Toshiba A505-S6034 User manual

This product specification is variable and subject to change prior to product launch.
© Copyright 2009 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
atellite A505- 6034 Page 1 of 3
Satellite A505 Detailed Product Specification
1
Model Name
:
A505
-
S60
3
4
Part Number:
PSAT U
-
00L005
UPC:
883 7436 553
Operating System
C1 2
• Genuine Windows
®
7 Home Premium 64-bit
Processor
3
and Graphics
4
• Intel
®
Core™ i7-720QM Processor
o 1.6 GHz (2.8 GHz with Turbo Boost Technology), 6MB L3 Cache
• Mobile Intel
®
HM55 Express Chipset
• NVIDIA
®
GeForce
®
310M with 512MB GDDR3 discrete graphics
memory, plus up to 1755MB dynamically allocated shared graphics
memory using NVIDIA
®
TurboCache™ technology.
o Total Available Graphics memory 2267MB
Memory
5
• Configured with 4GB DDR3 1066MHz (max 8GB)
• 2 main memory slots. Both slots may be occupied.
Storage Drive
6
• 500GB (5400 RPM) erial ATA hard disk drive
• TO HIBA Hard Drive Impact ensor (3D sensor)
Fixed Optical Disk Drive
7
• DVD uperMulti drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (24x), DVD-ROM (8x), DVD-R ( ingle Layer, (8x)),
DVD-R (Double Layer, (6x)), DVD-RW (6x), DVD+R ( ingle
Layer, (8x)), DVD+R (Double Layer, (6x)), DVD+RW (8x), DVD-
RAM (5x)
Display
8
• 16.0” diagonal widescreen TruBrite
®
TFT LCD display at 1366 x 768
native resolution (HD)
o Native support for 720p content
o 16:9 aspect ratio
Sound
• Built-in harman/kardon
®
stereo speakers
• Dolby
®
ound Room
®
Input Devices
• Premium U keyboard with 10 key (black)
• TouchPad™ pointing device with multi-touch control
• TouchPad™ Enable/Disable button
• Media Control Buttons:
o TO HIBA eco utility™ (Energy-saving mode)
o Mute
o Media
o CD/DVD control buttons
o Volume up, volume down
Communications
• Webcam and microphone
• 10/100 Ethernet
• Wi-Fi
®
Wireless networking (802.11b/g/n)
9
Expandability
• ExpressCard™ slot (ExpressCard/34 and ExpressCard/54)
• Memory Card Reader
o ecure Digital, ecure Digital High Capacity, Memory tick™,
Memory tick PRO™, Multi Media Card, xD Picture Card
[shared slot]
Ports
• Video
o RGB (monitor) output port
o HDMI-CEC (REGZA LINK™)
• Audio
o /P DIF output port (shared with headphone port)
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o 4 U B v2.0 ports (3 U B + 1 e ATA/U B combo with U B
leep and Charge
10
)
o RJ-45 LAN port
• ecurity
o lot for ecurity Lock
Physical Description
• Fusion™ Finish in Quantum Black
• Dimensions (W x D x H ): 15.1” x 10.2” x 1.44”/1.61”
• Weight: tarting at 6.48 lbs., depending upon configuration
11
Battery
12
• 6 cell (4000 mAh) Lithium Ion battery pack
• Battery Life Rating (measured by MobileMark™ Productivity 2007)
o Included 6 cell battery: 2 hours, 35 minutes
Power Supply
• 90W (19V x 4.74A) Auto-sensing ,100-240V/50-60Hz AC Adapter
• Dimensions (W x D x H): 5.2” x 2.3” x 1.2”
• Weight: starting at .81 lbs.
Environmental Specifications
• This product is RoH
13
compatible
• Energy tar Qualified
• EPEAT™ Gold Compliant
• EPEAT™ Gold Compliant
1 YEAR STANDARD LIMITED WARRANTY
15
• Includes International Limited Warranty for obtaining service when
traveling outside the United tates.
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as ystemGuard
®
,
On- ite Repair, and erviceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Memory Upgrade
Part Number Description
PA3676U-1M2G Toshiba 2GB DDR3-1066 Memory Module
PA3677U-1M4G Toshiba 4GB DDR3-1066 Memory Module
Power
Part Number Description
PA3717U-1ACA Toshiba 120W Global AC Adapter
PA3534U-1BR Toshiba Primary Li Ion Battery Pack (6 cell)
Operating Non-operating
Temperature
14
5° to 35° C -20° to 60° C
Relative Humidity
(non-condensing)
20% to 80% 10% to 90%
Thermal Gradient 15° C per hour (max) 20° C per hour (max)
Altitude
(relative to sea level)
0 to 3,000 meters 0 to 10,000 meters
hock 10G 60G
Vibration 0.5G 1.0G

