Owner's Manual
Integrated High Definition
LCD Television
[OL 0RSTRER M®HD
1Il DOLBY H~ml
DIGITAL I ~

Dear Customer,
Thank you for purchasing this Toshiba LCD TV. This manual will
help you use the many exciting features of your new LCD TV. Before
operating your LCD TV, please read this manual completely, and
keep it nearby for future reference.
CHILD SAFETY:
It Makes A Difference How and Where You Use Your Flat
Panel Display
www.CE.org/safety
Tune Into Safety
• One size does NOT fit all. Follow the manufacturer's recommendations
for the safe installation and use of your flat panel display.
• Carefully read and understand all enclosed instructions for
proper use of this product.
• Don't allow children to climb on or play with furniture and
television sets.
• Don't place flat panel displays on
furniture that can easily be used as
steps, such as a chest of drawers.
• Remember that children can
become excited while watching a
program, especially on a "larger
than life" flat panel display. Care
should be taken to place or install
the display where it cannot be
pushed, pulled over, or knocked down.
• Care should be taken to route all cords and
cables connected to the flat panel display so that they cannot be
pulled or grabbed by curious children.
Wall Mounting: If you decide to wall mount your
flat panel display, always:
• Use a mount that has been recommended by the display
manufacturer and/or listed by an independent laboratory (such
as Ul, CSA, ETl).
• Follow all instructions supplied by the display and wall mount
manufacturers.
• If you have any doubts about your ability to safely install your
flat panel display, contact your retailer about professional
installation.
• Make sure that the wall where you are mounting the display is
appropriate. Some wall mounts are not designed to be mounted
to walls with steel studs or old cinder block construction. If you
are unsure, contact a professional
installer.
• A minimum of two people are
required for installation. Flat panel
displays can be heavy.
Congratulations on your purchase! As you enjoy your
new product, please keep these safety tips in mind:
The Issue
• The home theater entertainment experience is a growing trend
and larger flat panel displays are popular purchases. However,
flat panel displays are not always supported on the proper stands
or installed according to the manufacturer's recommendations.
• Flat panel displays that are
inappropriately situated on dressers,
bookcases, shelves, desks,
speakers, chests or carts may fall
over and cause injury.
TOSHIBA Cares!
• The consumer electronics industry
is committed to making home
entertainment enjoyable and safe.
~
RISK OF ELECTRIC SHOCK 00 NOT
OPEN
The lightning flash with arrowhead symbol, within an
equilateral triangle, is intended to alert the user to the
presence of uninsulated "dangerous voltage" within the
product's enclosure that may be of sufficient magnitude to
constitute a risk of electric shock to persons.
The exclamation point within an equilateral triangle is
intended to alert the user to the presence of important
operating and maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING: If you decide to wall mount this television, always
use a Ul Listed wall bracket appropriate for the size and weight of
this television. The use of any wall bracket other than a Ul Listed
wall bracket appropriate for the size and weight of this television for
wall mounting this television could result in serious bodily injury
and/or property damage. See "Removing the Pedestal Stand" (~
page 5).
Safety Precautions
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC
SHOCK, DO NOT EXPOSE THIS APPLIANCE TO RAIN OR
MOISTURE.
WARNING: TO REDUCE THE RISK OF ELECTRIC
SHOCK,
DO NOT REMOVE COVER (OR BACK).
NO USER·SERVICEABLE PARTS INSIDE. REFER
SERVICING
TO QUALIFIED SERVICE PERSONNEL.
WARNING
To prevent injury, this apparatus must be securely attached to the
floor/wall in accordance with the installation instructions. See item 23
on page 3.
NOTE TO CATV INSTALLERS
This is a reminder to call the CATV system installer's attention to
Article 820-40 of the U.S. NEC, which provides guidelines for proper
grounding and, in particular, specifies that the cable ground shall be
connected to the grounding system of the building, as close to the
point of cable entry as practical. For additional antenna grounding
information, see items 30 and 31 on page 4.
2

Important Safety Instructions
13) Unplug this apparatus during lightning storms or when
unused for long periods of time.
TV top
H~
TV side
25) Never block or cover the slots or openings in the TV cabinet
back, bottom, and sides. Never place the TV:
• on a bed, sofa, rug, or similar
surface;
• too close to drapes, curtains, or
walls; or
• in a confined space such as a
bookcase, built-in cabinet, or any
other place with poor ventilation.
( continued)
24) The apparatus shall not be exposed to dripping or splashing and
that no objects filled with liquids, such as vases, shall be placed
on the apparatus.
23) Always place the TV on the floor or a sturdy, level, stable surface
that can support the weight of the unit. To secure the TV, use
a sturdy strap from the hook(s) on the rear of the TV to a wall
stud, pillar, or other immovable structure. Make sure the strap is
tight, secure, and parallel to the floor.
Sturdy strap (as short as possible)
20) Never modify this equipment. Changes or modifications may
void: a) the warranty, and b) the user's authority to operate
this equipment under the rules of the Federal Communications
Commission.
22) To avoid damage to this product, never place or store the TV in
direct sunlight; hot, humid areas; or areas subject to excessive
dust or vibration.
21) Lh DANGER: RISK OF SERIOUS
I PERSONAL INJURY, DEATH, OR
• EQUIPMENT DAMAGE!
Never place the TV on an unstable
cart, stand, or table. The TV may fall,
causing serious personal injury, death, or
serious damage to the TV.
19) NEVER route the product's power cord inside a wall or similar
enclosed area.
Installation, Care, and Service
Installation
Follow these recommendations and precautions and heed all warnings
when installing your TV:
18) ALWAYS plug the product into an outlet that is located in such
a manner that it can be easily unplugged in case the product
requires service.
17) WARNING:
NEVER expose batteries to excessive heat such as sunshine,
fire, or the like.
unless the blades can be inserted completely to prevent
blade exposure.
• To prevent electric shock, match wide blade of plug to wide
slot; fully insert.
16) WARNING:
To prevent the spread of fire, keep candles or other open flames
away from this product at all times.
~
';;:;7"l
r';r 0'
~ ~
-----_.
14) Refer all servicing to qualified service personnel. Servicing
is required when the apparatus has been damaged in any way,
such as power-supply cord or plug is damaged, liquid has been
spilled or objects have fallen into the apparatus, the apparatus
has been exposed to rain or moisture, does not operate
normally, or has been dropped.
Additional Safety Precautions
14a) CAUTION: If the TV is dropped and the cabinet or enclosure
surface has been damaged or the TV does not operate normally,
take the following precautions:
• ALWAYS turn off the TV and unplug the power cord to avoid
possible electric shock or fire.
