SERVICE MANUAL
COLOR TELEVISION
N2NS Chassis
PUBLISHED IN JAPAN. Aug. 2002 So
(TAC0221)(TAC0220)
32AFX62 , 36AFX62

– 2 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
TABLE OF CONTENTS
CHAPTER 1 GENERAL ADJUSTMENTS
SAFETY INSTRUCTIONS ...............................................................................................................................................3
SET-UP ADJUSTMENT ................................................................................................................................................... 4
SERVICE MODE ............................................................................................................................................................. 8
ELECTRICAL ADJUSTMENTS ..................................................................................................................................... 11
CIRCUIT CHECKS ........................................................................................................................................................ 13
CHAPTER 2 SPECIFIC INFORMATIONS
SETTING & ADJUSTING DATA .................................................................................................................................... 14
LOCATION OF CONTROLS .......................................................................................................................................... 15
PROGRAMMING CHANNEL MEMORY ........................................................................................................................ 17
CHASSIS AND CABINET REPLACEMENT PARTS LIST ............................................................................................. 18
PC BOARDS BOTTOM VIEW ....................................................................................................................................... 31
TERMINAL VIEW OF TRANSISTORS .......................................................................................................................... 39
CIRCUIT BLOCK DIAGRAM ......................................................................................................................................... 42
SPECIFICATIONS ..................................................................................................................................................... END
APPENDIX:
CIRCUIT DIAGRAM

–3 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
CHAPTER 1 GENERAL ADJUSTMENTS
SAFETY INSTRUCTIONS
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION”AND “PRODUCT SAFETY NOTICE”INSTRUCTIONS BELOW.
X-RAY RADIATION PRECAUTION
1. Excessive high voltage can produce potentially hazard-
ous X-RAY RADIATION. To avoid such hazards, the high
voltage must not be above the specified limit. The nominal
value of the high voltage of this receiver is (A) kV at zero
beam current (minimum brightness) under a 120V AC
power source. The high voltage must not, under any cir-
cumstances, exceed (B) kV.
Refer to table-1 for high voltage (A), (B).
(See SETTING & ADJUSTING DATA on page 14)
Each time a receiver requires servicing, the high voltage
should be checked following the HIGH VOLTAGE CHECK
procedure in this manual. It is recommended that the read-
ing of the high voltage be recorded as a part of the service
record. It is important to use an accurate and reliable high
voltage meter.
2. This receiver is equipped with a Fail Safe (FS) circuit which
prevents the receiver from producing an excessively high
voltage even if the B+ voltage increases abnormally. Each
time the receiver is serviced, the FS circuit must be checked
to determine that the circuit is properly functioning, follow-
ing the FS CIRCUIT CHECK procedure in this manual.
3. The only source of X-RAY RADIATION in this TV receiver
is the picture tube. For continued X-RAY RADIATION pro-
tection, the replacement tube must be exactly the same
type tube as specified in the parts list.
4. Some part in this receiver have special safety-related char-
acteristics for X-RAY RADIATION protection. For contin-
ued safety, parts replacement should be undertaken only
after referring to the PRODUCT SAFETY NOTICE below.
SAFETY PRECAUTION
Connect a 1500 ohm 10 watt resistor, paralleled by a 0.15
µF, AC type capacitor, between a known good earth ground
(water pipe, conduit, etc.) and the exposed metallic parts,
one at a time. Measure the AC voltage across the combi-
nation of 1500 ohm resistor and 0.15 µF capacitor. Re-
verse the AC plug at the AC outlet and repeat AC voltage
measurements for each exposed metallic part. Voltage
measured must not exceed 0.3 volts rms. This corresponds
to 0.2 milliamp. AC. Any value exceeding this limit consti-
tutes a potential shock hazard and must be corrected im-
mediately.
WARNING : Service should not be attempted by anyone unfa-
miliar with the necessary precautions on this receiver. The fol-
lowing are the necessary precautions to be observed before
servicing this chassis.
1. An isolation Transformer should be connected in the power
line between the receiver and the AC line before any serv-
ice is performed on the receiver.
2. Always discharge the picture tube anode to the CRT con-
ductive coating before handling the picture tube. The pic-
ture tube is highly evacuated and if broken, glass frag-
ments will be violently expelled. Use shatter proof gog-
gles and keep picture tube away from the unprotected body
while handling.
3. When replacing a chassis in the cabinet, always be cer-
tain that all the protective devices are put back in place,
such as; non-metallic control knobs, insulating covers,
shields, isolation resistor-capacitor network etc.
4. Before returning the set to the customer, always perform
an AC leakage current check on the exposed metallic parts
of the cabinet, such as antennas, terminals, screwheads,
metal overlays, control shafts etc. to be sure the set is
safe to operate without danger of electrical shock. Plug
the AC line cord directly into a 120V AC outlet (do not use
a line isolation transformer during this check). Use an AC
voltmeter having 5000 ohms per volt or more sensitivity in
the following manner:
AC VOLTMETER
0.15µF
Good earth ground
such as a water
pipe, conduit, etc.
Place this probe on
each exposed
metallic part.
1500 ohm
10 watt
PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These characteristics are
often passed unnoticed by a visual inspection and the protection afforded by them cannot necessarily be obtained by using
replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety charac-
teristics are identified in this manual and its supplements; electrical components having such features are identified by the
international hazard symbols on the schematic diagram and the parts list.
Before replacing any of these components, read the parts list in this manual carefully. The use of substitute replacement
parts which do not have the same safety characteristics as specified in the parts list may create shock, fire, X-ray radiation
or other hazards.

–4 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION”AND “PRODUCT SAFETY NOTICE”ON PAGE 3 OF THIS MANUAL.
SET-UP ADJUSTMENT
■The following adjustments should be made when a complete realignment is required or a new picture tube is installed.
Perform the adjustments in order as follows :
1. Color Purity
2. Convergence
3. White Balance
Note: 1.The PURITY/CONVERGENCE MAGNET assembly and rubber wedges need mechanical positioning.
Refer to figure 1.
2.Mounting position of the purity magnet assembly should fit to same position as old one because slightly difference
to the position depend on a kind of tube.
*There are no adjustment of purity and convergence in some picture tube (Unified with purity magnet)
COLOR PURITY ADJUSTMENT
NOTE : Before attempting any purity adjustments, the
receiver should be operated for at least fifteen
minutes.
1. Evenly degauss the entire screen.
2. Set the CONTRAST and BRIGHTNESS Controls to
the maximum.
3. Display built-in green raster using the TEST SIGNAL
SELECTION function.
4. Loosen the clamp screw holding the deflection yoke
(and remove the rubber Wedges).
5. Slide the yoke forward or backward to provide vertical
green belt (zone) in the picture screen.
6. Rotate and spread the tabs of the purity magnet (See
figure 4.) around the neck of the picture tube until the
green belt is in the center of the screen. At the same
time, center the raster vertically by adjusting the mag-
net as shown below.
7. Move the yoke slowly forward or backward until a uni-
form green screen is obtained. Tighten the clamp screw
of the yoke temporarily.
8. Check the purity of the red and blue raster.
9. Put four wedges into the space between the picture
tube and the yoke to hold the yoke in the adjusted
position. (See figure 2.)
Do not tilt the yoke by excessive insertion of the wedge.
10. Remove cover paper of wedge and stick wedges on
the tube to fix the yoke in the adjusted position.
Fix the wedges with glass cloth tapes.
Green Belt
DEFLECTION YOKE
1-5/8”
PURITY/
CONV.
MAGNET
Xv Coil
Adhesive
RUBBER WEDGES
DEFLECTION
YOKE
Figure 2.
Figure 1.

