Toshiba W7 DN-57442-006 User manual

ADJUSTABLE SPEED DRIVES
W7 DN-57442-006
INSTALLATION & OPERATION MANUAL
June, 2020

Document Number: 57442-006
Date: June, 2020
W7 ASD
Installation and Operation Manual

Introduction
Congratulations on the purchase of the new W7 Adjustable Speed Drive!
The W7 Adjustable Speed Drive (ASD) is an 18-pulse PWM drive designed for use with 3-phase
AC induction motors. The 18-pulse design includes an 18-pulse input diode bridge rectifier
combined with an integral phase shifting transformer.
The drive has been designed with an 18-pulse front end to assist in the compliance of the
harmonic distortion limits of standard IEEE 519 1992 at the point of common coupling.
The W7 ASD is ideally suited to drive variable torque loads. Toshiba's technology, quality, and
reliability enables the motor to develop high torque and provide compensation for motor slip,
which results in smooth, quick starts and highly efficient operation. The W7 ASD uses digitally-
controlled pulse width modulation. The programmable functions may be accessed via the easy-
to-use menu. These features, combined with Toshiba's high-performance software, delivers
unparalleled motor control and reliability.
The W7 ASD is a very powerful tool, yet surprisingly simple to operate. The W7 ASD has an
easy-to-read LCD screen that provides easy access to the many monitoring and programming
features of the W7 ASD. The motor control software is menu-driven, which allows for easy
access to the motor control parameters and quick changes when required.
To maximize the abilities of your new W7 ASD, a working familiarity with this manual will be
required. This manual has been prepared for the ASD installer, user, and maintenance
personnel. This manual may also be used as a reference guide or for training. With this in mind,
use this manual to develop a system familiarity before attempting to install or operate the device.

About This Manual
This manual was written by the Toshiba Technical Publications Group. This group is tasked
with providing technical documentation for the W7 ASD. Every effort has been made to provide
accurate and concise information to you, our customer.
At Toshiba we’re continuously striving for better ways to meet the constantly changing needs of
our customers. E-mail your comments, questions, or concerns about this publication to
[e-mail].
Manual’s Purpose and Scope
This manual provides information on how to safely install, operate, perform maintenance, and
dispose of your W7 ASD. The information provided in this manual is applicable to the W7 ASD
family.
In our continuing effort to improve the W7 ASD, Toshiba has increased the available typeforms of
the W7 ASD family. The suffix B has been added to the part number of the newly added system
types.
System operation and functionality are the same for both system types. Throughout this manual,
unless otherwise specified, the W7 ASD and the W7B ASD will be referred to as
W7 ASD.
This operation manual provides information on the various features and functions of this powerful
cost-saving device, including
• Installation,
• System operation,
• Configuration and menu options, and
• Mechanical and electrical specifications.
Included is a section on general safety instructions that describe the warning labels and symbols
that are used. Read the manual completely before installing, operating, performing maintenance, or
disposing of this equipment.
This manual and the accompanying drawings should be considered a permanent part of the
equipment and should be readily available for reference and review. The ASD drawings received
with the W7 system supersedes schematic references contained in this manual.
Dimensions shown in the manual are in metric and/or the English equivalent.
Because of our commitment to continuous improvement, Toshiba International Corporation
reserves the right, without prior notice, to update information, make product changes, or to
discontinue any product or service identified in this publication.
Toshiba International Corporation (TIC) shall not be liable for direct, indirect, special, or
consequential damages resulting from the use of the information contained within this manual.
This manual is copyrighted. No part of this manual may be photocopied or reproduced in any form
without the prior written consent of Toshiba International Corporation.
© Copyright 2020 Toshiba International Corporation.
TOSHIBA ® is a registered trademark of Toshiba Corporation. All other product or trade references
appearing in this manual are registered trademarks of their respective owners.
All rights reserved.
Printed in the U.S.A.

