Toshiba MW2-AG23PF User manual

MICROWAVE SOLO OVEN
INSTRUCTION MANUAL
MW2-AG23PF(BK)
Please review this instruction manual before operating.

PRODUCT SAFETY
Precautions to avoid possible exposure to excessive
microwave energy ............................................................................................................................................ EN-01
Important safety instructions ....................................................................................................................... EN-03
To reduce the risk of injury to persons grounding installation......................................................... EN-08
Cleaning................................................................................................................................................................ EN-10
Utensils.................................................................................................................................................................. EN-11
Materials you can use in
microwave oven ................................................................................................................................................ EN-12
Materials can not be used in microwave oven ...................................................................................... EN-14
PRODUCT SETTING
Setting up your oven ....................................................................................................................................... EN-15
INSTRUCTION FOR USE
Before using for the rst time ....................................................................................................................... EN-19
Operation............................................................................................................................................................. EN-20
1. Clock setting.................................................................................................................................................. EN-21
2. Kitchen timer................................................................................................................................................. EN-22
3. Microwave cooking .................................................................................................................................... EN-23
4. Grill or combi. Cooking.............................................................................................................................. EN-23
5. Speedy cooking ........................................................................................................................................... EN-24
6. Defrost by weight........................................................................................................................................ EN-25
7. Defrost by time............................................................................................................................................. EN-25
8. Auto menu..................................................................................................................................................... EN-26
CONTENTS

9. Lock-out function for children................................................................................................................ EN-26
10. Eco function................................................................................................................................................ EN-27
11. Specication ............................................................................................................................................... EN-27
12. Turntable reset function......................................................................................................................... EN-27
Cleaning................................................................................................................................................................ EN-29
MAINTENANCE
Troubleshooting ................................................................................................................................................ EN-31
NOTE
BEFORE OPERATING THIS PRODUCT, READ,
UNDERSTAND, AND FOLLOW THESE INSTRUCTIONS.
BE SURE TO SAVE THIS BOOKLIST FOR FUTURE
REFERENCE.

EN-01
PRODUCT SAFETY
PRECAUTIONS TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY
(a). Do not attempt to operate this oven with the door open since
this can result in harmful exposure to microwave energy. It is
important not to break or tamper with the safety interlocks.
(b). Do not place any object between the
oven front face and the door or allow
soil or cleaner residue to accumulate on
sealing surfaces.
(c). WARNING: If the door or door seals are damaged, the
oven must not be operated until it has been repaired by a
competent person.
ADDENDUM
If the apparatus is not maintained in a good state of cleanliness, its
surface could be degraded and aect the lifespan of the apparatus
and lead to a dangerous situation.

EN-02
SPECIFICATIONS
MODEL MW2-AG23PF(BK)
RATED VOLTAGE 230-240V~50Hz
RATED INPUT POWERMICROWAVE 1250-1320W
RATED OUTPUT POWERMICROWAVE 850-900W
RATED INPUT POWERGRILL 1000-1050W
OVEN CAPACITY 23L
TURNTABLE DIAMETER 270mm
EXTERNAL DIMENSIONS 485x403x296mm
NET WEIGHT Approx. 14.1 kg

EN-03
IMPORTANT SAFETY INSTRUCTIONS
WARNING
To reduce the risk of re, electric shock, injury to
persons or exposure to excessive microwave oven
energy when using your appliance, follow basic
precautions, including the following:
Read and follow the
specic: "PRECAUTIONS
TO AVOID POSSIBLE
EXPOSURE TO EXCESSIVE
MICROWAVE ENERGY".
This appliance can be
used by children aged
from 8 years and above
and persons with reduced
physical, sensory or mental
capabilities or lack of
experience and knowledge
if they have been given
supervision or instruction
concerning use of the
appliance in a safe way and
understand the hazards
involved. Children shall not
play with the appliance.
Cleaning and user
maintenance shall not be
made by children without
supervision.
Keep the appliance and
its cord out of reach of
children less than 8 years.