–5 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
CONVERGENCE ADJUSTMENTS
NOTE: Before attempting any convergence adjustments,
the receiver should be operated for at least fifteen
minutes.
■CENTER CONVERGENCE ADJUSTMENT
1. Display built-in cross-dot pattern using the TEST SIG-
NAL SELECTION function.
2. Adjust the BRIGHTNESS and CONTRAST Controls
for well defined pattern.
3. Loosen the tightening ring and adjust two tabs of the
4-Pole Magnets to change the angle between them
(See figure 4.) and superimpose red and blue vertical
lines in the center area of the picture screen.
(See figure 3.)
4. Turn the both tabs at the same time keeping the con-
stant angle to superimpose red and blue horizontal
lines at the centre of the screen. (See figure 3.)
5. Adjust two tabs of 6-Pole Magnets to superimpose red/
blue line with green one. Adjusting the angle affects
the vertical lines and rotating both magnets affects the
horizontal lines.
6. Repeat adjustments 3, 4, 5 keeping in mind red, green
and blue movement, because 4-Pole Magnets and 6-
Pole magnets interact and make dot movement com-
plex.
7. After completing the “CENTER CONVERGENCE AD-
JUSTMENT”tighten the tightening ring to fix the mag-
nets.
Figure 3.
■Xv COIL ADJUSTMENT
Adjust the Xv coil (on the deflection yoke) to correct
misconvergence at both sides on screen.
Use a hexagonal tip stick (plastic) to adjust the core of
coil.
BLU
BLU RED
RED
6-POLE MAGNETS
MOVEMENT
4-POLE MAGNETS
MOVEMENT
RED/BLUE
RED/BLUE GRN
GRN
Center Convergence by Convergence Magnets
R
B
B
R
B
R
R
B
Clockwise Adjustment Counterclockwise Adjustment
XvCross Pattern View
■SCREEN-CORNER CONVERGENCE
When the misconvergence is still evident on corners even
though the above adjustment is done, use the ferrite sheet
(Part No. 23993622) to correct misconvergence.
1. Put ferrite sheets into the space under the yoke.
Decide such position that misconvergence becomes
minimum, watching picture screen. (See figure below.)
2. Remove cover paper of ferrite sheet to stick it in the
place on the tube. Put adhesive tapes on ferrite sheets
to fix.
Figure 4.
Ferrite
Sheets
Ferrite
Sheets
For correcting misconvergence
on the position A
A
4-POLE
MAGNETS
6-POLE
MAGNETS
PURITY
MAGNETS
PURITY/CONVERGENCE
MAGNETS
ADJUST THE ANGLE
(VERTICAL LINES) FIXED
ROTATE TWO TABS
AT THE SAME TIME
(HORIZONTAL LINES)
ADJUSTMENT OF MAGNETS
Clockwise Adjustment Counterclockwise Adjustment
XVCross Pattern View

–6 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION”AND “PRODUCT SAFETY NOTICE”ON PAGE 3 OF SERVICE MANUAL.
SET-UP ADJUSTMENT
■The following adjustments should be made when a complete realignment is required or a new picture tube is installed.
Perform the adjustments in order as follows :
1. Color Purity
2. Convergence
3. White Balance
Note: The PURITY/CONVERGENCE MAGNET assembly and rubber wedges need mechanical positioning.
Refer to figure 1.
COLOR PURITY ADUSTMENT
(1) Let the screen face in the installing direction or toward the east (when it is to be moved), bring up the service mode
screen after demagnetizing (front, left, right, and top) with the degaussing coil, receive white signals by pressing the
[TV/VIDEO] button, and then the receiver should be operated for more than 40 minutes.
(2) Perform rough adjustment of the central convergence with the P/C magnet according to the adjustment item.
(3) Receive built-in green signals, loosen set screws on the deflection yoke, remove rubber wedges, and shift the deflec-
tion yoke to toward front.
(4) Move alternately the two 2-pole magnets of the P/C magnets so that the green raster can come to the center of the
screen.
Figure 1.
(5) Receive built-in red and blue signals, check that there is no inclination of the single color raster toward one side, and if
each color tilts to a great extent, make adjustment with the 2-pole magnet so that the 3 colors will come to the center
evenly.
(6) Receive the green raster, shift the deflection yoke from
a foremost position (hitting against the picture tube) to a
backward position horizontally, stop the deflection yoke
at a position where it begins to become a green raster,
and perform accurate marking on the picture tube.
(7) Shift the deflection yoke further backward, and perform
accurate marking at a position where the green raster
begins to being luck.
(8) Fix the deflection yoke at a position 60% forward within
the range marked in items (6) and (7) above.
CONVERGENCE ADJUSTMENTS
* Adjust the convergence magnet to get vest convergence in the the order to (1) ~ (5).
■ CENTER CONVERGENCE:
(1) Receive the white crosshatch or dot pattern from the service signal generator.
(2) Use the 2 pieces of main 4-pole magnets of P/C magnets, change the open angle, and align the red and blue vertical
lines on the screen center.
(3) Freeze the open angle of the main 4-pole magnets, turn them simultaneously, and align the horizontal lines.
(4) Take the same steps for items (2) and (3) above and align red/blue with green on the screen center using two 6-pole
magnets.
A
P/C magnet installing position A
• 30"=26.5 mm
• 32"=30.5 mm or 32.5 mm
• 34"=37 mm
• 34"=39 mm
Green Belt
2-pole purity magnet
(27": Magnet is fixed with deflection yoke.)
Main 4-pole convergence magnet (30" : 32")
6-pole convergence magnet (34")
Sub-4-pole convergence magnet (32" : 34")
Sub-4-pole convergence magnet (to be installed on deflection yoke for 30", 32”)
6-pole convergence magnet (30" : 32")
Main 4-pole convergence magnet (34")
Fix the deflection yoke at a position 60% forward from a
point between (6) and (7)
Picture tube
Shift deflection yoke
(6)
(8)
(7) Perform marking of each point
on the tape of picture tube
CRT-D board
P/C Mag
100 60 0%

