SERVICE MANUAL
LCD Color Television
32HL85
FILE NO. 020-200505
Published in Japan, May. 2005 (YC)
TOSHIBA CORPORATION 2005
REVISION 1

- 2 -
TABLE OF CONTENTS
SERVICE SAFETY PRECAUTIONS .................................................................................................................................... 3
HANDLING THE LCD MODULE .......................................................................................................................................... 5
SERVICE MODE .................................................................................................................................................................. 7
LAYOUT OF MAJOR BOARDS .......................................................................................................................................... 12
MECHANICAL DISASSEMBLY .......................................................................................................................................... 13
EXPLODED VIEW .............................................................................................................................................................. 15
PACKING DISASSEMBLY ................................................................................................................................................. 17
CHASSIS AND CABINET REPLACEMENT PARTS LIST ................................................................................................. 18
PC BOARDS TOP & BOTTOM VIEW ................................................................................................................................ 23
CIRCUIT BLOCK DIAGRAM .............................................................................................................................................. 35
APPENDIX:
SCHEMATIC DIAGRAM

- 3 -
GENERAL ADJUSTMENTSSPECIFIC INFORMATIONS
SERVICE SAFETY PRECAUTIONS
• The caution items shown here describe major safety issues and should always be observed.
• The meanings of the various indications are as follows.
WARNING
CAUTION
Indicates a hypothetical situation in which service personnel and nearby third parties, or even
end users due to a product defect after the service operation is completed, could possibly be in
danger of injury or even death in the event of operational error.
Indicates a hypothetical situation in which service personnel and nearby third parties, or even
end users after the service operation is completed, could possibly be in danger of injury, or
where there could be physical damage in the event of operational error.
* Physical damage means major damage to a home, furnishings and other possessions.
Examples of marks
SHOCK HAZARD
PROHIBIT DISASSEM-
BLING
UNPULUG
The " indicates caution (including danger and warning).
The actual meaning of this caution is indicated inside the
" or nearby illustrations or text.
The example shown to the left indicates the danger of "electrical shock".
The indicates a forbidden action.
The actual meaning of this caution is indicated inside the or nearby illustrations or text.
The example shown to the left indicates that disassembly is forbidden.
The
- indicates a forced action (an action that must be performed).
The actual meaning of this forced action is indicated by
- or nearby illustrations or text.
The example shown to the left indicates that the power plug must be disconnected.

- 4 -
WARNING
KEEP CHILDREN
AWAY
UNPULUG
SHOCK HAZARD
USE SPECIFIED
PARTS
CAUTION FOR
WIRING
CAUTION FOR
ASSEMBLING /
WIRING
CHECK INSULATION
RESISTANCE
PROHIBIT
REMODELING
• Always advise users to keep children away.
There is danger of injury to children from tools, disassembled products, etc.
• Always disconnect the power plug before starting work whenever power is not required.
Failure to disconnect the power plug before starting work can result in electrical shock.
• Depending on the model, use an insulation transformer or wear gloves when servicing with the
power on, and disconnect the power plug to avoid electrical shock when replacing parts.
In some cases, alternating current is also impressed in the chassis, so electrical shock is pos-
sible if the chassis is contacted with the power on.
• Always use the replacement parts specified for the particular model when making repairs.
The parts used in products have the necessary safety characteristics such as inflammability,
voltage resistance, etc.; therefore, use only replacement parts that have these same character-
istics.
Use only the specified parts when the mark is included in a circuit diagram or parts list.
• Parts mounting and routing of the wiring should be the same as that used originally.
For safety purposes, insulating materials such as tubing or tape is sometimes used and printed
circuit boards are sometimes mounted floating.
Also make sure that wiring is routed and clamped to avoid parts that generate heat and which
use high voltage. Always follow the original scheme.
• After a repair has been completed, reassemble all disassembled parts, and route and recon-
nect the wiring, in accordance with the original scheme.
Do not allow internal wiring to be pinched by cabinets, panels, etc.
Any error in reassembly or wiring can result in electrical leakage, flame, etc., and may be
hazardous.
• After completing the work, disconnect the power plug from the outlet, remove the antenna, turn
on the power switch. Then, use a 500V insulation resistance meter to check the insulation
resistance of the antenna terminal, other metallic parts and between the prongs of the power
plug to make sure that the insulation resistance is 1M 1or more.
The set will require inspection and repair if the insulation resistance is below this value.
• Never remodel the product in any way.
Remodeling can result in improper operation, malfunction, or electrical leakage and flame,
which may be hazardous

