Toshiba Satellite 1400 Series User manual

Toshiba Personal Computer
Satellite 1400/2400 Series
Maintenance Manual
TOSHIBA CORPORATION
File Number 960-364/365

ii Satellite 1400/2400 Maintenance Manual (960-364/365)
Copyright
© 2002 by Toshiba Corporation. All rights reserved. Under the copyright laws, this manual
cannot be reproduced in any form without the prior written permission of Toshiba. No patent
liability is assumed with respect to the use of the information contained herein.
Toshiba Personal Computer Satellite 1400/2400 Series Maintenance Manual
First edition May 2002
Disclaimer
This manual has been validated and reviewed for accuracy. The instructions and descriptions
it contains are accurate for the TOSHIBA 1400/2400 Series Portable Personal Computer at
the time of this manual's production. However, succeeding computers and manuals are
subject to change without notice. TOSHIBA assumes no liability for damages incurred
directly or indirectly from errors, omissions or discrepancies between the computer and the
manual.
Trademarks
IBM is a registered trademark, and OS/2 and PS/2 are trademarks of IBM Corporation.
Microsoft, MS-DOS, Windows, DirectSound and DirectMusic are registered trademarks of
Microsoft Corporation.
Intel and Pentium are registered trademarks, and SpeedStep is a trademark of Intel
Corporation.
Sound Blaster is a registered trademark of Creative Technology Ltd.
Centronics is a registered trademark of Centronics Data Computer Corporation.
Photo CD is a trademark of Eastman Kodak.
All other properties are trademarks or registered trademarks of their respective holders.

Satellite 1400/2400 Maintenance Manual (960-364/365) iii
Preface
This maintenance manual describes how to perform hardware service maintenance for the
Toshiba Personal Computer Satellite 1400/2400 Series, referred to as 1400/2400 Series in
this manual.
The procedures described in this manual are intended to help service technicians isolate
faulty Field Replaceable Units (FRUs) and replace them in the field.
SAFETY PRECAUTIONS
Four types of messages are used in this manual to bring important information to your
attention. Each of these messages will be italicized and identified as shown below.
DANGER: “Danger” indicates the existence of a hazard that could result in death or
serious bodily injury, if the safety instruction is not observed.
WARNING: “Warning” indicates the existence of a hazard that could result in bodily
injury, if the safety instruction is not observed.
CAUTION: “Caution” indicates the existence of a hazard that could result in property
damage, if the safety instruction is not observed.
NOTE: “Note” contains general information that relates to your safe maintenance
service.
Improper repair of the computer may result in safety hazards. Toshiba requires service
technicians and authorized dealers or service providers to ensure the following safety
precautions are adhered to strictly.
! Be sure to fasten screws securely with the right screwdriver. If a screw is not fully
fastened, it could come loose, creating a danger of a short circuit, which could cause
overheating, smoke or fire.
! If you replace the battery pack or RTC battery, be sure to use only the same model
battery or an equivalent battery recommended by Toshiba. Installation of the wrong
battery can cause the battery to explode.

iv Satellite 1400/2400 Maintenance Manual (960-364/365)
The manual is divided into the following parts:
Chapter 1 Hardware Overview describes the Satellite 1400/2400Series system
unit and each FRU.
Chapter 2 Troubleshooting Procedures explains how to diagnose and resolve
FRU problems.
Chapter 3 Test and Diagnostics describes how to perform test and diagnostic
operations for maintenance service.
Chapter 4 Replacement Procedures describes the removal and replacement of the
FRUs.
Appendices The appendices describe the following:
! Handling the LCD module
! Board layout
! Pin assignments
! Keyboard scan/character codes
! Key layout
! Wiring diagrams
! BIOS Rewrite Procedures
! Reliability