• NEVER allow your body to come in contact with any broken
glass or liquid from the damaged television. The LCD panel
inside the TV contains glass and a toxic liquid. If the liquid
comes in contact with your mouth or eyes, or your skin is
cut by broken glass, rinse the affected area thoroughly with
water and consult your doctor.
• ALWAYS contact a service technician to inspect the TV any
time it has been damaged or dropped.
--_.
15) CAUTION:
• To reduce the risk of electric shock, do not use the polarized
plug with an extension cord, receptacle, or other outlet
9) Do not defeat the safety purpose of the Wd
polarized or grounding type plug. AIe blade ~
polarized plug has two blades with one wider~~.~.. . ~
than the other. A grounding type plug has '\\ ~
two blades and a third grounding prong. The
wide blade or the third prong are provided
for your safety. If the provided plug does not fit into your outlet,
consult an electrician for replacement of the obsolete outlet.
12) Use only with the cart, stand, tripod, bracket, Cl)
or table specified by the manufacturer, or B1
sold with the apparatus. When a cart is used, • ~
use caution when moving the cart/apparatus .. 1
combination to avoid injury from tip-over. ~ ~-a
8) Do not install near any heat sources such as radiators, heat
registers, stoves, or other apparatus (including amplifiers) that
produce heat.
1) Read these instructions.
2) Keep these instructions.
3) Heed all warnings.
4) Follow all instructions.
5) Do not use this apparatus near water.
---"----------,-~----------_._-_._----_._---_._-------------------
6) Clean only with dry cloth.
._--------
7) Do not block any ventilation openings. Install in accordance
with the manufacturer's instructions.
10) Protect the power cord from being walked on
or pinched, particularly at plugs, convenience ~
receptacles, and the point where they exit from ~
the apparatus. '.~ .
---
11) Only use attachments/accessories specified by the
manufacturer.
3

28) Never overload wall outlets and extension cords.
------ ----~ --- --~-----
29) Always operate this equipment from a 120 VAC, 60 Hz power
source only.
--------------- ----- --
30) Always make sure the antenna system is properly grounded to
provide adequate protection against voltage surges and built-up
static charges (see Section 810 of the National Electric Code).
WARNING:
RISK OF ElECTRIC SHOCK!
WARNING:
RISK OF ELECTRIC SHOCK!
40) &
Service
Never attempt to service the TV yourself. Opening and removing
the covers may expose you to dangerous voltage or other
hazards. Failure to follow this WARNING may result in death or
serious injury. Refer all servicing not specified in this manual to
a Toshiba Authorized Service Center.
Never strike the screen with a sharp or
heavy object.
._------_._,-------_ •. _-----_ .. _ .. __ ._-_ .. _..• ~--_._--.~--------_ .. _-_._--_._, .. _-,._---~.
39) • The LCD screen of this product can be damaged by
ultraviolet radiation from the sun. When selecting a location
for the television, avoid locations where the screen may be
exposed to direct sunlight, such as in front of a window.
• Never touch, press, or place anything on the LCD screen.
These actions will damage the LCD screen. If you need to
clean the LCD screen, follow the instructions in item 33 on
this page.
Never spill liquids or push objects of any kind into the TV
cabinet slots.
~------------
38) LLDANGER: RISK OF SERIOUS
I PERSONAL INJURY OR
• DEATH!
34) &
35) While it is thundering, do not touch the connecting cables or
apparatus.
._---
36) For added protection of your TV from lightning and power
surges, always unplug the power cord and disconnect the
antenna from the TV if you leave the TV unattended or unused
for long periods of time.
._--_ .. _----,-----_._--~---_."-,---, .. _-,---_._,---_.---_._--_._-----~_.,_._----_._. __ .,--
37) ALWAYS unplug the TV to completely disconnect from mains
power. When the TV is turned off using the on/off switch, it is
not completely disconnected from power and a minute amount
of current is still consumed.
Grounding conductors
(NEC Section 810-21)
/ Antenna lead-in wire
Antenna discharge unit
(NEC Section 810-20)
__ Power service grounding electrode
system (NEG Art 250 Part-H)
Electric service equipment
31) 1\ DANGER: RISK OF SERIOUS PERSONAL
~ INJURY OR DEATH!
• Use extreme care to make sure you are never in a position
where your body (or any item you are in contact with, such
as a ladder or screwdriver) can accidentally touch overhead
power lines. Never locate the antenna near overhead power
lines or other electrical circuits.
• Never attempt to install any of the following during lightning
activity: a) an antenna system; or b) cables, wires, or any
home theater component connected to an antenna or phone
system.
The slots and openings are provided to protect the TV from
overheating and to help maintain reliable operation of the TV. Leave
a space of at least 4 (four) inches around the TV.
26) Always place the back of the television at least four (4) inches
away from any vertical surface (such as a wall) to allow proper
ventilation.
27) Never allow anything to rest on or roll over the power cord, and
never place the TV where the power cord is subject to wear or
abuse.
Care
For better performance and safer operation of your TOSHIBA TV,
follow these recommendations and precautions:
32) If you use the TV in a room whose temperature is 32 OF (0 °C)
or below, the picture brightness may vary until the LCD warms
up. This is not a sign of malfunction.
--------~------ ---
33) Always unplug the TV before cleaning. Gently wipe the display
panel surface (the TV screen) using
,-
a dry, soft cloth only (cotton, flannel, "
etc.). A hard cloth may damage the I§~
surface of the panel. Avoid contact ~ " rill
with alcohol, thinner, benzene, acidic ~ ~
or alkaline solvent cleaners, abrasive
cleaners, or chemical cloths, which
may damage the surface. Never spray volatile compounds such
as insecticide on the cabinet. Such products may damage or
discolor the cabinet.
41) If you have the TV serviced:
• Ask the service technician to use only replacement parts
specified by the manufacturer.
• Upon completion of service, ask the service technician to
perform routine safety checks to determine that the TV is in
safe operating condition.
._---------------._._._----_._'----_.,------,,--",-,--------_._ .. _--,._-_._-_._ ..• _ .. ,-,- ..
42) The cold cathode fluorescent lamp in the LCD panel contains a
small amount of mercury.
When the TV reaches the end of its useful life, dispose of
the used TV by the approved method for your area, or ask a
qualified service technician to properly dispose of the TV.
Note. The lamp(s) inside this product contain mercury
LL
Disposal may be regulated due to environmental
Iconsiderations. For disposal or recycling
•information, contactyour local authorities or the
Electronics Industries Alliance (www.eiae.org).
4

Choosing a location for your LCD TV
To Display your LCD TV on the included Pedestal
Stand:
Observe the following safety precautions:
1) Read and Follow the pedestal assembly instructions included
with the pedestal.