- 5 -
GENERAL ADJUSTMENTSSPECIFIC INFORMATIONS
HANDLING THE LCD MODULE
Safety Precautions
In the event that the screen is damaged or the liquid crystal
(fluid) leaks, do not breathe in or drink this fluid. Also, never
touch this fluid.
Such actions could cause toxicity or skin irritation. If this fluid
should enter the mouth, rinse the mouth thoroughly with wa-
ter. If the fluid should contact the skin or clothing, wipe off
with alcohol, etc., and rinse thoroughly with water. If the fluid
should enter the eyes, immediately rinse the eyes thoroughly
with running water.
Precautions for Handling the LCD Module
The LCD module can easily be damaged during disassembly
or reassembly; therefore, always observe the following pre-
cautions when handling the module.
1. When attaching the LCD module to the LCD cover, posi-
tion it appropriately and fasten at the position where the
display can be viewed most conveniently.
2. Carefully align the holes at all four corners of the LCD
module with the corresponding holes in the LCD cover
and fasten with screws. Do not strongly push on the mod-
ule because any impact can adversely affect the perform-
ance. Also use caution when handling the polarized screen
because it can easily be damaged.
CAUTION The metal edges of the LCD module
are sharp, so use caution to avoid in-
jury.
3. If the panel surface becomes soiled, wipe with cotton or a
soft cloth. If this does not remove the soiling, breathe on
the surface and then wipe again.
If the panel surface is extremely solied, use a CRT cleaner
as a cleaner.Wipe off the panel surface by drop the cleaner
on the cloth. Do not drop the cleaner on the panel. Pay
attention not to scratch the panel surface.
4. Leaving water or other fluids on the panel screen for an
extended period of time can result in discoloration or
stripes. Immediately remove any type of fluid from the
screen.
5. Glass is used in the panel, so do not drop or strike with
hard objects. Such actions can damage the panel.
6. CMOS-LSI circuitry is used in the LCD module, so avoid
damage due to static electricity. When handling the mod-
ule, use a wrist ground or anchor ground.

- 6 -
7. Do not expose the LCD module to direct sunlight or strong
ultraviolet rays for an extended period of time.
8. Do not store the LCD module below the temperature con-
ditions described in the specifications. Failure to do so
could result in freezing of the liquid crystal due to cold air
or loss of resilience or other damage.
9. Do not disassemble the LCD module. Such actions could
result in improper operation.
10. When transporting the LCD module, do not use packing
containing epoxy resin (amine) or silicon resin (alcohol or
oxim). The gas generated by these materials can cause
loss of polarity.

- 7 -
CAUTION : Never try to perform initialization unless you have changed the memory IC.
SERVICE MODE
1. ENTERING SERVICE MODE
1) Press MUTE button twice on 2) Press MUTE button again and 3) While pressing the MUTE button,
Remote Control. keep pressing. press MENU button on TV set.
(Service mode display)
2. DISPLAYING THE ADJUSTMENT MENU
1) Press MENU button on Remote Control.
Service mode Adjustment mode
3. KEY FUNCTION IN THE SERVICE MODE
The following key entry during display of adjustment menu provides special functions.
Press
Press
MUTE
Test signal selection : TV/VIDEO button (on Remote)
Selection of the adjustment items : Channel / (on TV or Remote)
Change of the data value : Volume W/ X(on TV) or / (on Remote)
Adjustment menu mode ON/OFF : MENU button (on Remote)
Initialization of the memory : CALL + Channel button on TV ( )
Reset the count of operating protect circuit to “00” : CALL + Channel button on TV ( )
“RCUT” selection : 1 button
“GCUT” selection : 2 button
“BCUT” selection : 3 button
“CNTX” selection : 4 button
“COLC” selection : 5 button
“UVTT” selection : 6button
Automatic A/D Adjustment(PC, Component) : 7 button
Self diagnostic display ON/OFF : 9 button
----- Color thickness correction
note: Displayed differently as shown below, depending
on the setting of the receiving color system.
COLP (PAL)
COLC (NTSC)
COLS (SECAM)

- 8 -
Signals Picture
• Red raster
• Green raster
• Blue raster
• All Black
• All White
R
All BlackAll White
BSignal off G
4. SELECTING THE ADJUSTING ITEMS
1) Every pressing of CHANNEL button in the service mode changes the adjustment items in the order of table-2.
(button for reverse order)
5. ADJUSTING THE DATA
1) Pressing of VOLUME W/ X, / button will change the value of data in the range from 00H to FFH. The
variable range depends on the adjusting item.
6. EXIT FROM SERVICE MODE
1) Pressing POWER button to turn off the TV once.
INITIALIZATION OF MEMORY DATA
After replacing EEPROM IC, the following initialization is required.
1. Enter the service mode, then select any register item.
2. Press and hold the CALL button on the Remote, then press the CHANNEL button on the TV. The initialization of
EEPROM IC has been completed.
3. Check the picture carefully. If necessary, adjust any adjustment item above.
Perform “Auto tune” on the owner’s manual.
CAUTION: Never attempt to initialize the data unless EEPROM IC has been replaced.
7. TEST SIGNAL SELECTION
1) Every pressing of TV/VIDEO button on the Remote Control changes the built-in test patterns on screen as described
below in SERVICE MODE.