–7 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
(5) Adjust the sub-4-pole magnets only in case there is any deviation of Xv bow-shaped convergence. (To be usually set
at the initial position)
Align both sides with the sub-4-pole magnets and minimize the deviation of blue and red with the main 4-pole magnets.
blue
blue
red
red
Main 4-pole magnet
red/blue
red/blue
green
green
6-pole magnet
Xv bow-shaped deviation of convergence
blue
red
Sub-4-pole magnet
■CIRCUMFERENCE CONVERGENCE:
*Perform correction in the following manner.
A
D
E
F
A
B
C
B
C
S
N
D
E
F
A
B
C
D
E
F
N
S
VR3
YV YHC
GH
GH
VR2 VR1
blue
green
red
•Adjust coils and minimize deviation
(The 27”unit has coils underneath it)
blue
green
red
(Parts code:23 948 274) TC-S
Blue color or blue mark
*Insert the correction piece between the
picture tube and the deflection yoke.
(Insertion position of correction
piece)
Bonded surface
blue
green
red
(Parts code:23 948 464)
Transparent
Bonded surface
Adjust VR 1 and minimize the deviation of YH. *Only 27", 30" and 32".
Red
green
blue
Red
green
blue
Red
green
blue
Red
green
blue
Adjust VR 2 (YHC) and minimize the deviation of YH.
Red
green
blue
Red
green
blue
Red
green
blue
Red
green
blue
Adjust VR 3 (YV) and minimize the deviation of YV.
Red
blue
green
Red
blue
green
Red
blue
green
Red
blue
green
Red
blue
green
blue
red
green
Red
blue
green
blue
red
green
■ 30", 27", 32"
■ 34"
27" (Part No. 23 947 371)
32", 30" (Part No. 23 947 121)
34" (Part No. 23 993 080)
Perform correction by inserting the
correction piece into the clearance
of terminal board coils of the deflec-
tion yoke.
Note:
Perform insertion by turning the
metal side to the terminal board side
of the deflection yoke.

–8 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
SERVICE MODE
1. ENTERING TO SERVICE MODE
MUTE
S
(Service mode display)
3) While pressing the MUTE button,
press MENU button on TV set.
2) Press MUTE button
again to keep pressing.
1) Press MUTE button once
on Remote Control.
2. DISPLAYING THE ADJUSTMENT MENU
1) Press MENU button on TV.
Adjustment mode
Press
Press
Service mode
Item
Data
S
3. KEY FUNCTION IN THE SERVICE MODE
The following key entry during display of adjustment menu provides special functions.
A single horizontal line ON/OFF: TV (ANT)/VIDEO button (on TV)
Test signal selection : TV (ANT)/VIDEO button (on Remote)
Selection of the adjustment items : Channel s/t(on TV or Remote)
Change of the data value : Volume s/t(on TV or Remote)
Adjustment menu mode ON/OFF : MENU button (on TV)
Initialization of the memory (QA02, QA04) : RECALL+Channel (s) button on TV
Initialization of the self diagnostic data: RECALL+Channel (t) button on TV
“RCUT”selection : 1 button
“GCUT”selection : 2 button
“BCUT”selection : 3 button
“CNTX”selection : 4 button
“COLC”selection : 5 button
“TNTC”selection : 6 button
Test audio signal ON/OFF (1kHz) : 8 button
Self diagnostic display ON/OFF : 9 button

–9 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
4. SELECTING THE ADJUSTING ITEMS
1) Every pressing of CHANNEL sbutton in the service mode changes the adjustment items in the order of table-2.
(tbutton for reverse order)
Refer to table-2 for preset data of adjustment mode.
(See SETTING & ADJUSTING DATA on page 14)
5. ADJUSTING THE DATA
1) Pressing of VOLUME sor tbutton will cahnge the value of data in the range from 00H to FFH. The variable range
depends on the adjusting item.
6. EXIT FROM SERVICE MODE
1) Pressing POWER button to turn off the TV once.
■INITIALIZATION OF MEMORY DATA OF QA02 AND QA04
After replacing QA02 and QA04, the following initialization is required.
1. Enter the service mode, then select any register item.
2. Press and hold the RECALL button on the Remote, then press the CHANNEL sbutton on the TV. The initialization of QA02
and QA04 has been complated.
3. Check the picture carefully. If necessary, adjust any adjustment item above.
Perform “Programming Channel Memory”on the owner's manual.
CAUTION: Never attempt to initialize the data unless QA02, QA04 has been replaced.
7. TEST SIGNAL SELECTION
1) Every pressing of TV/VIDEO button on the Remote Control in the Service mode changes the built-in test patterns
on screen in the following order.
Normal picture
All white
Signals Picture
•All White
2) Press “8”button while any built-in test pattern to on the screen to output the 1 kHz sound. Press the button again to
cut off the sound.
Note: If the video cable is connected to the VIDEO1 INPUT jack, the built-in pattern signals are not displayed.

–10 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
8. SELF DIAGNOSTIC FUNCTION
1) Press “9”button on Remote Control during display of adjustment menu in the service mode.
The diagnosis will begin to check if interface among IC’s are executed properly.
2) During diagnosis, the following displays are shown.
SELF CHECK
NO. 23 * * * * * *
POWER : 000
BUS LINE : OK
BUS CONT : OK
BLOCK : UV V1 V2
or QV01 QV01S
SYNC





Part number of microprocessor (QA01)
Operation number of protection circuit (current limiter) . . . . “000”is normal.
BUS line check “OK”................... Normal
“SCL-GND”or “NG”.......... SCL-GND short circuit
“SDA-GND”or “NG”.......... SDA-GND short circuit
“SCL-SDA”or “NG”........... SCL-SDA short circuit
BUS line ACK (acknowledge) check
“OK”..................... Normal
Display of Location Number . . . . NG
(Display example)
“QA02 NG”, “H001 NG”, “Q501 NG”etc.
Note: The indication of failure place is only one place though failure places are plural. When
repair of a failure place finishes, the next failure place is indicated. (The order of priority of
indication is left side.)
Sync. signal check Green display ..... Normal
Cyan display ...... No check
Red display ........ NG
UV ........... TV mode
V1 ........... VIDEO 1 mode
V2 ........... VIDEO 2 mode
*The items marked with are not usable to display in the SELF DIAGNOSTIC FUNCTION for some model.

–11 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
ELECTRICAL ADJUSTMENTS
Vertical retrace line
1. Enter the service mode, then select any register item.
2. Press the TV/VIDEO button on the Remote until the black cross-bar pattern ap-
pears on the screen.
3. Adjust the FOCUS control (on T461) for well defined scanning lines on the picture
screen.
FOCUS VR ADJ
SUB-BRIGHTNESS
(BRTC)
1. Constrict the picture height until the verti-
cal retrace line appears adjusting the item
HIT (HEIGHT).
2. Adjust the CONTRAST control to the mini-
mum.
3. Call up the adjustment mode display, then
select the item BRTC.
4. Press the VOLUME sor tbutton so the
belt of vertical retrace line just disappear.
5. Adjust the CONTRAST control for the de-
sired contrast.
6. Perform the HEIGHT adjustment.
ITEM ADJUSTMENT PROCEDURE
SUB-COLOR
(SCOL)
SUB-TINT
(TNTC)
1. Receive color-bar signal from color-bar
generator.
2. Press the RESET button.
3. Connect oscilloscope to TP501 on SIG-
NAL board.
4. Adjust the CONTRAST control to the
minimum.
5. Call up the adjustment mode display,
then select the item TNTC.
6. Adjust the SUB-TINT by pressing the
VOLUME sor tbutton to obtain a blue
bar to magenta bar ratio of 3:2 as shown.
7. Press the RESET button.
8. Select the item SCOL.
9. Adjust the SUB-COLOR by pressing the VOLUME sor tbutton to achieve
1.6V0-p of a blue bar on scope.
10. Check the picture with off-air signal.
0
Blue
Magenta
2
3 (1.6V
0-P
)
WIDTH
(WID)
1. Call up the adjustment mode display, then select the item WID.
2. Press the VOLUME sor tbutton to get the picture so the left and right edges of
raster begins to lack.
3. Press the VOLUME sor tbutton to advance the data by 7 steps.
Note : Check the horizontal picture position is correct.

