Toshiba M780-S7231 User manual

This product specification is variable and subject to change prior to product launch.
© Copyright 2010 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portege M780- 7231 Page 1 of 4
Portege M780 Detailed Product Specification
1
Model Name
:
M780
-
S723
1
Part Numbe
r:
PPM78U
-
0
77
02U
UP
:
8839746327
56
Operating System
1 2
• Genuine Windows
®
7 Professional 64-bit
• Genuine Windows
®
7 Professional 32-bit
Processor
3
and Graphics
4
• Intel
®
Core™ i5-560M Processor
o 2.66 GHz (3.2 GHz with Turbo Boost Technology), 3MB Cache
• Mobile Intel
®
QM57 Express Chipset
• Intel
®
HD Graphics with 64MB-1240MB dynamically allocated shared
graphics memory(64-bit O )
Memory
5
• Configured with 3GB DDR3 1066MHz (max 8GB)
• 2 main memory slots. Both slots occupied.
Storage Drive
6
• 250GB (5400 RPM) erial ATA hard disk drive
Ultra SlimBay Optical Disk Drive
7
• DVD uperMulti drive supporting 11 formats
o Maximum speed and compatibility: CD-ROM (24x), CD-R (24x),
CD-RW (16x), DVD-ROM (8x), DVD-R ( ingle Layer, (8x)),
DVD-R (Double Layer, (4x)), DVD-RW (6x), DVD+R ( ingle
Layer, (8x)), DVD+R (Double Layer, (4x)), DVD+RW (8x), DVD-
RAM (5x)
Display
8
• 12.1” diagonal widescreen LED backlight LCD display at 1280 x 800
native resolution(WXGA) supporting digital pen and digital touch
Sound
• Built-in stereo speakers
Input Devices
• tandard 85-key U keyboard (black)
• Digitizer Pen
• TouchPad™ pointing device
• TouchPad™ Enable/Disable
• Media Control Buttons:
o Toshiba Assist button
o Presentation Button
o Windows ecurity button
o Display Rotation button
o Cross-Functional button
o Power Button Lock
ommunications
• Webcam and microphone
• Modem
9
• 10/100/1000 Ethernet
• Centrino
®
Advanced-N 6200 (Intel
®
802.11a/g/n
10
)
• Bluetooth
®
version 2.1 plus Enhanced Data Rate (EDR)
Expandability
• ExpressCard™ slot
• Memory Card Reader
o ecure Digital, ecure Digital High Capacity, Mini D Card,
Micro D Card, Memory tick™, Memory tick PRO™, Multi
Media Card, XD Card [shared slot]
Ports
• Video
o RGB (monitor) output
• Audio
o Microphone input port
o Headphone output port
• Data
o i.LINK™ IEEE-1394
o 3 U B v2.0 ports
o 2 x U B v2.0 ports
o 1 x e ATA/U B combo port with U B leep and
Charge
11
o RJ-45 LAN port
o RJ-11 modem port
• ecurity
o Trusted Platform Module (TPM v1.2)
o Fingerprint reader
o Reinforced ecurity Cable Lock lot
• upported on optional Toshiba Express Port Replicator II
o U B v2.0 – 6 ports
o Parallel port
o erial port
o RGB port (Monitor out)
o DVI-D
o Audio in
o Audio out
o 10/100/1000 Ethernet port
o AC adapter and security lock supported
Physical Description
• Titanium ilver
• Dimensions (W x D x H ): 12.0” x 9.41” x 1.47”/1.55”
• Weight: tarting at 4.63 lbs., depending upon configuration
12
Battery
13
• 51 Wh (6-cell) Lithium Ion battery pack
• Dimensions (WxDxH): 4.98” x 2.74” x 0.80”
• Weight: starting at 0.71 lbs
• Battery Life Rating (measured by MobileMark™, Productivity 2007)
14
 Included 6-cell battery: 5 hours, 8 minutes
Power Supply
• 75W (15V x 5A) 100-240V AC Adapter
• Dimensions (WxDxH): 5” x 2.01” x 1.20”
• Weight: starting at 0.78 lbs
Toshiba EasyGuard
® 15
• Protect & Fix
o Toshiba PC Health Monitor
o TO HIBA HDD protection (3D Accelerometer)
o TO HIBA hock Protection ystem
o HALT Tested Design
o LCD Cover pressure Resistant Design
o Hinge Design Enhancement
o pill Resistant Keyboard
o TO HIBA PC Diagnostic Tool
• ecure
o Multiple-Level Password Utilities
o Fingerprint Reader (includes software for password and identity
management)
o AuthenTec EntréPad
®
True uite
®
o Infineon TPM oftware Professional Package
o Trusted Platform Module v1.2
o TO HIBA ecure Digital Token Utility
o Reinforced ecurity Cable Lock lot
o Execute Disable Bit
• Connect
o Diversity Antenna
o TO HIBA ConfigFree
®
o Voice-over-IP Ready Design
o TO HIBA Bluetooth
®
tack
o Wireless Communication On/Off witch
• Optimize
o Toshiba Disc Creator
o TO HIBA Device Access Control

This product specification is variable and subject to change prior to product launch.