EN-04
If the supply cord is
damaged, it must
be replaced by the
manufacturer, its service
agent or similarly qualied
persons in order to avoid a
hazard.
WARNING: Ensure that the
appliance is switched o
before replacing the lamp
to avoid the possibility of
electric shock.
WARNING: It is hazardous
for anyone other than a
competent person to carry
out any service or repair
operation that involves the
removal of a cover which
gives protection against
exposure to microwave
energy.
WARNING: Liquids and
other foods must not be
heated in sealed containers
since they are liable to
explode.
When heating food in
plastic or paper containers,
keep an eye on the oven
due to the possibility of
ignition.
Only use utensils that
are suitable for use in
microwave ovens.
If smoke is emitted, switch
o or unplug the appliance
and keep the door closed
in order to stie any ames.
Microwave heating of
beverages can result in
delayed eruptive boiling,
therefore care must be
taken when handling the
container.
The contents of feeding
bottles and baby food jars
shall be stirred or shaken
and the temperature
IMPORTANT SAFETY INSTRUCTIONS

EN-05
checked before
consumption, in order to
avoid burns.
The oven should be
cleaned regularly and any
food deposits removed.
Failure to maintain the
oven in a clean condition
could lead to deterioration
of the surface that could
adversely aect the life of
the appliance and possibly
result in a hazardous
situation.
Only use the temperature
probe recommended
for this oven. (for ovens
provided with a facility to
use a temperature-sensing
probe.)
The microwave oven must
be operated with the
decorative door open. (for
ovens with a decorative
door.)
This appliance is intended
to be used in household
and similar applications
such as:
1. sta kitchen areas in
shops, oces and other
working environments;
2. by clients in hotels,
motels and other
residential type
environments;
3. farm houses;
4. bed and breakfast type
environments.
The microwave oven is
intended for heating food
and beverages. Drying
of food or clothing and
heating of warming pads,
slippers, sponges, damp
cloth and similar may lead
to risk of injury, ignition or
re.
IMPORTANT SAFETY INSTRUCTIONS

EN-06
IMPORTANT SAFETY INSTRUCTIONS
The appliance is intended
to be used freestanding.
The rear surface of
appliances shall be placed
against a wall.
The temperature of
accessible surfaces may be
high when the appliance is
operating.
WARNING: When the
appliance is operated in
the combination mode,
children should only use
the oven under adult
supervision due to the
temperatures generated.
Eggs in their shell and
whole hard-boiled eggs
should not be heated in
microwave ovens since
they may explode, even
after microwave heating
has ended.
The appliance must not
be installed behind a
decorative door in order
to avoid overheating.
(This is not applicable for
appliances with decorative
door.)
The microwave oven shall
not be placed in a cabinet
unless it has been tested in
a cabinet.
Metallic containers for food
and beverages are not
allowed during microwave
cooking.
The appliance shall not
be cleaned with a steam
cleaner.

EN-07
IMPORTANT SAFETY INSTRUCTIONS
The appliances are not
intended to be operated by
means of an external timer
or separate remote-control
system.
READ CAREFULLY AND KEEP FOR
FUTURE REFERENCE

EN-08
TO REDUCE THE RISK OF INJURY TO
PERSONS GROUNDING INSTALLATION
This appliance must be grounded. In the event of an electrical
short circuit, grounding reduces the risk of electric shock by
providing an escape wire for the electric current.
This appliance is equipped with a cord having a grounding wire
with a grounding plug. The plug must be plugged into an outlet
that is properly installed and grounded.
WARNING - Improper use of the grounding can result in a risk of
electric shock. Consult a qualied electrician or serviceman if the
grounding instructions are not completely understood or if doubt
exists as to whether the appliance is properly grounded.
If it is necessary to use an extension cord, use only a 3-wire
extension cord.
DANGER
Electric Shock Hazard:
Touching some of the internal components can
cause serious personal injury or death. Do not
disassemble this appliance.