Satellite 1400/2400 Maintenance Manual (960-364/365) v
Conventions
This manual uses the following formats to describe, identify, and highlight terms and
operating procedures.
Acronyms
On the first appearance and whenever necessary for clarification acronyms are enclosed in
parentheses following their definition. For example:
Read Only Memory (ROM)
Keys
Keys are used in the text to describe many operations. The key top symbol as it appears on
the keyboard is printed in boldface type.
Key operation
Some operations require you to simultaneously use two or more keys. We identify such
operations by the key top symbols separated by a plus (+) sign. For example, Ctrl + Pause
(Break) means you must hold down Ctrl and at the same time press Pause (Break). If
three keys are used, hold down the first two and at the same time press the third.
User input
Text that you are instructed to type in is shown in the boldface type below:
DISKCOPY A: B:
The display
Text generated by the computer that appears on its display is presented in the type face
below:
Format complete
System transferred

vi Satellite 1400/2400 Maintenance Manual (960-364/365)

Satellite 1400/2400 Maintenance Manual (960-364/365) vii
Table of Contents
Chapter 1 Hardware Overview
1.1 Features ....................................................................................................................1-1
1.2 System Unit Block Diagram ....................................................................................1-9
1.3 3.5-inch Floppy Disk Drive....................................................................................1-19
1.4 2.5-inch Hard Disk Drive.......................................................................................1-20
1.5 CD-ROM Drive......................................................................................................1-21
1.6 DVD-ROM Drive...................................................................................................1-22
1.7 CD-R/RW Drive.....................................................................................................1-24
1.8 Multi Drive.............................................................................................................1-26
1.9 Power Supply .........................................................................................................1-28
1.10 Batteries..................................................................................................................1-30
Chapter 2 Troubleshooting Procedures
2.1 Troubleshooting .......................................................................................................2-1
2.2 Troubleshooting Flowchart......................................................................................2-3
2.3 Power Supply Troubleshooting................................................................................2-7
2.4 System Board Troubleshooting..............................................................................2-23
2.5 FDD Troubleshooting ............................................................................................2-35
2.6 HDD Troubleshooting............................................................................................2-38
2.7 Keyboard Troubleshooting.....................................................................................2-43
2.8 Display Troubleshooting........................................................................................2-46
2.9 DVD-ROM and CD-RW/DVD-ROM Troubleshooting........................................2-48
2.10 Modem Troubleshooting........................................................................................2-50
2.11 LAN Troubleshooting............................................................................................2-52
2.12 Sound Troubleshooting..........................................................................................2-54

viii Satellite 1400/2400 Maintenance Manual (960-364/365)
Chapter 3 Tests and Diagnostics
3.1 The Diagnostic Test .................................................................................................3-1
3.2 Executing the Diagnostic Test .................................................................................3-3
3.3 Subtest Names..........................................................................................................3-7
3.4 System Test ..............................................................................................................3-9
3.5 Memory Test..........................................................................................................3-10
3.6 Keyboard Test........................................................................................................3-12
3.7 Display Test............................................................................................................3-17
3.8 Floppy Disk Test....................................................................................................3-21
3.9 Printer Test.............................................................................................................3-23
3.10 Async Test..............................................................................................................3-25
3.11 Hard Disk Test .......................................................................................................3-27
3.12 Real Timer Test......................................................................................................3-30
3.13 NDP Test................................................................................................................3-32
3.14 Expansion Test.......................................................................................................3-33
3.15 CD-ROM/DVD-ROM Test....................................................................................3-35
3.16 Error Code and Error Status Names.......................................................................3-36
3.17 Hard Disk Test Detail Status..................................................................................3-39
3.18 Head Cleaning........................................................................................................3-41
3.19 Log Utilities............................................................................................................3-42
3.20 Running Test..........................................................................................................3-44
3.21 Floppy Disk Drive Utilities....................................................................................3-46
3.22 System Configuration.............................................................................................3-51
3.23 SETUP....................................................................................................................3-53
3.24 Wireless LAN Test Program..................................................................................3-71
3.25 Sound/LAN/Modem Test Program........................................................................3-76