Contacting Toshiba’s Customer Support
Center
Toshiba’s Customer Support Center can be contacted to obtain help in resolving any Adjustable
Speed Drive system problem that you may experience or to provide application information.
The Customer Support Center is open from 8 a.m. to 5 p.m. (CST), Monday through Friday. The
Center’s toll free number is US [phone]/Fax [phone] CAN [phone] MEX 01
[phone]. For after-hours support follow the directions in the outgoing message when calling.
To obtain help in resolving system problems specific to the W7 ASD, contact the Water Wastewater
Group by calling the Support Center number listed above.
You may also contact Toshiba by writing to:
Toshiba International Corporation
13131 West Little York Road
Houston, Texas 77041-9990
Attn.: Water Wastewater Group
For further information on Toshiba’s products and services, please visit our web site at
www.toshiba.com/tic/.
TOSHIBA INTERNATIONAL CORPORATION
W7 Adjustable Speed Drive
Complete the following information and retain for your records.
Model Number: ______________________________________________________________________
Serial Number:______________________________________________________________________
Project Number (if applicable):__________________________________________________________
Date of Installation:__________________________________________________________________
Inspected By:______________________________________________________________________
Name of Application:_________________________________________________________________

Important Notice
The instructions contained in this manual are not intended to cover all details or variations in equipment
types. Nor may it provide for every possible contingency concerning the installation, operations, or
maintenance of this equipment. Should additional information be required, contact the Toshiba Customer
Support Center.
The contents of this manual shall not become a part of or modify any prior or existing agreement,
commitment, or relationship. The sales contract contains the entire obligation of Toshiba International
Corporation. The warranty contained in the contract between the parties is the sole warranty of Toshiba
International Corporation and any statements contained herein do not create new warranties or modify the
existing warranty.
Any electrical or mechanical modifications to this equipment without the prior written consent of
Toshiba International Corporation may void all warranties and may void the UL/CSA listing or other
safety certifications. Unauthorized modifications may also result in a safety hazard or equipment
damage.
Misuse of this equipment could result in injury and/or equipment damage. In no event will Toshiba
International Corporation be responsible or liable for direct, indirect, special, or consequential
damage or injury that may result from the use or misuse of this equipment.
Warranty Information
Toshiba Industrial Corporation (TIC) warrants that the received goods will be free of defects in materials
and workmanship.
The complete Toshiba warranty for this equipment is located at the Toshiba.com/tic website.
Activating the TIC Warranty
To activate the TIC warranty for the received equipment go the Toshiba General Warranty & Product
Registration site listed below:
https://www.toshiba.com/tic/service-warranty/general-warranty-product-registration.
Complete all of the required fields of the form and click Submit.
A confirmation of the enacted warranty will be mailed to the registered contact entity.

Table of Contents
https://www.toshiba.com/tic/ i
Table of Contents
W7B ASD Installation & Operation Manual
General Safety Information .....................................................................................................1
Safety Alert Symbol ........................................................................................................... 1
Signal Words .....................................................................................................................1
Special Symbols ................................................................................................................1
Equipment Warning Labels ............................................................................................... 1
Qualified Personnel ........................................................................................................... 2
Equipment Inspection ........................................................................................................ 2
Handling and Storage ........................................................................................................ 2
Disposal .............................................................................................................................3
Installation Precautions ........................................................................................................... 3
Location and Ambient Requirements ................................................................................ 3
Mounting Requirements ....................................................................................................4
Conductor Requirements and Grounding .......................................................................... 4
Power Connections ........................................................................................................... 4
Protection .......................................................................................................................... 4
System Integration Precautions .............................................................................................. 5
Personnel Protection ......................................................................................................... 5
System Setup Requirements .............................................................................................6
Operational and Maintenance Precautions ........................................................................... 7
Service Life Information ..................................................................................................... 8
CE Directive ............................................................................................................................... 8
EMC Installation Guidelines .............................................................................................. 8
General EMC Guidelines for Compliance .......................................................................... 9
Motor Characteristics ............................................................................................................. 11
Motor Autotuning ............................................................................................................. 11
Pulse Width Modulation Operation .................................................................................. 11
Low-Speed Operation ...................................................................................................... 11
Overload Protection Adjustment ...................................................................................... 11
Operation Above 60 Hz ...................................................................................................11
Power Factor Correction .................................................................................................. 11
Light Load Conditions ...................................................................................................... 11
Motor Braking ..................................................................................................................11
ASD Characteristics ................................................................................................................. 12
Over-Current Protection ..................................................................................................12
ASD Capacity .................................................................................................................. 12
W7B ASD Installation & Operation Manual