–12 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
ITEM ADJUSTMENT PROCEDURE
E-W PARABOLA (DPC)
(PARA)
1. Call up the adjustment mode display, then select the item PARA.
2. Press the TV/VIDEO button on Remote until the cross-hatch pattern appears on
the screen.
3. Press the VOLUME sor tbutton to make vertical lines straight as shown below.
HORIZONTAL POSITION
(HPOS)
VERTICAL POSITION
(VPOS)
1. Call up the adjustment mode display, then select the item HPOS or VPOS.
2. Press the TV/VIDEO button on Remote until the
white cross-bar or black cross-bar pattern appears
on the screen.
3. Adjust the HORIZONTAL and VERTICAL position
alternately by pressing the VOLUME sor tbut-
ton for proper picture position.
4. Check the picture with off-air signal.
HEIGHT
(HIT)
1. Call up the adjustment mode display, then select the item HIT.
2. Press the VOLUME sor tbutton to get the picture so the top of raster begins to
lack.
3. Press the VOLUME sbutton to advance the data by 9 steps.
Note : Check the vertical picture position is correct.
WHITE BALANCE
(RCUT)
(GCUT)
(BCUT)
(GDRV)
(BDRV)
1. Adjust the CONTRAST control to the center, and BRIGHTNESS control to the
maximum.
2. Call up the adjustment mode display, and press the TV/VIDEO button on Remote
until the white and black pattern appears on the screen.
3. Adjust the following items with the CHANNEL s/tand VOLUME s/tbuttons.
4. Press the TV/VIDEO button on TV to display a single horizontal line on the screen.
5. Turn the SCREEN control (FBT) fully counterclockwise and gradually rotate clock-
wise until the first horizontal line appears slightly on the screen.
6. Press the TV/VIDEO button to display the normal picture.
7. Adjust the remaining two “?CUT”items (CHANNEL s/t→TV/VIDEO →VOL-
UME s/tin order) to obtain the slightly lighted horizontal line in the same levels of
three (red, green, blue) colors. The line should be white if the adjustments are
proper.
Bright area
Adjust "GDRV" or "BDRV" to be white.
Dark area
Fine adjust "RCUT", "GCUT" or "BCUT" to be black.
RCUT Data : 40H
GCUT Data : 40H
BCUT
Item :
Item :
Item :
Item :
Item :
Data : 40H
GDRV Data : 40H
BDRV Data : 40H

–13 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
CIRCUIT CHECKS
Troubleshooting Guide for Fail Safe Circuit
HIGH VOLTAGE CHECK
CAUTION: There is no HIGH VOLTAGE ADJUSTMENT on
this chassis. Checking should be done following the steps
below.
1. Connect an accurate high voltage meter to the second an-
ode of the picture tube.
2. Turn on the receiver. Set the BRIGHTNESS and CON-
TRAST controls to minimum (zero beam current).
3. High voltage must be measured below (B) kV.
Refer to table-1 for high voltage (B).
(See SETTING & ADJUSTING DATA on page 14)
4. Vary the BRIGHTNESS control to both extremes to be sure
the high voltage does not exceed the limit under any con-
ditions.
FS CIRCUIT CHECK
The Fail Safe (FS) circuit check is indispensable for the final
check in servicing. Checking should be done following the
steps below.
1. Turn the receiver on and press the RESET button.
2. Temporarily short TP-(R) and TP-(X) with a jumper wire.
Raster and sound will disappear.
3. The receiver must remain in this state even after removing
the jumper wire. This is the evidence that the FS circuit is
functioning properly.
4. To obtain a picture again, temporarily turn the receiver off
and allow the FS circuit more than 5 seconds to reset.
Then turn the power switch on to produce a normal pic-
ture.
Check that the set returns to normal operation when pin 12
of Z801(or emitter of Q472) is grounded with jumper wire.
Check the voltage across
Capacitor C471 is
approximately (C) volts.
Refer to table –4 for
FBT detection voltage (C) .
Faulty power
circuit or hori-
zontal circuit.
Defective Fail Safe Circuit
(See SETTING & ADJUSTING
DATA on page14)
YES NO
NO
YES

–14 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
SETTING & ADJUSTING DATA
32" 36"
HIGH VOLTAGE AT ZERO BEAM: (A) 32.7 kV 32.7 kV
MAX HIGH VOLTAGE: (B) 34.1 kV 34.1 kV
Table-1
RCUT
GCUT
BCUT
GDRV
BDRV
BRTC
TNTC
SCOL
SCNT
HIT
LIN
VSC
VPS
VCP
WID
PARA
R CUTOFF
G CUTOFF
B CUTOFF
G DRIVE
B DRIVE
BRIGHT CENT
TINT CENT
SUB-COLOR
SUB-CONTRAST
HEIGHT
V-LINEARITY
V-S CORRECTION
V-SHIFT
V-COMPENSATION
PICTURE WIDTH
E-W PARABOLA
SERVICE MODE
ADJUSTING ITEMS AND DATAS IN THE SERVICE MODE:
CHAPTER 2 SPECIFIC INFORMATIONS
SAFETY INSTRUCTIONS
Item Name of adjustment Item Name of adjustment Preset
Table-2
DESIGN MODE
ADJUSTING ITEMS AND DATAS IN THE DESIGN MODE:
Item Name of adjustment PRESET Data Remarks
OPT1 OPTION 1 4AH ←88H
OPT2 OPTION 2 05H ←0DH
TVOP MAIN TUNER for STOP 00H ←←
SUB TUNIER for STOP
Non-Signal Audio Mute
(0: on 1: off)
Table-3
CIRCUIT CHECKS
Table-4
FBT DETECTION VOLTAGE (C) 18.9 V
40H
40H
40H
40H
40H
80H
44H
05H
10H
47H
13H
31H
04H
03H
21H
22H
Preset
11H
3EH
04H
07H
16H
03H
—
—
00H
55H
46H
12H
19H
04H
1DH
1DH
CNR
TRAP
HCP
VFC
HPOS
VPOS
BLKS
BLKE
GMPS
CPAR
PHUE
PCNT
PCOL
PYOF
PIOF
PQOF
E-W CORNER
TRAPEZIUM
H-CONMPENSATION
V-F CORRECTION
H-POSITION
V-PHASE
BLANKING START
BLANKING END
GMPS
CENTER PARA
PIP TINT
PIP CONTRAST
PIP COLOR
PIP Y OFFSET
PIP I OFFSET
PIP Q OFFSET
Data
←
←
←
←
←
←
←
←
←
39H
12H
33H
←
02H
20H
1BH
Data
15H
34H
01H
0AH
13H
02H
←
←
←
32H
←
←
←
09H
←
←