- 9 -
8. SELF DIAGNOSTIC FUNCTION
1) Press “9” button on Remote Control during display of adjustment menu in the service mode.
The diagnosis will begin to check if interface among IC’s is executed properly.
2) During diagnosis, the following displays are shown.
000
000000
HL85_0100
M
N
O
P
Q
R
MFirmware :
Version information of microprocessor
In case of file name : HL85 and Version : 0100 indicates[HL85_0100].
NTime : Total hour of turn the TV on. (Unit : H)
OPower : Operation number of protecting circuit ----"000" is normal.
When indication is other than "000", overcurrent apt to flow, and circuit parts may possibly be damaged.
PBus line : --"OK" is normal
"SCL-GND"(Red indication) : SCL-GND short circuit
"SDA-GND"(Red indication) : SDA-GND short circuit
"SCL-SDA"(Red indication) : SCL-SDA short circuit
QBus cont : --- "OK" is normal.
NG is abnormal(Red indication).
When type name of semiconductor indicates.
RBlock
UV : TV reception mode
V1 : VIDEO 1 input mode
V2 : VIDEO 2 input mode
V3 : ColorStream HD IN
V4 : HDMI A/V IN

- 10 -
9. VERSION CHECK MODE
1) Press “9” button twice on Remote Control during display of adjustment menu in the service mode. The version of main
MPU will begin to check.
2) During Version Check, the following displays are shown.
HL85_0100 (U15)
32
20 00 01 34 00 00
00000155
CMO-32
M
N
O
P
Q
R
MMAIN MPU :
Version information of microprocessor
In case of file name : HL85, Version 0100 for Code Program Version
and (U15) for OSD Version indicates [HL85_0100(U15)]
NEEPROM :
Version information of EEPROM : Display 1 byte data.
OSUB MPU :
Version information of SUB MPU : Display 1 byte data.
POPTION :
Option information : Display six numbers of 1 byte data.
QHDMI ID :
HDMI ID information : Display 4 byte data.
RLCD Panel Vender information display
The following Panel Vender and screen size are displayed.
Panel Vender Screen Size(Inch)
CMO -27
SHP -32
Example : CMO-27 indicates that vender is CMO and Screen Size is 27 inch.

- 11 -
10. STATUS CHECK MODE
1) Press “9” button thrice on Remote Control during display of adjustment menu in the service mode. The status of this
model will begin to check.
2) During Status Check, the following displays are shown.
MMAIN :
Main source information :
Display RF position number (0 - 99) on the main screen, or Input Source (EXT1/2/3/HDMI etc.)
NMAIN FORMAT :
Display Video and PC format information
OMAIN PLL :
Main PLL information : Display 1 byte data at five.
PSCREEN SIZE :
Display the screen size as follows.
EXT1
480i
NATURAL
C638 54 CE 08
0000 0000 0000
M
N
P
Q
O
QOTHER STATUS :
Other status information : Display three numbers of 2 byte data.
Theater Wide 1
Theater Wide 2
Theater Wide 3
FULL
NATURAL

- 12 -
LAYOUT OF MAJOR BOARDS
U101A
AV TERMINAL BOARD
U103A
SIGNAL BOARD
U101D
KEY BOARD
U101C
LED BOARD
U812
AC-IN BOARD
U101B
FRONT AV BOARD
U811
POWER BOARD

- 13 -
BITTB4×16SBN
×10
PP3×8
+SW+W SBN
×5
PP5×16
SW+W SBN
×5
A450
A401
A445
A420
MECHANICAL DISASSEMBLY
1. Removethe stand (foot) and back cover.
2. Removethe boards (FRONT AV, LED, KEY) and piece key ass'y.
P801
A315
A340
BITTB
3×12 SBN
×5
PP3×8
+SW+W SBN
×3
PP3×8+SW+W ECO
×3
PP3×8
+SW+W SBN
×2
PP3×8
+SW+W SBN
BITTB3×8 SBN
×3
PP3×8
+SW+W ECO
PP3×8+SW+W ECO
PP3×8+SW+W ECO
×4
PP3×8+SW+W ECO
×2
PP3×8+SW+W ECO
BITTB3×12 SBN
×2
PP12
A320
PP08
U101C
U101B
U101D

- 14 -
PP3×8+SW+W ECO
×4
PP3×8+SW+W ECO
×4
W661
W661
BITTB4×16SBN
×4
BITTB4×16SBN
×4
PP3×8+SW+W ECO
×5
PP3×8+SW+W ECO
×5
H001
PP08
PP12
PP08
U103A
U101A
U811
U812
3. Removethe boards (POWER, AC-IN, SIGNAL, AV TERMINAL) and speaker.
4. Removethe display.
PP3×8+SW+W ECO
×2
PP3×8+SW+W ECO
×2
A317
B001
A201
BITTB4×16ECO
×14
PB4×5 ECO
×2
PB4×5 ECO
×2
PP4×5 ECO
×2

- 15 -
EXPLODED VIEWS
1. Chassis Block
BITTB4×16SBN ×10
BITTB3×12 SBN
×5
BITTB3×8 SBN ×3
PP3×8+SW+W SBN
BITTB3×12 SBN
×2
PP3×8+SW+W ECO
×4
PP3×8+SW+W ECO
×2
PP3×8+SW+W SBN
×5
PP3×8+SW+W SBN
×3
PP3×8
+SW+W ECO
PP5×16
SW+W SBN
×5
PP3×8+SW+W ECO
×3
PP3×8+SW+W ECO
PP3×8
+SW+W SBN
×2
PP3×8+SW+W SBN
A450
A401
A445
A340
P801
A315
PP08
PP12
A320
U101C
U101B
U101D
A420