Table of Contents
W7B ASD Installation & Operation Manual
ii https://www.toshiba.com/tic/
Installation and Connections ................................................................................................. 13
Installation Notes .............................................................................................................13
Mounting the ASD ........................................................................................................... 14
Connecting the ASD ........................................................................................................14
Lead Length Specifications ............................................................................................. 15
I/O and Control ................................................................................................................17
ASD Control ..................................................................................................................... 21
Typical Connection Diagram ...........................................................................................24
Electronic Operator Interface ................................................................................................ 25
EOI Operation ..................................................................................................................25
Front Panel Indicators/Control ......................................................................................... 26
EOI Remote Mounting ..................................................................................................... 27
System Operation ................................................................................................................... 30
Startup Wizard .................................................................................................................30
Operation (Hand) ............................................................................................................. 30
Default Setting Changes .................................................................................................. 30
System Configuration and Menu Options ........................................................................... 32
Root Menus .....................................................................................................................32
Frequency Command Screen .......................................................................................... 32
Monitor Screen ................................................................................................................ 33
Program Screen .............................................................................................................. 34
Program Menu Navigation ............................................................................................... 35
Startup Wizard Requirements ............................................................................................... 47
Direct Access Parameter Information ................................................................................... 51
Direct Access Parameters/Numbers ............................................................................... 51
Alarms, Trips, and Troubleshooting ................................................................................... 177
Alarms and Trips ........................................................................................................... 177
Enclosure Dimensions and Weight Information ............................................................... 187
Current/Voltage Specifications ........................................................................................... 194
Cable/Terminal Specifications ............................................................................................. 196
Spare Parts Listing ................................................................................................................ 200

https://www.toshiba.com/tic/ 1
Safety Information and Precautions
W7B ASD Installation & Operation Manual
General Safety Information
DO NOT attempt to install, operate, maintain, or
dispose of this equipment until you have read and
understood all of the product safety information and
directions that are contained in this manual.
Safety Alert Symbol
The Safety Alert Symbol is comprised of an
equilateral triangle enclosing an exclamation
mark. This indicates that a potential personal
injury hazard exists.
Signal Words
Listed below are the signal words that are used
throughout this manual followed by their
descriptions and associated symbols. When the
words DANGER, WARNING, and CAUTION are
used in this manual, they will be followed by
important safety information that must be carefully
followed.
The word DANGER
preceded by the safety
alert symbol indicates that an imminently
hazardous situation exists that, if not avoided or if
instructions are not followed precisely, will result in
serious injury to personnel or loss of life.
The word WARNING
preceded by the safety
alert symbol indicates that a potentially hazardous
situation exists that, if not avoided or if instructions
are not followed precisely, could result in serious
injury to personnel or loss of life.
The word CAUTION
preceded by the safety
alert symbol indicates that a potentially hazardous
situation exists that, if not avoided or if instructions
are not followed precisely, may result in minor or
moderate injury.
The word CAUTION
without the safety alert
symbol indicates a potentially hazardous situation
exists that, if not avoided or if instructions are not
followed precisely, may result in equipment and
property damage.
Special Symbols
To identify special hazards, other symbols may
appear in conjunction with the DANGER,
WARNING, and CAUTION signal words. These
symbols indicate areas that require special and/or
strict adherence to the procedures to prevent
serious injury to personnel or loss of life.
Electrical Hazard Symbol
A symbol that is comprised of an equilateral
triangle enclosing a lightning bolt indicates a
hazard of injury from electrical shock or burn.
Explosion Hazard Symbol
A symbol that is comprised of an equilateral
triangle enclosing an explosion indicates a
hazard of injury from exploding parts.
Equipment Warning Labels
DO NOT attempt to install, operate, perform
maintenance, or dispose of this equipment until you
have read and understood all of the product labels
and user directions that are contained in this
manual.
Warning labels that are attached to the equipment
will include the exclamation mark within a triangle.
DO NOT remove or cover any of these labels. If the
labels are damaged or if additional labels are
required, contact the TIC Customer Support Center
for additional labels.
Labels attached to the equipment are there to
provide useful information or to indicate an
imminently hazardous situation that may result in
serious injury, severe property and equipment
damage, or loss of life if safe procedures or
methods are not followed as outlined in this
manual.
Danger Safety Alert Symbol
The word DANGER preceded by
the safety alert symbol indicates
that an imminently hazardous
situation exists that, if not
avoided, will result in serious
injury to personnel or loss of life.
DANGER
WARNING
CAUTION
CAUTION
HAZARDOUS VOLTAGE
- Ground equipment
- Before servicing:
- Remove all power
- Wait 10 minutes
- Verify no voltage is present
- Close panel after servicing
Failure to comply will result
in death or serious injury
DANGER

