Toshiba MM-EM25P(WH) User manual

MM-EM25P(WH)
INSTRUCTION MANUAL
MICROW AVE OVEN

NOTE
CONTENTS
BEFORE OPERATING THIS PRODUCT, READ, UNDERSTAND, AND
FOLLOW THESE INSTRUCTIONS.BE SURE TO SAVE THIS BOOKLIST
FOR FUTURE REFERENCE
SETTING UP YOUR OVEN............................................................................................... EN-11
CONTROL PANEL.............................................................................................................. EN-14
OPERATION......................................................................................................................... EN-15
TROUBLE SHOOTING....................................................................................................... EN-21
PRODUCT SAFETY
PRODUCT INTRODUCTION
INSTRUCTION FOR USE
MAINTENANCE
PRECAUTIONS TO AVOID POSSIBLE EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY .................................................................................................... EN-5
TO REDUCE THE RISK OF INJURY TO PERSONS GROUNDING
INSTALLATION................................................................................................................... EN-6
MATERIALS YOU CAN USE IN MICROWAVE OVEN ............................................. EN-9
MATERIALS CAN NOT BE USED IN MICROWAVE OVEN ................................... EN-10
IMPORTANT SAFETY INSTRUCTIONS........................................................................ EN-2

PRODUCT SAFETY
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of fire, electric shock, injury to persons or
exposure to excessive microwave oven energy when using
your appliance, follow basic precautions, including the
following:
1. Read and follow the specific:"PRECAUTIONS TO AVOID
POSSIBLE EXPOSURE TO EXCESSIVE MICROWAVE ENERGY".
2. This appliance can be used by children and persons with
reduced physical, sensory or mental capabilities or lack of
experience and knowledge if they have been given
supervision or instruction concerning use of the appliance
in a safe way and understand the hazards involved.
Children shall not play with the appliance. Cleaning and
user maintenance shall not be made by children unless
they are supervised.
3. Keep the appliance and its cord away from children unless
they are continuously supervised.
4. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or similarly qualified persons
in
order to avoid a hazard.
5. WARNING: Ensure that the appliance is switched offbefore
replacing the lamp to avoid the possibility of electric shock.
6.
WARNING: It is hazardous for anyone other than a
competent
person to carry out any service or repair
operation that involves the removal of a cover which gives
protection against exposure to microwave energy.
SAFETY WARNING
EN-2

EN-3
IMPORTANT SAFETY INSTRUCTIONS
7. WARNING: Liquids and other foods must not be heated
in sealed containers since they are liable to explode.
8. When heating food in plastic or paper containers, keep
an eye on the oven due to the possibility of ignition.
9. Only use utensils that are suitable for use in microwave
ovens.
10. If smoke is emitted, switch off or unplug the appliance
and keep the door closed in order to stifle anyflames.
11. Microwave heating of beverages can result in delayed
eruptive boiling, therefore care must be taken when
handling the container.
12. The contents of feeding bottles and baby food jars shall
be stirred or shaken and the temperature checked before
consumption, in order to avoid burns.
13. Eggs in their shell and whole hard-boiled eggs should not
be heated in microwave ovens since they may explode,
even after microwave heating has ended.
14. The oven should be cleaned regularly and any food
deposits removed.
15. Failure to maintain the oven in a clean condition could
lead to deterioration of the surface that could adversely
affect the life of the appliance and possibly result in a
hazardous situation.
16. Only use the temperature probe recommended for this
oven.(for ovens provided with a facility to use
atemperature-sensing probe.)
17. The microwave oven shall not be placed in a cabinet
unless it has been tested in a cabinet.
SAFETY WARNING

IMPORTANT SAFETY INSTRUCTIONS
18. This appliance is intended to be used in household and
similar applications such as:
environments;
environments;
-farm houses;
-bed and breakfast type environments.
19. The microwave oven is intended for heating food and
beverages. Drying of food or clothing and heating of
warming pads, slippers, sponges, damp cloth and similar
may lead to risk of injury, ignition or fire.
20. Metallic containers for food and beverages are not
allowed during microwave cooking.
21. The appliance shall not be cleaned with a steam cleaner.
22. The appliance is intended to be used freestanding.
23. The rear surface of appliances shall be placed against a
wall.
24. The appliances are not intended to be operated by
means of an external timer or separate remote-control
system.
READ CAREFULLY AND KEEP FOR FUTURE REFERENCE
SAFETY WARNING
EN-4
PRODUCT SAFETY
-staff kitchen areas in shops,
offices and other working
-by clients in hotels, motels and other residential type

