Toshiba ER-ND300C User manual

󰿤ThankyouforpurchasingToshibamicrowaveovenwithsuperheatedsteamoven.
󰿤Inordertousetheproductsafely,pleasereadandunderstandalltheinstructionsmanualand
Cookingbook,beforeusingtheunit.
󰿤Afterreading,pleasekeeptheinstructionmanualhandy.
●Pleaseensureyouobtainthewarrantycardforthisproduct.
ForHouseholdAppliances TOSHIBAMICROWAVEOVENWITHSUPERHEATEDSTEAMOVEN
InstructionManual&Cookingbook
Affectionate
checking
Stop
using
the
oven
Powersupply
Powerconsumption
Microwaveoutput
Microwavefrequency
Heaterpoweroutput
Temperatureadjustment
Bodydimension
Cavitydimension
Bodyweight
Timerlimits
AC220V50Hz
Microwave1430W,Heater1420W
900W※1/600W/500W/200Wequivalent/100WequivalentOutputswitching
2450MHz
Convection1390W/Grill1100W/Steam350W
Fermentation(30,35,40,45℃,Steamfermentation(40℃)),100-300℃※2
500(W)x450(D)x388(H)mm
398(W)x330(D)x232(H)mm
Approx.18kg Cavityvolume 30L
Microwave900W:10mins
Steamed/Steammicrowave:30mins
Microwave600W/Microwave500W/Grill30mins
Microwave200W/Microwave100W/Convection/Ferment/Steamferment:90mins
Superheatedsteam:60mins
TOSHIBAMICROWAVEOVENWITHSUPERHEATEDSTEAMOVENInstructionManual&Cookingbook
※1Ratedmicrowaveoutput900Wisashortdurationhighpowerfunction(approximately10minutes)and
ratedcontinuousmicrowaveoutputis600W.Themicrowavepowerautomaticallychangesto600W.
※2Theoperatingtimeat300℃isapproximately5minutes.Evenifyousetthetemperatureabove240℃,
itwillautomaticallyloweredto230℃.Temperatureof250℃canbesetwithsuperheatedsteam.
Temperatureismeasuredatthecenteroftheovenchamberusingathermoelectricthermometerinthe
emptystate.(JISmeasurementmethodisused)Thetemperaturemaynotmatchifthetemperatureis
measuredwiththefoodoraccessoriesplacedinsidetheoven.(Forcooking,considerthetemperature
givenintheseparatecuisinebookletasthestandard.)
●Sincetheactualpowerconsumeddependsonthefrequencyofusage,duration,quantityandthe
surroundingtemperature,monitortheprocesscarefully.
●AnnualpowerconsumptionisthevalueinaccordancewiththeEnergysavinglaws/Specifieddevice
“Microwave”measurementmethods.
●ThecavityvolumeisbasedonJIS(JapanIndustrialStandard)specifications.
Pleasecheckupyourmicrowaveyouareusingforsolong!
●Thepowercordorplugisabnormallyhot.
●Fooddoesnotheatupevenafter
cookingstartsonpressingthekey.
●Ovendoesnotswitchoffautomatically.
●Strangenoiseorsmelloccursduringuse.
●Ovenwallorcoverisdirtyandspark
orsmokeoccurs.
●Otherabnormalitiesorfailureoccurs.
Don'tyouhave
symptoms
likethis?
Topreventdamagedue
tofailure,disconnectthe
powercordfromthe
powersupplyandcontact
yourdealerforrepairor
service.(Donotallow
anyoneotherthana
qualifiedtechnicianto
disassembletheunit.)
4MW5866302
Specification
Model

1
STEP
2
STEP
3
STEP
4
STEP
5
STEP
Squaretray
Gridiron
■ Don'tusesquaretrayand/orgridiron.
Instead,pleaseputthefooddirectlyintheoven
・ iconwillappearonthedisplayscreen
Whenheatingwithmicrowaveoven
Putthefood
insidedirectlywithout
anythingelse!
Theoventurns
onwhenyou
openthedoor
OncestephavebeendoneOncestephavebeendone
〜〜
15
ReadSafetyprecautions（Page2〜8）
＊Includesinstructionsyouhavetofollow.
Earthconnector（Page4）
＊Topreventelectricshockthatmayoccur
duringfailureorshortcircuit.
Open/Closethedoor（Page8）
Insertthepowerplug
Heatemptyoven（Page16）
＊Astheinsideofyourovenwillbecomehot,
pleaseuseitafteritcooleddown.
Warmingup riceandsidedish ････ Pages20〜22 ・ 30
Thawing meatandfish ･･････････ Pages24 ・ 25
Warmingup milk  ･･････････････････ Pages24 ・ 26
Boiling vegetables ･･･････････････ Pages27 ・ 29
Warming friedfoodcrisp ･･･････ Pages27 ・ 30
Warmingup sake ･･････････････････ Pages27 ・ 32
＊Wehavedescribedaselectionofwarm-upswellusedineverydaylife.Forothersand
details,pleaseseethetableofcontentsontherightpage.
Pleasereadpages18〜19,thenstartcooking.
Firstofall,besuretodothefollowingsteps!
Let'sstartcooking!
Movesmallanimalstoanotherroom,andventilate
theroom!
●Pleasemove
animalswhich
aresensitiveto
smokeandsmell
(ex.smallbirds)
toanotherroom,
thenturnonthe
exhaustfanor
openthewindow.
●Especiallyatthebeginning,smokeandsmell
maycomeoutwhenyou'reheatingtheempty
ovenandburningofftheoil.
Openthewindow
Turnontheexhaustfan
Whenheatingwithheater