Satellite 1400/2400 Maintenance Manual (960-364/365) ix
Chapter 4 Replacement Procedures
4.1 General.....................................................................................................................4-1
4.2 HDD .......................................................................................................................4-15
4.3 Memory Modules...................................................................................................4-19
4.4 Modem Daughter Card...........................................................................................4-22
4.5 Wireless LAN Card................................................................................................4-25
4.6 Keyboard................................................................................................................4-29
4.7 Power Switch Board...............................................................................................4-33
4.8 Top Cover with Display Assembly........................................................................4-35
4.9 Optical Disk Drive .................................................................................................4-40
4.10 FDD........................................................................................................................4-43
4.11 Touch Pad...............................................................................................................4-45
4.12 Battery Board .........................................................................................................4-47
4.13 HDD Connector Board...........................................................................................4-49
4.14 RTC Battery ...........................................................................................................4-51
4.15 Sound Board...........................................................................................................4-53
4.16 CD Switch Board ...................................................................................................4-55
4.17 DC-IN Cable ..........................................................................................................4-58
4.18 Cooling Fan............................................................................................................4-61
4.19 System Board .........................................................................................................4-65
4.20 PC Card Slot...........................................................................................................4-68
4.21 Speakers .................................................................................................................4-71
4.22 CPU........................................................................................................................4-75
4.23 Display Mask..........................................................................................................4-80
4.24 FL Inverter Board...................................................................................................4-83
4.25 LCD Module ..........................................................................................................4-85
4.26 Antenna Coaxial Cables.........................................................................................4-89
4.27 LCD/FL Cable........................................................................................................4-92
4.28 TFT FL (Model 14.1 LG.Philips)...........................................................................4-95
4.29 TFT FL (Model 14.1 Samsung) ...........................................................................4-103
4.30 TFT FL (Model 14.1 SHARP).............................................................................4-113

x Satellite 1400/2400 Maintenance Manual (960-364/365)
4.31 TFT FL (Model 14.1 CHI MEI)...........................................................................4-121
4.32 TFT FL (Model 14.1 Toshiba LTM14C433).......................................................4-127
4.33 TFT FL (Model 14.1 Toshiba LTM14C501).......................................................4-140
4.34 TFT FL (Model 15.0 LG.Philips).........................................................................4-151
4.35 TFT FL (Model 15.0 Samsung) ...........................................................................4-159
4.36 TFT FL (Model 15.0 Toshiba).............................................................................4-167
4.37 TFT FL (Model 15.0 SHARP).............................................................................4-174
4.38 TFT FL (Model 15.0 SXGA Toshiba).................................................................4-191
4.39 TFT FL (Model 15.0 SXGA SHARP) .................................................................4-203
Appendices
Appendix A Handling the LCD Module..........................................................................A-1
Appendix B Board Layout............................................................................................... B-1
Appendix C Pin Assignments.......................................................................................... C-1
Appendix D Keyboard Scan/Character Codes.................................................................D-1
Appendix E Key Layout...................................................................................................E-1
Appendix F Wiring Diagram............................................................................................F-1
Appendix G BIOS Rewrite Procedures ...........................................................................G-1
Appendix H EC/KBC Rewrite Procedures......................................................................H-1
Appendix I Reliability......................................................................................................I-1

Chapter 1
Hardware Overview

1 Hardware Overview
1-ii Satellite 1400/2400 Maintenance Manual (960-364/365)

1 Hardware Overview
Satellite 1400/2400 Maintenance Manual (960-364/365) 1-iii
Chapter 1 Contents
1.1 Features......................................................................................................................1-1
1.2 System Unit Block Diagram......................................................................................1-9
1.3 3.5-inch Floppy Disk Drive..................................................................................... 1-19
1.4 2.5-inch Hard Disk Drive......................................................................................... 1-20
1.5 CD-ROM Drive ....................................................................................................... 1-21
1.6 DVD-ROM Drive ....................................................................................................1-22
1.7 CD-R/RW Drive ......................................................................................................1-24
1.8 Multi Drive .............................................................................................................. 1-26
1.9 Power Supply...........................................................................................................1-28
1.10 Batteries...................................................................................................................1-30
1.10.1 Main Battery.......................................................................................1-30
1.10.2 Battery LED (Main Battery) ..............................................................1-30
1.10.3 Battery Charging Control...................................................................1-31
1.10.4 RTC battery........................................................................................1-32