–15 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
LOCATION OF CONTROLS (Representative: 32AFX62)
TV Front
VIDEO-3
IN
S-VIDEO VIDEO L/MONO AUDIO INSIDE DOOR R
Video/Audio inputs
(Video 3) MENU
VOLUME ts
DEMO
TV/VIDEO
Power Indicator
POWER
TV Rear
CHANNEL ts
Remote Sensor
ANT-1 OUT ANT-2
ANT(75 )
S-VIDEO
VIDEO
L/
MONO
AUDIO
R
VIDEO 2VIDEO 1
Y
P
B
P R
COLOR
STREAM
INPUT
L
L
AUDIO
R
R
AUDIO CENTER
CHANNEL IN
DVD IN
VIDEO
VAR
AUDIO
L/
MONO
AUDIO
R
IN OUT
OUT
ON OFF

–16 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
Remote Control
Power turns the TV on or off
SLEEP sets the TV to turn at a specific time
LIGHT The initial press of the LIGHT button causes two actions:
Channel Numbers (0–9, 100) allow direct access to channels
MODE cycles through the 6 device modes
FAVOURITE allows access to Multi-Window function
INFO allows access to Multi-Window function
MENU allows access to programming
ENTER sets programming menu information
stT Sselects or adjusts programming menus
[FAV] TSselects your favourite channels
Volume st adjusts the volume level
EXIT exits programming menus
Channel st cycles through programmed channels
CH RTN returns to the last viewed channels
RECALL displays on-screen information
MUTE mutes the sound
INPUT selects video input source
PIP allows access to PIP functions
PIP turns the PIP on or off
PIP CH st selects the PIP channels
MULTI allows access to Multi-Windows function
STILL freezes the PIP
SOURCE selects the PIP source
LOCATE moves the PIP
SWAP switches the PIP and main pictures

– 17 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
PROGRAMMING CHANNEL MEMORY
The channel memory is the list of TV channel numbers your TV will stop on when you press the CHANNEL sor tbutton.
First, use the TV/CABLE and CH PROGRAM functions to preset all active channels in your area automatically.
If necessary, arrange the preset channels with the ADD/ERASE functions so that you can tune into only desired channels.
Note: If you utilize both ANT-1 and ANT-2 terminals for some model, perform programming channels for each input source.
TV/CABLE function
1Press MENU, then press Sor Tuntil the SET UP menu
appears.
2Press t(or s) until “TV/CABLE” is highlighted.
3Press :or ;to highlight either “TV” or “CABLE”, whichever
you use.
CH PROGRAM function
1Select “CH PROGRAM” following steps 1 and 2 above.
2Press :or ;to start channel programming.
The TV will automatically cycle through all the TV or CABLE
channels selected by the TV/CABLE function, and store
active channels in the channel memory.
3When channel programming is complete, you will see the
message to the right.
4Press CHANNEL sor tto make sure the channel
programming has been done properly.
ADD/ERASE function
After performing the CH PROGRAM function, you can add
or erase specific channels.
1Select the channel you want to erase using the CHANNEL
sor tbutton, or select the channel you want to add using
the Channel Number buttons.
2Press MENU, then press Sor Tuntil the SET UP menu
appears.
3Press t(or s) until “ADD/ERASE” is highlighted.
4Press Sor T:
To erase the channel
Press the button until “Erase” is highlighted.
To add the channel
Press the button until “Add” is highlighted.
5Repeat steps 1 to 4 for other channels.
You have now completed the channel programming.
Note: The CHANNEL t/s buttons on the TV function as
the t/s buttons while a menu is on the screen.
∗Please refer to owner's manual in detail.

