Philips PET708/98 User manual

Portable DVD Player
User manual
PET708
PET708_98_Eng 3/11/08 17:13 Page 1

1
1
2
7
3
8
9
4
5
6
10 11 12 13
PET708_98_Eng 3/11/08 17:13 Page 2

2
FRONT VIEW
REAR VIEW
PET708_98_Eng 3/11/08 17:13 Page 3

English FUNCTIONAL OVERVIEW
Main unit controls ( see figure 1)
1OPEN....................Open disc door to insert or remove disc
2POWER ...............Switch the player on / off
39... .......................Press once to stop playback and store the stop position.
Press twice to stop playback completely.
2;... ......................Start / pause / resume playback
4J( /§... ...............Search backward ( J( ) or search forward ( )K )
5- VOL + .................Volume control
6SETUP ..................Enters SETUP menu
MENU...................Display MENU page
73,4,1,2..........Up / down / left / right cursor
OK .........................Confirm selection
Front of player ( see figure 1)
8POWER/CHR/IR .....Power and charging indicator / Remote sensor
PET708_98_Eng 3/11/08 17:13 Page 4

CAUTION
Use of controls or adjustments or performance of procedures
other than herein may result in hazardous radiation exposure
or other unsafe operation.
FUNCTIONAL OVERVIEW
Right of player ( see figure 1)
9PHONE ......................... Headphones jack
0AV OUT ........................ Audio/Video output jack
!AV IN ............................ Audio/Video input jack
@COAXIL......................... Digital audio output jack
#DC IN 12V.................... Power supply socket
COPYRIGHT INFORMATION
The making of unauthorized copies of copy-protected material, including
computer programmes, files, broadcasts and sound recordings, may be an
infringement of copyrights and constitute a criminal offence. This equipment
should not be used for such purposes.
. DISPOSAL OF YOUR OLD PRODUCT
Your product is designed and manufactured with high quality materials and
components, which can be recycled and reused.
When this crossed-out wheeled bin symbol is attached to a product it
means the product is covered by the European Directive 2002/96/EC.
Please inform yourself about the local separate collection system for
electrical and electronic products.
Please act according to your local rules and do not dispose of your old
products with your normal household waste. The correct disposal of your
old product will help prevent potential negative consequences for the environment
and human health.
PET708_98_Eng 3/11/08 17:13 Page 5

REMOTE CONTROL
Remote controls ( see figure 2)
13,4,1,2..........Up / down / left / right cursor
OK .........................Confirms selection
2VOL+ / - ................Volume control
3J( / §... ...........For previous (J( ) or next (§) chapters, tracks or titles
;... .........................Pauses playback
2.. .........................Starts / resumes playback
9............................Press twice to stop playback
5/ 6... ..............Search backward (5 ) or search forward (6)
4OSD.......................On Screen Display on / off
...........................Slow motion
5AUDIO ..................Audio langauge selector
ZOOM...................Enlarges video image
6A > B.....................To repeat or loop a sequence in a title
PLAY-MODE ........Selects play order options
70 - 9.......................Numeric keypad
8MUTE....................Muting player volume
REPEAT ................Repeats chapter / title / disc
9RETURN ...............For VCD menu page
ANGLE..................Selects DVD camera angle
0SUBTITLE ............Subtitle language selector
LANGUAGE .........Language selector
!MENU...................Displays MENU page
@SETUP ..................Enters SETUP menu
#Infra Red port
$BATTERY COMPARTMENT
PET708_98_Eng 3/11/08 17:13 Page 6

INTRODUCTION
Your portable DVD player
Your portable DVD player plays digital video discs conforming to the universal
DVD Video standard. With it, you will be able to enjoy full-length movies with
true cinema picture quality, and stereo or multichannel sound (depending on the
disc and on your playback set-up).
The unique features of DVD-Video, such as selection of soundtrack and subtitle
languages, and of different camera angles (again depending on the disc), are all
included.
What’s more, parental lock lets you decide which discs your children will be able
to see. You will find your player remarkably easy to use with the On-Screen
Display and player display in combination with the remote control.
Unpacking
First check and identify the contents of your package, as listed below:
• Portable DVD player • Remote Control
• Car adaptor (12V) • AC power adaptor
• Rechargeable battery pack • User Manual
• Warranty • Audio / Video cable
• Second LCD screen (PAC13X) • Car headrest mounting kit
• Power cord
Placement
• Place the player on a firm, flat surface.
• Keep away from domestic heating equipment and direct sunlight.
• If the player cannot read CDs/DVDs correctly, try using a commonly
available cleaning CD/DVD to clean the lens before taking the player to be
repaired. Other cleaning methods may destroy the lens.
• Always keep the disc door closed to avoid dust on the lens.
•The lens may cloud over when the player is suddenly moved from cold to warm
surroundings. It is then not possible to play a CD/DVD. Leave the player in a warm
environment until the moisture evaporates.
PET708_98_Eng 3/11/08 17:13 Page 7