CAUTION: Before beginning pedestal assembly, carefully lay the
front of the LCD Panel face down on aflat, cushioned surface
such
as aquilt or blanket. Leave the bottom of the unit protruding
over the edge
of the surface and assemble the pedestal as
indicated below.
Note: Extreme care shouldalways be used when attaching
the
pedestal stand to avoid damage to the LCD panel.
2) Place the TV on asturdy, level surrace that can support the
weight
of the TV
3) Be sure to secure the TV to awall, pillar, surface, or other
immovable structure.
(1& item 23, page 3).
26" TV
VESA Mounting Pattern
Four screws Sturdy strap
(as short
as possible)
32" TV
VESA Mounting Pattern
To Display your LCD TV using a Wall Bracket:
If you decide to wall mount your LCD TV, always use a UL listed wall
bracket appropriate for the size and weight of the LCD TV (1& page 2):
I) CAUTION: Two people are required for installation.
2) Unplug and remove any cables and/or other component
connectors from the rear
of the TV
3) Remove the screws of the 32"/ 37" VESA Mounting Pattern
show in the right diagram.
4) Follow the instructions provided with your wall bracket.
Before proceeding, make sure the appropriate bracket(s) are
attached to the wall and the back
of the TV as described in the
instructions provided with the wall bracket.
5) After attaching the appropriate bracket(s) to the wall and the
back
of the TV, remove the pedestal stand from the TV as
described below.
6) VESA Mounting Pattern
Removing the Pedestal Stand
I) Carefully lay the front of the unit face down on aflat,
cushioned surface such as aquilt
or blanket. Leave the stand
protruding over the edge
of the surface.
Note: Extreme care should always be used when removing
the pedestal stand to avoid damage to the LCD panel.
2) Remove the four screws shown in the right diagram. This will
allow removal
of the pedestal stand.
3) Once you have removed all four screws, holding the pedestal
stand in place, remove the pedestal stand from the
TV
TV Size
26"
32"
37"
Hole PaUern(VxH)
IOOx200 mm
200x200 mm
200x200 rum
Screw Size
M4
M6
M6
(unit in mm)
Four screws Sturdy strap
(as short
as possible)
37" TV
VESA Mounting Pattern
Hook
Sturdy strap
(as short
as possible)
Always place the TV on the floor or asturdy, level, stable surrace
that can support the weight
of the unit. To secure the TV, use a
sturdy strap from the hook(s) on the rear
of the TV to awall stud,
pillar, or other immovable structure. Make sure the strap
is tight,
secure, and parallel to the floor.
5

ENERGY STAfI® User Information
Important notes about your LCD
TV
ENERGY STAR User Information Statement: the factory default
settings
of this television meet ENERGY STAR requirements.
Changing Picture Settings may increase energy consumption,
possibly beyond the limits required for ENERGY STAR
qualification.
To ensure your television is operating at optimal energy
efficiency, select [Home] mode during initial activation. To
return to [Home] mode settings, select [Standard] picture mode.
[Standard] mode
is recommended for normal home use.
The following symptoms are technical limitations of LCD
Display technology
and are not an indication of malfunction;
therefore, Toshiba is not responsible for perceived issues
resulting from these symptoms.
I) An afterimage (ghost) may appear on the screen if afixed,
nonmoving image
is displayed for along period of time. The
afterimage
is not permanent and will disappear in ashort
period
of time.
2)
The LCD panel contained in this TV is manufactured using
an extremely high level
of precision technology; however,
there may be an occasional pixel (dot
of light) that does not
operate properly (does not light, remains constantly lit, etc.).
This
is astructural property of LCD technology, is not a
sign
of malfunction, and is not covered under your warranty.
Such pixels are not visible when the picture is viewed from a
normal viewing distance.
Note: Interactive video games that involve shooting a"gun"
type
of joystick at an on-screen target may not work with this
TV
ENERGY STAR® qualified TV. Products that
earn the ENERGY STAR prevent green house
gas emissions by meeting strict guidelines set
by the U.S. Environmental Protection Agency.
ENERGY STAR and the ENERGY STAR mark
are registered U.S. marks.
118
'·di;
Jri4
4i
t
.!;,
Note: This equipment has been tested and found to comply
with the limits for aClass Bdigital device, pursuant
to Part
15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference
in a
residential installation. This equipmentgenerates, uses, and
can radiate radio frequency energyand, if not installed and
used in accordance with the instructions, may cause harmful
interference
to radio communications. However, there is
no guarantee that interference will not occur in aparticular
installation. If this equipment does cause harmful interference
to radio or television reception, which can be determined by
removing and applying power to the equipment, the user is
encouraged to try to correct the interference by one or more
of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and the
receiver.
•Connect the equipment into an outlet on acircuit different
from that to which the receiver is connected.
•Consult the dealer
or an experienced radiorrV technician for
help.
Caution: Changes or modifications to this equipment not
expressly approved
by Toshiba could void the user's authority
to operate this equipment.
The
Toshiba 26AV52R, 26AV502R, 32AV52R, 32AV502R, 37AV52R,
and 37AV502R Televisions comply with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
(I) this
device may not cause harmful interference, and (2)
thi~ device
must accept any interference received, including interference that
may cause undesired operation.
The party responsible for compliance to these rules is:
Toshiba America Consumer Products,
L.L.c.
82 Totowa Rd. Wayne, NJ 07470.
Ph: 1-800-631-381 I
FCC Declaration of Conformity
Compliance Statement
(Part 15):
Trademark Information
•Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
•HDMI, the
HDMIIogo and High-Definition Multimedia Interface are
trademarks
or registered trademarks of HDMI Licensing LLC.
6

Contents
Important Safety Instructions 3
Installation, Care, and Service 3
Chapter 1: Introduction 8
Features of your new TV 8
Overview
of steps for installing, setting up,
and using your new TV 9
TV front and side panel controls and connections
10
TV back panel connections II
Chapter 2: Connectin!l your TV 12
Overview of cable types 12
About the connection illustrations 12
Connecting aVCR (or aVCR with S-video)
and antenna, Cable TV or Camcorder.
13
Connecting aDVD player with ColorStream® (component
video), aVCR, and asatellite receiver.