2https://www.toshiba.com/tic/
Safety Information and Precautions
W7B ASD Installation & Operation Manual
Emergency Off Symbol
The words EMERGENCY OFF
enclosed within a circle indicate the
location on the exterior of the
equipment that an emergency off
means is available.
Manual Symbol
The manual symbol indicates that
the user shall read and understand
the Installation and Operation
manual before attempting to install,
operate, perform maintenance, or
dispose of this equipment.
Qualified Personnel
Installation, operation, and maintenance shall be
performed by Qualified Personnel Only. A
Qualified Person is one that has the skills and
knowledge relating to the construction, installation,
operation, and maintenance of the electrical
equipment and has received safety training on the
hazards involved (refer to the latest edition of NFPA
70E for additional safety requirements).
Qualified Personnel shall:
• Have carefully read the entire operation
manual.
• Be familiar with the construction and function
of the ASD, the equipment being driven, and
the hazards involved.
• Be able to recognize and properly address
hazards associated with the application of
motor-driven equipment.
• Be trained and authorized to safely energize,
de-energize, ground, lockout/tagout circuits and
equipment, and clear faults in accordance with
established safety practices.
• Be trained in the proper care and use of
protective equipment such as safety shoes,
rubber gloves, hard hats, safety glasses, face
shields, arc flash clothing, etc., in accordance
with established safety practices.
For additional information on workplace safety, visit
www.osha.gov.
Equipment Inspection
• Upon receipt of the equipment, inspect the
packaging and equipment for shipping
damage.
• Carefully unpack the equipment and check
for parts that may have been damaged during
shipping, missing parts, or concealed damage.
If any discrepancies are discovered, it should
be noted with the carrier prior to accepting the
shipment, if possible. File a claim with the
carrier if necessary and immediately notify the
TIC Customer Support Center.
•DO NOT install the ASD if it is damaged or if
it is missing any component(s).
• Ensure that the rated capacity and the model
number specified on the nameplate conform to
the order specifications.
• Modification of this equipment is dangerous
and is to be performed by factory-trained
personnel. When modifications are required,
contact the TIC Customer Support Center.
• Inspections may be required after moving
equipment.
• Contact the TIC Customer Support Center to
report discrepancies or for assistance if
required.
Handling and Storage
• Use proper lifting techniques when moving
the ASD; including properly sizing up the load,
getting assistance, and using a forklift if
required.
G
S
T
O
P
R
E
N
E
M
E
C
Y

