SERVICE MANUAL
COLOR TELEVISION/
DVD VIDEO PLAYER
DOCUMENT CREATED IN JAPAN, April, 2005
MD14F11
FILE NO. 140-200515
(MFR’S VERSION B)

A1-1
PREPARATION OF SERVICING
The laser diode used for a pickup head may be destroyed with external static electricity.
Moreover, even if it is operating normally after repair, when static electricity discharge is received at the
time of repair, the life of the product may be shortened.
Please perform the following measure against static electricity, be careful of destruction of a laser diode
at the time of repair.
• Place the unit on a workstation equipped to protect, against static electricity, such as conductive mat.
• Soldering iron with ground wire or ceramic type is used.
• A worker needs to use a ground conductive wrist strap for body.
Location of the required Marking
The rating sheet and the safety caution are on the rear of the unit.
CERTIFICATION: COMPLIES WITH FDA
RADIATION PERFORMANCE STANDARDS,
21 CFR SUBCHAPTER J.
CAUTION
THIS DIGITAL VIDEO PLAYER EMPLOYS A LASER SYSTEM.
TO ENSURE PROPER USE OF THIS PRODUCT, PLEASE READ THIS SERVICE MANUAL CARE-
FULLYAND RETAIN FOR FUTURE REFERENCE. SHOULD THE UNIT REQUIRE MAINTENANCE,
CONTACT AN AUTHORIZED SERVICE LOCATION-SEE SERVICE PROCEDURE.
USE OF CONTROLS, ADJUSTMENTS OR THE PERFORMANCE OF PROCEDURES OTHER THAN
THOSE SPECIFIED HEREIN MAY RESULT IN HAZARDOUS RADIATION EXPOSURE.
TO PREVENT DIRECT EXPOSURE TO LASER BEAM, DO NOT TRY TO OPEN THE ENCLOSURE.
VISIBLE LASER RADIATION MAY BE PRESENT WHEN THE ENCLOSURE IS OPENED. DO NOT
STARE INTO BEAM.

A1-2
SERVICING NOTICES ON CHECKING
6. AVOID AN X-RAY1. KEEP THE NOTICES
As for the places which need special attentions,
they are indicated with the labels or seals on the
cabinet, chassis and parts. Make sure to keep the
indications and notices in the operation manual.
3. USE THE DESIGNATED PARTS
5. TAKE CARE TO DEAL WITH THE
CATHODE-RAY TUBE
In the condition that an explosion-proof cathode-
ray tube is set in this equipment, safety is
secured against implosion. However, when
removing it or serving from backward, it is
dangerous to give a shock. Take enough care to
deal with it.
Safety is secured against an X-ray by consider-
ing about the cathode-ray tube and the high
voltage peripheral circuit, etc.
Therefore, when repairing the high voltage pe-
ripheral circuit, use the designated parts and
make sure not modify the circuit.
Repairing except indicates causes rising of high
voltage, and it emits an X-ray from the cathode-
ray tube.
PERFORM A SAFETY CHECK AFTER
SERVICING
7.
Confirm that the screws, parts and wiring which
were removed in order to service are put in the
original positions, or whether there are the
portions which are deteriorated around the
serviced places serviced or not. Check the
insulation between the antenna terminal or
external metal and the AC cord plug blades.
And be sure the safety of that.
(INSULATION CHECK PROCEDURE)
1.
2.
3.
4.
Unplug the plug from the AC outlet.
Remove the antenna terminal on TV and turn
on the TV.
Insulation resistance between the cord plug
terminals and the eternal exposure metal
[Note 2] should be more than 1M ohm by
using the 500V insulation resistance meter
[Note 1].
If the insulation resistance is less than 1M
ohm, the inspection repair should be
required.
[Note 1]
If you have not the 500V insulation
resistance meter, use a Tester.
[Note 2]
External exposure metal: Antenna terminal
2. AVOID AN ELECTRIC SHOCK
There is a high voltage part inside. Avoid an
electric shock while the electric current is
flowing.
The parts in this equipment have the specific
characters of incombustibility and withstand
voltage for safety. Therefore, the part which is
replaced should be used the part which has
the same character.
Especially as to the important parts for safety
which is indicated in the circuit diagram or the
table of parts as a mark, the designated
parts must be used.
4. PUT PARTS AND WIRES IN THE
ORIGINAL POSITION AFTER
ASSEMBLING OR WIRING
There are parts which use the insulation
material such as a tube or tape for safety, or
which are assembled in the condition that
these do not contact with the printed board.
The inside wiring is designed not to get closer
to the pyrogenic parts and high voltage parts.
Therefore, put these parts in the original
positions.
Please include the following informations when you order parts. (Particularly the VERSION LETTER.)
1. MODEL NUMBER and VERSION LETTER
The MODEL NUMBER can be found on the back of each product and the VERSION LETTER can be
found at the end of the SERIAL NUMBER.
2. PART NO. and DESCRIPTION
You can find it in your SERVICE MANUAL.
HOW TO ORDER PARTS