PRECAUTIONS TO AVOID POSSIBLE EXPOSURE
TO EXCESSIVE MICROWAVE ENERGY
(a) Do not attempt to operate this oven with the door open
since this can result in harmful exposure to microwave
energy. It is important not to break or tamper with the
safety interlocks.
(b) Do not place any object between the oven front face
and the door or allow soil or cleaner residue to
accumulate on sealing surfaces.
(c) WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by
a competent person.
ADDENDUM
If the apparatus is not maintained in a good state of
cleanliness, its surface could be degraded and affect the
life span of the apparatus and lead to a dangerous situation.
SPECIFICATIONS
EN-5
Model:
Rated Voltage:
Power Consumption (Microwave):
Rated Output Power (Microwave):
MM-EM25P(WH)
230V-240V~50Hz
1400W-1450W
850W-900W

DANGER
Electric Shock Hazard
Touching some of the internal components can cause serious
personal injury or death. Do not disassemble this appliance.
WARNING
Electric Shock Hazard
Improper use of the grounding can result in electric shock.
Do not plug into an outlet until appliance is properly installed
and grounded.
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current.
This applianceis equipped with a cord having a grounding
wire with agrounding plug. The plug must be plugged into
an outlet that is properly installed and grounded.
Consult a qualified electrician or serviceman if the grounding
instructions are not completely understood or if doubt exists
as to whether the appliance is properly grounded.
If it is necessary to use an extension cord, use only a 3-wire
extension cord.
1. A short power-supply cord is provided to reduce the risks
resulting from becoming entangled in or tripping over a
longer cord.
2. If a long cord set or extension cord is used:
a. The marked electrical rating of the cord set or extension
cord should be at least as great as the electrical rating of
the appliance.
b.
The extension cord must be a grounding-type 3-wire cord.
c. The long cord should be arranged so that it will not drape
over the counter top or tabletop where it can be pulled
on by children or tripped over unintentionally.
TO REDUCE THE RISK OF INJURY TO PERSONS
GROUNDING INSTALLATION
PRODUCT INTRODUCTION
EN-6

CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly
damp cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must
be cleaned carefully with a damp cloth when they are
dirty.
4. Do not use harsh abrasive cleaners or sharp metal
scrapers to clean the oven door glass since they can
scratch the surface, which may result in shattering of the
glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that
the food cooked can touch: Place half a lemon in a bowl,
add 300ml (1/2 pint) water and heat on 100% microwave
power for 10 minutes. Wipe the oven clean using a soft,
dry cloth.
EN-7

PRODUCT INTRODUCTION
UTENSILS
CAUTION
Personal Injury Hazard
It is hazardous for anyone other than a competent person
to carry out any service or repair operation that involves
the removal of a cover which gives protection against
exposure to microwave energy.
See the instructions on "Materials you can use in microwave
oven or to be avoided in microwave oven. " There may be
certain non-metallic utensils that are not safe to use for
microwaving. If in doubt, you can test the utensil in question
following the procedure below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup of cold water
(250ml) along with the utensil in question.
2. Cook on maximum power for 1 minute.
3. Carefully feel the utensil. If the empty utensil is warm, do
not use it for microwave cooking.
4. Do not exceed 1 minute cooking time.
EN-8