https://www.toshiba.com/tic/ 3
Safety Information and Precautions
W7B ASD Installation & Operation Manual
• Store in a well-ventilated covered location
and preferably in the original carton if the
equipment will not be used upon receipt.
• Store in a cool, clean, and dry location. Avoid
storage locations with extreme temperatures,
rapid temperature changes, high humidity,
moisture, dust, corrosive gases, or metal
particles.
• The storage temperature range of the W7B
ASD is 14° to 131° F (-10° to 55° C).
•DO NOT store the unit in places that are
exposed to outside weather conditions (i.e.,
wind, rain, snow, etc.).
• Store in an upright position.
Disposal
Never dispose of electrical components via
incineration. Contact your state environmental
agency for details on disposal of electrical
components and packaging in your area.
Installation Precautions
Location and Ambient
Requirements
• The W7B ASD is intended for permanent
installations only.
• The W7B ASD is commercial in design. The
equipment is not intended for use in a
residential environment at any time.
• Installation should conform to the National
Electrical Code — Article 110 (NEC)
(
Requirements For Electrical Installations ), all
regulations of the Occupational Safety and
Health Administration, and any other applicable
national, regional, or industry codes and
standards.
Note: For all references to the National Electrical
Code (NEC), see the latest release of the National
Electrical Code.
• Select a mounting location that is easily
accessible, has adequate personnel working
space, and adequate illumination for
adjustment, inspection, and maintenance of the
equipment (refer to NEC Article 110-13).
•DO NOT mount the ASD in a location that
would produce catastrophic results should it
become dislodged from its mounting location
(equipment damage or injury).
•DO NOT mount the ASD in a location that
would allow it to be exposed to flammable
chemicals or gases, water, solvents, or other
fluids.
• Avoid installation in areas where vibration,
heat, humidity, dust, fibers, metal particles,
explosive/corrosive mists or gases, or sources
of electrical noise are present.
• The installation location shall not be exposed
to direct sunlight.
• Allow proper clearance spaces for
installation. DO NOT obstruct the ventilation
openings. Refer to the section titled Installation
and Connections on pg. 13 for additional
information on ventilation requirements.
• The ambient operating temperature range of
the W7B ASD is 14° to 104° F (-10° to 40° C).

4https://www.toshiba.com/tic/
Safety Information and Precautions
W7B ASD Installation & Operation Manual
• See the section titled Installation and
Connections on pg. 13 for additional
information on installing the drive.
Mounting Requirements
•OnlyQualified Personnel should install this
equipment.
• Install the unit in a secure and upright
position in a well-ventilated area.
• As a minimum, the installation of the
equipment should conform to the National
Electrical Code — Article 110 (NEC), OSHA, as
well as any other applicable national, regional,
or industry codes and standards.
• Installation practices shall conform to the
latest revision of NFPA 70E Electrical Safety
Requirements for Employee Workplaces.
• It is the responsibility of the ASD installer/
maintenance personnel to ensure that the unit
is installed into an enclosure that will protect
personnel against electric shock.
Conductor Requirements and
Grounding
• Use separate metal conduits for routing the
input power, output power, and control circuits.
• A separate ground cable should be run
inside the conduit with the input power, output
power, and control circuits.
•DO NOT connect CC to earth ground.
• Always ground the unit to prevent electrical
shock and to help reduce electrical noise.
• It is the responsibility of the ASD installer/
maintenance personnel to provide proper
grounding and branch circuit protection in
accordance with the National Electrical Code
and any applicable local codes.
— The Metal Of Conduit Is
Not An Acceptable Ground —
Power Connections
• Turn off and lock out/tag out all power
sources before proceeding to connect the
power wiring to the equipment.
• After ensuring that all power sources are
turned off and isolated in accordance with
established lock out/tag out procedures,
connect the 3-phase power source wiring of the
correct voltage to the correct input terminals
and connect the output terminals to a motor of
the correct voltage and type for the application
(refer to NEC Article 300 – Wiring Methods and
Article 310 – Conductors For General Wiring).
Size the branch circuit conductors in
accordance with NEC Table 310.16.
• Adhere to the recommended conductor sizes
listed in the section titled Cable/Terminal
Specifications on pg. 196. If multiple conductors
are used in parallel for the input or output power
and it is necessary to use separate conduits,
each parallel set shall have its own conduit (i.e.,
place U1, V1, W1, and a ground wire in one
conduit and U2, V2, W2, and a ground wire in
another) (refer to NEC Article 300.20 and
Article 310.4). National and local electrical
codes should be referenced if three or more
power conductors are run in the same conduit
(refer to NEC Article 310 adjustment factors).
• Ensure that the 3-phase input power is NOT
connected to the output of the ASD. This will
damage the ASD and may cause injury to
personnel.
•DO NOT install the ASD if it is damaged or if
it is missing any component(s).
•DO NOT connect resistors across terminals
P
A – PC or PO – PC. This may cause a fire.
• Ensure the phase sequence is correct and
the desired direction of motor rotation in the
Bypass mode (if applicable).
• Turn on the power only after attaching and/or
closing the front cover.
Protection
• Ensure that primary protection exists for the
input wiring to the equipment. This protection
must be able to interrupt the available fault
WARNING
DANGER