A1-3
IMPORTANT SAFEGUARDS
1.
2.
3.
4.
5.
6.
7.
8.
8A.
9.
10.
11.
12.
13.
14.
15.
16.
READ INSTRUCTIONS
All the safety and operating instructions should be read before the unit is operated.
RETAIN INSTRUCTIONS
The safety and operating instructions should be retained for future reference.
HEED WARNINGS
All warnings on the unit and in the operating instructions should be adhered to.
FOLLOW INSTRUCTIONS
All operating and use instructions should be followed.
CLEANING
Unplug this unit from the wall outlet before cleaning. Do not use liquid cleaners or aerosol cleaners. Use a damp
cloth for cleaning.
ATTACHMENTS
Do not use attachments not recommended by the unit’s manufacturer as they may cause hazards.
WATER AND MOISTURE
Do not use this unit near water. For example, near a bathtub, washbowl, kitchen sink, or laundry tub, in a wet
basement, or near a swimming pool.
ACCESSORIES
Do not place this unit on an unstable cart, stand, tripod, bracket, or table. The
unit may fall, causing serious injury, and serious damage to the unit. Use only
with a cart, stand, tripod, bracket, or table recommended by the manufacturer.
An appliance and cart combination should be moved with care. Quick stops,
excessive force, and uneven surfaces may cause the appliance and cart
combination to overturn.
VENTILATION
Slots and openings in the cabinet and in the back or bottom are provided for ventilation, to ensure reliable
operation of the unit, and to protect it from overheating. These openings must not be blocked or covered. The
openings should never be blocked by placing the unit on a bed, sofa, rug, or other similar surface. This unit
should never be placed near or over a radiator or heat source. This unit should not be placed in a built-in
installation such as a bookcase or rack unless proper ventilation is provided or the manufacturer’s instructions
have been adhered to.
POWER SOURCES
This unit should be operated only from the type of power source indicated on the rating plate. If you are not sure
of the type of power supply to your home, consult your appliance dealer or local power company. For units
intended to operate from battery power, or other sources, refer to the operating instructions.
GROUNDING OR POLARIZATION
This unit is equipped with a polarized alternating-current line plug (a plug having one blade wider than the other).
This plug will fit into the power outlet only one way. This is a safety feature. If you are unable to insert the plug
fully into the outlet, try reversing the plug. If the plug should still fail to fit, contact your electrician to replace your
obsolete outlet. Do not defeat the safety purpose of the polarized plug. If your unit is equipped with a 3-wire
grounding-type plug, a plug having a third (grounding) pin, this plug will only fit into a grounding-type power
outlet. This too, is a safety feature. If you are unable to insert the plug into the outlet, contact your electrician to
replace your obsolete outlet. Do not defeat the safety purpose of the grounding-type plug.
POWER-CORD PROTECTION
Power-supply cords should be routed so that they are not likely to be walked on or pinched by items placed upon
or against them, paying particular attention to cords at plugs, convenience receptacles, and the point where they
exit from the appliance.
LIGHTNING
To protect your unit from a lightning storm, or when it is left unattended and unused for long periods of time,
unplug it from the wall outlet and disconnect the antenna or cable system. This will prevent damage to the unit
due to lightning and power line surges.
POWER LINES
An outside antenna system should not be located in the vicinity of overhead power lines or other electric light or
power circuits, or where it can fall into such power lines or circuits. When installing an outside antenna system,
extreme care should be taken to keep from touching such power lines or circuits, as contact with them might be
fatal.
OVERLOADING
Do not overload wall outlets and extension cords, as this can result in a risk of fire or electric shock.
OBJECT AND LIQUID ENTRY
Do not push objects through any openings in this unit, as they may touch dangerous voltage points or short out
parts that could result in fire or electric shock. Never spill or spray any type of liquid into the unit.
PORTABLE CART WARNING
(symbol provided by RETAC)
S3126A