INTRODUCTION
Playable disc formats
In addition to DVD-Video disc, you will also be able to play all Video CDs and
audio CDs (including CDR, CDRW,DVD±R and DVR±RW).
DVD-Video
Depending on the material on the disc (a movie, video clips, a
drama series, etc.) these discs may have one or more Titles,
and each Title may have one or more Chapters. To make
access easy and convenient, your player lets you move
between Titles, and also between Chapters.
Video CD
Depending on the material on the disc (a movie, video clips,
a drama series, etc.) these discs may have one or more
Tracks, and tracks may have one or more indexes, as indicat-
ed on the disc case.To make access easy and convenient,
your player lets you move between tracks and between
indexes.
Audio CD / MP3 CD
Audio CDs / MP3 CD contain music tracks only. You can play them in the conven-
tional way through a stereo system using the keys on the remote control and/or
main unit, or via the TV using the On Screen Display (OSD).
CD with JPEG files
You can also view JPEG still photos on this player.
PET708_98_Eng 3/11/08 17:13 Page 8

GENERAL INFORMATION
Power Sources
This unit operates on a supplied AC adaptor, car adapter, or a rechargeable bat-
tery pack.
• Make sure that the input voltage of the AC adaptor is in line with the local volt-
age. Otherwise, the AC adaptor and unit may be damaged.
• Do not touch the AC adaptor with wet hands to prevent electric shock.
• When connecting with car power (cigarette lighter) adaptor, be sure the
input voltage of the adaptor is identical with car voltage.
• Unplug the AC adaptor from the outlet or remove the battery pack when
the unit is not used for long periods of time.
• Hold the plug to disconnect the AC adaptor. Do not pull the power cord.
Safety and maintenance
• Do not disassemble the unit for laser rays are dangerous to eyes.
Any service should be done by qualified service personnel.
• Unplug the AC adaptor to cut the power if liquid or objects get inside the unit.
• Take care not to drop the unit or subject it to strong shocks, which may
cause malfunction.
• Do not expose to excessive heat caused by heating equipment or
direct sunlight.
• This product is not waterproof: do not allow your player to be submersed
in water. Water entering the player may cause major damage.
• Do not use any cleaning agents containing alcohol, ammonia, benzene,
or abrasives as these may harm the player.
• Apparatus shall not be exposed to dripping or splashing. Do not place any
sources of danger on the appartus (e.g. liquid filled objects,lighted candles)
• Do not touch the lens!
Note: When the player is in use for a long period of time, the surface will be
heated. This is normal.
PET708_98_Eng 3/11/08 17:13 Page 9

GENERAL INFORMATION
Hearing Safety
Listen at a moderate volume:
• Using headphones at a high volume can impair your hearing. This
product can produce sounds in decibel ranges that may cause hear-
ing loss for a normal person, even for exposure less than a minute.
The higher decibel ranges are offered for those that may have
already experienced some hearing loss.
• Sound can be deceiving. Over time your hearing "comfort level" adapts to high-
er volumes of sound. So after prolonged listening, what sounds "normal" can
actually be loud and harmful to your hearing. To guard against this, set your
volume to a safe level before your hearing adapts and leave it there.
To establish a safe volume level:
• Set your volume control at a low setting.
• Slowly increase the sound until you can hear it comfortably and clearly, without
distortion.
Listen for reasonable periods of time:
• Prolonged exposure to sound, even at normally "safe" levels, can also cause
hearing loss.
• Be sure to use your equipment reasonably and take appropriate breaks.
Be sure to observe the following guidelines when using your headphones:
• Listen at reasonable volumes for reasonable periods of time.
• Be careful not to adjust the volume as your hearing adapts.
• Do not turn up the volume so high that you can't hear what's around you.
• You should use caution or temporarily discontinue use in potentially hazardous
situations.
• Do not use headphones while operating a motorized vehicle, cycling, skate-
boarding, etc.; it may create a traffic hazard and is illegal in many areas.
PET708_98_Eng 3/11/08 17:13 Page 10