© Copyright 2010 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portege M780- 7231 Page 2 of 4
o TO HIBA Power Management Extension
o TO HIBA Password Utilities
o TO HIBA Recovery Media Creator
o TO HIBA eco Utility
o TO HIBA Assist
o TO HIBA U B leep and Charge
o TO HIBA Zooming Utility
o FN hortcut Keys
Software
1
16
• Toshiba oftware and Utilities
o Bluetooth tack for Windows by Toshiba
o Electronic User’s Guide
o Hard Disc Drive (HDD) Recovery
o TO HIBA App Place
M
o TO HBIA Assist
o TO HIBA BookPlace™
o TO HIBA Bulletin Board™
o TO HIBA ConfigFree
®
o TO HIBA Disc Creator
o TO HIBA DVD Player
o TO HIBA Face Recognition
o TO HIBA Laptop Checkup
o TO HIBA PC Health Monitor
o TO HIBA Power-saving eco utility™
o TO HIBA Recovery Media Creator
o TO HIBA ReelTime™
o TO HIBA ervice tation
o TO HIBA upervisor Password Utility
o TO HIBA Tablet PC Extension
o TO HIBA Value Added Package
o TO HIBA Web Camera Application
• Third-party oftware
o Microsoft
®
Office tarter 2010
17
o Microsoft
®
Windows Media Player 12
o Microsoft Office OneNote
®
2007
o Microsoft
®
ilverlight™
o Microsoft
®
Live Essentials
 Photo Gallery
 Messenger
 Mail
 Writer
 Movie Maker
o Internet Explorer 8
o Adobe
®
Acrobat
®
Reader
o Google
®
Toolbar
o Google
®
Chrome
o WildTangent
®
Games Console
• pecial Offers and Trial oftware
o Intuit
®
Quickbooks
®
Financial Center
o KidZui™, The Internet for Kids
o NetZero
®
Internet ervice
o Norton Internet ecurity™ 2011 (30-day trial subscription)
o kype
®
o Toshiba Online Backup (30-day trial subscription)
Environmental Specifications
• This product is RoH
18
compatible
• Energy tar 5.0 Qualified
• EPEAT™ Gold Compliant
Operating Non-operating
Temperature
19
5° to 35° C -20° to 65° C
Relative Humidity 20% to 80% 10% to 90%
(non-condensing)
Thermal Gradient 15° C per hour (max) 20° C per hour (max)
Altitude
(relative to sea level)
0 to 3,000 meters 0 to 10,000 meters
hock 10G 60G
Vibration 0.5G 1.0G
3 YEAR STANDARD LIMITED WARRANTY
20
• Includes International Limited Warranty for obtaining service when
traveling outside the United tates.
Service Upgrades and Extensions
Toshiba offers many different enhanced services such as ystemGuard
®
,
On- ite Repair, and erviceExpress to provide additional support to your
notebook PC. For a full description and complete list of programs and
program terms and conditions, please visit www.pcsupport.toshiba.com.