1 Hardware Overview
1-iv Satellite 1400/2400 Maintenance Manual (960-364/365)
Figures
Figure 1-1 Front of the computer.........................................................................................1-6
Figure 1-2 System unit configuration (FRTSI*)..................................................................1-7
Figure 1-2 System unit configuration (FRTSA*)................................................................1-8
Figure 1-3 System unit block diagram (Satellite 1400 series).............................................1-9
Figure 1-3 System unit block diagram (Satellite 2400 series)...........................................1-10
Figure 1-4 3.5-inch FDD ...................................................................................................1-19
Figure 1-5 2.5-inch HDD...................................................................................................1-20
Figure 1-6 CD-ROM drive ................................................................................................1-21
Figure 1-7 DVD-ROM drive .............................................................................................1-22
Figure 1-8 CD-R/RW drive ...............................................................................................1-24
Figure 1-9 Multi drive........................................................................................................1-26
Tables
Table 1-1 3.5-inch FDD specifications..............................................................................1-19
Table 1-2 2.5-inch HDD specifications.............................................................................1-20
Table 1-3 CD-ROM drive specifications...........................................................................1-21
Table 1-4 DVD-ROM drive specifications (1/2)............................................................... 1-22
Table 1-4 DVD-ROM drive specifications (2/2)............................................................... 1-23
Table 1-5 CD-R/RW drive specifications (1/2)................................................................. 1-24
Table 1-5 CD-R/RW drive specifications (2/2)................................................................. 1-25
Table 1-6 Multi drive specifications (1/3).........................................................................1-26
Table 1-6 Multi drive specifications (2/3).........................................................................1-27
Table 1-6 Multi drive specifications (3/3).........................................................................1-27
Table 1-7 Power supply board output rating ..................................................................... 1-29
Table 1-8 Battery specifications........................................................................................1-30
Table 1-9 Time required for quick charges ....................................................................... 1-31
Table 1-10 RTC battery charging/data preservation time .................................................1-32

1.1 Features 1 Hardware Overview
Satellite 1400/2400 Series Maintenance Manual (960-364/365) 1-1
1 Features
1.1 Features
The Toshiba Satellite 1400/2400 Series Personal Computer uses extensive Large Scale
Integration (LSI), and Complementary Metal-Oxide Semiconductor (CMOS) technology
extensively to provide compact size, minimum weight, low power usage and high reliability.
The computer is built and configured to order, to best meet the customer’s needs. This
computer incorporates the following features and benefits:
! Processor
Intel Celeron Processor or Intel Pentium 4Processor.
• Intel Celeron (0.13 micron) Processor
The processor runs at the following speed:
– 1200MHz (1.45volts)
The processor incorporates a 16KB L1 cache memory and 256KB L2 cache
memory.
• Intel Mobile Pentium 4Processor featuring Intel Enhanced SpeedStep technology
(except 1.6GHz Chip)
The processor runs at one of the following speeds:
– 1600MHz (1.30volts) / 1200MHz (1.20volts: Battery Optimized Mode)
– 1700MHz (1.30volts) / 1200MHz (1.20volts: Battery Optimized Mode)
– 1800MHz (1.30volts) / 1200MHz (1.20volts: Battery Optimized Mode)
The processor incorporates a 12KB L1 cache memory and 512KB L2 cache
memory.
! Memory
The computer contains 128MB, 256MB or 512 MB of memory.
For models with an Intel Mobile Pentium 4Processor, two PC2100 or PC1600
compatible DDR-SDRAM slots are available for installation of a 128 or 256MB
memory module, for a total of 512MB.
For models with an Intel Mobile Celeron (0.13 micron) Processor, two PC133
compatible SDR-SDRAM slots are available for installation of a 128, 256 or 512MB
memory module, for a total of 1024MB.