A1-4
IMPORTANT SAFEGUARDS (CONTINUED)
OUTDOOR ANTENNA GROUNDING
If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded
so as to provide some protection against voltage surges and built-up static charges. Section 810 of the National
Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting
structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of
antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.
SERVICING
Do not attempt to service this unit yourself as opening or removing covers may expose you to dangerous voltage
or other hazards. Refer all servicing to qualified service personnel.
DAMAGE REQUIRING SERVICE
Unplug this unit from the wall outlet and refer servicing to qualified service personnel under the following
conditions:
REPLACEMENT PARTS
When replacement parts are required, be sure the service technician uses replacement parts specified by the
manufacturer or those that have the same characteristics as the original parts.
Unauthorized substitutions may result in fire, electric shock or other hazards.
SAFETY CHECK
Upon completion of any service or repairs to this unit, ask the service technician to perform safety checks to
determine that the unit is in proper operating condition.
WALL OR CEILING MOUNTING
The product should be mounted to a wall or ceiling only as recommended by the manufacturer.
HEAT
The product should be situated away from heat sources such as radiators, heat registers, stoves, or other
products (including amplifiers) that produce heat.
DISC TRAY
Keep your fingers well clear of the disc tray as it is closing. It may cause serious personal injury.
CONNECTING
When you connect the product to other equipment, turn off the power and unplug all of the equipment from the
wall outlet. Failure to do so may cause an electric shock and serious personal injury. Read the owner's manual of
the other equipment carefully and follow the instructions when making any connections.
SOUND VOLUME
Reduce the volume to the minimum level before you turn on the product. Otherwise, sudden high volume sound
may cause hearing or speaker damage.
SOUND DISTORTION
Do not allow the product output distorted sound for a longtime. It may cause speaker overheating and fire.
HEADPHONES
When you use the headphones, keep the volume at a moderate level. If you use the headphones continuously
with high volume sound, it may cause hearing damage.
LASER BEAM
Do not look into the opening of the disc tray or ventilation opening of the product to see the source of the laser
beam. It may cause sight damage.
DISC
Do not use a cracked, deformed, or repaired disc. These discs are easily broken and may cause serious
personal injury and product malfunction.
NOTE TO CATV SYSTEM INSTALLER
This reminder is provided to call the CATV system installer’s attention to Article 820-40 of the NEC that provides
guidelines for proper grounding and, in particular, specifies that the cable ground shall be connected to the
grounding system of the building, as close to the point of cable entry as practical.
17.
18.
19.
20.
21.
22.
23.
24.
25.
26.
27.
28.
29.
30.
31.
a.
b.
c.
d.
e.
f.
When the power-supply cord or plug is damaged.
If liquid has been spilled, or objects have fallen into the unit.
If the unit has been exposed to rain or water.
If the unit does not operate normally by following the operating instructions. Adjust only those controls that
are covered by the operating instructions, as an improper adjustment of other controls may result in
damage and will often require extensive work by a qualified technician to restore the unit to its normal
operation.
If the unit has been dropped or the cabinet has been damaged.
When the unit exhibits a distinct change in performance, this indicates a need for service.

A1-5
EXAMPLE OF ANTENNA GROUNDING AS PER THE NATIONAL ELECTRICAL CODE
ANTENNA
DISCHARGE UNIT
(NEC SECTION 810-20)
ANTENNA LEAD
IN WIRE
GROUNDING CONDUCTORS
(NEC SECTION 810-21)
GROUND CLAMPS
POWER SERVICE GROUNDING
ELECTRODE SYSTEM
(NEC ART 250, PART H)
GROUND
CLAMP
ELECTRIC SERVICE
EQUIPMENT
NEC-NATIONAL ELECTRICAL CODE
S2898A
IMPORTANT SAFEGUARDS (CONTINUED)

A1-6
1.
2.
3.
Remove the Back Cabinet and AV PCB/DVD Block. (Refer to item 1 of the DISASSEMBLY
INSTRUCTIONS.)
Rotate the Main Gear in the direction of the arrow by hand.
(Refer to Fig. 1)
Manually open the Tray.
DISC REMOVAL METHOD AT NO POWER SUPPLY
Fig. 1
Deck CDMain Gear
Before removing Pick Up PCB and DVD PCB connector, the short circuit the position shown in Fig. 1
using a soldering iron. If you remove the DVD Deck with no soldering, the Laser may be damaged.
WHEN REPLACING DVD DECK
[ When removing the DVD Deck ]
[ When installing the DVD Deck ]
Remove all the soldering on the short circuit position after the connection of Pick Up PCB and DVD
PCB connector.
NOTE
Fig. 1 Short circuit using a
soldering iron.
Pick Up PCB
Before your operation, please read “PREPARATION OF SERVICING”.
Use the Pb Free solder.
Manual soldering conditions
•Soldering temperature: 350 ±5˚C
•Soldering time: Within 2 seconds
•Soldering combination: Sn-3.0Ag-0.5Cu
When Soldering/Removing of solder, use the draw in equipment over the Pick Up Unit to prevent the
Flux smoke from it.
•
•
•
•