Accessories
For additional and most updated accessories, please visit
www.accessories.toshiba.com
Power
Part Number Description
PA3755U-1ACA Toshiba 75W Global AC Adapter
PA3191U-5BR Toshiba Primary Li Ion Battery Pack (6 Cell)
PA3510U-1BRL Toshiba lice Expansion Li Ion Battery (6 Cell)
Expansion
Part Number Description
PA3680U-1PRP Toshiba Express Port Replicator II
PA3778U-2PRP Toshiba dynadock V Universal Docking tation
PA3575U-1PRP Toshiba dynadock U Universal Docking tation
Security & Protection
Part Number Description
PA3610U-1ETC Toshiba Keyboard Protector
PA1437U-1NC Toshiba Enhanced Protection Case for Portege M7xx
PA1331U-1NC * Toshiba 3 in 1 Tablet PC Leather Portfolio
* Does not accommodate Slice Battery
Storage
Part Number Description
PA1434U-1ETC Toshiba HDD Casing for Ultra lim Bay HDD Adapter
PA3697U-1ETC Toshiba Ultra lim Bay II HDD Adapter
PA3877U-1M4B Toshiba 4GB U B Hi- peed Flash Drive
PA3877U-1M8B Toshiba 8GB U B Hi- peed Flash Drive
PA3877U-1MAB Toshiba 16GB U B Hi- peed Flash Drive
E05A050CAU2XK Toshiba 500GB U B 2.0 Port Hard Drive, Raven Black
E05A075CAU2XL Toshiba 750GB U B 2.0 Port Hard Drive, Liquid Blue
E05A100PBU2XY Toshiba 1TB U B 2.0 Port Hard Drive, atin ilver
Wireless/Bluetooth
Part Number Description
PA3710U-1BTM Toshiba Bluetooth V2.1+EDR U B Nano Adapter
PA3847U-1ETB Toshiba Bluetooth Laser Mouse
Input Devices
Part Number Description
PA3316U-3ETC Toshiba Tablet PC Pen II
PA3317U-2ETC Toshiba Tablet PC Reserve Pen
PA1438U-1ETC Toshiba Tablet Pen Tether
Subject to hange
While Toshiba has made every effort at the time of publication to ensure the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all subject to change without notice. For the most up-to-date product information about your
computer, or to stay current with the various computer software or hardware options, visit Toshiba’s Web site at http://www.pcsupport.toshiba.com

This product specification is variable and subject to change prior to product launch.
© Copyright 2010 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portege M780- 7231 Page 3 of 4
Return Policy
Notwithstanding anything to the contrary in any third party License Agreement or product documentation supplied with your PC, Toshiba America Information
ystems, Inc. (“TAI ”) does not accept the return of component parts, or bundled software, that have been removed from the PC system. Pro-rata refunds on
individual PC components or bundled software, including the operating system, will not be granted. If you wish to return a complete PC system, contact the
TAI dealer where you purchased the product, and comply with the dealer’s standard return policies and procedures.
Toshiba America Information ystems, Incorporated (“TAI ”)
9740 Irvine Boulevard
Irvine CA 92618
ToshibaDirect website: http://www.toshibadirect.com
TAI website for resellers: http://sell.toshiba.com
TAI PC upport website: http://pcsupport.toshiba.com
atellite, ConfigFree and ystemGuard are registered trademarks of Toshiba America Information ystems, Inc. and/or Toshiba Corporation. All other
products and names mentioned are the property of their respective owners.
C164-bit computing:
64-bit computing requires that the following hardware and software requirements are met:
- 64-bit Operating ystem
- 64-bit CPU, Chipset and BIO (Basic Input/Output ystem)
- 64-bit Device drivers
- 64-bit applications
Certain device drivers and/or applications may not be compatible with a 64-bit CPU and therefore may not function properly. ee "Detailed pecs" for more information.
1
Product Series Legal Footnote . The product specifications and configuration information are designed for a product eries. Your particular model may not
have all the features and specifications listed or illustrated. For more detailed information about the features and specifications on your particular model,
please visit Toshiba's Web site at pcsupport.toshiba.com.