1
SteamReheat
Moistandhot
Convection
REHEAT
Grill
Steamed
Lowtemperaturesteamed
＊
Quickly
roastingathigh
temperature
Steamingupsoftly
300℃
−10℃
90℃
★Makingfrozenstiffice
creameasiertoeat
★Softeningbutter
Cookingatlowtemperature
around80℃
Onlyonetouchtostart
DesiredTemperature
Adjustable
Steammicrowave
Quicklygivingmoisture
Inaddition
tothat…
※Aspectsofinsideofovenandimagesareforillustrative
purposesonly.
Microwave
Handyandconvenient
Superheatedsteam
Highheating
steamtocutout
extraoil
250℃
++
WhatshouldIdo?
＊ Onlyforautomaticcooking
ofsteamedegghotchpotch
andpudding
SteamSteam
plusplus
SteamSteam
+
plusplus
Max.Max. Max.Max.
Strongheatingpower
fromabovetobrown
thesurfaceoffood
Forthosewhotakecareoftheirbody...Forthosewhotakecareoftheirbody...
Healthycooking
OilOil OilOil
Forfoodslikesteamed
egghotchpotchandpudding
requiringdelicateheatcontrol
Forfoodslikesteamed
egghotchpotchandpudding
requiringdelicateheatcontrol
REHEAT
START
Herearetheimagesandtheirmeaningsinthisbook.
Tableofcontents
＊Recipecollectionsareatpages60〜151
Menutouse
steam
Display
Lighting Flashing
Steam
MicrowaveMicrowave
Warmingup
Roasting Steaming
Safetyprecautions 2
〜
8
PartsnameandFunctions 8
〜
11
Heatingmechanism 12,13
Vesselsyoucanuse/Vesselsyoucan'tuse
14,15
Heatingemptyoven/Deodorizing 16
REHEATrecommendations 17
Whenheatingwithmicrowave
18,19
Warmingupriceandsidedish
20
TipstousewellREHEAT
21,22
NON-FRIED/HYBRIDcooking
23
Thawingmeatandfish,warmingupmilk
24
Tipstousewell3TYPESDEFROSTMILK
25
,
26
Cookingwiththedialmenu
27
,
28
Tipstousewellthedialmenu
29
〜
33
Heating/Stewingwithmicrowave
34,35
Warmingupatthedesired
temperature
36,37
CookingwithCONVECTION
38,39
Fermenting
40
CookingwithGRILL
41
Cookingwithsteam(STEAMED/
STEAMMICROWAVE)
42,43
CookingwithSUPERHEATEDSTEAM
44,45
Referenceformanualheating'ssettingtime
46
Aboutnotificationsound
Aboutnotificationsignal/operationguide
47
Howtodomaintenance
48
〜
51
Commoninquiry
52
Incaseyoucan'tcookwell
53
〜
56
Meaningofindicatorsandwhattodo
57
Beforeaskingforrepairs
58,59
Specification Backcover
Howtocook
Inthefollowing
situations
Preparationand
confirmation
Let'scook!
Automaticcooking
Manualcooking

2
Safetyprecautions
Pleasemakesuretofollowtheseinstructionsforyoursafety
DANGER
WARNING
Donotusetheproductin
casethepowercableand/or
powerplugisdamaged,orthe
electricaloutletisloose.
Ifthesupplycordisdamaged,itmust
bereplacedbythemanufacturer,
itsserviceagentorsimilarlyqualified
personsinordertoavoidahazard.
Itmaycausefire/electricshock.
Donotdismantle/repair/
modifytheproductyourself
Itmaycausefire/electricshock/injury.
Foranyrepairs,pleasecontactthe
shopwhereyoupurchasedtheproduct
orToshiba'ssupportcenterforhome
electricappliances.
Dismantling
isforbidden
Forbidden
Makesureforconnectthe
microwaveoventoanexclusive
powersupplyoftherelated
voltage.
Sharingpowersupplywithother
applianceoruseofextensionpower
cord,maycausefireandelectricshock.
Exclusive
power
supply
Forbidden
●
Importantcontentsarementionedtoavoidinjurytoanypersonordamagetoanyproperty,andtousetheproductcorrectlyandsafely.
Donotinsertfingers,aforeignbody,
orametalobjectlikeapinora
wireinsidetheproduct'sinletport,
exhaustport,watersupplycassette's
deliveryport,orotherholes.
Itmaycauseelectricshock/injury.
Incaseofanyforeignbodycomesinto
theproduct,pleasepulloutthepower
plugandcontacttheshop
whereyoupurchased
theproductor
Toshiba'ssupport
centerforhome
electricappliances.
Manipulationofpowerplug/powercable/electricaloutlet
Pleasemakesureyoufullyplugged
thepowerplugintotheoutlet.
It may cause electric shock and/or fire
duetoheatdeveloped.
■Mentionedthesectioneddegreesofinjuriesand
damageswhichcanoccurincaseyou'reusingthe
productwithoutrespectingthesafetyprecautions.
DANGE
R
Matterswhichhavegreat
riskofcausingserious
injuriesordeath.
WARNING
Matterswhichcancause
slightinjuriesordamages
toyourhouse/property.
CAUTION
Matterswhichhavepossible
riskofcausingserious
injuriesordeath.
■Mentionedtheinstructionsyou
shouldfollow,classifiedbysymbols.
Forbiddenmattersyou
shouldneverdo
Mattersyou should follow
theinstructionsof
Mattersyoushouldpay
attentionto
Theovencontainshighvoltageparts
IMPORTANTSAFETYINSTRUCTIONS
READCAREFULLYANDKEEPFORFUTUREREFERENCE

3
Preparationand
confirmation
Safetyprecautions
Forbidden
Donotforcedlybend,pull,
twist,tietogether,putundera
heavyobject,tuck,orprocess
thepowercableorpowerplug
Thepowercablemaybedamagedand
causefire/electricshock.
Forbidden
Donotapproachpowercable
orpowerplugtoexhaust
portorotherplaceswithhigh
temperature.
Itmaycausefire/electricshock.
Forbidden
Donotoperateifthedoorare
damaged.
Ifthedoorordoorsealsaredamaged,
theovenmustnotbeoperateduntil
ithasbeenrepairedbyacompetent
person.
Cleanupregularlytheduston
thepowerplug
Ifdustcollectsonpowerplug,itmay
sufferinsulation
failuredueto
dampness,andit
maycausefire.
Pleasewipeitup
withadrytowel.
Cleanup
thedust
MICROWAVE
ENERGY
Manipulationofpowerplug/powercable/electricaloutlet(Continued)
Ifyou'llnotusetheproductfora
longperiodoftime,pulloutthe
powerplugfromelectricaloutlet
Orelse,itmaycauseelectricleakage
fireduetoinsulationdeterioration.
Pulloutfrom
electrical
outlet
Keeppackagingplasticbagout
ofyoungchildren'sreachor
disposeofthem
Ifyoungchildrenwearapackaging
bagontheirhead,itmayobstruct
theirmouthandnoseandcause
asphyxiation.
Wheninstallationtheproduct
Removeallpackagingmaterial
beforeusingtheproduct
Ifyoudon'tremovethem,theymay
igniteduringoperationandcausefire/
burn.
Remove
the
packaging
material
Donotmoveflammableorheat-sensitivesubstancesclosertothe
machinebody
Donotmovespraycanclosertoit
Itmaycauseburntdeposit/fire.
Spraymayigniteandexplode.
Donotputitontatamimat,carpet,ortablecloth,anddonotmovecurtainsclosertoit.
Ifyouputtheproduct'sexhaustslotclosetoheat-sensitivefurniture,wallswithanelectrical
outlet,orheat-sensitivewalls,theymaysufferthermaldeformation.Sopleasekeepthem
awaytheproduct.
Forbidden
Whenyou'repullingthepower
plugoutfromanelectrical
outlet,holdthepowerplug
whilepullingitout
Ifyouholdthe
powercablewhile
pullingthepower
plugout,itmay
damagethepower
cableandcause
fire/electricshock.
Pullout
holding
theplug
Hazardouswhencarryoutany
service.
Itishazardousforanyoneotherthan
acompetentpersontocarryout
anyserviceorrepairoperationthat
involvestheremovalofacoverwhich
givesprotectionagainstexposureto
microwaveenergy.
WARNING
WARNING

