Toshiba 32ZP48P User manual

SERVICE MANUAL
Colour Television
32ZP48P
36ZP48P
ZP38 Chassis
FILE NO. 030-200408
Jul. 2004 (YC/X)

– 2 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
TABLE OF CONTENTS
CHAPTER 1 GENERAL ADJUSTMENTS
SAFETY INSTRUCTIONS ........................................................................................................................................ 3
SET-UP ADJUSTMENT ............................................................................................................................................ 4
SERVICE MODE ...................................................................................................................................................... 6
DESIGN MODE ........................................................................................................................................................ 9
ELECTRICAL ADJUSTMENTS .............................................................................................................................. 10
CIRCUIT CHECK.................................................................................................................................................... 15
CHAPTER 2 SPECIFIC INFORMATIONS
SETTING & ADJUSTING DATA.............................................................................................................................. 16
LOCATION OF CONTROLS ................................................................................................................................... 17
CHASSIS AND CABINET REPLACEMENT PARTS LIST ......................................................................................19
PC BOARDS BOTTOM VIEW................................................................................................................................. 32
TERMINAL VIEW OF TRANSISTORS ................................................................................................................... 43
CIRCUIT BLOCK DIAGRAM .................................................................................................................................. 45
SPECIFICATIONS .............................................................................................................................................. END
APPENDIX:
CIRCUIT DIAGRAM

–3 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
CHAPTER 1 GENERAL ADJUSTMENTS
SAFETY INSTRUCTIONS
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION”AND “PRODUCT SAFETY NOTICE”INSTRUCTIONS BELOW.
X-RAY RADIATION PRECAUTION
1. Excessive high voltage can produce potentially hazard-
ous X-RAY RADIATION. To avoid such hazards, the high
voltage must not be above the specified limit. The nominal
value of the high voltage of this receiver is (A) kV at zero
beam current (minimum brightness) under a (C) V AC power
source.The high voltage must not, under any circumstances,
exceed (B) kV.
Refer to table-1 for high voltage (A), (B) & AC voltage (C).
(See SETTING & ADJUSTING DATA on page 16)
Each time a receiver requires servicing, the high voltage
should be checked following the HIGH VOLTAGE CHECK
procedure in this manual. It is recommended that the read-
ing of the high voltage be recorded as a part of the service
record. It is important to use an accurate and reliable high
voltage meter.
2. The only source of X-RAY RADIATION in this TV receiver
is the picture tube. For continued X-RAY RADIATION pro-
tection, the replacement tube must be exactly the same
type tube as specified in the parts list.
3. Some part in this receiver have special safety-related char-
acteristics for X-RAY RADIATION protection. For contin-
ued safety, parts replacement should be undertaken only
after referring to the PRODUCT SAFETY NOTICE below.
SAFETY PRECAUTION
WARNING : Service should not be attempted by anyone unfamiliar with the necessary precautions on this receiver. The following
are the necessary precautions to be observed before servicing this chassis.
1. An isolation transformer should be connected in the power line between the receiver and the AC line before any service is
performed on the receiver.
2. Always discharge the picture tube anode to the CRT conductive coating before handling the picture tube. The picture tube
is highly evacuated and if broken, glass fragments will be violently expelled. Use shatter proof goggles and keep picture tube
away from the unprotected body while handling.
3. When replacing a chassis in the cabinet, always be certain that all the protective devices are put back in place, such as; non-
metallic control knobs, insulating covers, shields, isolation resistor-capacitor network etc.
PRODUCT SAFETY NOTICE
Many electrical and mechanical parts in this chassis have special safety-related characteristics. These characteristics are
often passed unnoticed by a visual inspection and the protection afforded by them cannot necessarily be obtained by using
replacement components rated for higher voltage, wattage, etc. Replacement parts which have these special safety char-
acteristics are identified in this manual and its supplements; electrical components having such features are identified by
the international hazard symbols on the schematic diagram and the parts list.
Before replacing any of these components, read the parts list in this manual carefully. The use of substitute replacement
parts which do not have the same safety characteristics as specified in the parts list may create shock, fire, X-ray
radiation or other hazards.

–4 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
WARNING: BEFORE SERVICING THIS CHASSIS, READ THE “X-RAY RADIATION PRECAUTION”, “SAFETY PRECAU-
TION”AND “PRODUCT SAFETY NOTICE”ON PAGE 3 OF SERVICE MANUAL.
SET-UP ADJUSTMENT
■The following adjustments should be made when a complete realignment is required or a new picture tube is installed.
Perform the adjustments in order as follows :
1. Color Purity
2. Convergence
3. White Balance
Note: The PURITY/CONVERGENCE MAGNET assembly and rubber wedges need mechanical positioning.
Refer to figure 1.
COLOR PURITY ADUSTMENT
(1)Let the screen face in the installing direction or toward the east (when it is to be moved), bring up the service mode
screen after demagnetizing (front, left, right, and top) with the degaussing coil, receive white signals by pressing the
[TV/VIDEO] button, and then the receiver should be operated for more than 40 minutes.
(2)Perform rough adjustment of the central convergence with the P/C magnet according to the adjustment item.
(3)Receive built-in green signals, loosen set screws on the deflection yoke, remove rubber wedges, and shift the deflection
yoke to toward front.
(4)Move alternately the two 2-pole magnets of the P/C magnets so that the green raster can come to the center of the
screen.
Figure 1.
(5)Receive built-in red and blue signals, check that there is no inclination of the single color raster toward one side, and if
each color tilts to a great extent, make adjustment with the 2-pole magnet so that the 3 colors will come to the center
evenly.
(6)Receive the green raster, shift the deflection yoke from a
foremost position (hitting against the picture tube) to a
backward position horizontally, stop the deflection yoke
at a position where it begins to become a green raster,
and perform accurate marking on the picture tube.
(7)Shift the deflection yoke further backward, and perform
accurate marking at a position where the green raster
begins to being luck.
(8)Fix the deflection yoke at a position 60% forward within
the range marked in items (6) and (7) above.
CONVERGENCE ADJUSTMENTS
* Adjust the convergence magnet to get vest convergence in the the order to (1) ~ (5).
■ CENTER CONVERGENCE:
(1)Receive the white crosshatch or dot pattern from the service signal generator.
(2)Use the 2 pieces of main 4-pole magnets of P/C magnets, change the open angle, and align the red and blue vertical
lines on the screen center.
(3)Freeze the open angle of the main 4-pole magnets, turn them simultaneously, and align the horizontal lines.
(4)Take the same steps for items (2) and (3) above and align red/blue with green on the screen center using two 6-pole
magnets.
A
P/C magnet installing position A
• 30"=26.5 mm
• 32"=30.5 mm or 32.5 mm
• 34"=37 mm
• 34"=39 mm
Green Belt
2-pole purity magnet
(27": Magnet is fixed with deflection yoke.)
Main 4-pole convergence magnet (30" : 32")
6-pole convergence magnet (34")
Sub-4-pole convergence magnet (32" : 34")
Sub-4-pole convergence magnet (to be installed on deflection yoke for 30", 32”)
6-pole convergence magnet (30" : 32")
Main 4-pole convergence magnet (34")
Fix the deflection yoke at a position 60% forward from a
point between (6) and (7)
Picture tube
Shift deflection yoke
(6)
(8)
(7) Perform marking of each point
on the tape of picture tube
CRT-D board
P/C Mag
100 60 0%