14
Connecting an HDMFM or DVI device to the HDMI input .. 15
REGZA-LINK connection 16
Connecting adigital audio system 17
Connecting an audio system 17
Connecting apersonal computer (PC) 18
Chapter 3: Using the Iremote control 19
Preparing the remote control for use 19
Installing the remote control batteries 19
Remote control effective range 19
Learning about the remote control.. 20
Using the remote control to control your other devices
21
Remote Control functional key chart 22
Programming the remote control to control your
other devices
23
Remote control codes 24
Chapter 4: Menu layout and navigation 26
Main menu layout 26
Setup/Installation menu layout 27
Navigating the menu system 27
Chapter 5: Setting up your TV 28
Selecting the menu language 28
Configuring the antenna input source for the
ANT/CABLE terminal 28
Programming channels into the
TV's channel memory 29
Programming channels automatically 29
Manually adding and deleting channels
in the channel memory 29
Labeling channels
30
Setting the HDMFM audio mode 31
Viewing the digital signal meter 32
Setting the time zone 32
Viewing the system status 32
Chapter 6: Using the TV's features 33
Selecting the video input source to view 33
Labeling the video input sources 33
Tuning channels 34
Tuning channels using the Channel
Browse?M 34
Setting the Channel Tuning Mode 36
Tuning to the next programmed channel 36
Tuning to aspecific channel (programmed or
unprogrammed) 36
Switching between two channels using Channel Return 37
Switching between two channels using
SurfLock™ 37
Selecting the picture size 37
Scrolling the TheaterWide@ picture
(TheaterWide 2and 3only) 39
Using the auto aspect ratio feature 39
Selecting the cinema mode 39
Using the FREEZE feature 39
Adjusting the picture
.40
Selecting the picture mode 40
Adjusting the picture quality
.40
Using the closed caption mode 41
Base closed captions .41
Digital
CC Settings .41
CC Selector
41
Adjusting the audio 42
Muting the sound 42
Using the digital audio selector
.42
Selecting stereo/SAP broadcasts 42
Adjusting the audio quality 43
Selecting the optical audio output format 43
Using the
Dolby® Digital Dynamic Range
Control feature 43
Using the Locks menu 44
Entering the PIN code
.44
If you cannot remember your PIN code 44
Changing your PIN code
.44
Blocking TV programs and movies by rating (V-Chip) .. 44
Downloading an additional rating system
for blocking TV programs and movies 45
Blocking channels 46
Unlocking programs temporarily 46
Using the input lock feature 46
Using the GameTimer® .47
Using the control panel lock feature .47
Using the PC settings feature
.48
Setting the PC Audio .48
Setting the sleep timer .48
Using REGZA-LINK 49
REGZA-LINK playback device
(DVD player, etc.) control 49
REGZA-LINK input source selection 49
VOLUME and MUTE controls
of Audio Receiver 49
Other REGZA-LINK functions 50
Displaying TV status information 50
Understanding the auto power
off feature 50
Understanding the last mode memory feature 50
Chapter 7: Using the TV's advanced features 51
Using the advanced picture settings features 51
Using dynamic contrast... 51
Using the static gamma feature 51
Selecting the color temperature 51
Using CableClear® digital noise reduction 52
Using MPEG noise reduction 52
Using the Game Mode feature 52
Chapter 8: Troubleshooting 53
General troubleshooting 53
Chapter 9: Appendix 55
Specifications 55
Acceptable signal formats
for PC IN and HDMI terminals
56
Limited United States Warranty
for LCD Televisions 26" and Larger 57
Limited Canadian Warranty
for Toshiba Brand Flat Panel Televisions 58
7

Features of your new TV
The following are just afew of the many exciting features of
your new Toshiba widescreen, integrated HD, LCD TV:
• Integrated digital tuning (8VSB ATSC and QAM)
eliminates the need for aseparate digital converter set-top
box (in most cases).
•Two
HDMITM digital, high-definition multimedia
interfaces 1080p input support
(1& page IS).
•HDMI new capability
Lip-Sync Latency activates an audio/video display timing
adjustment function that allows HDMI source devices to
accurately perform synchronization automatically.
•Two sets
of ColorStream® HD high-resolution component
video inputs (1& page 14).
•Digital Audio
Out optical audio connection with Dolby®
Digital optical output format (1& page 43).
•CableClear® digital picture noise reduction
(1& page 52).
•
PC IN (Analog RGB) computer terminal (1& page 18).
•
Channel Labeling allows you to put the Call Letters (e.g.
ABC, HBO, etc.) on the screen along with the station
numbers, so you always know what you're watching
(1& page 30).
•
REGZA-LINK allows control of external devices from the
TV remote via HDMI connection (1& page 49).
8

Overview of steps for installing,
setting up, and using your new TV
Follow these steps to set up your TV and begin using its many
exciting features.
1Carefully read the important safety, installation, care,
and service information. Keep this manual for future
reference.
2Observe the following when choosing alocation for the
TV:
•Read "Important notes about your LCD TV"
(1I@f' page 6).
•Place the TV on the floor or asturdy, level, stable
surface that can support the weight
of the unit. Secure
the TV to awall, pillar, or other immovable structure
(1I@f' page 3).
•Place the TV in alocation where light does not reflect
on the screen.
•Place the TV far enough from walls and other objects
to allow proper ventilation. Inadequate ventilation may
cause overheating, which will damage the
TV. THIS
TYPE
OF DAMAGE IS NOT COVERED UNDER
THE TOSHIBA WARRANTY.
3Do not plug in any power cords until AFTER you have
connected all cables and devices to your
TV.
4BEFORE connecting cables or devices to the TV, learn
the functions
of the TV's connections and controls
(1I@f' pages 10-11).
5Connect your other electronic device(s) to the TV
(lI@f'pages 12-18).
6Install the batteries in the remote control (1I@f' page 19).
7See "Learning about the remote control" (1I@f' page 20) for
an overview
of the buttons on the remote control.
8Program the remote control to operate your other
device(s)
(1I@f' pages 21-25).
9AFTER connecting all cables and devices, plug in the
power cords for your TV and other devices. Then press
POWER on the TV control panel or remote control to turn
on the
TV. If the TV stops responding to the controls on
the remote control or TV control panel and you cannot
turn the TV off or on, please unplug the power cords few
seconds then re-plug to try again.
10 See "Menu layout and navigation" for aquick overview
of navigating the TV's menu system (1I@f' page 26).
11 Program channels into the TV's channel memory
(1I@f' page 29).
12 For details on using the TV's features, see Chapters 6
and
7.
13 For help, refer to the Troubleshooting Guide, Chapter 8.
14 For technical specifications and warranty information,
see Chapter
9.
15 Enjoy your new TV!
9

Chapter 1: Introduction
TV front and side panel controls and connections
Model 37AVS02R is used in this manual for illustration purposes.
Control panel
Left side panel
II POWER
5--8
111
0
U
jCHANNELJD-
9
0::=====;=~_
6 I~ III I~
loEJD-10 I
7_
11
IMENU ~
~I·I:;
8 -~I EX'TC::::T 11 VIDEO~ 1
~i8-3
~JI
U~~-4
TV front
~ ...
