Toshiba ML2-EC09SAIT User manual

MICROWAVE OVEN
INSTRUCTION MANUAL
Please review this instruction manual before operating.
ML2-EC09SAIT(BS)

PRODUCT SAFETY
Precautions to avoid possible exposure to excessive microwave energy.................................... EN-01
Important safety instructions ....................................................................................................................... EN-03
Grounding instructions................................................................................................................................... EN-07
Radio interference ............................................................................................................................................ EN-09
Utensils.................................................................................................................................................................. EN-10
Materials you can use in microwave oven ............................................................................................... EN-11
Materials can not be used in microwave oven ...................................................................................... EN-13
PRODUCT SETTING
Setting up your oven ....................................................................................................................................... EN-14
INSTRUCTION FOR USE
Before using for the rst time ....................................................................................................................... EN-17
Operation............................................................................................................................................................. EN-18
1. Clock setting.................................................................................................................................................. EN-19
2. Microwave cooking .................................................................................................................................... EN-19
3. Kitchen timer setting ................................................................................................................................. EN-20
4. Lock function ................................................................................................................................................ EN-21
5. Eco function .................................................................................................................................................. EN-21
6. Grill cooking .................................................................................................................................................. EN-21
CONTENTS

7. Combination cooking ............................................................................................................................... EN-22
8. Speedy cooking ........................................................................................................................................... EN-23
9. Convection without preheat................................................................................................................... EN-23
10. Convection with preheat ....................................................................................................................... EN-24
11. Auto menu .................................................................................................................................................. EN-24
12. Homefry........................................................................................................................................................ EN-25
13. Pro defrost ................................................................................................................................................... EN-26
Cleaning................................................................................................................................................................ EN-29
MAINTENANCE
Trouble shooting............................................................................................................................................... EN-31
One year limited warranty ............................................................................................................................. EN-33
BEFORE OPERATING THIS PRODUCT, READ,
UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
BE SURE TO SAVE THIS BOOKLIST FOR FUTURE
REFERENCE.
NOTE

EN-01
PRODUCT SAFETY
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a). Do not attempt to operate this oven with the door open
since open door operation can result in harmful exposure to
microwave energy.
It is important not to defeat or tamper with the safety
interlocks.
(b). Do not place any object between the
oven front face and the door or allow
soil or cleaner residue to accumulate on
sealing surfaces.
(c). Do not operate the oven if it is damaged. It is particularly
important that the oven door closes properly and that there is
no damage to the:
(1). DOOR (bent)
(2). HINGES AND LATCHES (broken or loosened)
(3). DOOR SEALS AND SEALING SURFACES
(d). The oven should not be adjusted or repaired by anyone
except properly qualied service personnel.

EN-02
SPECIFICATIONS
MODEL
RATED VOLTAGE
RATED INPUT POWERMICROWAVE
RATED OUTPUT POWERMICROWAVE
RATED INPUT POWER GRILL
RATED INPUT POWER CONVECTION
ML2-EC09SAIT(BS)
120V~ 60Hz
1400W
900W
1000W
1800W
All pictures in this manual are for illustrative purposes only; these may be
slightlydifferentfromthe purchasedequipment,please refer tothe
actual product.
NOTE
PRODUCT SIZE 19.47 x 17.60 x 11.47 inch
WEIGHT 28.66 lbs NET

EN-03
IMPORTANT SAFETY INSTRUCTIONS
Read all instructions before
using the appliance.
Read and follow the
specific:
"PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO
EXCESSIVE MICROWAVE
ENERGY" found on page 1.
This appliance must be
grounded. Connect only to
properly grounded outlet.
See "GROUNDING
INSTRUCTIONS" found on
page 7.
Install or locate this
appliance only in
accordance with the
provided installation
instructions.
As with any appliance,
close supervision is
necessary when used by
children.
When cleaning surfaces
of door and oven that
comes together on closing
the door, use only mild,
nonabrasive soaps, or
detergent applied with a
sponge or soft cloth.
Keep cord away from
heated surface.
When using electrical appliances basic safety
precautions should be followed, including the
following. To reduce the risk of burns, electric shock,
re, injury to persons or exposure to excessive
microwave energy.
WARNING