–5 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
(5)Adjust the sub-4-pole magnets only in case there is any deviation of Xv bow-shaped convergence. (To be usually set at
the initial position)
Align both sides with the sub-4-pole magnets and minimize the deviation of blue and red with the main 4-pole magnets.
blue
blue
red
red
Main 4-pole magnet
red/blue
red/blue
green
green
6-pole magnet
Xv bow-shaped deviation of convergence
blue
red
Sub-4-pole magnet
■CIRCUMFERENCE CONVERGENCE:
*Perform correction in the following manner.
A
D
E
F
A
B
C
B
C
S
N
D
E
F
A
B
C
D
E
F
N
S
VR3
YV YHC
GH
GH
VR2 VR1
blue
green
red
•Adjust coils and minimize deviation
(The 27”unit has coils underneath it)
blue
green
red
(Parts code:23 948 274) TC-S
Blue color or blue mark
*Insert the correction piece between the
picture tube and the deflection yoke.
(Insertion position of correction
piece)
Bonded surface
blue
green
red
(Parts code:23 948 464)
Bonded surface
Adjust VR 1 and minimize the deviation of YH. *Only 27", 30" and 32".
Red
green
blue
Red
green
blue
Red
green
blue
Red
green
blue
Adjust VR 2 (YHC) and minimize the deviation of YH.
Red
green
blue
Red
green
blue
Red
green
blue
Red
green
blue
Adjust VR 3 (YV) and minimize the deviation of YV.
Red
blue
green
Red
blue
green
Red
blue
green
Red
blue
green
Red
blue
green
blue
red
green
Red
blue
green
blue
red
green
■ 30", 27", 32"
■ 34"
27" (Part No. 23 947 371)
32", 30" (Part No. 23 947 121)
34" (Part No. 23 993 080)
Perform correction by inserting the
correction piece into the clear-
ance of terminal board coils of
the deflection yoke.
Note:
Perform insertion by turning the
metal side to the terminal board
side of the deflection yoke.

–6 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
SERVICE MODE
1. ENTERING TO SERVICE MODE
S
(Service mode display)
Item
Data
Mute or
3) While pressing the obutton,
press MENU button on TV set.
2) Press obutton again to
keep pressing.
2. DISPLAYING THE ADJUSTMENT MENU
1) Press MENU button on TV.
3. KEY FUNCTION IN THE SERVICE MODE
The following key entry during display of adjustment menu provides special functions.
A single horizontal line ON/OFF: INFO button (on Remote) or abutton (on TV)
Test signal selection : abutton (on Remote)
Selection of the adjustment items : Channel s/t(on TV or Remote)
Change of the data value : Volume ;+/–(on TV or Remote)
Adjustment menu mode ON/OFF : MENU button (on TV)
Initialization of the memory (QA02) : CALL + Channel button on TV (s)
Reset the count of operating protect
circuit to “00”: CALL + Channel button on TV (t)
“RCUT”selection : 1 button
“GCUT”selection : 2 button
“BCUT”selection : 3 button
“CNTX”(or “SCNT”) selection : 4 button
“COLC”selection : 5 button
“TNTC”selection : 6 button
Self diagnostic display ON/OFF : 9 button
1) Press obutton once on
Remote Control.
Adjustment mode
Item
Data
Service mode
S
Press
Press
ITEM
DATA
Color thickness correction
note: Displayed differently as shown below, de-
pending on the setting of the receiving color
system.
COLP (PAL)
COLC (NTSC)
COLS (SECAM)
CAUTION : Never try to perform initialization unless you have changed the memory IC.

–7 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
4. SELECTING THE ADJUSTING ITEMS
1) Every pressing of CHANNEL sbutton in the service mode changes the adjustment items in the order of table-2.
(tbutton for reverse order)
Refer to table-2 for preset data of adjustment mode.
(See SETTING & ADJUSTING DATA on page 16)
5. ADJUSTING THE DATA
1) Pressing of VOLUME ;+/–button will change the value of data in the range from 00H to FFH. The variable
range depends on the adjusting item.
6. EXIT FROM SERVICE MODE
1) Pressing POWER button to turn off the TV once.
■INITIALIZATION OF MEMORY DATA OF QA02
After replacing QA02, the following initialization is required.
1. Enter the service mode, then select any register item.
2. Press and hold the CALL button on the Remote, then press the CHANNEL sbutton on the TV.The initialization of QA02 has
been complated.
3. Check the picture carefully. If necessary, adjust any adjustment item above.
Perform “Auto search Memory”on the owner’s manual.
CAUTION: Never attempt to initialize the data unless QA02 has been replaced.