- 16 -
BITTB4×16SBN
×4
BITTB4×16SBN
×4
PP3×8+SW+W ECO
×4
PP3×8+SW+W ECO
×4
PP3×8+SW+W ECO
×5
PP3×8+SW+W ECO
×5
PB4×5 ECO
×2
BITTB4×16ECO
×14
PB4×5 ECO
×2
PB4×5 ECO
×2
PP3×8+SW+W ECO
×2
PP3×8+SW+W ECO
×2
B001
W661
W661
A201
H001
PP08
PP12
PP08
PP08
A317
U103A
U101A
U811
U812
2. Main Block

- 17 -
PACKING DISASSEMBLY
A702B
A702B
A703
A702A
A702A
K902Y170
A709
Y109
Y101
A701A

- 18 -
Location Parts No.Description
No.
Location Parts No.Description
No.
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “SERVICE SAFETY PRECAUTIONS” ON PAGE 3 OF THIS
MANUAL.
CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components which
have special characteristics important for safety and should be replaced only with types identical to those in the original
circuit or specified in the parts list. The mounting position of replacements is to be identical with originals. Before replacing
any of these components, read carefully the SERVICE SAFETY PRECAUTIONS. Do not degrade the safety of the receiver
through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model
number and Description.
• The PC board assembly with ∗ mark is no longer available after the end of the production.
CHASSIS AND CABINET REPLACEMENT PARTS LIST
Model : 32HL85
Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
CAPACITORS
C102 76073019 ELECTROLYTIC, 10V 470UF M 3A
C103 76109102 CERAMIC CHIP, 50V B 1000PF K
C104 76073084 ELECTROLYTIC, 50V 4.7UF M 3A
C105 76073019 ELECTROLYTIC, 10V 470UF M 3A
C108 76092730 CERAMIC CHIP, 16V B 0.1UF K
C121 76105560 CERAMIC CHIP, 50V CH 56PF J
C123 76105470 CERAMIC CHIP, 50V CH 47PF J
C124 76105220 CERAMIC CHIP, 50V CH 22PF J
C16176109102 CERAMIC CHIP, 50V B 1000PF K
C16276105101 CERAMIC CHIP, 50V CH 100PF J
C16476092730 CERAMIC CHIP, 16V B 0.1UF K
C605 76109102 CERAMIC CHIP, 50V B 1000PF K
C60676109102 CERAMIC CHIP, 50V B 1000PF K
C65676797100 ELECTROLYTIC, 50V 10UF M
C66076669479 ELECTROLYTIC, 50V 4.7UF M
C66176669479 ELECTROLYTIC, 50V 4.7UF M
C66276109681 CERAMIC CHIP, 50V B 680PF K
C66376109681 CERAMIC CHIP, 50V B 680PF K
C670 76669100 ELECTROLYTIC, 50V 10UF M
C671 76669100 ELECTROLYTIC, 50V 10UF M
C673 76667470 ELECTROLYTIC, 25V 47UF M 3A
C674 76073081 ELECTROLYTIC, 50V 1UF M 3A
C675 76669339 ELECTROLYTIC, 50V 3.3UF M
C67676796101 ELECTROLYTIC, 35V 100UF M
C678 76503041 PLASTIC FILM , 63V 0.1UF J
C679 76503041 PLASTIC FILM , 63V 0.1UF J
C680 76073072 ELECTROLYTIC, 35V 1000UF M 3A
C681 76073072 ELECTROLYTIC, 35V 1000UF M 3A
C682 76073072 ELECTROLYTIC, 35V 1000UF M 3A
C684 76109103 CERAMIC CHIP, 50V B 0.01UF K
C685 76109103 CERAMIC CHIP, 50V B 0.01UF K
C801 76503507 PLASTIC FILM, AC275V 0.22UF K
C802 76503507 PLASTIC FILM, AC275V 0.22UF K
C803 76503250 PLASTIC FILM 7E2G224J-SC
C804 76214103 CERAMIC DISC, 500V B 0.01UF K
C805 76092281 CERAMIC DISC, AC250V E 4700PF
C80676092281 CERAMIC DISC, AC250V E 4700PF
C810 76073233 ELECTROLYTIC, 200V 560UF M
C811 76092569 CERAMIC DISC, AC250V E 2200PF M
C812 76092569 CERAMIC DISC, AC250V E 2200PF M
C813 76503047 PLASTIC FILM, 63V 0.33UF J
C815 76503049 PLASTIC FILM, 63V 0.47UF J
C81676073183 ELECTROLYTIC CE04P 35V 220UF M 3A
C817 76567224 PLASTIC FILM, 50V 0.22UF J
C819 76214101 CERAMIC DISC, 500V B 100PF K
C820 76567224 PLASTIC FILM, 50V 0.22UF J
C821 76092343 CERAMIC DISC, 2KV 680PF K
C822 76092344 CERAMIC DISC, 2KV 820PF K
C823 76092341 CERAMIC DISC, 2KV R 470PF K
C824 76591102 PLASTIC FILM, 50V 1000PF J
C825 76503053 PLASTIC FILM, 63V 1UF J
C82676092341 CERAMIC DISC, 2KV R 470PF K
C827 76678229 ELECTROLYTIC, 200V 2.2UF M 3A
C851 76092538 CERAMIC CHIP, 10V F 1UF Z
C852 76109102 CERAMIC CHIP, 50V B 1000PF K
C883 76073193 ELECTROLYTIC, 35V 2200UF M 3A
C884 76073193 ELECTROLYTIC, 35V 2200UF M 3A
C889 76073094 ELECTROLYTIC, 50V 1000UF M 3A
C890 76503047 PLASTIC FILM, 63V 0.33UF J
C6600 76797470 ELECTROLYTIC, 50V 47UF M
C6601 76085944 ELECTROLYTIC, NP, 50V 2.2UF M 11L
C6602 76085944 ELECTROLYTIC, NP, 50V 2.2UF M 11L
C6603 76797229 ELECTROLYTIC, 50V 2.2UF M
C6604 76797229 ELECTROLYTIC, 50V 2.2UF M
C660676797229 ELECTROLYTIC, 50V 2.2UF M
C6607 76797229 ELECTROLYTIC, 50V 2.2UF M
C6615 76797229 ELECTROLYTIC, 50V 2.2UF M
C661676797229 ELECTROLYTIC, 50V 2.2UF M
C6990 76206478 ELECTROLYTIC, 50V 0.47UF M 7L 3A
C8001 76073072 ELECTROLYTIC, 35V 1000UF M 3A
C8110 76073233 ELECTROLYTIC, 200V 560UF M
CB01 76202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB02 76202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB03 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CB04 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CB05 76202221 ELECTROLYTIC, 10V 220UF M 7L 3A
CB38 76100104 CERAMIC CHIP, 25V F 0.1UF Z
CC11 76109102 CERAMIC CHIP, 50V B 1000PF K
CC12 76109102 CERAMIC CHIP, 50V B 1000PF K
CE04 76092281 CERAMIC DISC, AC250V E 4700PF
CE05 76092281 CERAMIC DISC, AC250V E 4700PF