1 Hardware Overview 1.1 Features
1-2 Satellite 1400/2400 Series Maintenance Manual (960-364/365)
! HDD
Ultra DMA Interface, ATA66 The following HDDs are available:
• 18.63GB (20.0 billion bytes)
• 27.94GB (30.0 billion bytes)
• 37.26GB (40.0 billion bytes)
! FDD
A 3.5-inch FDD accommodates both 2HD (1.44MB) and 2DD (720KB) disks.
! CD-ROM Drive
A full-size, maximum 24-speed CD-ROM drive, contains an AT Attachment Packet
Interface (ATAPI) controller, and supports the following formats: Audio CD, ISO
9660, Photo-CD, CD-Extra, CD-R (read only) and CD-Rewritable (read only).
DVD-ROM Drive
A full-size drive that runs either 12cm (4.72-inch) or 8cm (3.15-inch) DVD/CDs
without an adaptor. It plays DVDs at a maximum 8-speed and reads CDs at maximum
24-speed. It supports the following formats: DVD-ROM, DVD-R (read only), DVD-
Video,Audio CD, Photo-CD, ISO 9660, CD-Extra, CD-R (read only) and CD-
Rewritable (read only).
! CD-R/RW Drive
A full-size, maximum 24-speed CD-ROM drive, maximum 8-speed CD-R writing
and maximum 8-speed CD-RW writing, maximum 8-speed CD-RW reading,
maximum 24-speed CD-ROM/CD-RW reading, contains an AT Attachment Packet
Interface (ATAPI) controller, and supports the following formats: Video CD, CD-
EXTRA, Audio CD, Photo CD, CD-R, CD-ROM, CD-Rewritable, CD-ROM x A,
CD-DA and CD-Text.
! Multi Drive
This drive is a combination DVD-ROM and CD-R/RW Drive. It is full-size and runs
either 12cm (4.72-inch) or 8cm (3.15-inch) DVD/CDs without an adaptor. It plays
DVDs at a maximum 8-speed, writes CD-R at maximum 8-speed CD-R, writes CD-
RW at maximum 8-speed, and reads CDs at maximum 24-speed. This drive supports
the following formats: CD-ROM, CD-RW, Audio CD, DVD-ROM, Photo CD, DVD-
R (read only), CD-EXTRA, DVD Video and CD-R.

1.1 Features 1 Hardware Overview
Satellite 1400/2400 Series Maintenance Manual (960-364/365) 1-3
! Keyboard
An easy-to-use 85/86-key keyboard provides a numeric keypad overlay for fast
numeric data entry or for cursor and page control. The keyboard also includes two
keys that have special functions in Microsoft Windows XP. It supports software that
uses a 101- or 102-key enhanced keyboard.
! Touch pad
A touch pad and control buttons in the palm rest enable control of the on-screen
pointer and scrolling of windows.
! Display
The following displays are available:
• 14.1-inch XGA TFT screen, 1024×768 pixels, 16M colors
• 15.0-inch XGA TFT screen, 1024×768 pixels, 16M colors
• 15.0-inch SXGA+ TFT screen, 1024×768 pixels, 16M colors
(Satellite 1400 Series Pentium Model)
A video controller and a 16MB of VRAM enables an external monitor with an
RGB cable to display 64k colors at a resolution of 1600 x 1200 pixels.
! Batteries
The computer has two batteries: a lithium-ion main battery pack and RTC battery
(that backs up the Real Time Clock and CMOS memory).
! Slot for optional memory
For Intel Mobile Celeron (0.13 micron) Processor models:
Two SDR-SDRAM (PC133) slots are available for 128, 256 and 512MB memory
modules, consisting of SDRAM chips.
For Intel Mobile Pentium 4Processor models:
Two DDR-SDRAM (PC2100) slots are available for 128 and 256MB memory
modules, consisting of SDRAM chips (PC1600). One module must be installed in
slot A.
! Universal Serial Bus (USB)
The computer comes with two USB ports that comply with Open Host Controller
Interface (OHCI). The USB enables daisy-chain connection of up to 127 USB-
equipped devices and 12Mbps serial data transfer. It is designed for easy
configuration by a Plug-and-Play operating system and provides hot insertion/ejection
capability.