–8 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
8. SELF DIAGNOSTIC FUNCTION
1) Press “9”button on Remote Control during display of adjustment menu in the service mode.
The diagnosis will begin to check if interface among IC’s are executed properly.
2) During diagnosis, the following displays are shown.
23******
TIME
POWER : 00
BUS CONT : OK
BLOCK :
UV V1 V2 V3 V4
V5
<SELF CHECK>
Part number of microcomputer (QA01)
Operation number of protecting circuit ----“00”is nor-
mal.
When indication is other than “00”, overcurrent apts to
flow, and circuit parts may possibly be damaged.
BUS CONT ----“OK”is normal.
When indication shows “Q uuu NG”, the device with
the number may possibly be damaged.
BLOCK
UV : TV reception mode
V1 : VIDEO 1 input mode (a1)
V2 : VIDEO 2 input mode (a2)
V3 : VIDEO 3 input mode (a3)
V4 : VIDEO 4 input mode (a4)
V5 : VIDEO 5 input mode (a5)
Indicated color of mode now selected : Green and Red
Indicated color of other modes : White
Green : Normal
Red : The microcomputer operates to provide judgement
of no video signal. The red color is still indicated
though the signal is input, failure may exist in input
signal line including QV01.
QV01 : In case of indication green ---Normal
In case of indication red with input signal----
Failure may exist in output line including QV01.




* The items marked with are not usable to display in the SELF DIAGNOSTIC FUCTION for some model.

–9 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
DESIGN MODE
1. ENTERING TO DESIGN MODE
ITEM
DATA
S D Press
(Design mode) (Adjustment mode)
Press
3) Press MENU button on TV.
2) While pressing oor CALL button on
Remote and press MENU button on TV.
1) Select the Service mode.
2. SELECTING THE ADJUSTING ITEMS
Every pressing of CHANNEL tbutton in the design mode changes the adjustment items in the order of table-3.
(sbutton for reverse order)
Refer to table-3 for data of design mode.
(See SETTING & ADJUSTING DATA on page 16)
3. ADJUSTING THE DATA
Pressing of VOLUME sor tbutton will change the value of data.
When QA02 is initialized, items “OPT0”and “OPT1”of DESIGN MODE are set to the data of the representative model of this
chassis family.
Therefore, because ON-SCREEN specification remains in the state of the representative of model. This model is required to
reset the data of items “OPT0”and “OPT1”.

–10 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
ELECTRICAL ADJUSTMENTS
1. Enter the service mode, then select any register item.
2. Press the TV/VIDEO button on the Remote until the black cross-bar pattern ap-
pears on the screen.
3. Adjust the FOCUS control (on T461) for well defined scanning lines on the picture
screen.
FOCUS VR ADJ
SUB-BRIGHTNESS
(BRTC)
Note: Constrict the picture height
until the vertical retrace line
appears adjusting the item
HIT (HEIGHT).
1. Set CONTRAST to minimum, and
BRIGHTNESS to center by adjusting user
controls.
2. Set the TV in service mode to get Black
cross-bar of inside pattern.
3. Select BRTC (brightness correction), and
adjust the ;–/+ button to reduce the
value so that white portion of inside pat-
tern slightly light.
4. Adjust ;–/+ button to increase the data
value of BRTC, and set it just before the
difference between the belt of vertical re-
trace and the border of black portion of
inside pattern is visible.
After that, return vertical height and con-
trast.
ITEM ADJUSTMENT PROCEDURE
Belt of vertical retrace
HORIZONTAL POSITION
ADJUSTMENT (HPOS)
VERTICAL POSITION
ADJUSTMENT (VPOS)
1. Set the TV in service mode, and get
black cross-bar signal with VIDEO
button on remote hand unit.
2. Select either HPOS (Horizontal pic-
ture phase) or VPOS (Vertical picture
phase) with CHANNEL s, tbuttons,
and adjust horizontal or vertical pic-
ture position in the center of screen
with VOLUME ;–/+ buttons.
VERTICAL AMPLITUDE
ADJUSTMENT (HIT)
1. Set the TV in service mode, and get
black cross-hatch signal with VIDEO
button on remote hand unit.
2. Select HIT (Vertical amplitude) with
CHANNEL s, tbuttons, and adjust
vertical amplitude with VOLUME
;–/+ buttons so that vertical am-
plitude lacks a little.
3. Adjust vertical amplitude with VOL-
UME ;–/+ buttons so that the first
bar on cross-hatch signal touches
edge of screen.
The first

–11 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
ITEM ADJUSTMENT PROCEDURE
1. Call up the adjustment mode display, then select the item WID.
2. Press the ;–/+ button to get the picture so the left and rightedges of raster
begins to lack.
3. Press the ;–/+ button to advance the data by 7 steps.
Note : Check the horizontal picture position is correct.
1. Call up the adjustment mode display, then select the item PARA.
2. Press the abutton on Remote until the cross-hatch pattern appears on the screen.
3. Press the ;–/+ button to make vertical lines straight as shown below.
WIDTH
(WID)
E-W PARABOLA
(PARA)
WHITE BALANCE
ADJUSTMENT
•CUTOFF ADJUSTMENT
(RCUT)
(GCUT)
(BCUT)
•DRIVE ADJUSTMENT
(GDRV)
(BDRV)
1. Set Contrast to 40, and brightness to +20 by picture control.
2. Receive the Black and White pattern.
3. Select RCUT, GCUT and BCUT with CHANNEL s, tbuttons, to set individual
values to Initial reference data, and to set GDRV and BDRV to Initial reference
data with VOLUME ;–/+ buttons (See page 18).
4. Press -/- - button on the remote control and rotate Screen VR to get one slight
horizontal line on screen.
Note: Every pressing of -/- - button provides Horizontal line picture and Normal
picture alternately.
5. Press -/- - button to release horizontal line picture, and select the two other colors
which did not light in the above step with CHANNEL s, tbuttons. Then tap VOL-
UME ;–/+ buttons so that three colors slightly light in the same level.
XTo correct white balance in light area,
select GDRV and BDRV with CHANNEL
s, tbuttons to adjust.
XTo correct white balance in dark area,
perform fine adjustment of RCUT, GCUT
and BCUT.
Light area check
(to show white)
Dark area check
(to show black)