If the stored 4 digit password in the Rating Level menu needs to be cancelled, please follow the steps
below.
Turn Unit ON.
Set the DVD to the Stop Mode.
Check that 'No disc' is displayed on the screen.
Press and hold the 'STOP' button on the front panel.
Simultaneously press and hold the '7' key on the remote control unit.
Hold both keys for more than 3 seconds.
The On Screen Display message 'PASSWORD CLEAR' will appear.
The 4 digit password has now been cleared.
1.
2.
3.
4.
5.
6.
7.
8.
PARENTAL CONTROL - RATING LEVEL
4 DIGIT PASSWORD CANCELLATION
A1-7
Tray cannot be opened by setting the Tray Lock, please follow the steps below.
Turn Unit ON.
Set the DVD to the Stop Mode.
Press it in order of 'SETUP', 'SUBTITLE', '3', 'AUDIO SELECT' and '0' key of a remote control unit.
The On Screen Display message ' ' will appear.
The Tray Lock has now been set up.
1.
2.
3.
4.
5.
TRAY LOCK
To unlock the Tray Lock, please follow the steps below.
Turn Unit ON.
Set the DVD to the Stop Mode.
Press it in order of 'SETUP', 'SUBTITLE', '3', 'AUDIO SELECT' and '0' key of a remote control unit.
The On Screen Display message ' ' will appear.
The Tray Lock has now been cleared.
1.
2.
3.
4.
5.
Tray cannot be opened by setting the Tray Lock, please follow the steps below.
Turn Unit ON.
Set the DVD to the Stop Mode.
Press and hold the 'STOP(DVD)' key on the front panel.
Simultaneously press and hold the '9' key on the remote control unit.
Hold both keys for more than 3 seconds.
Press the OPEN/CLOSE key on the front panel to check the Tray Lock setting.
1.
2.
3.
4.
5.
6.
To unlock the Tray Lock, please follow the steps below.
Turn Unit ON.
Set the DVD to the Stop Mode.
Press and hold the 'STOP(DVD)' key on the front panel.
Simultaneously press and hold the '9' key on the remote control unit.
Hold both keys for more than 3 seconds.
The Tray Lock has now been cleared.
1.
2.
3.
4.
5.
6.
It is likely to be going to be changed to the following steps without a previous notice in the future.
If the above is not effective measures, please follow the steps below.
NOTE: No indications on the screen when the Tray Lock is setting.
NOTE: No indications on the screen when the Tray Lock is setting.
NOTE: No indications on the screen when the Tray Lock is setting.
NOTE: No indications on the screen when the Tray Lock is setting.

PCBs (manufactured) using lead free solder will have a PbF printing on the PCB.
(Please refer to figures.)
Caution:
Pb free solder has a higher melting point than standard solder;
Typically the melting point is 50°F~70°F(30°C~40°C) higher.
Please use a soldering iron with temperature control and adjust it to 650°F ±20°F (350°C ±10°C).
In case of using high temperature soldering iron, please be carefull not to heat too long.
Pb free solder will tend to splash when heated too high (about 1100°F/ 600°C).
All products with the printed circuit board with PbF printing must be serviced with lead free solder.
When soldering or unsoldering, completely remove all of the solder from the pins or solder area,
and be sure to heat the soldering points with the lead free solder until it melts sufficiently.
Distinction of PbF PCB:
Recommendations
Recommended lead free solder composition is Sn-3.0Ag-0.5Cu.
ABOUT LEAD FREE SOLDER (PbF)
•
•
•
A1-8

TABLE OF CONTENTS
CAUTION ....................................................................................................................................
SERVICING NOTICES ON CHECKING.....................................................................................
HOW TO ORDER PARTS ..........................................................................................................
IMPORTANT SAFEGUARDS.....................................................................................................
WHEN REPLACING DVD DECK ...............................................................................................
DISC REMOVAL METHOD AT NO POWER SUPPLY .............................................................
PARENTAL CONTROL-RATING LEVEL ..................................................................................
TRAY LOCK................................................................................................................................
ABOUT LEAD FREE SOLDER (PbF)........................................................................................
TABLE OF CONTENTS..............................................................................................................
GENERAL SPECIFICATIONS ...................................................................................................
DISASSEMBLY INSTRUCTIONS
1. REMOVAL OF MECHANICAL PARTS AND P. C. BOARDS............................................
2. REMOVAL OF DVD DECK PARTS ...................................................................................
3. REMOVAL OF ANODE CAP..............................................................................................
4. REMOVAL AND INSTALLATION OF FLAT PACKAGE IC ...............................................
SERVICE MODE LIST ................................................................................................................
CONFIRMATION OF HOURS USED .........................................................................................
WHEN REPLACING EEPROM (MEMORY) IC ..........................................................................
ELECTRICAL ADJUSTMENTS..................................................................................................
BLOCK DIAGRAMS
DVD..........................................................................................................................................
TV ............................................................................................................................................
POWER ..................................................................................................................................
PRINTED CIRCUIT BOARDS
DVD..........................................................................................................................................
AV/CRT ....................................................................................................................................
LOADING MOTOR/SW ...........................................................................................................
SCHEMATIC DIAGRAMS
MPEG/MICON/DSP.................................................................................................................
MEMORY .................................................................................................................................
MOTOR DRIVE .......................................................................................................................
AUDIO/VIDEO .........................................................................................................................
REGULATOR...........................................................................................................................
MICON/TUNER .......................................................................................................................
VIF/SIF/CHROMA....................................................................................................................
SOUND AMP ...........................................................................................................................
IN/OUT .....................................................................................................................................
STEREO ..................................................................................................................................
DEFLECTION ..........................................................................................................................
CRT ..........................................................................................................................................
POWER ...................................................................................................................................
LOADING MOTOR/SW ...........................................................................................................
INTERCONNECTION DIAGRAM ...............................................................................................
WAVEFORMS .............................................................................................................................
MECHANICAL EXPLODED VIEWS...........................................................................................
DVD DECK EXPLODED VIEW...................................................................................................
MECHANICAL REPLACEMENT PARTS LIST .........................................................................
DVD DECK PLACEMENT PARTS LIST ....................................................................................
ELECTRICAL REPLACEMENT PARTS LIST...........................................................................
A1-1
A1-2
A1-2
A1-3~A1-5
A1-6
A1-6
A1-7
A1-7
A1-8
A2-1
A3-1~A3-6
B1-1, B1-2
B2-1~B2-4
B3-1
B4-1, B4-2
C-1
C-1
C-2
D-1~D-6
E-1, E-2
E-3, E-4
E-5, E-6
F-1, F-2
F-3~F-6
F-7, F-8
G-1, G-2
G-3, G-4
G-5, G-6
G-7, G-8
G-9, G-10
G-11, G-12
G-13, G-14
G-15, G-16
G-17, G-18
G-19, G-20
G-21, G-22
G-23, G-24
G-25, G-26
G-27, G-28
G-29, G-30
H-1~H-3
I1-1~I1-3
I2-1
J1-1
J2-1
J3-1~J3-5
A2-1