Location Parts No.Description
No.
Location Parts No.Description
No.
- 19 -
CE07 76503049 PLASTIC FILM, 63V 0.47UF J
CE09 76668339 ELECTROLYTIC, 35V 3.3UF M 3A
CE10 76073217 ELECTROLYTIC, 200V 560UF M
CE12 76503041 PLASTIC FILM , 63V 0.1UF J
CE13 76092561 CERA CAP B 250V 101 CD70-B2GA101KYNS
CE14 76092561 CERA CAP B 250V 101 CD70-B2GA101KYNS
CE1676073181 ELECTROLYTIC CE04P 35V 56UF M 3A
CE17 76092339 CERAMIC DISC, 2KV 330PF K
CE18 76503253 PLASTIC FILM, 1250VH 0.01UF H
CE23 76214471 CERAMIC DISC, 500V B 470PF K
CE24 76285104 CERAMIC CHIP, 50V B 0.1UF K
CE29 76436561 CERAMIC DISC, 50V SL 560PF J
CE40 76073183 ELECTROLYTIC CE04P 35V 220UF M 3A
CE42 76539104 PLASTIC FILM, 50V 0.1UF J
CE43 76503041 PLASTIC FILM , 63V 0.1UF J
CE51 76617023 ELECTROLYTIC, 16V 330UF M
CE52 76092179 CERAMIC CHIP, 25V B 0.22UF K
CE53 76092179 CERAMIC CHIP, 25V B 0.22UF K
CE55 76073181 ELECTROLYTIC CE04P 35V 56UF M 3A
CE7676073181 ELECTROLYTIC CE04P 35V 56UF M 3A
CE82 76676470 ELECTROLYTIC, 100V 47UF M 3A
CE85 76073186ELECTROLYTIC CE04P 35V 470UF M 3A
CE87 76669100 ELECTROLYTIC, 50V 10UF M
CE90 76503047 PLASTIC FILM, 63V 0.33UF J
CE91 76503041 PLASTIC FILM , 63V 0.1UF J
CE92 76794101 ELECTROLYTIC, 16V 100UF M
CV10 76109102 CERAMIC CHIP, 50V B 1000PF K
CV687
6085988 ELECTROLYTIC, NP, 50V 1UF M 7L
CV72 76794471 ELECTROLYTIC, 16V 470UF M
CV74 76794101 ELECTROLYTIC, 16V 100UF M
CV7676100104 CERAMIC CHIP, 25V F 0.1UF Z
CV78 76797010 ELECTROLYTIC, 50V 1UF M
RESISTORS
R103 76011101 CHIP, 1/20W 100 OHM J
R104 76011103 CHIP, 1/20W 10K OHM J
R105 76011273 CHIP, 1/20W 27K OHM J
R107 76000445 CHIP JUMPER, 1608TYPE
R108 76000445 CHIP JUMPER, 1608TYPE
R110 76011682 CHIP, 1/20W 6.8K OHM J
R111 76011681 CHIP, 1/20W 680 OHM J
R113 76000445 CHIP JUMPER, 1608TYPE
R114 76000445 CHIP JUMPER, 1608TYPE
R115 76011102 CHIP, 1/20W 1K OHM J
R120 76011821 CHIP, 1/20W 820 OHM J
R122 76000445 CHIP JUMPER, 1608TYPE
R16176011102 CHIP, 1/20W 1K OHM J
R16576011392 CHIP, 1/20W 3.9K OHM J
R166 76011472 CHIP, 1/20W 4.7K OHM J
R16776011101 CHIP, 1/20W 100 OHM J
R16876011101 CHIP, 1/20W 100 OHM J
R657 76011473 CHIP, 1/20W 47K OHM J
R658 76011473 CHIP, 1/20W 47K OHM J
R659 76011103 CHIP, 1/20W 10K OHM J
R670 76011472 CHIP, 1/20W 4.7K OHM J
R671 76011472 CHIP, 1/20W 4.7K OHM J
R672 76011182 CHIP, 1/20W 1.8K OHM J
R673 76011182 CHIP, 1/20W 1.8K OHM J
R678 76871229 CHIP, 1/8W 2.2 OHM J
R679 76871229 CHIP, 1/8W 2.2 OHM J
R680 76011103 CHIP, 1/20W 10K OHM J
R681 76011103 CHIP, 1/20W 10K OHM J
R683 76011223 CHIP, 1/20W 22K OHM J
R684 76011104 CHIP, 1/20W 100K OHM J
R685 76011183 CHIP, 1/20W 18K OHM J