–12 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
Items Names Settings Input signals Measuring points Adjusting methods Adjusting standards
(User control)
PICTURE MODE-1
Screen size: WIDE
Audio system: I
PICTURE MODE-1
Screen size: WIDE
PICTURE MODE-1
Screen size: WIDE
PICTURE MODE-1
Screen size: WIDE
[RCUT]: 40H
[GCUT]: 40H
[BCUT]: 40H
[GDRV]: 35H
[BDRV]: 35H
Sub-bright signal
(PAL-I Signal)
Sub-bright Signal
Sub-bright Signal
(PAL)
TP46B
Screen adjust-
ment
TP46B
Screen adjustment
쩸Adjust the amplitude from the pedestal
level to the white peak.
쩸Adjust the number of collapsed black lines
of the sub-bright signal.
쩹Adjust this after adjusting W/B, [SCNT].
쩸Adjust the amplitude of B-Y.
(Apply Y mute at the time of adjustment)
쩸Enter Horizontal Straight-line Mode.
쩹Gradually increase the screen VR until R,
G, or B line starts to light up slightly.
쩺Determine this location as the adjusting
position of the screen VR.
쩻Gradually raise the respective lines other
than the line that glimmered in above
and stop at the location where each of
them glimmers.
(Adjust so that it will become almost white)
쩼Escape from horizontal straight-line mode.
쩽Use the CA100 and adjust repeatedly so
that both the dark and bright areas will
come to correct values.
2.4 ±0.1 Vp-p
4±1.5 pieces
Screen adjustment
1.2 ±0.1 Vo-p
Bright part
(103cd/m
2
)
8750K-0.002uv
Dark part
(17cd/m
2
)
8750K-0.002uv
Screen judgment
(CA100)
[SCNT]
[BRTC]
[COLP]
SCREEN
VR
[RCUT]
[GCUT]
[BCUT]
[GDRV]
[BDRV]
Sub-contrast
Sub-bright
Center
Sub-color center
PA L
R Cutoff
G Cutoff
B Cutoff
G Drive
B Drive
(Reference Factory Adjustments)
[SBY]
[SRY]
[COLS]
SECAM
B-Y Black
level
SECAM
R-Y Black
level
Sub-color
Center
SECAM
PICTURE MODE-1
Screen size: WIDE
SECAM Color bar
SECAM Color bar
SECAM Color bar
TP01
TP02
TP46B
쩸Vary [SBY] so that the level of black and
white signal areas will be aligned with that
of BLK.
쩸Vary [SRY] so that the level of black and
white signal areas will be aligned with that
of H. BLK.
쩸Adjust the amplitude of B-Y.
(Apply Y mute at the time of adjustment)
0 ±10 mV
0 ±10 mV
1.6 ±0.1 Vo-p
(Pedestal to Peak)

–13 –
GENERAL ADJUSTMENTS
SPECIFIC INFORMATIONS
Vertical WIDE mode
Vertical amplitude [HIT]
Vertical position [VPS1]
Super-live mode
Vertical amplitude [HIT]
CINEMA mode
Vertical amplitude [HIT]
PAL WG Philips Pattern, User Adjustment Standard
Adjust the vertical amplitude by [HIT] so that the top-and-bot-
tom flags will be hidden.
PAL Philips Pattern, User Adjustment Standard
Adjust the vertical position [VPS1] so that the vertical screen
position will come to the center in Philips Pattern. (See the
figure on the right)
PAL Philips Pattern, User Adjustment Standard
Adjust the vertical amplitude position by [HIT] so that the top
and bottom of the circle will contact the CPT mask in Philips
Pattern. (See the figure on the right)
Philips Pattern, User Adjustment Standard
Adjust the vertical amplitude by [HIT] so that point shown in
the lower right will contact the CRT mask. (See the figure on
the right)
Adjusting items Adjusting methods
Contact point at
WIDE mode
Contact point at
Super-live
mode
Black
Yellow Red Yellow
Contact point at
CINEMA mode
1. Data adjustment