EN-04
Liquids, such as water,
coee, or tea are able
to overheat beyond the
boiling point without
appearing to be boiling.
Visible bubbling or boiling
when the container
is removed from the
microwave oven is not
always present.
THIS COULD RESULT
IN VERY HOT LIQUID
SUDDENLY BOILING OVER
WHEN THE CONTAINER IS
DISTURBED OR A UTENSIL
IS INSERTED INTO THE
LIQUID. To reduce the risk
of injury to persons:
1. Do not overheat the
liquid.
2. Stir the liquid both
before and halfway
through heating it.
3. Do not use straight-
sided containers with
narrow necks.
4. After heating, allow
the container to stand
in the microwave oven
for a short time before
removing the container.
5. Use extreme care when
inserting a spoon or
other utensil into the
container.
Oversized food or
oversized metal utensils
should not be inserted in
a microwave/toaster oven
as they may create a fire or
risk of electric shock.
This appliance should be
serviced only by qualied
service personnel.
Contact nearest authorized
service facility for
examination, repair, or
adjustment.
IMPORTANT SAFETY INSTRUCTIONS

EN-05
To reduce the risk of fire in
the oven cavity:
1. Do not overcook
food. Carefully attend
appliance when
paper, plastic, or other
combustible materials
are placed inside
the oven to facilitate
cooking.
2. Remove wire twist-ties
from paper or plastic
bag before placing bag
in oven.
3. If material inside of the
oven ignite, keep oven
door closed, turn oven
o, and disconnect the
power cord, or shut o
power at the fuse or
circuit breaker panel.
4. Do not use the cavity
for storage purposes.
Do not leave paper
products, cooking
utensils, or food in the
cavity when not in use.
Some products such as
whole eggs and sealed
containers, for example,
closed glass jars are able to
explode and should not be
heated in this oven.
Do not store this appliance
outdoors. Do not use this
product near water - for
example, near a kitchen
sink, in a wet basement,
near a swimming pool, or
similar location.
Do not immerse cord or
plug in water or any other
liquid.
IMPORTANT SAFETY INSTRUCTIONS

EN-06
IMPORTANT SAFETY INSTRUCTIONS
Do not let cord hang over
edge of table or counter.
Do not use paper products
when appliance is operated
in the toaster mode.
Do not operate this
appliance if it has a
damaged cord or plug, if it
is not working properly, or
if it has been damaged or
dropped.
Do not cover or block any
openings on the appliance.
Do not clean with metal
scouring pads.
Pieces can burn o the pad
and touch electrical parts
involving a risk of electric
shock.
Use this appliance only
for its intended use as
described in the manual.
Do not use corrosive
chemicals or vapors in
this appliance. This type
of oven is specifically
designed to heat, cook or
dry food.
It is not designed for
industrial or laboratory use.
Do not store any materials,
other than manufacturer's
recommended accessories,
in this oven when not in
use.
Do not cover racks or any
other part of the oven with
metal foil. This will cause
over-heating of the oven.
SAVE THESE INSTRUCTIONS

EN-07
GROUNDING INSTRUCTIONS
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current. This appliance is
equipped with a cord having a grounding wire with a grounding
plug. The plug must be plugged into an outlet that is properly
installed and grounded.
WARNING - Improper use of the grounding can result in a risk of
electric shock. Consult a qualified electrician or serviceman if the
grounding instructions are not completely understood, or if doubt
exists as to whether the appliance is properly grounded. If it is
necessary to use an extension cord, use only a 3-wire extension
cord that has a 3-blade grounded plug, and 3-slot receptacle
that will accept the plug on the appliance. The marked rating of
the extension cord shall be equal to or greater than the electrical
rating of the appliance.
Electric Shock Hazard:
Touching some of the internal components can
cause serious personal injury or death. Do not
disassemble this appliance.
DANGER