4
Safetyprecautions
Alwaysusethepoweroutletwithearthsocket.
Forsafety,connectthepowerplugtopoweroutletwithearthsocketonly.
Otherwise,itmaycauseelectricshock.
ALWAYS
CONNECTED
EARTH
Wheninstallingtheproduct(Continued)
・Inspectthemicrowaveregularly.Ifdoorleakageprotectorisbroken,donotoperatethe
microwaveuntilaproperrepairbyprofessional.
・Donotperformrepairthatneedtouncoverleakageprotectorwithoutprofessional.Otherwise,it
maycauseasevereinjuries.
・Observethemicrowavewhenoperatingwithplasticorpapercontainers.Itmaycausefire.
Uppersurface30cm
(ConformitytofireprotectionlawstandardsBuilt-intype)
2cm
ormore
0cmormore
fromthe
backsalie
2cm
ormore
Separation
(cm)
Place
Upperside 30
2
2
Open
0
0
Leftside
Rightside
Frontward
Backward
Downward
※Open2cmonbothsidesorleave4cmonthe
rightsideifyouleave0cmontheleftside.
30
0
4
Open
0
0
Donotuseinenvironmentclosetowaterdrops,steamemitting
machinesandfire.
Itmaycausefire/electricshock/electricleakage.
Forbidden
WARNING
CAUTION
Placingtheproductwithaspace
betweenitandthewall
Itmaycausefireduetooverheat.
Thereisanexhaustportfromtheinsideofthe
ovenattherearupperpartoftheproduct.
Leavespace
between
theproduct
andthewall
・ Whenthereisawallwhichisweakto
heat,consumerelectronics,furniture,
electricoutlet,pleaseleaveaspaceequal
orsuperiortothedimensionsonthe
right.Dependingonthewall'smaterial,
themachinebodymaycreatecontact
tracesonthewall.
Also,ifthereisanelectricoutletclose
totheexhaustport,orwhenyouare
worriedaboutdirt,pleaseleaveaspace
equalorsuperiortothedimensionson
therightinordertoavoiddirectcontact
withtheexhaustair.
・ Whenthereisaglassmaterialbackward,
asitmaycauseriskofcrackingdueto
thedifferenceoftemperatures,please
leaveaspaceequalorsuperiorto20cm.
(Glassmaycrackduetothedifferenceof
temperaturesevenwiththespace)
Putonaflatplacewhichisstrongenough
Ifyouputtheproductonatablewithoutenoughstrength,itmayfallorcollapseandcause
injuries.Also,dewcondensationwatermayslopoverthefloor.
Incaseittoppleddown/fellduetoearthquakeorother,pleaseleavetheproductwithout
usingitandasktheshopwhereyoupurchasedtheproductacheck.
Overturningpreventionmetalfixturetoavoidthemachinebody'sfall/topple.
Putona
flatplace
・ Ifyou'reworriedbythedirtonwallsdueto
exhaustairorbytheimpactofsteam,you
canreducethedirtonwallsandtheimpact
ofsteambyincreasingthedistancewiththe
wallorputaluminumfoilonthesurfaceof
thewall.

5
Preparationand
confirmation
Safetyprecautions
Whileusing
Iffoodburnsintheoven,donot
openthedoor
Byopeningthedoor,thefiregetsbiggerand
cancausemoredamage.
・ Pleasehandleiffoodburns:
① PressCancelkeywithdoorshutandstop
theoperation.
② Pulloutthepowerplug.
③ Keepburnableitemsawayand
waituntilthefiregetsputout.
④ Ifthefiredoesnʼtgetput
outbyitself,usewateror
fireextinguisher.
・ Donottrytouseagain.
Calltheresellerforcheckup.
Donotpulloutandputbackthe
powerplugwhilecooking
Itcausessparksandcouldleadfireand
electricshock.
Forbidden
Donotleaveachildandthosewho
donotknowhowtousetousethe
ovenbythemselves.Anddontuse
itwithininfantsreach.
Theapplianceisnottobeusedbypersons
(includingchildren)withreducedphysical,
sensoryormentalcapabilities,orlackof
experienceandknowledge,unlesstheyhave
beengivensupervisionorinstruction.
Childrenbeingsupervisednottoplaywiththe
appliance.
Especially,whileheatingtheovenorjust
afterheating,nevertakeyoureyesofffrom
yourchildren.Theymightgetelectricshock,
injured,orburnt.
Whentheapplianceisoperatedinthe
combinationmode,childrenshouldonlyuse
theovenunderadultsupervisionduetothe
temperaturesgenerated.
Forbidden
Donotjamobjectsinthedoor
whileusing
Theleakedelectronicwavemightcause
damagestohumanbodiesorstartfire.
Forbidden
Donotputanobjectontopofthe
ovenorcoverwithcloth.
Theobjectontheovengetshotandmight
causedeformation,burnt,orfire.Donot
putovensaccessoriessuchasthesquare
plate,either.
Duringusetheappliancesbecomeshot.Care
shouldbetakentoavoidtouchingheating
elementsinsidetheoven,forcookingranges
andovensAccessiblepartsmaybecomehot
duringuse.Youngchildrenshouldbekept
away.
Forbidden
Forbidden
Donothitorapplyimpactstothe
squareplate,thebottomofthe
oven,ortheglasspartofthedoor
withotherobjects
Thebrokenpiecescancauseinjuries.
Wheninsertingcontainersandbowls,please
becarefulnottohitthebottomoftheoven
ortheglasspartofthedoor.
Whenthereisascratchontheglass,itcould
breakwhileusing.
Forbidden
Stirredandtemptraturechecked
Thecontentsoffeedingbottlesandbabyfoodjars
shallbestirredorshakenandthetemperature
checkedbeforeconsumption,inordertoavoidburns.
BABYFOOD
Whenyouseesomethingunusualor
broken,stopusingimmediately
Theovenmightstartfire,smokeortheuser
mightgetelectricshock.
<Exampleofabnormality,broken>
・Thepowercordorthepluggetsveryhot.
・
Strangesoundorsmellcomesoutwhileusing.
・ Thepowersometimesdoesnotgooffautomatically.
・ Yousometimesseesparksorsmokescomingout.
・ Thedoordoesnotshuttightorisdeformed.
・  Youfeelelectricitywhentouchingtheoven.
■ Pleaseunplugandasktheresellerfor
checkupandrepair.
Ifsmokeisobserved,switchofforunplugthe
applianceandkeepthedoorclosedinorderto
stifleanyflames.
When
thereis
something
wrong,
stopusing
Donotputtoomuchpressuretothe
doororinsideoftheoven
Donothangtothedoororrideon
thedoor
Itwillcausedeformationofthedoorand
mightcausedamagestohumanbodiesby
theleakedelectricwaves.
Also,byhangingtothe
doororridingonthe
door,theovenmight
tipoverorfall,which
mightcauseinjuries.
Forbidden
Donotblocktheintakeportand
exhaustport.
Itcausesthefire.
Forbidden Donotuseforotherpurposethancooking
Byoverheatingorabnormaloperation,it
mightcauseburns,injuries,breakages,
orfire.Donotheatobjectslikeclothes,
towels,hot-waterbottlessoldforheating
inmicrowaves,feedingbottles(disinfection
bag),heatingpads,orwarmerforthebath
tab.
Forbidden
Becarefulnottojamyourfingers
whenopeningandclosingthedoor
Youmightgetburntorinjured.
Caution
WARNING
CAUTION