GENERAL SPECIFICATIONS
G-1 TV CRT CRT Size / Visual Size 14 inch / 357.0 mmV
System CRT Type Flat
Magnetic Field BV/BH +0.45G / 0.18G
Color System NTSC
Speaker 2 Speaker
Position Front
Size 1.5 x 2.7 inch
Impedance 8 ohm
Sound Output Max 2.5W + 2.5W
10%(Typical) __
G-2 DVD System Color System NTSC
Disc DVD, CD-DA, CD-R/RW, Video CD
DVD-R/RW (Video Format Only)
Disc Diameter 120 mm , 80 mm
Drive DM3O
Search speed Fwd 4 step
Actual 2-120 times(DVD, VIDEO CD)
4-40 times (CD)
Rev 4 step
Actual 2-120 times(DVD, VIDEO CD)
4-40 times (CD)
Slow speed Fwd 1/7 - 1/2 times
Actual --
Rev 1/7 - 1/2 times
Actual --
G-3 Tuning Broadcasting System US System M
System Tuner and System 1Tuner
Receive CH Destination US(w/CABLE)
CH Coverage 2~69, 4A, A-5~A-1, A~I, J~W, W+1~W+84
Intermediate Picture(FP) 45.75MHz
Frequency Sound(FS) 41.25MHz
FP-FS 4.50MHz
Preset CH No
Stereo/Dual TV Sound US-Stereo
Tuner Sound Muting Yes
G-4 Signal Video Signal Input Level 1 V p-p/75 ohm
Output Level --
S/N Ratio (Weighted) --
Horizontal Resolution at DVD Mode --
--
RGB Signal Output Level --
Audio Signal Input Level -8.0dBm/50k ohm
Output Level --
Digital Output Level 0.5 V p-p/75 ohm
S/N Ratio at DVD (Weighted) --
Harmonic Distortion --
Frequency Response : at DVD --
at Video CD --
at SVCD --
at CD --
G-5 Power Power Source AC 120V, 60Hz
DC --
Power Consumption at AC 90W at 120V 60Hz
at DC --
Stand by (at AC) 5W at 120V 60Hz
Per Year -- kWh/Year
Protector Power Fuse Yes
Safety Circuit Yes
IC Protector(Micro Fuse) No
Dew Sensor No
G-6 Regulation Safety UL
Radiation FCC
X-Radiation DHHS
Laser DHHS
G-7 Temperature Operation +5oC ~ +40oC
Storage -20oC ~ +60oC
G-8 Operating Humidity Less than 80% RH
A3-1

GENERAL SPECIFICATIONS
G-9 On Screen Menu(TV) Yes
Display Menu Type Icon
TV Setup Yes
Picture Yes
Audio No
Picture Preference Yes
Channel Setup Yes
TV/CABLE Yes
Auto CH Memory Yes
Add/ Delete Yes
V-chip Setup Yes
Language Yes
Sleep Timer Yes
CH / AV(LINE) / DVD Yes
Stereo/Audio Output Yes
Bilingual No
SAP Yes
Control Volume Yes
Level Brightness / Contrast / Sharpness / Color Yes
Tint Yes
Bass/Treble/Balance No
Caption / Text Yes
Auto Search/Position No
Game Yes
Mute Yes
A3-2