GENERAL INFORMATION
Handling discs
•Do not attach paper or tape to the disc.
•Keep the disc away from direct sunlight or heat
sources.
•Store the disc in a disc case after playback.
•To clean, wipe the disc outwards from the center
with a soft, lint-free clean cloth.
On handling the LCD screen
The LCD is manufactured using high precision technology. You may, however, see
tiny black points that continuously appear on the LCD. This is a normal result of
the manufacturing process and does not indicate a malfunction.
Environmental information
We have reduced the packaging to its minimum and made it easy to separate into
mono materials: cardboard, PS, PE and PET.
Your set consists of material which can be recycled if disassembled by a special-
ized company. Please observe the local regulations to dispose of packaging,
exhausted batteries and old equipment.
Copyright information
All other brand and product names are trademarks of their respective companies
or organizations.
Unauthorized duplication of any recordings downloaded from the internet or made
from CDs / VCDs / DVDs is a violation of copyright laws and international treaties.
PET708_98_Eng 3/11/08 17:13 Page 11

PREPARATIONS
Power supply
Using the AC / DC adaptor
Connect the supplied adapter to the set and
the main power supply (as shown).
TIP
To avoid damage to the player, switch off before plugging or unplugging the AC
adaptor.
Using the car adapter
Connect the supplied car adapter to the set and the car cigarette lighter outlet.
TIP
• To avoid damage to the player, switch off before plugging or unplugging the car
adaptor.
• When connecting with car power (cigarette lighter) adaptor, be sure the input
voltage of the adaptor is identical with car voltage.
Powering your remote control
1Open the battery compartment.
Remove the protective plastic tab
(first time users only).
2Insert 1 x lithium 3V battery, type CR2025, then close
the compartment.
✔
✔
PET708_98_Eng 3/11/08 17:13 Page 12

PREPARATIONS
Attaching and charging the battery pack*
1Switch off the set. Attach the battery pack
as shown.
2Connect the supplied adapter to the set and the
main power supply (as shown). Charge until the
red indicator turns off (approximately 4.5 - 6.5
hours when unit is charged from power off).
TIP
• It is normal for the battery pack to become warm
during charging.
• is shown on the screen when battery power is run-
ning low.
Detaching the battery pack
1Switch off the set.
2Unplug the AC adapter.
3Turn the player upside down.
4Press down the battery pack lock switch 1.
5Slide off the battery pack as shown 23.
* Rechargeable batteries have a limited num-
ber of charge cycles and may eventually
need to be replaced. Battery life and num-
ber of charge cycles vary by use and set-
tings.
POWER
ON OFF
POWER
ON OFF
✔
✔
PET708_98_Eng 3/11/08 17:13 Page 13

PREPARATIONS
Connections
Connecting headphones
Connect the headphones into the pjack of your set.
Connecting additional equipment
• Turn off your set before connecting to any addition-
al equipment.
• You can connect the player to a TV or an amplifier to
enjoy DVDs or karaoke.
AV OUT
AV IN
Connection Color
Video Yellow
Audio (Left) White
Audio (right Red
AV OUT
L
R
VODEO IN
AUDIO IN
D
COAXIALAV IN
TV
White
Red
Yellow
L
R
VODEO OUT
AUDIO OUT
DC IN 12V
COAXIALAV IN
TV
White
Red
Yellow
PET708_98_Eng 3/11/08 17:13 Page 14

PREPARATIONS
Digital Audio Out
TIP
• You can also make use of the COAXIAL jack for
digital audio output.
• Please refer to the user manuals of your addi-
tional equipment for more information about
connection.
• Players support NTSC/PAL/AUTO television sets.
GENERAL EXPLANATION
About this manual
This manual gives the basic instructions for operating this DVD player.
Some DVD discs however are produced in a way that requires specific oper-
ation or allows only limited operation during playback. In these cases the
player may not respond to all operating commands. When this occurs,
please refer to the instructions in the disc inlay. When a appears on the
screen, the operation is not permitted by the player or the disc.
Remote control operation
• Unless otherwise stated, all operations can be carried out with the
remote control. Always point the remote control directly at the player,
making sure there are no obstructions in the path of the infrared beam.
• When there are corresponding keys on the main unit, they can also be used.
Menu navigation
• Your player has an intuitive menu navigation system to guide you through
various settings and operations.
• Use the function keys to activate / disable relevant operations.
• Use 3,4,1,2to browse through menus.
• Press OK key to confirm your selection.
✔
Yellow
✔
PET708_98_Eng 3/11/08 17:13 Page 15