POWER D
o
I I
SERVICE
ONLY
12
1
Green LEO
Power LED (Green) =Power indicator
2 Remote sensor -Point the remote control toward this
remote sensor
(1& "Remote control effective range" on
page 19).
3 VIDEO·2 IN -The side panel AN connections are
referred to as
"VIDEO 2" and include standard AN
connections.
4 Service port -For service use only. Used for updating
the television's firmware.
5 POWER -Press to turn the TV on and off.
If the TV stops responding to the controls on the remote
control
or TV control panel and you cannot turn off the
TV, press and hold the POWER button on the TV control
panel for 5
or more seconds to reset the TV.
6 ARROWS .... ~~ -When amenu is on-screen, these
buttons function as up/downl1eft/right menu navigation
buttons.
7
MENU (ENTER) -Press to access the menu system (1&
pages 26-27). When amenu is on-screen, the MENU
button on the TV's control panel functions as the ENTER
button.
1
10
8 EXIT -Press to instantly close an on-screen menu.
9 CHANNEL .... -When no menu is on-screen, these
buttons change the channel (programmed channels only;
1& page 29).
10 VOLUME ~~ -These buttons adjust the volume level.
11 INPUT -Repeatedly press to change the source you are
viewing
(ANT/CABLE, VIDEO 1, VIDEO 2, ColorStream
H01, ColorStream H02, HOMI1, HOMI2, PC).

TV back panel connections
For an explanation of cable types and connections, see pages 12-18.
1
7
- 6
-8
I
I
HDMIIN
Hom.
1 2
eJJ
lSl
INT
IN
Y @)<@)
€ ~:.:.:.:.:.» ~
PC IN
•
p,@)\:@)
VIDEO 1@
PCI
I
S-VIDEO
HOMII
0o
(AUDIO)
PR@)<@)
La I
VIDEO
[Q]
DIGITALrl
@)<@)
@)t
AOOIOOUT
ALDIO I
~OUT~
ANT/CABLE
UMIIIlI
L@)-'
~@)@)
r@)
AUDIO
COLOR COLOR
;@)
R@)
@
STREAM STREAM
HOI H02
TV back
2345
1 HDMITM IN -High-Definition Multimedia Interface input
receives digital audio and uncompressed digital video
from an HDMI device or uncompressed digital video
from aDVI device. Also see item 3. HDMI connection is
necessary to receive l080i signals.
2 ColorStream® HD-1 and ColorStream® HD-2 -Two sets
of ColorStream® high-definition component video inputs
(with standard stereo audio inputs) for connecting devices
with component video output, such as aToshiba DVD
player with ColorStream®.
Note: Component video cables carry only video
information; separate audio cables are required for a
complete connection.
3 VIDEO-1 IN -Standard (composite) video and standard
audio inputs plus optional S-video inputs for connecting
devices with composite video or S-video output.
Note: Standard (composite) video and S-video cables
carry only video information; separate audio cables are
required for acomplete connection.
4 Audio OUT Variable -Analog audio outputs for
connecting an audio amplifier.
5 ANT/CABLE -Antenna input that supports analog
(NTSC) and digital (ATSC) off-air antenna signals and
analog and digital Cable TV (QAM) signals.
6 Digital Audio OUT -Optical audio output in Dolby
Digital or PCM (pulse-code modulation) format for
connecting an external Dolby Digital decoder, amplifier,
A/V receiver, or home theater system with optical audio
input.
7 PC/HDMI-1 (AUDIO) IN -PC audio input terminals are
shared with HDMI-l analog audio input terminals, and
their use can be configured in the Audio Setup menu (1&
page 48).
8 PC IN -For use when connecting apersonal computer.
HDMI, the HDMI logo and High-Definition Multimedia Interface
are trademarks or registered trademarks of HDMI Licensing LLC.
Manufactured under license from Dolby Laboratories.
Dolby and the double-D symbol are trademarks of Dolby
Laboratories.
11 I

· CIJapter 2: Connecting your TV
Overview of cable types
Cables can be purchased from most stores that sell audio/
video devices. Before purchasing any cables, be sure
of
connector types required by your devices and the length of
each cable.
Coaxial (F-type) cable
G {lD------
Coaxial (F-type) cable is used for connecting your antenna,
cable
TV service, and/or cable converter box to the ANTI
CABLE input on your TV.
Standard AN cables (red/white/yellow)
~~ ~ -~-----
~
Standard AN cables (composite video) usually come in sets
of three, and are for use with video devices with analog audio
and composite video output. These cables (and the related
inputs on your TV) are typically color-coded according to
use: yellow for video, red for stereo right audio, and white for
stereo left (or mono) audio.
S-video cable
OQTIIIDm .... ----
S-video cable is for use with video devices with S-video
output. Separate audio cables are required for acomplete
connection.
Note: An S-video cable provides betterpicture performance
than acomposite video cable. Ifyou connect an S-video
cable, be sure
to disconnect the standard (composite) video
cable
or the picture performance will be unacceptable.
Component video cables (red/green/blue)
~~
~ --+0-----
~
Component video cables come in sets of three and are for
use with video devices with component video output.
(ColorStream®
is Toshiba's brand of component video.) These
cables are typically color-coded red, green, and blue. Separate
audio cables are required for acomplete connection.
Note: Component video cables provide better picture
performance than astandard (composite) video or S-video
cable.
I HDMITM cable (with HDMI Logo "Huml")
IO~
HDMI (High-Definition Multimedia Interface) cable is for
use with devices with an HDMI output. An HDMI cable
delivers digital audio and video
in its native format. This
cable carries both video and audio information; therefore,
separate audio cables are not required for acomplete HDMI
device connection (lIE page
15 and page 18).
Note: HOMI cable provides betterpicture performance than
astandard (composite) video
or S-video cable.
Optical audio cable
[Q]~~--
Optical audio cable is for connecting receivers with Dolby
Digital or PCM (pulse-code modulation) optical audio input
to the
TV's DIGITAL AUDIO OUT terminal (lIE page 17).
Analog RGB (15-pin) computer cable
You can connect different types and brands of devices to
your TV
in several different configurations. The connection
illustrations in this manual are representative
of typical
device connections only. The input/output terminals on your
devices may differ from those illustrated herein. For details
on connecting and using your specific devices, refer to each
device's owner's manual.

Chaptei 2: Connecting your TV
Connecting a VCR (or a VCR with S-video) and antenna, Cable TV or
Camcorder
TV back panel
- IN T IN -,------------,
y@t@ €~:.:.:-:.:.»~ PC IN
.'====cm-====!
,,@x@ ~~I.@"N PC!