Product Offering Legal Footnote . Toshiba America Information ystems, Inc. reserves the right to modify or withdraw this offer at anytime without notice
2 Operating System. Also see 64-Bit Computing Legal Footnote, if applicable.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN UCH EVENT, YOU WILL NOT BE ABLE TO U E THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURE . Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
ome software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Offers. Offer terms, duration and product availability all subject to change without notice
3 Processor ( entral Processing Unit). Also see 64-Bit Computing Legal Footnote, if applicable.
CPU performance in your computer product may vary from specifications under the following conditions:
1. use of certain external peripheral products
2. use of battery power instead of AC power
3. use of certain multimedia, computer generated graphics or video applications
4. use of standard telephone lines or low speed network connections
5. use of complex modeling software, such as high end computer aided design applications
6. use of several applications or functionalities simultaneously
7. use of computer in areas with low air pressure (high altitude >1,000 meters or >3,280 feet above sea level)
8. use of computer at temperatures outside the range of 5°C to 30°C (41°F to 86° F) or >25°C (77°F) at high altitude (all temperature references are
approximate and may vary depending on the specific computer model – please visit the Toshiba website at www.pcsupport.toshiba.com for details).
CPU performance may also vary from specifications due to design configuration.
Under some conditions, your computer product may automatically shut-down. This is a normal protective feature designed to reduce the risk of lost data or damage to the product
when used outside recommended conditions. To avoid risk of lost data, always make back-up copies of data by periodically storing it on an external storage medium. Use your
computer product only under recommended conditions. Read additional restrictions under “Environmental Conditions” in your product “Detailed pecs.” Contact Toshiba Technical
ervice and upport for more information.
4 Graphics (Graphics Processing Unit). GPU performance may vary depending on product model, design configuration, applications, power management settings and features
utilized. GPU performance is only optimized when operating in AC power mode and may decrease considerably when operating in battery power mode.
Total Available Graphics Memory is the total of, as applicable, Dedicated Video Memory, ystem Video Memory and hared ystem Memory. hared ystem Memory will vary
depending on system memory size and other factors.
5 Memory (Main System). Part of the main system memory may be used by the graphics system for graphics performance and therefore reduce the amount of main system
memory available for other computing activities. The amount of main system memory allocated to support graphics may vary depending on the graphics system, applications
utilized, system memory size and other factors. Computers configured with a 32-bit operating system can address up to 3GB of system memory. Only computers configured with a
64-bit operating system can address 4 GB or more of system memory.

This product specification is variable and subject to change prior to product launch.
© Copyright 2010 Toshiba America Information ystems Inc. All Rights reserved.
TAI shall not be liable for damages of any kind for use of this information, which is subject to change without notice.
Portege M780- 7231 Page 4 of 4
6 Storage Drive (Internal HDD apacity). One Gigabyte (GB) means 109 = 1,000,000,000 bytes and One Terabyte (TB) means 1012 = 1,000,000,000,000 bytes using powers of
10. The computer operating system, however, reports storage capacity using powers of 2 for the definition of 1 GB = 230 = 1,073,741,824 bytes and 1TB = 240 =
1,099,511,627,776 bytes, and therefore shows less storage capacity. Available storage capacity will also be less if the computer includes one or more pre-installed operating
systems, such as Microsoft Operating ystem and/or pre-installed software applications, or media content. Actual formatted capacity may vary.
7 Optical Drive. Due to manufacturing and quality variations in third party optical media (e.g., CD or DVD) or optical media players/recorders, in certain cases, your Toshiba optical
drive may not record on certain optical media that bear the applicable logo, or playback optical media recorded by other PCs or optical media recorders. Additionally, certain optical
media recorded on your optical drive may not playback or operate properly on other PCs or optical media players. These problems are not due to any defect in your Toshiba PC or
optical drive. Please refer to your PC's product specification for listing of specific format compatibilities.
Recording or viewing of certain optical media may be limited or prevented in accordance with applicable copy protection standards.