EN-09
WARNING
Electric Shock Hazard:
Improper use of the grounding can result in electric
shock. Do not plug into an outlet until appliance is
properly installed and grounded.
1. A short power-supply cord is provided to reduce
the risks resulting from becoming entangled in or
tripping over a longer cord.
2. If a long cord or extension cord is used:
(1). The marked electrical rating of the cord set or
extension cord should be at least as great as
the electrical rating of the appliance.
(2). The extension cord must be a grounding-type
3-wire cord.
(3). The longer cord should be arranged so that it
will not drape over the counter top or tabletop
where it can be pulled on by children or
tripped over unintentionally.
TO REDUCE THE RISK OF INJURY TO
PERSONS GROUNDING INSTALLATION

EN-10
CLEANING
Be sure to unplug the appliance from the power supply.
1. Clean the cavity of the oven after using with a slightly damp
cloth.
2. Clean the accessories in the usual way in soapy water.
3. The door frame and seal and neighbouring parts must be
cleaned carefully with a damp cloth when they are dirty.
4. Do not use harsh abrasive cleaners or sharp metal scrapers to
clean the oven door glass since they can scratch the surface,
which may result in shattering of the glass.
5. Cleaning Tip---For easier cleaning of the cavity walls that the
food cooked can touch: Place half a lemon in a bowl, add 300ml
(1/2 pint) water and heat on 100% microwave power for 10
minutes. Wipe the oven clean using a soft, dry cloth.

EN-11
UTENSILS
CAUTION
Personal Injury Hazard:
It is hazardous for anyone other than a competent
person to carry out any service or repair operation
that involves the removal of a cover which gives
protection against exposure to microwave energy.
See the instructions on " Materials you can use in
microwave oven "or " Materials can not be used
in microwave oven "
There may be certain non-metallic utensils that are
not safe to use for microwaving. If in doubt, you can
test the utensil in question following the procedure
below.
Utensil Test:
1. Fill a microwave-safe container with 1 cup
of cold water (250ml) along with the utensil
in question.
2. Cook on maximum power for 1 min.
3. Carefully feel the utensil. If the empty
utensil is warm, do not use it for microwave
cooking.
4. Do not exceed 1 min cooking time.
NOTE KEEP THE CAVITY CLEAN

EN-12
MATERIALS YOU CAN USE IN
MICROWAVE OVEN
UTENSILS REMARKS
Browning dish
Follow manufacturer’s instructions.
The bottom of browning dish must be at least 3/16 inch
(5mm) above the turntable. Incorrect usage may cause
the turntable to break.
Dinnerware
Microwave-safe only. Follow manufacturer’s
instructions. Do not use cracked or chipped dishes.
Glass jars
Always remove lid. Use only to heat food until just
warm. Most glass jars are not heat resistant and may
break.
Glassware
Heat-resistant oven glassware only. Make sure there is
no metallic trim. Do not use cracked or chipped dishes.
Oven cooking bags
Follow manufacturer’s instructions. Do not close with
metal tie.
Make slits to allow steam to escape.
Paper plates and cups
Use for short–term cooking/warming only. Do not leave
oven unattended while cooking.
Paper towels
Use to cover food for reheating and absorbing fat. Use
with supervision for a short-term cooking only.
Parchment paper
Use as a cover to prevent splattering or a wrap for
steaming.