GENERAL SPECIFICATIONS
G-10 On Screen Menu (DVD) Yes
Display Menu Type Icon
Language Yes
Menu Yes
Subtitle Yes
Audio Yes
OSD Language(Set up Language) Yes
Video Yes
E.B.L. (Enhanced Black Level) No
TV Screen Size(4:3) Yes
OSD Display On/Off Yes
Picture Mode (Video/Film/Auto) Yes
JPEG Interval No
Audio Yes
DRC (Dynamic Range Control) Yes
Dialogue (On DRC[TV] / Off DRC[Std]) No
Surround No
System Yes
Disc/Card Slot No
Password Lock/ Un Lock Yes
Parental Yes
Select Files No
HDMI (480p/1080i/720p) No
Output No
Open Yes
Close Yes
No disc Yes
Reading Yes
Play Yes
Still/Pause Yes
Stop Yes
Prohibit Mark Yes
PBC Yes
Step Yes
Skip(>>|) Yes
Skip(|<<) Yes
Random Yes (CD, VIDEO CD)
Repeat Yes
Slow+ Yes
Slow- Yes
Search+ Yes
Search- Yes
Jump Yes
Resume Yes
Title No. Yes
Chapter No. Yes
Track No. Yes
Time Yes
Sub Title No. Yes
Angle No. Yes
Vocal On/Off No
Audio No. Yes
Audio Stereo L/R Yes (Video CD)
Zoom Yes
Marker No. Yes
Program Play Back Yes (CD, VIDEO CD)
Surround On/Off No
Screen Saver No
JPEG Folder Name No
File Name No
File No No
Time No
Track No No
G-11 OSD Language (TV) English, French, Spanish
(DVD) English, French, Spanish
G-12 Clock and Sleep Timer Max Time 120 Min
Timer Step 10 Min
On/Off Timer Program(On Timer / Off Timer) No
Wake Up Timer No
Timer Back-up (at Power Off Mode) more than -- Min Sec
A3-3

GENERAL SPECIFICATIONS
G-13 Remote Unit RC-KG
Control Glow in Dark Remocon Yes
Remocon Format TOSHIBA
Format TOSHIBA
Custom Code 40-BF H, 44-BB H, 45-BA H, 45-BC H
Power Source Voltage(D.C) 3V
UM size x pcs UM-4 x 2 pcs
Total Keys 48 Key
Keys Power Yes
1 Yes
2 Yes
3 Yes
4 Yes
5 Yes
6 Yes
7 Yes
8 Yes
9 Yes
0 Yes
Play Yes
Stop Yes
Search+ Yes
Search- Yes
Closed Caption/Skip+ Yes
Quick View(CH RTN)/Skip- Yes
Slow+ Yes
Slow- Yes
Pause/Still/Step Yes
DISPLAY Yes
TV/DVD Yes
Cancel Yes
Audio Select Yes
Angle Yes
Subtitle Yes
Top Menu Yes
Menu Yes
DVD Menu Yes
Return Yes
CH Up Yes
CH Down Yes
Vol Down Yes
Vol Up Yes
Up/ Set+ Yes
Down/ Set- Yes
Left/Select- Yes
Right/Select+ Yes
Enter Yes
Play Mode Yes
Input Select/Zoom Yes
Repeat A-B Yes
Mute Yes
Open/Close Yes
Sleep Yes
Marker Yes
Jump Yes
Game Yes
A3-4

GENERAL SPECIFICATIONS
G-14 Features CABLE Yes
(TV) Auto Shut Off Yes
Auto Setup Yes
Auto CH Memory Yes
V-Chip USA V-chip Yes
CANADA V-chip No
Auto Search No
SAP Yes
Game Position Yes
FM Transmitter No
Energy Star No
Closed Caption Yes
Comb Filter No
Protect of FBT Leak Circuit Yes
Picture Preference Yes
Choke Coil No
Power On Memory No
Features Tray Lock Yes
(DVD) Video CD Playback Yes
SVCD Playback No
Overlay Graphics And Text No
Command List No
Entry Point Jump No
MP3 Playback No
WMA Playback No
JPEG Playback No
Digital Out (Dolby Digital) Yes
(MPEG) Yes
(PCM) Yes
(DTS) Yes
Down Mix Out (Dolby Digital) Yes
(DTS) No
3D Surround No
Screen Saver No
Audio DAC 192kHz / 24bit
G-15 Accessories Owner's Manual Language English
w/Guarantee Card Yes
Remote Control Unit Yes
Battery Yes
UM size x pcs UM-4 x 2 pcs
OEM Brand No
Rod Antenna No
Poles No
Terminal --
Loop Antenna No
Terminal --
U/V Mixer No
300 ohm to 75 ohm Antenna Adapter Yes
Antenna Change Plug No
Guarantee Card No
Registration Card Yes
Warranty Card No
ESP Card No
Service Station List No
DC Car Cord (Center+) No
Columbia Offer Sheet No
Sheet Information (Return) Yes
Netflix Card Yes [Until '05 MAR O/R]
A3-5