6
Safetyprecautions
Whilemicrowaveheating
Emptyfoodsincan,jar,orbag,retortfood,
andvacuum-packedfoodinotherdish
Removefreshness-keepingagent
(oxygenabsorber)
They may cause fire, explosion, damage
totheoven,injury,andburn.
Donotcookraweggs,boiledeggs
(withorwithoutshells),sunnysideup
Ifeggsarecookedintheoven,theyexplodeand
damagetheoven,causeinjuryandburns.They
mayexplodeaftertakingthemoutfromtheoven.
Eggsinthershellandwholehard-boiledeggs
shouldnotbeheatedinmicrowaveovens
sincetheymayexplode,evenafter
microwaveheatinghasended.
・ Scrambleeggsverywell
beforeheating.
・ Donotwarmupboiledeggs
(withindisheslikeOden,chopsuey).
Forbidden
Becarefulwhentakingoutdishes
orfoodsandwhenremoving
plasticwraps
Whenitshot,steammay
comeoutimmediately,
whichmaycauseburns.
Forbidden
Donotoverheatdrinks,oilyfoods,etc.
Itmayboilsuddenlywhenorjustafter
takingitoutandmaycauseburns.Also,
byputtingpowderlikeinstantcoffeemay
maketheliquidboilsuddenly.
Microwaveheatingofbeveragescanresult
indelayederuptiveboiling,thereforecare
mustbetakenwhenhandlingthecontainer.
● Drinks:liquidslikecoffee,milk,soymilk,
water,yogurt,soupslikemisosoup
● Oilyfoods:freshcream,butter,etc.
● Thickfoods:curry,stew,etc.
・ DonotheatdrinkswithREHEATkey.For
milk,useMilkkey.Use20Sakemenufor
Sake.Forotherliquidslikecoffeeandwater,
followtheinstructionsonpage46andset
moderatedurationandheatupmanually.
・ Ifoverheated,leavethefoodinsidethe
ovenformorethan2minutesandtakeit
outaftercooleddown.
・ Useshorter,widermouthcontainer.
・ Followthecontentsin
operationmanualwithregard
totheportion,container,
placement,etc.
・ Mixdrinkswithspoonorother
toolswellbeforeandafter
heating.
Donotheatfoodlessthan100g
automatically
Sincethefoodtemperatureisnotproperlydetected,
foodgetsoverheatedandmightcausefire.
・ Pleaseheat manually whilecheckingthefood
insidecarefully.
Forbidden
Removelidsfromhighsealingcontainers,
cutorcrackfoodswithskin,shell,orfilm
(squid,chestnuts,ginkgo,etc.)
Theymaybreakanddamage
theoven,causeinjuryorburns.
Removelid
Cutshell
Donotheatwithoutanythingintheoven
Itmaycausesparks,orthebodyorinsideof
theovengetsheatedabnormallyandleads
hightemperature,whichmaycauseburns.
Also,heatinglongdurationorsmallportionmakes
insideoftheovenhotandmaycauseburns.Please
donottouchinsideofovenrightafterheating.
Forbidden
Donotoverheatfoods
Longercookingtimeforthefoodportion,it
willcausesmokeandfire.
・Formanualheating,setmoderateduration
byreferringthesettingtimeonpage46
whilecheckingthefoodinsidecarefully.
・Especially,pleasebecarefulwithfollowing
foods:smallportion,foodwithoils(bread
withbutter,friedfoods,etc.),foodwith
lesswater(popcorn,etc.),rootvegetables
(sweetpotatoes,carrots,etc.),foodstend
togethot(redbeanbuns,etc.).
・Forautomaticcooking,pleasefollowthe
contentsintheinstructionmanualinregard
toportion,container,plasticwraps,etc.
Forbidden
Explosiveboil
Donotuseheatingcookwithinfrared
sensorforcontainerswithlids
Withlid,thefoodtemperaturecannotbe
properlydetected,foodgetsoverheatedand
mightcausefireorthecontainermightbreak.
・Pleaseremovethelidbeforeheating.
Forbidden
Whenheatingbabyfoodsand
nurseryfoods,mixwellandcheck
thetemperatureafterheating
Thefoodmaycauseburns.
WARNING
CAUTION
Remove
PACKAGING
Liquidsandotherfoodsmustnotbe
heatedinsealedcontainerssince
theyareliabletoexplode
Whenheatingfoodinplasticorpaper
containers,keepaneyeontheoven
duetothepossibilityofignition.
Onlyuseutensilsthataresuitableforuseinmicrowaveovens