–14–
Horizontal
WIDE mode
Horizontal phase: [HPOS]
Horizontal amplitude: [WID]
Side DPC: [PARA]
Trapezoidal distortion: [TRAP]
Corner distortion: [CNR]
Center distortion: [CPAR]
Parallelogram distortion: [CSAW]
DPCS letter distortion: [HSC]
Super-live mode
Horizontal amplitude: [WID]
Side DPC: [PARA]
Trapezoidal distortion: [TRAP]
Horizontal phase [HPOS]
DPCS letter distortion: [HSC]
Corner distortion: [CNR]
CINEMA mode
Horizontal amplitude: [WID]
Side DPC: [PARA]
Trapezoidal distortion: [TRAP]
Horizontal phase: [HPOS]
DPCS letter distortion: [HSC]
Corner distortion: [CNR]
Use PAL WG Philips Pattern and adjust the horizontal amplitude so that the mask will be adjusted to the frame of the left
and right flag sections at WIDE mode. Use [WID].
Use PAL WG Philips Pattern and adjust by [PARA] and [TRAP] so that the side pin distortion and trapezoidal distortion will
be optimized at WIDE mode.
As for the horizontal screen position, use horizontal phase [HPOS] and adjust so that the position will come to the center.
•Note: If the distortion adjustment by [PARA] and [TRAP] was insufficient, use
the DATA of [CNR], [CPAR], [CSAW], and [HSC] for adjustment.
When the distortion occurs as shown in Fig. (a), decrease [CPAR].
On the contrary, increase [CPAR] for the distortion of Fig. (b).
When the distortion occurs as shown in Fig. (c), decrease [CSAW].
On the contrary, increase [CSAW] for the distortion of Fig. (d).
When the distortion occurs as shown in Fig. (e), decrease [HSC].
On the contrary, increase [HSC] for the distortion of Fig. (f).
Use PAL Philips Pattern and adjust the frame of the left and right flag sections to the mask at Super-live mode.
Adjust so that the side pin distortion and trapezoidal distortion will be optimized.
If further adjustment is required, use horizontal phase [HPOS], corner distortion [CNR], and DPCS letter distortion [HSC]
f
or adjustment.
Use PAL Philips Pattern and adjust the horizontal amplitude so that the mask will be adjusted to the frame of left and right
flag sections at CINEMA mode.
Adjust so that the side pin distortion and trapezoidal distortion will be optimized.
If further adjustment is required, use horizontal phase [HPOS], corner distortion [CNR], and DPCS letter distortion [HSC]
f
or adjustment.
Adjustment items
Adjustment methods
3. Data Adjustment
(a)
(e)
(b) (c) (d)
(f)
GENERAL ADJUSTMENTS

–15–
GENERAL ADJUSTMENTS
CIRCUIT CHECK
HIGH VOLTAGE CHECK
CAUTION: There is no HIGH VOLTAGE ADJUSTMENT on this chassis. Checking should be done following the steps
below.
1. Connect an accurate high voltage meter to the second anode of the picture tube.
2. Turn on the receiver. Set the BRIGHTNESS and CONTRAST controls to minimum (zero beam current).
3. High voltage must be measured below (B) kV.
Refer to table-1 for high voltage (B).
(See SETTING & ADJUSTING DATA on page 16)
4. Vary the BRIGHTNESS control to both extremes to be sure the high voltage does not exceed the limit under any conditions.

–16–
SPECIFIC INFORMATIONS
DESIGN MODE
ADJUSTING ITEMS AND DATAS IN THE DESIGN MODE:
Table-3
SETTING & ADJUSTING DATA
32”36"
HIGH VOLTAGE AT ZERO BEAM: (A) 32.2 kV 32.4 kV
MAX HIGH VOLTAGE: (B) 35.0 kV 35.0 kV
AV VOLTAGE (C) 220~240 V 220~240 V
CHAPTER 2 SPECIFIC INFORMATIONS
SAFETY INSTRUCTIONS
Table-1
SERVICE MODE
ADJUSTING ITEMS AND DATAS IN THE SERVICE MODE:
Table-2
RCUT
GCUT
BCUT
GDRV
BDRV
BRTC
COLP
COLS
SCC
SRY
SBY
R CUTOFF
G CUTOFF
B CUTOFF
R DRIVE
B DRIVE
SUB BRIGHT CEN
SUB COLOR CEN PAL
SUB COLOR CEN SECAM
YOOUT LEVLE FOR FOR ATV
SECAM R-Y
SECAM B-Y
Item Adjustment
Reference data
40H
40H
40H
35H
35H
80H
19H
19H
66H
07H
04H
Item Name of adjustment Preset Data Remarks
OPT3 OPTION 3 01H
OPT2 OPTION 2 00H
OPT1 OPTION 1 76H
OPT0 OPTION 0 90H
Item Adjustment
WIDE SuperLive CINEMA
HPOS
HIT
VLIN
VPS2
WID
PARA
CNR
TRAP
CPAR
HSC
VPS1
CSAW
H-POSITION
PICTURE HEIGHT
V-LINEARITY
V-SHIFT
WIDTH
E-W PARABOLA
E-W CORNER
TRAPEZIUM
CENT PARA
EW S CORRECTION
V-POSITION
CENT SAW
32H
2BH
11H
40H
2AH
11H
13H
45H
07H
11H
70H
08H
32"Ref. Data Ref. Data Ref. Data
35H
←
←
←
1CH
12H
11H
4CH
09H
10H
7FH
←
36"
3BH
29H
0FH
←
22H
1AH
13H
40H
07H
←
←
←
32"
36H
32H
←
←
2BH
18H
15H
4DH
09H
←
7EH
←
36"
3AH
2FH
←
←
2DH
1EH
13H
43H
07H
←
←
←
32"
35H32H
←
←
←
1CH
22H
15H
4CH
08H
10H
7FH
←
36"
3BH
46H
←
←
26H
2BH
13H
41H
06H
←
←
←
32H
33H
0EH
←
39H
16H
18H
46H
←
←
6FH
←
4AH
0FH
←
2BH
21H
1AH
45H
06H
11H
72H
←












Front
Back
LOCATION OF CONTROLS
SPECIFIC INFORMATIONS
–17–














 

















 

 






  




 