8 Display. mall bright dots may appear on your screen display when you turn on your PC. Your display contains an extremely large number of thin-film transistors (TFT) and is
manufactured using high-precision technology. Any small bright dots that may appear on your display are an intrinsic characteristic of the TFT manufacturing technology. Over a
period of time, and depending on the usage of the computer, the brightness of the screen will deteriorate. This is also an intrinsic characteristic of the screen technology.
When the computer is operated on battery power, the screen with dim and you may not be able to increase the brightness of the screen while on battery power.
9 Modem Speed. Due to FCC limitations, speeds of 53 kbps are the maximum permissible transmission rates during download. Actual data transmission speeds will vary
depending on line conditions.
10
Wireless-N. The wireless adapter is based on a draft release version of the IEEE 802.11n specification, and may not be compatible with, or support all features (e.g., security) of,
certain Wi-Fi® equipment .
11
USB Sleep & harge. The "U B leep & Charge function" may not work with certain external devices even if they are compliant with the U B specification. In those cases, turn
the power of the computer ON to charge the device.
12 Weight. Weight may vary depending on product configuration, vendor components, manufacturing variability and options selected.
13 Battery Life Rating. Measured by MobileMark® 2007. MobileMark is a trademark of the Business Applications Performance Corporation. Rating based on either MobileMark
Productivity 2007 modeling a user performing common mobile office activities or Reader 2007 modeling a user reading documents. ee “Detailed pecifications” for test used.
Details of MobileMark 2007 testing are available at www.bapco.com.Rating is for comparison purposes only, and does not indicate the battery life that will be obtained by any
individual user. Actual battery life may vary considerably from specifications depending on product model, configuration, applications, power management settings and features
utilized, as well as the natural performance variations produced by the design of individual components. The battery life rating is only achieved on the select models and
configurations tested by Toshiba under the specific test settings at the time of publication and is not an estimate of a system’s battery life under any conditions other than the
specific test settings. After a period of time, the battery will lose its ability to perform at maximum capacity and will need to be replaced. This is normal for all batteries.
14 Battery Life - MobileMark™. Measured by MobileMark. MobileMark is a trademark of the Business Applications Performance Corporation.
15 EasyGuard. Toshiba EasyGuard™ technology comprises a number of features some of which may or may not be available on a particular Toshiba notebook depending on the
model selected. ee www.easyguard.toshiba.com for detailed information.
16 Software. Also see 64-Bit Computing Legal Footnote, if applicable.
ome software may differ from its retail version (if available), and may not include user manuals or all program functionality.
Certain Microsoft® software product(s) included with this computer may use technological measures for copy protection. IN UCH EVENT, YOU WILL NOT BE ABLE TO U E THE
PRODUCT IF YOU DO NOT FULLY COMPLY WITH THE PRODUCT ACTIVATION PROCEDURE . Product activation procedures and Microsoft’s privacy policy will be detailed
during initial launch of the product, or upon certain reinstallations of the software product(s) or reconfigurations of the computer, and may be completed by Internet or telephone (toll
charges may apply).
Includes Microsoft® Office 2010 preloaded. Purchase a Product Key to activate a full Microsoft Office 2010 suite.
17 Microsoft Office Starter 2010. Office tarter consists of reduced-functionality versions of Word and Excel with advertising. PowerPoint, Outlook, OneNote, Access and
Publisher are not included.
18 RoHS. This notebook is compatible with European Union Directive 2002/95/EC, Restriction of the use of certain Hazardous ubstances in electrical and electronic equipment
(RoH ), which restricts use of lead, cadmium, mercury, hexavalent chromium, PBB, and PBDE. Toshiba requires its notebook component suppliers to meet RoH requirements
and verifies its suppliers' commitment to meeting RoH requirements by conducting component sampling inspections during the product design approval process.
19 Temperature (Environmental) onditions. All temperature references are approximate and the performance of your computer may vary from specifications even when
operating within the recommended temperature range.
20 Warranty. The terms and conditions of Toshiba’s standard limited warranty are available at www.warranty.toshiba.com.