MATERIALS YOU CAN USE IN MICROWAVE OVEN
Browning dish
Dinnerware
Glass jars
Glassware
Oven cooking
bags
Paper plates and
cups
Paper towels
Parchment paper
Plastic
Plastic wrap
Wax paper Use as a cover to prevent splattering and retain moisture.
Microwave-safe only. Use to cover food during cooking to retain
moisture. Do not allow plastic wrap to touch food.
Microwave-safe only. Follow the manufacturer’s instructions.
Should be labeled "Microwave Safe". Some plastic containers
soften, as the food inside gets hot. "Boiling bags" and tightly
closed plastic bags should be slit, pierced or vented as directed
by package.
Use as a cover to prevent splattering or a wrap for steaming.
Use to cover food for reheating and absorbing fat. Use with
supervision for a short-term cooking only.
Use for short–term cooking/warming only. Do not leave oven
unattended while cooking.
Follow manufacturer’s instructions. Do not close with metal tie.
Make slits to allow steam to escape.
Heat-resistant oven glassware only. Make sure there is no
metallic trim. Do not use cracked or chipped dishes.
Always remove lid. Use only to heat food until just warm.
Most glass jars are not heat resistant and may break.
Microwave-safe only. Follow manufacturer’s instructions.
Do not use cracked or chipped dishes.
Follow manufacturer’s instructions.The bottom of browning dish
must be at least 3/16 inch (5mm) above the turntable. Incorrect
usage may cause the turntable to break.
UTENSILS REMARKS
EN-9

PRODUCT INTRODUCTION
UTENSILS REMARKS
MATERIALS TO BE AVOIDED IN MICROWAVE OVEN
Wood
Plastic foam
Paper bags
Metal twist ties
Metal or metal-
trimmed utensils
Food carton with
metal handle
Aluminum tray
Wood will dry out when used in the microwave oven and may
split or crack.
Plastic foam may melt or contaminate the liquid inside when
exposed to high temperature.
May cause a fire in the oven.
May cause arcing and could cause a fire in the oven.
Metal shields the food from microwave energy. Metal trim
may cause arcing.
May cause arcing. Transfer food into microwave-safe dish.
May cause arcing. Transfer food into microwave-safe dish.
EN-10

a. Never place the glass tray upside down.
The glass tray should never be restricted.
b. Both glass tray and turntable ring assembly
must always be used during cooking.
c. All food and containers of food are always
placed on the glass tray for cooking.
d. If glass tray or turntable ring assembly
cracks or breaks, contact your nearest
authorized service center.
Turntable Installation
SETTING UP YOUR OVEN
EN-11
Names of Oven Parts and Accessories
Remove the oven and all materials from the carton and oven cavity.
Your oven comes with the following accessories:
Glass tray 1
Turntable ring assembly 1
Turntable Shaft 1
Instruction Manual 1
D CB
E
G
F
A
A) Control panel
B) Turntable shaft
C) Turntable ring assembly
D) Glass tray
E) Observation window
F) Door assembly
G) Safety interlock system
Turntable ring
ring assembly
Hub (underside)
Glass tray
Turntable
shaft

COUNTERTOP INSTALLATION
INSTALLATION
INSTRUCTION FOR USE
SETTING UP YOUR OVEN
Remove all packing material and accessories. Examine the
oven for any damage such as dents or broken door.
Do not install if oven is damaged.
Cabinet: Remove any protective film found on the microwave
oven cabinet surface. Do not remove the light brown Mica cover
that is attached to the oven cavity to protect the magnetron.
EN-12
a. The minimum installation height is 85cm.
b. The rear surface of appliance shall be placed against a wall.
Leave a minimum clearance of 30cm above the oven, a
minimum clearance of 20cm is required between the oven
and any adjacent walls.
c. Do not remove the legs from the bottom of the oven.
d. Blocking the intake and/or outlet openings can damage the
oven.
e. Place the oven as far away from radios and TV as possible.
Operation of microwave oven may cause interference to your
radio or TV reception.
20cm
min85cm
20cm
30cm
0cm
Side Distance
(cm)
Top 30
Left 20
Right 20
Front Open
Rear 0
Bottom 0
1. Select a level surface that provide enough open space for the
intake and/or outlet vents.

WARNING
SETTING UP YOUR OVEN
Do not install oven over a range cooktop or
other heat-producing appliance. If installed
near or over a heat source, the oven could
be damaged and the warranty would be void.
2. Plug your oven into a standard household outlet. Be sure the
voltage and the frequency is the same as the voltage and the
frequency on the rating label.
EN-13
The accessible surface may
be hot during operation.

