TECRA M3
Model (s):
Tecra Mi3-KK301E
Intel®Pentium®M Processor 730-1.6GHz,
14.1”XGATFT, 512MB, 60GB HDD, CDRW/DVD,
Modem, LAN, TPM, Wireless LAN 802.11a/g,
Windows®XP Pro Windows®XP Pro
Processor
Mobile Intel®Pentium®M 730-1.6GHz processor, 533MHz
FSB
L1 Cache 32KB/32KB (instruction/data), L2 Cache 2MB
Operating System
Microsoft®Windows®XP Pro
HDD Pre-installed Image Recovery
Memory
Standard Memory: 1x512MB DDR2, 533MHz
Maximum Memory: 2GB DDR
Expansion Modules: 128MB, 256MB, 512MB, or 1024MB
Hard Disk Drive
60.0 billion bytes (5,400 rpm). 9.5mm height, Enhanced IDE
2.5” (ATA-6),
Optical Drive
Slim Select Bay Combo (CD-RW/DVD-ROM)
Maximum speed:
Read: CD-ROM (24x), DVD-ROM (8x)
Write: CD-R(24x), CD-RW (10x)
ATAPI Interface
Software Decoder: InterVideo WinDVD
Display System
Type: TFT Active Matrix colour LCD display
Size (diagonal): 14.1”TFT
LCD Panel Resolution: 1024x768x16.7 million colours
External Support and Maximum Colour Support:
640x480x16.7 million colours (clean stretch)
800x600x16.7 million colours (clean stretch)
1024x768x16.7 million colours (native resolution)
1280x1024x16.7 million colours (virtual screen)
1600x1200x16.7 million colours (vitual screen)
1920x1440x16.7 million colours (virtual screen)
2048x1536x16.7 million colours (virtual screen)
Graphics Controller
nVIDIA GeForce Go 6200 TE 64M
Video Memory: 64 MB DDR memory
PCI Express 16
2D and 3D Graphics
Sound System
Software Sound 16bit stereo
Analog Devices AD1981B
Built-in stereo speakers, Direct 3D sound, full duplex support,
Sound volume control dial, external MIC port (monaural),
stereo headphone port.
Communication
ModemV.92 Data/56K Fax Modem, Ring wake up resume.
10/100/1000 Integrated EthernetLAN, network boot.
Built-in Wireless LAN (802.11a/g)
Built-in Bluetooth Antenna
Expansion
2 memory slots (one filled with 512MB, can be replaced by
256MB, 512MB or 1 GB) other slot empty.
1 PC Card slot supports one Type II PC Card; supports
Cardbus
1ExpressCard Slot
Ports: SD Card Slot, 1 Parallel, 1 RGB, 1 Docking Interface
(for opt. Advanced Port Replicator III), 1 FIR, 2 USB (2.0), 1
Modem (RJ-11), 1 LAN (RJ-45), 1 IEEE 1394, 1 TV Out (S-
Video), External Mic, Stereo Headphone.
Supported via Advanced Port Replicator III: 1 Parallel, 1
Serial, 1 PS/2 Keyboard, 1 PS/2 Mouse, 4 USB (2.0), 1
Modem (RJ-11), 1 LAN (RJ-45 with LED), 1 Line-in, 1 Line-
out, 1 RGB, 1 IEEE, 1 DVI
Keyboard
Full sized 85 keys with 12 function keys
2.7mm keystroke, 6mm height
Dedicated Windows Keys
Pointing Device
Dual Pointing device – Touchpad + Accupoint
Additional Software
Microsoft Office OneNote 2003
Physical Dimensions
Dimensions: 341mm (W) x 259mm (D)x 31.5mm/34.9 (H)
Weight: 4.99lbs/2.26kg
AC Adapter
75W external Universal AC adaptor input voltage (100 –240V
50/60Hz frequency),(15Vx5A)
Battery
Battery Type: Removable, Rechargeable 6-cell Lithium Ion
(Li-ion) 4700mAh
Battery Life: 4 hours
Recharge Time: 3.0 hours off/ 5-13 hours on
BIOS
ACPI v1.0b, DDC, PnP v1.0a,VESA v2.0, DPMS,
SM BIOS v2.3.4, PCI BIOS Support V2.2.
Security
Cable lock slot, power on password, supervisor password,
TPM – Trusted Platform Module
Environmental Specifications
Temperature: Operating 5°to 35°C (41°to 95°F);
Non Operating –20°to 65°C (-4°to149°F)
Thermal Gradient: Operating 15°C per hr. max;
Non Operating 20°C per hr. max
Relative Humidity: Operating 20% to 80% non-condensing;
Non-Operating: 10% to 90% non-condensing
Altitude (relative to sea level): Operating: -60 to 3,000m.;
Non-Operating: -60 to 10,000m.