I ~ II (0 1k"1f1o\ S-video cable IJ
,,@.,@ ~ o:::DJ):;---------------- Stereo VCR 1
u;"@I,@ IOE~.,I! fQ '"~! Stan~~rd eVI~ ~u~ "CHoB ~;<@l
'LUD~ •. 1.... LOOO 1[l;:~r'·TI-l AN cable CH'U ~ I
R@i@ .r~·11 ~ II I ~"-,~~' ~~'~
~ef-I~~ r~· IIR~ II ~ I ~ ... 'I' ,', 'I' t~ ,
qQE::::D.... Audio cable
~'----------: I
:JY
I I
I I
~ J
From Cable TV
or antenna
Camcorder
VIDEO 2 inputs
on TV I'ight side panel
AUDIO VIDEO
OUT
f¥
L~ ~
I A!ffi>_l
-rr--
You will need:
•coaxial cables
•S-video cable
-For betterpicture performance, ifyour VCR has S-video,
use an S-video cable (plus the audio cables) instead of
the standard video cable. 00 not connect both types of
video cable to VIDEO 1 at the same time or the picture
performance will
be unacceptable.
-For betterpicture performance, if your camcorder has
S-video, connectan S-video
cable (plus the audio
cables) to VIDEO 1on the TV back side instead of the
VIDEO 2on the TV side panel.
-Ifyou have amono VCR, connect UMaNa on the TV
to your VCR's audio out terminal using the white audio
cable only
•S-video cable (if your VCR or camcorder has S-video)
- 00 not connect both types of video cable to VIDEO 1
at the same time or the picture performance will be
unacceptable.
•standard audio cables (If you have amono VCR or
camcorder has S-video)
Note: When you use aCable box, you may not be able to use
the remote control to
program or access certain features on
the
TV
To view the antenna or Cable signal:
Select the ANT/CABLE video input source on the TV *
To view basic and premium Cable channels:
Turn OFF the VCR. Select the ANT/CABLE video input
source on the
TV *Tune the TV to channel 3or 4(whichever
channel the Cable box output
is set to). Use the Cable box
controls to change channels.
To view the VCR:
Turn ON the VCR. Select the VIDEO 1video input source on
the
TV. *
To view the camcorder video:
Select the VIDEO 2video input source on the TV. *
* To select the video input source, press INPUT on the remote control
(DE page 20). To program the TV remote control to operate other
devices, see Chapter
3.
The unauthorized recording, use, distribution, or revision of television
programs, videotapes, DVDs, and other materials is prohibited under the
Copyright Laws of the United States and other countries, and may subject
you to civil and criminal liability.

Chapter 2: Connecting your TV
Connecting a DVD player with ColorStream® (component video), a VCR,
and a satellite receiver
YOUl'TV has two sets of ColorStream® (component video) inputs.
From antenna
~~~~g!!!:7--' Stereo VCR ~
~"~ ~u~ ',' ~::~"'~ANTC~
~~ ~ ~-'J' OUT"TV ~
f. f~fR \~f'
AUDIO
qrr
~~c::jjJl]J:::~
~
...--- :>+----I.-=~-----------
L..- ....
Y~P'~P' e ~
COMPONENT VIDEO S-VIOEO VIDEO
OUT OUT
From satellite dish
DVD player with component video
Satellite receiver with component video
You will need:
•coaxial cables
•standard
AN cables
-For betterpicture performance, if your VCR has S-video,
use an S-video cable (plus the audio cables) instead
of
the standard video cable. 00 not connect both types of
video cable to VIDEO 1 at the same time or the picture
performance will be unacceptable.
-Ifyou have amono VCR, connect UMaNa on the TV
to your VCR's audio out terminal using the white audio
cable only
•standard audio cables
•component video cables
- You can connect the component video cables (plus
audio cables) from the
OVO player or satellite receiver to
either set of ColorStream terminals on the TV (HD-1 or
HD-2). The ColorStream HD-1 and HD-2 terminals can
be used with Progressive (480p, 720p)
and Interlaced
(480i, 1080i) scan systems. A1080i signal will provide
the
best picture performance (1080p is not supported).
-Ifyour OVO player or satellite receiver does nothave
component video, connect astandard
AN cable to
VIDEO 2on the side panel. Ifyour OVO playerhas HoMI
video, see page 15.
To view satellite programs using the component
video connections:
Turn on the satellite receiver. Select the ColorStream HD·2
video input source on the TV *
To view the VCR or view and record antenna
channels:
Turn ON the VCR, Tune the VCR to the channel you want to
watch. Select the
VIDEO 1video input source on the TV. *
To record aTV program while watching aDVD:
Turn ON the VCR. Tune the VCR to the channel to record.
Select the
ColorStream HD-1 video input source on the TV* to
view the DVD.
* To select the video input source, press INPUT on the remote control
(~ page 20). To program the TV remote control to operate other
devices, see Chapter
3.
The unauthorized recording, use, distribution, or revision of television
programs, videotapes, DVDs, and other materials is prohibited under the
Copyright Laws of the United States and other countries, and may subject
you to civil and criminal liability.
To view antenna or Cable channels:
Select the ANT/CABLE video input source on the TV*
To view the DVD player:
Turn ON the DVD player. Select the ColorStream HD-1 video
input source on the
TV *
1
14

TV back panel
HOMIINY,
Homl
1 2
[1) EIA/CEA-861-D compliance covers the transmission of
uncompressed digital video with high-bandwidth digital content
protection, which
is being standardized for reception of high-
definition video signals. Because this
is an evolving technology, it
is possible that some devices may not operate properly with the
TV
HDMI, the HDMI logo and High-Definition Multimedia Interface are
trademarks or registered trademarks of HDMI Licensing LLC.
Note: To ensure that the HOMI or OVI device is reset properly,
it is recommended that you follow these procedures.'
•
When turning on your electronic components, turn on the
TV first, and then the HOMI or OVI device.
•
When turning offyour electronic components, turn off the
HDMI or DVI device first, and then the TV
To connect aDVI device, you will need:
•one HDMI-to-DVI adapter cable (HDMI type Aconnector)
per DVI device
-For proper operation, the length of an HOMI-to-OVI
adapter cable should not exceed 9.8 ft (3m). The
recommended length is 6.6 ft (2m).
•one pair of standard analog audio cables per DVI device
-An HOMI-to-OVI adaptercable transfers video only
Separate analog audio cables are required (see
illustration).
-See "Setting the
HOMITM audio mode" (~page 31).