1 Hardware Overview 1.1 Features
1-4 Satellite 1400/2400 Series Maintenance Manual (960-364/365)
! Infrared port
The infrared port is compatible with Fast InfraRed (FIR) standards enabling cableless
1.15 Mbps, 4 Mbps, 115.2 kbps, 57.6 kbps, 38.4 kbps, 19.2 kbps or 9.6 kbps data
transfer with Infrared Data Association (IrDA) 1.1 compatible external devices.
! Internal LAN
The computer is equipped with LAN circuits that support Ethernet LAN (10 megabits
per second, 10BASE-T) and Fast Ethernet LAN (100 mega bits per second, 100
BASE-Tx). It also supports Wakeup on LAN (WOL) and Magic Packet.
! Wireless LAN (mini PCI Card slot)
In some models, a Mini PCI Card with wireless LAN functions is available as a
dealer-installed option.
The mini PCI Card for wireless LAN is compatible with other LAN systems based on
Direct Sequence Spread Spectrum radio technology that complies with the IEEE
802.11 Standard (Revision B). It supports data transfer up to 11 Mbit/s. It has
Frequency Channel Selection (2.4GHz) and allows roaming over Multiple channels.
Modem + 802.11b and modem mini PCI cards do not support wireless LAN.
! PC Card Slot
A PC Card Slot accommodates two 5mm cards (Type II) or one 10.5mm (Type III)
card, which support the PC Card Standard Release 1997 cards and are ready for
advanced cards, including PC Card 16's multifunction cards and CardBus 32-bit cards.
! SD Card Slot
The computer is equipped with an SD Card slot that can accommodate Secure Digital
flash memory cards with capacities of 8MB, 16MB, 32MB, 64MB and 256MB. SD
cards let the user easily transfer data from devices, such as digital cameras and
Personal Digital Assistants, that use SD Card flash-memory. The cards have a high-
level of security and copy protection features.
! Sound system
This computer supports software sound (AC97 Audio). The sound system is equipped
with AC97 Audio, a CODEC chip, stereo speakers and jacks for headphone and
external microphone. The sound system is equipped with the following:
• Stereo speakers
• Volume control knob
• Headphone jack
• External microphone jack
• Line in/out jack

1.1 Features 1 Hardware Overview
Satellite 1400/2400 Series Maintenance Manual (960-364/365) 1-5
! Video out
This video-out mini-jack enables transfer of NTSC or PAL data (video and right/left
audio) to external devices such as a TV.
! Internet button
This button launches an Internet browser. When the computer is powered off, this
button automatically boots up the system and launches an Internet browser.
! TOSHIBA Console button
Press this button to launch an application automatically. The default is TOSHIBA
Console.
! Internal modem
The internal modem is equipped as a modem daughter card (MDC).
The internal modem provides capability for data and fax communication and supports
ITU-TV.90. For data reception it operates at 56,000bps and for data transmission it
operates at 33,600bps. For fax transmission it operates at 14,400bps. The speed of
data transfer and fax depends on analog telephone line conditions. It has an RJ11
modem jack for connecting to a telephone line.

1 Hardware Overview 1.1 Features
1-6 Satellite 1400/2400 Series Maintenance Manual (960-364/365)
The computer is shown in figure 1-1. The system unit configuration is shown in figure 1-2.
Figure 1-1 Front of the computer
