Toshiba G7 User manual

G7 Adjustable
Speed Drive
Operation Manual
Document Number: 51546-005
Date: November, 2001

About This Manual
This manual was written by the TOSHIBA Technical Publications Group. This group is tasked with providing
technical documentation for the G7 Adjustable Speed Drive. Every effort has been made to provide accurate and
concise information to you, our customer.
Contacting TOSHIBA’s Customer Support Center
TOSHIBA’s Customer Support Center can be contacted to obtain help in resolving any G7 Adjustable Speed Drive
system problem that you may experience or to provide application information.
The center is open from 8 a.m. to 5 p.m. (CST), Monday through Friday. The Support Center’s toll free number is
US [phone]/Fax [phone] — Canada [phone].
You may also contact TOSHIBA by writing to:
TOSHIBA International Corporation
13131 West Little York Road
Houston, Texas 77041-9990
Attn: ASD Product Manager.
For further information on TOSHIBA’s products and services, please visit our website at TIC.TOSHIBA.COM.

TOSHIBA is a registered trademark of the TOSHIBA Corporation.
All other product or trade references appearing in this manual are registered trademarks of their respective owners.
The information in this manual is subject to change without notice.
TOSHIBA International Corporation shall not be liable for technical or editorial omissions or mistakes in this
manual, nor shall it be liable for incidental or consequential damages resulting from the use of information contained
in this manual.
This manual is copyrighted. No part of this manual may be photocopied or reproduced in any form without the prior
written consent of TOSHIBA International Corporation.
© Copyright 2001 TOSHIBA International Corporation.
All rights reserved.
Printed in the U.S.A.

TOSHIBA INTERNATIONAL CORPORATION
G7 Adjustable Speed Drive
Please complete the Warranty Card supplied with the ASD and return it to Toshiba by prepaid mail. This will
activate the 12 month warranty from the date of installation; but, shall not exceed 18 months from the date of
purchase.
Complete the following information about the drive and retain it for your records.
G7 Model Number:
G7 Serial Number:
Date of Installation:
Inspected By:
Name of Application:

Important Notice
This user manual may not cover all of the variations of ASD applications, nor may it provide information
on every possible contingency concerning installation, programming, operation, or maintenance.
The contents of this user manual shall not become a part of or modify any prior agreement, commitment,
or relationship between the customer and TOSHIBA International Corporation. The sales contract
contains the entire obligation of TOSHIBA International Corporation. The warranty contained in the
contract between the parties is the sole warranty of TOSHIBA International Corporation’s ASD Division
and any statements contained herein do not create new warranties or modify the existing warranty.
Any electrical or mechanical modifications to this equipment without prior written consent of TOSHIBA
International Corporation will void all warranties and may void the UL/CUL listing or other safety
certifications. Unauthorized modifications may also result in equipment damage or personal injury.
This Manual’s Purpose and Scope
This manual provides information that will assist the qualified user in the safe installation, setup,
operation, and disposal of the G7 Adjustable Speed Drive. The information provided in this manual is
applicable to the G7 Adjustable Speed Drive only.
This operation manual provides information on the various features and functions of this powerful cost-
saving device, including
•Installation,
•System operation,
•Configuration and menu options, and
•Mechanical and electrical specifications.

Table of Contents
G7 Operation Manual i
Introduction .............................................................................................................................1
Safety Precautions ...................................................................................................................2
Installation Precautions ......................................................................................................2
Maintenance Precautions ....................................................................................................4
Service Life Information ............................................................................................. 4
Adjustable Speed Drive Inspection ....................................................................................5
Storage ................................................................................................................................5
Disposal ..............................................................................................................................5
Installation and Connections ..................................................................................................6
Installation Notes ................................................................................................................6
Mounting the ASD .............................................................................................................7
Connecting the ASD ...........................................................................................................8
System Grounding .......................................................................................................8
Power Connections .....................................................................................................8
Startup and Test ..........................................................................................................9
I/O and Control .................................................................................................................10
Control Terminal Strip I/O Signals ........................................................................... 11
G7 Options .......................................................................................................................13
CN7 Pinout ................................................................................................................ 14
CNU1A and CNU2A Pinout .....................................................................................15
I/O Circuit Configurations ........................................................................................16
Typical Connection Diagram ...........................................................................................17
Motor Characteristics ...........................................................................................................18
Motor Autotuning .............................................................................................................18
Pulse Width Modulation Operation ..................................................................................18
Low Speed Operation .......................................................................................................18
Overload Protection Adjustment ......................................................................................18
Operation Above 60 Hz ....................................................................................................19
Power Factor Correction ..................................................................................................19
Light Load Conditions ..................................................................................................... 19
Motor/Load Combinations ...............................................................................................19
Load-produced Negative Torque ......................................................................................19
Motor Braking ..................................................................................................................20
Drive Characteristics .............................................................................................................21
Over-current Protection ....................................................................................................21
Drive Capacity .................................................................................................................. 21
AC ASD Derating ............................................................................................................ 22
Thermal Derating ......................................................................................................22
Altitude Derating .......................................................................................................22
Single-phase Derating ...............................................................................................23
Lead Length Specifications ..............................................................................................24