7
Preparationand
confirmation
Safetyprecautions
Whileheatingheater,move
smallanimals,suchassmall
birds,thataresensitiveto
smokeorsmelltoanotherroom.
Turntheextractorfanoropen
thewindowforventilation
Especiallywhenbakingforthefirsttime
todeodorizeandburnoilintheoven,
smokeandsmelltendtohappen.
Donottouchhotparts(insidethe
oven,door,body,exhaustport,water
supplycassette)andtakenoutsquare
plateduringandaftercooking.
Duetothehightemperature,itmay
causeburns.
・
Pleasediscardwaterinwaterreceiving
partafteritgetscooleddown.
・Donotplacesquareplateonplaces
notresistanttoheataftercooking.
Itmaycausedeformationand
discoloring.
Donot
touch
Donotputwatertothedoor,inside
oftheoven,squareplateorcool
themdownsuddenlyduringand
aftercooking
Itmaycausecrackandyoumaygetinjured
oritmaydeform.
Also,generatedsteamorhotspraymay
causeburns.
Prohibit
onwater
Donotusethewatersupply
cassetteifitisbroken
Itmaycauseinjury.
Ifthereiscrackorchip,donotusethe
ovenandconsultthereseller.
Forbidden
Becarefulwiththeremaining
steamtobegeneratedwhileor
aftersteamcooking
Openingandputtinghandsintotheoven
rightawaycancauseburnsandinjuries.
Pleasebecarefulifyouhaveopenedthe
ovenwhilecookingassteammaykeep
comingoutforawhile.
Becareful
withsteam
Move
small
animals
Donotusetornorwetmittens
Itmaycauseburnsandinjuries.
Forbidden
Donotputyourhandsclosetothe
leftsideoftheinsideofovenand
steamoutlet
Itmaycauseburns.
Forbidden
Changewaterinwatersupply
cassetteforeveryuse
Discardwaterinwaterreceiving
partaftereveryuse
Itmaycausemoldandbacteriatogrow.
・Pleasealwaysusefreshwaterwhen
cooking.Pleasediscardwaterinwater
receivingpartaftercooking.
・Sinceitmaybehot,pleasewaitand
discardwaterinwaterreceivingpart
andrinseit.
Whileheatingheaterandsteamheating
Openthewindow
Turnontheexhaustfan
Thispart
getshottoo
Donotputyourfaceorother
bodypartsclosetothedoor
duringoraftercooking
Itmaycauseburns.
Duringandaftersteamheating,please
becarefulwithheatandsteam.Please
beextracarefulwhenopeningthedoor
ashotsteammay
comeout.
Forbidden
CAUTION
Usethickcommerciallyavailable
mittenswhenputtingandtaking
outfoodsandaccessories
Ifyoutouchthemdirectly,itmaycause
burnsandinjuries.
Donotusecontainersandbagsthathasbeenfinishedwithmetalssuchas
thesquareplate,wirenet,aluminumfoil,metalcontainer,metalskewer,
metalrope,aluminumtape,aluminum
Itmaycausesparksandthebottomoftheovenordoorglassbreaksandmayleadinjuries.
Forbidden

Showsinformationlikeautomaticmode,
temperaturetime.
Displaypart
Thisisshownwhenselecting
microwavecooking(includes
cookingwithmicrowaveheating
asapartofcooking)andflashes
duringcooking.
Operationparts
Justselectamenu.Automaticmenus
don,trequiresettingoftemperature
andduration.
Automaticmenu＊
8
・Placingtheoventosomewherethebodytopcan
beleftopenifyoucookfishorotherfoodthat
causeoilsmokeeasilybyheaterheatingcooking.
Keepatleast4mawayfromdevicessuch
asTV,radio,wirelessunit(wirelessLAN),
wireantenna.
Attheplaceswithlowerreceptionlevel,extendthe
distanceuntilyoudonothearthenoisetoprevent
noiseordisorderedvideoimage.
Keepawayfromheatandsteam
Pleasemakesurethesteamsfromdevicessuchas
ricecookerandelectrickettlewillnotbesprayedon
theoven.Itmaycausedamage.
Becarefulwhenmovingthemachinebody
Pleaseholdthebottomofleftandrightsideofthe
productandmove.
Notes
Safetyprecautions Partsname
andFunctions
Unplugthepowerplugduring
maintenance
Orelse,itmaycauseelectricshock,
injuryorburns.
Unplug
Maintenance
Donotunplugthepowerplug
withwethand
Itmaycauseelectricshock.
Nowet
hand
Unplugand
cooldown
Unplugthepowerplugand
letthemachinebodycooldown
beforecleaningthebody.
Orelse,itmaycauseelectricshockorburns.
-Donotuseharshabrasivecleanersor
sharpmetalscraperstocleantheoven
doorglasssincetheycanscratchthe
surface,whichmayresultinshattering
oftheglass.
-Shallstateasteamcleanerisnotbeused.
-Theapplianceshallnotbecleanedwith
asteamcleaner
Donotheatwhileoil,foodparticles
orwaterexistsinsideofoven
Theelectricwavefocusesonthedirtypart
andmaycausesparkle,smoke,andfire.
・ Ifsomethingsticks,pleasewipeitoff
afterthemachinebodyiscooleddown.
・Theovenshouldbecleanedregularly
andanyfooddepositsremoved.
・Failuretomaintaintheoveninaclean
conditioncouldleadtodeterioration
ofthesurfacethatcouldadversely
affectthelifeoftheapplianceand
possiblyresultinahazardoussituation.
Forbidden
Closethedoorwhiledraining
thewater
Steamisgeneratedwhiledrainingthewater.
Pleaseclosethedoortopreventburns.
Automaticpoweroff
Thepowerautomaticallyshutsoffiftheovenisnotused.
■Ifthedoorleftshut/closedformorethan5minutes
whilethedisplaypartshows0,thepower
automaticallyshutsoff.

WhileHightemperatureisshown,thepowerwill
notbeshutoffautomatically.
Energysavingfunction
CAUTION
WARNING
Thepowerturnedonwhenthe
doorisopened
Thedisplaypartshows0
(Pluggingthepowerplugonlydoesnotturnonthepower)