BASIC FUNCTIONS
Switching on for OSD language setup
English is the default language of your player’s on screen display. You may
choose to use English, French, or German for your player’s on screen display.
Countries OSD Language Options
Asia Pacific English, French, German
1Slide the POWER switch to ON to switch on the
player.
2Press SET UP for the set up menu.
3Select GENERAL SETUP and press OK.
4Scroll and select OSD LANG and press 2to
select from OSD language options.
5Select your preferred language and press OK.
Loading discs and switching on
1Press OPEN to open the disc door.
2Insert your chosen disc, label side up (also when a double sided
DVD disc is inserted). Make sure it is sitting properly in the correct recess.
3Gently push to close the door.
4Slide the POWER switch to ON to switch on the player.
TIP
A normal mechanical noise is heard during playback.
✔
PET708_98_Eng 3/11/08 17:13 Page 16

BASIC FUNCTIONS
Playing a DVD disc
After switching on, inserting the disc and closing the door, playback starts auto-
matically. The screen shows the type of disc loaded. The disc may invite you to
select an item from a menu. Use the 3,4,1,2keys to highlight your
selection,and press OK.
Note: Since it is usual for DVD movies to be released at different times in differ-
ent regions of the world, all players have region codes and discs can have an
optional region code. If you load a disc of a different region code to your player,
you will see the region code notice on the screen. The disc will not play, and
should be unloaded.
Playing an audio or video CD disc
• After switching on, inserting the disc and closing the door, the screen shows
the type of disc loaded as well as information about the disc’s contents.
Press 2to start playback.
• While playing VCD with MTV/Karaoke, press number keys(0-9) to select the
track and press 2or OK to play the track. Press RETURN to go back to menu
of the selection.
PET708_98_Eng 3/11/08 17:13 Page 17

BASIC FUNCTIONS
Playing a MP3-CD
The following playback features are available for MP3-CDs.
Please refer to the corresponding sections for more information.
Volume control, skipping tracks, searching, repeat, shuffle, etc.
Use the 3,4,1,2keys to highlight your selected music folder.
Press OK to play.
Playing a JPEG discs
Use the 3,4,1,2keys to highlight your selected picture folder.
Press OK. The player will then automatically enter the slide show mode.
Using the full display screen, this shows the rest of the JPEG files, one-by-one,
located in the selected current folder.
• Use the 1,2 to rotate the picture.
• Use the 3to flip up/down.
• Use the 4 to flip left/right.
•During the slide show, press MENU to go back to folder screen.
• Press 9to go to group preview.
• Use the 3,4,1,2to highlight the preview picture and access the
on-screen functions.
Note: Unless stated otherwise, all operations described are based on remote con-
trol operation.
PET708_98_Eng 3/11/08 17:13 Page 18

GENERAL FEATURES
Moving to another title / track / chapter
When a disc has more than one title or track, you can
move to another title/track/chapter as follows:
• Press §briefly during play to select the next title/
track / chapter.
• Press J( briefly during play to step back to the previous title/track/chapter.
• To go directly to any title, track or chapter, enter the corresponding
number using the numerical keys (0-9).
Still picture and step frame
Press ;once or more for the following still picture and step frame options:
;x 1 Pause / Still picture
;x 2 screen shows ;2
After the icon ;2 is displayed, press ;repeatedly to
play frame by frame.
Press OK to resume normal playback.
Search
Press Krepeatedly for the following forward search options:
Press J repeatedly for the following backward search options:
JK
2X backwards 2 X forward
4 X backwards 4 X forward
8 X backwards 8 X forward
16 X backwards 16 X forward
32 X backwards 32 X forward
normal speed normal speed
Press OK or 2to resume normal playback.
PET708_98_Eng 3/11/08 17:13 Page 19

GENERAL FEATURES
Slow motion
Press >once or more for the following slow play options:
x 1 1/2 x 5* 1/2 x backward
x 2 1/4 x 6* 1/4 x backward
x 3 1/8 x 7* 1/8 x backward
x 4 1/16 x 8* 1/16 x backward
Press OK or 2to resume normal playback.
*for DVDs only
Changing the audio output
Press AUDIO repeatedly for the following audio options.
x 1 Mono left x 2 Mono right
x 3 Mixed mono x 4 Stereo
ZOOM
The Zoom function allows you to enlarge the video image and to pan
through the enlarged image. Press ZOOM repeatedly to select the following
zooming options.
Zoom x 1 2X Zoom x 2 3X
Zoom x 3 4X Zoom x 4 1/2
Zoom x 5 1/3 Zoom x 6 1/4
Zoom x 7 normal
MUTE
Press MUTE once to mute player volume.
Press MUTE again to disable.
REPEAT
Press REPEAT repeatedly for the following repeat options:
DVD actions VCD actions
x 1 repeats chapter repeats track
x 2 repeats title repeats all
x 3 repeats all cancels repeat
x 4 cancels repeat
PET708_98_Eng 3/11/08 17:13 Page 20
