Toshiba Cinema REGZA 52XV648U User manual

LEADING THE WAY IN
HOME ENTERTAINMENT
INNOVATION
52XV648U
1080p Full HD LCD TV
with ClearFrame™ 120Hz
LEADING THE WAY IN
HOME ENTERTAINMENT
INNOVATION
52XV648U 52.0” diagonal 1080p HD LCD TV with ClearFrame™ 120Hz
PRELIMINARY
ADVANTAGE
• 1080p Full HD CineSpeed®Display
• ClearFrame™ 120Hz with 5:5 Pull-Down Option
• 50,000:1 Dynamic Contrast Ratio
• CrystalCoat™ Contrast Enhancer
• Resolution+™1Super Resolution Technology
• PixelPure®5G 14-Bit Internal Digital Video Processor
• AutoView™ Automatic Picture Adjustment
• ColorMasterTM Wide Color Enhancer
• Dolby®Volume Automatically Adjusts Uneven Volume Levels
• DynaLight™ Dynamic Backlight Control for Deep Black Levels
• Gaming Mode for Fast Game Controller Response
• 3 HDMI™ Digital Inputs with REGZA-LINK®2
• High-Res PC Input (S-XGA, 15 Pin, D-sub)
• ATSC/QAM Digital Tuner for Over-the-Air and Cable-in-the-Clear Digital Tuning
• Bottom Deep Lagoon™ Design with Invisible Speakers
NEW
NEW
NEW

52XV648U
The REGZA®XV648 Cinema Series®introduces Crystal-
Coat™ for 30%+ more contrast in bright rooms3, and
Dolby®Volume to maintain a consistent volume level
when changing channels or between commercials. The
result is improved picture and stabilized sound for an
enhanced home theater experience.
New CrystalCoatTM -- You may watch TV at night in a dark room, but
sometimes you may keep the lights on and have a bright room, or watch
the game on Sunday afternoon with even brighter sunlight coming through
the windows. Extra room light can lower the contrast on some TVs, but with
CrystalCoatTM, you don’t have to worry. CrystalCoatTM stops ambient room
light reflections from washing out the picture, creating 30%+ better contrast
in bright rooms3. Now you can enjoy the deep high contrast REGZA®picture
in all room light conditions.
New Dolby® Volume -- If you have ever been bothered by loud TV commer-
cials or inconsistent volume when changing channels, Dolby®Volume technol-
ogy is the solution. Advanced algorithms monitor the audio during programs,
when commercials start, and when changing channels. Louder programming
is brought down, while lower programming is brought up. This ensures a con-
sistent volume level with full dynamic range at all times.
ClearFrame™ 120Hz -- Doubles the video frames from 60 per second to
120 per second to reduce any motion blur that could be caused by fast ac-
tion video. By using advanced motion vector frame interpolation, it improves
picture clarity without affecting picture brightness or adding flicker. For those
that prefer a more film-like picture, there is also a 5:5 Pull-Down option avail-
able.
Resolution+™1-- Some video content is in high definition (HD), but some is
still in standard definition (SD). However, REGZA®virtually levels the content
playing field with Resolution+™. Resolution+™ is super resolution technology
that upconverts and enhances 480i, 480p, and even 720p content to create
a sharper, more detailed picture. With REGZA®and Resolution+™ all of
your standard DVDs, SD TV channels, camcorder videos, and even SD video
games will feel like HD.
SERIES: REGZA®
Cabinet Bottom Deep LagoonTM Design
Screen Size (measured diagonally) 52.0”
LCD PANEL:
Resolution 1080p
Dynamic Backlight Control DynaLightTM
Response Time CineSpeed®
CrystalCoatTM Contrast Enhancer •
VIDEO:
Digital Video Processor PixelPure®5G 14 Bit
Resolution+TM1 •
AutoViewTM •
Video Scan Rate ClearFrameTM 120Hz
Cinema Mode 24fps45:5 Pull-Down
TheaterWide®Modes •
Color Temperature Control •
ColorMasterTM Wide Color Enhancer •
Native ModeTM •
Deep Color •
AUDIO:
Speaker System Invisible
Volume Limiter Dolby® Volume
Mute/Half Mute •
CONVENIENCE:
Built-in TV Tuning NTSC/ATSC/QAM
Auto Aspect Control •
Sleep Timer •
REGZA-LINK®(HDMITM-CEC)2 •
Gaming Mode •
Channel BrowserTM •
Channel Labeling •
Input Labeling •
Expert Mode •
Logo Light On/Off •
ENERGY STAR®3.0 Compliant •
JACK PACK:
HDMITM v1.3 Digital Inputs with InstaPortTM 3 (1 Side)
ColorStream®Component Video Inputs 2
Side A/V / Rear A/V / Rear S-Video 1 / 1 /1
High Res PC Input (S-XGA, 15 Pin, D-sub) 1
Analog Audio Out Fixed
Dolby®Digital Optical Out •
REMOTE CONTROL:
Type 4 Item Universal5
PRODUCT & PACKAGING:
VESA®Mounting Pattern6200 x 400
Unit Dimensions (WHD) in. (with stand) 49.29 x 33.03 x 13.86
Unit Dimensions (WHD) in. (without stand) 49.29 x 31.14 x 3.94
Carton Dimensions (WHD) in. 54.41 x 36.81 x 18.31
Unit Weight (with stand) 71.6 lbs.
Carton Weight 92.6 lbs.
UPC Code 022265002889
1Effect of Resolution+TM enhancements may vary depending upon the input signal and content quality.
2Use of REGZA-LINK®which is a feature based on HDMITM-CEC requires an HDMITM-CEC compatible peripheral device. Depending on the specifications of your device, some or all REGZA-LINK®
functions may not work even if your device is HDMITM-CEC compatible.
3”Bright rooms” are defined as rooms with light intensity measuring 200 or more lux.
4Viewing 24 frames per second requires content created in 480p / 24 frames/second.
5In some cases, the universal remote may not operate additional devices or certain features of such devices, in which case, it is suggested that you use the original remote control for the applicable
device.
6If you decide to wall mount your Toshiba television, always use a UL Listed wall bracket appropriate for the size and weight of the television.