https://www.toshiba.com/tic/ 5
Safety Information and Precautions
W7B ASD Installation & Operation Manual
current from the power line. The equipment
may or may not be equipped with an input
disconnect (option).
• All cable entry openings must be sealed to
reduce the risk of entry by vermin and to allow
for maximum cooling efficiency.
• Follow all warnings and precautions and DO
NOT exceed equipment ratings.
• If using multiple motors, provide separate
overload protection for each motor and use V/f
control.
• It is the responsibility of the ASD installer/
maintenance personnel to set up the
Emergency Off braking system of the ASD. The
function of the Emergency Off braking system
is to remove output power from the drive in the
event of an emergency. A supplemental
braking system may also be engaged in the
event of an emergency. For additional
information on braking systems, see DC
Injection Braking on pg. 99.
Note: A supplemental emergency stopping system
should be used with the ASD. Emergency stopping
should not be a task of the ASD alone.
• Ear protection is required for noise levels
exceeding 80 dB (contact TIC to request the
acoustic noise levels for units not listed below).
• Where residual current operated protective
device (RCD) is used for protection in case of
direct or indirect contact, only RCD of type B is
allowed on the supply side of this Electronic
Equipment (EE). Otherwise, another protective
measure shall be applied, such as separation
of the EE from the environment by double or
reinforced insulation, or isolation of the EE and
the supply system by a transformer. Toshiba
recommends the installation of a 300 mA RCD
type B from ABB, Siemens, or Bender.
System Integration
Precautions
The following precautions are provided as general
guidelines for the setup of the W7B ASD within the
system.
• The W7B ASD is a general-purpose product.
It is a system component only and the system
design should take this into consideration.
Please contact the TIC Customer Support
Center for application-specific information or for
training support.
• The W7B ASD is part of a larger system and
the safe operation of the ASD will depend on
observing certain precautions and performing
proper system integration.
• Improperly designed or improperly installed
system interlocks may render the motor unable
to start or stop on command.
• The failure of ancillary components may
cause intermittent system operation (i.e., the
system may start the motor without warning).
• A detailed system analysis and job safety
analysis should be performed by the systems
designer and/or systems integrator before the
installation of the ASD component. Contact the
TIC Customer Support Center for options
availability and for application-specific system
integration information if required.
Personnel Protection
• Installation, operation, and maintenance
should be performed by Qualified Personnel
Only.
• A thorough understanding of the ASD will be
required before the installation, operation, or
maintenance of the ASD.
• Rotating machinery and live conductors can
be hazardous and shall not come into contact
with personnel. Personnel should be protected
from all rotating machinery and electrical
hazards at all times.
• Insulators, machine guards, and electrical
safeguards may fail or be defeated by the
Table 1. W7B ASD 460-Volt NEMA 1 Acoustic
Noise Levels.
Model Number Approx. Acoustic
Noise (dB)
460 V 20-200 HP
64
575 V 100-200 HP
460 V 250-500 HP
77
575 V 250-400 HP
WARNING