1COOKED RICE 2 DISH 3 2 DISHES
DECISIONSETTING
ONE TOUCH
MICROWAVE CONVECTION
FERMENT
GRILL
MILK
3 TYPES
DEFROST
CANCEL
●Dialmenu:Turnandselectmenu(14-43).
●Duration:
Turnrightforlonger,turnleftforshorterduration.
Thiscanbeadjustedwhilecooking.
●Temperature: Turnrighttoincrease10℃,turnleftto
decrease10℃.
Thiscanbeadjustedwhilecooking.
Desiredtemperaturecanbeincreasedor
decreasedwhilesetting.Turningtotheright
increases5℃andturningtotheleft
decreases5℃.
・Pressthekeytoimmediatelystartheating.
・The“reheat”keywillnotworkoncemore
than1minhaspassedafteropening/closing
thedoor.(“Door”willbedisplayed)
Setthedurationandtemperatureaccordingtocooking.
(Page34-35)
CancelKey
Usethiskeytocancelanyoperationor
setting,ortostopanongoingcooking.
※ Toconfirminthemiddleofacooking,
openthedoorwithoutpressingthekey.
(Thecookingwillresumeifyouclose
thedoorandpressStart)
Increase
Decrease
321 123
Dial
Standard
●Finishadjustment:Thisisusedforautomaticmenu.
TurningtotherightmakesitIncrease
andturningtotheleftmakesitDecrease
Forreheat(rice,dish),Sake,Boiledvegetable
(rootvegetable),andSteamreheat,turningto
therightsetstoFinishlevel4.
※Usethisoptionforbiggerportions
(for3〜4people).
Followthedialmenuʼssettings,duration,temperature,etc.
・Turn:Setduration,temperature,finishadjustment,etc.
・Press:Enter
Manualcookingkey
Automaticmenusthatdonotrequiredurationor
temperatureset.(Page23-26)
・Menuwillswitcheverytimeyoupress.
Non-fried/Hybrid:
Chickenkaraage → Fried → Tempura → Teriyakichicken
HamburgSteak
→ Beefstuffedpepper
3typesofdefrost: Steamdefrost → Rapiddefrost
Sashimi(Semi-defrost)
Milk: 1cup→2cups→3cups→4cups
Touchmenukey
Reheat/StartDoubleusageKey
Usethiskeytoreheatriceandsidedish
(Pages20-22)and,startcooking.
Nextoperationwillbenotifiedwithflash.
・：Selectorsetbyturningthedial.
・：Presstoconfirm.
・：PressWarmup/start.
Notificationforeachusagewillbeshownwithflashes.
・
Noplasticwrap: Whenplasticwrapisnotrequiredforcooking,itflashes.
Pleasestilluseplasticwrapforwarmingupfrozenfood
orthickfood.
・ Addwater Duringcookingthatusesteams,itflasheswhenno
morewaterisleft.
・ Nometal : Duringmicrowaveheating,thiswarnsnottouseitems
withmetal.
・ ManualmicrowaveheatingOK:Itflasheswhenmanualmicrowave
heating(600W,500W,200W,100W,900W,stew)
canbedoneeventheoveniscoolingdownaftercooking.
Notificationsignal Operationguide
9
＊ AutomaticmenuincludesTouchmenu(4-13)andDialmenu(14-43).
Menunumberwillbeshowninthedisplaypart.Pleaseselectthedesiredmenunumberandusetheoven.
Preparationand
confirmation
Safetyprecautions/PartsnameandFunctions

10
PartsnameandFunctions(continued)
Body
［Front］
Insideofoven
Adaptedheatresistant
deodorantcoating
Hotblastheater
Cabinet
Safetylabel
Ratingplate
Door
Rackholders(Upperrack,
middlerack,bottomrack)
Forputtingracks
Exhaustport
Steamheater
Steamoutlet
※Upperheater,Hotblastheater”and“Steamheater”
areoutsideofinsideofovensotheyareinvisible.
Watersupplycassettex1
Drainreceptaclex1
Containertoputwaterforsupplyingwatertothesteam.
Setthistothebodyevennotinuse.
Containertoreceivefooddirt,waterdroplet,
steamwaterandother.
Setthistothebodyevenwhenyou'renotusingsteam.
Airintake
port(bottom)
・Usedforoven,grillcooking,fermentation,etc.
※Formicrowavecookingthatshowsinthe
displaypart,thiscannotbeusedasitcauses
sparks.(ForEasybakingʼsfermentation,etc.)
※Pleasedonottocooldownimmediatelyafter
using.Itmaycausedamageordeformation.
Pleaserefertopage11forhowtosettothebody
orfordetailsabouthowtouse,anduseproperly.
・Usedforoven,grillcooking,crispwarmingup,etc.
※Formicrowavecookingthatshowsinthe
displaypart,thiscannotbeusedasitcauses
sparks.
2xSquareTray(metal)
1xGridiron
Airintakeport
(side)
Safetyswitchdetector
Pleasedonothitwithitems.
Ifthisisdamaged,theproductmaynotworkproperly.
Upperheater
Insidelamp
Turnsonwhile
cookingor
preheating.
Doorpacking
Thiscannotberemoved.
Pleasedonotpressorpullhard.
Accessories Pleaseuseaccessoriesproperly
Watersupplycassetteandwaterreceiver
Pleasewipeoffthedirtypartimmediately.
・Donotuseaccessoriesinotherdevicesorforother
purposesotherthanforthismicrowaveoven.
Powerplug
Powercord

11
Whenusingsteammodesteam,refertopage51foraboutcleaning.
［Front］
Handle
Frontpanel
Controlpanel／
Display
・Checkifthesettingiscorrectbeforecooking
・Removethewatereachtime,afterthesteam
hasbeenused.
・Asitholdswateraccumulatedduringsteam
cooking,careshouldbetakenwhenpullingout
thetray.
・Takecaresothatyourfingersdonotget
caughtwhilefixing
Acontainertostoreswaterrequiredforsteam
cooking.
Keepsettingonthemainbodyevenifsteam
cookingisnotused.
■Insertingandremoving
Whencookingusingsteam,thecapisopenedand
setbyfillingtapwateruptothelineoffulllevel.
・ Ensurethatthecapandtankcoverisclosed
properly.
・ Alwayskeepflatwhileinusebecausetilting
causeswaterspills.
・ Removethewatereachtime,afterthesteam
hasbeenused.
・ Takecaresothatyourfingersdonotget
caughtwhilefixing
■Insertingandremoving
■Howtoaddwater
Containertoputwatertosupplytosteam.
Setontheconsoleevenwhennotinuse.
Atacapacityofapprox.200cc,approx.30mins
ofsteamcookingandapprox.60minsof
superheatedsteamcookingispossible.
Waterwillbe
collectedinthis
portion
Cap
tankcover
［Filledwithwater］
※Lidisalsoremoved
Tillhere
Pushthewater
tankinsidetill
itlatches
perfect
DraintrayWatertank
Notice
・Whenusingthesteammenuforthefirsttimeorwhendirtaccumulatesduetoprolongednon~usage,
refertopage50forHowtocleanwithsteamsystem.
・Ensurethatthewatertankanddraintrayisalwaysclean.
・Fillthewatersupplycassettewithnewwaterforeachusage.
・Usetapwaterforsteammenu.Donotusemineralwater,wellwateroralkalineionizedwater.The
steamoutletmayclogafterprolonguse.
・
Beforecooking,ensurethatwatertankisfilledwithsufficientwaterandboththetankandtrayare
fittedproperly.Ifthewateristoolittleorifthetankisinsertedhalfway,anerrormessageisdisplayed
andthefoodwillnotbecookedproperly.
・Donotfillthewatertankwithliquidotherthanwaterasitmaycausedamage.
・Careshouldbetakentoensurethatthewaterisnotatatemperaturelowerthan5℃ .Waterwill
freezeandsteamwillnotcomeout.
Preparationand
confirmation
PartsnameandFunctions