Shock: Operating: 10G; Non-Operating 60G
Vibration: Operating 0.5G; Non-Operating: 1G
Canada and InternationalLimited Warranty
The Tecra M3 notebook comes with a three (3) year parts
and labour Limited International Warranty. Note the original
battery is warranted for one year from date of purchase. Pre-
installed software is excluded form TCL standard limited
warranty. For complete details on this warranty program and
other Warranty Programs such as On-site and Next Business
Day Service visit toshiba.ca
Accessories
PA3314U-1PRP Advanced port Replicator III
ACC021 USB FDD Kit
PA3378C-1ACA Universal AC Adaptor
PA3356U-2BAS 6Cell Li-ion Battery Pack
PA3357U-1BAL 12 cell Li-ion Battery Pack
PA3129U-2BAS Slim Select Bay 2nd Battery Pack
PA3091U-1CHG Battery Charger
PA3359U-1DV2 Slim Select Bay DVD Super-Multi Drive
PA3204U-1H60 Slim Select Bay 60GB HDD
PA3230U-1H80 Slim Select Bay 80GB HDD
PA3406U-1HA0 Slim Select Bay 100GB HDD
PA3134U-1ETC Slim Select Bay HDD Adaptor
PA3425U-1BTM Bluetooth Module
Kingston Memory Modules:
•KTT-533D2/128i
•KTT-533D2/256i
•KTT-533D2/512i
•KTT-533D2/1Gi
Part Number/UPC code
PTM30C-KK301E (English)/6-23506-01019-1
PTM30C-KK301EF (French)/ 6-23506-01021-4
iToshiba of Canada Limited Information Systems Group shall
not be liable for damages of any kind for use of this
information, which is subject to change without notice.
Central Processing Unit (“CPU” Performance Disclaimer:
CPU performance in your computer product may vary from
specifications under the following conditions:
•use of certain external peripheral products
•use of battery power instead of AC power
•use of certain multimedia games or videos with special
effects
•use of standard telephone lines or low speed network
connections
•use of complex modeling software, such as high end
computer aided design applications
Toshiba recommends Microsoft® Windows®XP Professional

•use of computer in areas with low air pressure (high
altitude >1,000 meters or >3,280 feet above sea level)
•use of computer at temperatures outside the range of 5°C
to 35°C (41°F to 95°F) or > 25°C (77°F) at high altitude
(all temperature references are approximate).
CPU performance may also vary from specifications due to design
configuration. Under some conditions, your computer product may
automatically shutdown. This is a normal protective feature designed to
reduce the risk of lost data or damage to the product when used outside
recommended conditions. To avoid risk of lost data, always make back-
up copies of data by periodically storing it on an external storage
medium. For optimum performance, use your computer product only
under recommended conditions. Read additional restrictions under
“Environmental Conditions” in your product Resource Guide. Contact
Toshiba Technical Support for more information.
Hard Disk Drive Disclaimer: 1 Gigabyte (GB) means 1000 * 1000 *
1000 = 1,000,000,000 bytes using powers of 10. The computer operating
system, however, reports storage capacity using powers of 2 for the
definition of 1 GB = 1024 * 1024 * 1024 = 1,073,741,824 bytes, and
therefore may show less storage capacity. Available storage capacity will
also be less if the product includes pre-installed operating system and/or
application software. Actual formatted capacity may vary.
TFT Display Disclaimer: Small bright dots may appear on your TFT
display when you turn on your PC. Your display contains an extremely
large number of thin-film transistors (TFT) and is manufactured using
high-precision technology. Any small bright dots that may appear on your
display are an intrinsic characteristic of the TFT manufacturing
technology.
Weight: Weight may vary depending on actual configuration.
Battery: Battery life may vary depending on product model,
configuration, applications, power management settings and features
utilized. Recharge time varies depending on usage. Battery may not
charge while computer is consuming full power. After a period of time,
the battery will lose its ability to perform at maximum capacity and will
need to be replaced. This is normal for all batteries. To purchase a new
battery pack, see the accessories information that shipped with your
computer or visit the Toshiba of Canada website at toshiba.ca/accessories
Subject to Change:
While Toshiba has made every effort at the time of publication to ensure
the accuracy of the information provided herein, product specifications,
configurations, prices, system/component/options availability are all
subject to change without notice. For the most up-to-date product
information about your computer, or to stay current with the various
computer software or hardware options, visit Toshiba’s website at
toshiba.ca/support 6/3/2005 v.2