6https://www.toshiba.com/tic/
Safety Information and Precautions
W7B ASD Installation & Operation Manual
purposeful or inadvertent actions of workers.
Insulators, machine guards, and electrical
safeguards are to be inspected (and tested
where possible) at installation and periodically
after installation for potential hazardous
conditions.
•DO NOT allow personnel near rotating
machinery. Warning signs to this effect shall be
posted at or near the machinery.
•DO NOT allow personnel near exposed
electrical conductors. Contact with electrical
conductors can be fatal. Warning signs to this
effect shall be posted at or near the hazard.
• Personal Protection Equipment (PPE) shall
be provided and used to protect employees
from any hazards inherent to system operation.
System Setup Requirements
• When using the ASD as an integral part of a
larger system, it is the responsibility of the
ASD installer/maintenance personnel to ensure
that there is a fail-safe in place (i.e., an
arrangement designed to switch the system to
a safe condition if there is a fault or failure).
• The failure of external or ancillary
components may cause intermittent system
operation (i.e., the system may start the motor
without warning).
• Power factor improvement/correction
capacitors or surge absorbers MUST NOT be
installed on the output of the ASD.
• Use of the built-in system protective features
is highly recommended (i.e., E-Off, Overload
Protection, etc.).
• The operating controls and system status
indicators should be clearly readable and
positioned where the operator can see them
without obstruction.
• Additional warnings and notifications shall be
posted at the equipment installation location as
deemed required by Qualified Personnel.
• System safety features should be designed
and employed into the integrated system in a
manner such that system operation, even in the
event of system failure, will not cause harm or
result in system damage or injury to personnel
(i.e., E-Off, Auto-restart settings, System
Interlocks, etc.)
• The programming setup and system
configuration of the ASD may allow it to start
the motor unexpectedly. A familiarity with the
Auto-restart and the Hand/Auto settings and
function is a requirement to use this product.
• There may be thermal or physical properties,
or ancillary devices integrated into the overall
system that may allow for the ASD to start the
motor without warning. Signs to this effect must
be posted at the equipment installation
location.
• If a secondary magnetic contactor (MC) or
an ASD output disconnect is used between the
ASD and the load, it should be interlocked to
halt the ASD before the secondary contact
opens. If the output contactor is used for
bypass operation it must be interlocked such
that commercial power is never applied to the
ASD output terminals (U, V, W).
• When using an ASD output disconnect, the
ASD and the motor must be stopped before the
disconnect is either opened or closed. Closing
the output disconnect while the 3-phase output
of the ASD is active may result in equipment
damage or injury to personnel.
DANGER
CAUTION

https://www.toshiba.com/tic/ 7
Safety Information and Precautions
W7B ASD Installation & Operation Manual
Operational and
Maintenance Precautions
• Turn off and lock out/tag out the main power,
the control power, and instrumentation
connections before inspecting or servicing the
drive, opening the door of the enclosure, or
connecting/disconnecting the power wiring to
the equipment.
• The capacitors of the ASD maintain a
residual charge for a period of time after turning
the ASD off. The required time for each ASD
typeform is indicated with a cabinet label and
the front door-mounted Charge LED. Wait at
least the minimum time indicated on the
enclosure-mounted label and ensure that the
Charge LED has gone out before opening the
door of the ASD once the ASD power has been
turned off.
• Turn on the power only after attaching (or
closing) the front cover and DO NOT remove or
open the front cover of the ASD when the
power is on.
•DO NOT attempt to disassemble, modify, or
repair the ASD. Call the TIC Customer Support
Center for repair information.
•DO NOT place any objects inside of the ASD.
• If the ASD should emit smoke, or an unusual
odor or sound, turn off the power immediately.
• The heat sink and other components may
become extremely hot to the touch. Allow the
unit to cool before coming in contact with these
items.
• Remove power from the ASD during
extended periods of non-use.
• Ensure that the Run functions (F, R, Preset
Speed, etc.) of the ASD are off before
performing a Reset. The post-reset settings
may allow the ASD to start unexpectedly.
• Retry or Reset settings may allow the motor
to start unexpectedly. Warnings to this effect
should be clearly posted near the ASD and the
motor (see pg. 107 for more information).
• In the event of a power failure, the motor may
restart after power is restored.
• The system should be inspected periodically
for damaged or improperly functioning parts,
cleanliness, and to ensure that the connectors
are tightened securely.
DO NOT install, operate, perform maintenance, or
dispose of this equipment until you have read and
understood all of the product warnings and user
directions. Failure to do so may result in equipment
damage, operator injury, or loss of life.
WARNING