GENERAL SPECIFICATIONS
G-16 Interface Switch Front Power (Tact) Yes
Channel Up Yes
Channel Down Yes
Volume Up Yes
Volume Down Yes
Play Yes
Open/Close Yes
Skip+ /Search+ Yes
Skip- /Search- Yes
Still/Pause No
Stop Yes
Main Power SW No
Rear Main Power SW No
Indicator Power Yes (Red)
Stand-by No
On Timer No
Terminals Front Video Input RCA x 1
Audio Input RCA x 2(Stereo)
Other Terminal HeadPhone
Rear Video Input No
Audio Input No
Video Output No
Audio Output No
Digital Audio Output Coaxial (DVD Only)
Diversity No
DC Jack 12V(Center +) No
VHF/UHF Antenna Input F Type
G-17 Set Size Approx. W x D x H (mm) 440x392.5x393
G-18 Weight Net (Approx.) 13.5kg (29.8lbs)
Gross (Approx.) 15.5kg (34.2lbs)
G-19 Carton Master Carton No
Content --- Sets
Material --- / ---
Dimensions W x D x H(mm) ---
Description of Origin ---
Gift Box Material Double/Full Color
W/Color Photo Label No
Dimensions W x D x H(mm) 550x496x471
Description of Origin Yes
Drop Test Natural Dropping At 1 Corner / 3 Edges / 6 Surfaces
Height (cm) 62
Container Stuffing (40' container) 476 Sets
G-20 Material Cabinet Front PS 94V0 DECABROM
Rear PS 94V0 DECABROM
Jack Panel -
PCB Non-Halogen Demand No
Eyelet Demand Yes
G-21 Environment Environmental standard requirement (by buyer) Green procurement of TOSHIBA
Pb-free Phase3(Phase3A)
A3-6

DISASSEMBLY INSTRUCTIONS
B1-1
1.REMOVAL OF MECHANICAL PARTS
AND P.C. BOARDS
1-1: BACK CABINET (Refer to Fig. 1-1)
1.
2.
3.
4.
Remove the 5 screws 1.
Remove the screw 2which are used for holding the Back
Cabinet.
Remove the AC cord from the AC cord hook 3.
Remove the Back Cabinet in the direction of arrow.
1-3: AV PCB/DVD BLOCK (Refer to Fig. 1-3)
1.
2.
3.
Remove the 2 screws 1.
Disconnect the following connectors:
(CP301, CP302, CP401 and CP3800).
Remove the AV PCB/DVD Block in the direction of arrow.
Fig. 1-3
AV PCB/DVD Block
1
1
1-2: CRT PCB (Refer to Fig. 1-2)
CAUTION: BEFORE REMOVING THE ANODE CAP,
DISCHARGE ELECTRICITY BECAUSE IT
CONTAINS HIGH VOLTAGE.
BEFORE ATTEMPTING TO REMOVE OR
REPAIR ANY PCB, UNPLUG THE POWER
CORD FROM THE AC SOURCE.
1.
2.
3.
Remove the Anode Cap.
(Refer to REMOVAL OF ANODE CAP)
Disconnect the following connector:
(CP801).
Remove the CRT PCB in the direction of arrow.
CRT PCB
Front Cabinet
Fig. 1-1
Fig. 1-2
Front Cabinet
Front Cabinet
1
1
2
1
Back Cabinet
3
1
1-4: DVD BLOCK (Refer to Fig. 1-4)
1.
2.
3.
4.
5.
6.
7.
8.
Remove the 11 screws 1.
Remove the Top Shield in the direction of arrow (A).
Disconnect the following connectors:
(CP8001 and CP8002).
Remove the 4 screws 2.
Remove the DVD Block in the direction of arrow (B).
Remove the screw 3.
Remove the Jack Shield.
Remove the AV PCB in the direction of arrow (C).
Fig. 1-4
11
1
1
1
1
1
11
1
1
(A)
3
2
(B)
(C)
2
2
2
Top Shield
DVD Block
AV PCB
Bottom Plate
Jack Shield
CP801
CP301
CP302
CP401
CP3800
CP8001
CP8002
1

DISASSEMBLY INSTRUCTIONS
B1-2
1.
2.
3.
4.
5.
6.
Short circuit the position shown in Fig. 1-5 using a
soldering iron. If you remove the DVD Deck with no
soldering, the Laser may be damaged.
Remove the 4 screws 1.
Remove the DVD Deck in the direction of arrow (A).
Disconnect the following connectors:
(CP2301, CP2302 and CP2303).
Remove the 2 screws 2.
Remove the DVD PCB in the direction of arrow (B).
1-5: DVD PCB/DVD DECK (Refer to Fig. 1-5)
Fig. 1-5
DVD Deck
Deck Angle
2
2
Short circuit using a
soldering iron.
Pick Up PCB
(A)
(B)
1
11
1
DVD PCB
NOTE
Before your operation, please read “PREPARATION OF
SERVICING”.
Use the Lead Free solder.
Manual soldering conditions
• Soldering temperature: 350 ±5˚C
• Soldering time: Within 2 seconds
• Soldering combination: Sn-3.0Ag-0.5Cu
When Soldering/Removing of solder, use the drawing
equipment over the Pick Up Unit to keep the Flux smoke
away from it.
When installing the DVD Deck, remove all the soldering on
the short circuit position after the connection of Pick Up
PCB and DVD PCB connector.
1.
2.
3.
4.
5.
CP2301
CP2302
CP2303