I"HOO' OUT'
[
~HOM"N;]
Hom,
1 2
,~
••
VIDEO I AUDIOs
[O~ ~~~
[0 ~ ~~~'
L R
TV back panel
HDMI device
To view the HDMI device video:
Select the HDMI I, or HDMI 2video input source on the
TV.*
To connect an HDMI device, you will need:
•one HDMI cable: (type Aconnector) per HDMI device
-For proper operation, it is recommended that you use an
HOMI cable with the HOMI Logo
(HOm.).
- To display an 10801160Hz signal format, you will need a
Category 2cable. Conventional HOM I/O VI cable may
not work properly
-HOMI cable transfers both video
and audio. Separate
analog audio cables are not required (see illustration).
-See "Setting the
HOMITM audio mode" (~page 31).
The HDMI input on your TV receives digital audio and
uncompressed digital video from an HDMI source device,
or uncompressed digital video from aDVI (Digital Visual
Interface) source device.
This input
is designed to accept HDCP (High-Bandwidth
Digital-Content Protection) program material
in digital form·
from EIA/CEA-861-D-compliant[l] consumer electronic
devices (such as aset-top box or DVD player with HDMI or
DVI output).
The HDMI input can accept and display VGA, SVGA, XGA,
WXGA, SXGA, 480i (60Hz), 480p (60Hz),
nop (60Hz),
1080i (60Hz) and 1080p (24Hz/60Hz) signal formats. For
detailed signal specifications, see page 56.
Supported Audio format: Linear PCM, sampling rate 32/44.11
48 kHz
Note: To connect a PC to the HOMI input, see page 18.
Connectin!1 an HOMITM or OVI
device to the HOM I input
* To select the video input source, press INPUT on the remote control
(~ page 20). To program the TV remote control to operate other
devices, see Chapter
3.
15 I

Chapter 2: Connecting your PI
REGZA·LINK connection
You can control the basic functions of connected audio/video devices using the TV's remote control if you connect a
REGZA-LINK compatible audio receiver or playback device. For
an explanation of setup and operations, see pages 49.
TV back panel
Playback device
(REGZA-liNK HD DVD player,etc.)
,---- HDMIIN ---,
Hi:Jrtll
2
Playback device
(REGZA-liNK DVD player,etc.)
To connect an Audio Receiver and Playback Devices,
you will need:
•HOMI cables (~page 15)
Note:
• If several devices are connected, REGZA-LINK feature
may not operate properly.
•For proper operation, it
is recommended that you use
HOMI cables with the HOMI Logo
(HOm.).
Before controlling the device(s):
•After completing the above connections, set the REGZA-
LINK Setup menu as you desire (~ page 50).
•The connected devices must also be set. For details, see the
operation manual for each device.
•The REGZA-LINK feature uses the CEC technology as
regulated by the HOMI standard. This feature
is limited to
models incorporating Toshiba's
•This feature
is limited to models incorporating Toshiba's
REGZA-LINK. However, Toshiba
is not liable for those
operations. Refer to the individual instruction manuals for
compatibility information.
Note: This feature may not work properly depending on the
devices that are connected.

.'
Chapter 2: CDnnecting yDur TV
Audio
Digital Audio Selector
Audio Sailings
o
o
Analog audio amplifier
o
o
You will need:
•standard audio cables
*Manufactured under license from Dolby Laboratories. Dolby and
the double-D symbol are trademarks of Dolby Laboratories.
Note:
•Some audio systems may not be compatible with Dolby
Digital bitstream signals, Older audio systems that are
not compatible with standard optical out signals
may
not work properly, creating ahigh noise level that may
damage speakers or headphones, THIS DAMAGE IS NOT
COVERED BY YOUR WARRANTY
•
The DIGITAL AUDIO OUT terminal may not outputsome
digital audio sources because
of copy restrictions.
TV back panel
IN T IN -,--------,
,@@~PC"
~@·flJ7 "'""" ~PCI
~I~ S-VI>EO 0 HllMI~
~@,@~~
""'@!@ @t~
I "'" l OUT~r""""l
~@j@ r@ ~""II-~
"'" I >----'
J\.'}8i. sW~ L@ ~+-ii =
HOl HD2 R~ R~ I~I
To control the audio:
1Turn on the TV and the stereo amplifier.
2Set up aoptimum volume level of the stereo amplifier.
Then you can adjust the sound volume level from the TV's
volume control or the amplifier's volume control.
3Menu item of Speakers can turn to OFF to mute the TV's
built in speakers.
Connecting an audio system
This connection allows you to use external speakers with an
external analog audio amplifier to adjust the sound level.
o
o
DIGITAL
AlJDIOOlfT
Dolby Digital decoder or
other digital audio system
o
o
TV back panel
4In the Optical Output Format field, select either Dolby
Digital or PCM, depending on your device (~"Selecting
the optical audio output format" on page 43).
To control the audio:
The TV's DIGITAL AUDIO OUT terminal outputs a Dolby®*
DigitallDD"?o~~~ or 2-channel down-mixed peM (pulse-code
modulation) signal for use with an external Dolby® Digital
decoder or other external audio system with optical audio
input.
1Tum on the TV and the digital audio device.
2Press MOU on the TV's remote control and open the Audio
menu.
3Highlight Audio Setup and press 8.
You will need:
•optical audio cable (Use an optical audio cable that has
the larger "TosLink" connector and not the smaller "mini-
optical" connector.)
Connecting a digital audio system
Audio Setup
o
o
o
10
10
Bass
Treble
Balance
Audio Settings
Compressed
DoneReset
PC Audio No
HDMI 1Audio Auto
MTS Stereo
Language English
Optical output Format ,~4~;;tiiiiJ!iii::::ie
Dolby Digital
Dynamic Range Control
Reset Done

Connecting a personal computer
(PC)
PC on which you are playing the OVO- Video, some scenes
may be skipped
or you may not be able to pause during
multi-angle scenes.
•Signal names for mini O-sub IS-pin connector
With either the PC IN or HOMI connection, you can watch
your computer's display on the TV and hear the sound from
the
TV's speakers.
To connect a PC to the PC IN terminal on the TV:
When connecting aPC to the PC IN terminal on the TV,
use an analog RGB (IS-pin) computer cable and aPC audio
cable.
Pin No.
Signal
Pin No.
Signal
Pin No.
Signal
name name name
IR6Ground
11
Reserved
2G7Ground
12 SOA
3B8Ground
13 H-sync
4Reserved 95V
14 V-sync
5Reserved 10
Ground 15 SCL
PC audio
cable
PC audio
output
CD III
-Homl~
1 2
'rE
ej
~
I
1NT1N
~
y@@
PC IN
..