8https://www.toshiba.com/tic/
Safety Information and Precautions
W7B ASD Installation & Operation Manual
Service Life Information
CE Directive
In addition to local and regional safety
requirements, the Electromagnetic Compatibility
(EMC) Directive and the Low-Voltage Directive
make it obligatory to put the European Conformity
(CE) certification mark on all relevant products
placed in the European market. It is the
responsibility of the manufacturer to ensure that this
mark is visible on its final products.
Although ASDs are not subject to the EMC
Directive because they are used in combination
with other machinery, the CE mark must be placed
on relevant ASDs because they are subject to the
low-voltage directive.
The Low-Voltage Directive provides for the safety of
machines and systems. All W7B ASDs are CE-
marked in accordance with the European Standard
EN 50178 specified by the latest revision of the
Low-Voltage Directive on Electrical Safety, and are
available in the European market.
ASDs are not individually tested to check for CE
compliance because compliance is based on how
the ASD has been installed and connected. The
W7B ASD complies with the CE directive once the
recommended filter has been installed and is
properly wired.
TIC also complies with European standards 60529,
60721-3-3 (environment conditions), and 60068-2-6
(vibrations).
EMC Installation Guidelines
All systems placed on the European market are
required to comply with the latest revision of the
European Conformity directive regarding EMC.
EMC standards are divided into immunity-related
standards and emission-related standards.
Standards are further categorized according to the
operating environment of the ASD.
Part Name Service Life Remarks
Air Filter Environment Dependent Change when necessary
(i.e., dirty, broken, etc.)
Large Capacity Electrolytic
Capacitor 5 Years When not used for extended periods, charge semi-annually.
Cooling Fan 26,000 Hours
CN Connectors 100 Connects/
Disconnects
On-board Relays 500,000 Actuations

https://www.toshiba.com/tic/ 9
Safety Information and Precautions
W7B ASD Installation & Operation Manual
TIC has applied the following standards for systems
deployed in the European market:
General EMC Guidelines for
Compliance
• Input EMI filters to reduce transmission and
radiation noise (Tabl e 3 and Tab l e 4 ).
• Use shielded power and control cables.
• Minimize cable lengths and DO NOT route
them parallel or bind them together.
• Earth the steel cabinet containing the ASD
and the control panel securely.
• Keep control and power cabling separated.
•DO NOT route the input and output cables
together.
• Insert an iron core in shielded cables.
Table 2. EMC Standard s.
Category Subcategory Product Standards Test Standard and Level
Emission
Radiated
EN61800-3
EN55011 Class A Group 1
Conducted EN55011 Class A Group 1
Immunity
Generic Industrial EN 61000-6-2
Electrostatic Discharge EN 61000-4-2
Radiated EN 61000-4-3
Electrical Fast Transient Burst EN 61000-4-4
Lighting Surge EN 61000-4-5
Conducted EN 61000-4-6
Voltage Dip EN 61000-4-11
Table 3. W7B ASD 460-Volt Filter Recommendations.
ASD Model Schaffner Filter FLA @ 40° C EPCOS Filter FLA @ 40° C
4220 FN 258-30-07 30
B84143A0036R105 36
4270 FN 258-42-07 42
4330 FN 258-55-07 55 B84143A0050R105 50
4400
FN 258-75-34
75
B84143A0066R105 66
4500 75
4600 FN 258-100-35 110 B84143A0090R105 90
4750 FN 258-130-35 143 B84143A0120R105 120
410K FN 258-180-40 197 B84143A0150R105 150
412K
FN 258-250-40 275
B84143B0250S020 180
415K B84143B0250S020 250

10 https://www.toshiba.com/tic/
Safety Information and Precautions
W7B ASD Installation & Operation Manual
420K FN 3359-320-99 350 B84143B0320S020 320
425K FN 3359-400-99 438 B84143B0400S020 400
430K
FN 3359-600-99 657
B84143B0600S020
600
440K B84143B0600S020
450K FN 3359-800-99 876 B84143B1000S020
1000460K
FN 3359-1000-99 1095
B84143B1000S020
470K B84143B1000S020
480K FN 3359-1600-99 4600 B84143B1600S020 1600
Table 4. W7B ASD 690-Volt Filter Recommendations.
ASD Model Schaffner Filter FLA @ 40° C EPCOS Filter FLA @ 40° C
620K FN 3359HV-250-28 250 B84143B0250S024 250
625K FN 3359HV-320-99 350
B84143B0400S024 400
630K FN 3359HV-400-99 438
640K FN 3359HV-600-99 657 B84143B0600S024 600
Table 3. W7B ASD 460-Volt Filter Recommendations.
ASD Model Schaffner Filter FLA @ 40° C EPCOS Filter FLA @ 40° C