EN-13
UTENSILS REMARKS
Plastic
Microwave-safe only. Follow the manufacturer’s
instructions. Should be labeled “Microwave Safe”. Some
plastic containers soften, as the food inside gets hot.
“Boiling bags”and tightly closed plastic bags should be
slit, pierced or vented as directed by package.
Plastic wrap
Microwave-safe only. Use to cover food during cooking
to retain moisture. Do not allow plastic wrap to touch
food.
Thermometers
Microwave-safe only (meat and candy thermometers).
Wax paper
Use as a cover to prevent splattering and retain
moisture.
MATERIALS YOU CAN USE IN
MICROWAVE OVEN

EN-14
MATERIALS CAN NOT BE USED IN
MICROWAVE OVEN
UTENSILS REMARKS
Aluminum tray
May cause arcing. Transfer food into microwave-safe
dish.
Food carton with metal
handle
May cause arcing. Transfer food into microwave-safe
dish.
Metal or metal trimmed
utensils
Metal shields the food from microwave energy.
Metal trim may cause arcing.
Metal twist ties
May cause arcing and could cause a fire in the oven.
Paper bags
May cause a fire in the oven.
Plastic foam
Plastic foam may melt or contaminate the liquid
inside when exposed to high temperature.
Wood
Wood will dry out when used in the microwave oven
and may split or crack.

EN-15
NAMES OF MICROWAVE OVEN PARTS AND ACCESSORIES
Remove the oven and all materials from the carton and oven cavity.
A. Control panel
B. Glass tray
C. Turntable shaft
D. Turntable ring assembly
E. Door assembly
F. Observation window
G. Safety interlock system
E
G
F
B
AD C
Instruc
tion Manual
Glass Tray
(
Can be used under all functions) Grill Rack( Can not be used in microwave
function and must be placed on the glass tray )
PRODUCT SETTING
SETTING UP YOUR OVEN

EN-16
SETTING UP YOUR OVEN
TURNTABLE INSTALLATION
Cleaning the cooking compartment and putting the turntable in place.
For new installations, make sure all packaging and shipping tape has been removed from the
turntable shaft.
Before using the appliance to prepare food for the first time, you will need to put the turntable
in place correctly. You must clean the cooking compartment and accessories.
How to put the turntable in place:
1. Place the turntable ring assembly ③into the recess in
the cooking compartment.
2. Place the glass tray ①on the turntable ring
assemblies ③.
Fit the raised, curved lines in the center of the glass
tray bottom between the three spokes of the shaft.
Make sure that the glass tray ①engages in the
turntable shaft ②in the center of the cooking
compartment floor. The rollers on the shaft should fit
inside the turntable bottom ridge.
NOTE
• Never use the appliance without the turntable. Make sure that it is properly
engaged. The turntable can turn clockwise or anti-clockwise.
• Never place the glass tray upside down. The glass tray should never be
restricted.
• Both glass tray and turntable ring assembly must always be used during
cooking.
• All food and containers of food are always placed on the glass tray for
cooking.
• Never restrict the movement of the turntable.
• If glass tray or turntable ring assembly cracks or breaks, contact your nearest
authorized service center.
1
2
3

EN-17
COUNTERTOP INSTALLATION
Remove all packing material and accessories. Examine the oven for any damage such as dents or
broken door. Do not install if oven is damaged.
Cabinet: Remove any protective lm found on the microwave oven cabinet surface. Do not
remove the light brown Mica cover that is attached to the oven cavity to protect the magnetron.
INSTALLATION
1. Select a level surface that provide enough open space for the intake and/or outlet vents.
a. The minimum installation height is 85cm.
b. The rear surface of appliance shall be placed against a wall. Leave a minimum clearance
of 30cm above the oven. A minimum clearance of 20cm is required between the oven
and any adjacent walls.
c. Do not remove the legs from the bottom of the oven.
d. Blocking the intake and/or outlet openings can damage the oven.
e. Place the oven as far away from radios and TV as possible.
Operation of microwave oven may cause interference to your radio or TV reception.
0 inches
(0 cm)
8,0 inches
(20 cm)
12 inches (30 cm)
8
,0 inches
(20 cm)
>
(85 см)
SIDE DISTANCE
INCHES/CM
Top 12 inches/30cm
Left 8.0 inches/20cm
Right 8.0 inches/20cm
Behind 0 inches/ 0cm
Front Open
SETTING UP YOUR OVEN