This product specification is variable and subject to change prior to product launch.
© Copyright 2009 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
atellite A505- 6034 Page 2 of 3
PA3727U-1BR Toshiba Primary High Capacity Li Ion Battery Pack
(12 cell)
Expansion
Part Number Description
PA3575U-1PRP dynadock U U B Docking tation with DVI/VGA port
PA3686U-1PRP dynadock Wireless U Docking tation with Wireless
U B Adapter
PA3579U-1ETC Toshiba Universal Notebook/Projector tand
Storage
Part Number Description
PA3556U-1M2G Toshiba 2GB U B Hi- peed Flash Drive, ReadyBoost
PA3556U-1M4G Toshiba 4GB U B Hi- peed Flash Drive, ReadyBoost
PA3556U-1M8G Toshiba 8GB U B Hi- peed Flash Drive, ReadyBoost
HDDR320E04XW Toshiba External U B Hard Drive, 320GB (White)
HDDR500E04XL Toshiba External U B Hard Drive, 500GB (Blue)
HDDR640E04XR Toshiba External U B Hard Drive, 640GB (Red)
Protection
Part Number Description
PA3611U-1ETC Toshiba Keyboard Protector
Bluetooth
Part Number Description
PA3573U-1ETA Toshiba Bluetooth Optical Tilt-Wheel Mouse
(Black/ ilver)
PA3573U-1ETB Toshiba Bluetooth Optical Tilt-Wheel Mouse
(Black/Red)
Carrying Case
Part Number Description
PA1446U-1C 6 Toshiba 16" Envoy Ballistic Polyester Carrying Case
(Fits up to 16")
PA1448U-1R 6 Toshiba 16" Envoy Roller Case (Fits up to 16")
Subject to Change
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
ystems, Inc. (“TAI ”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAI dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information ystems, Incorporated (“TAI ”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAI website for resellers: http://sell.toshiba.com
TAI PC upport website: http://pcsupport.toshiba.com
atellite, ConfigFree and ystemGuard are registered trademarks of Toshiba America Information ystems, Inc. and/or Toshiba Corporation. All other
products and names mentioned are the property of their respective owners.
C164-bit computing:
64-bit computing requires that the following hardware and software requirements are met:
- 64-bit Operating ystem
- 64-bit CPU, Chipset and BIO (Basic Input/Output ystem)
- 64-bit Device drivers
- 64-bit applications
Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. ee "Detailed pecs" for more information.
1
Product Series Legal Footnote . The product specifications and configuration information are designed for a product eries. Your particular model may not
have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,
please visit Toshiba's Web site at pcsupport.toshiba.com.
Product Offering Legal Footnote . Toshiba America Information ystems, Inc. reserves the right to modify or withdraw this offer at anytime without notice
2 Operating System. Also see 64-Bit Computing Legal Footnote, if applicable.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN UCH EVENT, YOU WILL NOT BE ABLE TO U E THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURE . Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
ome software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice
3 Processor (Central Processing Unit). Also see 64-Bit Computing Legal Footnote, if applicable.
CPU performance in your computer product may vary from specifications under the following conditions:

This product specification is variable and subject to change prior to product launch.
© Copyright 2009 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
atellite A505- 6034 Page 3 of 3
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product
when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your
computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed pecs.” Contact Toshiba Technical
ervice and upport for more information.
4 Graphics (Graphics Processing Unit). GPU performance may vary depending on product model, design configuration, applications, power management settings and features
utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.
Total Available Graphics Memory is the total of, as applicable, Dedicated Video Memory, ystem Video Memory and hared ystem Memory. hared ystem Memory will vary
depending on system memory size and other factors.
5 Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system
memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications
utilized, system memory size and other factors. Computers configured with a 32-bit operating system can address up to 3GB of system memory. Only computers configured with a
64-bit operating system can address 4 GB or more of system memory.
6 Storage Drive (Internal HDD Capacity). One Gigabyte (GB) means 109 = 1,000,000,000 bytes and One Terabyte (TB) means 1012 = 1,000,000,000,000 bytes using powers of
10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes and 1TB = 240 =
1,099,511,627,776 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the computer includes one or more pre-installed operating
systems, such as Microsoft Operating ystem and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
7 Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical
drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical
media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or
optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.
Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.
8 Display. mall bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is
manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a
period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.
9
Wireless-N. The wireless adapter is based on a draft release version of the IEEE 802.11n specification, and may not be compatible with, or support all features (e.g., security) of,
certain Wi-Fi® equipment
.
10
USB Sleep & Charge. The "U B leep & Charge function" may not work with certain external devices even if they are compliant with the U B specification. In those cases, turn
the power of the computer ON to charge the device.
11 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
12 Battery Life Rating. Measured by MobileMark® 2007. MobileMark is a trademark of the Business Applications Performance Corporation. Rating based on either MobileMark
Productivity 2007 modeling a user performing common mobile office activities or Reader 2007 modeling a user reading documents. ee “Detailed pecifications” for test used.
Details of MobileMark 2007 testing are available at www.bapco.com.Rating is for comparison purposes only, and does not indicate the battery life that will be obtained by any
individual user. Actual battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features
utilized, as well as the natural performance variations produced by the design of individual components. The battery life rating is only achieved on the select models and
configurations tested by Toshiba under the specific test settings at the time of publication and is not an estimate of a system’s battery life under any conditions other than the
specific test settings. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.
13 RoHS. This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous ubstances in electrical and electronic equipment
(RoH ), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoH requirements
and verifies its suppliers' commitment to meeting RoH requirements by conducting component sampling inspections during the product design approval process.
14 Temperature (Environmental) Conditions. All temperature references are approximate and the performance of your computer may vary from specifications even when
operating within the recommended temperature range.
15 Warranty. The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