Remote Control
SPECIFIC INFORMATIONS
–18 –

WARNING: BEFORE SERVICING THIS CHASSIS, READ THE "X-RAY RADIATION PRECAUTION", "SAFETY PRE-
CAUTION" AND "PRODUCT SAFETY NOTICE" ON PAGE 3 OF THIS MANUAL.
CAUTION: The international hazard symbols " " in the schematic diagram and the parts list designate components
which have special characteristics important for safety and should be replaced only with types identical to those in the
original circuit or specified in the parts list. The mounting position of replacements is to be identical with originals.
Before replacing any of these components, read carefully the PRODUCT SAFETY NOTICE. Do not degrade the safety
of the receiver through improper servicing.
NOTICE:
··
··
· The part number must be used when ordering parts, in order to assist in processing, be sure to include the
Model number and Description.
··
··
· The PC board assembly with
*
mark is no longer available after the end of the production.
Capacitors ............. CD : Ceramic Disk PF : Plastic Film EL : Electrolytic
Resistors ............... CF : Carbon Film CC : Carbon Composition MF : Metal Film
OMF : Oxide Metal Film VR : Variable Resistor FR : Fusible Resistor
(All CD and PF capacitors are ±5%, 50V and all resistors, ±5%, 1/6W unless otherwise noted.)
– 19 –
Location Parts No. Description
No.
Location Parts No. Description
No.
Model : 32ZP48P/36ZP48P
CHASSIS AND CABINET REPLACEMENT PARTS LIST
#1 : [32ZP48P]
#2 : [36ZP48P]
CAPACITORS
C102 24762221 ELECTROLYTIC, 10V 220UF M
C105 24109102 CERAMIC CHIP, 50V B 1000PF K
C106 24797100 ELECTROLYTIC, 50V 10UF M
C108 24762221 ELECTROLYTIC, 10V 220UF M
C109 24109103 CERAMIC CHIP, 50V B 0.01UF K
C115 24109103 CERAMIC CHIP, 50V B 0.01UF K
C160 24503045 PLASTIC FILM, 63V 0.22UF J
C205 24797229 ELECTROLYTIC, 50V 2.2UF M
C206 24794100 ELECTROLYTIC, 16V 10UF M
C302 24214471 CERAMIC DISC, 500V B 470PF K
C303 24214471 CERAMIC DISC, 500V B 470PF K
C305 24795222 ELECTROLYTIC, 25V 2200UF M
C308 24766221 ELECTROLYTIC, 50V 220UF M
C309 24590102 PLASTIC FILM, 50V 1000PF J
C310 24795222 ELECTROLYTIC, 25V 2200UF M
C313 24082280 PLASTIC FILM, 100V 0.22UF J
C316 24795471 ELECTROLYTIC, 25V 470UF M
C317 24214821 CERAMIC DISC, 500V B 820PF K
C318 24794471 ELECTROLYTIC, 16V 470UF M
C320 24795471 ELECTROLYTIC, 25V 470UF M
C321 24503051 PLASTIC FILM, 63V 0.68UF J
C322 24617915 ELECTROLYTIC, 50V 1UF K 3A LI
C323 24503049 PLASTIC FILM, 63V 0.47UF J
C325 24590183 PLASTIC FILM, 50V 0.018UF J
C326 24797010 ELECTROLYTIC, 50V 1UF M
C327 24794471 ELECTROLYTIC, 16V 470UF M
C331 24503038 PLASTIC FILM, 63V 0.056UF J
C332 24212102 CERAMIC DISC, 50V B 1000PF K
C361 #1 24591222 PLASTIC FILM, 50V 2200PF J
#2 24503045 PLASTIC FILM, 63V 0.22UF J
C366 24082275 PLASTIC FILM CQ922 M 100V 82000PF J
C370 24794100 ELECTROLYTIC, 16V 10UF M
C372 24797470 ELECTROLYTIC 04G, 50V 47UF M
C373 24797470 ELECTROLYTIC 04G, 50V 47UF M
C410 24092341 CERAMIC DISC, 2KV R 470PF K
C413 24214392 CERAMIC DISC, 500V B 3900PF K
C416 24676330 ELECTROLYTIC, 100V 33UF M 3A
C417 24214391 CERAMIC DISC, 500V B 390PF K
C419 24212102 CERAMIC DISC, 50V B 1000PF K
C420 24794101 ELECTROLYTIC, 16V 100UF M
C421 24232103 CERAMIC DISC, 50V F 0.01UF Z @U902
24503041 PLASTIC FILM , 63V 0.1UF J @U903A
C423 24829563 PLASTIC FILM, 400V 0.056UF J
C430 24820103 PLASTIC FILM, 630V 0.01UF J
C431 24232103 CERAMIC DISC, 50V F 0.01UF Z
C432 24590103 PLASTIC FILM, 50V 0.01UF J
C441 24503291 PLASTIC FILM CF92 T 400V R62UF J
C442 24082637 PLASTIC FILM, 400V 0.1UF J
C443 24503190 PLASTIC FILM, 400V 0.12UF J
C444 24503196 PLASTIC FILM CF92 T 1800VH 5600PF H
C445 24829473 PLASTIC FILM, 400V 0.047UF J
C446 24679330 ELECTROLYTIC, 250V 33UF M 3A
C447 #1 24820243 PLASTIC FILM CQ92 T 630V 24000PF
#2 24820273 PLASTIC FILM, 630V 27000PF J
C448 24073118 ELECTROLYTIC, 160V 33UF M
C449 24829333 PLASTIC FILM, 400V 0.033UF J
C451 24503047 PLASTIC FILM, 63V 0.33UF J
C460 24679220 ELECTROLYTIC, 250V 22UF M 3A
C461 24503195 PLASTIC FILM, 1800VH 5100PF H
C462 24666101 ELECTROLYTIC 04Q, 16V 100UF M 3A
C464 24503149 PLASTIC FILM, 250V 3.3UF
C465 24590183 PLASTIC FILM, 50V 0.018UF J
C466 24503261 PLASTIC FILM CF92 T 1250VH 6800PF H
C467 24503253 PLASTIC FILM, 1250VH 0.01UF H
C468 24503253 PLASTIC FILM, 1250VH 0.01UF H
C470 24794470 ELECTROLYTIC, 16V 47UF M
C471 24503046 PLASTIC FILM, 63V 0.27UF J
C472 24503049 PLASTIC FILM, 63V 0.47UF J
C473 24669010 ELECTROLYTIC, 50V 1UF M 3A
C475 24820822 PLASTIC FILM, 630V 8200PF J
C476 24794220 ELECTROLYTIC, 16V 22UF M
C478 24503038 PLASTIC FILM, 63V 0.056UF J
C481 24590103 PLASTIC FILM, 50V 0.01UF J
C482 24085988
ELECTROLYTIC, NONPOLAR, 50V 1.0UF M 7L @U902
24212152 CERAMIC DISC, 50V B 1500PF K @U904
C489 24590393 PLASTIC FILM, 50V 0.039UF J
C495 24092343 CERAMIC DISC, 2KV 680PF K
C496 24092343 CERAMIC DISC, 2KV 680PF K
C498 24590821 PLASTIC FILM CQ922M 50V 820PF J
C501 24092730 CERAMIC CHIP, 16V B 0.1UF K
C502 24092730 CERAMIC CHIP, 16V B 0.1UF K
C503 24794470 ELECTROLYTIC, 16V 47UF M
C504 24109103 CERAMIC CHIP, 50V B 0.01UF K
C505 24794470 ELECTROLYTIC, 16V 47UF M
C506 24109103 CERAMIC CHIP, 50V B 0.01UF K
C507 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C508 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C509 24100104 CERAMIC CHIP, 25V F 0.1UF Z
SPECIFIC INFORMATIONS