""@@
-
VIDEO 1
@H~!I
I0
(AUDIO
P.@x.@
I [gJ =~I
lilOO I
IDEO
r@@
@t
AUDIO I
=-OUT~ NfTI
~@{@
T@
L@_
~OR:IOOLOR
'r@
R@
0
STFlEAM STREAM
HD1 H02
Computer
TV back panel
HDMIIN
Note:
•
The edges of the images may be hidden.
•
If receiving a480i (HoMI), 480p (HOM/), 720p, 1080i, or
1080p signal program, Native mode scales the video to
display the entire picture within the borders of the screen
(i.e. no overscanning).
The HOMI input can accept and display VGA, SVGA, XGA,
WXGA, SXGA, 480i (60Hz), 480p (60Hz),
nop (60Hz),
1080i (60Hz), and 1080p (24Hz/60Hz) signal formats. For
detailed signal specifications, see page 56.
To connect a PC to the HDMI terminal on the TV:
When connecting aPC to the HOMI terminal on the TV, use
an HOMI-to OVI adapter cable and analog audio cables.
If connecting aPC. with an HOMIterminal, use an HOM I
cable (type Aconnector). Separate analog cables are not
necessary
(~page 15).
PC audio
cable
TV back ~~~~I
Homl
Conversion adapter
(if necessary)
• To use aPC, set the monitor output resolution on the PC
before connecting it to the
TV. The PC IN terminal can
accept and display VGA, SVGA, XGA, WXGA and SXGA
signal formats. For detailed signal specifications
(~ page
56).
Other formats
or non-standard signals will not be displayed
correctly.
•
To display the optimum picture, use the PC setting feature
(~ "Using the PC settings feature" on page 48).
Note:
•
The PC audio input terminals on the TV are shared with the
HoMI-1 analog audio input terminals
(~ page 48).
•Some PC models cannot
be connected to this TV.
•An adapter is not needed for computers with acompatible
mini
o-sub 15-pin terminal.
•Depending on the
OVO'S title and the specifications of the
1
18

Chapter 3: Using the remote control
Preparing the remote control for
use
Your TV remote control can operate your TV and many other
devices such as cable converter boxes, satellite receivers,
VCRs, DVD players, and HTIBs (home theater in abox),
even if they are different brands.
If you have a Toshiba device:
Your TV remote control is preprogrammed to operate most
Toshiba devices (1l3'l' page 23).
If you have a nOI1- Toshiba device or a Toshiba device
that the remote (~ontrol is not preprogrammed to
operate:
You can program the TV remote control so it will operate the
other device (~pages 21-25).
Installing the remote control
batteries
1Remove the battery cover from the back of the remote
control.
•Always remove batteries from the remote control if they
are
dead or if the remote control is not to be used for an
extended
period of time. This will prevent battery acid from
leaking into the battery compartment.
Remote control effective range
For optimum performance, aim the remote control directly
at the TV and make sure there is no obstruction between the
remote control and the TV.
. ..
.- .
!.
Point remote control
toward remote sensor
on front of TV.
-
..:'~~
h-
--
300
16.4 It (5m)
Squeeze tab
and lift cover.
2Install two "AAA" size batteries, making sure to match
the +and -signs on the batteries to the signs on the
battery compartment.
3Reinsert the battery cover in the remote control until the
tab snaps.
Caution: Batteries must not be exposed to excessive heat
such as sunshine, fire
or the like.
Note:
•Be sure to use AAA size batteries.
•Dispose
of batteries in adesignated disposal area.
•Batteries should always be
disposed of with the
environment in mind. Always dispose
of batteries in
accordance with applicable laws and regulations.
•
If the remote control does not operate correctly, or if the
operating range becomes reduced, replace batteries with
new ones.
•
When necessary to replace batteries in the remote control,
always replace both batteries with new ones. Never mix
battery types
or Lise new and used batteries in combination
19 \

Chapter 3: Using the remote control
Learning about the remote control
The buttons used for operating the TV only are described
here. For acomplete list
of the remote control's functions, see
the remote control functional key
chart (I@" page 22).
1 POWER turns the TV on and off. When the TV is on, the
green
LED indicator on the TV front will be illuminated.
2
FREEZE freezes the picture. Press again to restore the
moving picture
(I@" page 39).
3 SLEEP accesses the sleep timer (I@" page 48).
4
PIC SIZE cycles through the picture sizes: Natural,
TheaterWide 11213, Full, 4:3 HD, Native and Dot by
Dot (I@" page 38).
5
Channel Numbers (0-9, -/100) directly tune
channels.
The @button is used to tune digital channels
(I@" page 36) or to edit the Favorites List (I@" page 34).
6 INPUT selects the video input source (I@" page 33).
7 CH. Tcycles through programmed channels when no
menu
is on-screen (I@" page 29).
8 VOL +- adjusts the volume level.
9
FAV BROWSER accesses the Favorites List in the
Channel
Brower™ (I@" page 34).
10 RECALL displays TV status information (I@" page 50).
11 CH RTN returns to the last viewed channel or source
(I@" page 37).
12 MUTE reduces or turns off the sound (I@" page 42).
13 INFO displays TV status information as well as program
details, when available
(I@" page 50).
14 ; <IIlIl /; ~ While watching TV, these buttons open the
Channel
Browser™ and tune to the previous/next channel
in the channel history (I@" page 35). (Also see "Arrow
buttons.")
15 Arrow buttons (. T <IIlIl ~) When amenu is on-screen,
these buttons select
or adjust programming menus. (Also
see;; <IIlIl/; ~.)
16 ENTER activates highlighted items in the main menu
system.
17 MENU accesses the main TV menu system (I@" pages 26
and 27).
18 EXIT closes on-screen menus.
19 MODE SELECT switch switches between TV,
CABLE/SAT, AUX I, and AUX 2modes
(I@" page 21).
Set to "TV" to control the TV.
19
18
TOSHIBA
ANGLE SUB TITLE AUDIO EJECT
[§][Q]@DI ~ I
MODE SELECT
.~~.
[!i]f-----
SLEEP PIC SIZE FREEZE POWER
~-ltt-O P C\ @-'-J
CD CD CD
CDCDffi
5Tmmm
8 III ®®8 III 6
IIIFI8~~~~~ER ;/ RECALL III 7
9rnS2 (::I ~I W~,~, III 10
12
10
[) 8 O~I -11
~~M~ INFO II
o ... 013
14 IIIB~-:rt ~ (8NTER~ ~ N;T
15un\)~
16 III MENU ~VflfLEAR
17 () ()
PAUSE/STEP PLAY STOP
(1I111~) 0 ~
SKIP REW FF SKIP
8GG8
Tv/VCR REC RESUME PLAY SLOW
000CE)
SEARCH
CT·90302
Note: The error message "NOTAVAILABLE" may appear if
you press akey for afunction that is notavailable.