EN-08
GROUNDING INSTRUCTIONS
Electric Shock Hazard:
Improper use of the grounding can result in electric
shock. Do not plug into an outlet until appliance is
properly installed and grounded.
1. A short power-supply cord is provided to reduce
the risks resulting from becoming entangled in or
tripping over a longer cord.
2. Longer cord sets or extension cords are available
and may be used if care is exercised in their use.
3. If a long cord or extension cord is used:
(1). The marked electrical rating of the cord set or
extension cord should be at least as great as
the electrical rating of the appliance.
(2). The extension cord must be a grounding-type
3-wire cord.
(3). The longer cord should be arranged so that it
will not drape over the counter top or tabletop
where it can be pulled on by children or
tripped over unintentionally.
WARNING

EN-09
RADIO INTERFERENCE
1. Operation of the microwave oven may cause interference to
your radio, TV or similar equipment.
2. When there is interference, it may be reduced or eliminated by
taking the following measures:
(1).Clean door and sealing surface of the oven.
(2).Reorient the receiving antenna of radio or television.
(3).Relocate the microwave oven with respect to the receiver.
(4).Move the microwave oven away from the receiver.
(5).Plug the microwave oven into a dierent outlet so that
microwave oven and receiver are on dierent branch circuits.
This device complies
with part 18 of the FCC
Rules.

EN-10
UTENSILS
Personal Injury Hazard:
Tightly-closed utensils could explode. Closed
containers should be opened and plastic pouches
should be pierced before cooking.
See the instructions on "Materials you can use in
microwave oven or to be avoided in microwave
oven."
There may be certain non-metallic utensils that are
not safe to use for microwaving. If in doubt, you can
test the utensil in question following the procedure
below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup
of cold water (8.5 oz) along with the utensil
in question.
2. Cook on maximum power for 1 min.
3. Carefully feel the utensil. If the empty
utensil is warm, do not use it for microwave
cooking.
4. Do not exceed 1 min cooking time.
KEEP THE CAVITY CLEAN
CAUTION
NOTE

EN-11
MATERIALS YOU CAN USE IN
MICROWAVE OVEN
UTENSILS REMARKS
Browning dish
Follow manufacturer’s instructions.
The bottom of browning dish must be at least 3/16 inch
(5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Dinnerware
Microwave-safe only. Follow manufacturer’s
instructions. Do not use cracked or chipped dishes.
Glass jars
Always remove lid. Use only to heat food until just
warm. Most glass jars are not heat resistant and may
break.
Glassware
Heat-resistant oven glassware only. Make sure there is
no metallic trim. Do not use cracked or chipped dishes.
Oven cooking bags
Follow manufacturer’s instructions. Do not close with
metal tie.
Make slits to allow steam to escape.
Paper plates and cups
Use for short–term cooking/warming only. Do not leave
oven unattended while cooking.
Paper towels
Use to cover food for reheating and absorbing fat. Use
with supervision for a short-term cooking only.
Parchment paper
Use as a cover to prevent splattering or a wrap for
steaming.
Microwave-safe only. Follow the manufacturer’s
instructions. Should be labeled“Microwave Safe”. Some
plastic containers soften, as the food inside gets hot.
“Boiling bags”and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Plastic

EN-12
UTENSILS REMARKS
Microwave-safe only. Use to cover food during cooking
to retain moisture. Do not allow plastic wrap to touch
food.
Microwave-safe only (meat and candy thermometers).
Use as a cover to prevent splattering and retain
moisture.
MATERIALS YOU CAN USE IN
MICROWAVE OVEN
Plastic wrap
Thermometers
Wax paper

EN-13
MATERIALS CAN NOT BE USED IN
MICROWAVE OVEN
UTENSILS REMARKS
Aluminum tray
May cause arcing. Transfer food into microwave-safe
dish.
Food carton with metal
handle
May cause arcing. Transfer food into microwave-safe
dish.
Metal or metal trimmed
utensils
Metal shields the food from microwave energy.
Metal trim may cause arcing.
Metal twist ties
May cause arcing and could cause a fire in the oven.
Paper bags
May cause a fire in the oven.
Plastic foam
Plastic foam may melt or contaminate the liquid
inside when exposed to high temperature.
Wood
Wood will dry out when used in the microwave oven
and may split or crack.