ii G7 Operation Manual
Electronic Operator Interface ..............................................................................................25
EOI Features .....................................................................................................................25
EOI Operation ..................................................................................................................26
System Operation .................................................................................................................. 27
Initial Setup ......................................................................................................................27
Operation ..........................................................................................................................27
Default Setting Changes ................................................................................................... 28
Startup Wizard Requirements ............................................................................................. 29
System Configuration and Menu Options ...........................................................................32
Root Menus ...................................................................................................................... 32
Frequency Command Mode ...................................................................................... 32
Monitor Mode ...........................................................................................................34
Program Mode ...........................................................................................................36
Direct Access Parameter Information .................................................................................48
Direct Access Parameters/Numbers .................................................................................48
Appendix A ........................................................................................................................... 165
Enclosure Dimensions and Conduit Plate Information ..................................................165
Enclosure Dimensions .............................................................................................165
Conduit Plate Information .......................................................................................171
Appendix B ........................................................................................................................... 173
G3-to-G7 Adapter Mounting Plates ...............................................................................173
Appendix C ........................................................................................................................... 174
EOI Dimensions (mounting) ..........................................................................................174
EOI Mounting Hardware Requirements .................................................................175
EOI Extender Cables ...............................................................................................175
Appendix D ........................................................................................................................... 176
Current/Voltage Specifications .......................................................................................176
Appendix E ........................................................................................................................... 179
Cable/Terminal Specifications .......................................................................................179

G7 ASD Operation Manual 1
Introduction
Congratulations on the purchase of the new G7 Adjustable Speed Drive (ASD). The G7 True Torque
Control2Adjustable Speed Drive is a solid-state AC drive that features True Torque Control2. TIC’s
Vector Control Algorithm enables the motor to develop high starting torque and provide compensation
for motor slip, which results in smooth, quick starts and highly efficient operation. The G7 uses digitally-
controlled pulse width modulation. The programmable functions may be accessed via the easy-to-use
menu or via the Direct Access Numbers (see pg. 48). This feature, combined with Toshiba’s high-
performance software, delivers unparalleled motor control and reliability.
The G7 is a very powerful tool, yet surprisingly simple to operate. The G7 has an easy-to-read 240 x 64
pixel graphical LCD screen with a user-friendly Electronic Operator Interface (EOI). The EOI provides
easy access to the many monitoring and programming features of the G7.
The motor control software is menu-driven, which allows for easy access to the motor control parameters
and quick changes when required.
To maximize the abilities of your new G7, a working familiarity with this manual will be required. This
manual has been prepared for the G7 ASD installer, user, and maintenance personnel. This manual may
also be used as a reference guide or for training. With this in mind, use this manual to develop a system
familiarity before attempting to install or operate the device.

2G7 ASD Operation Manual
Safety Precautions
Rotating shafts and electrical equipment can be hazardous. Installation, operation, and maintenance
shall be performed by Qualified Personnel only.
Qualified Personnel shall be:
•Familiar with the construction and function of the ASD, the equipment being driven, and the
hazards involved.
•Trained and authorized to safely clear faults, ground and tag circuits, energize and de-energize
circuits in accordance with established safety practices.
•Trained in the proper care and use of protective equipment in accordance with established safety
practices.
Installation of ASD systems should conform to the 1999 National Electrical Code Article 110
(NEC) (Requirements For Electrical Installations), all regulations of the Occupational Safety and
Health Administration, and any other applicable national, regional, or industry codes and
standards.
•Ensure that the Run functions (F, R, Preset Speed, etc.) of the ASD are off before performing a
Reset. The post-reset settings may allow the ASD to start unexpectedly.
•In the event of a power failure, the motor may restart after power is restored.
•Retry or Reset settings may allow the motor to start unexpectedly. Warnings to this effect
should be clearly posted near the ASD and motor.
DO NOT install, operate, perform maintenance, or dispose of this equipment until you have read
and understood all of the following product warnings and user directions. Failure to do so may result
in equipment damage, operator injury, or death.
Installation Precautions
•Use lockout/tagout procedures on the branch circuit disconnect before installing the ASD.
•Do Not mount the device in a location that would produce catastrophic results if it were to fall
from its mounting location (equipment damage or injury).
•Select a mounting location that is easily accessible by the user.
•Avoid installation in areas where vibration, heat, humidity, dust, metal particles, or high levels
of electrical noise (EMI) are present.
•Do not install the ASD where it may be exposed to flammable chemicals or gasses, water,
solvents, or other fluids.
•Always ground the unit to prevent electrical shock to personnel and to help reduce electrical
noise. The input, output, and control power cables are to be run separately and each shall have
its own ground cable.
Note: Conduit is not an acceptable ground.
•Ensure that the 3 phase input power isNot connected to the output of the ASD. This will destroy
the ASD and may cause injury to personnel.
•Do Not connect resistors across terminals PA –PC or PO –PC. This may cause a fire.
•Do not install the ASD if it is damaged or if it is missing component(s).
•Turn the power on only after attaching the front cover.
DANGER!
DANGER!