CONTROL PANEL
EN-14
INSTRUCTION FOR USE
Weight Defrost
Time Defrost
Clock
Power
Stop/cancel
0/ Memory
Press to set specific cooking mode
memory.
Start/+30sec.
For starting cooking or adding
cooking time of 30sec. by every
press.
Digital Display
kitchen Timer
Auto Menu
Express Cook 1-6MIN
Time Cook

EN-15
OPERATION
11 power levels are available. Press “POWER” to select Level 10. Press the digit on
the Control Panel to select Level 9 to 0. When you select “PL0”, there is no power,
only FAN will work to remove odor in the cabinet.
1. MICROWAVE POWER LEVEL*
Power 100% 90% 80% 70% 60% 50% 40% 30% 20% 10%
Level 10 9 8 7 6 5 4 3 2 1 0
PL10Display PL9 PL8 PL7 PL6 PL5 PL4 PL3 PL2 PL1
0%
PL0
a. The clock system is 12-hour system.
b. Press “CLOCK” will display.
c. Press the number keys and enter the current time. For example, time is 12:10 now,
please press “1, 2, 1, 0” in turn.
d. Press “CLOCK” to finish clock setting. “:” will flash and the clock will be lighted.
e. If the numbers input are not within the range of 1:00--12:59, the setting will be
invalid until valid numbers are input.
2. CLOCK SETTING
a. Press “KITCHEN TIMER” the screen will display 00:00.
b. Press the number keys and enter the timer time. (The maximum setting time is
99 minutes and 99 seconds.)
c. Press “START/+30SEC.” to confirm setting.
d. When the timer time arrives, the buzzer will ring 5 times.
If the clock has been set (12-hour system), the screen will display the current time.
3. KITCHEN TIMER
• In the process of clock setting, if the “STOP/CANCEL” button is pressed
or if there is no operation within 1 minute, the oven will go back to the
former setting automatically.
• If the clock need to be reset, please repeat step b to step d.
NOTE
• The kitchen timer is different from 12-hour system. Kitchen Timer is for
you to count down the cooking time, when the cooking is not doing by
the oven.
• During kitchen timer, any program cannot be set.
NOTE
* The Microwave Power Level could only be set after setting the cooking time.
Please refer to ||MICROWAVE COOK for reference.

•In the process of setting, if the “STOP/CANCEL” button is pressed or
if there is no operation within 1 minute, the oven will go back to the
former setting automatically.
•If “PL0” selected, the oven will work with fan for no power. You can
use this level to remove the odor of the oven.
•During microwave cooking, “POWER” can be pressed to change the
power you need. After pressing “POWER”, the current power flashes
for 3 seconds, you can press number button to change the power.
The oven will work with the selected power for the rest time.
EN-16
INSTRUCTION FOR USE
OPERATION
NOTE
a. Press “TIME COOK” once, the screen will display “00:00”.
b. Press number keys to input the cooking time. (The maximum cooking time is
99 minutes and 99 seconds.)
c. Press “POWER” once, the screen will display “PL10”. The default power is 100%
power. Now you can press number keys to adjust the power level.
d. Press “START/+30SEC.” to start cooking.
Example: To cook the food with 50% microwave power for 15 minutes.
•Press “TIME COOK” once. “00:00” displays.
•Press “1”, “5”, “0”, “0” in order.
• Press “POWER” once, then press “5” to select 50% microwave power.
•Press “START/+30SEC.” to start cooking.
4. MICROWAVE COOK
a. In waiting state, instant cooking at 100% power level can be started by select a
cooking time from 1 to 6 minutes by pressing number pads 1 to 6.
Press “START/+30SEC.” to increase the cooking time. The maximum cooking time
is 99 minutes and 99 seconds.
b. In waiting state, instant cooking at 100% power level with 30 seconds’ cooking
time can be started by pressing “START/+30SEC.”. Each press on the same button
will increase cooking time by 30 seconds. The maximum cooking time is 99
minutes and 99 seconds.
5. EXPRESS COOK
• During microwave cooking and time defrost, time can be added by
pressing “START/+30SEC.” button.
NOTE