– 20 –
Location Parts No. Description
No.
Location Parts No. Description
No.
C511 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C512 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C513 24109103 CERAMIC CHIP, 50V B 0.01UF K
C514 24763221 ELECTROLYTIC, 16V 220UF M
C516 24105110 CERAMIC CHIP, 50V CH 11PF J
C517 24206478 ELECTROLYTIC, 50V 0.47UF M 7L 3A
C519 24797479 ELECTROLYTIC, 50V 4.7UF M
C520 24503047 PLASTIC FILM, 63V 0.33UF J
C521 24092733 CERAMIC CHIP, 50V B 0.022UF K
C522 24109103 CERAMIC CHIP, 50V B 0.01UF K
C523 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C524 24109103 CERAMIC CHIP, 50V B 0.01UF K
C525 24503041 PLASTIC FILM , 63V 0.1UF J
C526 24109103 CERAMIC CHIP, 50V B 0.01UF K
C527 24797229 ELECTROLYTIC, 50V 2.2UF M
C530 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
C531 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C532 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C533 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C534 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C536 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C537 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C540 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C541 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C542 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C543 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C544 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C545 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C547 24109103 CERAMIC CHIP, 50V B 0.01UF K
C548 24763101 ELECTROLYTIC, 16V 100UF M
C563 24206010 ELECTROLYTIC, 50V 1.0UF M 7L 3A
C564 24797479 ELECTROLYTIC, 50V 4.7UF M
C565 24797478 ELECTROLYTIC, 50V 0.47UF M
C575 24092730 CERAMIC CHIP, 16V B 0.1UF K
C580 24100104 CERAMIC CHIP, 25V F 0.1UF Z
C613 24666471 ELECTROLYTIC 04Q, 16V 470UF M 3A
C615 24085945 ELECTROLYTIC, NONPOLAR 04J, 50V 2.2UF
C616 24590183 PLASTIC FILM, 50V 0.018UF J
C617 24590152 PLASTIC FILM, 50V 1500PF J
C618 24590563 PLASTIC FILM, 50V 0.056UF J
C619 24794221 ELECTROIYTIC 04G, 16V 220UF M
C620 24794101 ELECTROLYTIC, 16V 100UF M
C621 24590102 PLASTIC FILM, 50V 1000PF J
C626 24797478 ELECTROLYTIC, 50V 0.47UF M
C628 24797470 ELECTROLYTIC 04G, 50V 47UF M
C629 24109221 CERAMIC CHIP, 50V B 220PF K
C630 24109221 CERAMIC CHIP, 50V B 220PF K
C631 24669010 ELECTROLYTIC, 50V 1UF M 3A
C632 24669479 ELECTROLYTIC, 50V 4.7UF M 3A
C633 24503042 PLASTIC FILM, 63V 0.12UF J
C634 24668471 ELECTROLYTIC, 35V 470UF M 3A
C639 24793222 ELECTROLYTIC, 10V 2200UF M
C641 24669010 ELECTROLYTIC, 50V 1UF M 3A
C644 24669010 ELECTROLYTIC, 50V 1UF M 3A
C645 24667470 ELECTROLYTIC CE04Q, 25V 47UF M 3A
C647 24591102 PLASTIC FILM, 50V 1000PF J
C648 24591102 PLASTIC FILM, 50V 1000PF J
C649 24797229 ELECTROLYTIC, 50V 2.2UF M
C650 24668102 ELECTROLYTIC, 35V 1000UF M 3A
C651 24668471 ELECTROLYTIC, 35V 470UF M 3A
C652 24668471 ELECTROLYTIC, 35V 470UF M 3A
C654 24503042 PLASTIC FILM, 63V 0.12UF J
C655 24503042 PLASTIC FILM, 63V 0.12UF J
C656 24232103 CERAMIC DISC, 50V F 0.01UF Z
C657 24797229 ELECTROLYTIC, 50V 2.2UF M
C660 24797229 ELECTROLYTIC, 50V 2.2UF M
C661 24797478 ELECTROLYTIC, 50V 0.47UF M
C662 24797229 ELECTROLYTIC, 50V 2.2UF M
C663 24669229 ELECTROLYTIC, 50V 2.2UF M 3A
C664 24794100 ELECTROLYTIC, 16V 10UF M
C665 24073083 ELECTROLYTIC CE04P 50V 3.3UF M 3A
C666 24073083 ELECTROLYTIC CE04P 50V 3.3UF M 3A