R68676011102 CHIP, 1/20W 1K OHM J
R687 76871102 CHIP, 1/8W 1K OHM J
R688 76871102 CHIP, 1/8W 1K OHM J
R689 76871102 CHIP, 1/8W 1K OHM J
R695 76871102 CHIP, 1/8W 1K OHM J
R69676871102 CHIP, 1/8W 1K OHM J
R697 76871102 CHIP, 1/8W 1K OHM J
R801 76004716METAL GLAZE, 1/2W 2.2M OHM J
R803 76366182 CARBON FILM, 1/6W 1.8K OHM J
R805 76366102 CARBON FILM, 1/6W 1K OHM J
R80676552470 OXIDE METAL FILM, 1/2W 47 OHM J
R807 76366153 CARBON FILM, 1/6W 15K OHM J
R808 76552101 OXIDE METAL FILM, 1/2W 100 OHM J
R809 76321689 OXIDE METAL FILM, 1/2W 6.8 OHM J
R812 76552681 OXIDE METAL FILM, 1/2W 680 OHM J
R813 76366120 CARBON FILM, 1/6W 12 OHM J
R814 76552330 OXIDE METAL FILM, 1/2W 33 OHM J
R815 76552100 OXIDE METAL FILM, 1/2W 10 OHM J
R81676011681 CHIP, 1/20W 680 OHM J
R817 76382823 0XIDE FILM 1W 82K J
R821 76382680 OXIDE METAL FILM, 1W 68 OHM J
R827 76383103 OXIDE METAL FILM, 2W 10K OHM J
R850 76011101 CHIP, 1/20W 100 OHM J
R851 76011102 CHIP, 1/20W 1K OHM J
R852 76011471 CHIP, 1/20W 470 OHM J
R853 76011103 CHIP, 1/20W 10K OHM J
R854 76011102 CHIP, 1/20W 1K OHM J
R855 76011471 CHIP, 1/20W 470 OHM J
R85676011102 CHIP, 1/20W 1K OHM J
R857 76011471 CHIP, 1/20W 470 OHM J
R858 76011471 CHIP, 1/20W 470 OHM J
R859 76011102 CHIP, 1/20W 1K OHM J
R86176007416CERAMIC COVERED, 5W 82 OHM J
R86276120002 CERAMIC COVERED G 5W 68 J
R873 76366152 CARBON FILM, 1/6W 1.5K OHM J
R890 76011102 CHIP, 1/20W 1K OHM J
R899 76004718 METAL GLAZE, 1/2W 8.2M OHM J
R6555 76011103 CHIP, 1/20W 10K OHM J
R655676011103 CHIP, 1/20W 10K OHM J
R6601 76011223 CHIP, 1/20W 22K OHM J
R6602 76011103 CHIP, 1/20W 10K OHM J
R6603 76011104 CHIP, 1/20W 100K OHM J
R6604 76011102 CHIP, 1/20W 1K OHM J
R6614 76011102 CHIP, 1/20W 1K OHM J
R6615 76011102 CHIP, 1/20W 1K OHM J
R661676011104 CHIP, 1/20W 100K OHM J
R6617 76011104 CHIP, 1/20W 100K OHM J
R6620 76011101 CHIP, 1/20W 100 OHM J
R6622 76011100 CHIP, 1/20W 10 OHM J
R6623 76011100 CHIP, 1/20W 10 OHM J
R6624 76011100 CHIP, 1/20W 10 OHM J
R6625 76011473 CHIP, 1/20W 47K OHM J
R662676011473 CHIP, 1/20W 47K OHM J
R6627 76011473 CHIP, 1/20W 47K OHM J
R6628 76011473 CHIP, 1/20W 47K OHM J
R6629 76011103 CHIP, 1/20W 10K OHM J
R6630 76011103 CHIP, 1/20W 10K OHM J
R6633 76011100 CHIP, 1/20W 10 OHM J
R6634 76011100 CHIP, 1/20W 10 OHM J
R6635 76011473 CHIP, 1/20W 47K OHM J
R663676011473 CHIP, 1/20W 47K OHM J
R6638 76011473 CHIP, 1/20W 47K OHM J
R6639 76011473 CHIP, 1/20W 47K OHM J
R6657 76011100 CHIP, 1/20W 10 OHM J
R6658 76011473 CHIP, 1/20W 47K OHM J
R6659 76011101 CHIP, 1/20W 100 OHM J
R666076011473 CHIP, 1/20W 47K OHM J