– 18 –
SPECIFIC INFORMATIONS
Location Parts No. Description
No.
Location Parts No. Description
No.
CAPACITORS
C102 24665221 ELECTROLYTIC, 10V 220UF M 3A
C105 24474102 CERAMIC, 50V B 1000PF K
C106 24669479 ELECTROLYTIC, 50V 4.7UF M 3A
C107 24666221 ELECTROLYTIC, 16V 220UF M 3A
C112 24665221 ELECTROLYTIC, 10V 220UF M 3A
C115 24474102 CERAMIC, 50V B 1000PF K
C117 24666221 ELECTROLYTIC, 16V 220UF M 3A
C151 24436102 CERAMIC DISC, 50V SL 1000PF J
C201 24794100 ELECTROLYTIC, 16V 10UF M
C203 24503041 PLASTIC FILM , 63V 0.1UF J
C204 24797010 ELECTROLYTIC, 50V 1UF M
C205 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
C206 24206108 ELECTROLYTIC, 50V 0.1UF M 7L 3A
C207 24436390 CERAMIC DISC, 50V SL 39PFJ
C208 24436390 CERAMIC DISC, 50V SL 39PFJ
C209 24436390 CERAMIC DISC, 50V SL 39PFJ
C212 24794100 ELECTROLYTIC, 16V 10UF M
C213 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
C214 24794220 ELECTROLYTIC, 16V 22UF M
C220 24436680 CERAMIC DISC, 50V SL 68PF J
C260 24085967 ELECTROLYTIC, NONPOLAR, 16V 47UF M 11L
C303 24214471 CERAMIC DISC, 500V B 470PF K
C304 24693473 PLASTIC FILM, 100V 0.047UF J
C306 24795332 ELECTROLYTIC, 25V 3300UF M
C308 24669221 ELECTROLYTIC, 50V 220UF M 3A
C310 24073095 ELECTROLYTIC, 50V 2200UF M 3A
C312 24503037 MT PLA CAP 63V 0.047UF J
C313 24082057 PLASTIC FILM, 100V 220000PF J
C314 24793101 ELECTROLYTIC, 10V 100UF M
C315 24797229 ELECTROLYTIC, 50V 2.2UF M
C316 24212222 CERAMIC DISC, 50V B 2200PF K
C318 24073041 ELECTROLYTIC, 16V 470UF M 3A
C319 24591103 PLASTIC FILM, 50V 0.01UF J
C320 24669101 ELECTROLYTIC, 50V 100UF M 3A
C322 24617912 ELECTROLYTIC, 50V 2.2UF K 3A LI
C323 24539474 PLASTIC FILM, 50V 0.47UF J
C325 24591203 PLASTIC FILM, 50V 0.02UF J
C327 24073041 ELECTROLYTIC, 16V 470UF M 3A
C328 24591102 PLASTIC FILM, 50V 1000PF J
C352 24617915 ELECTROLYTIC, 50V 1UF K 3A LI
C361 24567474 PLASTIC FILM, 50V 0.47UF J
C366 24693154 PLASTIC FILM CQ921 M 100V 0.15MF J
C370 24794101 ELECTROLYTIC, 16V 100UF M
C371 24794100 ELECTROLYTIC, 16V 10UF M
C391 24666100 ELECTROLYTIC, 10V 10UF M 3A
C393 24666100 ELECTROLYTIC, 10V 10UF M 3A
C396 24082825 PLASTIC FILM, 1800VH 1800PF H
C399 24085981 ELEC. NONPOLAR CE04J 16V 10UF M 11L NP
C401 24503041 PLASTIC FILM , 63V 0.1UF J
C403 24591203 PLASTIC FILM, 50V 0.02UF J
C404 24797229 ELECTROLYTIC, 50V 2.2UF M
C413 24214821 CERAMIC DISC, 500V B 820PF K
C415 24591392 PLASTIC FILM, 50V 3900PF J
C416 24678010 ELECTROLYTIC, 200V 1UF M 3A
C417 24214391 CERAMIC DISC, 500V B 390PF K
C420 24666101 ELECTROLYTIC, 16V 100UF M 3A
C423 24503125 PLASTIC FILM, 400V 0.075UF J (32AFX62)
C423 24503124 PLASTIC FILM CQ92 T 400V 68000PF J
(36AFX62)
C430 24232103 CERAMIC DISC, 50V F 10000PF Z
C431 24794101 ELECTROLYTIC, 16V 100UF M
C440 24082592 PLASTIC FILM CF92 T 1800VH 1000PF H
(36AFX62)
C441 24082925 PLASTIC FILM CF92 T 315V 0.62UF J
(32AFX62)
C441 24082917 PLASTIC FILM, 315V 0.3UF J (36AFX62)
C442 24082924 PLASTIC FILM, 315V 0.56UF J (36AFX62)
*C443 24082958 PLASTIC FILM CF92 T 1500VH 7800PF H
(32AFX62)
*C443 24082961 PLASTIC FILM, 1500VH 8200PF H (36AFX62)
*C444 24082616 PLASTIC FILM CF92 T 1800VH 10000P
(32AFX62)
*C444 24082961 PLASTIC FILM, 1500VH 8200PF H (36AFX62)
C445 24828473 PLASTIC FILM, 200V 47000PF J
C446 24679330 ELECTROLYTIC, 250V 33UF M 3A
C447 24829393 PLASTIC FILM, 400V 39000PF J (32AFX62)
C447 24829473 PLASTIC FILM, 400V 47000PF J (36AFX62)
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY
PRECAUTION” AND “PRODUCT SAFETY NOTICE” ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols “ ” in the schematic diagram and the parts list designate components
which have special characteristics important for safety and should be replaced only with types identical to those in the
original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals.
Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not degrade the
safety of the receiver through improper servicing.
NOTICE:
• The part number must be used when ordering parts, in order to assist in processing, be sure to include the Model
number and Description.
• The PC board assembly with * mark is no longer available after the end of the production.
Model : 32AFX62/36AFX62
Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
CHASSIS AND CABINET REPLACEMENT PARTS LIST