・Watermoleculesof
foodisledfriction
whenmicrowaveshit,
andgenerateheats.
Thus,thefoodgets
heateduniformly
insideandoutside.
●
Thetimeshouldbebalancedwith
thequantityoffood.Ifthe
quantityoffoodisdoubled,
thecookingtimeshouldbe
almostdoubledaswell.
● Thetimetakenislowasthe
moistureisabsorbedandthe
foodbecomesdry.Presetthe
timetoashorterdurationand
observethefoodwhengetting
cooked.
● Placethefooddirectlyinthe
oven.
Heatingmode Heatingmechanism Heatingpoint
Microwaveheating Steamheating
Heatswithelectricwaves
■Natureofradiowave
●
Heatingatadesiredfinal
temperaturethatrange-10to
90℃.
Babyfoodiscookedaccordingto
desiredconsistencyofcream.
● Refertopage37topresetthe
oventodesiredfinaltemperature.
● Timingisnotsetinordertoheat
tillthefinishingtemperature.
Heatsaccordingto
thefinalpreset
temperature.
Absorbedby
foodand
moisturecontent
Itpenetrates
potteriesor
porcelains
Metalcontainers,
aluminumretort
packswillreflect
andcannotbe
usedforheating
Accessories
cannotbe
useddue
tospark
andfire.
Squaretray
Gridiron
Squaretray
Gridiron
Microwave
Desired
Temperature
● Thefinaltemperature
ofthefoodisdetected
bytheInfraredsensors.
Usableaccessories
Unusableaccessories
● Usedforsteamingdishessuch
asChawanmushi.
Microwave
steam
Usemicrowaveandsteamforcooking.
Steamed
Heatwithsteam,
ovenandmicrowaves.
12
Heatingmechanism

Heaterheating
Followthedish
collectionand
combine.
Thecombinationof
superheatedsteam
andheaterandfanhelp
tocookfoodevenly.
●Somefoodincreaseinsizeafter
cooking.Placefooditems
properly.
●Observetheconditionoffood
andadjusttimeaswell.Ifthe
chamberstillhot,maybe
repeatedheating,setashorter
timeandobservethecondition
offood.
●Donotopenandclosethedoor
frequently.Thetemperature
insidewilldecrease.
●Duringheating,rotatefoodor
wrapthecookedpartwith
aluminumfoil.
●Takeoutthefoodimmediately
aftercookingtoprevent
overcooking.
●Tomarkburnevenly,flipthe
foodinthemiddleofheating.
●Afterheating,takethefoodout
immediatelytoavoidoverburns.
Grill
Superheated
steam
CONVECTION
Fermentation
Superheatedsteam…
● Steamisheatedat
hightemperature
greaterthan100℃
toproducegas.
Foodgetscooked
quickly.
● Itisaneffectiveway
tocookhealthycook
asitremoveexcess
oilfromfood.
CONVECTION…
● Duetothefunctions
ofheatersandfans,
itmakesheatedsteam
orheatwavepervasive,
andheatasifwrapping
food.
Withthestrongheatfrom
theupperheater,mark
burnonthesurfaceoffood.
Heatwithheatersand
fansascontrollingthe
temperatures.
●Usedforfermentationofbread
dough.
●Therearealso
fermentationusing
steam.
Duetothetemperaturein
cooker,steammaynotbe
visible.
Especially,overheatedsteam
isinvisible.
PleasereadCautionsforsafety“Whenheatingwithmicrowave”,“Whenheatingwithheater/steam”onpage6-7.
Heatingmode Heatingmechanism Heatingpoint
Usableaccessories
Unusableaccessories
Squaretray
Gridiron
Squaretray
Gridiron
Squaretray
Gridiron
13
Preparationand
confirmation
Heatingmechanism

14
Vesselsyoucanuse/Vesselsyoucan'tuse
Typesofheating Containersthatcanbeused
MICROWAVE
STEAMMICROWAVE
Defrost
CONVECTION
Noticesignwillbe
displayed
Superheatedsteam
Grill
Fermentation
Steamfermentation
STEAMED
●
However,thefollowingcontainerscannotbeused.
• Containerswithgoldandsilver(Sparking)
• Containerswithpainting(paintingwillpeeloff)
● Therearesomecontainersthatgetheatedwith
theradiowaves.Takecareandavoidburns.
Pottery・Porcelain
●Ifthecontaineriscooledimmediatelyafter
beingheated,itmaybreak.
●Removethelidforautocookingmenu
function.
Heatresistant
glass
●However,ifthecontaineriscooled
immediatelyafterbeingheated,
itmaybreak.
Heat
resistant
glass
●However,containerswithplastic
handlesarenottobeusedassuch
handleswillmelt.
●Cannotbeusedforapartofthemenu.
Metalcontainers,wire
meshandskewers
ofaluminum
andenamel
etc.
●Itmaybeusedforcoversquaretray
orunderthefoodburningorwhen
grilling.
●Cannotbeusedforapartofthemenu.
Aluminum
Foil
Siliconcontainer
●However,itisunusableforveryfatty
food,becausesuchfoodreachahigh
temperature.
●Polyethyleneplasticwrapisunusable,
becauseitwillmeltandmaycatchfire.
Wrappingwithminimum
resistance
temperature
of140℃.
・Thetemperatureoftheovenissettoresistancetemperatureofthe
container-30℃,donotplacesiliconcontainersattherearendof
theovenchamber.
(Exampleofpresettemperature:Incasetheheatresistancetemperature
ofthecontaineris200℃→Presettemperaturemustbebelow170℃）
・Willgetheatedtoahighertemperatureifkeptneartheairoutletofthe
hotairheater(innerrearend).
Thesiliconcontainermaydeformifkeptattheinnerrearend.
Cannotbeusedfor
Superheatedsteamandgrill.
Plasticcontainersthat
areheatresistantupto
aminimumtemperature
of140℃.
● However,thefollowingitemscannotbeused.
• Foodwithhighcontentofoilsandfatsor
sugar(becomesveryhot)
• Sealedcontainers
• Lidsvulnerabletoheat
• Containersnotmarkedwith
“Microwaveovenuse”
• Containersorbagsprocessedwithmetal
suchasaluminumonsurfaces
(Maynotbedonewell)
● Autoreheatcannotbeusedoncontainers
withlids.Removethelid.