DISASSEMBLY INSTRUCTIONS
B2-1
Loader Ass'y
Check Hook
2. REMOVAL OF DVD DECK PARTS
2-1: TRAY (Refer to Fig. 2-1-A)
Set the Tray opened. (Refer to the DISC REMOVAL
METHOD AT NO POWER SUPPLY)
Unlock the 2 supports 1and remove the Tray.
1.
2.
Fig. 2-1-A
Tray
Loader Ass'y
1
NOTE
1. In case of the Tray installation, install them as the circled
section of Fig. 2-1-B so that the each markers are met.
2-2: TRAVERSE ASS'Y (Refer to Fig. 2-2-A)
Remove the screw 1.
Unlock the 2 supports 2.
Remove the Insulator (R) from the Loader Sub Ass'y.
Remove the Traverse Ass'y.
1.
2.
3.
4.
Fig. 2-2-A
Tray
Loader Ass'y
Fig. 2-1-B
Insulator (R)
NOTE
1. Disassemble only the DVD DECK PARTS parts listed
here. Minute adjustments are needed if the disassembly
is done. If the repair is needed except listed parts, replace
the DVD MECHA ASS'Y.
1
1
2
Loader Sub Ass'y
Traverse Ass'y
2
• Screw Torque: 2.0 ±0.5kgf•cm
NOTE
1.
2.
In case of the Traverse Ass'y, install it from (1) to (4) in
order. (Refer to Fig. 2-2-B)
In case of the Traverse Ass'y installation, hook the wire
on the Loader Ass'y as shown Fig. 2-2-C.
Fig. 2-2-B
Fig. 2-2-C
(1)
(2)
(3)
(3)
(4)
(3)
Check Lock
(4)
Traverse Ass'y
Rack Loading
Loader Ass'y (Bottom Side)
Holder Traverse

DISASSEMBLY INSTRUCTIONS
B2-2
NOTE
1.
2.
3.
4.
In case of the Pulley Motor installation, check if the value
of the Fig. 2-3-B is correct.
When installing the Loading Motor, do it on the position of
Fig. 2-3-C with the following soldering conditions.
Manual soldering conditions
• Soldering temperature: 350 ±5˚C
• Soldering time: Within 4 seconds
• Soldering combination: Sn-3.0Ag-0.5Cu
When installing the Loading Motor PCB Ass'y, install it
correctly as Fig. 2-3-C.
In case of the Loading Motor PCB Ass'y installation, hook
the wire on the Traverse Ass'y as shown Fig. 2-3-C.
Fig. 2-3-B
7.0 ±0.1mm
Safety surface for pressing
of the insert.
Loading Motor
Pulley Motor
Fig. 2-3-C
Rack Loading AB
The Lever should be position
between A and B.
Check Hook
2-4: RACK LOADING/GEAR MAIN/GEAR PULLEY
(Refer to Fig. 2-4-A)
1.
2.
3.
Press down the catcher 1and slide the Rack Loading.
Unlock the support 2and remove the Gear Pulley.
Remove the Gear Main.
Loading Motor PCB Ass’y
Loading Belt
Pulley Motor
1
Loader Sub Ass’y
2-3: LOADING MOTOR PCB ASS'Y/ LOADING BELT
(Refer to Fig. 2-3-A)
1.
2.
3.
4.
5.
Remove the Loading Belt.
Remove the screw 1.
Remove the 2 screws 2.
Remove the Loading Motor PCB Ass'y.
Remove the Pulley Motor.
Fig. 2-3-A
22
Loading Motor PCB Ass’y
• Screw Torque: 2.5 ±0.3kgf•cm (Screw 1)
• Screw Torque: 1.0 ±0.3kgf•cm (Screw 2)
Rack Loading
1
Main Frame
Gear Main
Gear Pulley
2
Fig. 2-4-A
Fig. 2-4-B
NOTE
1. In case of the Rack Loading installation, do not mesh it
to the Gear Main as shown the Fig. 2-4-B.
Check Hook
Gear Main
Rack Loading
2-5: CLAMPER ASS'Y (Refer to Fig. 2-5-A)
Press the Clamper and rotate the Plate Clamper
clockwise, then unlock the 3 supports 1.
Remove the Clamper Plate, Magnet Clamper and
Clamper.
1.
2.
Plate Clamper
Magnet Clamper
Fig. 2-5-A
Main Frame
Clamper
1
1
1
NOTE
1. In case of the Clamper Ass'y installation, install correctly
as Fig. 2-5-B.
Fig. 2-5-B
No gap
Plate Clamper
Clamper
Soldering