OPERATION
EN-17
a. Press “WEIGHT DEFROST”, screen will display “dEF1”.
b. Press numerical buttons to input weight to be defrosted. Input the weight ranged
between 100~2000 g.
c. If the weight input is not within 100~2000, the input will be invalid.
d. Press “START/+30SEC.” to start defrosting and the cooking time remained will be
displayed.
6. WEIGHT DEFROST FUNCTION
a. Press “TIME DEFROST”, screen will display “dEF2”.
b. Press number pads to input defrosting time. The effective time range is 00:01~99:99.
c. The default microwave power is power level 3. If you want to change the power
level, press “POWER” once, and the screen will display “PL 3”, then press the number
pad of the power level you wanted.
d. Press “START/+30SEC.” to start defrosting. The remaining cooking time will be
displayed.
7. TIME DEFROST FUNCTION
• POPCORN
a. Press “POPCORN” repeatedly until the number you wish appears in the display,
“50”, “100” grams will display in order.
For example, press “POPCORN” once, “50”appears.
b. Press “START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes,
buzzer will sound five times and then turn back to waiting state.
c. Important Information About Microwave Popcorn Feature :
• When selecting 100 g of popcorn, it is suggested that you fold down a triangle
on each corner of the bag before cooking. Refer to the picture at right.
• If/When the popcorn bag expands and no longer rotates properly, please press
“STOP/CANCEL“ button once and open the oven door and adjust the bag position
to ensure even cooking.
8. AUTO MENU FUNCTION
popcorn
popcorn

EN-18
OPERATION
INSTRUCTION FOR USE
a. Press “POTATO” repeatedly until the number you wish appears in the display, “1”,
“2”, “3” will display in order.
“1”SET : 1 potato (approximate 230 grams)
“2”SETS: 2 potatoes (approximate 460 grams)
“3”SETS: 3 potatoes (approximate 690 grams)
For example, press “POTATO” once, “1” appears.
• POTATO
b. Press “START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes,
buzzer sounds five times and then turn back to waiting state.
• FROZEN VEGETABLE
a. Press “FROZEN VEGETABLE” repeatedly until the number you wish appears in the
display, “150”, “350”, “500” grams will display in order.
For example, press “FROZEN VEGETABLE” once, “150” appears.
b. Press “START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes,
buzzer sounds five times and then turn back to waiting state.
• BEVERAGE
a. Press “BEVERAGE” repeatedly until the number you wish appears in the display,
“1”, “2”, “3” cup will display in order. One cup is about 120ml. For example, press
“BEVERAGE” once, “1” appears.
b. Press “START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes,
buzzer sounds five times and then turn back to waiting state.
•DINNER PLATE
a. Press “DINNER PLATE” repeatedly until the number you wish appears in the
display. “250”, “350”, “500” grams will display in order.
For example, press “DINNER PLATE” once, “250” appears.
b. Press “START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes,
buzzer sounds five times and then turn back to waiting state.
•PIZZA
a. Press “PIZZA” repeatedly until the number you wish appears in the display, “100”,
“200”, “400” grams will display in order.
For example, press “PIZZA” once, “100” appears.
b. Press “START/+30 SEC.” to cook, buzzer sounds once. When cooking finishes,
buzzer sounds five times and then turn back to waiting state.

EN-19
OPERATION
At most 2 stages can be set for cooking. In multi-stage cooking, if one stage is
defrosting, then defrosting shall be placed at the first stage automatically.
Example: If you want to cook with 80% microwave power for 5 minutes + 60%
microwave power for 10 minutes. The cooking steps are as following:
•Press “TIME COOK” once, then press “5”, “0”, “0” to set the cooking time;
•Press “POWER” once, then press “8” to select 80% microwave power.
•Press “TIME COOK” once, then press “1”, “0”, “0”, “0” to set the cooking time;
•Press “POWER” once, then press “6” to select 60% microwave power.
•Press “START/ +30 SEC.” to start cooking.
9. MULTI-STAGE COOKING
• Auto cooking cannot work in the multi-stage cooking.
NOTE
Lock: In waiting state, press “STOP/CANCEL” for 3 seconds, there will be a long
“beep” denoting the entering into the children-lock state, meanwhile, screen will
display “ “.
Lock quitting: In locked state, press “STOP/CANCEL” for 3 seconds, there will be a
long “beep” denoting that lock is released.
10. LOCK FUNCTION FOR CHILDREN