Location Parts No.Description
No.
Location Parts No.Description
No.
- 20 -
RA71 76011683 CHIP, 1/20W 68K OHM J
RA72 76011223 CHIP, 1/20W 22K OHM J
RA73 76011103 CHIP, 1/20W 10K OHM J
RA74 76000445 CHIP JUMPER, 1608TYPE
RA77 76011103 CHIP, 1/20W 10K OHM J
RA78 76000445 CHIP JUMPER, 1608TYPE
RA79 76000445 CHIP JUMPER, 1608TYPE
RB08 76011470 CHIP, 1/20W 47 OHM J
RB09 76011470 CHIP, 1/20W 47 OHM J
RB15 76011471 CHIP, 1/20W 470 OHM J
RB24 76000445 CHIP JUMPER, 1608TYPE
RC11 76011821 CHIP, 1/20W 820 OHM J
RC12 76011821 CHIP, 1/20W 820 OHM J
RE03 76553683 OXIDE METAL FILM, 1W 68K OHM J
RE04 76553683 OXIDE METAL FILM, 1W 68K OHM J
RE05 76554683 OXIDE RES 2W 68K J
RE12 76552221 OXIDE METAL FILM, 1/2W 220 OHM J
RE13 76366473 CARBON FILM, 1/6W 47K OHM J
RE15 76366102 CARBON FILM, 1/6W 1K OHM J
RE1676366102 CARBON FILM, 1/6W 1K OHM J
RE17 76366363 CARBON FILM, 1/6W 36K OHM J
RE18 76019463 METAL PLATE, 2W 0.22 OHM J
RE19 76310829 OXIDE METAL FILM, 1/2W 8.2 OHM J
RE23 76552152 OXIDE METAL FILM, 1/2W 1.5K OHM J
RE41 76011152 CHIP, 1/20W 1.5K OHM J
RE42 76871222 CHIP, 1/8W 2.2K OHM J
RE43 76011753 CHIP, 1/20W 75K OHM J
RE44 76000593 METAL FILM CHIP 1/16W 10K F
RE4676000448 CHIP, 1/16W 1.8K OHM F
RE48 76011222 CHIP, 1/20W 2.2K OHM J
RE51 76011393 CHIP, 1/20W 39K OHM J
RE52 76011152 CHIP, 1/20W 1.5K OHM J
RE53 76871222 CHIP, 1/8W 2.2K OHM J
RE54 76871222 CHIP, 1/8W 2.2K OHM J
RE5676190012 METAL FILM CHIP 1/16W 1.5K F
RE57 76190012 METAL FILM CHIP 1/16W 1.5K F
RE58 76190013 CHIP RES 1/16W 22K F
RE59 76011334 CHIP, 1/20W 330K OHM J
RE6076011473 CHIP, 1/20W 47K OHM J
RE6176190014 METAL FILM CHIP 1/16W 18K F
RE82 76011473 CHIP, 1/20W 47K OHM J
RE83 76011473 CHIP, 1/20W 47K OHM J
RE84 76011152 CHIP, 1/20W 1.5K OHM J
RE87 76011473 CHIP, 1/20W 47K OHM J
RE88 76011103 CHIP, 1/20W 10K OHM J
RE91 76011103 CHIP, 1/20W 10K OHM J
RE93 76011223 CHIP, 1/20W 22K OHM J
RE94 76871271 CHIP, 1/8W 270 OHM J
RE95 76553122 OXIDE METAL FILM, 1W 1.2K OHM J
RE9676011473 CHIP, 1/20W 47K OHM J
RE97 76553681 0XIDE RES 1W 68 J
RE98 76011104 CHIP, 1/20W 100K OHM J
RV07 76011750 CHIP, 1/20W 75 OHM J
RV18 76011750 CHIP, 1/20W 75 OHM J
RV19 76011750 CHIP, 1/20W 75 OHM J
RV20 76000445 CHIP JUMPER, 1608TYPE
RV21 76011750 CHIP, 1/20W 75 OHM J
RV22 76000445 CHIP JUMPER, 1608TYPE
RV23 76000445 CHIP JUMPER, 1608TYPE
RV25 76011750 CHIP, 1/20W 75 OHM J
RV2676011750 CHIP, 1/20W 75 OHM J
RV27 76011750 CHIP, 1/20W 75 OHM J
RV28 76011750 CHIP, 1/20W 75 OHM J
RV29 76011750 CHIP, 1/20W 75 OHM J