15
AccessoriesContainersthatcannotbeused
Squaretray・Gridiron
Unusable
●Notuseddueto
sparking.
●
Specially,incaseofwiremesh
andskewerstherewillbesparking.
●
However,isusedpartiallyforraw
defrosting(microwave)Usein
accordancetotheinformation
containedinthisbooklet.
RawdefrostingPage25,:Liquorcans:Page32
● Theydeformorbreakduetomelting.
●Plasticssuchpolyethylene,styrene,
phenol,melamineandureacannot
beused.
Usable
Plasticcontainers
andwraps
※1
Aluminumandmetal
containerssuch
asmetalrack
unscrewed,etc.
AluminumFoil
●Cutglassortoughened
glassescannotbeused.
●Crystalorhardened
containersofdifferent
thicknessorifdistorted
areunusable.
Glassthatarenot
heatResistant
Wood・Bamboo・Paper
● Mayresultinsparksor
burning.
● However,incaseofeasy
baking,papersubjectedto
heattreatmentoroven
sheetcanbeused.
Lacquerware
● Thereisriskofthepainting
peelingofforgetting
cracked.
Plasticcontainersandwraps
thatareheatresistantupto
amaximumtemperatureof
140℃
●Theydeformorbreakdueto
melting.
Ceramicandporcelain※1
● However,heatresistancepottery
suchasacookingpan,gratindish,
etc.,isusable.
※1： ｢Fermentation｣｢Steamfermentation｣
areusable.
Useheatresistantones.
Squaretray・Gridiron
Notice Forthewaytousecontainerswhicharenotmentioned,pleasecontacttheir
manufacturersordistributors.
Preparationand
confirmation
Vesselsyoucanuse/Vesselsyoucan'tuse

16
CUP
MIN
Openthewindow
Switchonthefan
CUP
MIN
Heatingemptyoven/Deodorizing
Warmingtheemptyoven・Deodorize
Donotplaceanythinginsidetheoven,
Closethedoor.
1
3
2
Select43Decide
4
Thebuzzerwillbeep3times
whenfinishdeodorizing
・「Hightemperature」willbedisplayed.
Openthedoorandwaitforthetemperatureinsidetocooldown.
・Sincetheglassdoorandovenchamberishot,becareful.
・Donotrepeatthedeodorizeoption.
Start（StartDeodorizing）
・30minutestodeodorize
・Ifyouturnleft,youcanselectquicker.
Emptygrillinganddeodorization
mustbedoneonlyafterwiping
offanydirtinsidetheoven.
Whenoperatingtheovenforthefirsttime,refertoCleaningon[43Deodorize],inordertoburn
awayanyodorduetooilorgrease（Emptygrilling）
Duringthefirsttime,smokeandsmellmaybereleased,thisdoesnotindicateamalfunction.
Removeanysmallpetsorbirdstodifferentroomthathasventilationtoavoidsuffocationdueto
smokeandopenallwindows.
DECISIONSETTING
Turn
Push

17
●Riceorfood
→Reheat「1COOKEDRICE」, 「 2DISH」,
「32DISHES」
Dialmenu「16SteamReheat」
●Milk
→TouchmenuWith
「13Milk」
page24・26
●Sake
→Dialmenu
「20Sake」
page27・32
●Coffee・Water
Beverages
→Settimeandoutput
powerin「Microwave」
page34 〜 35・46
●  Defrostmeatandfish
→Touchmenu「10SteamDefrost」,
「11RapidDefrost」,
「12Sashimi(Semi-Defrost)」
page24・25
●  Wellcookedfood,friedfood,
roastedfood
→Dialmenu「17CrispyReheat」
page27・30
●  Breadwithside-dishonTop,butterrolland
Frenchbread
→Dialmenu「18FluffyBread」 page27・31
＊Breadtoast,pleaseseeonpage130
●  Chinesebun
→Dialmenu
「19SteamedBun」
page27・31
●  Frozenboiledvegetable
→Settimeandoutputpowerin
「Microwave」
page34 〜 35・46
＊Sprinklewaterforheatingcorn
andmixedvegetable.
Usemicrowavesafecontainerforheating.
●  Commerciallyprocessedfrozenfood
→Settimeandoutputpowerin
「Microwave」
page34 〜 35・46
＊ Refertotheinstructionsonthepacketfor
heatingandmonitorthefoodwhileheating.
page20 〜 22
page27・30
REHEAT
recommendations
Whatcanbeusedtowarmup?
Heatingemptyoven/Deodorizing/REHEATrecommendations
Preparationand
confirmation

18
Whenheatingwithmicrowave
●Reheat（Cookedrice・Dish・2dishes）●3Defrost●Milk●Boiledvegetables
●Steamreheat●Sake●Desiredtemperature
※Whatisinfraredsensor?
Itisasensortomeasureinfraredvolumeradiatingfromfoodinordertodetect
temperatureatfoodsurface.Heatingwhiledetectingtemperatureatfoodsurface,
enableustocookatdefinedtemperaturewithoutbeingaffectedbystarting
temperature,weightoffoodcontainers,etc.
Toprovideproperdetectionoffoodtemperaturewithaninfraredsensor,Please
referpage18〜19.
Microwaveheatingusingtheinfraredsensor
Pleasefollowtheinstructions
●Properuseofwraps
・Whenfoodwrapisused,someportionofitisunused.
Readtheinstructioninthemenucarefully.
・Ensurethewrapdoesnotoverlapandiscoveredsecurelyin
thebottom.
・Incorrectuseswillcausethedishmaynotbecookedwell.
Thefoodmayburnduetosmokeorfire.
●Donotusecover
・Ifceramic,glassorplasticproductsarecoveredwithalid,the
infra-redsensorwillnotbeabletodetectthetemperatureof
thefoodaccuratelyandcannotheatcorrectly.
・Foodboxesinmarketarethesame.Pleasetakecoverandaluminumfoilout.
●Iftheoveniscontinuousused,ensurethatitcoolsdown.
・Iftheovenishot,theinfraredsensormaynotbeableto
detectthetemperaturecorrectly.
Ifthe[HIGHTEMP]isdisplayedinthecontrolpanel,
waituntilthedisplaydisappears.
● Usepropercontainersaccordingtothe
quantitiesoffood.
● Usethecontainerswithalowandwideedge.
● Cleanthecavityandwipevaporbeforenextuse.
・Ifnotproceedthecleaning,theinfraredsensormaynotwork
properly.Italsowillcausesmokeorfire.
●Donotusesquaretrayandgridiron.
・ Ifsquaretraysandgrillsareused,thesecancausesparkingleadingto
malfunction.
Cool
down
Wipeoff