–19 –
SPECIFIC INFORMATIONS
Location Parts No. Description
No.
Location Parts No. Description
No.
C448 24640962 ELECTROLYTIC, 200V 33UF M
C463 24212152 CERAMIC DISC, 50V B 1500PF K
C464 24640872 ELECTROLYTIC, 100V 10UF M 3A
C466 24503041 PLASTIC FILM , 63V 0.1UF J
*C467 24503156 PLASTIC FILM CF92 T 630V 47000PF H
C471 24206479 ELECTROLYTIC, 50V 4.7UF M 7L 3A
C472 24539474 PLASTIC FILM, 50V 0.47UF J
C474 24794100 ELECTROLYTIC, 16V 10UF M
C475 24095887 PLASTIC FILM, 630V 11000PF H
C480 24747220 ELECTROLYTIC, 50V 22UF M 7L 3A
C481 24567474 PLASTIC FILM, 50V 0.47UF J (32AFX62)
C481 24503041 PLASTIC FILM , 63V 0.1UF J (36AFX62)
C482 24539474 PLASTIC FILM, 50V 0.47UF J
C483 24503037 MT PLA CAP 63V 0.047UF J (32AFX62)
*C491 24082920 PLASTIC FILM CF92 T 315V 0.39UF J
(32AFX62)
*C491 24082925 PLASTIC FILM CF92 T 315V 0.62UF J
(36AFX62)
C492 24214121 CERAMIC DISC, 500V B 120PF K
C498 24436270 CERAMIC DISC, 50V SL 27PFJ
C501 24232103 CERAMIC DISC, 50V F 10000PF Z
C502 24232103 CERAMIC DISC, 50V F 10000PF Z
C503 24763101 ELECTROLYTIC, 16V 100UF M
C504 24591222 PLASTIC FILM, 50V 2200PF J
C505 24353120 CERAMIC DISC, 50V CH 12PF J
C508 24794100 ELECTROLYTIC, 16V 10UF M
C509 24763101 ELECTROLYTIC, 16V 100UF M
C510 24763101 ELECTROLYTIC, 16V 100UF M
C511 24232103 CERAMIC DISC, 50V F 10000PF Z
C512 24206228 ELECTROLYTIC, 50V 0.22UF M 7L 3A
C513 24232103 CERAMIC DISC, 50V F 10000PF Z
C514 24503041 PLASTIC FILM , 63V 0.1UF J
C515 24503041 PLASTIC FILM , 63V 0.1UF J
C517 24472010 CERAMIC, 50V CH 1PF M
C601 24232103 CERAMIC DISC, 50V F 10000PF Z
C602 24232103 CERAMIC DISC, 50V F 10000PF Z
C612 24793221 ELECTROLYTIC, 10V 220UF M
C621 24206479 ELECTROLYTIC, 50V 4.7UF M 7L 3A
C622 24206108 ELECTROLYTIC, 50V 0.1UF M 7L 3A
C623 24591472 PLASTIC FILM, 50V 4700PF J
C624 24206479 ELECTROLYTIC, 50V 4.7UF M 7L 3A
C625 24206479 ELECTROLYTIC, 50V 4.7UF M 7L 3A
C626 24206479 ELECTROLYTIC, 50V 4.7UF M 7L 3A
C627 24206479 ELECTROLYTIC, 50V 4.7UF M 7L 3A
C628 24206100 ELECTROLYTIC, 50V 10UF M 7L 3A
C629 24206100 ELECTROLYTIC, 50V 10UF M 7L 3A
C630 24206108 ELECTROLYTIC, 50V 0.1UF M 7L 3A
C631 24591472 PLASTIC FILM, 50V 4700PF J
C632 24203470 ELECTROLYTIC, 16V 47UF M 7L 3A
C633 24567224 PLASTIC FILM, 50V 0.22UF J
C634 24206108 ELECTROLYTIC, 50V 0.1UF M 7L 3A
C635 24203220 ELECTROLYTIC, 16V 22UF M 7L 3A
C636 24206479 ELECTROLYTIC, 50V 4.7UF M 7L 3A
C637 24206100 ELECTROLYTIC, 50V 10UF M 7L 3A
C638 24794101 ELECTROLYTIC, 16V 100UF M
C639 24232103 CERAMIC DISC, 50V F 10000PF Z
C640 24591273 PLASTIC FILM, 50V 0.027UF J
C641 24591822 PLASTIC FILM, 50V 8200PF J
C642 24206100 ELECTROLYTIC, 50V 10UF M 7L 3A
C643 24206479 ELECTROLYTIC, 50V 4.7UF M 7L 3A
C644 24206339 ELECTROLYTIC, 50V 3.3UF M 7L 3A
C645 24591333 PLASTIC FILM, 50V 0.033UF J
C646 24591153 PLASTIC FILM, 50V 0.015MF J
C647 24591683 PLASTIC FILM, 50V 0.068UF J
C648 24591563 PLASTIC FILM, 50V 0.056MF J
C649 24591273 PLASTIC FILM, 50V 0.027UF J
C650 24591822 PLASTIC FILM, 50V 8200PF J
C651 24232103 CERAMIC DISC, 50V F 10000PF Z
C652 24232103 CERAMIC DISC, 50V F 10000PF Z
C653 24232103 CERAMIC DISC, 50V F 10000PF Z
C654 24763101 ELECTROLYTIC, 16V 100UF M
C660 24669229 ELECTROLYTIC, 50V 2.2UF M 3A
C661 24794100 ELECTROLYTIC, 16V 10UF M
C664 24797220 ELECTROLYTIC, 50V 22UF M
C671 24669010 ELECTROLYTIC, 50V 1.0UF M 3A
C673 24669479 ELECTROLYTIC, 50V 4.7UF M 3A
C674 24797010 ELECTROLYTIC, 50V 1UF M
C675 24667470 ELECTROLYTIC, 25V 47UF M 3A
C676 24797479 ELECTROLYTIC, 50V 4.7UF M
C677 24591102 PLASTIC FILM, 50V 1000PF J
C678 24591102 PLASTIC FILM, 50V 1000PF J
C679 24591473 PLASTIC FILM, 50V 0.047UF J
C680 24668102 ELECTROLYTIC, 35V 1000UF M 3A
C681 24668471 ELECTROLYTIC, 35V 470UF M 3A
C682 24668471 ELECTROLYTIC, 35V 470UF M 3A
C683 24668102 ELECTROLYTIC, 35V 1000UF M 3A
C684 24503041 PLASTIC FILM , 63V 0.1UF J
C685 24503041 PLASTIC FILM , 63V 0.1UF J
C686 24503041 PLASTIC FILM , 63V 0.1UF J
C704 24232103 CERAMIC DISC, 50V F 10000PF Z
C705 24232103 CERAMIC DISC, 50V F 10000PF Z
C707 24794101 ELECTROLYTIC, 16V 100UF M
C713 24709100 ELECTROLYTIC, 200V 10UF M
C714 24436101 CERAMIC DISC, 50V SL 100PF J
C715 24214472 CERAMIC DISC, 500C B 4700PF K
C716 24436101 CERAMIC DISC, 50V SL 100PF J
C717 24214472 CERAMIC DISC, 500C B 4700PF K
C718 24794470 ELECTORLYTIC, 16V 47UF M
C719 24435560 CERAMIC DISC, 500V SL 56PF J
C720 24709100 ELECTROLYTIC, 200V 10UF M
C721 24794470 ELECTORLYTIC, 16V 47UF M
C726 24212102 CERAMIC DISC, 50V B 1000PF K
*C801 24503002 PLASTIC FILM, AC275V 0.22UF M
*C802 24503001 PLASTIC FILM, AC275V 0.1UF M
C805 24092623 CERAMIC DISC, 250V F 0.01UF Z
C806 24092623 CERAMIC DISC, 250V F 0.01UF Z
C810 24086062 ELECTROLYTIC 692Q 200V 1000UF M 3F
*C811 24092585 CERAMIC DISC CK45E AC250V 4700PF M
*C812 24092585 CERAMIC DISC CK45E AC250V 4700PF M
*C813 24092586 CERAMIC DISC CK45F AC250V 10000PF M
*C814 24092586 CERAMIC DISC CK45F AC250V 10000PF M
C831 24794470 ELECTORLYTIC, 16V 47UF M
C840 24667102 ELECTROLYTIC, 25V 1000UF M 3A
C842 24792101 ELECTROLYTIC, 6.3V 100UF M
C843 24666100 ELECTROLYTIC, 10V 10UF M 3A
C850 24794470 ELECTORLYTIC, 16V 47UF M
C860 24214103 CERAMIC DISC, 500V B 10000PF K
C861 24212101 CERAMIC DISC, 50V B 100PF K
C863 24503041 PLASTIC FILM , 63V 0.1UF J
C864 24092345 CERAMIC DISC, 2KV 1000PF K
C865 24092345 CERAMIC DISC, 2KV 1000PF K
C866 24766478 ELECTROLYTIC, 50V 0.47UF M
C867 24591103 PLASTIC FILM, 50V 0.01UF J
C868 24667470 ELECTROLYTIC, 25V 47UF M 3A
C869 24678229 ELECTROLYTIC, 200V 2.2UF M 3A
C870 24082869 PLASTIC FILM CF92 T 400V R18UF J
C871 24092345 CERAMIC DISC, 2KV 1000PF K
C873 24567224 PLASTIC FILM, 50V 0.22UF J
C874 24435221 CERAMIC DISC, 500V SL 220PF J
C875 24435221 CERAMIC DISC, 500V SL 220PF J