RV30 76011750 CHIP, 1/20W 75 OHM J
RV40 76000445 CHIP JUMPER, 1608TYPE
RV41 76000445 CHIP JUMPER, 1608TYPE
RV42 76000445 CHIP JUMPER, 1608TYPE
RV43 76000445 CHIP JUMPER, 1608TYPE
RV44 76000445 CHIP JUMPER, 1608TYPE
RV7676011750 CHIP, 1/20W 75 OHM J
RV79 76000445 CHIP JUMPER, 1608TYPE
RV82 76011822 CHIP, 1/20W 8.2K OHM J
RV123 76872750 CHIP, 1/16W 75 OHM J
COIL & TRANSFORMERS
L101 23248398 COIL, CHOKE, TLN3278D
L102 23103828 INDUCTOR, BEAD, TEM2121M
L103 23103828 INDUCTOR, BEAD, TEM2121M
L122 23246654 COIL, CHIP, TRF4220CG
L801 23217782 TRANSFORMER, CHOKE 8.1MH 3.0A TPW2067AS
L802 23217783 TRANSFORMER, CHOKE 3.05MH 3.0A TPW2068AS
L805 23103302 FERRITE CHOKE, TEM2011AH
L80623248417 COIL, CHOKE, TLN3481AH
L807 23248417 COIL, CHOKE, TLN3481AH
L874 23103302 FERRITE CHOKE, TEM2011AH
L875 23103302 FERRITE CHOKE, TEM2011AH
L87623103302 FERRITE CHOKE, TEM2011AH
L878 23103302 FERRITE CHOKE, TEM2011AH
L883 23248466 COIL, CHOKE COIL 4.7MMH 8.0A TLN3551AH
L888 23248432 COIL, CHOKE, TLN3499AH
L921 75001248 CHIP BEADS INDUCTOR
L922 75001248 CHIP BEADS INDUCTOR
L923 75001248 CHIP BEADS INDUCTOR
L925 75001248 CHIP BEADS INDUCTOR
L92675001248 CHIP BEADS INDUCTOR
L930 75001248 CHIP BEADS INDUCTOR
L931 75001248 CHIP BEADS INDUCTOR
L932 75001248 CHIP BEADS INDUCTOR
L933 75001248 CHIP BEADS INDUCTOR
L934 75001248 CHIP BEADS INDUCTOR
L935 75001248 CHIP BEADS INDUCTOR
L93675001248 CHIP BEADS INDUCTOR
L943 75001248 CHIP BEADS INDUCTOR
LE11 23103302 FERRITE CHOKE, TEM2011AH
LE52 23289025 COIL, PEAKING, TRF4330AT
LE53 23248399 COIL, CHOKE, TLN3283D
LE73 23248417 COIL, CHOKE, TLN3481AH
LE74 23248417 COIL, CHOKE, TLN3481AH
T801 23211881 COIL, LINE FILTER 34X25.5H 13MH TRF3252AD
T802 23211881 COIL, LINE FILTER 34X25.5H 13MH TRF3252AD
T862 23217804 TRANSFORMER,CONVERTERTPW3562BS
TE62 23217805 TRANSFORMER,CONVERTERTPW3563BS
SEMICONDUCTORS
Q101 23205506TRANSISTOR, 2SC4081 Q
Q102 23205507 TRANSISTOR, 2SA1576A Q
Q161 23205506TRANSISTOR, 2SC4081 Q
Q651 23205325 TRANSISTOR,RN2404(F)
Q652 23205302 TRANSISTOR,2SC3326-B(F)
Q653 23205302 TRANSISTOR,2SC3326-B(F)
Q662 23205325 TRANSISTOR,RN2404(F)
Q663 23205506TRANSISTOR, 2SC4081 Q
Q664 23205506TRANSISTOR, 2SC4081 Q
Q670 23085039 IC, TA8246AHQ
Q671 23205302 TRANSISTOR,2SC3326-B(F)
Q672 23205302 TRANSISTOR,2SC3326-B(F)
Q673 23205443 TRANSISTOR,2SA1162-Y(F)
Q801 23135087 IC, HYBRID VDS=200V STR-Z4317
Q82623000823 IC, PHOTO COUPLER, TLP421F(GR)
Q851 23205446TRANSISTOR, 2SC2412K, Q T146
Q852 23205446TRANSISTOR, 2SC2412K, Q T146
