2 System Block Diagram
Figure 1-2 shows the system block diagram.
Figure 1-2 System block diagram
QOSMIO E10 Maintenance Manual (960-492) 1-5

1 Hardware Overview 1.2 System Block Diagram
The PC contains the following components.
❑ CPU
Intel ®Mobile Pentium ®-M
Pentium-M 1.50GHz (Processor Number ; 715)
1.60GHz (Processor Number ; 725)
1.70GHz (Processor Number ; 735)
1.80GHz (Processor Number ; 745)
2.00GHz (Processor Number ; 755)
L1 cache : 64KB (32KB + 32KB)
L2 cache : 2MB
Bus : 400Hz Core voltage : 1.340~0.748V
Intel ®Mobile Celeron ®-M
Celeron-M 1.40GHz (Processor Number ; 330)
1.50GHz (Processor Number ; 340)
L1 cache : 64KB (32KB + 32KB)
L2 cache : 1MB
Bus : 400Hz Core voltage : 1.356~1.200V
❑ Memory
Two memory slots capable of accepting DDR-SDRAM (PC2700) 256MB, 512MB,
or 1024MB memory modules for a maximum of 2GB.
• 200-pin small-size DIMM
• 2.5V operation
• PC2700/2100 support
❑ BIOS ROM (Flash memory)
• 8Mbit (512K×16-bit chip)
− 64KB used for logo/icon
− 224KB used for system BIOS
− 64KB used for VGA-BIOS
− 60KB used for Intel PXE
− 32KB used for ACPI
− 16KB used for MBI
− 17KB used for booting
− 16KB used for Parameter Block
− 19KB are reserved
1-6 QOSMIO E10 Maintenance Manual (960-492)