–20 –
SPECIFIC INFORMATIONS
Location Parts No. Description
No.
Location Parts No. Description
No.
C876 24503041 PLASTIC FILM , 63V 0.1UF J
C877 24092345 CERAMIC DISC, 2KV 1000PF K
C884 24086049 ELECTROLYTIC, 160V 330UF M 3D
C885 24214471 CERAMIC DISC, 500V B 470PF K
C886 24214471 CERAMIC DISC, 500V B 470PF K
C887 24667102 ELECTROLYTIC, 25V 1000UF M 3A
C889 24668332 ELECTROLYTIC, 35V 3300UF M 3A
C891 24082229 PLASTIC FILM, 250V 0.1UF D
C892 24794100 ELECTROLYTIC, 16V 10UF M
C893 24092333 CERAMIC DISC, 2KV 100PF K
C894 24092333 CERAMIC DISC, 2KV 100PF K
C896 24214471 CERAMIC DISC, 500V B 470PF K
C897 24668332 ELECTROLYTIC, 35V 3300UF M 3A
C898 24503045 PLASTIC FILM, 63V 0.22UF J
C899 24214471 CERAMIC DISC, 500V B 470PF K
C902 24092353 CERAMIC DISC, 2KV 4700PF K
C904 24436561 CERAMIC DISC, 50V SL 560PF J
C905 24436561 CERAMIC DISC, 50V SL 560PF J
C907 24436561 CERAMIC DISC, 50V SL 560PF J
C909 24679220 ELECTROLYTIC, 250V 22UF M 3A
C910 24797478 ELECTROLYTIC, 50V 0.47UF M
C911 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A
C912 24794471 ELECTROLYTIC, 16V 470UF M
C913 24794100 ELECTROLYTIC, 16V 10UF M
C914 24212103 CERAMIC DISC, 50V B 10000PF K
C920 24232103 CERAMIC DISC, 50V F 10000PF Z
C921 24232103 CERAMIC DISC, 50V F 10000PF Z
C930 24214102 CERAMIC DISC, 500V B 1000PF K
C970 24794470 ELECTORLYTIC, 16V 47UF M
C971 24794470 ELECTORLYTIC, 16V 47UF M
C972 24794470 ELECTORLYTIC, 16V 47UF M
C3260 24539474 PLASTIC FILM, 50V 0.47UF J
C3440 24082395 PLASTIC FILM, 1250VH 1100PF H
CA10 24212101 CERAMIC DISC, 50V B 100PF K
CA13 24212221 CERAMIC DISC, 50V B 220PF K
CA19 24666100 ELECTROLYTIC, 10V 10UF M 3A
CA20 24474181 CERAMIC CK141B 50V 180PF K
CA21 24085957 ELEC. NONPOLAR CE04J 50V 0.47UF M NP
CA22 24232103 CERAMIC DISC, 50V F 10000PF Z
CA23 24436181 CERAMIC DISC, 50V SL 180PF J
CA24 24085957 ELEC. NONPOLAR CE04J 50V 0.47UF M NP
CA25 24666100 ELECTROLYTIC, 10V 10UF M 3A
CA26 24085958 ELEC. NONPOLAR CE04J 50V 1.0UF M NP
CA27 24085958 ELEC. NONPOLAR CE04J 50V 1.0UF M NP
CA29 24474221 CERAMIC, 50V B 220PF K
CA30 24474101 CERAMIC, 50V B 100PF K
CA34 24474101 CERAMIC, 50V B 100PF K
CA45 24666100 ELECTROLYTIC, 10V 10UF M 3A
CA49 24666100 ELECTROLYTIC, 10V 10UF M 3A
CA50 24232103 CERAMIC DISC, 50V F 10000PF Z
CA52 24591272 PLASTIC FILM, 50V 2700PF J
CA54 24474101 CERAMIC, 50V B 100PF K
CA56 24503041 PLASTIC FILM , 63V 0.1UF J
CA59 24474101 CERAMIC, 50V B 100PF K
CA60 24474101 CERAMIC, 50V B 100PF K
CA61 24666220 ELECTROLYTIC, 16V 22UF M 3A
CA64 24232103 CERAMIC DISC, 50V F 10000PF Z
CA68 24666100 ELECTROLYTIC, 10V 10UF M 3A
CA69 24232103 CERAMIC DISC, 50V F 10000PF Z
CA71 24474101 CERAMIC, 50V B 100PF K
CA72 24085970 ELECTROLYTIC, NONPOLAR, 16V 10UF M 7L
CA73 24666100 ELECTROLYTIC, 10V 10UF M 3A
CA541 24539474 PLASTIC FILM, 50V 0.47UF J
CB01 24794470 ELECTORLYTIC, 16V 47UF M
CB13 24085970 ELECTROLYTIC, NONPOLAR, 16V 10UF M 7L
CB14 24474101 CERAMIC, 50V B 100PF K
CB15 24794100 ELECTROLYTIC, 16V 10UF M
CB40 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
CB41 24591102 PLASTIC FILM, 50V 1000PF J
CB42 24232103 CERAMIC DISC, 50V F 10000PF Z
CB43 24591122 PLASTIC FILM, 50V 1200PF J
CB44 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A
CB45 24436561 CERAMIC DISC, 50V SL 560PF J
CB77 24212271 CERAMIC DISC, 50V B 270PF K
CB90 24591103 PLASTIC FILM, 50V 0.01UF J
CB91 24794101 ELECTROLYTIC, 16V 100UF M
CD02 24591562 PLASTIC FILM, 50V 5600PF J
CD03 24591393 PLASTIC FILM, 50V 0.039MF J
CD04 24591393 PLASTIC FILM, 50V 0.039MF J
CD08 24794100 ELECTROLYTIC, 16V 10UF M
CD10 24436101 CERAMIC DISC, 50V SL 100PF J
CD12 24436101 CERAMIC DISC, 50V SL 100PF J
CD13 24797479 ELECTROLYTIC, 50V 4.7UF M
CD14 24797229 ELECTROLYTIC, 50V 2.2UF M
CD15 24794470 ELECTORLYTIC, 16V 47UF M
CD16 24797229 ELECTROLYTIC, 50V 2.2UF M
CR12 24206108 ELECTROLYTIC, 50V 0.1UF M 7L 3A
CR13 24206108 ELECTROLYTIC, 50V 0.1UF M 7L 3A
CR14 24206108 ELECTROLYTIC, 50V 0.1UF M 7L 3A
CR15 24503041 PLASTIC FILM , 63V 0.1UF J
CR16 24503041 PLASTIC FILM , 63V 0.1UF J
CR17 24503041 PLASTIC FILM , 63V 0.1UF J
CS03 24436221 CERAMIC DISC, 50V SL 220PF J
CS04 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
CS07 24436221 CERAMIC DISC, 50V SL 220PF J
CS08 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
CS09 24436331 CERAMIC DISC, 50V SL 330PF J
CS10 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
CS11 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
CS12 24436221 CERAMIC DISC, 50V SL 220PF J
CS13 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
CS14 24436221 CERAMIC DISC, 50V SL 220PF J
CS15 24436331 CERAMIC DISC, 50V SL 330PF J
CS16 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
CS21 24436101 CERAMIC DISC, 50V SL 100PF J
CS22 24436101 CERAMIC DISC, 50V SL 100PF J
CS24 24436331 CERAMIC DISC, 50V SL 330PF J
CS25 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
CS28 24436331 CERAMIC DISC, 50V SL 330PF J
CS29 24436331 CERAMIC DISC, 50V SL 330PF J
CS32 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A
CS33 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A
CS34 24436331 CERAMIC DISC, 50V SL 330PF J
CS35 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
CS36 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
CS38 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
CS41 24436331 CERAMIC DISC, 50V SL 330PF J
CS42 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
CS43 24436331 CERAMIC DISC, 50V SL 330PF J
CS44 24206229 ELECTROLYTIC, 50V 2.2UF M 7L 3A
CS115 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
CS116 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
CS118 24794470 ELECTORLYTIC, 16V 47UF M
CS119 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
CS120 24232103 CERAMIC DISC, 50V F 10000PF Z
CS121 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
CV01 24085981 ELEC. NONPOLAR CE04J 16V 10UF M 11L NP
CV02 24232103 CERAMIC DISC, 50V F 10000PF Z
CV03 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A
CV04 24203100 ELECTORLYTIC, 16V 10UF M 7L 3A