EN-14
PRODUCT SETTING
SETTING UP YOUR OVEN
NAMES OF MICROWAVE OVEN PARTS AND ACCESSORIES
Remove the oven and all materials from the carton and oven cavity.
A. Control panel
Instruction Manual
Glass Tray Turntable Ring Assembly
Lower Wire Rack Higher Wire Rack Bake Tray
(Cannot be used in conjunc-
tion with microwave
function and can be placed
on the girll rack)
A
B. Observation window
B
C
C. Door assembly
D
D. Safety interlock system
E
E. Oven cavity
microwave function
and must be placed
( Can not be used in
on the glass tray )
microwave function
and must be placed
( Can not be used in
on the glass tray )

EN-15
SETTING UP YOUR OVEN
TURNTABLE INSTALLATION
Cleaning the cooking compartment and putting the turntable in place.
For new installations, make sure all packaging and shipping tape has been removed from the
turntable shaft.
Before using the appliance to prepare food for the first time, you will need to put the turntable
in place correctly. You must clean the cooking compartment and accessories.
How to put the turntable in place:
1. Place the turntable ring assembly into the
recess in the cooking compartment.
2. Place the glass tray ①on the turntable ring
assemblies .
1) Glass Tray
2) Turntable Ring Assembly
• Never use the appliance without the turntable. Make sure that it is properly
engaged. The turntable can turn clockwise or anti-clockwise.
• Never place the glass tray upside down. The glass tray should never be
restricted.
• Both glass tray and turntable ring assembly must always be used during
cooking.
• All food and containers of food are always placed on the glass tray for cooking.
• Never restrict the movement of the turntable.
• If glass tray or turntable ring assembly cracks or breaks, contact your nearest
authorized service center.
2
1
NOTE
②
②

EN-16
COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven for any damage such as dents or
broken door. Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave oven cabinet surface. Do not
remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron.
INSTALLATION
2. Plug microwave oven into a standard household outlet. Be sure the voltage and the
frequency is the same as the voltage and the frequency on the rating label.
• Do not install oven over a range cooktop or
other heat-producing appliance.
If installed near or over a heat source, the oven
could be damaged and the warranty would be
avoid.
NOTE
1. Select a level surface that provide enough open space for the intake and/or outlet vents.
b.Leave a minimum clearance of 3.0 inches on each side, 3.0 inches on top and 1.0 inch in the rear.
c.Do not remove the legs from the bottom of the oven.
d.Blocking the intake and/or outlet openings can damage the oven.
e.
Please place the oven as far away from radios and TV as possible.
Operation of microwave oven may cause interference to your radio or TV reception.
3.0 inches(7.5cm)
3.0 inches
(7.5cm)
3.0 inches
(7.5cm)
>3.0 ft
(91.6cm)
1.0 inch
(2.5cm)
a. The minimum installation height is 3.0 ft.
The accessible surface may be
hot during operation

EN-17
INSTRUCTION FOR USE
BEFORE USING FOR THE FIRST TIME
The appliance may produce unpleasant odors when it is used for the first time.
This section tells you what you need to do before using your microwave to prepare food for the
first time. Read the section entitled "IMPORTANT SAFETY INSTRUCTIONS" beforehand on page
3.
Before you can use your new appliance, you will need to put the turntable in place correctly. You
must also clean the cooking compartment and accessories.
• Never use the appliance without the turntable.
• Make sure that it is properly engaged.The turntable can turn clockwise or anti-
clockwise.
NOTE Fan may continue to operate after cook cycle completes.
•