C667 24669229 ELECTROLYTIC, 50V 2.2UF M 3A
C668 24590102 PLASTIC FILM, 50V 1000PF J
C669 24797330 ELECTROLYTIC, 50V 33UF M
C670 24590222 PLASTIC FILM, 50V 2200PF J @U902
24797330 ELECTROLYTIC, 50V 33UF M @U903C
C671 24669010 ELECTROLYTIC, 50V 1UF M 3A
C672 24590222 PLASTIC FILM, 50V 2200PF J
C673 24669010 ELECTROLYTIC, 50V 1UF M 3A
C674 24669010 ELECTROLYTIC, 50V 1UF M 3A
C675 24667470 ELECTROLYTIC CE04Q, 25V 47UF M 3A
C676 24669479 ELECTROLYTIC, 50V 4.7UF M 3A
C677 24590471 PLASTIC FILM, 50V 470PF J
C678 24590471 PLASTIC FILM, 50V 470PF J
C679 24591473 PLASTIC FILM, 50V 0.047UF J
C680 24668102 ELECTROLYTIC, 35V 1000UF M 3A
C681 24668102 ELECTROLYTIC, 35V 1000UF M 3A
C682 24668102 ELECTROLYTIC, 35V 1000UF M 3A
C683 24668102 ELECTROLYTIC, 35V 1000UF M 3A
C684 24666470 ELECTORLYTIC, 16V 47UF M 3A
C685 24503042 PLASTIC FILM, 63V 0.12UF J
C686 24503042 PLASTIC FILM, 63V 0.12UF J
C687 24232103 CERAMIC DISC, 50V F 0.01UF Z
C688 24666220 ELECTROLYTIC, 16V 22UF M 3A
C689 24503042 PLASTIC FILM, 63V 0.12UF J
C691 24797010 ELECTROLYTIC, 50V 1UF M
C692 24797010 ELECTROLYTIC, 50V 1UF M
C695 24668101 ELECTROLYTIC, 35V 100UF M 3A
C696 24667470 ELECTROLYTIC CE04Q, 25V 47UF M 3A
C704 24590822 PLASTIC FILM, 50V 8200PF J
C705 24797229 ELECTROLYTIC, 50V 2.2UF M
C707 24794470 ELECTROLYTIC, 16V 47UF M
C712 24794470 ELECTROLYTIC, 16V 47UF M
C713 24790100 ELECTROLYTIC, 160V 10UF M
C715 24214472 CERAMIC DISC, 500V B 4700PF K
C717 24214472 CERAMIC DISC, 500V B 4700PF K
C718 24794470 ELECTROLYTIC, 16V 47UF M
C719 24435151 CERAMIC DISC, 500V SL 150PF
C720 24790100 ELECTROLYTIC, 160V 10UF M
C721 24794470 ELECTROLYTIC, 16V 47UF M
C801 24503506 PLASTIC FILM, AC275V 0.1UF K
C802 24503506 PLASTIC FILM, AC275V 0.1UF K
C803 #1 24503507 PLASTIC FILM, AC275V 0.22UF K
C805 24092281 CERAMIC DISC, AC250V E 4700PF
C806 24092281 CERAMIC DISC, AC250V E 4700PF
C808 24668101 ELECTROLYTIC, 35V 100UF M 3A
C809 24503049 PLASTIC FILM, 63V 0.47UF J
C810 24086873 ELECTROLYTIC, 400V 330UF
C813 24092555 CERAMIC DISC, AC250V E 1000PF M
C814 24092555 CERAMIC DISC, AC250V E 1000PF M
C816 24669479 ELECTROLYTIC, 50V 4.7UF M 3A
C817 24092339 CERAMIC DISC, 2KV 330PF K
C818 24095931 PLASTIC FILM, 1250VH 2200PF J
C821 24214471 CERAMIC DISC, 500V B 470PF K
C822 24503049 PLASTIC FILM, 63V 0.47UF J
C823 24214471 CERAMIC DISC, 500V B 470PF K
C829 24591272 PLASTIC FILM, 50V 2700PF J
C831 24794470 ELECTROLYTIC, 16V 47UF M
C832 24794470 ELECTROLYTIC, 16V 47UF M
C834 24794470 ELECTROLYTIC, 16V 47UF M
C835 24795100 ELECTROLYTIC, 25V 10UF M
C836 24794470 ELECTROLYTIC, 16V 47UF M
C838 24794470 ELECTROLYTIC, 16V 47UF M
C840 24667102 ELECTROLYTIC, 25V 1000UF M 3A
C842 24669100 ELECTROLYTIC, 50V 10UF M 3A
C872 24669221 ELECTROLYTIC, 50V 220UF M 3A
C884 24086953 ELECTROLYTIC, 160V 220UF M 3A
C885 24214471 CERAMIC DISC, 500V B 470PF K
C889 24669222 ELECTROLYTIC, 50V 2200UF M 3A
C891 24667472 ELECTROLYTIC, 25V 4700UF M 3A
C892 24667472 ELECTROLYTIC, 25V 4700UF M 3A
C893 24092337 CERAMIC DISC, 2KV 220PF K
C896 24214471 CERAMIC DISC, 500V B 470PF K
C898 24212102 CERAMIC DISC, 50V B 1000PF K
C899 24214471 CERAMIC DISC, 500V B 470PF K
C902 24092353 CERAMIC DISC, 2KV 4700PF K
C904 24436471 CERAMIC DISC, 50V SL 470PF J
C905 24436471 CERAMIC DISC, 50V SL 470PF J
C907 24436391 CERAMIC DISC, 50V SL 390PF J
C909 24679330 ELECTROLYTIC, 250V 33UF M 3A
C910 24797478 ELECTROLYTIC, 50V 0.47UF M
SPECIFIC INFORMATIONS
